The Container Store Clybourn Sparrow Bench User manual

PAGE 1 OF 11PRODUCT INFO
The Original Storage and Organization Store®
Clybourn Sparrow Bench
Assembly Instructions

PAGE 2 OF 11PAGE 2 OF 11
A
B
C
D
E
F
G
H
I
J
K
L
M
1
1
1
1
1
1
1
1
1
1
1
1
1
PARTS LIST
Please review the hardware listed on the next page as well as individual components of
this product. As you unpack and prepare for assembly, place the contents on a carpeted
or padded area to protect them from damage.
Top Panel
Left Panel
Right Panel
Bottom Panel
Rail
Back Panel
Bin Door
Bin Back Panel
Bin Left Panel
Bin Right Panel
Bin Bottom Panel
Bin Top Panel
Cushion
C
D
F
G
I
J
H
E
B
A
M
K
L

PAGE 3 OF 11
HARDWARE & TOOLS
H1 x 10
CAM BOLT
H5 x 2
PIN
H3 x 6
THICK
CAM
H13 x 8
DOWEL
H14 x 4
SMALL
DOWEL
H8 x 10
CAM COVER
H15 x 1
HINGE
H9 x 4
BOLT
H16 x 1
RIGHT
CONNECTOR
H10 x 4
LOCK
WASHER
H17 x 1
LEFT
CONNECTOR
H11 x 4
WASHER
H18 x 4
SHORT PAN
HEAD SCREW
H12 x 1
ALLEN
WRENCH
H19 x 2
SMALL
WASHER
H7 x 14
TRUSS HEAD
SCREW
H2 x 4
THIN
CAM
H6 x 4
LONG PAN
HEAD SCREW
H4 x 5
SHORT PAN
HEAD SCREW
TOOLS REQUIRED: Phillips Screwdriver | Two People

PAGE 4 OF 11HOW TO USE CAM LOCK SYSTEM
180º
1 2 3
4 5

PAGE 5 OF 11
STEP 1 STEP 2
ASSEMBLY
H1 x 4
CAM BOLT
H6 x 4
LONG PAN
HEAD SCREW
H2 x 4
THIN CAM
H8 x 4
CAM
COVER

J
(H18)
(H14)
PAGE 6 OF 11
STEP 3 STEP 4
ASSEMBLY
H4 x 5
SHORT PAN
HEAD SCREW
H17 x 1
LEFT
CONNECTOR
H18 x 2
SHORT FLAT
HEAD SCREW
H1 x 2
CAM BOLT
H10 x 2
LOCK
WASHER
H3 x 2
THICK CAM
H11 x 2
WASHER
H8 x 4
CAM
COVER
H9 x 2
BOLT
H13 x 3
DOWEL
H14 x 2
DOWEL
H12 x 1
ALLEN
WRENCH

B
(H19)
(H5)
45
45
E
STEP 5
H5 x 1
PIN
STEP 6
H1 x 1
CAM BOLT
H13 x 1
DOWEL
H3 x 1
THICK CAM
PAGE 7 OF 11ASSEMBLY
H19 x 1
SMALL
WASHER

C
STEP 7
PAGE 8 OF 11
STEP 8
ASSEMBLY
H14 x 2
DOWEL
H13 x 4
DOWEL
H5 x 1
PIN
(H14)
H15 x 1
HINGE
H16 x 1
RIGHT
CONNECTOR
H18 x 2
SHORT FLAT
HEAD SCREW
(H19)
(H5)
H19 x 1
WASHER

STEP 10
C
PAGE 9 OF 11ASSEMBLY
H12 x 1
ALLEN
WRENCH
STEP 9
H1 x 3
CAM BOLT
H10 x 2
LOCK
WASHER
H3 x 3
THICK CAM
H11 x 2
WASHER
H8 x 2
CAM
COVER
H9 x 2
BOLT
H12 x 1
ALLEN
WRENCH
Adjust braking hinge
tension using the
provided allen
wrench. Turn clock-
wise to add tension,
turn counter-clock-
wise to reduce
tension.

Begin by installing all of the screws along one edge
of the back panel. Next, using a square or tape
measure, make sure that the cabinet is square.
(If using a tape measure, the distance from one
corner, diagonally to the other corner should be
the same in both directions.) Install the remaining
screws, starting with the corners.
pre-drilled
holes
PAGE 10 OF 11ASSEMBLY
STEP 12
STEP 11
H7 x 14
TRUSS HEAD
SCREW
H8 x 2
CAM COVER

PAGE 11 OF 11CARE INSTRUCTIONSThe Original Storage and Organization Store®
WARNING: Do not exceed the recommended weight limits on the designated panels. Exceeding these
limits could cause sagging, possibly resulting in failure of product or bodily injury. Severe injury may occur
if furniture tips over. Never allow children to climb or play on this product. Place heaviest items on lower
shelves and as far back as possible, never overload product.
250 lbs
25 lbs
!WARNING
This product is not intended
or suitable for a toy chest.
