The Container Store Clybourn 4 Cube Cubby Tall User manual

PAGE 1 OF 8PRODUCT INFO
The Original Storage and Organization Store®
Assembly Instructions
Clybourn 4 Cube Cubby Tall

PAGE 2 OF 8PAGE 2 OF 8
A
B
C
D
E
F
1
2
1
1
2
1
Top Panel
Side Panel
Center Fixed Shelf
Bottom Panel
Fixed Shelf
Back Panel
PARTS LIST
Please review the hardware listed on the next page as well as individual components of
this product. As you unpack and prepare for assembly, place the contents on a carpeted
or padded area to protect them from damage.
A
D
E
E
F
B
B
C

PAGE 3 OF 8
HARDWARE & TOOLS
H1 x 12
CAM BOLT
H6 x 2
PAN HEAD
SCREW
H11 x 2
CORNER
BRACKET
H13 x 20
DOWEL
H4 x 16
TRUSS HEAD
SCREW
H8 x 4
WASHER
H2 x 4
THIN CAM
H3 x 8
THICK CAM
H7 x 2
WALL STRAP
H12 x 4
FLAT HEAD
SCREW
H5 x 2
WALL ANCHOR
H9 x 2
WALL
SCREW
H10 x 12
CAM
COVER
TOOLS REQUIRED: PHILLIPS SCREWDRIVER

PAGE 4 OF 8HOW TO USE CAM LOCK SYSTEM
180º
1 2 3
4 5

PAGE 5 OF 8
STEP 1 STEP 2
ASSEMBLY
H1 x 4
CAM BOLT
H3 x 4
THICK CAM
H13 x 8
DOWEL
H10 x 4
CAM
COVER
H10 x 4
CAM
COVER
H1 x 4
CAM BOLT
H3 x 4
THICK CAM
H13 x 8
DOWEL
front edge

PAGE 6 OF 8
STEP 3 STEP 4
ASSEMBLY
H11 x 2
CORNER
BRACKET
H1 x 4
CAM BOLT
H2 x 4
THIN CAM
H13 x 4
DOWEL
H10 x 4
CAM
COVER
H4 x 16
TRUSS HEAD
SCREW
H12 x 4
FLAT HEAD
SCREW
(H12)

PAGE 7 OF 8
STEP 5
ASSEMBLY
(H6)
(H7)
(H8)
H6 x 2
PAN HEAD
SCREW
H7 x 2
WALL
STRAP
H8 x 4
WASHER
Position against wall
Mark position of strap hole
on wall
Drill 1/4’’ hole
tap in wall anchor
Fasten anti-tip strap with
wall screw provided
H9
H8
H5
H5 x 2
WALL
ANCHOR
H9 x 2
WALL
SCREW

PAGE 8 OF 8CARE INSTRUCTIONSThe Original Storage and Organization Store®
WARNING: Do not exceed the recommended weight limits on the designated panels. Exceeding these
limits could cause sagging, possibly resulting in failure of product or bodily injury. Severe injury may occur
if furniture tips over. Never allow children to climb or play on this product. Place heaviest items on lower
shelves and as far back as possible, never overload product.
15 lbs
15 lbs
15 lbs
15 lbs
15 lbs
