Theben MIX 2 Series User manual

MIX 2 series RMG 4 U / RME 4 U actuators
MIX 2 series actuators
RMG 4 U / RME 4 U
RMG 4 U 4930223
RME 4 U 4930228
Updated: Apr-15 (Subject to changes) Page 1 of 50

MIX 2 series RMG 4 U / RME 4 U actuators
Contents
1Functional characteristics ................................................................................................4
2MIX and MIX2 devices .....................................................................................................5
3Operation...........................................................................................................................6
4Technical data ...................................................................................................................7
5The application programme "MIX2 V1.8".....................................................................8
5.1 Selection in the product database...........................................................................8
5.2 Communication objects ...........................................................................................9
5.2.1 Channel-related objects:.........................................................................................9
5.2.2 Common objects:..................................................................................................12
5.2.3 Description of objects...........................................................................................13
5.3 Parameter................................................................................................................20
5.3.1 Parameter pages....................................................................................................20
5.3.2 Parameter description...........................................................................................21
5.3.2.1 The "General" parameter page.....................................................................21
5.3.2.2 The "RMG 4 U basic module" parameter page............................................23
5.3.2.3 The "RMG 4 U channel Cx: Configuration options" parameter page..........24
5.3.2.4 The "Contact characteristics" parameter page ............................................26
5.3.2.5 The "On/Off delay" parameter page.............................................................27
5.3.2.6 The "Pulse function.." parameter page.........................................................27
5.3.2.7 The "Staircase light with forewarning function .." parameter page.............28
5.3.2.8 The "Flashing.." parameter page..................................................................29
5.3.2.9 The "Threshold" parameter page..................................................................30
5.3.2.10 The "Block function" parameter page.......................................................32
5.3.2.11 The "Scenes" parameter page...................................................................33
5.3.2.12 The "Feedback" parameter page ..............................................................36
5.3.2.13 The "Hour counter and service" parameter page.....................................37
5.3.2.14 The "Link" parameter page.......................................................................39
6Typical applications.........................................................................................................40
6.1 2x switching with push button interface ..............................................................40
6.1.1 Devices:................................................................................................................40
6.1.2 Overview..............................................................................................................40
6.1.3 Objects and links..................................................................................................40
6.1.4 Important parameter settings................................................................................41
6.2 Switching light with service counter and display................................................42
6.2.1 Devices.................................................................................................................42
6.2.2 Overview..............................................................................................................42
6.2.3 Objects and links..................................................................................................43
6.2.4 Important parameter settings................................................................................44
6.3 Simple warning function with flashing light........................................................45
6.3.1 Devices:................................................................................................................45
Updated: Apr-15 (Subject to changes) Page 2 of 50

MIX 2 series RMG 4 U / RME 4 U actuators
6.3.2 Overview..............................................................................................................45
6.3.3 Objects and links..................................................................................................45
6.3.4 Important parameter settings................................................................................46
7Appendix..........................................................................................................................47
7.1 The scenes................................................................................................................47
7.1.1 Principle ...............................................................................................................47
7.1.2 Call up or save scenes: .........................................................................................48
7.1.3 Teach in scenes without telegrams (MIX2 devices ONLY) ................................50
7.2 Conversion of percentages to hexadecimal and decimal values.........................50
Updated: Apr-15 (Subject to changes) Page 3 of 50

MIX 2 series RMG 4 U / RME 4 U actuators
1 Functional characteristics
•MIX2 4-way switch actuator.
•MIX2 basic module.
•Can be upgraded to a maximum of 12 channels.
•Up to 2 MIX or MIX2 extension modules can be connected to a basic module.
•Device and KNX bus module can be swapped independently of each other.
•Removable KNX bus module enables devices to be changed without reprogramming.
•Manual set-up and use of switch actuators is also possible without KNX bus module.
•LED switching status indicator for each channel.
•Manual operation on device (even without bus voltage).
•Adjustable features: e.g. switching, delayed switching, pulse function.
•Links, type of contact (NC contact/NO contact) and participation in central commands such
as permanent On, permanent Off, central switching, and save/call up scene.
•Switch functions: e.g. On/Off, pulse, On/Off delay, staircase light with forewarning.
•Logical links: e.g. block, AND, release, OR.
•Activation of the channel function via 1-bit telegram or 8-bit threshold.
Updated: Apr-15 (Subject to changes) Page 4 of 50

MIX 2 series RMG 4 U / RME 4 U actuators
2 MIX and MIX2 devices
The MIX2 series consists of the basic modules RMG 4 I, RMG 4 U, RMG 8 S, RMG 8 T, DMG 2 T,
JMG 4 T, JMG 4 T 24V, HMG 6 T, BMG 6 T + extensions RME 4 I,
RME 4 U, RME 8 S, RME 8 T, DME 2 T, JME 4 T, JME 4 T 24V, HMG 6 T, BME 6 T (as of
03/2015).
Any MiX and MIX2 extension modules can be connected to a MIX2 basic module.
Table 1
Device type Ord.
No. Designation Can be used with basic module..
in the MIX series in the MIX2
series
MIX2 basic
modules
493…
RMG 4 I, RMG 4 U,
RMG 8 S, RMG 8 T,
DMG 2 T, JMG 4 T,
HMG 6 T, JMG 4 T 24V,
BMG 6 T
--
MIX2
extensions
493…
RME 4 I, RME 4 U,
RME 8 S, RME 8 T,
DME 2 T, JME 4 T,
HME 6 T, JME 4 T 24V, BME
6 T.
no Yes
MIX basic
modules
491…
BMG 6, DMG 2 S, HMG 4,
JMG 4 S, RMG 4 S,
RMG 4 C-load, SMG 2 S
--
MIX extensions
491…
BME 6, DME 2 S, HME 4,
JME 4 S, RME 4 S,
RME 4 C-load, SME 2 S
yes Yes*
* Adjusted parameter display and object numbering.
Updated: Apr-15 (Subject to changes) Page 5 of 50

MIX 2 series RMG 4 U / RME 4 U actuators
3 Operation
Each channel can be switched on and off independently of all parameters using the buttons on the
device. A status LED displays the current switching status.
All bus telegrams are ignored with manual operation switched on (manual button) and the channels are
exclusively to be operated via the buttons.
Mains voltage is required for the functioning of the buttons and LEDs, bus voltage or bus module are
not required.
Updated: Apr-15 (Subject to changes) Page 6 of 50

MIX 2 series RMG 4 U / RME 4 U actuators
4 Technical data
KNX operating voltage
Bus voltage, ≤ 4 mA
Operating voltage
110 – 240 V AC
Frequency
50 – 60 Hz
Standby output
0.3 W
Type of installation
DIN-rail
Width
4 TE
Connection type
KNX bus terminal
Max. cable cross-section
Solid: 0.5 mm² (Ø 0.8) to 4 mm² | strand with
crimp terminal: 0.5 mm² to 2.5 mm²
Number of channels
4
Contact gap
< 3 mm
Voltage output
240 V AC
Switch output
Floating
Switching of different phases
Possible
Type of contact
16 A, 3 A NO contact
Resistive load
3680 W
Incandescent and halogen lamp load
2000 W
Fluorescent lamp load (KVG)
parallel-corrected
1300 W (140 μF)
Fluorescent lamp load (KVG) not
corrected
2000 VA
Fluorescent lamp load (EB)
1200 W
Energy-saving lamps
300 W
LED lamps
< 2 W = 55 W or > 2 W < 8 W = 180 W
Suitable for SELV
Yes, if all channels switch SELV
Ambient temperature
-5 °C … +45 °C
Protection rating
IP 20
Protection class
II in accordance with EN 60 730-1
Updated: Apr-15 (Subject to changes) Page 7 of 50

MIX 2 series RMG 4 U / RME 4 U actuators
5 The application programme
"MIX2 V1.8"
5.1 Selection in the product database
Manufacturer
Theben AG
Product family
Output
Product type
RMG 4 U
Program name
MIX2 V1.8
The ETS database can be found on our downloads page: www.theben.de/en/downloads_en.
Table 2
Number of communication objects:
254
Number of group addresses:
254
Number of associations:
255
Updated: Apr-15 (Subject to changes) Page 8 of 50

MIX 2 series RMG 4 U / RME 4 U actuators
5.2 Communication objects
The objects are divided into channel-related and common objects
5.2.1 Channel-related objects:
Table 3:
No. Object name Function
Type
DPT
Flags
C
R
W
T
0RMG 4 U channel C1
Switch object
1 bit
1,001

Threshold as percent
1 byte
5,001

Threshold 0..255
1 byte
5,010

Threshold EIS 5
(DPT9.xxx)
2 byte
9.xxx

Threshold 0..65535
2 byte
7,001

1RMG 4 U channel C1
Logic input in AND gate
1 bit
1,001

Logic input in OR gate
1 bit
1,001

Logic input in XOR gate
1 bit
1,001

2RMG 4 U channel C1 Block
1 bit
1,003

3RMG 4 U channel C1 Call up/save scenes
1 byte
18,001

4RMG 4 U channel C1
Block scenes = 1
1 bit
1,003

Enable scenes = 1
5RMG 4 U channel C1 Feedback On/Off
1 bit
1,001

6RMG 4 U channel C1 Time to next service
2 byte
7,001

Operating hours feedback
2 byte
7,001

7RMG 4 U channel C1 Service required
1 bit
1,001

C
R
W
T
Updated: Apr-15 (Subject to changes) Page 9 of 50

MIX 2 series RMG 4 U / RME 4 U actuators
Continuation:
No. Object name Function
Type
DPT
Flags
C
R
W
T
8RMG 4 U channel C1
Switching with priority
2 bit
2,001

Reset service
1 bit
1,001

Reset operating hours
1 bit
1,001

9
Not used
10..
198
Channels C2 .. C4 and extension modules: See next table.
Updated: Apr-15 (Subject to changes) Page 10 of 50

MIX 2 series RMG 4 U / RME 4 U actuators
Table 4: Overview of channel-related objects
BASIC MODULE: RMG 4 U
C1 C2 C3 C4
0 10 20 30
1 11 21 31
2 12 22 32
3 13 23 33
4
14
24
34
5 15 25 35
6 16 26 36
7 17 27 37
8 18 28 38
1st EXTENSION: RME 4 U
C1
C2
C3
C4
80
90
100
110
81
91
101
111
82
92
102
112
83
93
103
113
84
94
104
114
85
95
105
115
86
96
106
116
87
97
107
117
88
98
108
118
2nd EXTENSION: RME 4 U
C1
C2
C3
C4
160
170
180
190
161
171
181
191
162
172
182
192
163
173
183
193
164
174
184
194
165
175
185
195
166
176
186
196
167
177
187
197
168
178
188
198
Updated: Apr-15 (Subject to changes) Page 11 of 50

MIX 2 series RMG 4 U / RME 4 U actuators
5.2.2 Common objects:
These objects are partly used by the basic module and the two extension modules.
Table 5:
No. Object name Function
Type
DPT
Flags
C
R
W
T
78
RMG 4 U
Manual 1 bit
1,001 
158
EM1 RME 4 U
238
EM2 RME 4 U
240 Central continuous ON
RMG/E4x/8x,DMG/E2x,
SME2S
1 bit
1,001

241 Central continuous OFF
RMG/E4x/8x,DMG/E2x,
SME2S
1 bit
1,001

242 Central switching
RMG/E4x/8x,DMG/E2x,
SME2S
1 bit
1,001

243 Call up/save central scenes
RMG4x/8x,DMG/E2x,
JMG/E4x,SME2S
1 byte
18,001

244 Central safety 1 For JME 4 S
1 bit
1,001

245 Central safety 2 For JME 4 S
1 bit
1,001

246 Central safety 3 For JME 4 S
1 bit
1,001

247 Central up/down For JME 4 S
1 bit
1,008

248 Central safety rain For JMG 4 T
1 bit
1,002

249 Central safety frost For JMG 4 T
1 bit
1,002

250 Version of bus coupling unit transmit
14 byte
16,001

251 Version of basic module transmit
14 byte
16,001

252 Version of 1st extension module transmit
14 byte
16,001

253 Version of 2nd extension module transmit
14 byte
16,001

C
R
W
T
Updated: Apr-15 (Subject to changes) Page 12 of 50

MIX 2 series RMG 4 U / RME 4 U actuators
5.2.3 Description of objects
•Object 0 "Switch object, threshold as percent, threshold 0..255, threshold EIS 5
(DPT 9.xxx), threshold 0..65535 "
This object activates the set channel function (see parameter: Channel function).
The set channel function can either be activated via 1-bit telegram or by exceeding a threshold (8- or
16-bit telegram).
Table 6:
Parameter
Activation of channel function
via
Activation of function via
Type of threshold object
Switch object
1-bit telegram
Exceeding the threshold
Object type: Percent (DPT
5.001)
Exceeding percentage value
Object type: Counter value
0..255 (DPT 5.010)
Any value in given numerical
range
Object type: Counter value
0..65535 (DPT 7.001)
Object type: EIS5 e.g. CO2,
brightness (DPT 9.xxx)
2 byte floating-point number
•Object 1 "Logic input in AND gate, in OR gate, in XOR gate"
Only available if Link is activated (Configuration options parameter page).
Forms a logical link together with object 0 to activate the channel function.
•Object 2 "Block"
Locks the channel function.
Responses to setting and cancelling the block can be configured if the block function has been
activated (Configuration options parameter page).
Updated: Apr-15 (Subject to changes) Page 13 of 50

MIX 2 series RMG 4 U / RME 4 U actuators
•Object 3 "Call up/save scene"
Only available if the scene function has been activated (Configuration options parameter page).
This object can be used to save and subsequently call up scenes.
Saving stores the channel status.
It does not matter how this status is produced (whether via switch commands, central objects or the
buttons on the device).
The saved status is restored when it is called up.
All scene numbers from 1 to 64 are supported.
Each channel can participate in up to 8 scenes.
See appendix: Scenes
•Object 4 "Block scenes = 1, Enable scenes = 1"
Locks the scene function with a 1 or a 0 depending on the configuration.
As long as it is blocked, scenes cannot be saved or called up.
•Object 5 "On/Off feedback"
Reports the current channel status.
The status can also be fed back inverted depending on configuration.
•Object 6 "Time to next service, operating hours feedback "
Only available if the hour counter function
has been activated (Configuration options parameter page).
Reports, depending on selected Type of hour counter (Hour counter and service parameter page),
either the remaining period to the next service or the current status of the hour counter.
•Object 7 "Service required"
Only available if the hour counter function has been activated (Configuration options parameter page)
and Type of hour counter = Counter for time to next service.
Reports if the next service is due.
0 = not due
1 = service is due.
Updated: Apr-15 (Subject to changes) Page 14 of 50

MIX 2 series RMG 4 U / RME 4 U actuators
•Object 8 "Switching with priority, reset service, reset operating hours"
The function of the object depends on whether or not the hour counter function has been activated
(Configuration options parameter page).
Activate hour counter
Function Use
yes
Reset service*
Reset service interval counter.
Reset operating hours*
Reset hour counter
no Switching with priority
Priority control:
Status of
object 8
Channel status
0as set by
object 0
1
2
OFF
3
ON
* Depending on configuration.
•Objects 78, 158, 238 "Manual"
Only available for devices in the MIX2 series (order number 493…)
Puts the relevant module in manual mode or sends the status of the manual operation.
Telegram
Meaning
Explanation
0
Auto
All channels can be operated via the bus as well as via the buttons.
1Manual
The channels can only be operated via the buttons on the device. Bus
telegrams will not work.
The duration of the manual mode, i.e. the Function of the manual button can be configured on the
General parameter page.
Updated: Apr-15 (Subject to changes) Page 15 of 50

MIX 2 series RMG 4 U / RME 4 U actuators
•Object 240 "Central permanent ON"
Central switch-on function.
Enables simultaneous switch on of all channels (basic and extension modules) with a single telegram.
0 = No function
1 = Permanent ON
Participation in this object can be set individually for each channel (Configuration options parameter
page).
IMPORTANT:
This object takes top priority.
As long as it is set, the other switch commands will not work on the participating channels.
Works on the following devices:
RMG 4 U / RME 4 U, RMG 4 I / RME 4 I, RMG 8 S / RME 8 S, RMG 8 T / RME 8 T,
RME 4 S / C-load, DMG 2 T, DME 2 S/T, SME 2 S.
•Object 241 "Central permanent OFF"
Central switch-off function.
Enables simultaneous switch off of all channels (basic and extension modules) with a single telegram.
0 = No function
1 = Permanent OFF
Participation in this object can be set individually for each channel (Configuration options parameter
page).
IMPORTANT: This object has the second highest priority after Central permanent ON. As long as it
is set, the other switch commands will not work on the participating channels.
Works on the following devices:
RMG 4 U / RME 4 U, RMG 4 I / RME 4 I, RMG 8 S / RME 8 S, RMG 8 T / RME 8 T,
RME 4 S / C-load, DMG 2 T, DME 2 S/T, SME 2 S.
Updated: Apr-15 (Subject to changes) Page 16 of 50

MIX 2 series RMG 4 U / RME 4 U actuators
•Object 242 "Central switching"
Central switch function.
Enables simultaneous switch on or off of all channels (basic and extension modules) with a single
telegram.
0 = OFF
1 = ON
Participation in this object can be set individually for each channel (Configuration options parameter
page).
With this object, every participating channel responds exactly as if its 1st object
(i.e. obj. 0, 10, 20, etc.) were receiving a switch command.
Works on the following devices:
RMG 4 U / RME 4 U, RMG 4 I / RME 4 I, RMG 8 S / RME 8 S, RMG 8 T / RME 8 T,
RME 4 S / C-load, DMG 2 T, DME 2 S/T, SME 2 S.
•Object 243 "Call up/save central scenes"
Central object for using scenes.
This object can be used to save and subsequently call up "scenes".
Works on the following devices:
RMG 4 I / RME 4 I, RMG 4 U / RME 4 U, RMG 8 S / RME 8 S, RMG 8 T / RME 8 T, DMG 2 T /
DME 2 T, JMG 4 T / JME 4 T, RME 4 S / C-load, DME 2 S, SME 2 S, JME 4 S
See appendix: Scenes
•Objects 244 - 249
Not used.
Updated: Apr-15 (Subject to changes) Page 17 of 50

MIX 2 series RMG 4 U / RME 4 U actuators
•Object 250 "Version of bus coupling unit"
For diagnostic purposes only.
Sends the bus coupling unit software version after reset or download.
Can also be read out via the ETS.
Format: Axx Hyy Vzzz
Code
Meaning
xx
00 .. FF = Version of application without dividing point (17 = V1.7, 18 = V1.8 etc).
yy
Hardware version 00..99
zzz
Firmware version 000..999
EXAMPLE: A18 H25 V025
- ETS application version 1.8
- Hardware version $25
- Firmware version $25
•Object 251 "Version of basic module"
For diagnostic purposes only.
Only for basic modules in the MIX2 series (order number 493…).
Sends the software version (firmware) of the basic module after reset or download.
Can also be read out via the ETS.
The version is issued as an ASCII character string.
Format: Mxx Hyy Vzzz
Code
Meaning
xx
01 .. FF = Module code (hexadecimal).
yy
Hardware version 00..99
zzz
Firmware version 000..999
EXAMPLE: M18 H25 V025
- Module $18 = RMG 4 U
- Hardware version V25
- Firmware version V25
Updated: Apr-15 (Subject to changes) Page 18 of 50

MIX 2 series RMG 4 U / RME 4 U actuators
Possible module codes (as of 03/2015)
Module
Code
Module or mains voltage are unavailable.
$00
RMG 8 S
$11
RMG 4 I
$12
DMG 2 T
$13
JMG 4 T/JMG 4 T 24V
$14
HMG 6 T
$15
RMG 8 T
$17
RMG 4 U
$18
BMG 6 T
$92
•Object 252 "Version of 1st extension module"
Telegram format: See above, object 251
Possible module codes (as of 03/2015)
Module
Code
Module or mains voltage are unavailable.
$00
RME 8 S
$11
RME 4 I
$12
DME 2 T
$13
JME 4 T/JME 4 T 24V
$14
HME 6 T
$15
RME 8 T
$17
RME 4 U
$18
BME 6 T
$92
•Object 253 "Version of 2nd extension module"
See above, object 252
Updated: Apr-15 (Subject to changes) Page 19 of 50

MIX 2 series RMG 4 U / RME 4 U actuators
5.3 Parameter
5.3.1 Parameter pages
Table 7
Function
Description
General
Selection of modules and central parameters.
BASIC MODULE:
RMG 4 U
General parameters for the basic module: Collective feedback and relay
switch delay.
RMG 4 U channel Cx
configuration options
Characteristics of channel and activation of additional functions (scenes,
links, etc.).
Contact characteristics
Type of contact and status after download, bus failure etc.
Threshold
Settings for triggering channel function through exceeding threshold.
Block function
Type of block telegram and response to blocking.
Scenarios
Selection of scene numbers relevant to the channel.
Feedback
Status of feedback object etc.
Hour counter and
service
Type of hour counter and, if required, service interval etc.
Link
Selection of logical link.
Updated: Apr-15 (Subject to changes) Page 20 of 50
