The Wings Maker DF-032 User manual

It is designed for maximum performance. Please seek advice if one is not familiar with this kind
of electric powered precision model. Operating this model without prior preparation may cause
injuries. Remember, safety is the most important thing. Always keep this instruction manual at
hand for quick reference.
Warning ! This model is not a toy.
THE WINGS MAKER
FACTORY PRE-FABRICATED
ALMOST-READY-TO-FLY (ARF) SERIES
MADE IN CHINA
* Specifications are subject to change without notice.*
www thewingsmaker com. .
SpecificationsSpecifications
Before commencing assembly please read these instructions thoroughly, .
INSTRUCTION MANUAL
Wing Span: 33 in / 850 mm
Wing Area: 299 sq in / 19.3 sq dm
Flying Weight: 24 oz / 680 g
Fuselage Length: 26.5 in / 675 mm
Requires: 3-channel “mixing radio”(elevator and aileron)
w/ 2 micro servos, 30A (burst 35A) Brushless ESC
and 3 cells 11.1V 20C 2100 mAh battery and charger
(GM032SXM)
GM032SXMPO27851203

INDEX
BEFORE YOU BEGIN
BEFORE YOU BEGIN
PARTS LIST
ASSEMBLY
SAFETY PRECAUTIONS
P.1
P.2
P.3-P.9
P.9
P.1
Check all parts. If you find any defective or missing parts contact your local dealer. Please
DRY FIT and check for defects for all parts that will require CA or Epoxy for final assembly.
Any parts you find to be defective after the gluing process may be difficult to remove for
warranty replacement. The manufacturer will replace any defective parts, but will not extend
to the parts that are good before gluing to defective parts during assembly. Warranty will
not cover any parts modified by customer. For pre-assembled kits, please check proper
functions of all servos on the ground before flying. Servo gears could be damaged when
control surfaces are hit during transportation of models. The manufacturer will replace any
servos due to manufacturer`s defect, but will not cover plane crashes due to damaged
servos not detected before flying.
Symbols used throughout this instruction manual comprise of the following :-
Read through the manual before you begin, so you will have an overall idea of what to do.
1
2
3
Cut off shaded portion.
Ensure smooth non-binding
movement while assembling.
Apply instant glue
(C.A.glue, super glue.)
Assemble left and right
sides the same way.
Peel off shaded portion
covering film.
Pay close attention here!
Apply epoxy glue.
Must be purchased separately !
Drill holes with the specified
diameter (here: 3mm). Pierce the shaded portion
covering film.
3mm
Do not overlook this symbol !
Warning!
Apply thread locker
GM032SXMPO27851203

Parts List
1. MAIN WING -- 1 pair
WING TIP -- 1 pair
FIBRE TAPE 17x300mm -- 2 pcs
2. SCREW PA1.7x8mm -- 8 pcs
SERVO MOUNTING PANEL PL5310020 -- 1 pair
PLYWOOD 2x36x36mm (For Aileron Servo) -- 2 pcs
STRAPER PL4112106 -- 2 pcs
CLEVIS PL4112105 -- 2 pcs
FUEL TUBE d2xD4x4mm -- 4 pcs
HORN PL4113103 -- 2 pcs
PUSHROD Ø1.4x55mm w/Threads (For Aileron) -- 2 pcs
3. FUSELAGE -- 1 pc.
CANOPY / BATTERY COVER -- 1 pc.
PLYWOOD&MAGNET “-” 11x12mm -- 2 pcs
PLYWOOD&MAGNET “+” Ø12 mm -- 2 pcs
PLYWOOD 2x66x182mm (For Battery) -- 1 pc.
PLYWOOD 3x38x86mm (For Fuselage) -- 1 pc.
DUMMY COWLING -- 1 pc.
BATTERY TIE 200mm -- 1 pc.
4. VERTICALFIN -- 1 set
5. PLYWOOD 4x10x35mm (For Ducted Fan) -- 2 pcs
SCREW PM2.5x8mm -- 4 pcs
WASHER d3xD7mm -- 4 pcs
PLYWOOD&MAGNET “-” 11x12mm -- 2 pcs
PLYWOOD&MAGNET “+” Ø12 mm -- 2 pcs
DUCTED FAN COVER -- 1 pc.
6. CARBON FIBER TUBE Ø5x450mm -- 1 pc.
7. BATTERY MAT 50x150mm -- 2 pcs
DOUBLE-SIDED TAPE 30x35mm -- 1 pc.
8. DECALS: GM032SDEC -- 1 set
GM032SXMPO27851203

Aileron Servo
Bottom View
Bottom View
PA1.7x8mm Screw
8
TWM PL8210010
CLEVIS WRENCH
02L
03L
04L
02R
03R
04R
Please choose either 02L & 02R or 03L & 03R or 04L & 04R that suits your servo.
Horn
Aileron Servo Lead
Bottom View
Plywood
2x36x36
Completed
Bottom View
17x300mm
Fibre Tape
Fibre Tape
Bottom Wing Tip
UP
P.3
2
Main Wing
1
Straper Fuel Tube
d2xD4x4mm
PA1.7x8mm
Clevis
Pushrod
Ø1.4x55mm
Fuel Tube
d2xD4x4mm
Horn
GM032SXMPO27851203

P.4
Vertical Fin
4
Fuselage
3
Completed
Plywood 182x66x2mm
Plywood
3x38x86mm
Battery Tie 200mm
Plywood&Magnet “-” 11x12mm
Plywood&Magnet “+” Ø12mm
Dummy Cowling
GM032SXMPO27851203

P.5
Ducted Fan Propulsion Unit with 28/31 Motor
5
Make sure rotating motor
casing is not in contact with
wirings or anything.
123
456
M3x6mm
PM2x5mm
7
Completed
4
d3xD7mm Washer
PM2.5x8mm Screw
4
Optional Parts
Ducted Fan
Propulsion Unit
with Motor PL6800010
& Outrunner 28 / 31 KM0283110
Plywood
4x10x35mm
Solder D5x30mm
HEAT SHRINK TUBE
Electric Wire Insulation
Washer
d3xD7mm
PM2.5x8mm
Make sure TWM logo on ducted
fan stay on bottom of fuselage.
CenterLine
Bottom
Electric Wire
Apply a drop of CA to each notch will hold the intake cone in place, pry the notch with screw
driver to remove the cone for impeller or motor replacement.
Plywood&Magnet “-” 11x12mm
Plywood&Magnet “+” Ø12mm
GM032SXMPO27851203

P.6
Main Wing
6
Battery & ESC
7
Install and arrange the equipment as shown in the picture.
Battery
Battery Tie
Battery Mat
50x150mm
Bottom View Completed
Completed
Solder Solder
TWM
KP0011310
Bottom View
ESC Ducted Fan
Carbon Fiber Tube
Ø5x450mm
Aileron Servo Lead
Foam
151x13x5mm Foam 151x13x5mm
Aileron Servo Lead
Aileron Servo Lead
Aileron Servo Lead
Aileron Servo Lead
ReceiverReceiver
Double-Sided tape
Double-Sided tape
30A Brushless ESC
30A Brushless ESC
Inside View
30A Brushless ESC30A Brushless ESC
GM032SXMPO27851203

Decals
P.7
8
Bottom View
GM032SXMPO27851203

P.8
Field Stand / Launching Pad
The field stand can be used as a launching-pad if you are flying on paved
runways. Place the on the stand, point it into the wind, check your
controls and advance the throttle. When the gets enough air speed,
pull the elevator gently and the will fly off the field stand and get
airborne gracefully.
If you are flying on grass fields and could not use the field stand as a
launching pad, you will need to hand launch the .
When the has gained enough air speed, gently pull the elevator
and let the climb to a higher safe altitude. Reduce the throttle to
slow the while maintaining altitude. The should fly well
about half throttle. You may add power when turning, climbing or doing
loops. Learn how the behaves and adjust the trims for level flight.
To avoid overheating of ducted fan motor and battery, we recommend you
use full power intermittently. This will also give you longer flying time and
extend the battery life.
For the first hand launch flight, we recommend having an assistant to hand
launch the for you. Ask your assistant to hold the by the
fuselage, pointed into the wind, while you check the correct control surface
response. Fully advance the throttle to start the motor and once the ducted
fan is at full power, the hand launcher should gently push the plane into the
air at a level attitude. Don’t use excessive force as it is not necessary, and
don’t throw the model up the sky as it will cause the model to stall before
gaining air speed. Make sure the is being launched into the wind
and be alert to make corrections to keep the model flying straight and level
into the wind.
9
GM032SXMPO27851203

C.G.
Control Throws
Adjust the control throws as shown in
the diagram. These throws are good for
general flying. You can adjust according
to your personal preference.
10mm
10mm
Ailerons / Elevator
The ideal C.G. position is 70mm (2.76 in.) behind the leading edge
measured at where the wing meets the fuselage. In order to obtain
the C.G. specified, add weight to the fuselage or move the battery
position. Check the C.G. before flying.
70mm
2.76 in
C.G.
P.9
11
10
Important Safety Precautions
# First time flyer should never fly by himself / herself. Assistance from experienced flyer
is absolutely necessary.
# Pre-flight adjustment must be done before flying, it is very dangerous to fly a badly
pre-adjusted aircraft.
# is specially designed to be powered by KM0283110 Outrunner Motor.
# Make sure the air field is spacious, never fly the plane too close to people and never
get too close to a running propeller.
# Check and re-tighten up all factory assembled screws, use thread locker if necessary.
Warning!
Please note that the mixing function of your radio will add up the control throws of
aileron and elevator input. A control throw of 10mm for the aileron or elevator alone
will give you up to 20mm throw if you input aileron and elevator throw at the same time.
http://www.thewingsmaker.com/instructionManuals.php
GM032SXMPO27851203

Optional Parts
30A Brushless ESC
Code No. Size Package
KC2030A02 24 x 45 x11mm 1 pc
-Current : 30A continuous
-Burst current ( < 10 seconds) : 40A
-Weight : 25g (with wires)
-BEC output : 2A
-Input :
Li - ion / Li - poly 2 - 4 cells;
Nimh / Nicd 5 - 12 cells
3 - Pin EZ Connector
Code No. Size Package
KP0011310 40A Max. Current 1 set
-ideal for electric models
-ideal for electric models
180mm Extension
Code No. Size Package
KW0011800 180mm 1 set
Speed : 0.1 sec / 60° @4.8V
Torque : 16kg.cm / 22.2 oz - in @4.8V
Size : 22.4 x 11.4 x 20.0mm /
0.88x0.45 x 0.79in
Weight : 7.8 g / 0.28 oz
Code No SV2031
Micro Servo
Clevis Wrench
Code No. Size Package
PL8210010 1 set
Small Clevis Large Clevis
( ACCESSORIES)
Ducted Fan Propulsion Unit without Motor
Code No. Size Package
PL6800010 1 set
-Operating Voltage / Current :
12V / 30A (35A Burst)
-Thrust : Approx. 560g
-Weight : 60g (without motor)
-Rotor diameter : 67 mm
-Outer casing diameter : 74 mm
-Color : Black
Outrunner 28 / 31 (for ducted fan)
Code No. Size Package
KM0283110 D28 x 31 mm 1 set
-Kv (rpm / V): 3600
-Operating Power: 375W
-Operating Voltage: 6 - 15V
-Operating Current: 30A
-Peak Current: 35A (max. 15 sec.)
-Internal Resistance: 25 m ohms
-Diameter: 28 mm
-Length: 31 mm
-Weight: 58 g
-Shaft Diameter: 3 mm
-Shaft Length: 14.8 mm
-Mounting Screw:
M3 (Front) and M2 (Back)
-Distance of Mounting Holes:
16 mm and 19 mm
2 - Pin EZ Connector
Code No. Size Package
KP0011210 40A Max. Current 1 set
Heat Shrink Tube
Code No. Size Package
PT1115050 D5mm x 10cm 2 pcs x 3 colors
-Three colors (Black, Red, Yellow)
Silicon Wire
Code No. Size Package
HW2110101 D4.0mm 1 set
-1 M black & 1 M red / pkg
Special tool for clevis installation.
Suitable for standard and small
(EP) clevis.
GM032SXMPO27851203
