Thermo Scientific Smart-Vue User manual

Thermo Scientific
Smart-Vue
'U\&RQWDFW
Installation *XLGH
316266H0January 2011

© 2011 Thermo Fisher Scientific Inc. All rights reserved.
Disclaimer and limitation of liability
Thermo Fisher Scientific assumes no responsibility for any loss or claims by third parties which may arise
through the use of this manual and the information contained herein. This document is non-contractual and
subject to change without notice.
Thermo Fisher Scientific’s liability is subject to its standard terms and conditions of sale.
Do not open the product casing and do not disassemble or modify internal components in any manner
whatsoever. Thermo Scientific products do not contain any internal components that require user intervention
or repair. If the product or device shows signs of improper operation, disconnect it immediately from its power
source and contact Thermo Scientific technical services so that the device can be examined under proper
conditions.
Release history:
Initial release January 2011

Table of Contents
Thermo Fisher Scientific Smart-Vue Dry Contact Module Installation Guide iii
Table of Contents
Notices .....................................................................................1
Safety instructions....................................................................1
Battery warning........................................................................1
FCC statement.........................................................................1
Conformity with European regulations ....................................2
WEEE compliance...................................................................2
Environmental protection ........................................................2
RoHS compliance ....................................................................2
Introduction .............................................................................3
Package contents ......................................................................3
Product overview......................................................................3
Main features ...........................................................................3
What is a Smart-Vue wireless end-point module? .....................4
Typical installation...................................................................5
Requirements and recommendations ........................................6
General requirements and recommendations............................6
Where to find more information...............................................7
Installation procedure ...............................................................7
Getting started .........................................................................7
Placing your Smart-Vue module for best performance .............7
Recommended order for installing end-point modules.............8
Preparing mounting kit with a magnet (optional) ....................9
Activating the end-point module (automatic wireless setup)...10
Software configuration............................................................12
Testing the connection...........................................................12
Basic end-point module configuration....................................13
Additional configuration ........................................................16
Appendix ................................................................................18
Troubleshooting ....................................................................18
Specifications .........................................................................19
Contact information ...............................................................20
Warranty statement ................................................................21

Notices
Thermo Fisher Scientific Smart-Vue Dry Contact Module Installation Guide 1
Notices
Safety instructions IMPORTANT NOTE: Do not use this product for protection or as part of
an automated emergency system or as for any other application that involves
protecting people and/or property. Customers and users of Thermo
Scientific products are responsible for making sure that the product is fit for
the intended usage. Do not open the product casing and do not disassemble
or modify internal components in any manner. Thermo Scientific products
do not contain any internal components that require user intervention or
repair. If the device shows signs of improper operation, disconnect it
immediately from its power source and contact Thermo Fisher Scientific
technical services.
Battery warning This product contains a lithium battery. Make sure you respect polarity (+/-)
when inserting batteries into Thermo Scientific devices. Reversing polarity
by inserting the batteries incorrectly can cause the product to heat up, and
may lead to a battery liquid leak. Use only batteries recommended by
Thermo Fisher Scientific. Do not change battery types, such as alkaline and
magnesium, or use batteries of different brands, or even different types of
batteries of the same brand. Incorrect batteries may cause the device to heat
up, and may result in a fire or battery liquid leakage. Never dispose of
batteries in fire. Do not charge regular batteries that are not specifically
rechargeable. When batteries are low, or in case the battery-operated device
in question remains unused for a lengthy period of time, remove the
batteries from the device in order to avoid any risk of battery liquid leakage.
Never leave batteries within the reach of children. In case of a battery leak,
avoid all contact with the liquid present on the batteries. Rinse with clear
water immediately in case the battery liquid comes into contact with the
eyes, mouth or skin. Contact a doctor or emergency service immediately.
Battery liquid is corrosive and can damage vision, or cause blindness or
chemical burns.
FCC statement This paragraph pertains to 915 MHz Smart-Vue™ wireless end-point
modules. This device complies with part 15 of the FCC rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation: FCC
Part 15 §107 - §109 - §207 - §247 (Ed 2008).

Notices
2 Smart-Vue Dry Contact Module Installation Guide Thermo Fisher Scientific
Conformity with
European regulations This paragraph pertains to 868 MHz Smart-Vue wireless end-point
modules. The CE mark on this product indicates that Thermo Fisher
Scientific declares that this product is compliant with Radio equipment and
Telecommunications Terminal equipment (R&TTE) directive 1999/5/EC
and the Low Voltage Directive (LVD) 2006/95/EC. The following
standards were utilized to meet the essential requirements of these directives:
EN 301 489-3 v1.4.1 (02), EN 300 220-2 V2.1.2 (R&TTE) & EN
60950-1:2006/A11:2009 (LVD).
The most current EC Declaration of Conformity may be downloaded from
the Smart-Vue World Wide Web at www.thermoscientific.com/smart-vue
Caution: Any changes or modifications not expressly approved by Thermo
Fisher Scientific could void the user's authority to operate the equipment.
WEEE compliance This wireless device complies with the essential requirements and other
relevant provisions of the Waste Electrical and Electronic Equipment
Directive 2002/96/EC (WEEE Directive).
Environmental
protection Please respect local regulations concerning disposal of packaging, unused
wireless devices and their accessories, and promote their recycling.
RoHS compliance The wireless device is in compliance with the restriction of the use of certain
hazardous substances in electrical and electronic equipment Directive
2002/95/EC
(RoHS Directive). Do not dispose of this product with household trash.
Thermo Fisher Scientific recycles this product under certain conditions.
Please contact us for more information.

Introduction
Thermo Fisher Scientific Smart-Vue Dry Contact Module Installation Guide 3
Introduction Congratulations and thank you for choosing the Thermo Scientific
Smart-Vue wireless monitoring end-point module. This manual covers
Smart-Vue end-point modules for use with dry contact devices.
This guide describes how to get your new Smart-Vue end-point module up
and running quickly. Detailed configuration instructions and software
settings are provided in the complete Thermo Scientific Smart-Vue Software
User Manual provided with your product.
Package contents • Smart-Vue wireless monitoring end-point module with battery – 3.6V
Lithium, 3600 mA (p/n SVU503-500-LSB) and attached 2-wire cable
to connect to the dry contact sensor
• Smart-Vue mounting kit with plastic holder, magnet, screws, cable ties
and plastic cable holders and Velcro®
• Documentation CD-ROM
Product overview The Smart-Vue dry contact wireless end-point module can be connected to
any industry-standard device with a dry contact output. Dry contact devices
do not generate any power. The Smart-Vue end-point module emits a low
current to detect whether the switch on the other device is open or closed.
Typical devices that provide a dry contact output include alarm units, door
open/close sensors, and switches. The Smart-Vue end-point module can be
configured to detect either a “normally closed” or “normally open” state to
correspond with the device to monitor. The Smart-Vue end-point module
indicates open or closed in large characters on its LCD display.
Main features • Configurable data logging, wireless transmission and alerts
• Automatic wireless set-up
• Wireless range indoors: 25-100 meters (82-328 ft); up to 400 meters
(1,312 ft) with 3 repeaters
• Operating temperature range for wireless end-point module: 0°C to
+50°C

What is a Smart-Vue wireless end-point module?
4 Smart-Vue Dry Contact Module Installation Guide Thermo Fisher Scientific
What is a Smart-Vue
wireless end-point
module?
Smart-Vue wireless end-point modules connect to remote devices (e.g.,
sensors) to monitor their status, transmitting information wirelessly to a
central database managed by Thermo Scientific Smart-Vue Server software.
Alerts can be sent automatically in case these readings indicate specific alarm
conditions configured in the software.
Figure 1. Smart-Vue wireless dry contact end-point module with 2-wire
cable
LCD display with
contact state, signal
and battery indicators
Push button
2-wire cable for
dry contact device

What is a Smart-Vue wireless end-point module?
Thermo Fisher Scientific Smart-Vue Dry Contact Module Installation Guide 5
Typical installation Smart-Vue end-point modules transmit remote readings and alerts to a PC
running Thermo Scientific Smart-Vue Server/Smart-Vue Client software
equipped with a wireless receiver. The receiver may also be located remotely
from the PC on a TCP/IP receiver installed directly on an Ethernet
network. Repeaters may be used when the wireless range between the
receiver and the Smart-Vue end-point module is too great to achieve a
strong signal. The diagram below shows these basic configurations:
Figure 2. Typical Smart-Vue wireless configurations
NOTE: Be sure to configure each end-point module (and repeater, if
applicable) to connect to one receiver only, as shown above in Figure 1. Any
given end-point module can only be read by one receiver.
Smart-Vue end-point modules for dry contact monitoring are generally
installed in a convenient location at room temperature.

Requirements and recommendations
6 Smart-Vue Dry Contact Module Installation Guide Thermo Fisher Scientific
Requirements and
recommendations For the purposes of this installation guide we assume that:
• Smart-Vue Server/Smart-Vue Client software is installed and configured
on your computer, and you have appropriate access rights to configure
devices.
• A Smart-Vue receiver is installed and functioning on your computer or
network.
General requirements
and recommendations • The personal computer (PC) running Smart-Vue Server software runs
continuously, 24/7/365, and should be connected to an Uninterruptible
Power Supply (UPS) that protects against power surges and provides
power to back up the PC and components.
• The AC adapter used for your serial receiver (if applicable) should also
be plugged into the UPS.
• The UPS is also recommended as a power backup for your
communication/network systems.
• Weekly manual system testing (e.g., temporarily remove a sensor to
verify the communications system is working) should be performed as
defined in your Standard Operating Procedure (SOP).
• Recommended maintenance and calibration procedures should be
followed.
• If you are storing cold products, Thermo Fisher Scientific recommends
use of a back-up cooling system (e.g., CO2or LN2) to maintain freezer
chamber temperature below the critical level should a power failure
occur. Contact your local sales representative for more information.
• Thermo Fisher Scientific recommends Installation and Operational
Qualifications (IQ/OQ) be performed before initial use.
• For timely notification of an emergency/alarm, it is critical to establish
primary, secondary and tertiary call-out procedures with escalation so
contact is not dependent on reaching one individual. Ideally, ultimate
contact is with a security department or company with 24/7
monitoring.
• End-point modules with internal sensors should not be placed in
cold-rooms.
• Please see the relevant product manuals for details on installing
Smart-Vue receivers and Smart-Vue Server/Smart-Vue Client software.

Where to find more information
Thermo Fisher Scientific Smart-Vue Dry Contact Module Installation Guide 7
Where to find more
information This guide leads you through basic installation steps to get you started with
your product. For more details, please see the Thermo Scientific Smart-Vue
Software User Manual. You may click on Help ==> User manual to open it
directly from within the Smart-Vue Client software.
Installation
procedure The procedure described here assumes that Smart-Vue Server/Smart-Vue
Client software is installed on your computer, and that your Thermo
Scientific wireless receiver is configured and ready to use.
Getting started Wiring the Smart-Vue end-point module to a dry contact device
Connect the 2-wire cable extending from the Smart-Vue end-point module
to the appropriate output on the device where you are measuring the
open/closed status.
For dry contact devices, it is important to establish whether they are
configured for “normally open” (status is considered normal if the contact is
detected as “open”) or “normally closed” (status is considered normal if the
contact is detected as “closed”).
When working with “normally open” devices, the Smart-Vue tests emit a
small charge to test the current loop. If the loop is open, the device’s status is
considered normal. If the loop is closed, an alarm is sent. However, an alarm
will not be sent if the cable between the Smart-Vue end-point module and
the device is cut, as the loop will still be open just as for a “normally open”
condition and the cut cable will not be detected. When working with a
device configured for “normally closed”, the Smart-Vue end-point module
will send an alarm if the cable is cut.
Placing your Smart-Vue
end-point module for
best performance
For optimal operation, follow these recommendations when physically
placing your device:
• Do not place the end-point module within 40 cm (16 inches) of another
module.
• Make sure the wireless end-point module is not placed on an electrical
conduit or cable tray (such as for computer network cables).
• For best results, place the end-point module so that it faces the general
direction of the receiver antenna.
• Keep about 20 cm (8 inches) of clear space around the end-point
module. A module that is “stuck” between two refrigerators may not
communicate effectively.

Installation procedure
8 Smart-Vue Dry Contact Module Installation Guide Thermo Fisher Scientific
• Refer to the Appendix on page 18 for additional considerations.
When routing the cable for any Smart-Vue sensor, avoid direct contact with
or close proximity placement of the sensor cabling with any high voltage
wiring. Cabling should be placed with no less than a minimum of 5 cm (2
inches) distance from high voltage components. Also, avoid running the
sensor cable in parallel with high voltage wiring.
For all other manufacturers’ equipment, contact the manufacturer of the
instrument for instructions regarding proper placement of the sensor.
Recommended order for
installing end-point
modules
In addition to placing your Smart-Vue end-point module as described above
for best wireless performance, you may also optimize overall network
performance by proceeding with installation as follows:
1. Examine the general layout of your site to determine the placement
of your Smart-Vue end-point modules. The extent of your
pre-installation site survey depends on the number of end-point
modules to install. Feel free to contact your sales representative for
more information on this topic.
2. Place all end-point modules in their final locations before running
wireless setup (described on page 10).
Begin activation by pressing on the end-point module’s button for 3 seconds
(long-press), starting with the end-point modules closest to your receiver,
working your way “out” in concentric circles. This enables each Smart-Vue
end-point module to establish the optimal connection to your receiver.
Figure 3. Start installation with end-point modules closest to your
receiver and work your way “out” in concentric circles

Installation procedure
Thermo Fisher Scientific Smart-Vue Dry Contact Module Installation Guide 9
Preparing mounting kit
with a magnet (optional) Your Smart-Vue end-point module includes a plastic holder so you can
mount the device easily on various surfaces. In addition to the provided
screws, you will also find a magnetic pad with adhesive backing that you can
use to adhere the holder to metal surfaces easily.
1. Clean the back of the holder with a mild cleanser or alcohol.
2. Remove the protection from the adhesive pad on the magnet and
place the magnet on the back of the holder
3. Place the holder and magnet down on a flat surface and press down
strongly for 30 seconds to firmly attach the magnet.

Installation procedure
10 Smart-Vue Dry Contact Module Installation Guide Thermo Fisher Scientific
Activating the end-point
module (automatic
wireless setup)
The Smart-Vue dry contact monitor is a standalone device that runs on
battery power. To activate your Smart-Vue end-point module and add it
automatically to your wireless monitoring network, do the following:
1. Insert the provided battery, if not already installed, making sure to
respect the polarity (see image printed inside battery slot). We
recommend that you use a manual screwdriver, being careful not to
over-tighten the screws.
Figure 4. Remove the back cover and insert backup battery
2. To begin collecting data on the state of your contact right away,
make sure that Smart-Vue Client is running with a properly
configured receiver, and then initiate the wireless configuration
sequence by pressing the button on the front of the end-point
module for 3 seconds (until “Searching” displays on the screen).
This installation method is designed for networks with up to about 15
end-point modules. For larger sites, please see the Thermo Scientific
Smart-Vue Software User Manual for setup instructions or check with an
experienced technician.

Installation procedure
Thermo Fisher Scientific Smart-Vue Dry Contact Module Installation Guide 11
If a receiver or repeater is within wireless range, the Smart-Vue end-point
module automatically establishes the wireless connection, as shown in the
sequence of screen shots below:



Figure 5. Smart-Vue end-point module automatic wireless setup
sequence
The end-point module begins data-logging upon startup even if it does not
connect to the wireless system. Once the end-point module does connect to
the system, as shown in Figure 5, we recommend that you avoid performing
a long-press again, which consumes battery life for no reason.
Refreshing the end-point module display with a short press
You may refresh the Smart-Vue display with the latest sensor readings by
performing a short press on the end-point module’s push-button. Press the
button briefly to update and view the current reading.

Software configuration
12 Smart-Vue Dry Contact Module Installation Guide Thermo Fisher Scientific
Software
configuration When activating your Smart-Vue end-point module as described in the
previous section, the device adds itself to your current Smart-Vue
Server/Smart-Vue Client configuration.
Testing the connection Checking wireless signal strength
You may use Smart-Vue Client to test the wireless signal strength as
described here, entering your login name and password when prompted by
the software.
1. Launch Smart-Vue Client on your computer and enter your login
name and password to continue.
2. Select Settings ==> Sensor settings or press F11.
3. Click on Add/Update an end-point module.
4. Select your receiver in the pick-list (“local” in Figure 6), and then
select the wireless module from the sensor list on the left.
Figure 6. Configuration with the Smart-Vue dry contact end-point
module on receiver “local”
5. Click on Power to test the connection. You may also click on
Initialize and Current sensor measurement, and Synchronize
end-point module clock to confirm proper operation. Click on
Close to exit the screen.

Software configuration
Thermo Fisher Scientific Smart-Vue Dry Contact Module Installation Guide 13
If this test does not show a wireless signal, please refer to the Thermo
Scientfic Smart-Vue Software User Manual for instructions on adding
end-point modules into the system manually.
Basic end-point module
configuration Smart-Vue end-point modules offer a variety of data-logging, alert and
transmission options. This section describes the basic settings to get started
right away. Please see the complete Thermo Scientific Smart-Vue Software
User Manual for more details.
Moving the Smart-Vue end-point module into a group
1. Launch Smart-Vue Client on your computer and enter your login
name and password to continue. The new Smart-Vue end-point
module should be listed as shown here, where “local” refers to the
receiver and “SDP-local” refers to a generic group for new
un-configured end-point modules connected to that receiver.
Figure 7. Example with new dry contact end-point module in the
generic “SDP” group
2. Press F11 or select Settings ==> Sensor settings ( ), and log in>
when prompted.
3. You may choose to click on Modify Sensor Name to assign replace
the numeric end-point module address with a user-friendly name
(e.g., Dry Contact 1).
The name on the end-point module's LCD is refreshed every 24 hours
(maximum) to preserve battery life. Thus, name changes may not be shown
immediately, but they are taken into account in the software.

Software configuration
14 Smart-Vue Dry Contact Module Installation Guide Thermo Fisher Scientific
4. Create an active group by clicking on the receiver name (“local” in
this example) to Create group, and then enter the group name
(“Lab_1” in this example). Click on OK to continue.
5. Drag the new sensor from the “SDP-local” group to the group you
just created:
Figure 8. Move sensor from the generic “SDP” group to your active
group
6. Click on Close ==> Yes ==> OK to update the end-point module,
save this change, and return to the tree structure, as shown below:
Figure 9. Dry contact sensor in the ““Lab_1” group

Software configuration
Thermo Fisher Scientific Smart-Vue Dry Contact Module Installation Guide 15
Testing the end-point module by running an on-demand read or status
update
You may confirm end-to-end operation by launching an on-demand read
from Smart-Vue Client.
1. Click on the sensor in the tree structure (“Dry Contact 1” in our
example).
2. Click on the latest reading (rectangle next to the top-most field in
the image below) to read the sensor wirelessly and update the
display.
Figure 10. Run an on-demand read to confirm end-to-end
communication

Software configuration
16 Smart-Vue Dry Contact Module Installation Guide Thermo Fisher Scientific
Additional configuration Your Smart-Vue end-point module offers many features that are controlled
by your Smart-Vue Server/Smart-Vue Client software. Use the software to
define settings for measurement period, frequency of data transmission,
alarm limits for sending alerts via phone, fax, e-mail and SMS, sensor
calibration/correction parameters, archiving and more. Enter your login
name and password when prompted.
Setting basic sensor parameters
1. Access end-point module settings by pressing F11 or selecting
Setting ==> Sensor settings on the Smart-Vue Client main screen.
Figure 11. Main sensor settings screen for dry contact end-point module
2. Choose a sensor in the left-hand panel (tree structure), and adjust
the specific settings (Sensor Settings tab). You should do this for all
sensors in your system.
Note that the Unit field contains “State”. This indicates that the
Smart-Vue end-point module in question is indeed a module for
measuring binary open/closed states on a dry contact device.
We recommend setting both the data transfer and the measurement
intervals to 1 minute so you are notified as quickly as possible if the
monitored device has changed from its normal state.A warning triangle is
shown in the Smart-Vue display if the end-point module’s current status is
in not “normal” (i.e., closed instead of open, or open instead of closed).

Software configuration
Thermo Fisher Scientific Smart-Vue Dry Contact Module Installation Guide 17
Setting alarms for open / closed status change
Set your end-point module for “normally open” or “normally closed” as
described here:
1. In the Settings screen (F11), click on the Alarm settings tab.
2. Click on either Alarm on closing, if an alarm should be sent if the
dry contact closes or Alarm on opening, if an alarm should be sent if
the dry contact opens.
Figure 12. F11 ==> Alarm settings tab for dry contact end-point
module
3. Set the delay to wait before an alarm is sent.
4. Click on Close ==>Yes ==> OK to save your settings.
Please see the Thermo Scientific Smart-Vue Software User Manual for more
details on these and other important features. Click on Help ==> User
Manual ( ) to open the PDF file directly.
