The Wings Maker GM040P User manual

It is designed for maximum performance. Please seek advice if one is not familiar with this kind
of electric powered precision model. Operating this model without prior preparation may cause
injuries. Remember, safety is the most important thing. Always keep this instruction manual at
hand for quick reference.
Warning ! This model is not a toy.
THE WINGS MAKER
FACTORY PRE-FABRICATED
ALMOST-READY-TO-FLY (ARF) SERIES
MADE IN CHINA
* Specifications are subject to change without notice.*
www thewingsmaker com. .
SpecificationsSpecifications
Before commencing assembly please read these instructions thoroughly, .
INSTRUCTION MANUAL
Wing Span: 39.5 in / 1000 mm
Wing Area: 292 sq in / 18.8 sq dm
Flying Weight: 27 oz / 760 g
Fuselage Length: 40.5 in / 1030 mm
Requires: 4-channel radio w/ 4 micro servos. Outrunner
Motor KM0283010 w/ Propeller Adaptor HW2340100
20A Brushless ESC, 3 cells 11.1V 15C 1800 mAh Li-Po
battery & charger.
sunrise ep
GM040PO27791202

INDEX
BEFORE YOU BEGIN
BEFORE YOU BEGIN
PARTS LIST
ASSEMBLY
SAFETY PRECAUTIONS
P.1
P.2
P.3-P.9
P.9
Check all parts. If you find any defective or missing parts contact your local dealer. Please
DRY FIT and check for defects for all parts that will require CA or Epoxy for final assembly.
Any parts you find to be defective after the gluing process may be difficult to remove for
warranty replacement. The manufacturer will replace any defective parts, but will not extend
to the parts that are good before gluing to defective parts during assembly. Warranty will
not cover any parts modified by customer.
Symbols used throughout this instruction manual comprise of the following :-
Read through the manual before you begin, so you will have an overall idea of what to do.
1
2
3
P.1
Cut off shaded portion.
Ensure smooth non-binding
movement while assembling.
Apply instant glue
(C.A.glue, super glue.)
Assemble left and right
sides the same way.
Peel off shaded portion
covering film.
Pay close attention here!
Apply epoxy glue.
Must be purchased separately !
Drill holes with the specified
diameter (here: 3mm). Pierce the shaded portion
covering film.
3mm
Do not overlook this symbol !
Warning!
Apply thread locker
sunrise ep
GM040PO27791202

P.2
Parts List
1.MAIN WING -- 1 pair
MICRO AILERON SERVO MOUNT PL5310020 -- 1 pair
STRAPER PL4112106 -- 2 pcs
CLEVIS PL4112105 -- 2 pcs
FUEL TUBE d2xD4x4mm -- 4 pcs
HORN PL4113103 -- 2 pcs
PUSHROD Ø1.4x65mm w/ Threads (ForAileron) -- 2 pcs
SCREW PA1.7x8mm -- 8 pcs
FIBRE TAPE 17x300mm -- 2 pcs
PLYWOOD 36.7x36.7x3mm -- 2 pcs
2.FUSELAGE -- 1 set
STABILIZER & ELEVATOR -- 1 set
FIBRE TAPE 17x380mm -- 1 pc.
3.VERTICAL FIN & RUDDER -- 1 set
FIBRE TAPE 17x175mm -- 1 pc.
PLYWOOD 36.7x36.7x3mm -- 1 pc.
4.TAIL LANDING GEAR PL3410030 --1 set
SCREW PA2x8mm -- 2 pcs
PLYWOOD 36.7x36.7x3mm -- 1 pc.
5.MAIN LANDING GEAR -- 1 set
MAIN WHEEL Ø40mm PL3116040 -- 2 pcs
WOODEN COLLAR Ø2.6mm -- 2 pcs
COLLAR Ø2.6mm w/ Set Screw -- 2 sets
SCREW PA2x8mm -- 1 pc.
SCREW PWA2x6mm -- 4 pc.
PLYWOOD 48x35.7x2.5mm (For Main Landing Gear) -- 1 pc.
MOUNTING PLATE 12x20mm -- 2 pcs
WHEEL PANTS -- 1 pair
LANDING GEAR COVERS -- 2 pcs
6.MICRO AILERON SERVO MOUNT PL5310020 -- 1 pc.
SCREW PA1.7x8mm -- 4 pcs
FUEL TUBE d2xD4x4mm -- 2 pcs
CLEVIS PL4112105 --1 pc.
STRAPER PL4112106 -- 1 pc.
HORN PL4113103 -- 1 pc.
PUSHROD Ø1.4x135mm w/ Threads (For Elevator) -- 1 pc.
7.MICRO AILERON SERVO MOUNT PL5310020 -- 1 pc.
SCREW PA1.7x8mm -- 4 pcs
FUEL TUBE d2xD4x4mm -- 2 pcs
CLEVIS PL4112105 --1 pc.
STRAPER PL4112106 -- 1 pc.
HORN PL4113103 -- 1 pc.
PUSHROD Ø1.4x130mm w/ Threads (For Rudder) -- 1 pc.
8.SOCKET HEAD SCREW M3x6mm -- 4 pcs
SCREW PM2x12mm -- 2 pcs
SCREW PA2.6x8mm -- 2 pcs
WASHER d3xD7mm -- 4 pcs
SPINNER Ø45mm SP27045BKO -- 1 pc.
10x6 FOLDING PROPELLER SET PL6314020 -- 1 set
9.WING TUBE Ø6x458mm -- 1 pc.
RUBBER BAND 4x30mm -- 2 pcs
10.COCKPIT -- 1 pc.
BATTERY TIE 200mm-- 1 pc.
SPONGE 10x50x150mm (For Radio Equipment & Battery) -- 2 pcs
DOUBLE-SIDED TAPE 30x35mm (For Brushless ESC) -- 1 pc.
11.DECALS: GM040 DEC -- 1 set
GM040PO27791202

P.3
Bottom View Bottom View
Bottom View
Please choose either (02L&02R) or (03L&03R) or (04L&04R) that suits your servo.
Aileron Servo
1
PA1.7x8mm Screw
8
Fibre Tape
17x300mm
Plywood
36.7x36.7x3mm Servo(For Aileron) Aileron Servo Lead
Fibre Tape
Bottom
Straper
Fuel Tube
d2xD4x4mm
PA1.7x8mm
PA1.7x8mm
02L
03L
04L
02R
03R
04R
TWM PL8210010
CLEVIS WRENCH
Clevis
Pushrod
Ø1.4x65mm
Fuel Tube
d2xD4x4mm
Horn
GM040PO27791202

P.4
0
Vertical Fin & Rudder
3
Completed
0
Tail Landing Gear
4
Bottom View
PA2x8mm Screw
2
Fibre Tape
17x175mm
Fibre Tape
Plastic
Collar
Wheel Ø23mm
PA2x8mm
1.2mm
Bottom View
Stabilizer & Elevator
2
Fibre Tape
17x380mm
FibreTape
Bottom
Joining surfaces should
be clean and dry. Slightly
roughen surfaces with
sandpaper for best results.
Joining surfaces should be clean and dry. Slightly roughen
surfaces with sandpaper for best results.
Plywood
36.7x36.7x3mm
Plywood
36.7x36.7x3mm
GM040PO27791202

Main Landing Gear
Elevator Pushrod
5
6
Bottom ViewCompleted
Bottom View
P.5
Bottom View
PA2x8mm Screw
1
PWA2x6mm Screw
4
Plywood
48x35.7x2.5mm
Landing Gear Covers
2.6mm
2
PA1.7x8 mm Screw
4
TWM PL8210010
CLEVIS WRENCH
Straper Fuel Tube
d2xD4x4mm
PA1.7x8mm
02L
03L
04L
02R
03R
04R
Please choose either (02L&02R) or (03L&03R) or (04L&04R) that suits your servo.
100
Bottom View
Landing Gear
Bottom View
PA2x8mm
Collar w/ Set Screw
M3x3mm Set Screw
2.6mm Collar
2.6mm Collar
Wheel Ø40mm
Wheel Pants
PWA2x6mm
12x20mm
Mounting Plate
Landing Gear
Landing Gear
Fuselage
Clevis
Pushrod
Ø1.4x135mm
Fuel Tube
d2xD4x4mm
Horn
GM040PO27791202

Outrunner Motor 28/ 30
KM0283010
PropellerAdaptor
(d3xD5) HW2340100
Rudder Pushrod
Outrunner Motor / Spinner
7
8
P.6
PA2.6x8mm Screw
2
M3x6mm
Socket Head Screw
4
PM2x12mm Screw
2
d3xD7mm Washer
4
Don’t over-tighten the PM2 screws, let the propeller
blades align themselves when spinning.
3
PM2x12mm
Folding Propeller
Set PL 6314020
PM2x12mm
Make sure rotating motor casing is not in
contact with wirings or anything.
Optional Parts
TWM PL8210010
CLEVIS WRENCH
2
d3xD7mm Washer
M3x6mm
Don't over-tighten the M3 screws, too much
stress on the screws could split the firewall.
1
Brushless ESC
EZ Connector
Solder Solder
TWM
KM0283010
ESC
Motor
4 5
M5 Nut
Ø45mm
PA2.6x8mm
TWM HW3111400
PROPELLER ADAPTOR WRENCH Completed
Straper Fuel Tube
d2xD4x4mm
PA1.7x8mm
02L
03L
04L
02R
03R
04R
Please choose either (02L&02R) or (03L&03R) or (04L&04R)
that suits your servo.
PA1.7x8 mm Screw
4
Clevis
Pushrod
Ø1.4x130mm
Fuel Tube
d2xD4x4mm
Horn
GM040PO27791202

P.7
Main Wing
9
Rubber Band
Wing Tube
Aileron Servo Lead
Ø6x458mm
Radio Equipment
10
Battery
Install and arrange the equipment as shown in the picture.
Outrunner Motor
Battery Tie Sponge
Receiver
Front
Brushless
ESC
Double Sided Tape
Completed
Fuselage Bottom
Cockpit
Completed
GM040PO27791202

P.8
Bottom View
Top View
Control Throws
12
Elevator
Rudder
Ailerons
Adjust the control throws as shown in
the diagram. These throws are good for
general flying. You can adjust according
to your personal preference.
12mm
12mm
10mm
10mm
25mm
25mm
Decals
11
GM040PO27791202

P.9
Important Safety Precautions
# First time flyer should never fly by himself / herself. Assistance from experienced flyer
is absolutely necessary.
# Pre-flight adjustment must be done before flying, it is very dangerous to fly a badly
pre-adjusted aircraft.
# is specially designed to be powered by KM0283010 Outrunner Motor.
# Make sure the air field is spacious, never fly the plane too close to people and never get
too close to a running propeller. Extreme caution should be exercised when working with
electric powered models. Make sure the propeller is cleared of all objects, especially your
hands before connecting the battery to the model. Make sure you understand the
operation of the ESC (Electronic Speed Control) by studying the ESC manual. Once you
plug in the battery for electric powered model, always treat the propeller as a rotating one,
as accidental movement of the throttle stick will spin the propeller and could cause injuries.
# Check and re-tighten up all factory assembled screws, use thread locker if necessary.
Warning!
sunrise ep
C.G.
13
The ideal C.G. position is 95mm (3.75in.) behind the leading edge
measured at where the wing meets the fuselage. In order to obtain
the C.G. specified, add weight to the fuselage or move the battery
position. Check the C.G. before flying.
95mm
3.75in
C.G.
http://www.thewingsmaker.com/instructionManuals.php
GM040PO27791202

Large Clevis•
Small Clevis•
Pl8210010
-Kv(rpm/V): 1010
-Operating Power: 225W
-Operating Voltage: 6-15V
-Operating Current: 15A
-Peak Current: 20A(max.15 sec.)
-Internal Resistance: 102 m ohms
-Diameter: 28mm
-Length: 32mm
-Weight: 60g
-Shaft Diameter: 3mm
-Shaft Length: 15mm
-Mounting Screw:
M3(Front) and M2(Back)
-Distance of Mounting Holes:
16mm and 19mm(Front),
12mm(Back)
KM02832R1
Outrunner 28/ 32 Deluxe (25% higher power)
GM040PO27791202
