THE SHOWER LAB VIEW 25 User manual
10/2021 V 1.1
VIEW 25 Illustration - View 25
H1 Handle
Right Hand
Neo Angle Enclosure
10/2021 V 1.1
VIEW 25
IMPORTANT
•This shower screen / enclosure must be installed by suitably qualified individuals. We
recommend a minimum of two people for safe assembly of certain sections of this screen.
•Ensure all appropriate safety equipment, especially protective footwear, safety glasses
and gloves are used.
•When drilling holes in ceramic tiles, use masking tape to prevent the drill from slipping:
DO NOT use hammer action as this will crack the tiles. Use a high quality drill bit to ensure
a clean, precise hole.
Tighten hinges and brackets to the recommended 15.6N.
•
•
Please leave these instructions with the customer following installation.
PRIOR TO INSTALLATION
•Before disposing of the packaging and prior to commencing assembly, please check all
the components to ensure that they have been supplied correctly and are undamaged.
Subsequent claims for missing or damaged pieces will not be accepted once the
packaging has been disposed of and installation commenced.
•In the event of any queries please contact your supplier quoting the relevant model
information.
•The Tray / Tiled floor on which this screen is to be installed must be level on all sides.
•It may be necessary to use alternate fixings to those supplied, depending on the properties
of the walls to be fixed to.
•Use the protective corners supplied at all times until the glass is moved to its final position.
•Ensure that the glass is installed correctly, taking care to avoid installing the glass upside
down. On certain panels an easy clean coating is applied to one side only, this is clearly
marked with a sticker on the non-coated side. The coated surface is to be fitted inwards
towards the inside (wet side) of the screen.
•Ensure that all surfaces to be sealed are clean and dry prior to applying the silicone
sealant. Use a high grade fungal resistant sealant.
•Allow a minimum of 24 hours after application of the silicone sealant prior to using the
screen.
TOOLS & MATERIALS REQUIRED
Junior Hacksaw
Straight Edge (Steel
Rule)
Fine Tooth File
Set or Roofing
Square
Masking Tape
Modelling Knife
Spirit Level
Pencil
Silicone Gun
Power Drill
Ø6mm Masonry Drill Bit
2x Suction Glass Lifters
High Quality Silicone Sealant
Tape Measure
Pozi-drive
Screwdrivers, PZ1&2
Safety Glasses and
Gloves
CARE AND MAINTENANCE
(please ensure that these instructions are left with the installed unit)
•We recommend routine cleaning of your screen / enclosure with hot water using a soft
cloth, then drying with a dry soft cloth or chamois leather.
Ritec Aftercare for Shower Glass is recomended for best results.
•All glass has been treated with EASY CLEAN glass finish and care must be taken to avoid
any abrasive cleaning products that may damage the special surface protection.
•DO NOT use acidic based de-scaler products or products containing bleaches or solvents.
Digital Torque Wrench
10/2021 V 1.1
VIEW 25
Supplied Parts
Hinged Side Fixed Panel
x1
Door
x1
Nylon Block
x1
Glass Support
x2
Handle Side Fixed Panel
x1
135°Glass to Glass Hinge
x2
Wall Prole End Cap
x2
Door Handle
(Option dependant)
x1
10/2021 V 1.1
VIEW 25
Supplied Parts
Underframe Wedge Gasket
x4
Underframe
x3
Underframe Gasket
x2
Wall Prole
x2
Wall Prole Soft Seal
x2
Wall Prole Rigid Seal
x2
Underframe Top
x1
135°Return Panel to Door Bubble Seal
x1
Glass to Glass Seal
x1
10/2021 V 1.1
VIEW 25
Supplied Parts
Bottom Door Seal
x1
Spacers
Underframe 135°Connector
x2
Packers
10/2021 V 1.1
VIEW 25
Supplied Parts
Please use this page to nd which stay bar your enclosure has been supplied with.
SB5 - With Glass Clamps
10/2021 V 1.1
VIEW 25
These instructions are for the View 25. An SB5 Stay Bar is used for this illustration.
The following instructions are valid for both the 20mm and 30mm proles. The 30mm prole is
used in the following instructions.
Please use the below diagram to reference the list of parts.
A
B
I
C
H
D
F
E
G
Handle Side Fixed Panel
Door Panel
Hinge Side Fixed Panel
Wall Prole End Cap
Wall Prole Soft Seal
Wall Prole Rigid Seal
Underframe Wedge Gasket
Underframe
JUnderframe Gasket
Wall Prole
N
M
K
L
Bottom Door Seal
Underframe Top
Underframe 135°Connector
Glass to Glass Hinge
OGlass to Glass Return Seal
PGlass to Glass Bubble Seal
QHandle (H1 Shown)
RStay Bar (SB5 Shown)
R
D
J
C
P
H
N
Q
A
F
B
E
O
M
I
LK
G
10/2021 V 1.1
VIEW 25
ADJUSTMENT SHEET
LH RH
Enclosure dimensions to OUTSIDE of Underframe
NOTE: Wall Profiles overlap the Underframe by 3mm
If you have a Bespoke Enclosure, reference the Install Sheet for the panel specifica�ons of the Enclosure.
NOTE: Allow 3mm for Wall Profile to overlap the Underframe
CH30 - Bespoke Panel A: Panel A + 20 = Minimum Width + 14 = Maximum Width
CH30 - Bespoke Door B: Door B + 20 = Fixed Width
CH30 - Bespoke Panel C: Panel C + 20 = Minimum Width + 14 = Maximum Width
BESPOKE ENCLOSURES - 30mm (CH30) Wall Profiles
A
A
B B
C C
10/2021 V 1.1
VIEW 25
01/12
Lip Distance
Shower Tray
x - 10mm
R
10/2021 V 1.1
VIEW 25
02/12
Place the Underframe Gaskets where
the glass will sit into the Underframe
together using the Underframe 135°
Add a small amount of silicone to the
ends of the Undeframe before
05 06
07 08
Silicone
10/2021 V 1.1
VIEW 25
Pre drill the No 6 screws in to the Wall
(No 8) Prole - Wall
(No 6) Prole - Top Cap
03/12
Wet Side
Professional Tip
If drilling ceramic tiles, place
masking tape on the tiles before
marking and drill through the
tape to prevent the drill bit from
skidding.
DO NOT use Hammer Action as
this will break the tiles.
09 10
11 12
10/2021 V 1.1
VIEW 25
Glass Panel
135°Connector
Flush
04/12
Remove and replace the Panels adding
level the Panels (to a maximum height
of 5mm inside the Underframe).
Check the Panels are level using a Spirit
Level.
Align the Fixed Panels so the Panels are
of the Underframe.
the top of the Glass Panels, mark the
be trimmed.
recommended to mark on masking
tape.
careful not to damage the channel
10/2021 V 1.1
VIEW 25
05/12
Ensure there is adequate glass in both
the Wall Profiles. (6mm is minimum)
To centre the panels, add 1mm Packers
on both sides of Inline Panels in the
Underframe.
Apply the Rigid Seals to the dry side of
the Wall Profiles star�ng from the
archway of the Wall Profile up to the
top.
Flush
6mm min
Wall ProleGlass Panel
Rigid Seal
Glass Panel
If the Glass is s�ll in place, remove it.
Add silicone in the corner where the
Wall profile Meets the Underframe at
the back.
Re-install the Glass.
Silicone the
inside corner
17 18
19 20
10/2021 V 1.1
VIEW 25
06/12
Gently tap the Wall Profile Rigid Seals
into place using a rubber mallet with
the Nylon Block to protect the Glass
and the Wall Profile.
Trim both of the Wall Profile seals at
the top face of each Wall Profile using a
blade.
21 22
10/2021 V 1.1
VIEW 25
07/12
Assemble the SB5 Stay Bar and fit to
the two Fixed Panels using the grub
screws provided.
Ensure the Glass is fully inserted into
the grooves of the Clamps.
STAY BAR CONFIGURATION A - SB5
A1
x
Outside of
enclosure
10/2021 V 1.1
VIEW 25
Cover Plate
Clamping
Plate
Measure to
this face
08/12
Measure the distance between the two
Underframe 135° Connectors.
Mark and cut the Underframe Top.
Snap the Underframe Top on to the
Underframe.
Remove Packers and feed the
Underframe Wedge Gasket into the
archway gap of the Fixed Panel and
trace along the Glass on both sides.
Spray water on Glass Panel and use
Nylon Block to help feed Gasket.
Trim the Wedge Gasket where it meets
the Underframe Top.
Repeat for the opposite Fixed Panel.
Fixed Panel. Ensure you have the
Gaskets are just “nipping” the Glass.
Tighten all screws.
You should hear a creaking sound.
23 24
25 26
10/2021 V 1.1
VIEW 25
Wet Side
Glass Supports
Inside Enclosure
(Wet Side)
09/12
27 28
29
10/2021 V 1.1
VIEW 25
10/12
Outside of
enclosure
31 32
33 34
10/2021 V 1.1
VIEW 25
11/12
35 36
37 38
Trim
10/2021 V 1.1
VIEW 25
Silicone
Silicone
Silicone
12/12
Apply silicone to the edge of the
Underframe Top where it meets the
two Fixed Panels.
Check silicone has been applied to all
the below outside areas.
Check silicone has been applied to all
the below inside areas.
Let the silicone sealant cure for 24
hours.
Underframe
Wall Channel
Silicone
Apply silicone sealant along the wall
and floor, all around the outside of the
Underframe and Wall Profiles.
Silicone
39 40
41 42
