Thermo Scientific Odalog L2 Series User manual

OdaLog® L2 – Gas Logger User Manual
Odalog L2 Series
User Manual
ODA10-1000 January 2024

OdaLog® L2 – Gas Logger User Manual
P/N: 10-1000 Revision G, January 2024 Page | i
Gas Logger
COPYRIGHT© 2024
The sole purpose of this document is to assist in the operaon of the OdaLog® portable gas logger.
We do not convey any right to use this informaon for any purpose other than in the operaon or
maintenance of the OdaLog® portable gas logger.
OdaStat™ & OdaStat-G™ © Soware Copyright 2024 (Thermo Fisher Scienc Pty Ltd).
GENERAL DISCLAIMER
This Manual summarises our knowledge of the OdaLog® portable gas logger, including how to use it based
on the informaon available at the me. You should read this Manual carefully and consider the
informaon in the context of how the instrument will be used.
The OdaLog® portable gas logger is sold subject to our standard terms and condions of sale and any
wrien warranty given by Thermo Fisher. Thermo Fisher does not accept any other liability, either directly
or indirectly, for any losses suered in connecon with the use and applicaon of the OdaLog® portable
gas logger, whether or not in accordance with any advice, specicaon, recommendaon, or informaon
given by it or as a result of any errors or omissions in this manual.

OdaLog® L2 – Gas Logger User Manual
P/N: 10-1000 Revision G, January 2024 Page | ii
Revision History
Revision
Date
Descripon
A
29th September 2008
Inial version
B
6th May 2010
Update the contents
C
7th October 2014
Inclusion of cercate as the content to Rev B
D
Update the contents
E
Update to include the Bluetooth circuit
F
16th July 2020
Inclusion of cercate as the content to Rev E
G
19th January 2024
Update the design and contents, and remove obsolete
models.

OdaLog® L2 – Gas Logger User Manual
P/N: 10-1000 Revision G, January 2024 Page | iii
Table of Contents
Revision History............................................................................................................................................. ii
List of Figure.................................................................................................................................................. v
List of Table .................................................................................................................................................. vi
1. CERTIFICATION / CONFORMITY.............................................................................................................1
1.1. Cercaon & Performance Conformity ....................................................................................1
1.2. Condions of Safe Use ................................................................................................................1
1.3. Electromagnec compability (EMC) – Compliance Statement.................................................1
1.4. FCC Statement.............................................................................................................................1
1.5. Quality Statement.......................................................................................................................2
2. WARNINGS AND CAUTIONS..................................................................................................................3
3. DESCRIPTION.........................................................................................................................................4
4. GENERAL SPECIFICATIONS.....................................................................................................................6
5. QUICK OPERATIONAL GUIDE.................................................................................................................7
5.1. Switch On....................................................................................................................................7
5.2. LCD Layout Overview ..................................................................................................................7
5.3. Null (zero)....................................................................................................................................8
5.4. Pre-Use Span Check ....................................................................................................................8
5.5. Start Logging (*Manual Logging seng only).............................................................................8
5.6. Stop Logging (*Manual Logging seng only) .............................................................................8
5.7. Post-Use Span Check...................................................................................................................8
5.8. Download Data............................................................................................................................8
5.9. Switch O....................................................................................................................................8
5.10. Training........................................................................................................................................8
6. OPERATION............................................................................................................................................9
6.1. Operaon Overview....................................................................................................................9
6.2. Switching On .............................................................................................................................10
6.3. "CLOCK not SEt" Message.........................................................................................................10
6.4. Displaying STATUS on the LCD...................................................................................................11
6.5. Start Logging Funcon (*Manual Logging Mode only, [Default = Enabled]) ............................11
6.6. Stop Logging Funcon (*Manual Logging Mode only, [Default = Enabled]).............................12
6.7. Auto Log Start Funcon [Default = Disabled]............................................................................12
6.8. IrDA (Infra-Red Data Communicaon Mode)............................................................................12
6.8.1. Enter "IrDA" mode (Infra-Red Data Communicaon Mode)...............................................12
6.8.2. Exit "IrDA" mode (Infra-Red Data Communicaon Mode) .................................................12

OdaLog® L2 – Gas Logger User Manual
P/N: 10-1000 Revision G, January 2024 Page | iv
6.8.3. Precauons are required when using OdaLog® I.R communicaon...................................12
6.8.4. Steps to ensure reliable I.R communicaon. ......................................................................13
6.8.5. Communicaons Set-up......................................................................................................13
6.9. Switching o..............................................................................................................................14
6.10. Clear Logged Data .....................................................................................................................15
6.11. Low Baery Indicaon & Control..............................................................................................15
6.12. Key Lock (Default = Disabled)....................................................................................................16
6.13. Negave Suppress Funcon (Default = Enabled)......................................................................17
7. SENSOR OPERATION............................................................................................................................18
7.1. Sensor Cross-Sensivity ............................................................................................................18
7.2. Eects of Environmental Changes on OdaLog® Sensors...........................................................18
7.2.1. Temperature........................................................................................................................18
7.2.2. Humidity..............................................................................................................................18
7.2.3. Pressure...............................................................................................................................19
7.3. Long-Term Exposure to High Gas Levels ...................................................................................19
8. MAINTENANCE....................................................................................................................................20
8.1. Filter Replacement....................................................................................................................20
8.2. Service.......................................................................................................................................21
9. CALIBRATING THE OdaLog®.................................................................................................................22
9.1. Preparaon for Calibraon .......................................................................................................22
9.2. Adsorpon of Calibraon Mixture............................................................................................22
9.3. Tools and Test Equipment .........................................................................................................23
9.4. Calibraon Mixture Applicaon Times & Rates ........................................................................24
9.5. NULL (Fresh Air Zero) ................................................................................................................24
9.6. SPAN..........................................................................................................................................25
9.7. Calibraon Errors ......................................................................................................................26
9.8. Span Gas Check – Pre-Use and Post-Use (if required) ..............................................................27
9.8.1. Span Gas Check – Pre-Use...................................................................................................27
9.8.2. Span Gas Check – Post-Use .................................................................................................27
9.8.3. Decay Compensaon ..........................................................................................................28
10. OPTIONAL ACCESSORIES AND SPARES ............................................................................................30
10.1. Accessories................................................................................................................................30
10.2. Spare Parts ................................................................................................................................30
11. WARRANTY......................................................................................................................................31
11.1. Warranty ...................................................................................................................................31

OdaLog® L2 – Gas Logger User Manual
P/N: 10-1000 Revision G, January 2024 Page | v
11.2. What the warranty does not cover. ..........................................................................................31
11.3. What Thermo Fisher will do......................................................................................................31
11.4. Limitaons.................................................................................................................................31
11.5. Validity.......................................................................................................................................31
12. Patents, Trademarks, and Registered Designs ................................................................................32
13. Appendix A - GLOSSARY OF TERMS AND ABBREVIATIONS..............................................................33
List of Figure
Figure 1: Odalog L2 .......................................................................................................................................4
Figure 2: Features of Odalog L2 ....................................................................................................................5
Figure 3: Display during Switch-ON...............................................................................................................7
Figure 4: LCD Layout......................................................................................................................................7
Figure 5: Odalog L2 Menu Map.....................................................................................................................9
Figure 6: Clock not SEt ................................................................................................................................10
Figure 7: Odalog status screen....................................................................................................................11
Figure 8: Start logging process....................................................................................................................11
Figure 9:Setup of IrDA Communicaon ......................................................................................................14
Figure 10: Display during Switching OFF. ....................................................................................................14
Figure 11: Accessing CLEAR LOG .................................................................................................................15
Figure 12: Baery Indicator ........................................................................................................................15
Figure 13: Accessing Key Lock.....................................................................................................................16
Figure 14: Negave Suppress Funcon.......................................................................................................17
Figure 18: Filter Replacement .....................................................................................................................20
Figure 19: Clean (Well Venlated) Air.........................................................................................................22
Figure 20: Calibraon Mixture Connecon.................................................................................................23
Figure 21: Magnec Switch (RMS/LMS, SPAN/ NULL) ................................................................................23
Figure 22: Accessing NULL calibraon. .......................................................................................................24
Figure 23: NULL Calibraon.........................................................................................................................24
Figure 24: Seng Calibraon Gas...............................................................................................................25
Figure 25: Accessing SPAN calibraon. .......................................................................................................25
Figure 26: SPAN Calibraon.........................................................................................................................26
Figure 27: Display of Failed Calibraon.......................................................................................................26
Figure 28: Accessories and Spares ..............................................................................................................30

OdaLog® L2 – Gas Logger User Manual
P/N: 10-1000 Revision G, January 2024 Page | vi
List of Table
Table I: Compliance Informaon...................................................................................................................1
Table II: Compliance Statement ....................................................................................................................1
Table III: General Specicaon......................................................................................................................6
Table IV: Available Gas Sensor Type..............................................................................................................6
Table V: Cross Sensivity of H2S Sensor ......................................................................................................18
Table VI: Flow Rate and Time for Calibraon..............................................................................................24
Table VII: Accessories List............................................................................................................................30
Table VIII: Spare Parts List ...........................................................................................................................30
Table IX: Patent, Design and Trademark......................................................................................................32

OdaLog® L2 – Gas Logger User Manual
P/N: 10-1000 Revision G, January 2024 Page | 1
1. CERTIFICATION / CONFORMITY
1.1. Cercaon & Performance Conformity
The following Authories have granted intrinsic safety approval to the OdaLog® Logger (Type L2):
Table I: Compliance Informaon
Authority
Cercate Number
Code
ITACS
IECEx ITA 08.0010X
Ex ia IIC T4 Ga (-20°C≤Ta≤50°C) IP66/68
NEMKO
Nemko 08ATEX1270
II 2 G, Ex ia IIC T4 IP66/68
1.2. Condions of Safe Use
FOR SAFETY REASONS, THIS EQUIPMENT MUST BE OPERATED AND SERVICED BY QUALIFIED
PERSONNEL ONLY. READ THE INSTRUCTION MANUAL, UNDERSTAND, AND ADHERE TO THE
MANUFACTURER'S LIVE MAINTENANCE PROCEDURES BEFORE OPERATING OR SERVICING.
TO AVOID BUILD-UP OF ELECTROSTATIC CHARGE, THE ODALOG TYPE L2 SHALL BE USED OR PLACED
WHERE IT WILL BE PROTECTED FROM INADVERTENT RUBBING AND SHALL ONLY BE CLEANED OR
WIPED WITH A DAMP CLOTH WHEN USED IN EXPLOSIVE ATMOSPHERES CLASSIFIED AS GROUP IIC.
THE JTAG PORT IS NOT MEANT FOR USE BY THE USER.
THE BATTERY SHALL NOT BE REPLACED BY THE USER
1.3. Electromagnec compability (EMC) – Compliance Statement
The OdaLog® Type L2 and accessories comply with the emissions and immunity requirements of:
Table II: Compliance Statement
Standard Number
Title
Compliance
BS EN 502070: 1999
Electrical Magnec Compability – Electrical apparatus for the
detecon and measurement of combusble gases, toxic gases,
or oxygen
Fully
1.4. FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protecon against harmful
interference in a residenal installaon. This equipment generates uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instrucons, may cause harmful interference
to radio communicaons. However, there is no guarantee that interference will not occur in a parcular
installaon.
If this equipment does cause harmful interference to radio or television recepon, which can be
determined by turning the equipment o and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separaon between the equipment and the receiver.
Connect the equipment to an outlet on a circuit dierent from that to which the receiver is
connected.
Consult the dealer or an experienced radio/ TV technician for help.

OdaLog® L2 – Gas Logger User Manual
P/N: 10-1000 Revision G, January 2024 Page | 2
1.5. Quality Statement
Thermo Fisher Scienc Pty Ltd produces this product in accordance with our accredited AS/NZ ISO 9001
and ISO/IEC 80079-34 Quality System.

OdaLog® L2 – Gas Logger User Manual
P/N: 10-1000 Revision G, January 2024 Page | 3
2. WARNINGS AND CAUTIONS
DO NOT USE SOLVENTS TO CLEAN THE ODALOG® GAS LOGGER (A DAMP CLOTH WILL SUFFICE).
DO NOT INSERT OBJECTS (INCLUDING FINGER) INTO THE GAS INLET AS THE FILTER MAY BE
DAMAGED
DO NOT ATTEMPT TO DISASSEMBLE SENSORS, AS THEY ARE POTENTIALLY CORROSIVE.
THE USE OF LITHIUM BATTERIES OTHER THAN THE LITHIUM BATTERIES LISTED IN TABLE II WILL
INVALIDATE THE INTRINSIC SAFETY APPROVAL.
BEFORE EACH DAY'S USE, SENSITIVITY MUST BE TESTED ON A KNOWN CONCENTRATION OF TEST
GAS (TO MATCH THE SENSOR TYPE) EQUIVALENT TO 20…50 PERCENT OF FULL-SCALE
CONCENTRATION. ACCURACY MUST BE WITHIN ±10% OF ACTUAL CONCENTRATION OR ±5% OF
FULL SCALE. ACCURACY MAY BE CORRECTED BY CALIBRATION AS DESCRIBED IN THE "CALIBRATING
THE ODALOG" SECTION.
THE ODALOG® GAS LOGGER IS NOT DESIGNED TO OPERATE AS A SAFETY DEVICE. WHEN ENTERING
CONFINED SPACES AND TOXIC-HAZARD ENVIRONMENTS, ALL APPROPRIATE REGULATIONS AND
OCCUPATIONAL HEALTH AND SAFETY PRECAUTIONS SHOULD BE STRICTLY ADHERED TO. IF
UNSURE OF POTENTIAL HAZARDS OR SAFETY STANDARDS, SEEK ADVICE FROM YOUR WORKPLACE
OCCUPATION HEALTH AND SAFETY DEPARTMENT OR GOVERNMENT REGULATORY BODY.
THE AMBIENT TEMPERATURE RANGE THAT THE APPARATUS IS SUITABLE FOR IS -20°C TO +50°C.
"EX" CERTIFICATION IS VALID ONLY TO 21% VOL OXYGEN. THE ODALOG® GAS LOGGER SHOULD
NOT BE USED IN OXYGEN-ENRICHED ATMOSPHERES.

OdaLog® L2 – Gas Logger User Manual
P/N: 10-1000 Revision G, January 2024 Page | 4
3. DESCRIPTION
The OdaLog® is a compact portable gas data-logger designed by industry-proven manufacturer Thermo
Fisher Scienc – the gas detecon specialists for harsh environments, such as the wastewater industry.
With superior sealing and heavy-duty materials, this instrument is corrosion-resistant, durable, and
reliable.
The new generaon OdaLog® Logger picks up where its respected predecessor le o. With super-low
power consumpon coupled with a long-life lithium cell power source, baery life will exceed 12 months
in most cases, taking "low maintenance" to a whole new level.
New and faster infrared wireless communicaon and magnec switches enable the OdaLog® to be easily
calibrated and congured and download logged data without disassembly.
The extra-large, easy-to-read LCD makes the OdaLog® simple to use and interpret instrument data and
sengs on-site. The instrument's main features can be viewed on-screen, such as gas readings,
temperature, % of memory used, logging mode and me intervals, and a baery level indicator.
OdaLog® interfaces with Thermo Fisher's dedicated, easy-to-use OdaStat-G™ soware package that brings
logged data into the oce environment in a user-friendly format.
WARNING
The OdaLog® Gas Logger is not designed to operate as a safety device. When entering conned
spaces and toxic hazard environments all appropriate regulaons and occupaonal health and
safety precauons should be strictly adhered to. If unsure of potenal hazards or safety standards,
seek advice from your workplace occupaon health and safety department or Government
regulatory body.
The use of Lithium Baeries other than lithium baeries listed in Table II will invalidate the intrinsic
safety approval.
Figure 1: Odalog L2

OdaLog® L2 – Gas Logger User Manual
P/N: 10-1000 Revision G, January 2024 Page | 5
Figure 2: Features of Odalog L2
OdaLog Logger Type L2
New Features
OdaLog Logger Type L2
Proven Features
Simple and eecve assembly
Improved Single Screw Design
Improved baery life
Baery lasts up to 12 months
Easy to read menu
Larger LCD display
Increased Memory
Stores up to 42,000 data points
Faster downloading
Superior IrDA communicaon link
New Sensor Protecon Grill
Protect the lter from damage
Build Strong and easy to install
Stainless steel handle
Waterproof seal
Double O-ring seals
Purpose designed for harsh
wastewater environments
Unique robust design
Single Buon Operaon
User friendly

OdaLog® L2 – Gas Logger User Manual
P/N: 10-1000 Revision G, January 2024 Page | 6
4. GENERAL SPECIFICATIONS
Table III: General Specicaon
Parameters
Range
Instrument Temp Range
-20 °C (-4 °F) … 50 °C (122 °F)
Sensor Temp Range
-10 °C (-14 °F) … 40 °C (104 °F)
Instrument Relave Humidity Range
15 … 90 % non-condensing
Ingress Protecon
IP66/68 (2m/ 24hr)
External Dimensions
Diameter 62 mm (2.44") x Height 196 mm (7.72")
Instrument Weight
420 g (14.8 oz)
Power Supply(s)
C-Size Lithium Baery
Baery Life/ Run Time
Greater than eight months (for life of Lithium baery)
Data Logging Capacity
Up to 42,000 readings in total
Interval
Selectable from 1 second to 1 hour
Data Logging
Capacity > Logging Interval of 1min = 29 days
Duraon Example
Capacity > Logging Interval of 5min = 6+ months
Storage of the OdaLog® instrument, with sensors ed, should be limited to the temperature range of 0°C
(32°F) … +25°C (75°F) and between 20% … 80% RH.
The following is a list of gas types available for the OdaLog® L2:
Table IV: Available Gas Sensor Type
Model
Gas
Range
(ppm)
Resoluon
(ppm)
Accuracy FS1
Accuracy STP2
LL3
Hydrogen Sulde (H2S)
0-1000
1
1%
± 2ppm
LL
Hydrogen Sulde (H2S)
0-200
0.1
1%
SL4
Hydrogen Sulde (H2S)
0-2000
1
2%
SL
Hydrogen Sulde (H2S)
0-1000
1
1%
SL
Hydrogen Sulde (H2S)
0-200
0.1
1%
SL
Hydrogen Sulde (H2S)
0-50
0.1
4%
1
Full scale
2
Standard Temperature and Pressure: 20 °C (68 °F) @ absolute pressure 101.3 kPa (14.7 psi).
3
Long term logger
4
Standard logger

OdaLog® L2 – Gas Logger User Manual
P/N: 10-1000 Revision G, January 2024 Page | 7
5. QUICK OPERATIONAL GUIDE
This secon describes a brief operang procedure for the OdaLog® instrument, covering the basics of all
primary funconality. For more details, refer to the corresponding informaon in Secon 6.
5.1. Switch On
Press & hold the buon down; "ON" will count down ON 3-2-1; release the buon when the "test" screen
appears (all segments visible/black as shown). The unit will progress through "STATUS" screens and then
display the "INST" (Instantaneous reading) screen. (See Secon 6.1)
Figure 3: Display during Switch-ON
5.2. LCD Layout Overview
Figure 4: LCD Layout
1. Lower 7-segment characters – Displays gas readings and status values – usually numerical digits,
some supplemental menu headings, and prompts.
2. Upper 14-segment characters – Displays menu headings, prompts, and other visual feedback –
usually alphabec characters, and some numerical values are displayed on some screens.
3. Baery Level Indicator – Displays the baery levels (4-stage depleon, see Secon 6.11).
4. Communicaons Symbol – Indicates if the instrument is successfully connected and transferring
data (i.e., for downloading logs and changing parameters and sengs in the OdaStat-G™ soware
package).
5. Logging Symbol – This symbol ashing indicates that the instrument is Logging – Note: ashing
interval does not indicate logging interval (See Secon 6.5 for more logging informaon).
6. % - This symbol shows any units or screens that display units as a percentage (e.g., memory usage;
some gas types are displayed as % Volume).
7. Temperature units – displaying the temperature readings on-screen in degrees Cengrade or
Fahrenheit, depending on the seng chosen in the OdaStat-G™ soware package [Default = °C].
8. Gas Reading units – Indicates if gas readings shown are in "parts per million" or "parts per billion"
["ppb" disabled in OdaLog® Logger Type L2 series instruments].

OdaLog® L2 – Gas Logger User Manual
P/N: 10-1000 Revision G, January 2024 Page | 8
5.3. Null (zero)
With the unit in fresh air, press & hold the buon down unl "NULL" is displayed and then release. Move
the magnet over the word "NULL" on the LHS of the LCD screen. "DONE" should appear briey when
completed (see Secon 9.5).
5.4. Pre-Use Span Check
Apply a known level of gas over the sensor (using supplied calibraon ng, [Part No. 11-0001]) at the
ow rate and for the ow me as detailed in Table VII (or unl the reading stabilises) and record "Start
Level" result (see Secon 9.8.1).
5.5. Start Logging (*Manual Logging seng only)
Press and hold the buon down unl "START LOG" is displayed and then release (logging is conrmed by
the LOGGING symbol ashing on the screen and ashing LEDs) (see Secon 6.5).
5.6. Stop Logging (*Manual Logging seng only)
Press and hold the buon down unl "STOP LOG" is displayed and then release (see Secon 6.6).
5.7. Post-Use Span Check
Flow a known level of gas over the sensor (using supplied calibraon ng, [Part No. 11-0001]) at the ow
rate and for the ow me, as detailed in Table VII (or unl the reading stabilises) and record "End Level"
result when reading stabilises (see Secon 9.8.2).
5.8. Download Data
Stop logging as above, press & hold buon down unl "IrDA" is displayed, and then release. Use the Infra-
Red Data Communicaons link [Part No. 12-0002] and follow the OdaStat-G™ soware package
instrucons for communicang with the OdaLog® instrument (refer to Secon 6.8 for more informaon
on communicaon setup and data download).
5.9. Switch O
Press and hold the buon down unl "OFF" is displayed. Connue holding the buon as it counts down
OFF-2-1, then release (see Secon 6.9).
5.10. Training
To locate your nearest Thermo Fisher Scienc training centre please contact us at the address on the back
of this manual or refer to our website.

OdaLog® L2 – Gas Logger User Manual
P/N: 10-1000 Revision G, January 2024 Page | 9
6. OPERATION
6.1. Operaon Overview
Figure 5: Odalog L2 Menu Map
RELEASE AFTER
‘OFF” COUNT
DOWN
NOTE: PRESSING BUTTON DURING AUTO-SCROLL WILL PAUSE AT THE CURRENT SCREEN FOR 5
SEC
NOTE: HOLDING BUTTON DOWN WILL PAUSE AT THE CURRENT SCREEN UNTIL 5 SEC AFTER
BUTTON IS RELEASED
NOTE: IN ‘MANUAL LOGGING’ MODE,
THE LOG MUST BE STOPPED
BEFORE THE INSTRUMENT CAN
BE TURNED INTO ‘IrDA’ OR ‘OFF’
MODES
RELEASE BUTTON ON START/
STOP LOG SCREEN TO ENABLE/
DISABLE LOGGING MODE
AUTO LOGGING
(SET IN SOFTWARE)
MANUAL LOGGING
(SET IN SOFTWARE)
(AUTO RETURN TO ‘INST’ SCREEN)
AUTO SCROLL OF STATUS SCREENS
RELEASE
BUTTON
RELEASE
BUTTON
HOLD BUTTON
HOLD BUTTON
START-UP SCREEN SEQUENCE
(AUTO-LOG ON)
(BLOCK SCREEN)

OdaLog® L2 – Gas Logger User Manual
P/N: 10-1000 Revision G, January 2024 Page | 10
6.2. Switching On
Press and hold the buon for three seconds ("On" will count down from 3), then release. The LCD will
show (in order):
oTest Screen – All segments visible/black.
o"CLOCK…not Set" (See Note 3).
oInstalled OdaLog® Firmware Version.
oDays Since Last Calibrated.
o"STATUS" which displays in order.
o"PEAK" gas level since switch on or log start.
o"CLOCK" (shown in 24-hour me. If the clock is not set (See Secon 6.3), this value may be
incorrect on screen and in the instrument log – This must be set in the OdaStat-G™ Soware –
refer to the OdaStat-G™ Quick User Guide or "Help" secon in the soware manual).
oTemperature
o"BATT" (Baery), baery volts
oLogging "MEMORY"- % of memory used.
o"TYPE" of logging - "roLL" (connue logging aer the memory is full), "oncE" (stop logging aer
the memory is full).
oLogging interval, the me between gas readings displayed as "SECONDS" (set in the OdaStat-G™
soware).
o"CALGAS", Shows Calibraon Gas Level in ppm as set via the OdaStat-G™ soware package.
o"CLOCK not SEt" (see note 3 & Secon 6.3).
o"LOG FULL" (see note 4 & secon 6.7).
The display will then revert to display instantaneous gas readings in ppm.
Note 1:Releasing the buon during the countdown roune will cause an exit to the "OFF" screen.
Note 2:"Peak" is constantly updated when OdaLog® is in use. The Peak value is reset at the switch on
and at the start of each logging session.
Note 3:If the clock is not set, "CLOCK not SEt" will be displayed. The message will remain on the display
unl the buon is pressed to connue (see Secon 6.3).
Note 4:If the Logger memory is full and you have "Auto Log Start" & "Stop log when full" acve (refer to
the "Instrument Parameters" secon in the OdaStat-G™ soware package), the unit will not start
logging, and the display will show "LOG", "FULL", and the LED" s will illuminate at the same me.
The message will remain on the display unl the buon is pressed to connue.
6.3. "CLOCK not SEt" Message
Figure 6: Clock not SEt
If the clock has not been set since the last baery change, "CLOCK not...SEt" will be displayed upon start-
up and when starng logging funcons. This message will be displayed unl the buon is pressed. Logging
will start normally; however, the me and date will be incorrect.

OdaLog® L2 – Gas Logger User Manual
P/N: 10-1000 Revision G, January 2024 Page | 11
To set the correct me and date, stop the logging funcon (only necessary if the instrument is in Manual
Logging mode - see Secon 6.6), place the Instrument into IrDA mode (See Secon 6.8.1), and set the clock
via the
OdaStat-G™ soware package – for more informaon, refer to the "OdaStat-G Quick User Guide", or the
Help funcon in the soware.
6.4. Displaying STATUS on the LCD
Press and hold the buon unl "STATUS" is displayed, then release the buon. The display will cycle
through the "STATUS" screens as shown.
Figure 7: Odalog status screen
6.5. Start Logging Funcon (*Manual Logging Mode only, [Default = Enabled])
Figure 8: Start logging process.
Press and hold the buon down and connue holding as the screen displays "STATUS", then release the
buon when "START LOG" is displayed. See note 2 below if "CLOCK not SEt" is shown when the buon is
released.
The OdaLog® is now logging as conrmed by the ashing "LOGGING" symbol on the display and the LED"
s on either side of the display ashing once every 10 seconds (Default: Enabled - can be changed in the
OdaStat-G™ soware).
NOTE: Log can only be manually started/ stopped
when ‘auto-log’ is NOT enabled in the
Instrument Parameters in the OdaStat-G
soware
RELEASE
BUTTON
RELEASE
BUTTON
HOLD BUTTON

OdaLog® L2 – Gas Logger User Manual
P/N: 10-1000 Revision G, January 2024 Page | 12
Note 1:If the Logger memory is full and you have "Stop log when full" acve (refer to the "Instrument
Parameters" secon in the OdaStat-G™ soware package), the unit will not start logging, the
display will show "LOG" "FULL" and the LED" s will illuminate at the same me. The message will
remain on the display unl the buon is pressed to connue.
Note 2:If the clock is not set, "CLOCK not SEt" will be displayed. The message will remain on the display
unl the buon is pressed to connue (see Secon 6.3).
6.6. Stop Logging Funcon (*Manual Logging Mode only, [Default = Enabled])
Press and hold the buon down unl "STOP LOG" is displayed, then release the buon.
6.7. Auto Log Start Funcon [Default = Disabled]
This funcon is acvated via the OdaStat-G™ soware package as per the "Instrument Parameters" secon
by selecng the "Auto Log Start" opon. Once acve, logging will automacally start and stop every me
the OdaLog® instrument is switched on or o. Logging will also stop and start whenever the instrument
enters or exits from "IrDA" mode.
Note 1:If the Logger memory is full and you have "Auto Log Start" and "Stop log when full" acve (Refer
to the "Instrument Parameters" secon in the OdaStat-G™ soware package), the unit will not
start logging, the display will show "MEMORY FULL" and the LED's illuminate at the same me.
The message will remain on the display unl the buon is pressed to connue.
Note 2:If the clock is not set, "CLOCK not SEt" will be displayed. The message will remain on the display
unl the buon is pressed to connue (see Secon 6.3).
6.8. IrDA (Infra-Red Data Communicaon Mode)
6.8.1. Enter "IrDA" mode (Infra-Red Data Communicaon Mode)
From ON Mode: From the "INST" screen, press & hold the buon unl "IrDA" is displayed, then release
the buon (IrDA will appear on screen aer "STATUS"; see diagram in Secon 6.1).
From OFF Mode: From the "OFF" screen, press & hold the buon down unl "IrDA" is displayed, then
release the buon (IrDA will appear on screen aer the "ON" countdown and the test
screen/s; see diagram in Secon 6.10).
Note 1: This can only be done when logging is stopped unless Auto Log Start is acve. (See Secon 6.7)
Note 2:The magnec switches can be tested with a magnet in IrDA mode, and the LED will illuminate to
indicate they are funconing correctly.
6.8.2. Exit "IrDA" mode (Infra-Red Data Communicaon Mode)
Pressing the buon in "IrDA" mode or waing 75 seconds for the unit to "me out" will cause the
instrument to exit communicaon mode.
6.8.3. Precauons are required when using OdaLog® I.R communicaon.
The Infra-Red communicaons system used by the OdaLog® to communicate and transfer data to a
computer has been designed as a fast and convenient method to download informaon. Like all
communicaon systems, the Infra-Red system has some vulnerabilies that can interfere with normal

OdaLog® L2 – Gas Logger User Manual
P/N: 10-1000 Revision G, January 2024 Page | 13
communicaons as more portable devices are ulising this technology. As a result, the possibility of
interference between devices is increasing, and precauons should be taken to ensure that
communicaons between the OdaLog and PC are reliable and trouble-free.
Condions that have the potenal to disrupt OdaLog® to computer communicaons are:
Infra-Red ports built-in to the PC/Laptop or connected to any nearby computers should disabled.
Infra-Red ports on organisers, phones, modems, etc., that have been acvated or are in use.
Infra-Red ports on printers.
Strong light sources near the OdaLog during communicaons
Infra-Red remote-control devices from TVs, air condioners, etc.
Note: The OdaLog® is only suscepble to communicaon interference when placed into "IrDA" mode.
No other device or source of Infra-Red interference can aect the OdaLog® if the user has not
placed the OdaLog® into the "IrDA" mode.
6.8.4. Steps to ensure reliable I.R communicaon.
Posion the OdaLog® correctly with respect to the Infrared Data Communicaon Link, as shown
in Figure 9.
If you are using a computer with an Infra-Red port aached (other than the Infrared Data
Communicaon Link used with the OdaLog®), disable this port to prevent any Infra-Red
transmissions from it.
Ensure that other devices with Infra-Red ports (phones, other computers, organisers, etc.) within
about 10 metres of the OdaLog® do not have their Infra-Red ports acvated.
Ensure that strong light sources are not directed onto the OdaLog® while the instrument is in
"IrDA" mode.
When changing the conguraon of the OdaLog® using the OdaStat-G™ soware package, always
read back the sengs from the OdaLog® aer they have been changed to ensure they have been
received correctly.
Note: In severe cases of Infra-Red interference, the OdaLog® may stop responding. If this occurs,
contact your nearest OdaLog® distributor or service centre for advice on restoring normal
operaon to the OdaLog®.
6.8.5. Communicaons Set-up
If using a USB-based IR adapter, ensure the drivers are installed BEFORE connecng the device.
Connect the IrDA device to your PC and install the OdaStat-G™ soware package.
Using In-built IrDA Devices
While some infrared ports (laptops mainly) are compable with the OdaLog, due to the variaon in
manufacturers, drivers and communicaon protocols, users oen experience issues connecng
and/or downloading reliably. For this reason, Thermo Fisher strongly recommends that users only
aempt to connect to the OdaLog via the IR device supplied by us. Only advanced users should
aempt to use inbuilt IR ports. If dicules arise, ensure the inbuilt IR adapter is disabled, and
revert to using the provided adapter.
