Threshold TGAVC72-23 User manual

>> Assembly instructions
TM
© 2023 Target. The Bullseye Design is a trademark of Target Brands, nc. All rights reserved.
Promontory 72" Sliding Glass Media Stand
Style # TGAVC72-23 DPC-item #: 249-10-5786 (White)
Style # TGAVC72-24 DPC-item #: 249-10-8938 (Black)

2
Congratulations on your latest Target purchase.
Now what? Don’t start sweating over this box of parts. This will be easy. We did the hard work for you.
All you need to do is follow our simple instructions and you’ll be on your way to transforming your room in no time.
Good luck – though we’re confident you won’t need it.
before you begin
1. Check for damaged or missing parts. Call 1-855-MYTGTHOME (855-698-4846) to order missing supplies.
2. Use the carton as a work surface to prevent product damage during assembly.
3. Gather all tools prior to assembly.
tools needed (not included)
phillips head
screwdriver
For tipping restraint hardware kit only.
power drill

hardware
(H1) x 36
cam lock
(H2) x 36
cam bolt
(H3) x 28
M8 x 30 mm
wood dowel
(H5) x 16
white cam lock cover (TGAVC72-23)
black cam lock cover (TGAVC72-24)
pare hardware
(H9) x 2
tipping restraint hardware kit
(inside plastic bag)
(H6) x 8+1
rubber bumper
3
(H4) x 12
shelf support
(H7) x 12
M3.5 x 12 mm screw
(H8) x 4
M4 x 35 mm screw
(H10) x 20
brown cam lock cover

TEM DESCR PT ON QTY
A Top panel 1
B Left / Right adjustable shelf 2
C Base 1
D Middle partition 2
E Left sliding door 1
F Middle / Right sliding door 2
G Back panel 2
H Side panel 2
Middle adjustable shelf 1
exploded diagram
4
H
B
C
D
E
F
G
H
G
A
B
D
F

how to use the cam lock system
1. 2. 3.
4. 5.
1. 2. 3.
Screw cam bolt into panel Push cam into panel - arrow
feature on cam top points to
panel edge
Align cam bolt(s) with cam(s)
and insert all the way into
cross-bored hole(s)
Rotate cam(s) clockwise
190°-230° to lock panels
together
Panels should be tight against
each other and connection
should be rigid
190°-230°
5

1.1. Securely screw the cam bolts (H2) into the designated small holes on the top panel (A), the base (C) and the side panels (H).
step 1: prepare the top panel, side panels and base assembly
(H2) x 36
cam bolt
6
H
H
H2
H2
H2
H2
H2
H2
A
C
H2
H2
H2
H2

step 2: attach the back panel between the side panels
7
2.1. nsert four 30mm wood dowels (H3) into the side holes of the back panels (G) at both ends.
2.2. Align and attach the back panels (G) between the side panels (H) with eight cam locks (H1).
(H1) x 8
cam lock
(H3) x 4
M8 x 30 mm
wood dowel
G
H
H
H1
H3
G
The cam locks face inward

step 3: attach the previous assembly to the base
8
(H1) x 10
cam lock
(H3) x 8
M8 x 30 mm
wood dowel
3.1. nsert eight 30mm wood dowels (H3) into the bottom inner holes of the panels (H and G).
3.2. Align and attach both side panels (H) and back panel (G) to the base (C) with ten cam locks (H1).
G
H
H
G
H C
H1
H3
C Floor leveler
The floor protector
H1

D
step 4: attach the middle partitions to the base
9
(H1) x 4
cam lock
(H3) x 4
M8 x 30 mm
wood dowel
4.1. nsert two 30mm wood dowels (H3) into the bottom inner holes of each middle partition (D).
4.2. Align and attach the middle partitions (D) to the base (C) with four cam locks (H1).
C
H3
H1
C
D
D

D
step 5: attach the top panel to the previous assembly
(H1) x 14
cam lock
(H3) x 12
M8 x 30 mm
wood dowel
10
5.1. nsert twelve 30mm wood dowels (H3) into the top inner holes of the panels (D, G and H).
5.2. Align and attach the top panel (A) to the previous assembly using fourteen cam locks (H1).
G
H
H
H1
H3
A
A
D

11
step 6: fasten the back panels
6.1. With the help of another adult, stand the unit upright.
6.2. Fasten the back panels (G) to the middle partitions (D) with four 35mm screws (H8).
G
G
H8
(H8) x 4
M4 x 35 mm screw
NOTE: DO NOT use power tools.
H8
H8
H8

12
step 7: install the adjustable shelves
7.1. nsert four shelf supports (H4) into the desired holes in the sides of each compartment. Make sure you place the four shelf supports at the same level so the
shelf is not tilted.
7.2. Tilt and rest the adjustable shelves (B and ) onto the shelf supports. Secure the shelf in place with the 12mm screws (H7) for extra support.
(H4) x 12
shelf support (H7) x 12
M3.5 x 12 mm screw
H
D
H
H4
B
B
H7
B
D

13
step 8: install the sliding doors
8.1. Pick up the left sliding door (E) and rest the bottom sliding rollers onto the inner roller track on the base (C).
8.2. Line up guide pins with the top guideway and press lever to unlock guide pin and release into the track.
8.3. f the guide pins can’t slide into the top guideway properly, take a Phillips screwdriver and adjust the center screw head on the back plates of the sliding
rollers to correct the top gap.
8.4. Repeat above steps to install the middle and right sliding doors (F). You need slide inside door to one side to allow access to the other side of the outer door
in opening to access slide door lock and release the guide pin. Then slide inner door to opposite side to allow access to other side of outer door in the open
case and release the other guide pin.
1
2
Guide pin Lever
NOTE: The guide pins are retracted and
flush with the door top rail when shipping.
f the guide pins accidentally protruded out
(the lever is unlocked) when assembly,
press them down from the top and proceed
with the assembly.
F
E
A
C
C
F
A
Door inner view
8.2
Lever
Sliding roller
8.1
Turn the center screw head
clockwise to rise the roller.
Turn it counter-clockwise to
lower the roller.
Door inner view
8.3
C

F
14
step 9: Install the cam lock covers and rubber bumpers
9.1. Plug the cam lock covers (H5) into the visible cam locks onto the side panels (H) and the middle partitions (D) to conceal the cams.
9.2. Plug the brown cam lock covers (H10) into the visible cam locks onto the back panels (G) to conceal the cams.
9.3. Using the pilot holes as a guide, affix the rubber bumpers (H6) onto each side panel (H) where the sliding doors are in contact with.
(H6) x 8+1
rubber bumper
NOTE: DO NOT slam shut the sliding
doors to prevent from damaging and
leaving gap.
H6
H6
H
H
H
H5
H D
H10
G
(H10) x 20
brown cam lock cover
F
E
(H5) x 16
white cam lock cover (TGAVC72-23)
black cam lock cover (TGAVC72-24)

15
step 10: install the tipping restraint hardware kit
10.1. Adjust the pre-attached floor levelers to level the unit against a wall.
10.2. Follow the instructions printed on plastic bag containing tipping restraint hardware to attach tip-over restraint between the unit and wall.
NOTE: You must use this tipping restraint to attach this unit to the wall, to prevent accidents and/or injures.
Tools required: Phillips screwdriver, stud finder, tape measure, pencil, power drill and 1/8” drill bit (not provided).
Wooden stud
(H9) x 2
tipping restraint hardware kit
Wall
Metal bracket Nylon strap
Short screw
Wall
Long screw
Floor leveler
H9

FURNITURE TIPPING RE TRAINT
YOUNG CH LDREN MAY BE NJURED BY T PP NG FURN TURE AND YOU MUST USE TH S T PP NG
RESTRA NT TO ATTACH TH S UN T TO THE WALL, TO PREVENT ACC DENTS AND/OR NJUR ES.
TO PROV DE PROTECT ON AGA NST THE UNEXPECTED T PP NG OF
FURN TURE DUE TO MPROPER USE.
USE OF T P-OVER RESTRA NTS MAY ONLY REDUCE, BUT NOT EL M NATE, THE R SK OF T P-OVER.
16

Care and Maintenance
 Use a soft, clean cloth that will not scratch the surface when dusting.
 Use of furniture polish is not necessary. Should you choose to use polish, test first in an inconspicuous area.
 Using solvents of any kind on your furniture may damage the finish.
 Never use water to clean your furniture as it may cause damage to the finish.
 Always use coasters under beverage glasses and flowerpots.
 Liquid spills should be removed immediately. Using a soft, clean cloth, blot the spill gently. Avoid rubbing.
 Always use protective pads under hot dishes and plates. Heat can cause chemical changes that may create spotting within the furniture finish.
 Stains or marks from crayons or ink markers will be difficult to remove.
 n the event that your furniture is stained or otherwise damaged during use, we recommend that you call a professional to repair your furniture.
 Check bolts/screws and nuts periodically and tighten them if necessary.
Further Advice about Wood Furniture Care
t is best to keep your furniture in a climate-controlled environment. Extreme temperature and humidity changes can cause fading, warping, shrinking and
splitting of wood. t is advised to keep furniture away from direct sunlight as sun may damage the finish.
Proper care and cleaning at home will extend the life of your purchase. Following these important and helpful tips will enhance your furniture as it ages.
We hope you enjoy your purchase for many years.
Thank you for your purchase!
QUALITY GUARANTEE
We are confident that you will be delighted with your Whalen Furniture purchase.
Should this product be defective in workmanship or materials or fail under normal use, we will repair or replace it for up to one (1) year from date of purchase.
Every Whalen Furniture product is designed to meet your highest expectations. We guarantee that you will immediately see the value of our fine furniture.
This warranty gives you specific legal rights and you may also have other rights which vary from state to state or province to province.
Customer Service: 1-855-MYTGTHOME (855-698-4846)
8:30 a.m. - 4:30 p.m., PST, Monday to Friday
www.whalenfurniture.com
17

M AX I M U M R E C O M M E N D E D W E I G H T L O A D
MANUFACTURER: Whalen Furniture Manufacturing
CATALOG: Promontory 72" Sliding Glass Media Stand
MODEL # TGAVC72-23, TGAVC72-24
USE W TH TELEV S ONS
WE GH NG 120 LB (54.4 KG) OR LESS. USE W TH HEAV ER TELEV S ONS MAY RESULT N NSTAB L TY CAUS NG T P
OVER RESULT NG N DEATH OR SER OUS NJURY.
MAX MUM LOAD 22.7 kg / 50 lb
F TS UP TO MOST 188 cm / 74 in. D AGONAL
FLAT-PANEL TVS
MAX MUM LOAD 54.4 kg / 120 lb
18

The maximum recommended weight allowance is 54.4 kg / 120 lb for top panel.
The maximum recommended weight allowance is 22.7 kg / 50 lb for shelves.
Death or serious injury may occur when children climb on audio and/or video equipment furniture. A remote control or toys
placed on the furnishing may encourage a child to climb on the furnishing and as a result may tip over onto the child.
NEVER allow children to climb or play with the TV or furnishing supporting the TV.
NEVER place toys, food, remote, etc. on top of the TV or TV furnishing.
ALWAY use either the safety hardware as instructed or other wall anchoring device.
Relocating audio and/or video equipment to furniture not specifically designed to support audio and/or video equipment
may result in death or serious injury due to furniture collapse or over turning onto a child.
NEVER place a TV on furniture that is not intended to support a TV.
NEVER exceed the maximum size and weight of the TV shown in the instructions.
Be sure to refer to the TV warning label as shown in the instructions.
Overloading drawers and shelves may result in furniture that can break or sag, or tip-over which may result in injury.
NEVER exceed the weight limits shown in the instructions.
Place the heavier items on lower shelves as far back from the front as possible.
Load the bottom surfaces first to avoid top-heavy furniture.
Moving furniture that is not designed to be moved or equipped with casters may result in injury or damage to furnishings or
personal property.
ALWAY unload shelves and drawers, starting with the top surfaces, before moving.
NEVER push or pull furniture on carpet. Have a friend help lift properly to move and/or reposition it.
DO NOT use the unit as a seating surface.
This unit is not intended for use with CRT TVs. The top surface maximum weight capacity is 120 lb (54.4 kg) and maximum load
74 in. (188 cm) diagonal flat-panel TV. The shelf maximum recommended weight allowance is 50 lb (22.7 kg). Use
with heavier televisions may result in instability causing tip over resulting in death or serious injury.
Questions? Just call 1-855-MYTGTHOME (855-698-4846) for parts and service. For faster service, have the style number and DPC number ready when calling.
