Thermalright AXP-100 User manual

Thermalright
AXP-100

× 4
× 7
× 5
× 1
× 1 × 1
× 1
× 1 4
4
4
8
× 4
× 5
× 5
× 1
× 4
× 5
× 4
AXP-100
Assembly package

AXP-100
1
Intel 775/1155/1156/1366
Exploded view
Important! Before proceeding with installation, please check for the most
up-to-date instructions at www.thermalright.com
Heatsink Body
Screw Nut
Backplate cap
Metal Back Plate
Intel Washer(small)
M3 L10 Screw
Anchoring Mount
M3 L6 Screw
120mm Fan

2
The Ultimate Cooling Solutions!
www.thermalright.com
Component
1
1
2
2
3
3
4
4
5
5
6
6
7 8
8
9
109
10
15 16 17
11 12
15
12
1413
7
11
Heatsink Body ×1
Screw Nut ×4
M3 L10 Screw ×5
TY100 Fan×1
W3 L4
Screw ×5
1413
16 17
Thermal paste ×1
M3 L17 Screw ×5 M3 L30 Screw ×5
AMD Washer (big) ×4
Mounting Plate ×1
Metal Back Plate ×1
LGA2011 Type B
Screw Pillars x4
AMD Washer (big) ×4
Anchoring Mount ×1
Anchoring Mount ×1
M3 L6 Screw ×7
Backplate cap ×1

3
Installation Instructions:
Step 1:
Step 2:
Step 4:
Step 3:
Step 1 : Backplate Installation
Choose the platform (775/1155/1156/1366)you are in use. Make four M3L10 Screws go through the
Metal Back Plate from bottom towards top.And then place the Metal Back Plate on the table.
Put the four Washers (for Intel) around the Screw Cylinders.
Step 2 : backplate cap
Note: When installing on a 775 platform, please
rst insert the Back Plate Cap into the opening on
the Back plate. Make sure you have the Cap facing
downwards. (Only for 775).
Step 3 : Place the motherboard on top of the Back
Plate. See the four Screw Cylinders go through
the four holes around the processor socket.Cap
the four Screw Cylinders with the four Screw Nuts.
Make sure the side with a washer is facing the
Back Plate.
1366
775
1156
1155
Step 5:
Step 4 : Place the Anchoring Mount on the Screw
Nuts. Use the four M3L6 Screws to x
the Anchoring Mount on to the Screw Nuts.
Step 5 : Applying Thermal Paste
Apply the Thermal Paste to the base of the
Heatsink and the surface of the CPU evenly.

4
The Ultimate Cooling Solutions!
www.thermalright.com
Step 6:
Step 7:
Step 8:
Step 7 : Fan Installation
Place the included TY-100 onto the Heatsink Body. And then secure it by scewing on the four M3L17
Screws, though the fan’s mounting hole.
Step 6 : Mounting Plate Installation.
Place the Heatsink Body on top of the CPU. Make the Mounting Plate go through the Heatsink Body.
Then use the two M3L6 screws to secure the Mounting Plate.
Step 8 : Installation completed
Plug in the fan connector to the CPU PWM Fan socket on the motherboard. Installation complete.

AXP-100
5
Exploded view
Important! Before proceeding with installation, please check for the most
up-to-date instructions at www.thermalright.com
Heatsink Body
Screw Nut
Mounting Plate
Anchoring Mount
M3 L6 Screw
120mm Fan
Intel 2011

6
The Ultimate Cooling Solutions!
www.thermalright.com
Component
1
1
2
2
3
3
4
4
5
5
6
6
7 8
8
9
9
10
14 15 16
11 12
15
11
13
12
7
10
Heatsink Body ×1
LGA2011 Type B Screw Pillars x4
M3 L6 Screw ×7
W3 L4
Screw ×5 M3 L17 Screw ×5
1413
16
TY100 Fan×1
M3 L30 Screw ×5
AMD Washer (big) ×4
Mounting Plate ×1
Metal Back Plate ×1
M3 L10 Screw ×5
Backplate cap ×1
Anchoring Mount ×1
Screw Nut ×4
Intel Washer (small) ×4
Thermal paste ×1

7
Installation Instructions:
Step 1:
Step 2:
Step 3:
Step 1 : Screw Pillar Installation
Screw on the four LGA2011 Type B Screw Pillars into the Heatsink studs on the ILM Assembly Frame
around the processor socket.
Step 2 : Anchoring Mount Installation
Place the Anchoring Mount onto the four LGA2011 Type B Screw Pillars, secure it by tightening it with 4
M3L6 Screws.
Step 3 : Applying Thermal Paste
Apply the Thermal Paste to the base of the Heatsink and the surface of the CPU evenly.

AXP-100
8
The Ultimate Cooling Solutions!
www.thermalright.com
Step 5:
Step 4:
Step 5 : Fan Installation
Place the included TY-100 onto the Heatsink Body. And then secure it by scewing on the four M3L17
Screws, though the fan’s mounting hole.
Step 6 : Installation completed
Plug in the fan connector to the CPU PWM Fan socket on the motherboard. Installation complete.
Step 6:
Step 4 : Mounting Plate Installation.
Place the Heatsink Body on top of the CPU. Make the Mounting Plate go through the Heatsink Body.
Then use the two M3L6 screws to secure the Mounting Plate.

AXP-100
9
AM2/AM2+/AM3/AM3+/FM1/FM2
Exploded view
Important! Before proceeding with installation, please check for the most
up-to-date instructions at www.thermalright.com
Heatsink Body
Screw Nut
Mounting Plate
Backplate cap
Metal Back Plate
AMD Washer(big)
M3 L10 Screw
Anchoring Mount
M3 L6 Screw
120mm Fan

10
The Ultimate Cooling Solutions!
www.thermalright.com
Component
1
1
2
2
3
3
4
4
5
5
6
6
7 8
8
9
9
10
14 15 16
11 12
15
11
13
12
7
10
Heatsink Body ×1
LGA2011 Type B Screw Pillars x4
M3 L6 Screw ×7
W3 L4
Screw ×5 M3 L17 Screw ×5
1413
16
TY100 Fan×1
M3 L30 Screw ×5
AMD Washer (big) ×4
Mounting Plate ×1
Metal Back Plate ×1
M3 L10 Screw ×5
Backplate cap ×1
Anchoring Mount ×1
Screw Nut ×4
Intel Washer (small) ×4
Thermal paste ×1

11
Installation Instructions:
Step 1:
Step 2: Step 3:
Step 1 : Backplate Installation
Choose the platform (AMD) you are in use. Make four M3L10 Screws go through the Metal Back Plate
from bottom towards top. And then place the Metal Back Plate on the table. Put the four Washers (for
AMD) around the Screw Cylinders.
Step 2 : backplate cap
Note: When installing on a 939 platform, please
rst insert the Back Plate Cap into the opening on
the Back plate. Make sure you have the Cap facing
downwards. (Only for 939).
Step3 : Place the motherboard on top of the Back
Plate. See the four Screw Cylinders go through
the four holes around the processor socket.Cap
the four Screw Cylinders with the four Screw Nuts.
Make sure the side with a washer is facing the
Back Plate.
AMD
Step 4: Step 5:
Step 4 : Anchoring Mount Installation
Place the Anchoring Mount on the Screw Nuts.
Use the four M3L6 Screws to x the Anchoring
Mount on to the Screw Nuts.
Step 5 : Applying Thermal Paste
Apply the Thermal Paste to the base of the
Heatsink and the surface of the CPU evenly.

12
The Ultimate Cooling Solutions!
www.thermalright.com
Step 6:
Step 7:
Step 8:
Step 7 : Fan Installation
Place the included TY-100 onto the Heatsink Body. And then secure it by scewing on the four M3L17
Screws, though the fan’s mounting hole.
Step 8 : Installation completed
Plug in the fan connector to the CPU PWM Fan socket on the motherboard. Installation complete.
Step 6 : Mounting Plate Installation.
Place the Heatsink Body on top of the CPU. Make the Mounting Plate go through the Heatsink Body.
Then use the two M3L6 screws to secure the Mounting Plate.

AXP-100
13
Technical Spec
Heatsink Specifications:
Dimension: Length 105.47mm x Width 121.1mm x Height 44.15mm
Weight: 360g (including fan and mounting brackets)
Heatpipe: 6mm heatpipe*6 units
Copper Base: C1100 Pure copper nickel plated
