Thermalright AXP-200 Muscle User manual

Thermalright
AXP-200

× 4
× 7
× 5
× 1
× 1 × 1
× 1
× 1 4
4
4
8
× 4
× 5
× 5
× 1
× 4
× 5
× 4
AXP-200
Assembly Package

AXP-200
1
Intel 775/115x/1366
Exploded View
Important! Before proceeding with installation, please check for the most
up-to-date instructions at www.thermalright.com
Heatsink Body
Screw Nut
Metal Back Plate
Intel Washer (small)
M3 L10 Screw
Anchoring Mount
M3 L6 Screw
TY-14013 Fan
M3 L17 Screw
Mounting Plate

2
The Ultimate Cooling Solutions!
www.thermalright.com
Component
1
1
2
2
3
3
4
4
5
5
6
6
7 8
8
9
109
10
15 16 17
11 12
15
12
1413
7
11
Heatsink Body ×1
Screw Nut ×4
M3 L10 Screw ×5
TY-14013 Fan×1
M3 L4
Screw ×5
1413
16 17
M3 L17 Screw ×5 M3 L30 Screw ×5
Intel Washer (small) ×4
Mounting Plate ×1
Metal Back Plate ×1
LGA2011 Type B
Screw Pillars x4
AMD Washer (big) ×4
Enhanced Fan Mount ×1
Anchoring Mount ×1
M3 L6 Screw ×7
Back Plate Cap ×1
Chill Factor III ×1

3
Installation Instructions:
Step 1:
Step 2:
Step 4:
Step 3:
Step 1 : Backplate Installation
Choose the platform (775/115x/1366)you are in use. Make four M3L10 Screws go through the
Metal Back Plate from bottom towards top.And then place the Metal Back Plate on the table.
Put the four Washers (for Intel) around the Screw Cylinders.
Step 2 : Back Plate Cap
Note: When installing on a 775 platform, please
rst insert the Back Plate Cap into the opening on
the Back Plate. Make sure you have the Cap facing
downwards. (Only for 775).
Step 3 : Place the motherboard on top of the Back
Plate. See the four Screw Cylinders go through
the four holes around the processor socket.Cap
the four Screw Cylinders with the four Screw Nuts.
Make sure the side with a washer is facing the
Back Plate.
1366
775 1156
1155
Step 5:
Step 4 : Place the Anchoring Mount on the Screw
Nuts. Use the four M3L6 Screws to x
the Anchoring Mount on to the Screw Nuts.
Step 5 : Applying Thermal Paste
Apply the Chill Factor III to the base of the
Heatsink and the surface of the CPU evenly.

4
The Ultimate Cooling Solutions!
www.thermalright.com
Step 6:
Step 7:
Step 8:
Step 7 : Fan Installation
Place the included TY-14013 Fan onto the Heatsink Body. And then secure it by scewing on the four
M3L17 Screws, though the fan’s mounting hole.
Step 6 : Mounting Plate Installation.
Place the Heatsink Body on top of the CPU. Make the Mounting Plate go through the Heatsink Body.
Then use the two M3L6 screws to secure the Mounting Plate. (Screwdrive goes through holes on ns)
Step 8 : Installation Completed
Plug in the fan connector to the CPU PWM Fan socket on the motherboard. Installation complete.

AXP-200
5
Important! Before proceeding with installation, please check for the most
up-to-date instructions at www.thermalright.com
Heatsink Body
LGA 2011
Type B Screw Pillars
Mounting Plate
Anchoring Mount
Intel 2011
M3 L6 Screw
TY-14013 Fan
M3 L17 Screw
Exploded View

6
The Ultimate Cooling Solutions!
www.thermalright.com
Component
1
1
2
2
3
3
4
4
5
5
6
6
7 8
8
9
109
10
15 16 17
11 12
15
12
1413
7
11
Heatsink Body ×1
Screw Nut ×4
M3 L10 Screw ×5
TY-14013 Fan×1
M3 L4
Screw ×5
1413
16 17
M3 L17 Screw ×5 M3 L30 Screw ×5
Intel Washer (small) ×4
Mounting Plate ×1
Metal Back Plate ×1
LGA2011 Type B
Screw Pillars x4
AMD Washer (big) ×4
Enhanced Fan Mount ×1
Anchoring Mount ×1
M3 L6 Screw ×7
Back Plate Cap ×1
Chill Factor III ×1

7
Installation Instructions:
Step 1:
Step 2:
Step 3:
Step 1 : Screw Pillar Installation
Screw on the four LGA2011 Type B Screw Pillars into the Heatsink studs on the ILM Assembly Frame
around the processor socket.
Step 2 : Anchoring Mount Installation
Place the Anchoring Mount onto the four LGA2011 Type B Screw Pillars, secure it by tightening it with 4
M3L6 Screws.
Step 3 : Applying Thermal Paste
Apply the Chill Factor III to the base of the Heatsink and the surface of the CPU evenly.

AXP-200
8
The Ultimate Cooling Solutions!
www.thermalright.com
Step 5:
Step 4:
Step 5 : Fan Installation
Place the included TY-14013 Fan onto the Heatsink Body. And then secure it by scewing on the four
M3L17 Screws, though the fan’s mounting hole.
Step 6 : Installation Completed
Plug in the fan connector to the CPU PWM Fan socket on the motherboard. Installation complete.
Step 6:
Step 4 : Mounting Plate Installation.
Place the Heatsink Body on top of the CPU. Make the Mounting Plate go through the Heatsink Body.
Then use the two M3L6 screws to secure the Mounting Plate. (Screwdrive goes through holes on
ns)

AXP-200
9
AM2/AM2+/AM3/AM3+/FM1/FM2
Important! Before proceeding with installation, please check for the most
up-to-date instructions at www.thermalright.com
Heatsink Body
Screw Nut
Mounting Plate
Back Plate Cap
Metal Back Plate
AMD Washer (big)
M3 L10 Screw
Anchoring Mount
M3 L6 Screw
TY-14013 Fan
M3 L17 Screw
Exploded View

10
The Ultimate Cooling Solutions!
www.thermalright.com
Component
1
1
2
2
3
3
4
4
5
5
6
6
7 8
8
9
109
10
15 16 17
11 12
15
12
1413
7
11
Heatsink Body ×1
Screw Nut ×4
M3 L10 Screw ×5
TY-14013 Fan×1
M3 L4
Screw ×5
1413
16 17
M3 L17 Screw ×5 M3 L30 Screw ×5
Intel Washer (small) ×4
Mounting Plate ×1
Metal Back Plate ×1
LGA2011 Type B
Screw Pillars x4
AMD Washer (big) ×4
Enhanced Fan Mount ×1
Anchoring Mount ×1
M3 L6 Screw ×7
Back Plate Cap ×1
Chill Factor III ×1

11
Installation Instructions:
Step 1:
Step 2: Step 3:
Step 1 : Back Plate Installation
Choose the platform (AMD) you are in use. Make four M3L10 Screws go through the Metal Back Plate
from bottom towards top. And then place the Metal Back Plate on the table. Put the four Washers (for
AMD) around the Screw Cylinders.
Step3 : Place the motherboard on top of the Back
Plate. See the four Screw Cylinders go through
the four holes around the processor socket.Cap
the four Screw Cylinders with the four Screw Nuts.
Make sure the side with a washer is facing the
Back Plate.
AMD
Step 4: Step 5:
Step 4 : Anchoring Mount Installation
Place the Anchoring Mount on the Screw Nuts.
Use the four M3L6 Screws to x the Anchoring
Mount on to the Screw Nuts.
Step 5 : Applying Thermal Paste
Apply the Chill Factor III to the base of the
Heatsink and the surface of the CPU evenly.
Step 2 : Back Plate Cap
When installing on a AMD platform, please rst
insert the Back Plate Cap into the opening on the
Back plate. Make sure you have the Cap facing
downwards.

12
The Ultimate Cooling Solutions!
www.thermalright.com
Step 6:
Step 7:
Step 8:
Step 7 : Fan Installation
Place the included TY-14013 Fan onto the Heatsink Body. And then secure it by scewing on the four
M3L17 Screws, though the fan’s mounting hole.
Step 8 : Installation Completed
Plug in the fan connector to the CPU PWM Fan socket on the motherboard. Installation complete.
Step 6 : Mounting Plate Installation.
Place the Heatsink Body on top of the CPU. Make the Mounting Plate go through the Heatsink Body.
Then use the two M3L6 screws to secure the Mounting Plate. (Screwdrive goes through holes on ns)

AXP-200
13
Intel 775/115x/1366
Explosionszeichnung
Wichtig! Bitte prüfen Sie vor der Montage ob für Ihren Kühler aktualisierte
Montagehinweise auf der Webseite www.thermalright.com verfügbar sind.
Kühlkörper
Rändelschraube
Multi Plattform Backplate
Intel Unterlegscheibe
(klein)
M3 L10 Schraube
Montagerahmen
M3 L6 Schraube
TY-14013 Lüfter
M3 L17 Schraube

14
The Ultimate Cooling Solutions!
www.thermalright.com
Komponenten
1 2 3
4 5 6
7 8 9
10 11 12
15
Kühlkörper ×1
Rändelschraube ×4
M3 L10 Schraube ×5
TY-14013 Lüfter ×1
M3 L4 Schraube
×5
1413
16 17
M3 L17 Schraube ×5 M3 L30 Schraube×5
Intel Unterlegscheibe
(klein) ×4
Befestigungsplatte ×1
Multi Plattform
Backplate ×1
Verbesserte
Lüftermontage×1
LGA2011 Type B
Adapterschraube x4
AMD Unterlegscheibe
(groß) ×4
Chill Factro III
Wärmeleitpaste ×1
Montagerahmen ×1
M3 L6 Schraube ×7
Backplateeinsatz ×1
1 2 3
4 5 6
8109
15 16 17
12
1413
7
11

15
Installationsanleitung:
Achten Sie auf die für die entsprechenden Intel Sockel (775/115x/1366) vorgesehene
Bohrungen in der Multi Plattform Backplate. Führen Sie die vier M3L10 Schrauben jeweils von unten
durch diese Bohrungen und legen dann die Backplate auf den Tisch. Legen Sie die vier Unterlegscheiben
(für Intel) über die hervorstehenden Gewinde
Beachten Sie:
Bei Verwendung einer Intel Sockel 775 Plattform
setzen Sie zuerst den Backplateeinsatz in die
quadratische Öffnung der Backplate ein. Gehen
Sie sicher, dass der Aufsatz nach unten zeigt.
Platzieren Sie das Mainboard von oben auf die
Backplate, so dass die hervorstehenden
Schraubengewinde durch die Löcher um den
Prozessorsockel gehen. Schrauben Sie die
beiliegenden Rändelschrauben auf die vier
Schraubengewinde. Achten Sie dabei darauf, dass
die Seite mit der Unterlegscheibe zur Backplate
zeigt.
Setzen Sie den Montagerahmen auf die
Rändelschrauben. Verwenden Sie die vier
M3L6 Schrauben, um den Montagerahmen
auf den Rändelschrauben zu befestigen.
Step 1:
Step 2:
Step 4:
Step 3:
1366
775 1156
1155
Step 5:
Tragen Sie eine hauchdünne Schicht Chill Factro
III Wärmeleitpaste auf der Oberäche der CPU und
auf der Unterseite des Kühlers auf.

16
The Ultimate Cooling Solutions!
www.thermalright.com
Legen Sie den mitgelieferten TY-14013 Lüfter auf den Kühlkörper. Führen Sie die vier M3L17
Schrauben durch die Montagelöcher des Lüfters und drehen diese dann vorsichtig fest.
Platzieren Sie den Kühlkörper auf der CPU. Führen Sie die Befestigungsplatte durch den Kühlkörper.
Dann verwenden Sie die zwei M3L6 Schrauben, um die Befestigungsplatte zu xieren.
Verbinden Sie den Lüfterstecker mit dem CPU PWM Lüfteranschluss auf dem Mainboard.
Die Installation ist nun abgeschlossen.
Step 6:
Step 7:
Step 8:

AXP-200
17
Wichtig! Bitte prüfen Sie vor der Montage, ob für Ihren Kühler aktualisierte
Montagehinweise auf der Webseite www.thermalright.com verfügbar sind.
Kühlkörper
LGA2011 Type B
Adapterschraube
Befestigungsplatte
Montagerahmen
Intel 2011
M3 L6 Schraube
TY-14013 Lüfter
M3 L17 Schraube
Explosionszeichnung
