Thermo Scientific LevelPRO Series User manual

Part of Thermo Fisher Scientific
LevelPRO
Continuous Gamma Level System
Installation Guide
P/N 717760
Revision H

LevelPRO
Continuous Gamma Level System
Installation Guide
P/N 717760
Revision H

© 2011 Thermo Fisher Scientific Inc. All rights reserved.
“HART” is a registered trademark of the HART Communication Foundation.
“FOUNDATION fieldbus” and “Fieldbus Foundation” are registered trademarks of Fieldbus
Foundation.
“National Instruments” is a registered trademark of National Instruments Corporation.
All other trademarks are the property of Thermo Fisher Scientific Inc. and its subsidiaries.
Thermo Fisher Scientific Inc. (Thermo Fisher) makes every effort to ensure the accuracy and completeness of this
manual. However, we cannot be responsible for errors, omissions, or any loss of data as the result of errors or
omissions. Thermo Fisher reserves the right to make changes to the manual or improvements to the product at
any time without notice.
The material in this manual is proprietary and cannot be reproduced in any form without expressed written
consent from Thermo Fisher.

This page intentionally left blank.

Thermo Fisher Scientific LevelPRO Installation Guide v
Revision History
Revision Level Date Comments
1.0 03-1999 Initial release.
2.0 08-2001 Revised per ECO 7570.
A 02-2006 Revised per ECO 5101.
B 10-2007 Revised per ECO 6000.
C 08-2008 Revised per ECO 6540.
D 06-2009 Revised per ECO 6940.
E 04-2010 Revised per ECO 7323.
F 07-2010 Revised per ECO 7430.
G 09-2010 Revised per ECO 7508.
H 12-2011 Revised per ECO 7875.

This page intentionally left blank.

Thermo Fisher Scientific LevelPRO Installation Guide vii
Contents
Safety Information & Guidelines ..................................................................... ix
Safety Considerations.............................................................................ix
Warnings, Cautions, & Notes................................................................ix
Product Overview ............................................................................................. 1-1
Required Documentation.................................................................... 1-1
Handling & Storage .......................................................................................... 2-1
ESD Procedures .................................................................................. 2-1
Unpacking, Inspection, & Storage ...................................................... 2-2
Packing, Shipping, Transporting, & Receiving.................................... 2-2
Hardware Installation...................................................................................... 3-1
Licensing............................................................................................. 3-1
Source-Detector Configurations.......................................................... 3-2
Guidelines........................................................................................... 3-2
General ............................................................................................ 3-3
System Power Requirements ............................................................ 3-3
Protective Earth Grounding ............................................................. 3-3
Safety Disconnecting Means Requirements ...................................... 3-4
Detector-Transmitter .......................................................................... 3-4
Alignment ........................................................................................ 3-5
Measurable Range ............................................................................ 3-6
Top of Range ................................................................................ 3-6
Bottom of Range........................................................................... 3-6
The Source Housing ........................................................................... 3-9
Fan Beam Source Guidelines............................................................ 3-9
Strip Source Guidelines.................................................................. 3-10
Shutter Actuator............................................................................. 3-10
Multiple Detectors / Source Housings............................................... 3-11
Wiring.................................................................................................................. 4-1
Overview............................................................................................. 4-1
Preparation.......................................................................................... 4-1
Wiring Drawings ............................................................................. 4-2
General Procedure............................................................................... 4-2
The CPU Board.................................................................................. 4-3
System Configuration ...................................................................... 4-4
Chapter 1
Chapter 2
Chapter 3
Chapter 4

Contents
viii LevelPRO Installation Guide Thermo Fisher Scientific
Power Supply ...................................................................................... 4-5
DC Power........................................................................................ 4-5
Optional AC Power ......................................................................... 4-6
Relays............................................................................................ 4-6
Serial Communications ....................................................................... 4-7
RS485 Wiring.................................................................................. 4-7
Initial Setup for Party-Line Communications................................ 4-7
RS232 Wiring.................................................................................. 4-8
Using Serial Communications.......................................................... 4-8
HART Communications..................................................................... 4-8
FOUNDATION Fieldbus Communications ........................................... 4-9
Contact Closure Inputs ....................................................................... 4-9
Current Output .................................................................................. 4-9
Isolated, Loop Powered Configuration........................................... 4-10
Non-Isolated, Self-Powered Configuration..................................... 4-10
Isolated, Self-Powered Configuration ............................................. 4-10
Cascade Mode Wiring....................................................................... 4-11
Auxiliary Input Wiring...................................................................... 4-11
Service & Support .............................................................................................5-1
Getting Help....................................................................................... 5-1
Warranty............................................................................................. 5-2
Ordering Information .......................................................................................A-1
Specifications...................................................................................................B-1
Drawings............................................................................................................ C-1
Replacing the CPU PROM & HART PROM...................................................D-1
Purpose .............................................................................................. D-1
Procedure........................................................................................... D-1
CE-EMC Protection Installation Procedure ................................................ E-1
Purpose ...............................................................................................E-1
Procedure............................................................................................E-1
Installation ..........................................................................................E-3
AC Power Supply Replacement...........................................................E-5
Wiring ................................................................................................E-6
Related Technical Bulletins ...........................................................................F-1
Index ..........................................................................................................INDEX-1
Chapter 5
Appendix A
Appendix B
Appendix C
Appendix D
Appendix E
Appendix F

Thermo Fisher Scientific LevelPRO Installation Guide ix
Safety Information & Guidelines
This section contains information that must be read and understood by all
persons installing, using, or maintaining this equipment.
Failure to follow appropriate safety procedures or inappropriate use of the
equipment described in this manual can lead to equipment damage or
injury to personnel.
Any person working with or on the equipment described in this manual is
required to evaluate all functions and operations for potential safety hazards
before commencing work. Appropriate precautions must be taken as
necessary to prevent potential damage to equipment or injury to personnel.
The information in this manual is designed to aid personnel to correctly
and safely install, operate, and / or maintain the system described; however,
personnel are still responsible for considering all actions and procedures for
potential hazards or conditions that may not have been anticipated in the
written procedures. If a procedure cannot be performed safely, it must not
be performed until appropriate actions can be taken to ensure the safety
of the equipment and personnel. The procedures in this manual are not
designed to replace or supersede required or common sense safety practices.
All safety warnings listed in any documentation applicable to equipment
and parts used in or with the system described in this manual must be read
and understood prior to working on or with any part of the system.
Failure to correctly perform the instructions and procedures in this
manual or other documents pertaining to this system can result in
equipment malfunction, equipment damage, and / or injury to personnel.
Warnings, cautions, and notes are used throughout this manual to alert
users to potential hazards or important information. Failure to heed the
warnings and cautions in this manual can lead to injury or equipment
damage.
Warning Warnings notify users of procedures, practices, conditions, etc.
which may result in injury or death if not carefully observed or followed.
The triangular icon displayed with a warning varies depending on the type
of hazard (general, electrical, radiation). 
Safety
Considerations
Warnings,
Cautions, &
Notes

Safety Information & Guidelines
Warnings, Cautions, & Notes
xLevelPRO Installation Guide Thermo Fisher Scientific
Caution Cautions notify users of operating procedures, practices,
conditions, etc. which may result in equipment damage if not carefully
observed or followed. 
Note Notes emphasize important or essential information or a statement of
company policy regarding an operating procedure, practice, condition,
etc. 

Thermo Fisher Scientific LevelPRO Installation Guide 1-1
Chapter 1
Product Overview
Refer to the LevelPRO user guide for descriptions of instrument functions
and features.
In addition to this guide, the following documents must be read and
understood by all persons installing, using, or maintaining this equipment:
LevelPRO user guide, p/n 717778
LevelPRO HART operation guide, p/n 717817 (if using HART)
Model 9734 HHT user guide, p/n 717797 (if using the HHT)
Gamma Radiation Safety Guide, p/n 717904
LevelPRO with FOUNDATION™ Fieldbus Application Guide, p/n
717915 (if FOUNDATION fieldbus option is installed)
Required
Documentation

This page intentionally left blank.

Thermo Fisher Scientific LevelPRO Installation Guide 2-1
Chapter 2
Handling & Storage
This chapter addresses procedures for handling electrostatic discharge
(ESD) sensitive equipment, as well as procedures for unpacking, inspecting,
and storing of the system.
Caution This system is an ESD sensitive instrument. Use proper ESD
protective equipment and procedures. Failure to comply with ESD
procedures can result in circuit damage. 
The instrument contains electronic components that can be damaged from
discharges of static electricity: Do not touch the circuit board components.
Ordinarily, handling the circuit boards by their edges will not damage the
circuits.
Observe the following when installing, setting up, servicing,
troubleshooting, or repairing the instrument:
1. Use an antistatic bag. Most instrument subassemblies are shipped in a
special antistatic bag. When not installed, keep the assembly in the bag
as often as possible.
2. Remove ESD sensitive subassemblies only under the following
conditions:
a. When at a designated static-free workstation or when the bag is
grounded at a field site.
b. After the conductive area of the container has been neutralized.
c. After making firm contact with an antistatic mat and / or firmly
gripping a grounded individual.
3. Personnel handling ESD sensitive devices should be neutralized to a
static-free workstation by means of a grounding wrist strap that is
connected to the station or to a good grounding point at the field site.
4. Do not allow clothing to make contact with ESD sensitive devices.
ESD Procedures

Handling & Storage
Unpacking, Inspection, & Storage
2-2 LevelPRO Installation Guide Thermo Fisher Scientific
5. Avoid touching edge connectors and components.
6. Avoid partially connecting ESD sensitive devices. These devices,
especially the power supply connector, can be damaged by floating
leads.
7. Ground test equipment.
8. Avoid static charges during troubleshooting.
Note Inspection, adjustment, installation, and maintenance of the
instrument must be performed by experienced personnel only. 
1. Upon receipt, inspect the instrument for damage that may have
occurred while in transit. If there is evidence of rough handling or
damage, file a damage claim with the transportation company
immediately. Notify Thermo Fisher Scientific and / or your sales
representative as soon as possible.
2. Carefully inspect the packing material prior to discarding it to ensure
that all equipment and instruction paperwork has been removed.
3. Use the original packing material and container for storage if necessary.
4. If storing the instrument, the storage environment should be protected,
free from extremes of temperatures and high humidity, and fall within
the environmental constraints listed in the specifications.
All personnel involved in the packing, shipping, or receiving of hazardous
material must be trained in accordance with the United States Department
of Transportation (DOT) and OSHA hazardous materials regulations or in
accordance with the Canadian Nuclear Safety Commission (CNSC)
regulations.
Unpacking,
Inspection, & Storage
Packing, Shipping,
Transporting, &
Receiving

Thermo Fisher Scientific LevelPRO Installation Guide 3-1
Chapter 3
Hardware Installation
Read the Gamma Radiation Safety Guide (p/n 717904) PRIOR TO
installing the equipment.
Note Copies of the drawings referenced in this manual are provided in
Appendix C. 
For detector-transmitter housing layout details, refer to drawing 868502.
For mounting dimensions, refer to drawing 868672 or 868674 for water-
cooled units.
A variety of source housings are used with the scintillation detector
depending on the requirements of the application. Refer to the appropriate
drawing for your source.
Warning The instrument is a nuclear device regulated by federal and / or
state authorities. You are responsible for knowing and following the
pertinent safety and regulatory requirements. Refer to the Gamma
Radiation Safety Guide (p/n 717904) for a summary of these
requirements. 
Warning Moving or removing an installed source housing or any assembly
that includes a source housing requires a person who is specifically licensed
to install and commission Thermo Scientific source housings. 
In the United States, your general license permits you to own and install all
of the instrument’s components, including the source housing. However,
you may not commission the instrument (remove the lock and open the
source housing shutter for the first time) without a specific license
authorizing radiation commissioning of the instrument. In Canada, you are
only allowed to remove the instrument from the shipping container if your
CNSC license has a condition authorizing mounting / dismounting of
devices. For assistance obtaining a license and / or commissioning /
decommissioning the instrument, contact Thermo Fisher Scientific.
Licensing

Hardware Installation
Source-Detector Configurations
3-2 LevelPRO Installation Guide Thermo Fisher Scientific
The gauge is comprised of a source housing that contains the radioisotope
source and the detector-transmitter that contains the scintillation detector
and electronics. Sources are available in a fan beam or strip source
configuration. For most fan beams, the beam angle spreads at a 45° angle in
the vertical dimensions. A 30° beam angle spread is available with model
5210, and 60° beam angle spreads are available with models 5205B,
5206B, 5207B, and 5208B.
Strips sources emit radiation evenly along the length of the vessel from the
source and measure the radiation level reaching the detector after passing
through the vessel walls and the process material.
The scintillation detector is available in lengths ranging from 1 to 12 feet,
in 2-foot increments. For a tall or narrow tank, multiple sources and / or
detectors might be required. Contact Thermo Fisher. The specific source -
detector configuration depends on the application. Three possible
configurations are illustrated below.
Figure 3–1.
Warning Do not install the system in any hazardous area other than those
approved. Refer to the equipment tag for the specific approvals applicable
to the configuration of your instrument. 
Warning Do not apply power to the instrument in any hazardous area
unless the safety ground is properly wired inside the instrument and the
cover is properly installed. 
Instrument approvals are listed in Appendix B.
Source-Detector
Configurations
Guidelines

Hardware Installation
Guidelines
Thermo Fisher Scientific LevelPRO Installation Guide 3-3
Review the following guidelines when planning gauge installation:
1. Correct power source is available. See “Power Requirements” later in
this chapter.
2. You will need to supply the necessary brackets and hardware required
for mounting the gauge to the vessel.
3. Operating temperature range: -40°C to +60°C (-40°F to +140°F).
4. There should be enough clearance to install and service the source
housing and the detector. Refer to the appropriate dimensional
drawings in the drawing appendix.
5. Position the source housing so the radioactive source identification tag
is visible. Mount it so the tag is upright.
6. The gauge should not be mounted where process overflow or other
material can collect in the beam path. The source housing shutter
mechanism must be kept free of debris.
7. If the handheld terminal will be used for configuration, the connection
must be located in a safe area.
Ensure the correct power source is available. One of the following input
power sources is required: 24 Vdc ± 20% or 115/230 Vac ± 15%, 50/60
Hz (requires optional AC power board). The maximum power requirement
is 12 VA. Both DC and AC power may be supplied to the gauge at the
same time. The gauge will draw power from whichever input source
provides the higher DC source voltage.
The LevelPRO enclosure provides internal safety ground and external
safety ground lugs (reference drawing 868503) for Safety Protective Earth
Grounding. The external safety ground lug is used to connect the unit to
Earth Ground. The internal safety ground lug is used to connect the AC
power input ground line.
General
System
Power
Requirements
Protective Earth
Grounding

Hardware Installation
Detector-Transmitter
3-4 LevelPRO Installation Guide Thermo Fisher Scientific
As a permanently connected equipment, the LevelPRO gauge requires a
switch or circuit breaker as the means for disconnection. The customer
needs to prepare the switch or circuit breaker according to the following
requirements:
1. A switch or circuit breaker must be included in the building
installation.
2. It must be in close proximity to the equipment (LevelPRO) and within
easy reach of the operator.
3. It must be marked as the disconnecting device for this equipment
(LevelPRO).
Warning Do not install the system in any hazardous area other than those
approved. Refer to the equipment tag for the specific approvals applicable
to the configuration of your instrument. 
Warning Do not apply power to the instrument in any hazardous area
unless the safety ground is properly wired inside the instrument and the
cover is properly installed. 
Warning For hazardous location installations, the cable entries must be
sealed per the installation layout drawing (868502). 
Warning For non-hazardous location installations, the enclosure cable
entries must be sealed with a compound to protect against the passage of
gas or vapors. The sealing compound should not be affected by the
surrounding atmosphere or liquids. The sealing compound must have a
thickness of at least 5/8 inch (16 mm). 
Warning Use proper lifting procedures during installation to avoid injury.
Refer to drawings 868672 or 868674 (water-cooled units) for weights and
dimensions of the detector housing. 
Safety
Disconnecting
Means
Requirements
Detector-Transmitter
