thomann Stairville Replay Show User manual

Replay Show
DMX manager
user manual

Musikhaus Thomann
Thomann GmbH
Hans-Thomann-Straße 1
96138 Burgebrach
Germany
Telephone: [phone]
E-mail: [email protected]
Internet: www.thomann.de
26.11.2019, ID: 474470

Table of contents
1 General information................................................................................................................................. 5
1.1 Further information........................................................................................................................... 6
1.2 Notational conventions.................................................................................................................... 7
1.3 Symbols and signal words............................................................................................................... 8
2 Safety instructions.................................................................................................................................. 10
3 Features....................................................................................................................................................... 14
4 Installation and starting up................................................................................................................ 15
5 Connections and controls................................................................................................................... 18
6 Operating.................................................................................................................................................... 23
6.1 Starting the device........................................................................................................................... 23
6.2 Setting the operating modes....................................................................................................... 23
6.3 Control via app.................................................................................................................................. 33
6.4 Software update............................................................................................................................... 35
7 Technical specications....................................................................................................................... 36
8 Plug and connection assignments.................................................................................................. 38
Table of contents
Replay Show
3

9 Protecting the environment.............................................................................................................. 39
Table of contents
DMX manager
4

1 General information
This user manual contains important information on the safe operation of the device. Read and
follow all safety notes and all instructions. Save this manual for future reference. Make sure
that it is available to all persons using this device. If you sell the device to another user, be sure
that they also receive this manual.
Our products and user manuals are subject to a process of continuous development. We there‐
fore reserve the right to make changes without notice. Please refer to the latest version of the
user manual which is ready for download under www.thomann.de.
General information
Replay Show
5

1.1 Further information
On our website (www.thomann.de) you will nd lots of further information and details on the
following points:
Download This manual is also available as PDF le for you to download.
Keyword search Use the search function in the electronic version to nd the topics of
interest for you quickly.
Online guides Our online guides provide detailed information on technical basics
and terms.
Personal consultation For personal consultation please contact our technical hotline.
Service If you have any problems with the device the customer service will
gladly assist you.
General information
DMX manager
6

1.2 Notational conventions
This manual uses the following notational conventions:
The letterings for connectors and controls are marked by square brackets and italics.
Examples: [VOLUME] control, [Mono] button.
Texts and values displayed on the device are marked by quotation marks and italics.
Examples: ‘24ch’ , ‘OFF’ .
Text inputs that are carried out on the device are indicated by typewriter font.
Example: 2323
Letterings
Displays
Text input
General information
Replay Show
7

The individual steps of an instruction are numbered consecutively. The result of a step is
indented and highlighted by an arrow.
Example:
1. Switch on the device.
2. Press [Auto].
ðAutomatic operation is started.
3. Switch o the device.
1.3 Symbols and signal words
In this section you will nd an overview of the meaning of symbols and signal words that are
used in this manual.
Instructions
General information
DMX manager
8

Signal word Meaning
DANGER! This combination of symbol and signal word indicates an
immediate dangerous situation that will result in death or
serious injury if it is not avoided.
NOTICE! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in material and
environmental damage if it is not avoided.
Warning signs Type of danger
Warning – high-voltage.
Warning – danger zone.
General information
Replay Show
9

2 Safety instructions
This device is used for real-time recording, playback and distribution of DMX signals via LAN or
WLAN. Use the device only as described in this user manual. Any other use or use under other
operating conditions is considered to be improper and may result in personal injury or prop‐
erty damage. No liability will be assumed for damages resulting from improper use.
This device may be used only by persons with sucient physical, sensorial, and intellectual
abilities and having corresponding knowledge and experience. Other persons may use this
device only if they are supervised or instructed by a person who is responsible for their safety.
DANGER!
Danger for children
Ensure that plastic bags, packaging, etc. are disposed of properly and are not
within reach of babies and young children. Choking hazard!
Ensure that children do not detach any small parts (e.g. knobs or the like) from
the unit. They could swallow the pieces and choke!
Never let children unattended use electrical devices.
Intended use
Safety
Safety instructions
DMX manager
10

DANGER!
Electric shock caused by high voltages inside
Within the device there are areas where high voltages may be present. Never
remove any covers.
There are no user-serviceable parts inside.
Do not use the device if covers, protectors or optical components are missing or
damaged.
NOTICE!
Risk of re
Do not block areas of ventilation. Do not install the device near any direct heat
source. Keep the device away from naked ames.
Safety instructions
Replay Show
11

NOTICE!
Operating conditions
This device has been designed for indoor use only. To prevent damage, never
expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and
strong vibrations.
Only operate the device within the ambient conditions specied in the chapter
‘Technical specications’ of this user manual. Avoid heavy temperature uctua‐
tions and do not switch the device on immediately after it was exposed to tem‐
perature uctuations (for example after transport at low outside temperatures).
Dust and dirt inside can damage the unit. When operated in harmful ambient
conditions (dust, smoke, nicotine, fog, etc.), the unit should be maintained by
qualied service personnel at regular intervals to prevent overheating and other
malfunction.
Safety instructions
DMX manager
12

NOTICE!
External power supply
The device is powered by an external power supply. Before connecting the
external power supply, ensure that the input voltage (AC outlet) matches the
voltage rating of the device and that the AC outlet is protected by a residual cur‐
rent circuit breaker. Failure to do so could result in damage to the device and pos‐
sibly the user.
Unplug the external power supply before electrical storms occur and when the
device is unused for long periods of time to reduce the risk of electric shock or
re.
NOTICE!
Possible damage due to installation of a wrong fuse
The use of dierent types of fuses can cause serious damage to the unit. Fire
hazard!
Only fuses of the same type may be used.
Safety instructions
Replay Show
13

3 Features
DMX manager with the following features:
nDMX recorder and Art-Net-Node with wireless function
n2 DMX universes (1024 DMX channels)
nReal-time recording and playback of DMX and Art-Net signals
nBuilt-in WiFi access point
nArt-Net in / out via RJ45 socket or WLAN
n8 directly recallable memory locations, each with up to 20 hours of recording capacity
nOperation via buttons and display on the device as well as via Android and iOS applica‐
tions (e.g. Aurora DMX, Photon, ArtNetDMXRemote)
n2 playback modes: Single playback or endless loop
nDimmer and speed control
n2in1 DMX merge (HTP / LTP / Override / Backup)
n1in2 DMX splitter (adjustable via buttons and display)
nPower supply via Power Twist or USB port
nIncludes SD card (16 GB) for storing the shows
nRobust metal housing
Features
DMX manager
14

4 Installation and starting up
Unpack and check carefully there is no transportation damage before using the unit. Keep the
equipment packaging. To fully protect the product against vibration, dust and moisture during
transportation or storage use the original packaging or your own packaging material suitable
for transport or storage, respectively.
Create all connections while the device is o. Use the shortest possible high-quality cables for
all connections. Take care when running the cables to prevent tripping hazards.
NOTICE!
Possible data transmission errors
For error-free operation make use of dedicated DMX cables and do not use ordi‐
nary microphone cables.
Never connect the DMX input or output to audio devices such as mixers or ampli‐
ers.
Installation and starting up
Replay Show
15

Connect the output of the rst DMX device to the input of the second one and so on, to form a
series connection. Connect the output of this DMX chain to input A on the front or back of the
DMX Manager. Connect the output of a second DMX chain to input B on the front or back of
the DMX Manager. Connect the output on the front or rear of the DMX Manager to the DMX
input of a DMX controller or other DMX device. Make sure that the output of the last DMX
device in the chain is terminated by a resistor (110 Ω, ¼W). Note that the ports on the front
and back can not be used in parallel.
Connections in ‘DMX’ mode
Installation and starting up
DMX manager
16

While both the device and the DMX manager are in operation, the DMX indicators [DMX IN 1]/
[DMX IN 2] show that a DMX signal is being received on the input.
The unit has been designed for rack mounting in a standard 19" rack; it occupies one rack unit.
DMX indicator
Rack mounting
Installation and starting up
Replay Show
17

5 Connections and controls
Front panel
Connections and controls
DMX manager
18

1[WiFi]
Unscrewable WLAN antenna
2 Display
3[MENU]
Button to activate the main menu and to switch between the menu items. Closes an opened submenu.
[UP] / [DOWN]
Button to switch between the menu items of a menu level, increases or decreases the displayed value by one.
[ENTER]
Button to conrm the set value.
4[BRIDGE] / [RECORD] / [PLAY]
Buttons to select the operating mode
5/ /
Buttons for controlling the recording and playback functions
Connections and controls
Replay Show
19

6[MEM 1]…[MEM 8]
Buttons to select the memory locations
7[DMX IN 1] / [DMX IN 2]
Status display. The indicator LED for the DMX input lights up green as soon as a signal is received.
[DMX OUT 1] / [DMX OUT 2]
Status display. The indicator LED for the DMX output lights up red as soon as a signal is sent.
8[SPEED]
Rotary control for adjusting the speed
9[DIMMER]
Rotary control for adjusting the brightness
Connections and controls
