Threshold Marvale TGT70BK User manual

>> Assembly instructions
TM
© 2023 Target. The Bullseye Design is a trademark of Target Brands, Inc. All rights reserved.
Marvale Bookcase with Drawer
Style #: TGT70BK
DPC-item #: 249-14-0069

Congratulations on your latest Target purchase.
Now what? Don’t start sweating over this box of parts. This will be easy. We did the hard work for you.
All you need to do is follow our simple instructions and you’ll be on your way to transforming your room in no time.
Good luck – though we’re confident you won’t need it.
before you begin
1. Check for damaged or missing parts. Call 1-855-MYTGTHOME (855-698-4846) to order missing supplies.
2. Use the carton as a work surface to prevent product damage during assembly.
3. Gather all tools prior to assembly.
tools needed (only hex wench included)
Phillips head
screwdriver
For tipping restraint hardware kit only.
power drill
2
hex wrench

hardware
(H1) x 28
large cam lock
(H7) x 16
lock washer
(H3) x 44
cam bolt
(H9) x 24
M4 x 32mm screw
(H6) x 16
1/4” x 15mm bolt
(H4) x 8
M6 x 30 mm wood dowel
3
(H10) x 8
shelf support
(H13) x 4
cam lock cover
(H8) x 16
flat washer
(H11) x 2
handle
(H12) x 4
M4 x 18mm bolt
(H2) x 16
small cam lock
(H5) x 29
M8 x 30 mm wood dowel
(H14) x 1
hex wrench
(H15) x 2
tipping restraint hardware kit
(inside plastic bag)

hardware
Spare hardware
4
(H16) x 8
M3.5 x 12mm screw

exploded diagram
ITEM DESCRIPTION QTY
A Top panel 1
B Left side panel 1
C Right side panel 1
D Adjustable shelf 2
E Fixed shelf 1
F Bottom panel 1
G Back panel 2
H Upper drawer front panel 1
I Lower drawer front panel 1
J Drawer back panel 2
K Drawer left side panel 2
L Drawer right side panel 2
M Drawer bottom panel 2
N Drawer bottom support 4
O Base side frame 2
P Base top stretcher 2
Q Base bottom stretcher 2
R Panel reinforcement 2
E
D
A
C
L
B
F
I
M
G
N
K
5
J
D
G
H
O
J
K
L
M
P
P
Q
Q
R
N
O
R

how to use the cam lock system
1. 2. 3.
4. 5.
1. 2. 3.
Screw cam bolt into panel Push cam into panel - arrow
feature on cam top points to
panel edge
Align cam bolt(s) with cam(s)
and insert all the way into
cross-bored hole(s)
Rotate cam(s) clockwise
190°-230° to lock panels
together
Panels should be tight against
each other and connection
should be rigid
190°-230°
6

1.1. Orient and attach the base upper stretchers (P) to one base side frame (O) with two 1/4” bolts (H6) and two washers (H7 and H8).
step 1: attach base upper stretchers
7
O
P
H6
(H14) x 1
hex wrench
NOTE: DO NOT fully tighten
all fasteners until you finish
assembling all parts. Once
assembled, go back and fully
tighten all bolts. This will
make the assembly easier.
P
O
P
(H7) x 2
lock washer
(H6) x 2
1/4” x 15mm bolt
(H8) x 2
flat washer
H7
H8
The metal tabs face inward and
flush with each other.

2.1. Orient and fit the base bottom stretchers (Q) onto the U-shaped brackets on the base side frame (O) and fasten them into place using two 1/4” bolts (H6) and
two washers (H7 and H8).
step 2: attach base bottom stretchers
O
Q
H6
Q
(H14) x 1
hex wrench
(H7) x 2
lock washer
(H6) x 2
1/4” x 15mm bolt
(H8) x 2
flat washer
H7
H8
NOTE: DO NOT fully tighten
all fasteners until you finish
assembling all parts. Once
assembled, go back and fully
tighten all bolts. This will
make the assembly easier.
8

3.1. Repeat the same process with the other base side frame (O).
step 3: attach base side frame
O
Q
H6
9
Q
(H14) x 1
hex wrench
(H7) x 4
lock washer
(H6) x 4
1/4” x 15mm bolt
(H8) x 4
flat washer
H7
H8
NOTE: DO NOT fully tighten
all fasteners until you finish
assembling all parts. Once
assembled, go back and fully
tighten all bolts. This will
make the assembly easier.
P
P
O
H6
H7
H8

step 4: prepare drawer kit assembly
4.1. Securely screw the cam bolts (H3) into the designated small holes on the drawer front panels (H and I).
H
H3
H3
H3
H3
H3
H3
I
(H3) x 16
cam bolt
10

step 5: attach drawer side panels to the drawer back panel
5.1. Insert the small wood dowels (H4) into the middle holes of one drawer back panel (J) at both ends and attach it between the drawer left and right side panels
( K and L) with four 32mm screws (H9).
5.2. Complete the process two times for the other drawer.
K
x 2
J
L
H9
The grooves line up with each other.
(H9) x 8
M4 x 32mm screw
(H4) x 4
M6 x 30 mm wood dowel
H9
H4
H4
NOTE: DO NOT use power tools.
11

step 6: attach drawer bottom supports
6.1. Orient and fasten two drawer bottom supports (N) to the drawer back panel (J) with four 32mm screws (H9).
6.2. Complete the process two times for the other drawer.
K
x 2
J
L
H9
The cam lock holes face outward.
(H9) x 8
M4 x 32mm screw
H9
NOTE: DO NOT use power tools.
N
N
12

7.1. Slide the drawer bottom panels (M) into the grooves on the drawer side panels (K and L) until fully inserted into the drawer back panels (J).
step 7: install drawer bottom panels
M
N
x 2
J
K
L
N
13

step 8: attach the drawer front panels
8.1. Insert one small wood dowel (H4) into the inner hole on each drawer side panel (K and L).
8.2. Position the upper drawer front panel (H) onto the inserted wood dowels and fasten it into place by engaging eight small cam locks (H2).
8.3. Repeat the same process with the lower drawer front panel (I).
H
K
I
H2
H2
(H4) x 4
M6 x 30 mm wood dowel
(H2) x 16
small cam lock
H4
K
L L
N
N
N
N
14
H4

9.1. Orient and attach the handle (H11) to the front side of each drawer front panel (H and I) with two 18mm bolts.
step 9: install the drawer handle
H12
H11
I
(H11) x 2
handle
(H12) x 4
M4 x 18mm bolt
H12
H11
H
15

10.1. Orient and fasten one panel reinforcement (R) to the top panel (A) with four 32mm screws (H9), using the pilot holes as a guide.
10.2. Repeat the same process for the fixed shelf (E).
step 10: attach panel reinforcements
A
E
H9
16
NOTE: DO NOT use power tools.
(H9) x 8
M4 x 32mm screw
H9
H9
H9
H9
H9
R
R
16
The countersunk
holes face upward.

11.1. Securely screw the cam bolts into the designated small holes on the top panel (A) and bottom panel (F).
step 11: prepare top panel and fixed shelf assembly
H3
H3
H3
(H3) x 16
cam bolt
H3
H3
H3
A
F
17

12.1. Securely screw the cam bolts (H3) into the designated small holes on both side panels (B and C).
step 12: prepare side panel assembly
H3
H3
H3
(H3) x 12
cam bolt H3
H3
H3
B
C
18

13.1. Insert two large wood dowels (H5) into the left inner holes on the fixed shelf (E) and attach it to the left side panel (B) by engaging two large cam locks (H1)
as shown.
step 13: attach fixed shelf
E
H1
B
(H1) x 2
large cam lock
(H5) x 2
M8 x 30 mm wood dowel
H5
19
The reinforcement faces downward
and is located at front of the unit.

14.1. Attach one back panel (G) to the left side panel (B) using four cam locks (H1) and three large wood dowels (H5).
step 14: attach one back panel
G
H1
B
(H1) x 4
large cam lock
(H5) x 3
M8 x 30 mm wood dowel
H5
20
The cam locks face outward.
