Teze 12V150AH User manual

[email protected] Shenzhen Teze Power Co.,Ltd.
12V150AH
LiFePO4
https://tezepower.com/
(150A BMS)
PRODUCT
MANUAL
Lithium lron Phosphate (LiFePO4)Battery
Originate from TezePower

www.tezepower.com [email protected]m
1
PRODUCT OVERVIEW
BATTERY
Combination: 12.8V150Ah
Dimension: L20.94*W8.15*H8.46 inch
Plastic Shell Color: Black
TERMINAL & POST BOLTS
Terminal Size:
M8 (1.25mm Metric Thread)
Post Bolts:
M8 (1.25mm Metric Thread*16mm Bolt Length)
(The bolts can be replaced with M8 bolts of other lengths based on actual needs.)
GENERAL INFORMATION
Operating Voltage
12.8V
Charging Voltage
14.4±0.2V
Max Continuous Load Power
1920W
Max Continuous Charge/ Discharge Current
150A

www.tezepower.com [email protected]m
2
NOTICE BEFORE USING
Step 1:CONTACT US at [e-mail] to activate the FIVE-YEAR WARRANTY
Step 2:PULL OUT Insulating Plugs
Step 3: TIGHTLY SCREW IN Post Bolts
Please tightly screw in the post bolts. Having loose battery terminals will cause the terminals to
build up heat resulting in damage to the battery.
Step 4: PUT ON Insulating Covers
Please put on the insulating covers to avoid metal or conductive objects touching the positive and
negative terminals of the battery at the same time, otherwise it is likely to cause a short circuit.

www.tezepower.com [email protected]m
3
Step 5:TEST The Battery Voltage with Multimeter
≥12V To Step6
<12V Contact us at [e-mail] to help solve the problem.
Step 6: FULLY CHARGE The Battery Separately
(Refer to Page 06 for battery charging methods)
Step 7:CONNECT To Use
