THM Carbones Clavicula XC User manual

T H M C L A V I C U L A XC
INSTRUCTION BOOK
t h m . b i k e

LOREM
IPSUM
T H M C L A V I C U L A XC
E
Don’t forget that your THM component is a lightweight carbon design.
Be aware of this when carrying out assembly and maintenance work and when
handling the component. Proceed with utmost care!

T H M C L A V I C U L A XC
E
LOREM
IPSUM
CONTENT
CONTENT
CONTENT ............................................... 3
INTRODUCTION .................................. 4
Preface ................................................................... 4
SAFETY ................................................. 5
Intended use ........................................................ 5
Fundamental safety precautions ................. 5
Assembly & Maintenance ................................. 6
On the road ........................................................... 7
Transport & Storage .......................................... 7
SPECIFICATIONS ............................... 8
Scope of delivery ............................................... 8
Dimensions ........................................................... 9
THM Bottom Bracket ...................................... 10
Permitted Use ................................................... 12
Tightening Torques ......................................... 12
ASSEMBLY ..........................................13
General Information ........................................ 13
Preparing the Frame ....................................... 13
Bottom bracket assembly ............................. 14
Installation of the chainrings ....................... 18
Mounting the crankset....................................... 19
Adjusting the bottom bracket ..................... 21
Installing the pedals ......................................22
Finishing touches................................................23
DISASSEMBLY .................................... 24
Crankset................................................................24
Bottom bracket....................................................25
MAINTENANCE .................................28
Important maintenance information ........28
Disposal ...............................................................29
Before every journey ......................................29
Checking bottom bracket clearance ........30
Regular maintenance ..................................... 31
Liability for defects .........................................33
Fair deal promise ................................................33
Crash Replacement .........................................33

T H M C L A V I C U L A XC
E
4
LOREM
IPSUM
INTRODUCTION
INTRODUCTION
Preface
This manual is an integral part of your THM component, and it provides you with information
regarding the safe operation of your THM-Clavicula crank system.
Read this manual carefully prior to assembling your THM component. Always read and obey all
of the assembly and maintenance instructions in this manual, as well as those provided by the
manufacturers whose products are used onyour bicycle (e.g. chainrings, pedals, etc.).
Non-observance of the information contained in this manual could result in an accident and
death or serious injury.
You will encounter the following symbols and references in this manual:
➔The arrow indicates the consequence of your action.
This safety message indicates a hazardous situation which,
if not avoided, could result in death or serious injury.
This message warns of a risk of material damage.
This refers to additional information or tips.
Retain this manual for other users of your THM components. Make sure that all users read,
understand and follow this manual. If you ever sell or give away your THM components, this manual
should be transferred to the new owner.
We hope you get a lot of joy from your THM components!
Your THM-Carbones Team
WARNING
NOTICE
INFO
WARNING

T H M C L A V I C U L A XC
E
5
LOREM
IPSUM
SAFETY
SAFETY
Intended use
Any use differing from that intended could cause an accident and result in death or
serious injury.
THM-Clavicula crank systems have been exclusively designed
- for installation on standard racing cycles, time trial and gravel.
- for the permitted area ofapplication – see Areaofapplication , page 12
Fundamental safety precautions
The following warnings for the THM-Clavicula component apply to all Clavicula models
(Clavicula SE, Clavicula XC etc.), unless otherwise specified.
Forthe time being we limit the service life of your THM-Clavicula crank system to 100,000 km
or 10 years. It is mandatory for you to contact us before continuing to use your THM-Clavicula
crank system after one of these limits has expired!
Always remember that riding a bicycle involves potential danger for the rider and other road
users, as well as for the bicycle and its components. Even if protective equipment and safety
devices are used, accidents resulting in death or serious injury can still occur.
You should therefore use your common sense and avoid any unreasonable
behavior!
WARNING

T H M C L A V I C U L A XC
E
6
LOREM
IPSUM
SAFETY
Assembly & Maintenance
Risk of accident caused by assembly and maintenance work which has not been
conducted in a professional manner.
- Do not overestimate your technical ability. All assembly and maintenance work
should be performed by a specialist workshop for bicycles. This is the only way to
ensure the work is conducted in a professional manner.
- Always stick toall the specified tightening torques for the screw connections.
- Only use suitable, undamaged, high-quality tools.
- Only ever use original THM components which are available from your specialist
dealer or directly from THM.
- Never modify your THM components on your own.
- Check your crank system (incl. crankarms, bottom bracket, chainrings) to make
sure it is undamaged and working properly before every ride. Send your THM-
Clavicula component in for review before further use if damage is visible (cracks,
fractures, deformations, etc.) or if you are in any doubt about itsfunctionality.
- Check your THM components before each ride to ensure the surfaces are
completely undamaged. Send your THM components in for inspection before
further use if damage is visible (deep scratches inthe paintwork which extend into
the carbon structure, large abrasions, etc.), if you are in any doubt about their
functionality or if the Clavicula lettering is abraded at one or more points (wear
indicator).
- Always ensure your bicycle is well maintained and in a flawless condition. Care
and maintenance will prolong the service life of your bicycle and its components
and improve your personal safety.
WARNING

T H M C L A V I C U L A XC
E
7
LOREM
IPSUM
SAFETY
On the road
Danger of accidents due to improper behavior or improper equipment during riding.
- Always ride with foresight, attention and a readiness to brake.
- Adjust your speed to the prevailing conditions (traffic, weather, visibility, etc.).
- Do not use your THM components at ambient temperatures below -10°C (14°F).
- Do not exceed the maximum overall weight for which your THM
components have been approved – see Dimensions, page 9.
- Always comply with the traffic regulations that are in force in the country
where you are using your bicycle.
- When riding your bicycle, you should always wear a high-quality cycling
helmet (e.g. ANSI certified) that isin excellent condition. Yourclothing should
beclose-fitting butnot restrictive.
- Only ride your bicycle ifyou are in good physical condition and your
bicycle and all its components are operating in a flawless manner.
- If you are involved in a heavy fall, you should not continue to ride your
bicycle. If such a case occurs, send us your THM components for inspection,
even if no external damage is visible! In your own interest you should treat
all the components on your bicycle which have been produced by other
manufacturers in the same manner.
Transport & Storage
Risk of accident caused by damaged bicycle components.
- Always transport your bicycle in an appropriate and careful manner.
- Do not store your THM components at an ambient temperature below
-15°C (5°F) or above 55°C (131°F).
Risk of accident.
- Do not allow children to play with your bicycle.
WARNING
WARNING

T H M C L A V I C U L A XC
E
8
LOREM
IPSUM
SPECIFICATIONS
SPECIFICATIONS
Scope of delivery
1
Adjustment screw
5
Left crankarm (NDS)
2
Clamping (screw + bolts)
6
Right crankarm (DS)
3
Cone sleeve
7
Bottom bracket (optional)
see page 10
4
Spacer
8
4 x Chainring washer
1
2
3
4
5
6
7
8
4

T H M C L A V I C U L A XC
E
9
LOREM
IPSUM
SPECIFICATIONS
Dimensions
Weight:
299 g ±5 %
Bolt cycle diameter (BCD)
Ø 104 mm
Q-Factor:
168 mm
Chain line:
52 mm (Boost)
Inner width :
118 mm
Crankarm lengths:
170 mm - 172,5 mm - 175 mm
Spindle diameter:
Ø 30 mm
Boverall Bottom bracket width:
92 mm + 4 mm spacers
Min. number of teeth:
32
Max. permissible weight
(rider, bicycle + luggage):
110 kg

T H M C L A V I C U L A XC
E
10
LOREM
IPSUM
SPECIFICATIONS
THM Bottom Bracket
All Spacer configurations are only valid for THM Bearings. The Spacers ensure that
the tapered cone sleeve has exactly the required position on the spindle. Therefore,
we strongly recommend using THM Bearings. (See also “Mounting the crankset” p. 19)
There are stainless steel and hybrid ceramic bearings available.
Non-drive side
(left)
BSA MTB 73
Drive side
(right)
Non-drive side
(left)
Shimano PF 92
Drive side
(right)
Cone
sleeve
Threaded
Cone
sleeve
Spacer
Spacer
Press-fit
Seal
Seal
Seal
Seal
Spacer
Spacer
BB
Spacer
BB
Spacer

T H M C L A V I C U L A XC
E
11
LOREM
IPSUM
SPECIFICATIONS
Non-drive side
(left)
BB30
Drive side
(right)
Non-drive side
(left)
PF30
Drive side
(right)
Cone
sleeve
Press-fit
Cone
sleeve
Press-fit
Seal
Seal
Spacer
Spacer
Spacer
Spacer

T H M C L A V I C U L A XC
E
12
LOREM
IPSUM
SPECIFICATIONS
Permitted Use
Risk of accident caused by a malfunctioning crank system due to overload.
- Only ever use your Clavicula component within its permitted area of application.
Clavicula XC
X1–X3
X1 Racing cycle and light cross-country terrain
X2 Touring, road
X3 medium/heavy terrain
X4 Free ride, heavy terrain
X5 Downhill,extremeterrain
Tightening Torques
Risk of accident caused by a malfunctioning crank system due to loosened screw
connections.
- Check the required tightening torque of all screw connections after the first 100 km
- Retighten the connections if necessary. Repeat this check every 2500km!
Nm
lbf ·in
Adjustment screw
10
89
with thread lock
Crank clamping bolt
15
133
Bearing cups
40
354
greased
Chainring bolts, aluminum
6
53
Pedal threads
20
177
WARNING
WARNING

T H M C L A V I C U L A XC
E
13
LOREM
IPSUM
ASSEMBLY
ASSEMBLY
General Information
If not properly executed, assembly and maintenance work could cause accidents
resulting in serious or fatal injury.
- Do not overestimate your technical ability. All assembly and maintenance
work should be performed by a specialist workshop for bicycles. This is the
only way to ensure the work is conducted in a professional manner.
Preparing the Frame
It is mandatory for you to read and follow the safety and assembly instructions
provided by the manufacturer of your frame.
Secure your bicycle in an appropriate assembly stand.
If necessary, remove the crankset and the old
bottom bracket.
If necessary, use cleaning solvent or other similar
agents to clean the bottom bracket housing of your
frame.
Make sure that the outer faces of the bottom bracket
housing are plane, parallel, milled to the correct
dimension and free of burrs – page 10.
If necessary, rework the bottom bracket housing
using an appropriate milling tool (Cyclus, ParkTool®
or another similar tool).
Make sure that the threads of the bottom
bracket housing are clean, free from paint
residues and adequately tapped into the
housing.
If necessary, rework the threads with an appropriate
cutting tool (Cyclus, ParkTool® or another similar
tool).
WARNING
INFO

T H M C L A V I C U L A XC
E
14
LOREM
IPSUM
ASSEMBLY
Bottom bracket assembly
To find the required bottom bracket, please m easure the inner diameter and the width of the
bottom bracket housing of your bicycle frame.
Also check if you need threaded or press-fit bearing shells. The following table will show you
which THM bottom bracket you need:
Inner Diameter
Width
Bottom bracket
Threaded
33,8 mm
73 mm
BSA
Press-fit
46 mm
73 mm
PF 30
42 mm
73 mm
BB 30
41 mm
92
Shimano PF92
Make sure that the securing bolt of the derailleur cable guide does not protrude into the
bottom bracket area of your frame by more than 1 mm.
Apply grease to the threads and contact surfaces of the bearing cups.

T H M C L A V I C U L A XC
E
15
LOREM
IPSUM
ASSEMBLY
BSA
The non-drive (left) side bearing cup is marked with a groove.
- Screw the right –hand
bearing cup(R) (initially by
hand) anticlockwise into the
drive side of the bottom
bracket housing.
- Screw the left-hand bearing
cup(L) (initially by hand)
clockwise into the non-drive
side of the bottom bracket
housing.
- Use the THM Bottom bracket
tool ½ “( 1) to tighten both cups
to a torque of 40 Nm (354
lbf*in), using a torque wrench.
- Place the sealing
INFO

T H M C L A V I C U L A XC
E
16
LOREM
IPSUM
ASSEMBLY
BB30 / PressFit 30
For BB30, PressFit 30 bottom brackets:
The long bearing cup with internal thread is always located on the drive side.
The short bearing cup with external thread is always located on the non-drive side.
BB30 / Press-fit 30
- Apply grease to the threads
and all contact surfaces
between the frame and the
bearing cups.
- Insert the long bearing cup
(2) or (4) as far as possible
into the drive-side of the
bottom bracket housing.
- Screw the short bearing cup
(3) or (5) by hand clockwise
into the long bearing cup.
- Make sure that both bearing
cups are located centrally in
front of the bottom bracket
housing.
- Use the THM Bottom
bracket tool ½ “ (1) in
conjunction with a torque
wrench to apply 40 Nm of
torque.
- For PressFit 30 place the
seals
INFO

T H M C L A V I C U L A XC
E
17
LOREM
IPSUM
ASSEMBLY
Shimano ® Press-fit
- Press both bearing cups
simultaneously into the bottom
bracket housing as far as possible
by using a suitable pressing tool
(e.g. ParkTool®).
- Check the seals

T H M C L A V I C U L A XC
E
18
LOREM
IPSUM
ASSEMBLY
Installation of the chainrings
The Clavicula XC is designed for a single chainring setup. The spider has 4 holes in a 104 mm
diameter. To carry the load of the screws and to protect the carbon surface we strongly
recommend placing some special washers between the crankset and the screw (see below)
Danger of damage to the chainring mount.
- The number of chainwheel teeth must never be less than the minimum number
required – see page 10.
- Always observe the tightening torques specified by the manufacturer of the
chain ring bolts; however, do not exceed a max. tightening torque of 6 N·m
(53 lbf·in) under any circumstances.
Install 1 chainring
- Place the chainring nut (1)
in the chainring hole
- Place both on the crank
and place the chainring on
the inside.
- Apply grease on the
screws (2)
- Place the washer (3)
between screw and
crankset
- Tighten the screws (2)
to 6 Nm
WARNING
1
3
2
Torx TX30 -
> 6 Nm

T H M C L A V I C U L A XC
E
19
LOREM
IPSUM
ASSEMBLY
Mounting the crankset
Before mounting the crankset, please check if the bottom bracket is correctly installed and runs
smoothly. For BSA MTB 73, Shimano PF 92 and PF30, please check if the sealing is mounted. This
description is only valid if you use THM bottom bracket which are designed for the THM cranksets.
If you use non THM bearings, please check if the width (see Specifications) of the
bearings allows for the cone sleeve to be installed in the correct position as described
in this chapter.
- Locate the spacer (4) required for
your bottom brackt on the cone sleeve
(3). (See p. 10 ff).
- Press the cone sleeve in the bearing
on the non-drive side (left).
- Place the spacer (6) required for
your bottom brackt onto the axle.
(See p. 10 ff).
- Lightly grease the bearing seat of the
axle.
- Insert the axle oftherightcrank through
the bottom bracket up to its stop.
- Thoroughly degrease the axle and
crank multi-tooth segment.
- Make sure that the clamping screw (2)
is loosened or removed.
- Fit the left crank arm to the multi-
tooth segment of the axle.
- Press the cranks together by hand as
far as possible. Both cranks abut
against the spacer rings.
WARNING
4
3
1
2
6

T H M C L A V I C U L A XC
E
20
LOREM
IPSUM
ASSEMBLY
- Screw the adjusting screw (1) into the
axle –use the THM adjustment tool, or
a 6 mm Allen key for this.
tighten = screw counterclockwise!
loosen = screw clockwise!
- Tighten the adjusting screw until the
collar on the cone sleeve is flush
against the bearing or spacer ring.
The tightening torque required for
this is typically 5–10 Nm (44–
106lbf·in) –depending on the actual
width of the bottom bracket housing.
- Check the clearance between the
cranks, chainrings and the chain
stays of the frame.
- Minimum clearance: 3mm.
- Remove the adjusting screw (1) .
- Pull the crank arm a little off the
axle (3-5 mm).
- Check if the cone sleeve (black) is
flush with the end of the multi
segment area (green marked line) or
up to 1.5 mm more towards the
chainring side of the crankset.
- If the cone sleeve is not in the
position described above this can
lead to premature wear.
1
1
