EVM User's Guide: TPS51385EVM
TPS51385 Step-Down Converter Evaluation Module
Description
The TPS51385 is a single, D-CAP3™ control mode,
synchronous buck converter requiring a very low
external component count. TPS51385EVM is a fully
assembled and tested circuit for evaluating the
TPS51385 converter. This EVM operates typical 12-V
input, and provides a 5.1-V output at 7-A.
Features
• 4.5-V to 24-V input voltage range
• 0.6-V to 5.5-V output voltage range
• Support 7-A continuous output current
• Selectable PSM and OOA mode under light load
• Fast load transient response
Applications
•Notebook and PC computers
•Ultrabook, tablet computers
•TV , STB
• Distributed power systems
Top View of TPS51385EVM
www.ti.com Description
SLUUCX3 – AUGUST 2023
Submit Document Feedback
TPS51385 Step-Down Converter Evaluation Module 1
Copyright © 2023 Texas Instruments Incorporated

1 Evaluation Module Overview
1.1 Introduction
The TPS51385 evaluation module (EVM) is a single, synchronous buck converter providing 5.1-V at 7-A from a
6-V to 24-V input. This user’s guide describes the TPS51385EVM performance.
Table 1-1. Input Voltage and Output Current Summary
EVM Input Voltage (VIN) Range Output Current (IOUT) Range
TPS51385EVM 6 V to 24 V 0 A to 7 A
This user's guide describes the characteristics, operation, and use of the Texas Instruments TPS51385
evaluation module (EVM). The TPS51385EVM is designed to help user easily evaluate and test the operation
and functionality of the TPS51385. This user's guide includes the following:
• Setup instructions for the hardware
• Printed-circuit board layouts for the EVM
• Schematic diagram
• Bills of material
• Test results for the EVM
1.2 Kit Contents
• One TPS51385EVM board
• EVM disclaimer Read Me
1.3 Specification
A summary of the TPS51385EVM performance specifications is provided in Table 1-2. Specifications are given
for 12-V input voltage and 5.1-V output voltage, unless otherwise noted. The ambient temperature is 25°C for all
measurement, unless otherwise noted.
Table 1-2. TPS51385EVM Performance Specifications Summary
Specifications Test Conditions MIN TYP MAX Unit
VIN Input voltage 6 12 24 V
CH1
Output voltage 5.1 V
Operating frequency VIN = 12 V, IOUT = 7 A 1000 kHz
Output current range 0 7 A
Overcurrent limit VIN = 12 V, LOUT = 1 µH 8.8 A
Output ripple voltage VIN = 12 V, IOUT = 7 A 20 mVPP
1.4 Device Information
TPS51385 is the main device on the EVM board. The TPS51385 is a single, D-CAP3™ control mode,
synchronous buck converter requiring a very low external component count. Features include an accurate
reference voltage, fast load transient response, auto-skip mode operation for light load efficiency, OOA light load
operation with > 25-kHz switching frequency, D-CAP3control mode with good line, load regulation, and does not
require external compensation.
Evaluation Module Overview www.ti.com
2TPS51385 Step-Down Converter Evaluation Module SLUUCX3 – AUGUST 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

2 Hardware
2.1 Input and Output Connections
The TPS51385EVM is provided with input and output connectors and test points as shown in Table 2-1. Test
point TP2 provides a place to monitor the VIN input voltages with TP9 providing a convenient ground reference.
TP5 is used to monitor the output voltage with TP12 as the ground reference.
Table 2-1. Connection and Test Points
Reference
Designator Function
J1 VIN (see Table 1-1 for VIN range)
J2 VOUT, 5.1 V at 7-A maximum
JP1 PG pullup control. Short pin 1 and pin 2 to pull PG up to VCC.
JP2 EN high control. Short pin 1 and pin 2 to connect VIN to pin 1 of JP3.
JP3 EN control. Short pin 1 and pin 2 of JP2 to make EN high.
JP4 Mode control. Float or short pin 2 and pin 3 to set PSM mode. Short pin 2 and
pin 1 to set OOA mode.
TP1 VIN positive monitor point
TP2 VIN positive test point
TP3 Switch node (SW) test point
TP4 VOUT positive monitor point
TP5 VOUT positive test point
TP6 EN test point
TP7 PG test point
TP8 GND monitor point
TP9 GND test point
TP10 GND monitor point
TP11 Loop test point
TP12 GND test point
TP13 VCC test point
TP14, TP15, TP16 GND test point
2.2 Modifications
The evaluation module is designed to provide access to the features of the TPS51385. Some modifications can
be made to this module.
2.2.1 Output Voltage Setpoint
To change the output voltage of the EVM, change the value of resistor R4 (Rupper) and R6 (Rlower). The value of
R4 and R6 for a specific output voltage can be calculated using Equation 1.
)
R
R
1(6.0V
LOWER
UPPER
OUT u
(1)
2.2.2 Mode Selection
TPS51385 has a MODE pin that can offer two different options of light load performance, as shown in Table 2-2.
Table 2-2. MODE Pin Settings
MODE Pin Light Load Performance
Connect Pin2(MODE) to Pin3(L) of JP4 or leave MODE pin floating PSM
Connect Pin2(MODE) to Pin1(H) of JP4 OOA
www.ti.com Hardware
SLUUCX3 – AUGUST 2023
Submit Document Feedback
TPS51385 Step-Down Converter Evaluation Module 3
Copyright © 2023 Texas Instruments Incorporated

3 Implementation Results
This section describes how to properly connect, set up, and use the TPS51385EVM. The section also includes
test results typical for the evaluation modules.
3.1 Evaluation Setup
1. Make sure that the jumper at JP2 (Enable High Control) is covered to connect VIN to pin 1 of JP3. Also
make sure JP3 (Enable Control) pin 2 and 3 are covered to shunt EN to GND to disable the output.
2. Apply appropriate input voltage to VIN (J1-1) or TP1 and GND (J1-2) or TP8. Connect a power supply
capable of supplying 7-A to J1 through a pair of 20AWG wires. Note that the board cannot support hot
plug-in. The input lines must be connected between J1 and an external power source first before turning on
the power source.
3. Move the jumper at JP3 (Enable Control) from pin 2 and 3 (EN and OFF) to pin 2 and 1 (EN and ON) and
make sure JP2 pin 1 and pin 2 are covered. Then, the output can be enabled.
4. Apply the loading to VOUT (J2-2) or TP4 and GND (J2-1) or TP10. The load must be connected to J2
through a pair of 20AWG wires. The maximum load current capability is 7 A. Minimize wire lengths to reduce
losses in the wires.
3.2 Test Setup and Results
3.2.1 Start-Up
The following figures show the TPS51385EVM start-up waveform relative to EN.
VOUT=2V/div
PG=5V/div
IL=2A/div
EN=5V/div
Figure 3-1. Start-Up Relative to EN, IOUT = 0.1 A (2ms/div)
Implementation Results www.ti.com
4TPS51385 Step-Down Converter Evaluation Module SLUUCX3 – AUGUST 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

VOUT=2V/div
PG=5V/div
IL=5A/div
EN=5V/div
Figure 3-2. Start-Up Relative to EN, IOUT = 7 A (2ms/div)
3.2.2 Shutdown
The following figures show the TPS51385EVM shutdown waveform relative to EN.
VOUT=2V/div
PG=5V/div
IL=2A/div
EN=5V/div
Figure 3-3. Shutdown Relative to EN, IOUT = 0.1 A (2ms/div)
VOUT=2V/div
PG=5V/div
IL=5A/div
EN=5V/div
Figure 3-4. Shutdown Relative to EN, IOUT = 7 A (2ms/div)
www.ti.com Implementation Results
SLUUCX3 – AUGUST 2023
Submit Document Feedback
TPS51385 Step-Down Converter Evaluation Module 5
Copyright © 2023 Texas Instruments Incorporated

3.2.3 Output Voltage Ripple
The following images show the TPS51385EVM output voltage ripple.
VOUT=20mV/div (AC coupled)
SW=5V/div
Figure 3-5. TPS51385EVM Output Voltage Ripple, IOUT = 10 mA, PSM Mode (100us/div)
VOUT=20mV/div (AC coupled)
SW=5V/div
Figure 3-6. TPS51385EVM Output Voltage Ripple, IOUT = 10 mA, OOA Mode (10us/div)
VOUT=20mV/div (AC coupled)
SW=5V/div
Figure 3-7. TPS51385EVM Output Voltage Ripple, IOUT = 7 A (1us/div)
Implementation Results www.ti.com
6TPS51385 Step-Down Converter Evaluation Module SLUUCX3 – AUGUST 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

4 Hardware Design Files
4.1 Schematic
The following image shows the schematic for the TPS51385EVM.
Figure 4-1. TPS51385EVM Schematic Diagram
www.ti.com Hardware Design Files
SLUUCX3 – AUGUST 2023
Submit Document Feedback
TPS51385 Step-Down Converter Evaluation Module 7
Copyright © 2023 Texas Instruments Incorporated

4.2 PCB Layout
The following figures show the board layout for the TPS51385EVM. TPS51385EVM is with four layers. The top
layer contains the main power traces for VIN, VOUT, and GND. Also on the top layer are connections for the pins
of the TPS51385 and a large area filled with ground. Most of the signal traces are also located on the top side.
The input decoupling capacitors C4, C5, and C6 are located as close to VIN pins and PGND pins of the IC as
possible. The input and output connectors, test points, and all of the components are located on the top side.
The bottom layer is a ground plane along with signal ground copper fill and the feedback trace from the point of
regulation to the top of the resistor divider network. Two inner layers are ground plane.
Figure 4-2. Top Assembly
Figure 4-3. Top Layer
Hardware Design Files www.ti.com
8TPS51385 Step-Down Converter Evaluation Module SLUUCX3 – AUGUST 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

Figure 4-4. Inner1 Layer
Figure 4-5. Inner2 Layer
Figure 4-6. Bottom Layer
www.ti.com Hardware Design Files
SLUUCX3 – AUGUST 2023
Submit Document Feedback
TPS51385 Step-Down Converter Evaluation Module 9
Copyright © 2023 Texas Instruments Incorporated

4.3 Bill of Materials
The following table displays the TPS51385EVM bill of materials.
Table 4-1. Bill of Materials
Designator Qty Description Part Number Manufacturer(1)
C1, C6 2 CAP, CERM, 0.1 µF, 25 V, ±10%, X5R, 0603 CL10A104KA8NNNC Samsung Electro-
Mechanics
C4, C5 2 CAP, CERM, 10 μF, 35 V, ±10%, X5R, 0805 GRM21BR6YA106KE43L MuRata
C7, C8, C9 3 CAP, CERM, 22 μF, 10 V, ±20%, X5R, 0805 GRM21BR61A226ME44L MuRata
C12 1 CAP, CERM, 22 pF, 50 V, ±5%, C0G/NP0, 0603 C0603C220J5GACTU Kemet
C13 1 CAP, CERM, 1 μF, 10 V, ±10%, X5R, 0603 C0603C105K8PACTU Kemet
C14 1 CAP, CERM, 0.022 μF, 16 V, ±10%, X7R, 0603 C0603C220J5GACTU Kemet
C15 1 CAP, CERM, 0.01 μF, 16 V, ±10%, X7R, 0603 C0603C103K4RACTU Kemet
D1 1 Diode, Zener, 5.1 V, 200 mW, SOD-323 MMSZ5231BS-7-F Diodes Inc.
H1, H2, H3,
H4 4 Bumpon, Hemisphere, 0.44 × 0.20, Clear SJ-5303 (CLEAR) 3M
J1, J2 2 Terminal Block, 5.08 mm, 2 × 1, Brass, TH ED120/2DS On-Shore Technology
JP1, JP2 2 Header, 100mil, 2 × 1, Gold, TH PBC02SAAN Sullins Connector Solutions
JP3, JP4 2 Header, 100mil, 3 × 1, Tin, TH PEC03SAAN Sullins Connector Solutions
L1 1 Inductor, 1 μH, 14.4 A, 0.0064 Ω, SMD CMLE063T-1R0MS Cyntec
LBL1 1 Thermal Transfer Printable Labels, 1.250" W × 0.250" H
– 10,000 per roll THT-13-457-10 Brady
R1, R5 2 RES, 0, 5%, 0.1 W, 0603 RC0603JR-070RL Yageo
R2 1 RES, 51, 5%, 0.1 W, AEC-Q200 Grade 0, 0603 CRCW060351R0JNEA Vishay-Dale
R3 1 RES, 100 k, 5%, 0.1 W, 0603 CRCW0603100KJNEAC Vishay-Dale
R4 1 RES, 150 k, 1%, 0.1 W, 0603 RC0603FR-07150KL Yageo
R6 1 RES, 20.0 k, 1%, 0.1 W, AEC-Q200 Grade 0, 0603 ERJ-3EKF2002V Panasonic
R7, R8, R9 3 RES, 20.0 k, 1%, 0.1 W, AEC-Q200 Grade 0, 0603 CRCW060320K0FKEA Vishay-Dale
SH-JP1, SH-
JP2, SH-JP3,
SH-JP4
4 Shunt, 100 mil, Gold plated, Black SNT-100-BK-G Samtec
TP1, TP4,
TP8, TP10 4 Terminal, Turret, TH, Triple 1598-2 Keystone
TP2, TP3,
TP5, TP6,
TP7, TP11,
TP13
7 Test Point, Miniature, Red, TH 5000 Keystone
TP9, TP12,
TP14, TP15,
TP16
5 Test Point, Miniature, Black, TH 5001 Keystone
U1 1 4.5-V to 24-V Input, 7-A Synchronous Buck Converter TPS51385RJNR Texas Instruments
C2, C3 0 CAP, CERM, 10 μF, 35 V, ±10%, X5R, 0805 GRM21BR6YA106KE43L MuRata
C10, C11 0 CAP, CERM, 22 μF, 10 V, ±20%, X5R, 0805 GRM21BR61A226ME44L MuRata
(1) Unless otherwise noted in the Alternate Part Number or Alternate Manufacturer columns, all parts can be substituted with equivalents.
Hardware Design Files www.ti.com
10 TPS51385 Step-Down Converter Evaluation Module SLUUCX3 – AUGUST 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

5 Additional Information
Trademarks
D-CAP3™ is a trademark of Texas Instruments.
All trademarks are the property of their respective owners.
6 References
For related documentation, see the following:
Texas Instruments, TPS51385 4.5-V to 24-V Input, 7-A Synchronous Buck Converter data sheet
www.ti.com Additional Information
SLUUCX3 – AUGUST 2023
Submit Document Feedback
TPS51385 Step-Down Converter Evaluation Module 11
Copyright © 2023 Texas Instruments Incorporated

STANDARD TERMS FOR EVALUATION MODULES
1. Delivery: TI delivers TI evaluation boards, kits, or modules, including any accompanying demonstration software, components, and/or
documentation which may be provided together or separately (collectively, an “EVM” or “EVMs”) to the User (“User”) in accordance
with the terms set forth herein. User's acceptance of the EVM is expressly subject to the following terms.
1.1 EVMs are intended solely for product or software developers for use in a research and development setting to facilitate feasibility
evaluation, experimentation, or scientific analysis of TI semiconductors products. EVMs have no direct function and are not
finished products. EVMs shall not be directly or indirectly assembled as a part or subassembly in any finished product. For
clarification, any software or software tools provided with the EVM (“Software”) shall not be subject to the terms and conditions
set forth herein but rather shall be subject to the applicable terms that accompany such Software
1.2 EVMs are not intended for consumer or household use. EVMs may not be sold, sublicensed, leased, rented, loaned, assigned,
or otherwise distributed for commercial purposes by Users, in whole or in part, or used in any finished product or production
system.
2Limited Warranty and Related Remedies/Disclaimers:
2.1 These terms do not apply to Software. The warranty, if any, for Software is covered in the applicable Software License
Agreement.
2.2 TI warrants that the TI EVM will conform to TI's published specifications for ninety (90) days after the date TI delivers such EVM
to User. Notwithstanding the foregoing, TI shall not be liable for a nonconforming EVM if (a) the nonconformity was caused by
neglect, misuse or mistreatment by an entity other than TI, including improper installation or testing, or for any EVMs that have
been altered or modified in any way by an entity other than TI, (b) the nonconformity resulted from User's design, specifications
or instructions for such EVMs or improper system design, or (c) User has not paid on time. Testing and other quality control
techniques are used to the extent TI deems necessary. TI does not test all parameters of each EVM.
User's claims against TI under this Section 2 are void if User fails to notify TI of any apparent defects in the EVMs within ten (10)
business days after delivery, or of any hidden defects with ten (10) business days after the defect has been detected.
2.3 TI's sole liability shall be at its option to repair or replace EVMs that fail to conform to the warranty set forth above, or credit
User's account for such EVM. TI's liability under this warranty shall be limited to EVMs that are returned during the warranty
period to the address designated by TI and that are determined by TI not to conform to such warranty. If TI elects to repair or
replace such EVM, TI shall have a reasonable time to repair such EVM or provide replacements. Repaired EVMs shall be
warranted for the remainder of the original warranty period. Replaced EVMs shall be warranted for a new full ninety (90) day
warranty period.
WARNING
Evaluation Kits are intended solely for use by technically qualified,
professional electronics experts who are familiar with the dangers
and application risks associated with handling electrical mechanical
components, systems, and subsystems.
User shall operate the Evaluation Kit within TI’s recommended
guidelines and any applicable legal or environmental requirements
as well as reasonable and customary safeguards. Failure to set up
and/or operate the Evaluation Kit within TI’s recommended
guidelines may result in personal injury or death or property
damage. Proper set up entails following TI’s instructions for
electrical ratings of interface circuits such as input, output and
electrical loads.
NOTE:
EXPOSURE TO ELECTROSTATIC DISCHARGE (ESD) MAY CAUSE DEGREDATION OR FAILURE OF THE EVALUATION
KIT; TI RECOMMENDS STORAGE OF THE EVALUATION KIT IN A PROTECTIVE ESD BAG.

www.ti.com
2
3Regulatory Notices:
3.1 United States
3.1.1 Notice applicable to EVMs not FCC-Approved:
FCC NOTICE: This kit is designed to allow product developers to evaluate electronic components, circuitry, or software
associated with the kit to determine whether to incorporate such items in a finished product and software developers to write
software applications for use with the end product. This kit is not a finished product and when assembled may not be resold or
otherwise marketed unless all required FCC equipment authorizations are first obtained. Operation is subject to the condition
that this product not cause harmful interference to licensed radio stations and that this product accept harmful interference.
Unless the assembled kit is designed to operate under part 15, part 18 or part 95 of this chapter, the operator of the kit must
operate under the authority of an FCC license holder or must secure an experimental authorization under part 5 of this chapter.
3.1.2 For EVMs annotated as FCC – FEDERAL COMMUNICATIONS COMMISSION Part 15 Compliant:
CAUTION
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to
operate the equipment.
FCC Interference Statement for Class A EVM devices
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to
correct the interference at his own expense.
FCC Interference Statement for Class B EVM devices
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
3.2 Canada
3.2.1 For EVMs issued with an Industry Canada Certificate of Conformance to RSS-210 or RSS-247
Concerning EVMs Including Radio Transmitters:
This device complies with Industry Canada license-exempt RSSs. Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this device must accept any interference, including interference that may
cause undesired operation of the device.
Concernant les EVMs avec appareils radio:
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation
est autorisée aux deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit
accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
Concerning EVMs Including Detachable Antennas:
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser)
gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type
and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for
successful communication. This radio transmitter has been approved by Industry Canada to operate with the antenna types
listed in the user guide with the maximum permissible gain and required antenna impedance for each antenna type indicated.
Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited
for use with this device.

www.ti.com
3
Concernant les EVMs avec antennes détachables
Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec une antenne d'un type et
d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage
radioélectrique à l'intention des autres utilisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope
rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une communication satisfaisante. Le
présent émetteur radio a été approuvé par Industrie Canada pour fonctionner avec les types d'antenne énumérés dans le
manuel d’usage et ayant un gain admissible maximal et l'impédance requise pour chaque type d'antenne. Les types d'antenne
non inclus dans cette liste, ou dont le gain est supérieur au gain maximal indiqué, sont strictement interdits pour l'exploitation de
l'émetteur
3.3 Japan
3.3.1 Notice for EVMs delivered in Japan: Please see http://www.tij.co.jp/lsds/ti_ja/general/eStore/notice_01.page 日本国内に
輸入される評価用キット、ボードについては、次のところをご覧ください。
https://www.ti.com/ja-jp/legal/notice-for-evaluation-kits-delivered-in-japan.html
3.3.2 Notice for Users of EVMs Considered “Radio Frequency Products” in Japan: EVMs entering Japan may not be certified
by TI as conforming to Technical Regulations of Radio Law of Japan.
If User uses EVMs in Japan, not certified to Technical Regulations of Radio Law of Japan, User is required to follow the
instructions set forth by Radio Law of Japan, which includes, but is not limited to, the instructions below with respect to EVMs
(which for the avoidance of doubt are stated strictly for convenience and should be verified by User):
1. Use EVMs in a shielded room or any other test facility as defined in the notification #173 issued by Ministry of Internal
Affairs and Communications on March 28, 2006, based on Sub-section 1.1 of Article 6 of the Ministry’s Rule for
Enforcement of Radio Law of Japan,
2. Use EVMs only after User obtains the license of Test Radio Station as provided in Radio Law of Japan with respect to
EVMs, or
3. Use of EVMs only after User obtains the Technical Regulations Conformity Certification as provided in Radio Law of Japan
with respect to EVMs. Also, do not transfer EVMs, unless User gives the same notice above to the transferee. Please note
that if User does not follow the instructions above, User will be subject to penalties of Radio Law of Japan.
【無線電波を送信する製品の開発キットをお使いになる際の注意事項】 開発キットの中には技術基準適合証明を受けて
いないものがあります。 技術適合証明を受けていないもののご使用に際しては、電波法遵守のため、以下のいずれかの
措置を取っていただく必要がありますのでご注意ください。
1. 電波法施行規則第6条第1項第1号に基づく平成18年3月28日総務省告示第173号で定められた電波暗室等の試験設備でご使用
いただく。
2. 実験局の免許を取得後ご使用いただく。
3. 技術基準適合証明を取得後ご使用いただく。
なお、本製品は、上記の「ご使用にあたっての注意」を譲渡先、移転先に通知しない限り、譲渡、移転できないものとします。
上記を遵守頂けない場合は、電波法の罰則が適用される可能性があることをご留意ください。 日本テキサス・イ
ンスツルメンツ株式会社
東京都新宿区西新宿６丁目２４番１号
西新宿三井ビル
3.3.3 Notice for EVMs for Power Line Communication: Please see http://www.tij.co.jp/lsds/ti_ja/general/eStore/notice_02.page
電力線搬送波通信についての開発キットをお使いになる際の注意事項については、次のところをご覧くださ
い。https://www.ti.com/ja-jp/legal/notice-for-evaluation-kits-for-power-line-communication.html
3.4 European Union
3.4.1 For EVMs subject to EU Directive 2014/30/EU (Electromagnetic Compatibility Directive):
This is a class A product intended for use in environments other than domestic environments that are connected to a
low-voltage power-supply network that supplies buildings used for domestic purposes. In a domestic environment this
product may cause radio interference in which case the user may be required to take adequate measures.

www.ti.com
4
4EVM Use Restrictions and Warnings:
4.1 EVMS ARE NOT FOR USE IN FUNCTIONAL SAFETY AND/OR SAFETY CRITICAL EVALUATIONS, INCLUDING BUT NOT
LIMITED TO EVALUATIONS OF LIFE SUPPORT APPLICATIONS.
4.2 User must read and apply the user guide and other available documentation provided by TI regarding the EVM prior to handling
or using the EVM, including without limitation any warning or restriction notices. The notices contain important safety information
related to, for example, temperatures and voltages.
4.3 Safety-Related Warnings and Restrictions:
4.3.1 User shall operate the EVM within TI’s recommended specifications and environmental considerations stated in the user
guide, other available documentation provided by TI, and any other applicable requirements and employ reasonable and
customary safeguards. Exceeding the specified performance ratings and specifications (including but not limited to input
and output voltage, current, power, and environmental ranges) for the EVM may cause personal injury or death, or
property damage. If there are questions concerning performance ratings and specifications, User should contact a TI
field representative prior to connecting interface electronics including input power and intended loads. Any loads applied
outside of the specified output range may also result in unintended and/or inaccurate operation and/or possible
permanent damage to the EVM and/or interface electronics. Please consult the EVM user guide prior to connecting any
load to the EVM output. If there is uncertainty as to the load specification, please contact a TI field representative.
During normal operation, even with the inputs and outputs kept within the specified allowable ranges, some circuit
components may have elevated case temperatures. These components include but are not limited to linear regulators,
switching transistors, pass transistors, current sense resistors, and heat sinks, which can be identified using the
information in the associated documentation. When working with the EVM, please be aware that the EVM may become
very warm.
4.3.2 EVMs are intended solely for use by technically qualified, professional electronics experts who are familiar with the
dangers and application risks associated with handling electrical mechanical components, systems, and subsystems.
User assumes all responsibility and liability for proper and safe handling and use of the EVM by User or its employees,
affiliates, contractors or designees. User assumes all responsibility and liability to ensure that any interfaces (electronic
and/or mechanical) between the EVM and any human body are designed with suitable isolation and means to safely
limit accessible leakage currents to minimize the risk of electrical shock hazard. User assumes all responsibility and
liability for any improper or unsafe handling or use of the EVM by User or its employees, affiliates, contractors or
designees.
4.4 User assumes all responsibility and liability to determine whether the EVM is subject to any applicable international, federal,
state, or local laws and regulations related to User’s handling and use of the EVM and, if applicable, User assumes all
responsibility and liability for compliance in all respects with such laws and regulations. User assumes all responsibility and
liability for proper disposal and recycling of the EVM consistent with all applicable international, federal, state, and local
requirements.
5. Accuracy of Information: To the extent TI provides information on the availability and function of EVMs, TI attempts to be as accurate
as possible. However, TI does not warrant the accuracy of EVM descriptions, EVM availability or other information on its websites as
accurate, complete, reliable, current, or error-free.
6. Disclaimers:
6.1 EXCEPT AS SET FORTH ABOVE, EVMS AND ANY MATERIALS PROVIDED WITH THE EVM (INCLUDING, BUT NOT
LIMITED TO, REFERENCE DESIGNS AND THE DESIGN OF THE EVM ITSELF) ARE PROVIDED "AS IS" AND "WITH ALL
FAULTS." TI DISCLAIMS ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, REGARDING SUCH ITEMS, INCLUDING BUT
NOT LIMITED TO ANY EPIDEMIC FAILURE WARRANTY OR IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE OR NON-INFRINGEMENT OF ANY THIRD PARTY PATENTS, COPYRIGHTS, TRADE
SECRETS OR OTHER INTELLECTUAL PROPERTY RIGHTS.
6.2 EXCEPT FOR THE LIMITED RIGHT TO USE THE EVM SET FORTH HEREIN, NOTHING IN THESE TERMS SHALL BE
CONSTRUED AS GRANTING OR CONFERRING ANY RIGHTS BY LICENSE, PATENT, OR ANY OTHER INDUSTRIAL OR
INTELLECTUAL PROPERTY RIGHT OF TI, ITS SUPPLIERS/LICENSORS OR ANY OTHER THIRD PARTY, TO USE THE
EVM IN ANY FINISHED END-USER OR READY-TO-USE FINAL PRODUCT, OR FOR ANY INVENTION, DISCOVERY OR
IMPROVEMENT, REGARDLESS OF WHEN MADE, CONCEIVED OR ACQUIRED.
7. USER'S INDEMNITY OBLIGATIONS AND REPRESENTATIONS. USER WILL DEFEND, INDEMNIFY AND HOLD TI, ITS
LICENSORS AND THEIR REPRESENTATIVES HARMLESS FROM AND AGAINST ANY AND ALL CLAIMS, DAMAGES, LOSSES,
EXPENSES, COSTS AND LIABILITIES (COLLECTIVELY, "CLAIMS") ARISING OUT OF OR IN CONNECTION WITH ANY
HANDLING OR USE OF THE EVM THAT IS NOT IN ACCORDANCE WITH THESE TERMS. THIS OBLIGATION SHALL APPLY
WHETHER CLAIMS ARISE UNDER STATUTE, REGULATION, OR THE LAW OF TORT, CONTRACT OR ANY OTHER LEGAL
THEORY, AND EVEN IF THE EVM FAILS TO PERFORM AS DESCRIBED OR EXPECTED.

www.ti.com
5
8. Limitations on Damages and Liability:
8.1 General Limitations. IN NO EVENT SHALL TI BE LIABLE FOR ANY SPECIAL, COLLATERAL, INDIRECT, PUNITIVE,
INCIDENTAL, CONSEQUENTIAL, OR EXEMPLARY DAMAGES IN CONNECTION WITH OR ARISING OUT OF THESE
TERMS OR THE USE OF THE EVMS , REGARDLESS OF WHETHER TI HAS BEEN ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES. EXCLUDED DAMAGES INCLUDE, BUT ARE NOT LIMITED TO, COST OF REMOVAL OR
REINSTALLATION, ANCILLARY COSTS TO THE PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES, RETESTING,
OUTSIDE COMPUTER TIME, LABOR COSTS, LOSS OF GOODWILL, LOSS OF PROFITS, LOSS OF SAVINGS, LOSS OF
USE, LOSS OF DATA, OR BUSINESS INTERRUPTION. NO CLAIM, SUIT OR ACTION SHALL BE BROUGHT AGAINST TI
MORE THAN TWELVE (12) MONTHS AFTER THE EVENT THAT GAVE RISE TO THE CAUSE OF ACTION HAS
OCCURRED.
8.2 Specific Limitations. IN NO EVENT SHALL TI'S AGGREGATE LIABILITY FROM ANY USE OF AN EVM PROVIDED
HEREUNDER, INCLUDING FROM ANY WARRANTY, INDEMITY OR OTHER OBLIGATION ARISING OUT OF OR IN
CONNECTION WITH THESE TERMS, , EXCEED THE TOTAL AMOUNT PAID TO TI BY USER FOR THE PARTICULAR
EVM(S) AT ISSUE DURING THE PRIOR TWELVE (12) MONTHS WITH RESPECT TO WHICH LOSSES OR DAMAGES ARE
CLAIMED. THE EXISTENCE OF MORE THAN ONE CLAIM SHALL NOT ENLARGE OR EXTEND THIS LIMIT.
9. Return Policy. Except as otherwise provided, TI does not offer any refunds, returns, or exchanges. Furthermore, no return of EVM(s)
will be accepted if the package has been opened and no return of the EVM(s) will be accepted if they are damaged or otherwise not in
a resalable condition. If User feels it has been incorrectly charged for the EVM(s) it ordered or that delivery violates the applicable
order, User should contact TI. All refunds will be made in full within thirty (30) working days from the return of the components(s),
excluding any postage or packaging costs.
10. Governing Law: These terms and conditions shall be governed by and interpreted in accordance with the laws of the State of Texas,
without reference to conflict-of-laws principles. User agrees that non-exclusive jurisdiction for any dispute arising out of or relating to
these terms and conditions lies within courts located in the State of Texas and consents to venue in Dallas County, Texas.
Notwithstanding the foregoing, any judgment may be enforced in any United States or foreign court, and TI may seek injunctive relief
in any United States or foreign court.
Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265
Copyright © 2023, Texas Instruments Incorporated

IMPORTANT NOTICE AND DISCLAIMER
TI PROVIDES TECHNICAL AND RELIABILITY DATA (INCLUDING DATA SHEETS), DESIGN RESOURCES (INCLUDING REFERENCE
DESIGNS), APPLICATION OR OTHER DESIGN ADVICE, WEB TOOLS, SAFETY INFORMATION, AND OTHER RESOURCES “AS IS”
AND WITH ALL FAULTS, AND DISCLAIMS ALL WARRANTIES, EXPRESS AND IMPLIED, INCLUDING WITHOUT LIMITATION ANY
IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR NON-INFRINGEMENT OF THIRD
PARTY INTELLECTUAL PROPERTY RIGHTS.
These resources are intended for skilled developers designing with TI products. You are solely responsible for (1) selecting the appropriate
TI products for your application, (2) designing, validating and testing your application, and (3) ensuring your application meets applicable
standards, and any other safety, security, regulatory or other requirements.
These resources are subject to change without notice. TI grants you permission to use these resources only for development of an
application that uses the TI products described in the resource. Other reproduction and display of these resources is prohibited. No license
is granted to any other TI intellectual property right or to any third party intellectual property right. TI disclaims responsibility for, and you
will fully indemnify TI and its representatives against, any claims, damages, costs, losses, and liabilities arising out of your use of these
resources.
TI’s products are provided subject to TI’s Terms of Sale or other applicable terms available either on ti.com or provided in conjunction with
such TI products. TI’s provision of these resources does not expand or otherwise alter TI’s applicable warranties or warranty disclaimers for
TI products.
TI objects to and rejects any additional or different terms you may have proposed. IMPORTANT NOTICE
Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265
Copyright © 2023, Texas Instruments Incorporated

Mouser Electronics
Authorized Distributor
Click to View Pricing, Inventory, Delivery & Lifecycle Information:
Texas Instruments:
TPS51385EVM
