Threshold STUDIO McGEE Marvale End Table TGT20ATB User manual

>> Assembly instructions
TM
© 2023 Target. The Bullseye Design is a trademark of Target Brands, Inc. All rights reserved.
Marvale End Table
Style # TGT20ATB
DPC-item #: 249-17-1694

2
Congratulations on your latest Target purchase.
Now what? Don’t start sweating over this box of parts. This will be easy. We did the hard work for you.
All you need to do is follow our simple instructions and you’ll be on your way to transforming your room in no time.
Good luck – though we’re confident you won’t need it.
before you begin
1. Check for damaged or missing parts. Call 1-855-MYTGTHOME (855-698-4846) to order missing supplies.
2. Use the carton as a work surface to prevent product damage during assembly.
3. Gather all tools prior to assembly.
tools needed
Hex wrench
Questions? Just call 1-855-MYTGTHOME (855-698-4846) for parts and service. For faster service, have the style number and DPCI number ready when calling.

hardware
(H4) x 1
hex wrench
(H1) x 12
1/4” x 13 mm bolt
(H2) x 4
lock washer
(H3) x 4
flat washer
Spare hardware
3

ITEM DESCRIPTION QTY
ATable top 1
BLeg 4
CMetal stretcher 4
C
B
A
exploded diagram
B
B
B
C
C
C
4

1.1. Lay the table top (A) upside down on a level and protected surface.
1.2. Orient and attach two legs (B) to the table top (A) with two 13 mm bolts (H1), two lock washers (H2) and two flat washers (H3).
step 1: attach two legs to table top
H3
H1
H2
B
A
NOTE: DO NOT fully tighten all bolts
until you finish assembling all parts.
Once assembled, go back and fully
tighten all bolts. This will make the
assembly easier.
(H4) x 1
hex wrench
(H1) x 2
1/4” x 13 mm bolt
(H2) x 2
lock washer
(H3) x 2
flat washer
5
H1
H2
H3
B

x 2
step 2: attach metal stretchers to another two legs
2.1. Orient and fit two metal stretchers (C) onto the U-shaped brackets on one leg (B) and secure them into place with two 13 mm bolts (H1).
2.2. Repeat the same process to assemble another leg.
NOTE: DO NOT fully tighten all bolts
until you finish assembling all parts.
Once assembled, go back and fully
tighten all bolts. This will make the
assembly easier.
H1
B
C
B
C
6
C
B
C
H1
H1
(H1) x 4
1/4” x 13 mm bolt

step 3: attach one leg assembly to the previous assembly
3.1. Align and attach the assembled metal stretchers (C) to the assembled two legs (B) with two 13 mm bolts (H1) as shown.
3.2. Insert one 13 mm bolt (H1) with the washer(H2 and H3) through the metal bracket on the top panel (A) and screw into the leg (B).
(H4) x 1
hex wrench
(H1) x 3
1/4” x 13 mm bolt
(H2) x 1
lock washer
(H3) x 1
flat washer
NOTE: DO NOT fully tighten all bolts
until you finish assembling all parts.
Once assembled, go back and fully
tighten all bolts. This will make the
assembly easier.
7
B
C
C
BB
A
H1
H2
H3
A
B
H1
B
BC
C

8
step 4: attach the remaining leg and metal stretchers
4.1. Repeat the same process to attach the remaining leg (B) with metal stretchers (C).
4.2. Now, go back and securely tighten all the bolts. Make sure all the parts are tight and there are no gaps between the parts. This will keep the unit square.
(H4) x 1
hex wrench
(H1) x 3
1/4” x 13 mm bolt
(H2) x 1
lock washer
(H3) x 1
flat washer
NOTE: DO NOT fully tighten all bolts
until you finish assembling all parts.
Once assembled, go back and fully
tighten all bolts. This will make the
assembly easier.
B
C
C
B
B
AA
B
H1
H2
H3
H1
B
C
B
C
