DRV8846 Evaluation Module
This document is provided with the DRV8846 customer evaluation module (EVM) as a supplement to the
DRV8846 (SLLSEK2) datasheet. It details the hardware implementation of the EVM.
Contents
1 PCB (Top View).............................................................................................................. 2
2 Introduction ................................................................................................................... 2
2.1 Connectors .......................................................................................................... 2
2.2 Test Points........................................................................................................... 3
2.3 Jumpers.............................................................................................................. 4
2.4 Motor Outputs ....................................................................................................... 4
2.5 Operation of the EVM .............................................................................................. 4
2.6 Motor Control Frame (Includes Start/Stop Steps and Move Steps).......................................... 6
2.7 Schematic and Bill of Materials (BOM) .......................................................................... 9
Appendix A Driver Installation Instructions ................................................................................... 12
List of Figures
1 Connections .................................................................................................................. 3
2 DRV8846 Schematic (1 of 2)............................................................................................... 9
3 DRV8846 Schematic (2 of 2) ............................................................................................. 10
1
SLLU203A–June 2014–Revised March 2015 DRV8846 Evaluation Module
Submit Documentation Feedback Copyright © 2014–2015, Texas Instruments Incorporated

PCB (Top View) www.ti.com
1 PCB (Top View)
2 Introduction
The DRV8846 customer EVM is a platform revolving around the DRV8846, a low voltage dual H-bridge
driver and highly configurable power stage. This device has been optimized to drive a single bipolar
stepper with up to 32 degrees of internally generated microstepping.
The EVM houses an MSP430 microcontroller and a USB interface chip. The USB chip allows for serial
communications from a PC computer where a Microsoft®Windows®application is used to schedule serial
commands. These commands can be used to control each of the device’s signals, and drive the stepper
motor by issuing the step commands at the desired rate.
The microcontroller firmware operates using internal index mode.
This user's guide details the operation of the EVM, as well as the hardware configurability of the
evaluation module.
2.1 Connectors
The DRV8846EVM offers access to VM (motor voltage) power rail via a terminal block (J1). A set of test
clips in parallel with the terminal block allows for the monitoring of the input power rail.
Apply VM according to datasheet-recommended parameters.
NOTE: VDD for the microcontroller is derived from the micro USB connector.
Microsoft, Windows are registered trademarks of Microsoft Corporation.
2DRV8846 Evaluation Module SLLU203A–June 2014–Revised March 2015
Submit Documentation Feedback
Copyright © 2014–2015, Texas Instruments Incorporated

www.ti.com Introduction
Figure 1. Connections
2.2 Test Points
A 0.100 in pitch header connector (J4) is used to provide access to every device signal in the event a
different microcontroller is to be employed. To disconnect the internal MSP430 microcontroller, remove
resistor packs R5 and R6. Table 1 describes the connections available on the J4 header. Each header pin
is labeled on the evaluation module, and matches the pin of the DRV8846.
Table 1. Descriptions of the Connections Available on the J4 Header
Header Label Description
V3P3R 3.3 V after 33-Ωresistor
nFAULT Fault output
nSLEEP Sleep Mode input
RSVD Adaptive DECay input
DIR Direction input
nENBL Stepper motor enable
STEP Step input
M0 Step mode
M1 Step mode
TOFF_SEL Off-time selection
VREF Scale voltage to set IFS
VINT Internal supply voltage
I0 Torque (current level)
I1 Torque (current level)
DEC0 Decay mode
DEC1 Decay mode
GND Ground
GND Ground
3
SLLU203A–June 2014–Revised March 2015 DRV8846 Evaluation Module
Submit Documentation Feedback Copyright © 2014–2015, Texas Instruments Incorporated

VINT
VREF    (VREF _ slider 4)
4095
= ´ ´
VREF
I    TORQUE StepModifier
FS 6.6 RISENSE
= ´ ´
´
Introduction www.ti.com
2.3 Jumpers
There are no jumpers on the DRV8846EVM module.
2.4 Motor Outputs
Two motor connectors are provided. Connectors J2 and J3 are available as shown in Figure 1.
2.5 Operation of the EVM
Use the following steps to operate the EVM.
1. Install the drivers and GUI. Refer to Appendix A at the end of this document for instructions.
2. Connect the wires of the stepper motor to terminals AOUT1, AOUT2, BOUT1, and BOUT2.
3. Connect the VM power supply but do not apply power at this step.
4. Connect the USB between the PC and the EVM. Open the GUI by selecting the launcher.exe file. It
may take up to 15 seconds to establish connection.
(a) Once the USB connection is established, the Status LED will begin to blink.
5. Apply 12 V to the VM and GND connections.
6. Configure the current settings, step and decay modes, torque, and pwm off time as desired as shown
in the following image:
The current is calculated using the VREF slider, the Sense resistor value, the Torque setting, and the
Step mode setting using the formula.
(1)
Where StepModifier is 0.71 for full step and 1.0 for other STEP MODE settings
The 12-bit DAC channel 0 is connected to the DRV8846 analog input VREF. Changing the DAC digital
value from 0 to 4092 in steps of 4, changes the analog voltage at the VREF pin from 0 V to VINT V.
See Equation 2.
(2)
Where VINT is the output of the DRV8846 pin and VREF_slider is the slider value from 0 to 1023.
4DRV8846 Evaluation Module SLLU203A–June 2014–Revised March 2015
Submit Documentation Feedback
Copyright © 2014–2015, Texas Instruments Incorporated

www.ti.com Introduction
7. Wake and Enable the device for operation.
(a) After setting up the controls signals for the DRV8846, enabling the DRV8846 requires selecting
both the WAKE and ENABLE buttons. When the WAKE button or ENABLE button are selected, the
circle to the left of the button will toggle from red to green.
(b) The WAKE button, which controls the nSLEEP pin, is used to wake the DRV8846. The ENABLE
button, which controls the nENBL pin, is used to enable the DRV8846 outputs.
(c) A message which states that *Both WAKE and ENABLE must be Green to enable the motor control
buttons will be visible until both the WAKE and ENABLE buttons are activated. Once these two
buttons have been activated, the message disappears and the Start/Stop and Move Steps buttons
will be available.
(d) If the WAKE or ENABLE buttons are selected during motor operation, the motor is immediately
stopped and the STEP control signal from the microcontroller is reset.
8. The DRV8846 EVM is now awake and can be commanded to turn the motor. This can be done by
either selecting the Start/Stop Steps,Move # of Steps, or Reciprocate buttons.
The Start/Stop Steps button is used to run the motor indefinitely. The motor will accelerate to the target
speed and run until the Start/Stop Steps button is selected. When the Start/Stop Steps button is
selected, the red button will change to green, and the Move Steps and Reciprocate buttons will be
disabled.
The Move Steps button is used to allow movement of an exact number of steps. When the Move Steps
button is selected, the red button to the left of Move Steps will turn green, and the Start/Stop Steps and
Reciprocate buttons are disabled until the number of steps have completed.
The Reciprocate button is a special case of the Move Steps. When selected, the motor will advance
the specified number of steps in the direction initially set by the control inputs. After a short pause, the
motor will then advance the same number of steps in the opposite direction. This sequence is repeated
until the Reciprocate button is selected.
When the Reciprocate button is selected, the red button to the left of Reciprocate will turn green, and
the Start/Stop Steps and Move # of Steps buttons are disabled until the number of steps have
completed.
5
SLLU203A–June 2014–Revised March 2015 DRV8846 Evaluation Module
Submit Documentation Feedback Copyright © 2014–2015, Texas Instruments Incorporated

Introduction www.ti.com
2.6 Motor Control Frame (Includes Start/Stop Steps and Move Steps)
The GUI has an area which offers access to a series of very useful stepper control algorithms. This area
allows for determining the best current settings during running at various speeds, and when holding torque
is applied.
Motor motion can only happen by using an acceleration profile which will be detailed later on. A detailed
explanation of each stepper control section follows.
This frame allows the configuration and running of the stepper with the direction as specified by the DIR
checkbox, with the current decay mode as specified under the Decay Mode checkbox and the
microstepping resolution as specified under the Step Mode drop down box.
6DRV8846 Evaluation Module SLLU203A–June 2014–Revised March 2015
Submit Documentation Feedback
Copyright © 2014–2015, Texas Instruments Incorporated

Stopping SpeedStarting Speed
Steps to Stop
Number of Steps
Acceleration Rate
Target Speed
www.ti.com Introduction
The Motion Control frame gathers user information regarding stepping rate, or motor speed. An
acceleration profile is employed to start at a programmable speed and increase stepping rate until
reaching the programmable desired speed.
An internal 8-MHz timer is used to measure time and generate the steps on a timely manner. The GUI will
send the information to the microcontroller as PPS, and the microcontroller will transform it into the
respective clock cycles needed for the timer to generate accurate STEP pulse timing.
2.6.1 Start/Stop Steps
The acceleration profile is coded inside of the microcontroller to accept both the starting speed PPS and
target speed PPS as a clock cycle number. When the start steps command is issued (Starts/Steps button
is selected), the PWM timer generates steps at a rate specified by the start speed PPS parameter.
When accelerating or decelerating, PPS is adjusted every 32 ms, based on the integer value of PPSPS/32
ms. If a non-zero value of PPSPS is entered, a minimum value of 1 is used. The step rate is increased by
the calculated value until the target speed is reached.
The very same start steps command computes how frequent automatic speed updates are issued and a
second timer is used to change the speed according to the programmed acceleration rate profile.
Once the target speed (PPS) is reached, the acceleration profile ends and the motor stays running until
the stop stepper command is issued (Start/Stop Steps button is selected again). When the stepper is
commanded to stop, the controller does exactly as it did while accelerating, but in reverse to decelerate
until the stop speed PPS is reached, in which case the motor fully stops.
A second motor actuation is provided by the Move # of Steps and Reciprocate commands in which a
programmed number of steps are issued and then the motor stopped. The acceleration and deceleration
profiles work similarly as before, except when the deceleration starts and when the motor actually stops
are a function of the Steps to Stop and deceleration rate parameters.
This second motor actuation is adjusted automatically for rising edge or rising and falling edge settings in
the STEP MODE.
The following figure shows the acceleration profile and the role each parameter plays during speed
computation:
2.6.2 Move Steps
If the user desires to move the stepper a certain number of steps, this can be accomplished by using the
move steps function. Parameters from the other frames are reused and its utilization is as explained
previously. Two new parameters have been added to properly control the limited number of steps
actuation.
Number of Steps: Number of steps the controller will issue.
Steps to Stop: The controller is continuously monitoring the step being issued and when the current step
is equal to the steps to stop parameter, a deceleration profile is issued. If Steps to Stop is larger than the
number of steps, then the motor stops abruptly and without undergoing a deceleration profile.
When a deceleration profile is issued, the controller decreases the speed until reaching the stop speed
value. If the number of steps parameter is met before the deceleration profile is complete, then the motor
stops at the current speed. If the stop speed is met before all the number of steps is issued, then the
motor rotates at the stop speed value until all the steps are executed.
7
SLLU203A–June 2014–Revised March 2015 DRV8846 Evaluation Module
Submit Documentation Feedback Copyright © 2014–2015, Texas Instruments Incorporated

Introduction www.ti.com
Ideally, the system should be tuned to resemble the case in which the controller executes all the
commanded steps at a speed as close as possible to the stop speed. In the event this is not possible, due
to the particular parameters being chosen, stopping the motor at a speed very close to the stop speed is
often good enough to ensure good motion quality and application performance.
The following figure shows the three conditions possible when stopping and the action taken:
8DRV8846 Evaluation Module SLLU203A–June 2014–Revised March 2015
Submit Documentation Feedback
Copyright © 2014–2015, Texas Instruments Incorporated

1
1
2
2
3
3
4
4
5
5
6
6
D D
C C
B B
A A
1 1
5/13/2014
DRV8846EVM_RevA.SchDoc
Sheet Title:
Size:
Mod. Date:
File:
Sheet: of
Bhttp://www.ti.com
Contact: http://www.ti.com/support
DRV8846EVMProject Title:
Designed for: Public Release
Assembly Variant: 001
© Tex as Instruments 2014
Drawn By:
Engineer: Rick Duncan
Texas Instruments and/or its licensors do not warrant the accuracy or completeness of this specification or any information contained therein. Te xas Instruments and/or its licensors do not
warrant that this design will meet the specifications, will be suitable for your application or fit for any particular purpose, or will operate in an implementation. Texas Instruments and/or its
licensors do not warrant that the design is production worthy. You should completely validate and test your design implementation to confirm the system functionality for your application.
Not in version controlSVN Rev:
DRV8846EVMNumber: Rev: A
10µF
C1
VM
AOUT2
AOUT1
TOFF_SEL
10
nENBL
11
STEP
12 DIR 13
VREF 14
VM 15
NC 16
VINT 17
GND 18
ADEC 19
I0 20
I1 21
DEC0 22
nSLEEP 23
DEC1 24
PPAD
25
AOUT1
1
AISEN
2
AOUT2
3
BOUT2
4
BISEN
5
BOUT1
6
nFAULT
7
MO
8
M1
9
U1
DRV8846RGE
DEC1
GND
AOUT1
DEC0
GND
AOUT2
BOUT1
BISEN
BOUT2
DRV8846
nFAULT notification
GND
nFAULT
C
1A2
D1
D_LED_603_RED
0.1µF
C2
2.2µF
C3
1
2
J1
ED555/2DS
nSLEEP
nFAULT
4.99k
R3
BOUT1
BOUT2
VM
AISEN
VINT
VREF
DIR
I1
I0
M0
M1
TOFF_SEL
nENBL
STEP
ADEC
0.25
R1
0.25
R2
GND
510
R4
1
2
J2
ED555/2DS
1
2
J3
ED555/2DS
MSP_M1
MSP_TOFF_SEL
MSP_VREF
MSP_VINT
MSP_I0
MSP_I1
MSP_DEC0
MSP_DEC1
MSP_nFAULT
MSP_nSLEEP
MSP_ADEC
MSP_DIR
MSP_nENBL
MSP_STEP
MSP_M0
nSLEEP
ADEC
DIR
nENBL
STEP
M0
M1
TOFF_SEL
VREF
VINT
I0
I1
DEC0
DEC1
1
2
3
4
5
6
7
89
10
11
12
13
14
15
16
R5
EXB-2HV330JV
1
2
3
4
5
6
7
89
10
11
12
13
14
15
16
R6
EXB-2HV330JV
DEC1
DEC0
I1
I0
VINT
VREF
TOFF_SEL
M1
DIR
M0
STEP
nENBL
ADEC
nSLEEP
nFAULT
AOUT1 AOUT2
TEST POINTS & DEBUG MODE
BOUT1 BOUT2
VM
VM GND2 AOUT1 AOUT2 BOUT1 BOUT2
GNDGND
nFAULT
Remove R4 to
disable current flow
through diode
Motor Supply and
Outputs
VM range 4 to 16V
Connection to microcontroller
or external interface
Notes:
1) For normal operation, populate resistor packs R5 and R6
2) For external control, remove resistor packs R5,R6 and provide signals at J4
3) Signals can be observed at J4 during normal operation
GND
1GND 2
GND1
D3082-05
GND
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
J4
HEADER_1X18
V3P3R
V3P3
V3P3R
V3P3R
GND
0.1µF
C12
GND
www.ti.com Introduction
2.7 Schematic and Bill of Materials (BOM)
2.7.1 DRV8846 Schematic
Figure 2 and Figure 3 illustrate the schematics for this EVM.
Figure 2. DRV8846 Schematic (1 of 2)
9
SLLU203A–June 2014–Revised March 2015 DRV8846 Evaluation Module
Submit Documentation Feedback Copyright © 2014–2015, Texas Instruments Incorporated

1
1
2
2
3
3
4
4
5
5
6
6
D D
C C
B B
A A
1 1
5/13/2014
DRV8846EVM_MSP430F2617_RevA.SchDoc
Sheet Title:
Size:
Mod. Date:
File:
Sheet: of
Bhttp://www.ti.com
Contact: http://www.ti.com/support
DRV8846EVMProject Title:
Designed for: Public Release
Assembly Variant: 001
© Tex as Instruments 2014
Drawn By:
Engineer: Rick Duncan
Texas Instruments and/or its licensors do not warrant the accuracy or completeness of this specification or any information contained therein. Te xas Instruments and/or its licensors do not
warrant that this design will meet the specifications, will be suitable for your application or fit for any particular purpose, or will operate in an implementation. Texas Instruments and/or its
licensors do not warrant that the design is production worthy. You should completely validate and test your design implementation to confirm the system functionality for your application.
Not in version controlSVN Rev:
DRV8846EVMNumber: Rev: A
MSP430 w JTAG Interface
USB TO UART
1
2
3
4
5
6
7
10
11
8
9
J6
ZX62-B-5PA(11)
TXD
1
DTR#
2
RTS#
3
VCCIO
4
RXD
5
RI#
6
GND
7
NC
8
DSR#
9
DCD#
10
CTS#
11
CBUS4
12
CBUS2
13
CBUS3
14 USBDP 15
USBDM 16
3V3OUT 17
GND 18
RST# 19
VCC 20
GND 21
CBUS1 22
CBUS0 23
NC 24
AGND 25
TEST 26
OSCI 27
OSCO 28
U3
FT232RL
0.1µF
C9
GND
V3P3
1 2
L1
MI0805K400R-10
GND
GND
RX
TX
TX
RX
V3P3
DVCC
1
P6.3/A3
2
P6.4/A4
3
P6.5/A5
4
P6.6/A6
5
P6.7/A7/SVSIN
6
VREF+
7
XIN
8
XOUT
9
VEREF+
10
VREF-/VEREF-
11
P1.0/TACLK/CAOUT
12
P1.1/TA0
13
P1.2/TA1
14
P1.3/TA2
15
P1.4/SMCLK
16
P1.5/TA0
17
P1.6/TA1
18
P1.7/TA2
19
P2.0/ACLK/CA2
20
P2.1/TAINCLK/CA3
21
P2.2/CAOUT/TA0/CA4
22
P2.3/CA0/TA1
23
P2.4/CA1/TA2
24
P2.5/ROSC/CA5
25
P2.6/ADC12CLK/CA6
26
P2.7/TA0/CA7
27
P3.0/UCB0STE/UCA0CLK
28
P3.1/UCB0SIMO/UCB0SD
29
P3.2/UCB0SOMI/UCB0SC
30
P3.3/UCB0CLK/UCA0STE
31
P3.4/UCA0TXD/UCA0SIM
32
P3.5/UCA0RXD 33
P3.6 34
P3.7 35
P4.0/TB0 36
P4.1/TB1 37
P4.2/TB2 38
P4.3 39
P4.4 40
P4.5 41
P4.6 42
P4.7/TBCLK 43
P5.0 44
P5.1 45
P5.2 46
P5.3 47
P5.4/MCLK 48
P5.5/SMCLK 49
P5.6/ACLK 50
P5.7/TBOUTH/SVSOUT 51
XT2OUT 52
XT2IN 53
TDO/TDI 54
TDI/TCLK 55
TMS 56
TCK 57
RST/NMI 58
P6.0/A0 59 P6.1/A1 60 P6.2/A2 61
AVSS 62
DVSS 63
AVCC 64
U2
MSP430F2617TPMR
GND
GND
GND
RST
V3P3
3.32k
R8
1 2
3 4
5 6
7 8
9 10
11 12
13 14
J5
PEC07DAAN
V3P3
MSP_DEC0
MSP_I1
MSP_I0
MSP_TOFF_SEL
MSP_M1
MSP_M0
GND
FTDI regulator used for 3.3V
STATUS
MSP_VREF
MSP_BVREF
330
R7
GND
STATUS
GND
RST
C
1A2
D2
4
1
3
2
S1
EVQP1D05M
MSP_CA7 MSP_DEC1
MSP_nFAULT
MSP_nSLEEP
MSP_ADEC
MSP_DIR
MSP_nENBL
MSP_STEP
MSP_VINT
GND
0.1µF
C10
0.1µF
C4
DM
DP
VBUS
0.1µF
C5
4.7µF
C11
0
R10
0
R9
DNP
DNP R9. If debug or
programming adapter is used
to power the MSP430,
remove R10 and populate R9
1µF
C8
GND
Introduction www.ti.com
Figure 3. DRV8846 Schematic (2 of 2)
10 DRV8846 Evaluation Module SLLU203A–June 2014–Revised March 2015
Submit Documentation Feedback
Copyright © 2014–2015, Texas Instruments Incorporated

www.ti.com Introduction
2.7.2 Bill of Materials (BOM)
Table 2 lists the BOM for this EVM.
Table 2. DRV8846 Bill of Materials
Designator Description Manufacturer PartNumber Qty
!PCB Printed Circuit Board Any DRV8846EVM 1
AOUT1, AOUT2, Test Point, Compact, SMT Keystone 5016 6
BOUT1, BOUT2,
GND2, VM
C1 CAP, CERM, 10uF, 35V, +/-20%, X7R, 1210 Taiyo Yuden GMK325AB7106MM-T 1
C2 CAP, CERM, 0.1uF, 50V, +/-10%, X7R, 0603 AVX 06035C104KAT2A 1
C3 CAP, CERM, 2.2uF, 25V, +/-10%, X5R, 0402 TDK C1005X5R1E225K050BC 1
C4, C5, C9, C10 CAP, CERM, 0.1uF, 10V, +/-10%, X5R, 0402 MuRata GRM155R61A104KA01D 4
C8 CAP, CERM, 1uF, 10V, +/-10%, X5R, 0402 MuRata GRM155R61A105KE15D 1
C11 CAP, CERM, 4.7uF, 10V, +/-10%, X5R, 0603 TDK CGB3B1X5R1A475K055AC 1
C12 CAP, CERM, 0.1uF, 6.3V, +/-10%, X5R, 0402 TDK C1005X5R0J104K 1
D1 Diode, LED, Red, 2.1-V, 20-mA, 6-mcd Lite On LTST-C190CKT 1
D2 Diode, LED, Green, 2.1-V, 20-mA, 6-mcd Lite On LTST-C190GKT 1
GND1 Shorting Plug Harwin D3082-05 1
J1, J2, J3 Terminal Block, 6A, 3.5mm Pitch, 2-Pos, TH On-Shore Technology ED555/2DS 3
J4 Header, Male 18-pin, 100mil spacing, STD PEC18SAAN 1
J5 Header, 100mil, 7x2, Tin plated, TH Sullins Connector Solutions PEC07DAAN 1
J6 Connector, micro USB Type B, Receptacle, R/A, SMD Hirose Electric Co. Ltd. ZX62-B-5PA(11) 1
L1 Bead, Ferrite, yymA Steward MI0805K400R-10 1
R1, R2 RES, 0.25 ohm, 1%, 1W, 2010 Stackpole Electronics Inc CSRN2010FKR250 2
R3 RES, 4.99k ohm, 1%, 0.063W, 0402 Vishay-Dale CRCW04024K99FKED 1
R4 RES, 510 ohm, 5%, 0.063W, 0402 Vishay-Dale CRCW0402510RJNED 1
R5, R6 RES, 33 ohm, 5%, 0.0625W, Resistor Array - 8x1 Panasonic EXB-2HV330JV 2
R7 RES, 330 ohm, 5%, 0.063W, 0402 Vishay-Dale CRCW0402330RJNED 1
R8 RES, 3.32k ohm, 1%, 0.063W, 0402 Vishay-Dale CRCW04023K32FKED 1
R10 RES, 0 ohm, 5%, 0.063W, 0402 Panasonic ERJ-2GE0R00X 1
S1 Switch, Tactile, SPST-NO, 0.05A, 12V, SMT Panasonic EVQP1D05M 1
U1 IC, Motor Driver Texas Instruments DRV8846RGE 1
U2 IC, Mixed Signal Microcontroller, xKB+256B Flash Memory, 1KB TI MSP430F2617TPMR 1
RAM
U3 IC, USB UART Future Techonology Devices FT232RL 1
11
SLLU203A–June 2014–Revised March 2015 DRV8846 Evaluation Module
Submit Documentation Feedback Copyright © 2014–2015, Texas Instruments Incorporated

Appendix A
SLLU203A–June 2014–Revised March 2015
Driver Installation Instructions
1. Installing the DRV8846 Evaluation Board Application Software:
Download and install the latest version (must be v5.5 or later) of GUI Composer Runtime. Register for
a TI account if you don’t already have one. The link to GUI Composer Runtime is:
http://processors.wiki.ti.com/index.php/Category:GUI_Composer#GUI_Composer_Downloads
2. Installing the FTDI Driver:
Download the driver from the DRV8846EVM software file (SLLC446), in the DRV8846EVM folder.
Unzip it and install the USB driver:
• If using Windows XP, run \USB driver\CDM v2.10.00 WHQL Certified.exe
• If using Windows 7, go to the folder \USB driver\, right-click CDM v2.10.00 WHQL Certified.exe,
select Properties, go to the Compatibility tab, check “Run this program in compatibility mode for”,
select “Windows XP (Service Pack 2)”, OK. Then, run CDM v2.10.00 WHQL Certified.exe and click
“Yes” in the pop-up window.
3. Running the Application Software:
Go to the unzipped folder \Application\ and move the folder DRV8846EVM_GUIv1.0 into the
C:\ti\guicomposer\webapps\ directory. (Note: if you chose a non-default installation directory in Step 1,
the C:\ti\ part will be different.) When completed as desired, a shortcut can be created to
C:\ti\guicomposer\webapps\DRV8846EVM_GUIv1.0\launcher.exe by clicking and dragging the file
while holding the Alt key.
When complete, the folder C:\ti\guicomposer\webapps\DRV8846EVM_GUIv1.0 should exist with the
following files in the folder:
Name Type
.settings File folder
Images File folder
.appsettings APPSETTINGS File
app.css Cascading Style Sheets
app.html HTML Document
app.js JScript Script File
app.json JSON File
appInitScript.js JScript Script File
appProgram.out OUT File
index.html HTML Document
launcher File
launcher.exe Application
Revision History
Changes from Original (June 2014) to A Revision ......................................................................................................... Page
• Changed caption, fixed typo............................................................................................................ 10
• Changed format, new template. ....................................................................................................... 12
NOTE: Page numbers for previous revisions may differ from page numbers in the current version.
12 Driver Installation Instructions SLLU203A–June 2014–Revised March 2015
Submit Documentation Feedback
Copyright © 2014–2015, Texas Instruments Incorporated

STANDARD TERMS AND CONDITIONS FOR EVALUATION MODULES
1. Delivery: TI delivers TI evaluation boards, kits, or modules, including any accompanying demonstration software, components, or
documentation (collectively, an “EVM” or “EVMs”) to the User (“User”) in accordance with the terms and conditions set forth herein.
Acceptance of the EVM is expressly subject to the following terms and conditions.
1.1 EVMs are intended solely for product or software developers for use in a research and development setting to facilitate feasibility
evaluation, experimentation, or scientific analysis of TI semiconductors products. EVMs have no direct function and are not
finished products. EVMs shall not be directly or indirectly assembled as a part or subassembly in any finished product. For
clarification, any software or software tools provided with the EVM (“Software”) shall not be subject to the terms and conditions
set forth herein but rather shall be subject to the applicable terms and conditions that accompany such Software
1.2 EVMs are not intended for consumer or household use. EVMs may not be sold, sublicensed, leased, rented, loaned, assigned,
or otherwise distributed for commercial purposes by Users, in whole or in part, or used in any finished product or production
system.
2Limited Warranty and Related Remedies/Disclaimers:
2.1 These terms and conditions do not apply to Software. The warranty, if any, for Software is covered in the applicable Software
License Agreement.
2.2 TI warrants that the TI EVM will conform to TI's published specifications for ninety (90) days after the date TI delivers such EVM
to User. Notwithstanding the foregoing, TI shall not be liable for any defects that are caused by neglect, misuse or mistreatment
by an entity other than TI, including improper installation or testing, or for any EVMs that have been altered or modified in any
way by an entity other than TI. Moreover, TI shall not be liable for any defects that result from User's design, specifications or
instructions for such EVMs. Testing and other quality control techniques are used to the extent TI deems necessary or as
mandated by government requirements. TI does not test all parameters of each EVM.
2.3 If any EVM fails to conform to the warranty set forth above, TI's sole liability shall be at its option to repair or replace such EVM,
or credit User's account for such EVM. TI's liability under this warranty shall be limited to EVMs that are returned during the
warranty period to the address designated by TI and that are determined by TI not to conform to such warranty. If TI elects to
repair or replace such EVM, TI shall have a reasonable time to repair such EVM or provide replacements. Repaired EVMs shall
be warranted for the remainder of the original warranty period. Replaced EVMs shall be warranted for a new full ninety (90) day
warranty period.
3Regulatory Notices:
3.1 United States
3.1.1 Notice applicable to EVMs not FCC-Approved:
This kit is designed to allow product developers to evaluate electronic components, circuitry, or software associated with the kit
to determine whether to incorporate such items in a finished product and software developers to write software applications for
use with the end product. This kit is not a finished product and when assembled may not be resold or otherwise marketed unless
all required FCC equipment authorizations are first obtained. Operation is subject to the condition that this product not cause
harmful interference to licensed radio stations and that this product accept harmful interference. Unless the assembled kit is
designed to operate under part 15, part 18 or part 95 of this chapter, the operator of the kit must operate under the authority of
an FCC license holder or must secure an experimental authorization under part 5 of this chapter.
3.1.2 For EVMs annotated as FCC – FEDERAL COMMUNICATIONS COMMISSION Part 15 Compliant:
CAUTION
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to
operate the equipment.
FCC Interference Statement for Class A EVM devices
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to
correct the interference at his own expense.
SPACER
SPACER
SPACER
SPACER
SPACER
SPACER
SPACER
SPACER

FCC Interference Statement for Class B EVM devices
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
3.2 Canada
3.2.1 For EVMs issued with an Industry Canada Certificate of Conformance to RSS-210
Concerning EVMs Including Radio Transmitters:
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this device must accept any interference, including interference that may
cause undesired operation of the device.
Concernant les EVMs avec appareils radio:
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation
est autorisée aux deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit
accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
Concerning EVMs Including Detachable Antennas:
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser)
gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type
and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for
successful communication. This radio transmitter has been approved by Industry Canada to operate with the antenna types
listed in the user guide with the maximum permissible gain and required antenna impedance for each antenna type indicated.
Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited
for use with this device.
Concernant les EVMs avec antennes détachables
Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec une antenne d'un type et
d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage
radioélectrique à l'intention des autres utilisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope
rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une communication satisfaisante. Le
présent émetteur radio a été approuvé par Industrie Canada pour fonctionner avec les types d'antenne énumérés dans le
manuel d’usage et ayant un gain admissible maximal et l'impédance requise pour chaque type d'antenne. Les types d'antenne
non inclus dans cette liste, ou dont le gain est supérieur au gain maximal indiqué, sont strictement interdits pour l'exploitation de
l'émetteur
3.3 Japan
3.3.1 Notice for EVMs delivered in Japan: Please see http://www.tij.co.jp/lsds/ti_ja/general/eStore/notice_01.page 日本国内に
輸入される評価用キット、ボードについては、次のところをご覧ください。
http://www.tij.co.jp/lsds/ti_ja/general/eStore/notice_01.page
3.3.2 Notice for Users of EVMs Considered “Radio Frequency Products” in Japan: EVMs entering Japan may not be certified
by TI as conforming to Technical Regulations of Radio Law of Japan.
If User uses EVMs in Japan, not certified to Technical Regulations of Radio Law of Japan, User is required by Radio Law of
Japan to follow the instructions below with respect to EVMs:
1. Use EVMs in a shielded room or any other test facility as defined in the notification #173 issued by Ministry of Internal
Affairs and Communications on March 28, 2006, based on Sub-section 1.1 of Article 6 of the Ministry’s Rule for
Enforcement of Radio Law of Japan,
2. Use EVMs only after User obtains the license of Test Radio Station as provided in Radio Law of Japan with respect to
EVMs, or
3. Use of EVMs only after User obtains the Technical Regulations Conformity Certification as provided in Radio Law of Japan
with respect to EVMs. Also, do not transfer EVMs, unless User gives the same notice above to the transferee. Please note
that if User does not follow the instructions above, User will be subject to penalties of Radio Law of Japan.
SPACER
SPACER
SPACER
SPACER
SPACER

【無線電波を送信する製品の開発キットをお使いになる際の注意事項】 開発キットの中には技術基準適合証明を受けて
いないものがあります。 技術適合証明を受けていないもののご使用に際しては、電波法遵守のため、以下のいずれかの
措置を取っていただく必要がありますのでご注意ください。
1. 電波法施行規則第6条第1項第1号に基づく平成18年3月28日総務省告示第173号で定められた電波暗室等の試験設備でご使用
いただく。
2. 実験局の免許を取得後ご使用いただく。
3. 技術基準適合証明を取得後ご使用いただく。
なお、本製品は、上記の「ご使用にあたっての注意」を譲渡先、移転先に通知しない限り、譲渡、移転できないものとします。
上記を遵守頂けない場合は、電波法の罰則が適用される可能性があることをご留意ください。 日本テキサス・イ
ンスツルメンツ株式会社
東京都新宿区西新宿６丁目２４番１号
西新宿三井ビル
3.3.3 Notice for EVMs for Power Line Communication: Please see http://www.tij.co.jp/lsds/ti_ja/general/eStore/notice_02.page
電力線搬送波通信についての開発キットをお使いになる際の注意事項については、次のところをご覧くださ
い。http://www.tij.co.jp/lsds/ti_ja/general/eStore/notice_02.page
SPACER
4EVM Use Restrictions and Warnings:
4.1 EVMS ARE NOT FOR USE IN FUNCTIONAL SAFETY AND/OR SAFETY CRITICAL EVALUATIONS, INCLUDING BUT NOT
LIMITED TO EVALUATIONS OF LIFE SUPPORT APPLICATIONS.
4.2 User must read and apply the user guide and other available documentation provided by TI regarding the EVM prior to handling
or using the EVM, including without limitation any warning or restriction notices. The notices contain important safety information
related to, for example, temperatures and voltages.
4.3 Safety-Related Warnings and Restrictions:
4.3.1 User shall operate the EVM within TI’s recommended specifications and environmental considerations stated in the user
guide, other available documentation provided by TI, and any other applicable requirements and employ reasonable and
customary safeguards. Exceeding the specified performance ratings and specifications (including but not limited to input
and output voltage, current, power, and environmental ranges) for the EVM may cause personal injury or death, or
property damage. If there are questions concerning performance ratings and specifications, User should contact a TI
field representative prior to connecting interface electronics including input power and intended loads. Any loads applied
outside of the specified output range may also result in unintended and/or inaccurate operation and/or possible
permanent damage to the EVM and/or interface electronics. Please consult the EVM user guide prior to connecting any
load to the EVM output. If there is uncertainty as to the load specification, please contact a TI field representative.
During normal operation, even with the inputs and outputs kept within the specified allowable ranges, some circuit
components may have elevated case temperatures. These components include but are not limited to linear regulators,
switching transistors, pass transistors, current sense resistors, and heat sinks, which can be identified using the
information in the associated documentation. When working with the EVM, please be aware that the EVM may become
very warm.
4.3.2 EVMs are intended solely for use by technically qualified, professional electronics experts who are familiar with the
dangers and application risks associated with handling electrical mechanical components, systems, and subsystems.
User assumes all responsibility and liability for proper and safe handling and use of the EVM by User or its employees,
affiliates, contractors or designees. User assumes all responsibility and liability to ensure that any interfaces (electronic
and/or mechanical) between the EVM and any human body are designed with suitable isolation and means to safely
limit accessible leakage currents to minimize the risk of electrical shock hazard. User assumes all responsibility and
liability for any improper or unsafe handling or use of the EVM by User or its employees, affiliates, contractors or
designees.
4.4 User assumes all responsibility and liability to determine whether the EVM is subject to any applicable international, federal,
state, or local laws and regulations related to User’s handling and use of the EVM and, if applicable, User assumes all
responsibility and liability for compliance in all respects with such laws and regulations. User assumes all responsibility and
liability for proper disposal and recycling of the EVM consistent with all applicable international, federal, state, and local
requirements.
5. Accuracy of Information: To the extent TI provides information on the availability and function of EVMs, TI attempts to be as accurate
as possible. However, TI does not warrant the accuracy of EVM descriptions, EVM availability or other information on its websites as
accurate, complete, reliable, current, or error-free.
SPACER
SPACER
SPACER
SPACER
SPACER
SPACER

SPACER
6. Disclaimers:
6.1 EXCEPT AS SET FORTH ABOVE, EVMS AND ANY WRITTEN DESIGN MATERIALS PROVIDED WITH THE EVM (AND THE
DESIGN OF THE EVM ITSELF) ARE PROVIDED "AS IS" AND "WITH ALL FAULTS." TI DISCLAIMS ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED, REGARDING SUCH ITEMS, INCLUDING BUT NOT LIMITED TO ANY IMPLIED
WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE OR NON-INFRINGEMENT OF ANY
THIRD PARTY PATENTS, COPYRIGHTS, TRADE SECRETS OR OTHER INTELLECTUAL PROPERTY RIGHTS.
6.2 EXCEPT FOR THE LIMITED RIGHT TO USE THE EVM SET FORTH HEREIN, NOTHING IN THESE TERMS AND
CONDITIONS SHALL BE CONSTRUED AS GRANTING OR CONFERRING ANY RIGHTS BY LICENSE, PATENT, OR ANY
OTHER INDUSTRIAL OR INTELLECTUAL PROPERTY RIGHT OF TI, ITS SUPPLIERS/LICENSORS OR ANY OTHER THIRD
PARTY, TO USE THE EVM IN ANY FINISHED END-USER OR READY-TO-USE FINAL PRODUCT, OR FOR ANY
INVENTION, DISCOVERY OR IMPROVEMENT MADE, CONCEIVED OR ACQUIRED PRIOR TO OR AFTER DELIVERY OF
THE EVM.
7. USER'S INDEMNITY OBLIGATIONS AND REPRESENTATIONS. USER WILL DEFEND, INDEMNIFY AND HOLD TI, ITS
LICENSORS AND THEIR REPRESENTATIVES HARMLESS FROM AND AGAINST ANY AND ALL CLAIMS, DAMAGES, LOSSES,
EXPENSES, COSTS AND LIABILITIES (COLLECTIVELY, "CLAIMS") ARISING OUT OF OR IN CONNECTION WITH ANY
HANDLING OR USE OF THE EVM THAT IS NOT IN ACCORDANCE WITH THESE TERMS AND CONDITIONS. THIS OBLIGATION
SHALL APPLY WHETHER CLAIMS ARISE UNDER STATUTE, REGULATION, OR THE LAW OF TORT, CONTRACT OR ANY
OTHER LEGAL THEORY, AND EVEN IF THE EVM FAILS TO PERFORM AS DESCRIBED OR EXPECTED.
8. Limitations on Damages and Liability:
8.1 General Limitations. IN NO EVENT SHALL TI BE LIABLE FOR ANY SPECIAL, COLLATERAL, INDIRECT, PUNITIVE,
INCIDENTAL, CONSEQUENTIAL, OR EXEMPLARY DAMAGES IN CONNECTION WITH OR ARISING OUT OF THESE
TERMS ANDCONDITIONS OR THE USE OF THE EVMS PROVIDED HEREUNDER, REGARDLESS OF WHETHER TI HAS
BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. EXCLUDED DAMAGES INCLUDE, BUT ARE NOT LIMITED
TO, COST OF REMOVAL OR REINSTALLATION, ANCILLARY COSTS TO THE PROCUREMENT OF SUBSTITUTE GOODS
OR SERVICES, RETESTING, OUTSIDE COMPUTER TIME, LABOR COSTS, LOSS OF GOODWILL, LOSS OF PROFITS,
LOSS OF SAVINGS, LOSS OF USE, LOSS OF DATA, OR BUSINESS INTERRUPTION. NO CLAIM, SUIT OR ACTION SHALL
BE BROUGHT AGAINST TI MORE THAN ONE YEAR AFTER THE RELATED CAUSE OF ACTION HAS OCCURRED.
8.2 Specific Limitations. IN NO EVENT SHALL TI'S AGGREGATE LIABILITY FROM ANY WARRANTY OR OTHER OBLIGATION
ARISING OUT OF OR IN CONNECTION WITH THESE TERMS AND CONDITIONS, OR ANY USE OF ANY TI EVM
PROVIDED HEREUNDER, EXCEED THE TOTAL AMOUNT PAID TO TI FOR THE PARTICULAR UNITS SOLD UNDER
THESE TERMS AND CONDITIONS WITH RESPECT TO WHICH LOSSES OR DAMAGES ARE CLAIMED. THE EXISTENCE
OF MORE THAN ONE CLAIM AGAINST THE PARTICULAR UNITS SOLD TO USER UNDER THESE TERMS AND
CONDITIONS SHALL NOT ENLARGE OR EXTEND THIS LIMIT.
9. Return Policy. Except as otherwise provided, TI does not offer any refunds, returns, or exchanges. Furthermore, no return of EVM(s)
will be accepted if the package has been opened and no return of the EVM(s) will be accepted if they are damaged or otherwise not in
a resalable condition. If User feels it has been incorrectly charged for the EVM(s) it ordered or that delivery violates the applicable
order, User should contact TI. All refunds will be made in full within thirty (30) working days from the return of the components(s),
excluding any postage or packaging costs.
10. Governing Law: These terms and conditions shall be governed by and interpreted in accordance with the laws of the State of Texas,
without reference to conflict-of-laws principles. User agrees that non-exclusive jurisdiction for any dispute arising out of or relating to
these terms and conditions lies within courts located in the State of Texas and consents to venue in Dallas County, Texas.
Notwithstanding the foregoing, any judgment may be enforced in any United States or foreign court, and TI may seek injunctive relief
in any United States or foreign court.
Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265
Copyright © 2015, Texas Instruments Incorporated
spacer

IMPORTANT NOTICE
Texas Instruments Incorporated and its subsidiaries (TI) reserve the right to make corrections, enhancements, improvements and other
changes to its semiconductor products and services per JESD46, latest issue, and to discontinue any product or service per JESD48, latest
issue. Buyers should obtain the latest relevant information before placing orders and should verify that such information is current and
complete. All semiconductor products (also referred to herein as “components”) are sold subject to TI’s terms and conditions of sale
supplied at the time of order acknowledgment.
TI warrants performance of its components to the specifications applicable at the time of sale, in accordance with the warranty in TI’s terms
and conditions of sale of semiconductor products. Testing and other quality control techniques are used to the extent TI deems necessary
to support this warranty. Except where mandated by applicable law, testing of all parameters of each component is not necessarily
performed.
TI assumes no liability for applications assistance or the design of Buyers’ products. Buyers are responsible for their products and
applications using TI components. To minimize the risks associated with Buyers’ products and applications, Buyers should provide
adequate design and operating safeguards.
TI does not warrant or represent that any license, either express or implied, is granted under any patent right, copyright, mask work right, or
other intellectual property right relating to any combination, machine, or process in which TI components or services are used. Information
published by TI regarding third-party products or services does not constitute a license to use such products or services or a warranty or
endorsement thereof. Use of such information may require a license from a third party under the patents or other intellectual property of the
third party, or a license from TI under the patents or other intellectual property of TI.
Reproduction of significant portions of TI information in TI data books or data sheets is permissible only if reproduction is without alteration
and is accompanied by all associated warranties, conditions, limitations, and notices. TI is not responsible or liable for such altered
documentation. Information of third parties may be subject to additional restrictions.
Resale of TI components or services with statements different from or beyond the parameters stated by TI for that component or service
voids all express and any implied warranties for the associated TI component or service and is an unfair and deceptive business practice.
TI is not responsible or liable for any such statements.
Buyer acknowledges and agrees that it is solely responsible for compliance with all legal, regulatory and safety-related requirements
concerning its products, and any use of TI components in its applications, notwithstanding any applications-related information or support
that may be provided by TI. Buyer represents and agrees that it has all the necessary expertise to create and implement safeguards which
anticipate dangerous consequences of failures, monitor failures and their consequences, lessen the likelihood of failures that might cause
harm and take appropriate remedial actions. Buyer will fully indemnify TI and its representatives against any damages arising out of the use
of any TI components in safety-critical applications.
In some cases, TI components may be promoted specifically to facilitate safety-related applications. With such components, TI’s goal is to
help enable customers to design and create their own end-product solutions that meet applicable functional safety standards and
requirements. Nonetheless, such components are subject to these terms.
No TI components are authorized for use in FDA Class III (or similar life-critical medical equipment) unless authorized officers of the parties
have executed a special agreement specifically governing such use.
Only those TI components which TI has specifically designated as military grade or “enhanced plastic” are designed and intended for use in
military/aerospace applications or environments. Buyer acknowledges and agrees that any military or aerospace use of TI components
which have not been so designated is solely at the Buyer's risk, and that Buyer is solely responsible for compliance with all legal and
regulatory requirements in connection with such use.
TI has specifically designated certain components as meeting ISO/TS16949 requirements, mainly for automotive use. In any case of use of
non-designated products, TI will not be responsible for any failure to meet ISO/TS16949.
Products Applications
Audio www.ti.com/audio Automotive and Transportation www.ti.com/automotive
Amplifiers amplifier.ti.com Communications and Telecom www.ti.com/communications
Data Converters dataconverter.ti.com Computers and Peripherals www.ti.com/computers
DLP® Products www.dlp.com Consumer Electronics www.ti.com/consumer-apps
DSP dsp.ti.com Energy and Lighting www.ti.com/energy
Clocks and Timers www.ti.com/clocks Industrial www.ti.com/industrial
Interface interface.ti.com Medical www.ti.com/medical
Logic logic.ti.com Security www.ti.com/security
Power Mgmt power.ti.com Space, Avionics and Defense www.ti.com/space-avionics-defense
Microcontrollers microcontroller.ti.com Video and Imaging www.ti.com/video
RFID www.ti-rfid.com
OMAP Applications Processors www.ti.com/omap TI E2E Community e2e.ti.com
Wireless Connectivity www.ti.com/wirelessconnectivity
Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265
Copyright © 2015, Texas Instruments Incorporated
