The Wings Maker Flyboy 50 User manual

* Specifications are subject to change without notice.*
It is designed for maximum performance. Please seek advice if one is not familiar with this kind
of engine powered precision model. Operating this model without prior preparation may cause
injuries. Remember, safety is the most important thing. Always keep this instruction manual at
hand for quick reference.
Warning ! This model is not a toy.
Wing Span: 63.0 in /1600 mm
Wing Area: 660 sq in / 42.6 sq dm
Flying Weight: 6.0 lbs / 2700 g
Fuselage Length: 51 in / 1290 mm
Required : 2-stroke 0.40-0.46 or 4-stroke 0.70
engine, 5- channel radiow/ 6 servos
Specifications
INSTRUCTION MANUAL
Specifications
Before commencing assembly, please read these instructions thoroughly.
( )
GA014
GA014PO28971303

P.3-P.10
Do not overlook this symbol!
Cut off shaded portion.
Peel off shaded portion
covering film.
Pay close attention here!
Pierce the shaded portion
covering film.
Must be purchased separately!
Drill holes with the specified
diameter (here: 3mm).
3mm
INDEX
BEFORE YOU BEGIN
PARTS LIST
ASSEMBLY
SAFETY PRECAUTIONS
P. 1
P. 2
P. 10
BEFORE YOU BEGIN
Read through the manual before you begin, so you will have an overall idea of what to do.
Symbols used throughout this instruction manual comprise of the following : -
Ensure smooth non-binding
movement while assembling.
Apply instant glue
(C.A.glue, super glue.)
Assemble left and right
sides the same way.
Apply epoxy glue.
1
2
3
P.1
Check all parts. If you find any defective or missing parts contact your local dealer. Please DRY FIT
and check for defects for all parts that will require CA or Epoxy for final assembly. Any parts you
find to be defective after the gluing process may be difficult to remove for warranty replacement. The
manufacturer will replace any defective parts. but will not extend to the parts that are good before
gluing to defective parts during assembly. Warranty will not cover any parts modified by customer.
Apply thread locker
GA014PO28971303

P.2
Parts List
COVERING:
TOUGHLON STL 100 WHITE
TOUGHLON STL 331 CUB YELLOW
LIGHTEX SGX 310 RED
LIGHTEX SGX 360 VIOLET
1. MAIN WING -- 1 pair
2. SCREW PB2x25mm -- 6 pcs
FUEL TUBE Ø6x5mm -- 4 pcs
CLEVIS PL4112103 -- 2 pcs
STRAPER PL4112102 -- 2 pcs
TRI-HORN M3x14mm (For Aileron) PL4111185 -- 2 sets
PUSHROD Ø1.8x115mm w/ Threads (For Aileron) -- 2 pcs
3. WING JOINER 5x29x108mm -- 1 pc.
4. RETRACTABLE LANDING GEAR--1 pair
MAIN WHEEL Ø56mm -- 2 pcs
COLLAR Ø4.1mm w/ set screw -- 2 sets
5. LINKAGE CONNECTOR Ø2.1mm w/ set screw -- 2 sets
6. STABILIZER & ELEVATOR -- 1 set
FUSELAGE -- 1 pc.
7. VERTICAL FIN & RUDDER -- 1 set
8. TAIL LANDING GEAR -- 1 set
TAIL WHEEL Ø23mm -- 1 pc.
COLLAR Ø2.1mm w/ screw -- 1 set
SCREW PA3x12mm -- 2 pcs
9. ENGINE MOUNT PL5111050 -- 1 set
SOCKET HEAD SCREW M4x25mm -- 4 pcs
WASHER d4xD9mm -- 4 pcs
10. FUEL TANK 320cc -- 1 set
DOUBLE-SIDED TAPE 40x100mm -- 1 pc.
CABLE TIE 1.5x5x400mm -- 1 pc.
11. SCREW HM3.5x30mm -- 4 pcs
WASHER d3.5xD8mm -- 8 pcs
M3.5 NUT -- 8 pcs
THROTTLE PUSHWIRE Ø1.2x320mm -- 1 pc.
w/ Plastic Tube d2xD3x125mm -- 1 pc.
12. SCREW PB2x16mm -- 6 pcs
TRI-HORN M3x14mm (For Elevator) PL4111185 -- 2 sets
FUEL TUBE Ø6x5mm -- 2 pcs
CLEVIS PL4112103 --2 pcs
PUSHROD Ø1.8x605mm w/ Threads (For Elevator) -- 2 pcs
13. SCREW PB2x16mm -- 3 pcs
CLEVIS PL4112103 -- 1 pc.
FUEL TUBE Ø6x5mm -- 1 pc.
TRI-HORN M3x14mm (For Rudder) PL4111185 -- 1 set
PUSHROD Ø1.8x720mm w/ Threads (For Rudder) -- 1 pc.
14. LINKAGE CONNECTOR Ø2.1mm w/ set screw -- 1 set
15. SPONGE 10x80x200mm (For Radio Equipment) -- 2 pcs
STRAPER PL4112102 -- 2 pcs
FUEL TUBE Ø6x5mm -- 2 pcs
PUSHROD CONNECTOR 4x9x20mm (For Elevator) -- 1 set
PUSHROD Ø1.8x90mm (For Elevator) -- 1 pc.
PLYWOOD 3x49x113mm (For Throttle Servo) -- 1 pc.
BALSA 6x6x46mm (For Throttle Servo Stand ) -- 2 pcs
16. COWLING -- 1 pc.
TRANSPARENT DUMMY COWLING -- 1 pc.
SILICON GROMMET d1.5xD6.5mm -- 4 pcs
SPINNER Ø62mm PL2111062 -- 1 pc.
SCREW PWA2.6x12mm -- 4 pcs
17. CANOPY -- 1 pc.
SILICON GROMMET d1.5xD6.5mm -- 4 pcs
SCREW PWA2.3x12mm -- 4 pcs
PILOT PC001063A -- 1 pc.
18. SCREW HM4x40mm -- 2 pcs
WASHER d4xD15mm -- 2 pcs
19. DECALS: GA014DEC --1 set
GA014PO28971303

P.3
1Aileron
Bottom View
Aileron Servo Lead
Aileron Servo
2
Bottom View
1.8x115mm Ø
Pushrod
Fuel Tube
Ø 6x5mm
straper
1.5mm
PB2x25mm
Clevis
Tri-horn
M3x14mm
Main Wing
3
Wing Jioner
5x29x108mm
PB 2 x 25mm Screw
6
Ø
Please look for pin-hole marks at under side of control surfaces.
1mm pilot holes for The Wings Maker tri-horn are pre-drilled.
Apply instant type CA glue to both sides of each hinge.
Please dry fit wing joiner into left and right wing to make sure they fit with
the proper dihedral angle, mark the wing joiner if necessary. Apply epoxy
glue to both sides of all surfaces in contact. Use a stick to apply the glue
to inner side of wing joiner sleeve, and apply the glue to wing joiner before
putting them together. Wing joiner not glued properly will lead to wing failure
and plane crash.
TWM PL8210010
CLEVIS WRENCH
GA014PO28971303

P.4
Retractable Landing Gear
4
3mm Set Screw
KA3x14mm
4.1mm collar
Bottom View
Retract Servo
5
3 X 3mm Set Screw
2
L i n k a g e C o n n e c t o r
2
2mm Nut
2
2mm Washer
2
Select the servo horn that will give 26mm
0
travel when it rotates through 180 .
Wheels up position
Wheels down Position
To
R-side
To
L-side
1mm
3mm
6
Stabilizer & Elevator
A A'
A=A'
Temporary install the main wing,
adjust leveling of the stabilizer to
make it as parallel to the main wing
as possible.
(Stabilizer)
(Main Wing)
BB'
B
B'
Apply instant type CA glue to both
sides of each hinge.
*Also refer to step 19 Wing Setting
Remove coverings for all surfaces in
contact before applying A/B epoxy glue.
GA014PO28971303

P.5
7Vertical Fin & Rudder
Apply instant type CA glue to both
sides of each hinge.
Tail Landing Gear
8
3mm Set Screw
2.1mm Collar
2
1
1
PA 3 x 12mm Screw
1.5mm
Engine Mount
9
4
M4x25mm SocketHead Screw
4
d4 x D9mm Washer
C=C'
CC
Completed
2.5mm
Bottom View
M3x3mm Set Screw
PA3x12mm 2.1mm Collar
Wheel 23mmØ
Blind nuts are off-centered
to keep the spinner at the
fuselage axis.
Engine Mount
PL5111050
d4 x D9mm Washer
M 4 x 25mm
Remove coverings for all surfaces in
contact before applying A/B epoxy glue.
GA014PO28971303

Fuel Tank
10
P.6
Double-sided Tape x mm 40 100
Engine
11
8
d4 x D9mm Washer
8
M3.5 Nut
Throttle Pushwire
w/plastic tube
M3.5 Nut
3.2mm
d4 x D9mm
Washer
M3.5 x 30mm
d4 x D9mm
Washer
Illustration is for mounting. You can mount the engine or
sideways simply by rotation the engine mount. Thrust angles will not be
affected.
upright inverted
114mm
4.5 in
Install Engine position
Fuel Tank
320cc
4
HM3.5x30mm Socket Head Screw
Cable Tie 1.5x5x4 mm
00
1 2 3
Bottom View
Plywood 2x59.5x102.4 mm
GA014PO28971303

P.7
Rudder Pushrod
13
Elevator Pushrod
12
PB2 x 16mm Screw
6
170mm
46mm
Elevator Pushrod
Ø1.8x605mm
Tri-horn
M3x14mm(L)
PB2x16mm
Fuel Tube
Ø6x5mm
Clevis
Bottom View
Ø
Please look for pin-hole marks at under side of control surfaces.
1mm pilot holes for The Wings Maker tri-horn are pre-drilled.
125mm
26mm
Rudder Pushrod
Ø1.8x720mm
Tri-horn
M3x14mm(L)
PB2x16mm
Fuel Tube
Ø6x5mm
Clevis
Bottom View
Ø
Please look for pin-hole marks at side of control surfaces.
1mm pilot holes for The Wings Maker tri-horn are pre-drilled.
Please refer to attached sheet for linkage connector installation.
2mm
M2
2mm
Linkage Connector
M2 Nut
2mm Washer
1
1
1
2
Servo Set
14
3 x 3mm Set Screw
Throttle / Pushwire
w/ plastic tube
Included with the radio Set.
Throttle Servo.
PB2 x 16mm Screw
3
TWM PL8210010
CLEVIS WRENCH
TWM PL8210010
CLEVIS WRENCH
GA014PO28971303

Cowling
16
d1.5 x D6.5 mm Silicon Grommet
PWA2.6 x 12mm Screw
4
4
2mm
Spinner Ø62mm
Canopy
d1.5 x D6.5 mm Silicon Grommet
PWA2.3 x 12mm Screw
4
4
d1.5 x D6.5 mm
Silicon Grommet
2mm
PWA2.3 x 12mm
First insert the grommet to the canopy then apply screw.
17
Radio Equipment
15
Install and arrange the servo as shown in the diagram.
Elevator Pushrod
Front
Fuel Tube
Ø6x5mm
Sponge
Straper
Rudder Pushord
Elevator Servo
KM 2x8mm
M2 Nut
Elevator Pushrod
Ø1.8x90mm
Bottom View
Plywood
3x49x113mm
P.8
First insert the grommet to the cowling then apply screw.
Receiver
Rudder Servo
Elevator Servo
Throttle Servo
PWA2.6x12mm
Silicon Grommet
d1.5xD6.5mm
Cowling
Fuselage
Front
Pilot
Throttle Pushwire
Balsa 6x6x46mm
Balsa 6x6x46mm
GA014PO28971303

P.9
Main Wing
18
2
HM4 x 40mm Screw
2
d4 x D15mm Washer
HM4 x 40mm
d4 x D15mm Washer
Bottom View
Adjust the wing and fuselage configuration as shown in the diagrams.
Wing Setting
19
A =A'
B
B'
C C'
DD'
B =B'
C=C'
A
A'
D=D'
GA014PO28971303

P.10
30mm
9mm
Adjust the control throws as shown in the diagram
These throws are good for general flying. Yon can
adjust according to your personal preference.
.
First time flyer should never fly by himself / herself. Assistance from experienced flyer is
absolutely necessary.
Pre - flight adjustment must be done before flying, it is very dangerous to fly a badly
adjusted aircraft.
pre -
Make sure the air field is spacious, never fly the plane too close to people and never get
too close to a running propeller.
If you find wrinkles on the covering as a result of weather changes, you can use hot iron
to remove the wrinkles. Please begin with lower temperature setting and gradually raise
the temperature until the wrinkles are gone. Too hot an iron may damage the covering.
Check and re-tighten up all factory assembled screws, use thread locker if applicable.
30mm
9mm
is specially designed to be powered by 2C 0.40-0.46/4c 0.70 stroke
glow engine, using a more powerful engine does not mean better performance. In fact,
over powered engine may cause severe damage and injuries.
18mm
18mm
Elevator
Rudder
Ailerons
Important Safety Precautions
3.9in
100mm
100mm
3.9in
http://www.thewingsmaker.com/instructionManuals.php
The ideal C.G. position is 100mm (3.9in.) behind the leading edge measured at where the wing meets the
fuselage. In order to obtain the C.G. specified, add weight to the fuselage or move the battery position.
Check the C.G. before flying.
If you are converting this model to electric, please move the C.G. forward 10% of current C.G. distance from
leading edge to compensate for weight of fuel.
Measure C.G. with the wheels in retracted position.
GA014PO28971303

LINKAGE CONNECTOR
After fastening the round nut, make sure that the linkage connector can rotate freely.
Drill 2mm hole at servo horn.
Insert linkage connector
into servo horn.
Make sure shoulder of
screw is cleared from
servo horn.
Add washer to reduce
play if necessary.
Shoulder
Tighten up the round nut
against the shoulder. Apply
CA or permanent thread
locker.
