Threshold TGT15FC User manual

>> Assembly instructions
TM
© 2022 Target. The Bullseye Design is a trademark of Target Brands, Inc. All rights reserved.
2-Drawer File Cabinet
Style # TGT15FC
DPC-item #: 081-07-7161

2
Congratulations on your latest Target purchase.
Now what? Don’t start sweating over this box of parts. This will be easy. We did the hard work for you.
All you need to do is follow our simple instructions and you’ll be on your way to transforming your room in no time.
Good luck – though we’re confident you won’t need it.
before you begin
1. Check for damaged or missing parts. Call 1-855-MYTGTHOME (855-698-4846) to order missing supplies.
2. Use the carton as a work surface to prevent product damage during assembly.
3. Gather all tools prior to assembly.
tool needed (only hex wrench included)
For tipping restraint hardware kit only.
Phillips head
screwdriver
Hex wrench

hardware
(H1) x 18
large cam lock
(H2) x 8
small cam lock
(H3) x 26
cam bolt
(H4) x 8
M6 x 30 mm wood dowel
(H5) x 18
M8 x 30 mm wood dowel
(H6) x 8
1/4” x 45 mm bolt (H7) x 8
lock washer
(H10) x 4
22 mm handle bolt
(H9) x 8
M4 x 32 mm screw
(H8) x 8
flat washer
3
(H11) x 2
handle (H12) x 1
hex wrench
(H13) x 1
tipping restraint hardware kit
(inside plastic bag)
Spare hardware

4
exploded diagram
E
D
A
C
L
B
F
N
M
G
H
O
K
I
J
Q
R
Q
R
S
S
P
ITEM DESCRIPTION QTY
A Top panel 1
B Left side panel 1
C Right side panel 1
D Back panel 1
E Bottom panel 1
F Utility drawer front panel 1
G Utility drawer back panel 1
H Utility drawer left side panel 1
I Utility drawer right side panel 1
J Utility drawer bottom panel 1
K Front crossbar 1
L File drawer front panel 1
M File drawer back panel 1
N File drawer left side panel 1
O File drawer right side panel 1
P File drawer bottom panel 1
Q Guide rail 2
R File hanger 2
S Foot 4
S
S

how to use the cam lock system
1. 2. 3.
4. 5.
1. 2. 3.
Screw cam bolt into panel Push cam into panel - arrow
feature on cam top points to
panel edge
Align cam bolt(s) with cam(s)
and insert all the way into
cross-bored hole(s)
Rotate cam(s) clockwise
190°-230° to lock panels
together
Panels should be tight against
each other and connection
should be rigid
190°-230°
5

6
step 1: prepare drawers assembly
1.1. Securely screw the cam bolts (H3) into the designated small holes on the drawer front panels (F and L).
F
L
(H3) x 8
cam bolt
H3
H3
H3
H3
H3
H3
NOTE: Screw-in cam bolts must be
screwed down flush.
NOTE: Screw-in cam bolts must be
screwed down flush.

7
2.1. Attach the utility drawer side panels (H and I) to the utility drawer front panel (F) with four small cam locks (H2).
step 2: attach the utility drawer side panels
H
F
I
The grooves line up with
each other and face inward
(H2) x 4
small cam lock
H2
H2

step 3: install the utility drawer bottom panel
8
3.1. Slide the utility drawer bottom panel (J) into the grooves between the drawer side panels (H and I) until fully inserted into the groove of the drawer front
panel (F).
J
I
H
F

step 4: fasten the utility drawer back panel
4.1. Fasten the utility drawer back panel (G) to both utility drawer side panels (H and I) with four 32 mm screws (H9).
G
I
H
J
(H9) x 4
M4 x 32 mm screw
H9
H9
NOTE: Make sure that the drawer
bottom panel (J) fits securely into the
groove of the drawer back panel (G).
DO NOT use power tools.
9

step 5: install the utility drawer handle
10
5.1. Fasten one handle (H11) to the front side of the utility drawer front panel (F) with two 22 mm handle bolts (H10).
(H10) x 2
22 mm handle bolt
F
(H11) x 1
handle
H10
H10
H11

step 6: attach the file drawer side panels
6.1. Insert four small wood dowels (H4) into the inner holes of the file drawer back panel (M) at both ends.
6.2. Align and attach the file drawer side panels (N and O) to the file drawer back panel (M) with four 32 mm screws (H9).
(H4) x 4
M6 x 30 mm wood dowel
(H9) x 4
M4 x 32 mm screw N
O
M
H4
H4
H9
H9
NOTE: DO NOT use power tools.
11
The grooves line up with
each other and face inward
FINAL
13

step 7: install the file drawer bottom panel
12
7.1. Slide the file drawer bottom panel (P) into the grooves between the drawer side panels (N and O) until fully inserted into the groove of the drawer back
panel (M).
M
N
O
P

step 8: attach the file drawer front panel
8.1. Insert four small wood dowels (H4) into the inner holes on the two file drawer side panels (N and O).
8.2. Align and attach the file drawer front panel (L) to the file drawer side panels (N and O) with four small cam bolts (H2).
(H2) x 4
small cam bolt
(H4) x 4
M6 x 30 mm wood dowel
N
O
L
H4
H4
H2
H2
13

step 9: install the file drawer handle
14
(H10) x 2
22 mm handle bolt
(H11) x 1
handle
9.1. Fasten the other handle (H11) to the front side of the file drawer front panel (L) with two 22 mm handle bolts (H10).
H11
H10
H10
L

step 10: position the guide rails and file hangers
10.1. Position the guide rails (Q) onto the file drawer side panels (N and O) with the high side facing inward.
10.2. Hook the guide blocks of the file hangers (R) onto the high edge of the guide rails (Q). Slide the file hanger forward and backward to keep hanging files
organized.
N
O
R
R
15
Q
Q

step 11: attach the feet
16
11.1. Attach four feet (S) to the bottom corners of the bottom panel (E) with eight 45 mm bolts (H6), eight lock washers (H7) and eight flat washers (H8).
(H6) x 8
1/4” x 45 mm bolt (H7) x 8
lock washer
(H8) x 8
flat washer E
S
S
S
S
S
E
H6
H7
H8
NOTE: DO NOT fully tighten all the
bolts until you adjusted to even all
the feet.
(H12) x 1
hex wrench

step 12: prepare top panel and base assembly
A
E
(H3) x 12
cam bolt
H3
12.1. Securely screw the cam bolts (H3) into the designated small holes on the top panel (A) and bottom panel (E).
17
H3
H3
H3
H3
H3
H3
H3
NOTE: Screw-in cam bolts must be
screwed down flush.

step 13: prepare side panels assembly
13.1. Securely screw the cam bolts (H3) into the designated small holes on the side panels (B and C).
(H3) x 6
cam bolt
B
C
H3
H3
H3
H3
H3
H3
18
NOTE: Screw-in cam bolts must be
screwed down flush.

step 14: install file cabinet frame
14.1. Insert four large wood dowels (H5) into the inner holes of the back panel (D) at both long ends.
14.2. Align and attach the left side panel (B) to the back panel (D) by engaging two large cam locks (H1).
14.3. Insert one large wood dowel (H5) into the end hole of front crossbar (K) and attach it to the left side panel (B) using one large cam lock (H1).
14.4. Repeat the same process to install the right side panel (C).
(H1) x 6
large cam lock
(H5) x 6
M8 x 30 mm wood dowel
B
C
D
K
K
H1
H5
B C
/
19
The cam lock will face the floor
when the unit is turned upright

step 15: attach the top panel
20
15.1. Insert six large wood dowels (H5) into the top inner holes on both side panels (B and C) and the back panel (D).
15.2. Align and attach the top panel (A) to both side panels (B and C) and the back panel (D) by engaging six large cam locks (H1).
(H1) x 6
large cam lock
(H5) x 6
M8 x 30 mm wood dowel
A
B
C
B
C
A
H5
H1
D
D
