The Handy THLS-4 Installation and maintenance instructions

OPERATOR’S MANUALAND PARTS LIST
4 and 6 Ton Log Splitters - THLS-4 and THLS-6
Spares & Support: 01793 333212
www.thehandy.co.uk
Before use please read & understand this manual, paying particular
attention to the safety instructions.
Whilst every effort is made to accurately represent the product, small variations in colour, design and specification may occur. We reserve the right to
alter the product without giving notice.
23-06-2014

SAFETY WARNINGS & INSTRUCTIONS SYMBOLAFFIXED TO THE
MACHINE
zUNDERSTAND YOUR LOG SPLITTER
Read and understand the owner’s manual and the labels affixed
to the log splitter. Learn its application and limitations as well as
the specific potential hazards peculiar to it.
zDRUGS, ALCOHOL AND MEDICATION
Do not operate the log splitter while under the influence of drugs,
alcohol, or any medication that could affect your ability to use it
properly.
zAVOID DANGEROUS CONDITIONS
Put the log splitter on a 60 - 75cm high, stable, flat, and level
work bench where there is plenty of room to work. Bolt the log
splitter to the work surface if it tends to slip, walk, or slide.
Keep your work area clean and well lighted. Cluttered work areas
increase the likelihood of injuries occurring.
Do not use the log splitter in wet or damp areas or expose it to
rain.
Do not use it in areas where fumes from paint, solvents or
flammable liquids pose a potential hazard.
zINSPECT YOUR LOG SPLITTER
Check your log splitter before turning it on. Keep guards in place
and in working order. Frequently check to see that keys and
adjusting wrenches are removed from the tool area before
turning it on. Replace damaged, missing or failed parts before
using it.
zDRESS PROPERLY
Do not wear loose clothing, neckties or jewelry (rings, wrist
watches). They can be caught in moving parts.
Protective electrically non conductive gloves and non-skid
footwear are recommended when working. Wear protective hair
covering to contain long hair, preventing it from getting caught in
the machinery.
zPROTECT YOUR EYES AND FACE
Any log splitter may throw foreign objects into the eyes. This can
cause permanent eye damage. Always wear safety goggles.
Everyday eyeglasses have only impact resistant lenses. They
are not safety glasses.
Do not put the log splitter on the ground for operations. This is an
awkward operating position and may cause the operator to bring
their face close to the machine and risk being struck by wood
chips or debris.
2

zEXTENSION LEADS
Improper use of extension leads may cause inefficient operation
of the log splitter which can result in overheating. Be sure the
extension lead is no longer than 10m and its cross-section is no
less than 2.5mm2to allow sufficient current flow to the motor.
Avoid use of loose or inadequately insulated connections.
Connections must be made with a protected material suitable for
outdoor use.
zAVOID ELECTRICAL SHOCK
Check that the electric circuit is adequately protected and that it
corresponds with the power, voltage and frequency of the motor.
Check that there is a ground connection, and a regulation
differential switch further up the circuit.
Ground the log splitter. Prevent body contact with grounded
surfaces: pipes, radiators, ranges, and refrigerator enclosures.
Never open the pushbutton box on the motor. Should this be
necessary, contact a qualified electrician.
Make sure your fingers do not touch the plug’s metal prongs
when plugging or unplugging the log splitter.
zKEEP VISITORS AND CHILDREN AWAY
The log splitter must only be operated by one person. Other
people should keep a safe distance from the work area,
especially when the log splitter is under operation. Never use
another person to help you with freeing a jammed log.
zINSPECT YOUR LOG
Make sure there are no nails or foreign objects in logs to be split.
The ends of the logs must be cut square. Branches must be cut
off entirely so that the trunk is relatively smooth.
zDON’T OVERREACH
Floor must not be slippery.
Keep proper footing and balance at all times.
Never stand on the log splitter. Serious injury could occur if the
tool is tipped or if the cutting tool is unintentionally contacted. Do
not store anything above or near the log splitter so that someone
might stand on the tool to reach them.
zAVOID INJURY FROM ACCIDENTS
Always pay full attention to the movement of the log pusher.
Do not attempt to load the log on until the log pusher has
stopped.
Keep hands out of the way of all moving parts.
zPROTECT YOUR HANDS
Keep your hands away from splits and cracks which open in the
log. They may close suddenly and crush your hands.
Do not remove jammed logs with you hands.
3

zDO NOT FORCE THE TOOL
It will do a better and safer job at its designed rate. Never try to
split logs larger than those indicated in the specifications table.
This could be dangerous and may damage the machine.
Do not use log splitter for a purpose for which it was not
intended.
zNEVER LEAVE THE TOOL RUNNING UNATTENDED
Do not leave the tool until it has come to a complete stop.
zDISCONNECT POWER
Unplug when not in use, before making adjustments, changing
parts, cleaning, or working on the log splitter. Consult the
technical manual before servicing.
zPROTECT THE ENVIRONMENT
Take used oil to an authorized collection point or follow the local
stipulations that apply where the log splitter is being used.
Do not discharge into drains, soil or water.
zMAINTAIN YOUR LOG SPLITTER WITH CARE
Keep the log splitter clean for the best and safest performance.
zSTORE THE LOGSPLITTER SAFELY
Store the log splitter away from children and others not qualified
to use it.
TABLE OF CONTENTS
Safety Warnings & Cautions ………………………………………………………………….…. 2
Working Conditions ….……………………………………………………………………….……4
Specifications ……………………………………………………………………………………... 5
Electrical Requirements ………………………………………………………………………….. 5
Set up and Preparation for Operation ………………………………………………………….. 6
Wiring Diagram …………………………………………………….……………………………... 7
Hydraulics Diagram ..……………………………………………………………………………... 7
Log Splitter Operation ……………………………………………………………………………. 8
Freeing a Jammed Log …………………………………………………………………………. ..9
Ram Adjustment…………………………………………………………………………………..10
Replacing The Hydraulic Oil ……………………………………………………………………. 11
Sharpening The Wedge ………………………………………………………………………… 11
Trouble Shooting ………………………………………………………………………………... 12
Parts Schematic……………………………………………………………………………….…. 13
WORKING CONDITIONS
This log splitter is a domestic use model. It is designed for operating under ambient
temperatures between +5oC and 40oC and for installation at altitudes no more than 1000m
above M.S.L. The surrounding humidity should be less than 50% at 40oC. It can be stored
or transported under ambient temperatures between -25oC and 55oC.
4

SPECIFICATIONS
Model Number THLS-4 THLS-6
Motor 230V~ 50Hz 1500W IP54 230V~ 50Hz 2200W S6
(40%) IP54
Diameter * 5 - 25cm Log
Capacity Length 37cm 52cm
Splitting Force 4 t 6 t
Hydraulic Pressure 16Mpa 20Mpa
Hydraulic Oil Capacity 2.4L 3.5L
Length 780mm 940mm
Width 270mm
Overall
Size Height 510mm
Stroke Length 220mm 370mm
Weight 38kg 45kg
* The diameter of the log is not the only factor that determines how easy it will be to split. A
small log can be difficult to split when it has knots or is a particularly hard wood.
ELECTRICAL REQUIREMENTS
Connect the main leads to a standard 230V+10% (50Hz+1Hz) electrical supply which has
protection devices for under-voltage, over-voltage, over-current as well as a residual
current device (RCD) with maximum residual current rated at 0.03A.
5

SET UP AND PREPARATION FOR OPERATION
1. Bolt the Support Leg to the Log Splitter, lift the log splitter by the handles at both ends
and place it on a 60 – 75cm high, stable, flat and level work surface.
2. Familiarize yourself with the controls and features of this log splitter in the illustrations.
1. Log Pusher
2. Work Table
3. Wedge
4. Handle
5. Support Leg
6. Log Retaining Plates
7. Switch
8. Motor
9. Electric Motor Switch Case
10.Wheels (for short distances
ONLY).
11.Hydraulic Control Lever
12.Control Lever Guard
13.Bleed Screw
14.Oil Drain Bolt w/ Dipstick
Before operating the log splitter, the Bleed Screw should be loosened a few rotations
until air can go in and out of the oil tank smoothly.
Air flow through the Bleed Screw hole should be noticeable while the log splitter is
working.
Before moving the log splitter, make sure the Bleed Screw is tightened to avoid oil
leaks.
FAILURE TO LOOSEN THE BLEED SCREW WILL KEEP THE SEALED AIR IN
HYDRAULIC SYSTEM COMPRESSED. SUCH CONTINUOUS AIR COMPRESSION WILL
BLOW OUT THE SEALS OF THE HYDRAULIC SYSTEM AND CAUSE PERMANENT
DAMAGE TO THE LOG SPLITTER.
6

15. Max Pressure Limiting Screw
DO NOT ADJUST THE MAX PRESSURE
LIMITING SCREW !
The max pressure was set by the
manufacturer. The max pressure
limiting screw is sealed with glue to
ensure the log splitter works under
pressure no more than is listed in the
specifications. The setting was made
by a qualified mechanic with
professional instruments.
Unauthorized resetting will reduce the
performance of the hydraulic pump to
or RESULT IN SERIOUS INJURY AS WELL AS
DAMAGE TO THE MACHINE .
WIRING DIAGRAM PLUMBING DIAGRAM
7

LOG SPLITTER OPERATION
This log splitter is equipped with “ZHB” control system that must be operated with both of
the users hands – the left hand controls the hydraulic control lever while right hand controls
the pushbutton switch. The log splitter will freeze if either hand is removed. The log pusher
will only start to return backward to the starting position after both hands release the
controls. During use the logpusher will move towards the splitting wedge putting pressure
on the log.
The trigger type lockout device is used to avoid accidental Hydraulic Control Lever
activation. To operate the Hydraulic Control Lever, draw the Trigger backward with your
index finger before pushing the Hydraulic Control Lever forward.
Never force the log splitter for more than 5 seconds. Do not keep pressure
on it to split excessively hard wood.
After 5 seconds of constant use, the oil under pressure will be overheated and the machine
could be damaged. For such extremely hard logs, rotate it by 90oto see whether it can be
split in a different direction (the log should still be split with the grain as shown in the
diagrams in this manual). In any case, if you are not able to split the log, this means that its
hardness exceeds the capacity of the machine and thus that log should be discarded to
protect the log splitter.
8

Always set logs firmly on the log
retaining plates and work table. Make
sure that the log will not twist, rock or
slip while being split. Do not force the
blade by splitting the log on the upper
part of the wedge (as shown in the
diagram). This will break the blade or
damage the machine.
Break the log in the direction of its growing grain. Do not place log across the log splitter for
splitting. It may be dangerous and may seriously damage the machine.
Do not attempt to split 2 pieces of logs at the same time. One of them may be thrown by the
machine which could cause serious injuries to the user.
FREEING A JAMMED LOG
zRelease both controls.
zAfter the log pusher moves back and
completely stops at its starting position,
insert a wedge of wood under the jammed
log.
zStart the log splitter to push the wedge
wood to go completely under the jammed
one.
zRepeat above procedure with sharper
sloped wedges of wood until the log is
completely freed.
Do not try to knock the jammed log off.
This will damage the machine or may
launch the log and cause serious
injuries.
9

RAM ADJUSTMENT
The Handy Log Splitters are fitted with a Ram Adjustment Knob which reduces any
unnecessary movement of the ram, allowing for quicker and more efficient use of the tool.
Warning: When adjusting the ram movement do not put your hands between the hand
knob and the logsplitter, as accidental release of the Control Handle would cause the
returning hand knob and handle to trap and crush your hand against the splitter.
•To adjust the ram movement, first undo the hand knob.
•Then without a log on the work table depress the Control Handle and the start
button.
•When the gap between the ram and the splitting wedge is the intended size, release
the start button, but continue to hold the Control Handle to keep the ram in place.
•Slide the hand knob along the pipe to set the gap size. The closer you move the
Ram Adjustment Knob towards the Log Splitter, and the more you slide it down the
pipe, the smaller the gap will be left between the ram and the splitting wedge.
oIf the gap is correct you should place the hand knob against the log splitter.
oIf the gap is too small you can leave an equivalent space between the knob
and the logsplitter so that the ram returns further back.
oIf the gap is too small you will have to press the start button to reduce it before
setting the Ram Adjustment Knob.
•Once you have set the hand knob at the
desired position, retighten it to adjust the
movement of the ram.
•Make sure that your hand is clear of the
hand knob area. You can now release the
Control Handle. The Ram should now return
to the desired position whenever you
release the start button and Control Handle.
You can repeat these steps if further
adjustment is required.
Ram
Adjustment
Knob
10

REPLACING HYDRAULIC OIL
The logsplitter is usually empty when supplied, you
should therefore check if hydraulic oil needs to be
added. You should also replace the hydraulic oil in
the log splitter after every 150 hours of use. Follow
the steps below to replace it.
zMake sure all moving parts stop and the log
splitter is unplugged.
zUsing an Allen key, unscrew the Oil Drain Bolt
with Dipstick and remove it.
zTip the log splitter onto the Support Leg side
over a 4 litre capacity container to drain the
hydraulic oil off.
zTip the log splitter on the motor side.
zRefill with fresh hydraulic oil as per the hydraulic
oil capacity indicated in the specifications.
zClean the Dipstick and put it back into the oil
tank while keeping the log splitter held upright.
zMake sure the level of the refilled oil is just
between the 2 grooves around the Dipstick.
zClean the Oil Drain Bolt before replacing it.
Make sure they are tightened to avoid leaks
before lowering the log splitter back to a
horizontal position.
Periodically check the oil level to ensure it is
between the 2 grooves around the Dipstick. If
the oil level is lower, refill the oil. To check the
oil level, stand the logsplitter onto its wheels
and remove the dipstick. The oil level should be
between the 2 grooves.
The following hydraulic oils or equivalent are recommend for the log splitter’s
hydraulic transmission system:
Handy Parts Logsplitter Oil (Available from Handy Garden Machinery on 01793 333203.
1 Litre sold under Product Code WPL110, 5 Litres WPL113)
SHELL Tellus 22
MOBIL DTE 11
ARAL Vitam GF 22
BP Energol HLP-HM 22
11

SHARPENING WEDGE
After using the log splitters for some time, sharpen the wedge of the log splitter using a
fine-toothed file and smooth any burrs or crushed areas along the cutting edge.
TROUBLE SHOOTING
PROBLEM PROBABLE CAUSE REMEDY SUGGESTED
Log is improperly positioned Refer to the “Log Splitter Operation” section
for log loading instructions.
The sizes or hardness of the log
exceeds the capacity of the machine Reduce the log sizes before splitting it on the log splitter
Wedge cutting edge is blunt Refer to “Sharpening Wedge“ section to
sharpen the cutting edge.
Oil leaks Locate leak(s) and contact the dealer
Fails to split logs
Unauthorized adjustment was made
on Max. Pressure Limiting Screw.
Lower max pressure rating was set. Contact the dealer.
The log pusher
moves jerkily,
making unfamiliar
noises or vibrating
excessively
Lack of hydraulic oil
Excessive air in the hydraulic
system.
Check oil level for possible oil refilling.
Remove the bleed screw. Operate the ram 5
or 6 times without a log in place. Return the
bleed screw and split the log. If the problem
continues contact the dealer.
Air sealed in the hydraulic system
while operating. Loosen the Bleed Screw by 3 - 4 rotations before operating the log splitter
Bleed Screw was not tightened
before moving the log splitter. Tighten the Bleed Screw before moving the log splitter.
The Oil Drain Bolt with Dipstick is
not tight. Tighten the Oil Drain Bolt with Dipstick.
Oil leaks around
the cylinder ram or
from other points.
The Hydraulic Control Valve
Assembly and / or seal(s) are worn Contact the dealer
12

PARTS SCHEMATIC
13

THLS-4 Parts List
No Part No Description Qt
y
No Part No Description Qt
y
1 TH114-38 Lever Mount Nut 154 TH114-21 Screw 4
2 TH114-33 Nut Cap 355 TH114-88 Wheel Cover 2
3 TH114-36 Lever 156 TH114-89 Block Turn 2
4 TH114-37 Lever Knob 157 TH114-90 Wheel 2
5 TH114-34 Guard Plate 158 TH155-58 Washer 2
6 TH114-35 Nut 259 TH114-39 Wheel Shelf 1
7 TH114-28 Copper Gasket 460 TH114-87 Bolt 6
8 TH155-8 Screw 161 TH155-61 Spring Washer 9
9 TH155-9 O-ring 162 TH155-62 Washer 9
10 TH155-10 Snap Washer – Shaft 163 TH114-83 Gear Pump Cover 1
11 TH155-11 Valve Retract Spring 164 TH144-64 Spring 2
12 TH114-32 O-ring 165 TH186-76 Gear Housing Plate 1
13 TH114-43 Valve Core Rod 166 TH114-79 Circlip 2
14 TH155-14 Sliding Pressure Sensor Sleeve 167 TH186-80 Gear Shaft 1
15 TH155-15 Sliding Pressure Sensor Sleeve Spring 168 TH114-78 Steel Ball 1
16 TH186-27 Aluminium Cover (Rear) 169 TH186-77 Gear 2
17 TH186-26 O-ring 170 TH155-70 Pin 1
18 TH186-3 Piston 171 TH114-69 Washer 6
19 TH186-2 Piston Ring 172 TH114-70 Bolt 3
20 TH114-4 O-ring 173 TH114-71 Motor Cover 1
21 TH186-5 Spring 174 TH114-57 Seal 1
22 TH186-15 Stud 475 TH114-54 Nut 1
23 TH186-1 Hydraulic Cylinder 176 TH114-55 Screw 1
24 TH186-61 Aluminium Cover (Front) 177 TH186-65 Motor 1
25 TH114-12 Piston Rod Seal 178 TH155-78 Fan 1
26 TH114-14 O-ring 179 TH155-79 Block Turn 1
27 TH114-13 Bleed Screw 180 TH155-80 Shroud 1
28 TH114-62 Washer Groupware 181 TH155-81 Flat Washer 2
29 TH186-63 Dipstick 182 TH155-82 Spring Washer 3
30 TH186-6 Piston Rod 183 TH155-83 Screw 2
31 TH114-9 Lift Handle 184 TH114-59 Support Leg 1
32 TH114-10 Screw 285 TH155-85 Nut 5
33 TH186-20 Frame Tube 186 TH114-60 Bolt 5
34 TH186-19 Lead Plank 287 TH114-65 Cable & Plug 1
35 TH114-17 Spring Washer 488 TH114-66 Motor Foot Nut 3
36 TH114-16 Screw 689 TH114-67 Motor Foot 1
37 TH114-11 Nut 290 TH114-90 Electrical Cable Housing 1
38 TH114-8 Flat Washer 291 TH114-91 Screw 11
39 TH114-7 Nut 292 TH114-92 Switch Box Cover 1
40 TH114-51 Valve Plug 193 TH114-93 Airproof Underlay 1
41 TH114-50 Washer 194 TH114-94 Switch 1
42 TH155-42 Valve Sleeve 195 TH114-95 Connection Terminal 1
43 TH155-43 Spring 596 TH114-96 Capacitor 1
44 TH155-44 Adjusting Screw 197 TH114-97 Switch Box 1
45 TH114-40 Steel Ball 198 TH114-98 Waterproof Underlay 1
46 TH114-29 Pressure Valve Spring 199 TH114-73 Motor Support Left Shoe 1
47 TH114-30 Adjusting Screw 1100 TH114-72 Motor Support Right Shoe 1
48 TH186-53 Log Pusher Weldment 1101 TH114-75 Pin 2
49 TH114-52 Plastic Inserts 1 1102 TH114-82 Spring 2
50 TH114-23 Plastic Insert 2 1103 TH114-81 Sliding Sleeve 4
51 TH114-24 Log Pusher 1104 TH114-84 Bolt 3
52 TH114-25 Nut 4105 TH114-105 Ram Stopper 1
53 TH114-22 Flat Washer 5106 TH114-106 Ram Stopper 3-Star Screw 1
14

THLS-6 Parts List
No Part No Description Qt
y
No Part No Description Qt
y
1TH114-38 Lever Mount Nut 154 TH114-21 Screw 4
2TH114-33 Nut Cap 355 TH114-88 Wheel Cover 2
3TH114-36 Lever 156 TH114-89 Block Turn 2
4TH114-37 Lever Knob 157 TH114-90 Wheel 2
5TH114-34 Guard Plate 158 TH155-58 Washer 2
6TH114-35 Nut 259 TH114-39 Wheel Shelf 1
7TH114-28 Copper Gasket 460 TH114-87 Bolt 6
8TH155-8 Screw 161 TH155-61 Spring Washer 9
9TH155-9 O-ring 162 TH155-62 Washer 9
10 TH155-10 Snap Washer – Shaft 163 TH114-83 Gear Pump Cover 1
11 TH155-11 Valve Retract Spring 164 TH144-64 Spring 2
12 TH114-32 O-Ring 165 TH114-76 Gear Housing Plate 1
13 TH114-43 Valve Core Rod 166 TH114-79 Circlip 2
14 TH155-14 Sliding Pressure Sensor Sleeve 167 TH114-80 Gear Shaft 1
15 TH155-15 Sliding Pressure Sensor Sleeve Spring 168 TH114-78 Steel Ball 1
16 TH114-27 Aluminium Cover (Rear) 169 TH114-77 Gear 2
17 TH114-26 O-Ring 170 TH155-70 Pin 1
18 TH114-3 Piston 171 TH114-69 Washer 6
19 TH114-2 Piston Ring 172 TH114-70 Bolt 3
20 TH114-4 O-Ring 173 TH114-71 Motor Cover 1
21 TH114-5 Spring 174 TH114-57 Seal 1
22 TH114-15 Stud 475 TH114-54 Nut 1
23 TH114-1 Hydraulic Cylinder 176 TH114-55 Screw 1
24 TH114-61 Aluminium Cover (Front) 177 TH114-65 Motor 1
25 TH114-12 Piston Rod Seal 178 TH155-78 Fan 1
26 TH114-14 O-Ring 179 TH155-79 Block Turn 1
27 TH114-13 Bleed Screw 180 TH155-80 Shroud 1
28 TH114-62 Washer Groupware 181 TH155-81 Flat Washer 2
29 TH114-63 Dipstick 182 TH155-82 Spring Washer 3
30 TH114-6 Piston Rod 183 TH155-83 Screw 2
31 TH114-9 Lift Handle 184 TH114-59 Support Leg 1
32 TH114-10 Screw 285 TH155-85 Nut 5
33 TH114-20 Frame Tube 186 TH114-60 Bolt 5
34 TH114-19 Lead Plank 287 TH114-65 Cable & Plug 1
35 TH114-17 Spring Washer 488 TH114-66 Motor Foot Nut 3
36 TH114-16 Screw 689 TH114-67 Motor Foot 1
37 TH114-11 Nut 290 TH114-90 Electrical Cable Housing 1
38 TH114-8 Flat Washer 291 TH114-91 Screw 11
39 TH114-7 Nut 292 TH114-92 Switch Box Cover 1
40 TH114-51 Valve Plug 193 TH114-93 Airproof Underlay 1
41 TH114-50 Washer 194 TH114-94 Switch 1
42 TH155-42 Valve Sleeve 195 TH114-95 Connection Terminal 1
43 TH155-43 Spring 596 TH114-96 Capacitor 1
44 TH155-44 Adjusting Screw 197 TH114-97 Switch Box 1
45 TH114-40 Steel Ball 198 TH114-98 Waterproof Underlay 1
46 TH114-29 Pressure Valve Spring 199 TH114-73 Motor Support Left Shoe 1
47 TH114-30 Adjusting Screw 1100 TH114-72 Motor Support Right Shoe 1
48 TH114-53 Log Pusher Weldment 1101 TH114-75 Pin 2
49 TH114-52 Plastic Inserts 1 1102 TH114-82 Spring 2
50 TH114-23 Plastic Insert 2 1103 TH114-81 Sliding Sleeve 4
51 TH114-24 Log Pusher 1104 TH114-84 Bolt 3
52 TH114-25 Nut 4105 TH114-105 Ram Stopper 1
53 TH114-22 Flat Washer 5106 TH114-106 Ram Stopper 3-Star Screw 1
15

EC Declaration of Conformity
We，Importer
Handy Distribution
SN3 4NS
Declare that the product
Designation: 4 TON ELECTRIC LOG SPLITTER
Model: THLS-4
Complies with the following directives:
2006/95/EC- Low Voltage Directive
2004/108/EC- EMC Directive
The conformity assessment procedure followed was in according with Annex I of the
Directive 2006/42/EC.
Name of the Notified Body: TÜV Rheinland LGA Products GmbH
Address:. Tillystrasse 2, 90431 Nurnberg, GERMANY
Standards and technical specifications referred to:
06/42/EC – Annex I / 05.06
EN 60204-1 : 2006+A1
EN 609-1 : 1999+A2
Authorised signatory and technical file holder
Date: 1/7/2012
Signature:
Name / title: Mr. Simon Belcher / Managing Director
Hobley Drive, Stratton St Margaret, Swindon, Wiltshire, SN3 4NS.
16

EC Declaration of Conformity
We，Importer
Handy Distribution
SN3 4NS
Declare that the product
Designation: 6 TON ELECTRIC LOG SPLITTER
Model: THLS-6
Complies with the following directives:
2006/95/EC- Low Voltage Directive
2004/108/EC- EMC Directive
The conformity assessment procedure followed was in according with Annex I of the
Directive 2006/42/EC.
Name of the Notified Body: TÜV Rheinland LGA Products GmbH
Address:. Tillystrasse 2, 90431 Nurnberg, GERMANY
Standards and technical specifications referred to:
06/42/EC – Annex I / 05.06
EN 60204-1 : 2006+A1
EN 609-1 : 1999+A2
Authorised signatory and technical file holder
Date: 1/7/2012
Signature:
Name / title: Mr. Simon Belcher / Managing Director
Hobley Drive, Stratton St Margaret, Swindon, Wiltshire, SN3 4NS.
17

GUARANTEE
This product is guaranteed against manufacturing defects for a period of 12 months.
This does not cover the product where the fault is due to misuse, abuse, use in
contravention of the instructions, or where the product has been the subject of
unauthorised modifications or alterations. This warranty only covers domestic use
and will be void if the tool is used for a commercial application. In the event of a
problem with the product within the guarantee period, please contact Customer
Service on 01793 333212 or email customerserv[email protected]. If the
issue cannot be resolved over the telephone or by email, you may be referred to
your local approved service dealer.
Please keep your sales receipt as proof of purchase
Your statutory rights remain unaffected. Guarantor: Handy Distribution SN3 4NS
Whilst every effort is made to accurately represent the product, small variations in
colour, design and specification may occur. We reserve the right to alter the product
without giving notice. All images are illustrative only and may differ from the product
due to ongoing product development.
18

A SELECTION OF QUALITY PRODUCTS FROM OUR VAST RANGE
A SELECTION OF QUALITY PRODUCTS FROM OUR VAST RANGE
HAND PUSH LAWN MOWERS
HAND PUSH LAWN MOWERS
ELECTRIC & PETROL BLOW VACS
ELECTRIC & PETROL BLOW VACS
ELECTRIC & PETROL SHREDDERS
ELECTRIC & PETROL SHREDDERS
ELECTRIC, PETROL & MANUAL
ELECTRIC, PETROL & MANUAL
LOG SPLITTERS
LOG SPLITTERS
LAWN SWEEPERS
LAWN SWEEPERS
PETROL LINE TRIMMERS
PETROL LINE TRIMMERS
PETROL BRUSHCUTTERS
PETROL BRUSHCUTTERS
PETROL MULTICUTTERS
PETROL MULTICUTTERS
ELECTRIC & PETROL CHAINSAWS
ELECTRIC & PETROL CHAINSAWS
LOG SAW HORSES
LOG SAW HORSES
CORDLESS & PETROL
CORDLESS & PETROL
HEDGETRIMMERS
HEDGETRIMMERS
ELECTRIC & PETROL TILLERS
ELECTRIC & PETROL TILLERS
AERATORS & DETHATCHERS
AERATORS & DETHATCHERS
GARDEN & SALT SPREADERS
GARDEN & SALT SPREADERS
PUSH & TOWED ROLLERS
PUSH & TOWED ROLLERS
SNOW CLEARANCE TOOLS
SNOW CLEARANCE TOOLS
SPRAYERS
SPRAYERS
SACK TRUCKS
SACK TRUCKS
TROLLEYS & TRAILERS
TROLLEYS & TRAILERS
LIGHT CONSTRUCTION
LIGHT CONSTRUCTION
FIND OUT MORE AT WWW.THEHANDY.CO.UK
FIND OUT MORE AT WWW.THEHANDY.CO.UK
19

To order spare parts and see the complete range of garden
machinery and garden equipment from Handy, visit:
www.thehandy.co.uk
Spares & Support: 01793 333212
