Think PINPAD User manual
Pinpad is a simple arming device that allows local
control of the alarm system. It is battery powered and
requires no installation tools. Many can be installed
throughout the home to provide convenient system
control.
Features
• Secure encrypted wireless transmissions
• Secure 4 digit disarming
• Supports 1-button arming
• Red/Green LED arming feedback
• 3 year warranty
Enroll by sending an enrollment signal from the sensor
with the help of an installation specialist.
Option for sending an Enrollment Signal
• Press and hold 1and 3buttons
simultaneously
Install using the attached 3M VHB tape on the back of
the Pinpad to adhere it to a wall.
• See Pro Tips for recommendations about
using 3M VHB tape.
Operate using the Pinpad buttons. The Pinpad LED
will blink when a button is pressed.
Disarm by entering a valid 4 digit user code on
the number pad.
Arm Away by pressing and holding the AWAY
button until the Pinpad LED fl ashes red.
Arm Stay by pressing and holding the STAY
button until the Pinpad LED fl ashes red.
Trigger a panic alarm by pressing and holding
the STAY & AWAY buttons together until the
Pinpd LED fl ashes red.
Enrollment Buttons
Arm Stay Arm Away
Pinpad LED
Pinpad User Guide
Mounting Screw Holes
(optional)
VHB Tape
VHB Tape
Panic
Specications
Physical
Housing Dimensions
Weight with Battery
Mounting Fastener
2.28 x 1.97 x 0.40 inches (5.8 x 5.0 x 1.0 cm)
0.70 ounces (20 grams)
3M VHB™ Tape or #4/#6 screws (screws not provided)
Environmental
Operating Temperature
Maximum Humidity
32 to 120 °F (0 to 49 °C)
85% non-condensing relative humidity
Sensor Specications
Frequency
Replacement Battery
Nominal Battery Life
Battery Voltage
Transmitted Indications
433.92 MHz
One CR2032
4 to 6 years
3.0 VDC (Nominal), 2.2 VDC (Low)
Low Battery, Supervision
Specications subject to change without notice.
Pro Tips
To replace the battery insert a small screwdriver
into the top or bottom slit. Twist the screwdriver to
seperate the top white cover from the black wall
plate. Replace the battery and reinstall the cover
to the wall plate.
PINPAD – 020
Tech Support:
1-855-76-THINK
(1-855-768-4465)
www.thinkprotection.com
Surface Preparation
• Clean the surface
• Ensure the mounting surface temperature is above
50 °F (10 °C)
3M VHB Tape works great if the surface is
properly prepared and rm pressure is
applied for over 10 seconds.
