The Wings Maker J-11 B FIGHTER User manual

It is designed for maximum performance. Please seek advice if one is not familiar with this kind
of electric powered precision model. Operating this model without prior preparation may cause
injuries. Remember, safety is the most important thing. Always keep this instruction manual at
hand for quick reference.
Warning ! This model is not a toy.
THE WINGS MAKER
FACTORY PRE-FABRICATED
ALMOST-READY-TO-FLY (ARF) SERIES
MADE IN CHINA
* Specifications are subject to change without notice.*
www thewingsmaker com. .
SpecificationsSpecifications
Before commencing assembly please read these instructions thoroughly, .
INSTRUCTION MANUAL
Wing Span: 41 in / 1040 mm
Wing Area: 527 sq in / 34 sq dm
Flying Weight: 68 oz / 1920 g
Fuselage Length: 57 in / 1450 mm
Requires: 6-channel w/ 10 micro servos, 2x40A (burst 45A)
Brushless ESC and 2x4 cells 14.8V 20C 2100 mAh
battery and charger
GM046
GM046PO256341104

INDEX
BEFORE YOU BEGIN
BEFORE YOU BEGIN
PARTS LIST
ASSEMBLY
SAFETY PRECAUTIONS
P.1
P.2
P.3-P.13
P.13
Check all parts. If you find any defective or missing parts contact your local dealer. Please
DRY FIT and check for defects for all parts that will require CA or Epoxy for final assembly.
Any parts you find to be defective after the gluing process may be difficult to remove for
warranty replacement. The manufacturer will replace any defective parts, but will not extend
to the parts that are good before gluing to defective parts during assembly. Warranty will
not cover any parts modified by customer.
Symbols used throughout this instruction manual comprise of the following :-
Read through the manual before you begin, so you will have an overall idea of what to do.
1
2
3
P.1
Cut off shaded portion.
Ensure smooth non-binding
movement while assembling.
Apply instant glue
(C.A.glue, super glue.)
Assemble left and right
sides the same way.
Peel off shaded portion
covering film.
Pay close attention here!
Apply epoxy glue.
Must be purchased separately !
Drill holes with the specified
diameter (here: 3mm). Pierce the shaded portion
covering film.
3mm
Do not overlook this symbol !
Warning!
Apply thread locker
GM046PO256341104

Parts List
1. MAIN WING -- 1 pair
SCREW PA1.7x8mm -- 8 pcs
SCREW PB2x16mm -- 4 pcs
SERVO MOUNTING PANEL PL5310020 -- 1 pair
STRAPER PL4112106 -- 2 pcs
CLEVIS PL4112105 -- 2 pcs
FUEL TUBE d2xD4x4mm -- 4 pcs
HORN PL4113102 -- 2 sets
PUSHROD
Ø1.4x101mm w/ Threads (ForAileron) -- 2 pcs
FIBRE TAPE 17x210mm -- 2 pcs
PLYWOOD 36.5x36.5x2mm -- 2 pcs
2. VERTICAL FIN & RUDDER -- 1 pair
SCREW PA1.7x8mm -- 8 pcs
SCREW PB2x18mm -- 4 pcs
SERVO MOUNTING PANEL PL5310020 -- 1 pair
STRAPER PL4112106 -- 2 pcs
CLEVIS PL4112105 -- 2 pcs
FUEL TUBE d2xD4x4mm -- 4 pcs
HORN PL4113102 -- 2 sets
PUSHROD
Ø1.4x58mm w/ Threads (ForAileron) -- 2 pcs
FIBRE TAPE 17x190mm -- 2 pcs
PLYWOOD 36.5x36.5x2mm -- 2 pcs
3. STABILIZER & ELEVATOR -- 1 pair
SCREW PB2x20mm -- 4 pcs
STRAPER PL4112106 -- 2 pcs
CLEVIS PL4112105 -- 2 pcs
FUEL TUBE d2xD4x4mm -- 4 pcs
HORN PL4113102 -- 2 sets
PUSHROD
Ø1.4x35mm w/ Threads (ForAileron) -- 2 pcs
FIBRE TAPE 17x190mm -- 2 pcs
PLYWOOD 12x6x2mm -- 4 pcs
4. FUSELAGE -- 1 set
MECHANICAL NOSE RETRACT -- 1 set
PUSHROD Ø1.4x90mm w/ Threads -- 1 pc.
PUSHROD Ø1.4x40mm w/ Threads -- 1 pc.
COLLAR Ø2.6mm w/ Set Screw -- 3 sets
LINKAGE CONNECTOR 2.1mm HW7111050 -- 4 sets
RUBBER TAIL WHEELS
Ø30mm PL3410020 -- 1 pc.
RETRACTABLE LANDING GEAR--1 pair
RUBBER TAIL WHEELS Ø40mm PL3117040 -- 2 pcs
PUSHROD
Ø1.4x40mm w/ Threads -- 2 pcs
PLYWOOD 20x6x4mm -- 4 pcs
PLYWOOD 12x6x2mm -- 4 pcs
5. SCREW PM2.5x8mm -- 8 pcs
WASHER d2.5xD6x0.5mm -- 8 pcs
DUCTED FAN COVER -- 1 pair
6. CANOPY -- 1 pc.
PILOT PC101042B -- 1 pc.
NOSE CONE -- 1 pc.
DRAG PARACHUTE -- 1 pc.
7. MISSILE -- 2 pcs
9. BATTERY COVER -- 1 pc.
RECEIVER COVER -- 1 pc.
SPONGE 10x50x150mm (For Radio Equipment & Battery) -- 3 pcs
DOUBLE-SIDED TAPE 30x35mm -- 2 pcs
BATTERY TIE 200mm -- 2 pcs
FOAM 22x22x60mm (For Brushless ESC) -- 2 pcs
10. DECALS GM046DEC -- 1 set
GM046PO256341104

Bottom View
Aileron Servo
PA1.7x8mmScrew
8
PB2x16mmScrew
4
TWM PL8210010
CLEVIS WRENCH
Straper Fuel Tube
d2xD4x4mm
PA1.7x8mm
Please choose either (02L & 02R) or (03L & 03R) or (04L & 04R) that suits your servo.
Clevis
Horn
Fuel Tube
d2xD4x4mm
PB2x16mm
Pushrod
Ø1.4x101mm Aileron Servo Lead
Bottom View
Please do not overtighten PB2x16mm screw. Once the screw brings the horn
and backplate in contact with the foam, add 1/2 turn will do. Overtightening
will damage the foam.
√×
Ø1mm pilot holes for The Wings Maker
horn are pre-drilled. Please look for
pin-hole marks at under side of control
surfaces.
17x210mm
02L
03L
04L
02R
03R
04R
Fibre Tape
Bottom
Fibre Tape
Plywood
36.5x36.5x2mm
P.3
1
GM046PO256341104

Rudder Servo
PA1.7x8mmScrew
8
PB2x18mmScrew
4
TWM PL8210010
CLEVIS WRENCH
Straper Fuel Tube
d2xD4x4mm
PA1.7x8mm
Please choose either (02L & 02R) or (03L & 03R) or (04L & 04R) that suits your servo.
Clevis
Horn
Fuel Tube
d2xD4x4mm
PB2x18mm
Pushrod
Ø1.4x58mm Rudder Servo Lead
Please do not overtighten PB2x18mm screw. Once the screw brings the horn
and backplate in contact with the foam, add 1/2 turn will do. Overtightening
will damage the foam.
√×
17x190mm
Fibre Tape
02L
03L
04L
02R
03R
04R
P.4
2
Ø1mm pilot holes for The Wings Maker
horn are pre-drilled. Please look for
pin-hole marks at under side of control
surfaces.
Fibre Tape
Plywood
36.5x36.5x2mm
GM046PO256341104

Bottom View
Elevator Servo
PB2x20mmScrew
4
TWM PL8210010
CLEVIS WRENCH
Please choose either (02L & 02R) or (03L & 03R) or (04L & 04R) that suits your servo.
Clevis
Horn
Fuel Tube
d2xD4x4mm
PB2x20mm
Straper
Pushrod
Ø1.4x35mm
Elevator Servo Lead
Please do not overtighten PB2x20mm screw. Once the screw brings the horn
and backplate in contact with the foam, add 1/2 turn will do. Overtightening
will damage the foam.
√×
17x190mm
Plywood
12x6x2mm
P.5
3
1mm
Bottom View
Ø1mm pilot holes for The Wings Maker
horn are pre-drilled. Please look for
pin-hole marks at under side of control
surfaces.
Bottom Fibre Tape
Fibre Tape
GM046PO256341104

Retract Servo
P.6
4
PUSHROD TRAVEL
Left
Right
Pushrod Ø1.4x40mm
Pushrod Ø1.4x90mm
1mm
1mm
Nose Retract Servo
Steering Servo
Retract Servo Lead Retract Servo Lead
(For Steering Servo)
GE
GE-1 GE-2
GE-3
GE-1 GE-2
GE-3
Bottom ViewBottom View
Main Wheel
Nose Wheel
Bottom View
Completed
Bottom View
16mm
Travel
Wheel Down Wheel Up
PUSHROD TRAVEL
16mm
Travel
PUSHROD TRAVEL
16mm
Travel
1mm
Wheel Down Wheel Up
Wheel DownWheel Up
Nose Retract Servo
Plywood
12x6x2mm
Plywood
20x6x4mm
Plywood
20x6x4mm
GM046PO256341104

P.7
Ducted Fan Propulsion Unit with Turbo Outrunner
5
Make sure rotating motor casing is not in contact with
wirings or anything.
123
456
M3x6mm
PM2x4mm
7
Completed
d3xD7mm
Washer
PM2.5x8mm
8
d2.5xD6x0.5mm Washer
PM2.5x8mmScrew
8
Make sure TWM logo on ducted
fan stay on up of fusealge.
CenterLine
Bottom
Optional Parts
Ducted Fan
Propulsion Unit PL6800010
& Outrunner 28 / 31 KM0283120
Solder
HEAT SHRINK TUBE
D5x30mm
HEAT SHRINK TUBE
Electric Wire
Electric Wire
Insulation
Bottom View
Motor wire lead
R
R L
L
Ducted Fan Cover
Apply a drop of CA to each notch will hold the intake cone in place, pry the notch with screw
driver to remove the cone for impeller or motor replacement.
GM046PO256341104

Fuselage
P.8
6
Completed
Completed
Pilot Canopy Nose Cone
Drag Parachute
GM046PO256341104

Main Wings & Missiles
Missile
P.9
7
Completed
Completed
Bottom View Bottom View
Bottom View Bottom View
Joining surfaces should be clean and dry. Slightly roughen surfaces with
sandpaper for best results.
Aileron Servo Lead
Elevator Servo Lead
AI-1 AI-2
EL-1 EL-2
GM046PO256341104

Vertical Fin & Rudder
P.10
8
9
RU-1
RU-2
Completed
RU-3
RU-2
RU-1
RU RU-3RU-2
RU-1
Bottom View
Rudder Servo Lead
GM046PO256341104

Raido Equipment
Install and arrange the equipment as shown in the picture.
Solder Solder
TWM
KP0011310
ESC Ducted Fan
Front
Battery Cover Receiver Cover
P.11
9
Completed
Sponge 10x50x150mm
Battery
Battery Tie Brushless ESC
Receiver
Bottom View
Bottom View
Double - Sided Tape
Please check with your ESC manufacturer if you
can simply connect your ESCs in parallel by Y-cord.
Normally if you are using two identical ESCs, you can
simply connect them in parallel with Y-cord. If you are
not sure, you can disable the BEC in one of the ESCs,
before you connect them with Y-cord. you can do this
by pulling the red wire (the center one) from the 3-pin
plug that goes to the receiver.
ESC-1
ESC-2
FOAM
22x22x60mm
Make sure the heat dissipating surface
of ESC is flush with intake air duct and
expose to air flow.
Intake air duct
Heat dissipating surface of ESC
Pull the red wire
GM046PO256341104

Decals
Control Throws
Adjust the control throws as shown in
the diagram. These throws are good for
general flying. You can adjust according
to your personal preference.
11
P.12
10
Bottom ViewTop View
Elevator
15mm
15mm
Aileron
25mm
25mm
Rudder 25mm
25mm
GM046PO256341104

C.G.
The ideal C.G. position is 165mm (6.5 in.) behind the leading edge
measured at where the wing meets the fuselage. In order to obtain
the C.G. specified, add weight to the fuselage or move the battery
position. Check the C.G. before flying.
165mm
6.5in
C.G.
P.13
12
Important Safety Precautions
# First time flyer should never fly by himself / herself. Assistance from experienced flyer
is absolutely necessary.
# Pre-flight adjustment must be done before flying, it is very dangerous to fly a badly
pre-adjusted aircraft.
# is specially designed to be powered by 2xKM0283120 Outrunner Motor.
# Make sure the air field is spacious, never fly the plane too close to people and never
get too close to a running propeller.
# Check and re-tighten up all factory assembled screws, use thread locker if necessary.
Warning!
J-11B FIGHTER
Measure C.G. with the wheels in retracted position.
http://www.thewingsmaker.com/instructionManuals.php
GM046PO256341104

Optional Parts
40A Brushless ESC
Code No. Size Package
KC2040A02 55 x 28 x12mm 1 pc
-Current : 40A continuous
-Burst current ( < 10 seconds) : 55A
-Weight : 33g (with wires)
-BEC output : 3A
-Input :
Li - ion / Li - poly 2 - 5 cells;
Nimh / Nicd 5 - 15 cells
3 - Pin EZ Connector
Code No. Size Package
KP0011310 40A Max. Current 1 set
-ideal for electric models
-ideal for electric models
180mm Extension For Park Flyer
Code No. Size Package
KW0011800 180mm 1 set
Speed : 0.1 sec / 60° @4.8V
Torque : 16kg.cm / 22.2 oz - in @4.8V
Size : 22.4 x 11.4 x 20.0mm /
0.88x0.45 x 0.79in
Weight : 7.8 g / 0.28 oz
Micro Servo
Clevis Wrench
Code No. Size Package
PL8210010 1 set
Small Clevis Large Clevis
( ACCESSORIES)
Ducted Fan Propulsion Unit without Motor
Code No. Size Package
PL6800010 1 set
-Operating Voltage / Current :
12V / 30A (35A Burst)
-Thrust : Approx. 560A
-Weight : 60g (without motor)
-Rotor diameter : 67 mm
-Outer casing diameter : 74 mm
-Color : Black
Turbo Outrunner for ducted fan
Code No. Size Package
KM0283120 1 set
-Kv (rpm / V): 3030
-Operating Power: 660W
-Operating Voltage: 6 - 15V
-Operating Current: 45A
-Peak Current: 60A (max. 15 sec.)
-Internal Resistance: 28 m ohms
-Diameter: 28 mm
-Length: 31 mm
-Weight: 60 g
-Shaft Diameter: 3 mm
-Shaft Length: 14.8 mm
-Mounting Screw:
M3 (Front) & M2 (Back)
-Distance of Mounting Holes:
16 mm and 19 mm (Front)
2 - Pin EZ Connector
Code No. Size Package
KP0011210 40A Max. Current 1 set
Heat Shrink Tube
Code No. Size Package
Code No. Size Package
PT1115050 D5mm x 10cm 2 pcs x 3 colors
SV2031 1 set
-Three colors (Black, Red, Yellow)
Silicon Wire
Code No. Size Package
HW2110101 D4.0mm 1 set
-1 M black & 1 M red / pkg
Special tool for clevis installation.
Suitable for standard and small
(EP) clevis.
GM046PO256341104

THE WINGS MAKER
www.thewingsmaker.com
GM046PO256341104
