Tharo Systems H-426 User manual

THARO H-Series Users Manual
P/N. 920-011211-01 Edition 6 June 2004

FCC COMPLIANCE STATEMENT
FOR AMERICAN USERS
This equipment has been tested and found to comply with the limits for a CLASS A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. Operation
of this equipment in a residential area is likely to cause harmful interference in which case the user
will be required to correct the interference at his expense.
EMS AND EMI COMPLIANCE STATEMENT
FOR EUROPEAN USERS
This equipment has been tested and passed with the requirements relating to electromagnetic
compatibility based on the standards EN50081-1 (EN55022 CLASS A) and EN61000-4-2/-3/-4/-5/-6/
-8/-11 (IEC Teil 2,3,4). The equipment also tested and passed in accordance with the European
Standard EN55022 for both the Radiated and Conducted emissions limits.
CAUTION
Danger of explosion if battery is replaced incorrectly.
Only replace battery with an equivalent type as recommended by the manufacturer.
Dispose of used batteries according to the manufacturer’s instructions.
Copyright and Trademark Notice
© 2005 by Tharo Systems, Inc.
It is illegal to photocopy or electronically transmit a facsimile of this manual or any portion
of its contents for any means or purpose without the publisher’s permission. Fines of up
to $10,000.00 may be imposed for violation.
All brand or product names are trademarks or registered trademarks of their respective companies.
- 1 -

TABLE OF CONTENTS
1. PRODUCT DESCRIPTION......................................................................................... 5
General Information ......................................................................................................................... 5
Printer Options.................................................................................................................................... 5
Technical Specifications .................................................................................................................. 6
2. GENERAL SAFETY TIPS ........................................................................................... 7
3. UNPACKING THE PRINTER AND ACCESSORIES.................................................. 7
4. IDENTIFYING COMPONENTS .................................................................................. 8
5. PRINTER SETUP...................................................................................................... 10
6. CONTROL PANEL..................................................................................................... 11
General Description and Operation .......................................................................................... 11
Setting Mode ..................................................................................................................................... 11
Menu items and available options in Setting Mode ........................................................... 12
Interpreting LCD/LED Messages................................................................................................ 14
7. LOADING MEDIA .................................................................................................... 15
Ribbon Out ......................................................................................................................................... 15
Ribbon Installation.......................................................................................................................... 15
Label Installation ............................................................................................................................. 17
Activating the Stripper Sensor................................................................................................... 18
8. INSTALLING THE PRINTER’S OPTIONAL ACCESSORIES ................................ 19
Internal Rewind Module Components...................................................................................... 19
Internal Rewind Module Installation Instructions............................................................... 20
Cutter Module Components......................................................................................................... 21
Cutter Module Installation Instructions .................................................................................. 21
9. USING THE PRINTER WITH A PS/2 KEYBOARD ............................................ 23
Entering/Exiting Keyboard Mode............................................................................................... 23
Menu Items and Options available in Keyboard Mode...................................................... 24
- 2 -

APPENDIX A. COMMUNICATION INTERFACES ......................................................... 26
Parallel Interface.............................................................................................................................. 26
Serial Interface................................................................................................................................. 26
USB Interface.................................................................................................................................... 27
Installation of the USB HS Serial Converter......................................................................... 27
Removing the USB HS Serial Converter................................................................................. 29
PS/2 Interface................................................................................................................................... 29
APPENDIX B. ERROR MESSAGES / TROUBLESHOOTING ................................... 30
Self Test .............................................................................................................................................. 30
Dump Mode........................................................................................................................................ 30
LCD Error and LED Light Message Descriptions.................................................................. 31
Problems and Recommended Solutions ................................................................................. 32
APPENDIX C. MAINTENANCE AND ADJUSTMENT ................................................. 33
Cleaning the Thermal Printhead ................................................................................................ 33
Thermal Printhead Replacement ............................................................................................... 34
Thermal Printhead Print Line Adjustment.............................................................................. 35
Thermal Printhead Spring Box Position/Pressure Adjustment ...................................... 37
Ribbon Tension Adjustment ........................................................................................................ 37
Drive Roller Replacement............................................................................................................. 38
Auto Sensing ..................................................................................................................................... 40
Upgrading the Printer’s Firmware ............................................................................................. 40
Clearing Cutter Jams...................................................................................................................... 40
Cleaning Adhesive from the Cutter Blade.............................................................................. 41
- 3 -

Warranty Information
The THARO H-426/H-434 printers are warranted against defects in material or workmanship for 12
months (365 days) from the date of original shipment by THARO SYSTEMS, INCORPORATED. This
warranty does not cover normal wear and tear and shall be null and void if the equipment is modified,
improperly installed or used, damaged by accident or neglect, or in the event any parts are improperly
installed or replaced by the user.
Since printhead wear is part of normal operations, a printhead warranty of 3 months (90 days) from the
date of original shipment by THARO SYSTEMS, or 2,000,000 linear inches of use, whichever comes first.
To qualify for this warranty, the printhead must be returned to THARO or another authorized service
center. Although the user is not required to purchase THARO brand supplies (media and/or ribbons), to
the extent it is determined that the use of other supplies (media and/or ribbons) shall have caused any
defect in the thermal printhead for which a warranty claim is made, the user shall be responsible for
THARO's customary charges for labor and materials to repair such defect. To the extent that it is
determined that failure to follow the preventive maintenance schedule and procedures listed in the User
Guide shall have caused any defect in the thermal printhead for which a warranty claim is made, this
limited warranty shall be void. Any printhead returned to THARO with scratches or abrasions on the
printhead at the point of failure will be deemed abused and no warranty replacement will be provided.
THARO SYSTEMS' SOLE OBLIGATION UNDER THIS WARRANTY SHALL BE TO FURNISH PARTS AND
LABOR FOR THE REPAIR OR REPLACEMENT OF PRODUCTS FOUND TO BE DEFECTIVE IN MATERIAL
OR WORKMANSHIP DURING THE WARRANTY PERIOD.
As a condition of this warranty, the user must: (a) obtain a THARO Return Authorization for the printer,
or subassembly(s); (b) ship the printer or subassembly(s), transportation prepaid to the authorized
service location; and (c) include with the Product or subassembly(s) a written description of the claimed
defect. Unless THARO SYSTEMS authorizes return of the entire Product, the user shall return only the
subassembly(s). Products returned shall be packaged in the original packing and shipping container or
comparable container. In the event equipment is not so packaged or if shipping damage is evident, it will
not be accepted for service under warranty. Surface transportation charges for the return of the printer
to the customer shall be paid by THARO SYSTEMS within the 48 contiguous states and the District of
Columbia. Customer shall pay shipping costs, customs clearance, and other related charges outside the
designated area. If THARO SYSTEMS determines that the Product returned to it for warranty service or
replacement is not defective as herein defined, BUYER shall be subject to a minimal labor charge and all
costs of handling and transportation.
Warranty Exclusions and Conditions
The above warranties are in lieu of all other warranties, expressed or implied, oral or written, statutory
or otherwise, including any implied warranty of merchant-ability or fitness for a particular
purpose.
THARO SYSTEMS shall not be responsible for the specific application to which any Products are applied,
including but not limited to compatibility with other equipment.
All statements, technical information and recommendations relating to THARO Products are based upon
tests believed to be reliable but do not constitute a guarantee or warranty.
THARO SYSTEMS SHALL NOT, UNDER ANY CIRCUMSTANCES WHATSOEVER, BE LIABLE TO
BUYER OR ANY OTHER PARTY FOR LOST PROFITS, DIMINUTION OF GOODWILL OR ANY OTHER
SPECIAL OR CONSEQUENTIAL DAMAGES WHATSOEVER WITH RESPECT TO ANY CLAIM
HEREUNDER. IN ADDITION, THARO SYSTEMS' LIABILITY FOR WARRANTY CLAIMS SHALL NOT,
IN ANY EVENT, EXCEED THE INVOICE PRICE OF THE PRODUCT CLAIMED DEFECTIVE, NOR
SHALL THARO SYSTEMS BE LIABLE FOR DELAYS IN REPLACEMENT OR REPAIR OF PRODUCTS
No salesperson, representative or agent of THARO SYSTEMS is authorized to make any guarantee,
warranty, or representation in addition to the foregoing warranty.
NO WAIVER, ALTERATION, ADDITION, OR MODIFICATION OF THE FOREGOING WARRANTIES
SHALL BE VALID UNLESS MADE IN WRITING AND SIGNED BY AN EXECUTIVE OFFICER OF
THARO SYSTEMS.
- 4 -

1. Product Description
General Information
The THARO H-426 and H-434 Printers are heavy duty, high performance thermal transfer/direct
thermal label Printers suitable for large volume printing requirements in industrial applications. With
robust metal outer casing and inner mechanism, the Printers are designed to be durable, tough and
reliable, even in the harshest environments.
The THARO H-426 features a printhead density of 8 dots/mm (203 dots/in) and a maximum print
length of 1270mm (50”). The THARO H-434 features a printhead density of 12 dots/mm (300
dots/in) and a maximum print length of 558.8mm (22”).
Both Printers provide high-speed performance of up to 6 inches per second with an 8” diameter label
roll and 450 meter length ribbon capacities for large volume throughput. The THARO H-426 and H-
434 feature a large, backlit LCD that is easy to read and is capable of displaying either text or
graphics, making operation easy. A Real-Time Clock for time and date stamping of labels is standard
on the H-426 and H-434. Also standard on the THARO H-426 and H-434 Printers is a Stripper
Sensor to sense the presence of printed labels. With the Stripper Sensor activated, application
software such as EASYLABEL®can operate the Printers in Peel-Off or Tear-Off modes.
The THARO H-426 and H-434 Printers provide internal memory for storing downloaded label formats,
graphics, and fonts. Data can be downloaded to this memory via the Printers’ serial interfaces.
Using this memory the Printers can be operated without being connected to a computer, which
represents a great advantage regarding their flexibility.
Accessories available for the THARO H-426 and H-434 Printers include a Cutter for ticket or receipt
printing applications and the Internal Rewind to be used with the standard Stripper Sensor in strip-
and-peel applications.
Printer Options
Internal Rewind
The Internal Rewind can be used with the Stripper Sensor to rewind the label liner when the Printer is
operating in strip-and-peel mode. Its unique design incorporates a maximum liner switch that will
stop the Printer from printing when the liner diameter exceeds 110mm (4.33”).
Cutter
The optional Cutter can be used to cut labels or tag stock up to a 10-mil thickness. Cutter options
include a choice of: cut after each label, cut after a specific quantity of labels or cut at the end of a
print job.
2MB FLASH memory module
The Printer has the ability to use internal Flash memory for storing downloaded label formats,
graphics and fonts. This option provides an additional 2MB of memory above and beyond the 2MB
that is standard in the Printer. This increases the available space for the storage of these files.
External Keyboard
The PS/2 Keyboard connector allows you to connect your Printer to any standard PS/2 Keyboard.
This will allow you to input variable data to a label format stored in Flash memory.
EASYLABEL®- Label Design Software for Windows
EASYLABEL®labeling software allows you to drive your Printer and create a full range of label formats
with a minimum of effort. EASYLABEL can be installed under Microsoft Windows® on IBM PCs and
compatibles. For further information about EASYLABEL, please contact your THARO Reseller.
- 5 -

Technical Specifications - Specifications are subject to change without notice.
Model THARO H–426 THARO H-434
Resolution 8 dots/mm (203dpi) 12 dots/mm (300dpi)
Print Mode Thermal Transfer/Direct Thermal Thermal Transfer/Direct Thermal
Printer CPU 16 Bit Processor
Sensor Location Moveable, left aligned
Sensor Type Reflective, Transmissive
Sensor Detection Type: Label gap and black mark sensing
Detection: Label length auto sensing and/or program command setting
Print Speed 50.8mm (2”)/sec ~ 152.4mm
(6”)/sec 50.8mm (2”)/sec ~ 101.6mm (4”)/sec
Print Length 5mm (0.20”) ~ 1270mm (50”) 5mm (0.20”) ~ 558.8mm (22”)
Print Width 5mm (0.20”) ~ 104mm (4.09”) 5mm (0.20”) ~ 105mm (4.13”)
Media
Label Roll: Max. 203mm (8”) O.D.
Core Diameter: 38.1mm (1.6”) ~ 76.2mm (3”)
Width: 25.0mm (1”) ~ 118.0mm (4.65”)
Thickness: 0.06mm (0.002”) ~ 0.25mm (0.009”)
Ribbon
Material: Thermal Transfer ribbons (wax, resin and wax/resin)
Type: Ink inside or ink outside
Length: 450m (1471’)
Width: 30mm (1.18”) ~ 110mm (4.33”)
Inner Core Diameter: 25.4mm (1”)
Ribbon Roll Diameter: 75mm (2.95”)
Printer Language TPL (Tharo Programming Language)
Software Application: EASYLABEL®Start
Driver: Microsoft Windows 95, 98, ME, NT 4, 2000 and XP
Resident Fonts
9 resident alphanumeric fonts (including OCR A & B) that are available in 4
orientations (0°, 90°, 180°, 270°), 8-point sizes (6, 8, 10, 12, 14, 18, 24, 30),
and are expandable 8 times horizontally and vertically.
Downloadable Fonts Windows Bit-map fonts and Asian fonts are downloadable. Windows fonts in 4
orientations (0°, 90°, 180°, 270°). Asian fonts in 8 orientations.
Image Handling BMP and PCX
Bar Codes
Code 39, Code 93, Code 128 (subset A, B, C), UCC 128, UPC A, UPC E, UPC 2 &
5 digit add on, I 2 of 5, EAN 8, EAN 13, EAN 2 & 5 digit add on, Codabar,
Postnet, EAN 128, DUN 14, MaxiCode, PDF417, and DataMatrix
Interfaces Serial, Parallel, USB, PS/2 keyboard
Serial Interface
Transmission Speed Baud rate 300 ~ 115200, XON/XOFF, DSR/DTR
Memory Built-In: 2MB Flash, 2MB DRAM Optional: An additional 2MB of Flash
LCD Display
Backlit Graphic LCD Display
Three bi-color LED lamps: Power, Ready, Error
Three Control keys: Feed, Pause, Cancel
Power 110/240VAC, 50/60 Hz
Real-Time Clock Time and Date stamp
Environment Operation: 5°C to 40°C (40°F to 104°F)
Storage: -20°C to 50°C (-40°F to 122°F)
Humidity Operation: 30-85%, non-condensing. Free air.
Storage: 10-90%, non-condensing. Free air.
Agency Listings CE, CUL, FCC Class A
Printer Dimensions
Length: 454.58mm (17.9”)
Height: 277.30mm (10.92”)
Width: 275.55mm (10.85”)
Weight: 13Kg (28.7lbs)
Options
Cutter with Tray
Internal Rewind
2MB Flash memory module
Stand-alone keyboard
- 6 -

2. General Safety Tips
CAUTION!
 During the print process the printhead will become hot. Do NOT attempt to clean the
printhead until it has had time to cool.
 The Printhead is the Most Fragile part of your Printer. Do NOT use sharp or hard objects to
clean the Printhead. Do NOT touch the glass surface of the Printhead with your hand.
 This Printer is built exclusively to print labels, tickets and tags, continuous paper, etc. Only
use media that is recommended for a direct thermal or thermal transfer Printer.
 The Printer is configured for input voltages of 110 to 240 V. Connect only to a power outlet
with a grounded contact. Always ensure the Printer is switched OFF before connecting the
power cord to an electrical outlet.
 Do not expose the Printer to moisture or operate it in wet or damp areas.
 The Printer will operate with the cover open if necessary. This is not recommended, as the
Printer’s moving or rotating parts can cause injury. Keep long hair, jewelry and loose clothing
away from any moving parts.
 Remove the power cord from the rear of the Printer when disconnecting or attaching
accessories such as rewind units, cutters, etc.
3. Unpacking the Printer and Accessories
Check the condition of the packaging and contents for possible damage during transit.
NOTICE: Please retain original boxes and all original packing materials in
case the Printer must be returned.
In addition to this manual the following items should be included with your Printer:
 Bar Code Printer
 Power Cord (110V or 230V)
 Empty Ribbon Roll
 Quick Start Guide
 Accessories CD: Includes Label Software, Manuals and Windows Drivers
The following additional items are necessary for generating labels from your Printer:
 Serial, Parallel, or USB cable
 Applicable media (label stock/ribbon)
- 7 -

4. Identifying Components
1 Top Cover 11 Label Width Guide 21 Ribbon Feed Rod
2 Indicator Light 12 Ink Position Lever 22 Label Feed Rods
3 Liquid Crystal Display
(LCD) 13 Printhead Spring Box 23 Label Feed Guide
4 Control Keys 14 Stripper Sensor 24 Fan-Fold Label Slot
5 Ribbon Rod 15 Tear-Off Bar 25 Power Socket
6 Bottom Front Cover 16 Printer Mechanism 26 Power Switch
7 Printhead Lever 17 Rewind Option Cover Plate 27 Parallel Port
8 Ribbon Rewind Shaft 18 Rewind Connector 28 USB Port
9 Ribbon Supply Shaft 19 Cutter Connector 29 Serial Port
10 Label Roll Bar 20 Cable Configuration Holes 30 PS/2 Port
- 8 -

31 Moveable Sensor Lever 32 Sensor Position Mark 33 Moveable Sensor
- 9 -

5. Printer Setup
CAUTION!
- 10 -
When choosing a location for the Printer, ensure that the Printer and
operator remain dry. If the Printer or the operator get wet, serious
injury to the operator or damage to the Printer may occur.
CAUTION!
Make sure that the Printer’s power switch is in the “O” or “Off”
position before proceeding with the installation.
1. Plug the supplied power cord into the Printer’s power socket.
2. Plug the other end of the power cord into a grounded outlet.
3. Select the correct cable for the chosen interface. The Printer can be directly connected to the PC
in one of 3 ways: USB, parallel, or serial. For the connection to the USB port use a suitable USB
cable. For the connection to the PC’s parallel port use a suitable parallel interface cable. If the
serial interface is used make sure the proper serial cable is used. You can find pin assignments
and descriptions for all three interfaces connectors in Appendix A.
NOTICE!
For Serial communications make sure that the “COM Port Setup Options” in
the Printer’s front panel are configured the same as the software you will
be using with the Printer.
NOTICE!
If you wish to connect the Printer to the computer using the USB interface,
you must install the “USB HS Serial Converter”. (See ‘Appendix A.
Communication Interfaces’ for more details.)
4. Connect the Printer to the computer with the selected cable. Then secure the cable using any
screws or clips attached to the connectors. These prevent the connection from working loose.
5. Turn the Printer on, the LCD will show the Printer model and firmware version.

6. Control Panel
General Description and Operation
Pause Key
Pressing the Pause key when the Printer is in Standby Mode will put the Printer in Pause Mode and
the LCD will display “H-xxx Hx.xxx Pause”. When the Printer is in Pause it will not receive any
commands. Pressing the Pause key again will take the Printer out of Pause and put it back in
Standby Mode.
Pressing the Pause key while the Printer is printing will pause the current print job. Pressing the
Pause key again will take the Printer out of Pause and the Printer will continue with the rest of the
print job. For example, if the print job contains 10 labels and the Pause key is pressed after 2 labels
are printed, the Printer will stop printing the job. When the Pause key is pressed again, the Printer
will resume printing the remaining 8 labels.
Cancel Key
Pressing the Cancel key while the Printer is printing will cancel the job. The LCD will display
“xxxxxxxx Cancel” this confirms the job has been cancelled. For example, if the print job contains
10 labels and the Cancel key is pressed after 2 labels are printed the Printer will stop printing labels
and the remaining 8 labels will not be printed.
Feed Key
Pressing the Feed key will cause the Printer to advance the media (according to media type) to a
specified stop position. If the Printer is loaded with continuous media the Printer will feed the media
out a certain length. If the Printer is loaded with labels with gaps or black marks, the Printer will
advance one label at a time. If the label is not sent out in a correct position the sensor must be
calibrated. Follow the instructions for Sensor Calibration in the Maintenance and Adjustment section
of this manual.
Setting Mode
In Setting Mode you are able to change the various settings that control the operation of the Printer
such as: printing mode, options, media type, interface options, and language display.
1. To enter Setting Mode: Press and hold the ”Pause” key and ”Feed” key until the LCD
shows ”Setting Mode.”
2. Release the keys and you are now in “Setting Mode.” The first option will be displayed on
the LCD.
3. In Setting Mode, the control keys have the following functions:
Feed Key: Select or scroll through the available selections
Pause Key: Enter or confirm
Cancel Key: Exit
4. Current settings are displayed in highlighted text on the LCD.
5. Before exiting Setting Mode, the Printer will prompt the user if the settings should be saved or
not.
6. After user’s response, on whether or not to save the settings, the Printer will return to
Standby Mode.
- 11 -

Menu items and available options in Setting Mode
NOTICE!
“Default Setting” is the value of the setting as delivered from the factory.
Any changes made in Setup Mode are saved after the Printer is turned off.
Printing Mode
Thermal Transfer: when printing, a ribbon must be installed to transfer the
print contents onto the media.
Direct Thermal: when printing, no ribbon is necessary; it only requires direct
thermal media.
Option Setup
Strip Mode: turns the Stripper Sensor on
Cutter Mode: turns the Cutter on
Option OFF: turns off the Stripper Sensor or Cutter. This is the default
setting.
Applicator: Sets printer to be used with an applicator or foot switch.
Paper Setup
Black Mark: for label or plain paper with black mark on the back.
Gap Paper: for labels with liner and gap, or hang tags. The default is set to
be gap paper.
Plain Paper: continuous media without gaps or sensing marks.
COM Port Setup
Baud Rate: 4800/ 9600/ 19200/ 38400 /57600 /115200 bps, default: 9600
Parity Set: None / Odd / Even, default: None
Data Length: 7 / 8 bits, default: 8 bits
Stop bit: 1 / 2 bits, default: 1 bit
Auto Sensor
Auto Mode: automatically senses and sets the label type (black mark, gap or
plain paper) and length
Gap Mode: detects label stock with gaps
Black Mode: detects label stock with black marks
LCD Language
English
Simplified Chinese
Traditional Chinese
Spanish
Italian
German
French
Turkish
Code Page Setup Code Page 850, Code Page 852
Keyboard Setup
US International
United Kingdom
French
German
Spanish
Italian
Finnish
Dutch
Belgian
Keyboard Mode
Pressing Enter allows the user to use a keyboard connected to the Printer for
stand-alone printing. (This is the same as connecting the keyboard to the
Printer and then pressing the ‘Y’ key.)
Buzzer Setup
On: The printer will sound the buzzer (beep) as a confirmation of most
events.
Off: The printer will only sound the buzzer (beep) when there is a condition
that requires the operator’s attention.
- 12 -

Smart Backfeed
When in stripper or cut mode, a label is printed and moved forward to be cut
or peeled off. If Smart Backfeed is ON, the next label will be partially printed
so the printer does not have to backfeed to find the original starting point
when printing continues.
On: Turns smart backfeed on
Off: Turns smart backfeed off. (default)
Printhead position
Defines the location of the print image on the label.
Range is –100 to +100 (hundredths of inches) (-.254mm - .254mm)
Positive values cause the print image to be moved to the trailing edge of the
label.
Password On: Allows user to set a password to restrict setup changes.
Off: Allows any user to change setup selections. (default).
Preview
Selecting “Preview” allows the user to browse the current configuration
settings on the LCD. Pressing the Feed Key will allow the user to scroll
through the list of configuration options.
- 13 -

Interpreting LCD/LED Messages
LED Light
LCD
Display Power Ready Error Beep
Description
Model Name
Hx.xxx Green Green 1 H-xxx: Printer model; Hx.xxx: current firmware version.
Self-Test Green Green 3
Printer is in Self-Test Mode. Refer to Appendix B
for more information.
Now in
Dump Mode Green Green 3 Printer is in Dump Mode. Refer to Appendix B for
more information.
Auto
Sensing Mode Green 3
Printer is in Auto-Sensing Mode. Please refer to
Appendix C for more information.
Model Name
Pause Green Green Printer has paused, press Pause key again to continue printing.
Print job is
cancelled Green Green Cancel key pressed, stops all print jobs and clears
the Printer.
Press Feed key
to continue
print job
Green Red
Press the Feed key to allow Printer to continue
with the current print job.
PROGRAM
LOADING Green Red
(Flash) Printer is downloading the firmware.
LOADING
COMPLETE Green Green 1 Firmware has been successfully downloaded.
Setting Mode Green Green 1 Printer is currently in the Setting Mode. Please see
the Setting Mode section for more information.
- 14 -

7. Loading Media
Ribbon Out
If the ribbon runs out during a print job, the Printer will beep four times and the Red error light will
glow. An “Out of ribbon or check ribbon sensor” message will be displayed on the Printer’s front
panel. Replace the ribbon by following the instructions in this manual. Press the Feed key to
resume printing.
Ribbon Installation
1. Open the Printer’s top cover.
2. Pull the Printhead Lever out and rotate
it upward to the right
(counterclockwise) to open the
Thermal Printhead.
3. Remove the used ribbon from the
Ribbon Rewind Shaft. Remove the
empty ribbon core from the Ribbon
Supply Shaft.
4. Place the new ribbon roll onto the
Ribbon Supply Shaft.
5. Place the empty ribbon core onto the
Ribbon Rewind Shaft.
6. Feed the ribbon from the Ribbon
Supply Shaft Rod under the Printhead.
Be sure that the ribbon is not fed
under the Moveable Sensor.
- 15 -

7. Wrap the ribbon around the Ribbon
Shaft Rod making sure that the ribbon
rewind direction is correct.
8. Ribbon outside (ink outside the roll).
9. Ribbon inside (ink inside the roll).
10. Attach the end of the ribbon to the
empty ribbon core using adhesive tape
or part of a label.
11. Rotate the Printhead Lever clockwise
back to its original position making
sure it snaps into place.
12. Close the top cover to complete the
ribbon installation.
- 16 -

Label Installation
1. Open the Printer’s top cover.
2. Slide the roll of label stock onto the
Label Roll Bar all the way back to the
Printer’s inner wall.
3. Slide the Label Width Guide in until it
rests against the label stock. Avoid
pushing the guide in too far or you
will damage the edge of the label
stock.
4. Pull the Printhead Lever out and
rotate it up and to the right
(counterclockwise) to open the
Thermal Printhead.
5. Slide the Outside Label Feed Guide
to its outermost position and rotate
it upward.
6. Feed the label stock through the two
Label Feed Rods to the Tear-Off Bar.
Make sure the label stock is fed
under the Moveable Sensor.
- 17 -

7. Slide the inside edge of the label
stock inward against the Inside Label
Feed Guide. Then, slide the Outside
Label Feed Guide inwards until it
contacts the outside edge of the
label stock.
8. Rotate the Outside Label Feed Guide
back down to its original position and
clip the guide in position.
9. Rotate the Printhead Lever clockwise
back to its original position making
sure it snaps into place.
10. Close the top cover to complete the
label installation.
Activating the Stripper Sensor
The Stripper Sensor senses the presence of printed labels. With the Stripper Sensor activated, it is
possible to operate the Printer in Tear-Off or Peel-Off (Strip-and-Peel) modes. See the “THARO H-
Series Internal Rewind Module Installation Instructions” section in this manual for more information
about setting the Printer up for Strip-and-Peel.
To set up the Printer to operate in Tear-Off mode:
1. Press the Stripper Sensor (D) to flip
it open.
2. Correctly position the sensor and
close the Top Cover of the Printer.
3. Turn the Stripper Sensor on in the
Printer’s Setup Mode.
NOTICE!
When the Printer’s Stripper Sensor is activated, it blocks part of the Tear-
Off Bar. This can be a problem if the printed labels will be torn off after
they are printed. In this case it is recommended to use perforated label
stock to make tearing off the printed labels easier.
- 18 -

8. Installing the Printer’s Optional Accessories
The Optional Internal Rewind or Cutter can be easily installed and configured in the field using only a
number 2 Phillips screwdriver. This section will provide a component list and installation instructions
for both of these optional accessories.
CAUTION!
Make sure that the Printer’s power switch is in the “O” or “Off”
position before proceeding with the installation.
CAUTION!
Unplug the power cord from the Printer before performing any service
on it. Failure to do so could result in personal injury or damage to the
Printer!
THARO H-Series Internal Rewind Module Components
1.
2.
3.
Internal Rewind Module
U-Shaped Metal Clip
Screws (M3X4.5) Qty. 4
NOTICE!
The Internal Rewind must be used with the Stripper Sensor. Make sure
the Stripper Sensor is turned on in the Printer’s Setup Mode before using
the Internal Rewind.
NOTICE!
When the diameter of the wound label liner reaches about 110mm (4.33”)
the liner will touch the maximum liner switch and the Printer will stop
printing. The Printer will not resume printing until the used liner is
removed.
- 19 -
