The Wings Maker FAIRCHILD PT-26 40 User manual

THE WINGS MAKER
FACTORYPRE-FABRICATED
ALMOST-READY-TO-FLY(ARF) SERIES
MADE IN CHINA
* Specifications are subject to change without notice.*
It is designed for maximum performance. Please seek advice if one is not familiar with this kind
of engine powered precision model. Operating this model without prior preparation may cause
injuries. Remember, safety is the most important thing. Always keep this instruction manual at
hand for quick reference.
Warning ! This model is not a toy.
Wing Span: 57.5 in / 1460 mm
WingArea: 533 sq in / 34.4 sq dm
Flying Weight: 5.3 Ibs / 2400 g
Fuselage Length: 44 in / 1120 mm
Requires: 2-stroke 0.40 or
4-stroke 0.52 engine
4-channel radio w/ 5 servos
SpecificationsSpecifications
(GA021)
www.thewingsmaker.com
INSTRUCTION MANUAL
Before commencing assembly, please read these instructions thoroughly.
FAIRCHILD PT-26 40
FAIRCHILD PT-26 40
GA021SPO27821210

FAIRCHILD PT-26 40
FAIRCHILD PT-26 40
P. 1
INDEX
BEFORE YOU BEGIN
P.1
PARTS LIST
P.2
SAFETY PRECAUTIONS
P.10
BEFORE YOU BEGIN
Do not overlook this symbol!
Cut off shaded portion.
Ensure smooth non-binding
movement while assembling.
Apply instant glue
(C.A.glue, super glue.)
Assemble left and right
sides the same way.
Peel off shaded portion
covering film.
Pay close attention here!
Apply epoxy glue.
Pierce the shaded portion
covering film.
Must be purchased separately!
Drill holes with the specified
diameter (here: 3mm).
3mm
ASSEMBLY
P.3-10
Checkallparts. If youfindanydefectiveor missingparts contact your localdealer. Please DRYFIT
and checkfor defectsforallparts that willrequireCAorEpoxy forfinal assembly. Any parts you
findtobedefectiveafter thegluingprocessmay bedifficulttoremove forwarranty replacement. The
manufacturerwillreplaceanydefectiveparts, but will notextendtothe partsthataregoodbefore
gluingtodefectivepartsduringassembly.
Warrantywillnot coveranyparts modifiedbycustomer.
Readthroughthemanual beforeyou begin,soyou will havean overallideaofwhattodo.
Symbols used throughout this instruction manual comprise of the following : -
1
2
3
GA021SPO27821210

Parts List
P.2
COVERING:
LIGHTEX SGX 100 WHITE
LIGHTEX SGX 331 CUB YELLOW
LIGHTEX SGX 351 DARK BLUE
LIGHTEX SGX 311 FERRARI RED
LIGHTEX SGX 201 BLACK
1. MAIN WING -- 1 pair
2. WOODEN WING JOINER 9x21.8x124mm -- 1 pc.
3. MAIN LANDING GEAR -- 1 set
SCREW PA3x14mm -- 8 pcs
COLLAR Ø3.6mm w/ set screw -- 4 sets
MAIN :+((/ĭPPSFV
MOUNTING PLATE PL114020 -- 4 pcs
4. SERVO MOUNTING PANEL PL5310000(For Aileron) -- 1 pair
SCREW PB2x16mm -- 6 pcs
SCREW PWA2x8mm -- 8 pcs
PUSHROD Ø1.8x115mm w/ Threads (For Aileron) -- 2 pcs
CLEVIS PL4112103 -- 2 pcs
STRAPER PL4112102 -- 2 pcs
FUEL TUBE Ø6x5mm -- 4 pcs
TRI-HORN M3x14mm (s) PL4111221 -- 2 sets
5. STABILIZER & ELEVATOR -- 1 set
FUSELAGE -- 1 pc.
6. VERTICAL FIN & RUDDER -- 1 set
7TAIL LANDING GEAR Ø2mm PL7100001 -- 1 set
SCREW PA3x12mm -- 2 pcs
COLLAR Ø2.1mm w/ set screw -- 1 set
TAIL WHEEL Ø23mm -- 1 pc.
8. PUSHROD Ø1.8x640mm w/ Threads (For Rudder) -- 1 pc.
SCREW PB2x16mm -- 3 pcs
CLEVIS PL4112103 -- 1 pc.
FUEL TUBE Ø6x5mm -- 1 pcs
TRI-HORN M3x14mm (s) PL4111221 -- 1 set
9. PUSHROD Ø1.8x540mm w/ Threads(For Elevator)-- 2 pcs
SCREW PB2x16mm -- 6 pcs
CLEVIS PL4112103 -- 2 pcs
FUEL TUBE Ø6x5mm -- 2 pcs
TRI-HORN M3x14mm (s) PL4111221-- 2 sets
10.FUEL TANK 320cc -- 1 set
CABLE TIE 1.5x5x400mm -- 1 pc.
DOUBLE-SIDE TAPE 40x100mm -- 1 pc.
11.ENGINE MOUNT PL5111050 -- 1 set
SOCKET HEAD SCREW M4x25mm -- 4 pcs
WASHER d4xD9mm -- 4 pcs
12.LINKAGE CONNECTOR Ø2.1mm -- 1 set
13.SOCKET HEAD SCREW M3x30mm -- 4 pcs
M3 NUT -- 8 pcs
WASHER d3xD7mm -- 8 pcs
THROTTLE PUSHWIRE Ø1.2x400mm -- 1 pc.
PLASTIC TUBE d2xD3x270mm -- 1 pc.
14. PUSHROD Ø1.8x95mm (For Elevator) -- 1 pc.
FUEL TUBE Ø6x5mm -- 2 pcs
STRAPER PL4112102 -- 2 pcs
SPONGE 60x70x105mm (For Radio Equipment) -- 1 pc.
Y CONNECTOR PL4410010 -- 1 set
15. SCREW HM4x35mm -- 2 pcs
WASHER d4xD15mm -- 2 pcs
PLYWOOD 3x34x107mm(Wing Protection) -- 1 pc.
16. COWLING -- 1 pc.
TRANSPARENT 3D TEMPLATE -- 1 pc.
SCREW PWA2.6x12mm -- 4 pcs
SILICON GROMMET d1.5xD6.5mm -- 4 pcs
SPINNER NUT Ø22mm HW2340060 -- 1 set
17. COCKPIT -- 1 pc.
PILOT PC001065B -- 2 pcs
18. DECALS: GA021DEC -- 1 set
GA021SPO27821210

2
P.3
Main Wing
Main Wing
1
PA3x14mmScrew8
3
Bottom View
Bottom View
Pre-glued
Wing Joiner 9x21.8x124mm
2mm
PA3x14mm
Plate
3mm Set Screw
3.6mm Wheel Colla
4
4
Apply glue to both sides of all surfaces in contact. Use a stick to apply glue to
inner side of wing joiner sleeve, and apply glue to wing joiner before putting them
together. Wing joiner not glued properly will lead to wing failure and plane crash.
Main Landing Gear
3mm Set Screw
:KHHOĭPP
Aileron Servo Lead
GA021SPO27821210

Vertical Fin & Rudder
6
Stabilizer & Elevator
5
P.4
Completed
Completed
C=C'
CC
BB’
B=B’
Temporary install the main wing, adjust leveling
of the stabilizer to make it as parallel to the main
wing as possible.
Pre-glued
Pre-glued
A
A
A'
A'
(Stabilizer)
(Main Wing)
Aileron Servos
4
Bottom View
PWA2x8mm Screw
8
Clevis
1.5mm
PWA2x 8mm
1mm
PB2 x16mm Pushrod
Ø1.8x115mm
Pushrod
Ø1.8x115mm
Tri-horn
M3x14mm(s)
Clevis
Fuel Tube
Ø6x5mm
Fuel Tube
Ø6x5mm
PB2x16mm Screw
6
TWM PL8210010
CLEVIS WRENCH
Ø1mm pilot holes for The Wings Maker tri-horn are pre-drilled.
Please look for pin-hole marks at under side of control surfaces.
Remove coverings for all surfaces in contact before
applying A/B epoxy glue.
Remove coverings for all surfaces in contact before
applying A/B epoxy glue.
GA021SPO27821210

9
Rudder Pushrod
8
ElevatorPushrod
7
P.5
Tail Landing Gear
2.1mm Collar
1
PA3 x 12mm Screw
2
3
PB2 x16mm Screw
6
PB2 x16mm Screw
Clevis
WHEEL ĭPP
.P PCollar
[PPSet Screw
PA[PP
2mm
1.5mm
Rudder Pushrod
ĭ1.8x640mm
Fuel Tube
ĭ[PP
Tri-hotm
M3x14mm
PB2x16mm
ElevatorPushrod
ĭ1.8x540mm
Fuel Tube
ĭ[PP
Tri-hotm
M3x14mm
PB2x16mm
Ø1mmpilot holesfor The Wings Maker tri-horn are pre-drilled.
Please look for pin-hole marks atside of controlsurfaces.
Ø1mmpilot holesfor The Wings Maker tri-horn are pre-drilled.
Please look for pin-hole marks atunder side of controlsurfaces.
%RWWRP9LHZ
%RWWRP9LHZ
%RWWRP9LHZ
GA021SPO27821210

P.6
FuelTank
11
12
10
Servo Set
12
!
EngineMount
Blind nuts are off-centered to keep
the spinner at the fuselage axis.
Engine Mount PL5111050
Washer
d4xD9mm
M4x25mm
4
4
d4xD9mm Washer
Apply thread locker to screws.
Please refer to attached sheet for linkage connector installation.
Throttle Servo.
Included with the radio Set.
3mm
2mm
2mm
2mm
2mm
1
1
1
2
2mm Washer
M2 Nut
Linkage Connector
3 x 3mm Set Screw
LINKAGE CONNECTOR
Throttle Pushwire
UP
320cc
Completed
Cable Tie 1.5x5x400mm
Double-side Tape
40x100mm
M4x25mm Socket Head Screw
GA021SPO27821210

P.7
Engine
13
d3xD7mm Washer
Washer
d3xD7mm
8
8
M3 Nut
Radio Equipment
14
M3 NUT
ElevatorServo
Install Engine Position
Throttle Pushwire
Ø 1.8x400mm
Plastic Tube
d2xD3x270mm
M3x30mm
Install and arrange the servo as shown in the diagram.
ElevatorPushrod
Ø 1.8x540mm
Rudder Pushrod
Ø 1.8x640mm
Fuel Tube
Ø 6x5mm
Straper
Throttle Servo
ThrottlePushwire
Ø 1.2x400mm
Sponge
Front
Rudder Servo Battery
M2 Nut
Elevator Pushrod
1.8x95mm
120mm
4.7in.
Elevator Servo
KM 2x8mm
4
M3x30mm Socket Head Screw
GA021SPO27821210

Cowling
16
MainWing
15
P.8
2
2
Washer
d4xD15mm
HM4x35mm
Wing Protection
3x34x107mm
4
4
1.5mm
PWA2.6x12mm Screw
d1.5 x D6.5 mm SiliconGrommet
Spinner Nut
HM 4x35mm Screw
d4xD15mm Washer
4mm
Cockpit
17
d1.5xD6.5mm
Grommet
Cowling Fuselage
PWA2.6x12mm
Double-sided Tape
Pilot
Pilot
Front
First insert the grommet to the cowling then apply screw.
Please refer to the attached sheet for usage of the
transparent 3D template.
GA021SPO27821210

P.9
Wing Setting
18
B B’
C’C
A=A’
B=B’
C=C’
A A’
Adjust the wing and fuselage configuration as shown in the diagrams.
GA021SPO27821210

P.10
ControlThrows
19
C.G.
20
Elevator
Rudder
Ailerons
12mm
12mm
45mm
25mm
25mm
45mm
C.G.
Adjust the control throws as shown in the diagram.
These throws are good for general flying. You can
adjust according to your personal preference.
FAIRCHILD PT-26 40
FAIRCHILD PT-26 40
83mm
3.25 in
# First time flyer should never fly by himself / herself. Assistance from experienced flyer is absolutely necessary.
# Pre-flight adjustment must be done before flying, it is very dangerous to fly a badly pre-adjusted aircraft.
# is specially designed to be powered by 2 C 0.40 or 4 C 0.52 engine, using a more
powerful engine does not mean better performance. In fact, over powered engine may cause structural damage
and injuries.
# Make sure the air field is spacious, never fly the plane too close to people and never get too close to a running
propeller.
# If you find wrinkles on the covering as a result of weather changes, you can use hot iron to remove the wrinkles.
Please begin with lower temperature setting and gradually raise the temperature until the wrinkles are gone. Too
hot an iron may damage the covering. Don't use hot iron near the seams or edges, hot iron will melt the glue and
shrink the covering at the same time, causing the seams to pull away.
# Check and re-tighten up all factory assembled screws, use thread locker if necessary.
Important Safety Precautions
Warning!
http://www.thewingsmaker.com/instructionManuals.php
TheidealC.G.positionis83mm(3.25in.)behindtheleadingedgemeasuredatwherethe wingmeetsthe
fuselage.Inordertoobtainthe C.G.specified,addweightto thefuselageor movethe battery position.
Check the C.G.beforeflying.
Ifyouareconvertingthismodeltoelectric,pleasemovetheC.G.forward10%ofcurrentC.G.distancefrom
leadingedgetocompensateforweightoffuel.
GA021SPO27821210
