Tiso JETPAN User manual

1
"TiSO-PRODUCTION" LTD
WAIST-HIGH TURNSTILE
JETPAN
OPERATION MANUAL
AUIA.168 OM (rev.1)
2018

2
CONTENTS
INTRODUCTION................................................................................................................................3
1. DESCRIPTION AND OPERATION...............................................................................................6
1.1 General Information and Designation .....................................................................................6
1.2 Specifications...........................................................................................................................8
1.3 Configuration and Scope of Delivery......................................................................................8
1.4 Design and operation.............................................................................................................12
1.5 Instrumentation, tools and accessories ..................................................................................14
1.6 Description and operation of controllers as integral component of the turnstile...................14
2 INTENDED USE............................................................................................................................21
2.1 Operation restrictions ............................................................................................................21
2.2 Layout and installation ..........................................................................................................21
2.3 Turnstile preparation for use..................................................................................................30
2.4 Contingency actions ..............................................................................................................32
3 MAINTENANCE............................................................................................................................33
3.1 General guidelines.................................................................................................................33
3.2 Safety Measures.....................................................................................................................33
3.3 Maintenance procedure..........................................................................................................33
4 ROUTINE MAINTENANCE.........................................................................................................34
4.1 General guidelines.................................................................................................................34
4.2 Possible malfunctions............................................................................................................34
4.3. «JETPAN-1» turnstile blade initialization procedure ..........................................................35
4.4 Postrepair checkout................................................................................................................37
5 TRANSPORTATION AND STORAGE........................................................................................37
5.1 Turnstile storage....................................................................................................................37
5.2 Turnstile transportation..........................................................................................................38
6 DISPOSAL......................................................................................................................................38
7 MANUFACTURER'S WARRANTY AND TERMS OF WARRANTY MEAINTENANCE......38
Annex А Overall and installation dimensions of the “«JETPAN-1» type turnstile...........................40
Annex B Control desk and connection diagram.................................................................................42
Continued Annex B Control panel and connection diagram..............................................................43
Annex C.1 Wiring diagram of the «JETPAN» type turnstile ............................................................44
Annex D.1 Diagram of the turnstile connection to access control system (ACS) .............................45
Annex D.2 Diagram of the turnstile connection to access control system (ACS) .............................46
Annex D.3 Diagram of the turnstile connection to fire alarm (FA)...................................................47
Annex D.4 Diagram of the turnstile connection to control panel ......................................................48

3
INTRODUCTION
This Operation Manual (hereinafter referred to as OM) covers the servo-operated «JETPAN»
type waist-high turnstile (hereinafter referred to as the "turnstile"). The Operation Manual contains
information about design, specifications, installation for proper operation and maintenance of the
turnstile.
This Operation Manual is prepared in compliance with the specification requirements
ТU U 28.9-32421280-005:2018.
The turnstile shall be serviced only by the qualified staff having the relevant class of permit to
work with electrical facilities with voltage up to 1000V and scrutinizing this Operation Manual,
obtaining safety instructions and trained for operation and maintenance of the turnstile.
Reliability and durability of the turnstile operation are provided with observation of modes
and conditions of transportation, storage, installation and operation. So, fulfillment of all
requirements specified in this document is mandatory.
The turnstile «JETPAN» can be installed either singly or in line. The single turnstile includes
two cabinets (left-hand and right-hand), each of which has one glass blade.
The turnstile row is provided by installation one more or a number of additional cabinets
equipped with glass blades from both sides reducing costs and saving space.
Depending on the purpose and design features of the turnstile, the following pattern of
reference designation is accepted:
T3. KCD.  X.  /  / 
Leaf for access way width (pedestrian gate MASTER)
500
Leaf for access way width (pedestrian gate SLAVE)
500
Turnstile configuration:
X Jetpan-2 (two-leaf auxiliary cabinet)
_ Jetpan-1(kit of two one-leaf cabinets)
K Reciprocating mechanism
РPolished stainless steel
S Brushed stainless steel
K Painted housing
КСD Pedestrian gate with servomotor
Double-leaf
Т3 Floor-standing waist-high turnstile

4
Turnstile «JETPAN-1» - set of two pedestrian gates Master and Slave: - identification order code
T3.KCD.PK _/500 / 500
Turnstile «JETPAN-2» - one two-leaf pedestrian gate Master/Slave: - identification order code
T3.KCD.PK. X / 500 / 500
Fig. 1 –Definition of the turnstile component description
Example of reference designation of the single turnstile «JETPAN-1» consisting of Master
and Slave pedestrian gates made of brushed stainless steel:
The turnstile T3.КСD.SK ТU U 28.9-32421280-005:2018
Example of reference designation of the double turnstile «JETPAN-2» consisting of one
consisting of servo-operated Master/Slave pedestrian gate made of polished stainless steel
The turnstile T3.КСD.РK.X ТU U 28.9-32421280-005:2018
Due to regular improvement of the product its design can be modified without degradation
of the product features and quality not covered by this Operation Manual.
.

5
WARNINGS TO THE CUSTOMER ON SAFE OPERATION
OF THE TURNSTILE
These warnings are designed for ensuring of safety during operation of the turnstile to prevent
violation of safety characteristics by improper installation or operation. These warnings are aimed at
drawing attention of the customer to safety problems.
.
GENERAL WARNINGS
The Operation Manual is an integral part of the product and it should be handed over to the
customer. The OM should be kept for later use and consulted for clarifications if required. If the
turnstile is resold, handed over to another owner or transported to another place, make sure that
the OM is enclosed to the turnstile to be used by new owner and/or maintenance staff during
installation and/or operation.
Safety measures and requirements specified in this in this OM must be observed:
–the turnstile must be connected to ground loop prior to operation;
–the turnstile should be connected to AC network with parameters specified in p.1.2
"Specifications";
–inspection, adjustment and repair should be performed only after the turnstile is
deenergized.
After the turnstile is purchased it should be unpacked and its integrity should be checked. In
case of doubt in integrity of the turnstile it should not be used and the customer shall refer to the
supplier or to the manufacturer.
Packing accessories (wooden pallet, nails, clips, polyethylene bags, cardboard etc.) as
potential sources of hazard must be removed to unacceptable place prior to proper use of the
turnstile.
As electric shock protection device the turnstile is related to 01 protection class according to
the GOST (State Standard) 12.2.007.0-75 and is not intended for operation in explosive and fire-
hazardous areas by the “Electrical Installation Code”.
Using of the turnstile for unintended purpose, improper installation, nonobservance of
conditions of transportation, storage, installation and operation specified by this OM, may result in
damage to people, animals or property for which the manufacturer is not responsible.

6
1. DESCRIPTION AND OPERATION
1.1 General Information and Designation
1.1.1 Purpose:
The motorized turnstile is designed for pedestrian movement control at access points of
industrial enterprises, banks, stadiums, administrative facilities etc. by access control system (from
magnetic card readers) or manually (from manual control panel).
Traffic flow capacity of the turnstile with personal identification is at least 30 persons per
minute in one direction.
1.1.2 Dimensions and weight of the turnstile correspond to the values specified in Table 1
Dimensions of turnstile group - Table 1
Designation of turnstile
modification type
Access
way
width
Dimensions, mm
Max.
weight,
kg
H
L
B
Т3.КСD.XK_/500/500
500
1522 /
1800** (HG)
1080
1000 (1006*)
211
Т3.КСD.XK_/500/500
500+500
1870
345
When the turnstile with more than two access ways is ordered:
Ltotal = 790 · s + b
where s –number of 500 mm access ways «stаndard»;
b- lid width 290 mm;
Example of calculation of size Ltotal for double turnstile = 790 · 1 + 790 · 1 + 290 = 1870 mm (See Fig 2
Fig. 2 –Dimensions of turnstile group
* Overall dimension for the turnstile with glass countertop
** Overall dimension for the turnstile with high glass panel (Jetpan-HG 1800)

7
1.1.3 The turnstile component identification codes are specified in Table 2.
Overall dimensions of cabinet - Table 2
Description of the
turnstile component
Order code
Dimensions, mm
Max.
weight,
kg
Н
L
В
JETPAN-1
Т3.КСD.XK
1522
290
1000
(1006*)
100
JETPAN-2
Т3.КСD.XK
130
JETPAN-1 HG
Т3.КСD.XK.X
1800
105
JETPAN-2 HG
Т3.КСD.XK.X
134
* Overall dimension for the turnstile with glass countertop
Fig. 3 –Overall dimensions of the turnstile cabinet
1.1.4 The operation condition parameters according to GOST 15150-69 are specified in
Table 3.
Table 3
Operation conditions
For climatic
modification
Parameter value
1
2
3
Ambient air temperature
NF4
+1°С to +40°С
Relative air humidity
80% at +20ºС
Ambient air allowable pressure
84 to 106,7 kPa
Transportation temperature range
- 40°С to + 50°С
Storage temperature range
+ 5to + 40°С
Structural design category
L3

8
Continued Table 3
1
2
3
Altitude above sea level
up to 2000m
Environment
Explosion-proof, does not contain
current-conducting dust, aggressive
gases and vapours in concentration
destroying isolation and metals,
disturbing normal operation of the
equipment installed in turnstiles
Installation site
In enclosed spaces in the absence of
direct impact of precipitations and solar
radiation
Operating position
Vertical, deviation from vertical
position no more than 1º to any side is
allowed
1.1.5 Reliability indices:
−mean time to repair (without delivery time of spare parts, tools and accessories) – at
most 6 hours;
−mean time to failure – at least 1 500 000 accesses;
−mean service life between overhauls – at least 10 years
1.2 Specifications
Key parameters of the turnstile are specified in Table 4. Table 4
Parameter description
Unit measure
Parameter
value
Traffic flow capacity in free access mode, at least
man/min.
30
Opening/closing time
s
0,8
Maximum access way width
mm
500
Power supply voltage
–AC power supply (primary)
V
Hz
~ 100  240
50/60
–DC power supply (secondary)
V
12
Maximum power consumption
W
155
Index of protection according to EN 60529
-
IP41
1.3 Configuration and Scope of Delivery
1.3.1 The turnstile modification depends on the number of access ways:
1) For arrangement of single access way the turnstile «JETPAN-1» " is a set of two similar in
design pedestrian gates (Master and Slave) with one each of which has one glass leaf (reference
designation Т3.КСD.ХK))

9
2) For arrangement of two or more access ways the turnstile «JETPAN-1» is a set of two one-
leaf pedestrian gates (reference designation Т3.КСD.ХK) (Fig.1 b) and one or more auxiliary
pedestrian gate «JETPAN-2» (Master/Slave)with one each of which has two glass leaf (reference
designation Т3.КСD.ХK.Х).
1.3.2 Design of the single «JETPAN-1» type turnstile
1
2
8
3
5
6
7
4
109
1 – location for card reader;
2 – LED display;
3 – IR access sensors;
4 – Glass panel (leaf);
5 - Jumper (Fixed glass)
6 – Lid (or glass countertop);
7 – End panel;
8 – Base;
9 – Side panel (front and rear);
10 – Turnstile operating mechanism;
Fig. 4 –Design of the single turnstile «JETPAN-1»

10
The single turnstile «JETPAN-1» (See Fig.4) consists of two one-leaf cabinets.
One-leaf cabinet body includes:
–frame;
–base;
–set of side panels;
–top lids;
–retractable device with glass leaf;
–glass partitions;
–two LED displays.
Inside cabinet there are installed:
–terminal block;
–controller;
–seven access sensors;
–proximity identification card reader (to be equipped by the customer, if appropriate);
–power supply unit.
The cabinet design provides a space for installation of proximity identification card reader.
Cabinet has built-in components:
− controllers;
− power supply unit.
Optionally cabinet can be completed with battery* (4 А·h). The single turnstile control
desk equipped with power supply unit, circuit breaker and battery* is installed only in the cabinet
(Master) from the protected area side.
1.3.3 Design of the «JETPAN-2» type turnstile (See Fig.5).
The turnstile is an additional cabinet «JETPAN-2» (Master/Slave) with two leaves (glass
panels). The number of additional cabinets is specified in order.
The turnstile «JETPAN-2» operates only as part of the turnstile “JETPAN-1”. The additional
cabinet includes:
–base;
–set of side panels;
–top lid;
–two retractable devices with retractable glass leaves;
–glass partition;
–four LED displays.
Inside the additional cabinet body there are installed:
–terminal blocks;
–controllers;
–fourteen access sensors;
–two proximity identification card readers;
–power supply unit.
Optionally additional cabinet can be completed with battery*.

11
1
2
8
3
5
6
7
4
10
9
1 – location for card reader;
2 – LED display;
3 – IR access sensors;
4 – Glass panel (leaf);
5 - Jumper (Fixed glass);
6 – Lid (or glass countertop);
7 – End panel;
8 – Base;
9 – Side panel (front and rear);
10 – Turnstile operating mechanism
Fig. 5 –Design of the turnstile «JETPAN-2» Т3.КСD.ХK.X
1.3.4 Design, overall and installation dimensions of the turnstile are shown in Annex A.

12
1.3.5 The turnstile material of manufacture is carbon steel subject to painting, brushed
stainless steel or polished stainless steel.
1.3.6 Turnstile scope of delivery
The turnstile is delivered as a kit (set of pedestrian gates depending on the number of access
ways).
The turnstile is delivered by one or a number of packages (depending on the order).
1.4 Design and operation
1.4.1 Turnstile design
1.4.1.1 The cabinet body is a set of side panels (9) from stainless steel (See Fig.4-5), which
are securely fixed to frame and installed on base (8). A decorative lid (6) is mounted on the top of
frame (finishing material is determined by order). An additional vertical partition (5) with 10 mm
tempered safety glass is mounted in the center of body to prevent unauthorized intrusion along the
upper horizontal surface of the body.
Fig. 6 - Turnstile status display
1.4.1.2 The turnstile status (Fig.6) is displayed by LED display (4) installed in the cabinet
frame. Constantly lit blue LED means initial state of the turnstile. In case of attempt of
unauthorized access red LED starts blinking and sound signal is generated on control desk. When
opening command is issued, LED is changed to green from the side of authorized access. If
unauthorized access is attempted when glass leaves (10) are opened, then the leaves will be closed,
if there is no any obstacle in the leaves movement area.
1.4.1.3 Seven infrared sensors (3), installed on side panels of the turnstile from access side,
are designed for detection of the turnstile access, preventing closing of leaves during pedestrian
access in immediate proximity to them and minimizing personal injury during the turnstile access.
1.4.1.4 Leaf 1 is made from 10 mm tempered glass and is located in the middle of the cabinet
body on motion mechanism (1). Each leaf is actuated by separate servomotor. The additional
cabinet «JETPAN-2» is equipped with two servomotors (one per each leaf), while the «JETPAN-
1» turnstile cabinets are equipped with one servomotor per each cabinet.
1.4.1.5 In case of 230 V power supply failure the turnstile panels will be released and will
remain in the position in which they were and the turnstile operation will be maintained from
battery (if it is installed) until it is discharged.
1.4.1.6 The cabinet operating mechanism (Fig.4) provides reliable mechanical locking of
leaf in the end travel points due to tooth-belt drive.
Inside the turnstile body the panels are fixed to frame, on which controllers, power supply
unit, battery and terminal blocks to be connected to 230V mains and control devices are installed.
1.4.1.7 The controllers РСВ.201.01.00.00 control the turnstile motors analyzing signals from
speed and position sensors and provide motor overload protection. The controllers
PCB206.21.20.00 analyze infrared sensors, receive control commands from peripherals (control

13
panel , ACS etc.), control LED displays and generate feedback signals for ACS (More detailed
description of the turnstile controller is given in chapter 1.6).
1.4.1.8 Control panel has the following functions: single entry and single exit, locking of
entry and exit, free entry and exit.
1.4.2 General appearance of the turnstile operating mechanism and control desk
Fig.7–General appearance of and design of operating mechanism and control desk of the
turnstile «JETPAN-1» (Master cabinet)
Legend:
1 –pulley;
2 –magnetic sensor;
3 –crank;
4 –tensioning roller;
5 –tooth belt;
6 –drive;
7 –glassholder;
8 –bracket retainer;
9 –retractable glass;
10 –retractable
device rack
11 –tensioner cramp;
12 –balancing spring
13 –frame base;

14
1.4.3 3 Principle of operation
1.4.3.1 Access cycle:
1. In the initial state the turnstile glass blades are located perpendicular to the body block
access.
2. The turnstile is opened for access in the direction "А" or "В" after the appropriate
command from ACS or control panel is issued.
3. Green arrow is lit on LED display and glass blades go fully to slots, i.e. they open. A
pedestrian is able to access through the turnstile freely.
4.After pedestrian exit from control area, the "closed" mode is set until next access. Blue LED
is lit. Blades are reliably closed preventing attempts of unauthorized access.
More detailed description of the turnstile operation modes is given in section 1.6 "Description
and operation of controller as an integral component of the turnstile".
1.4.3.2 12V DC power voltage is provided by power supply unit.
1.4.3.3 In case of mains power supply failure, the turnstile is automatically switched to power
supply from 12V, 7A•h battery (optional), which ensures the turnstile's operation within 2 hours.
1.4.3.4 The turnstile wiring and connection diagrams are shown in Annex C.
1.5 Instrumentation, tools and accessories
Dedicated tools are not required for the turnstile installation (multi-purpose measurement
instrumentation and installation tools are sufficient).
1.6 Description and operation of controllers as integral component of the turnstile
1.6.1 Controller AUIA.206.21.20.00
1.6.1.1 Appearance of controller AUIA.206.21.20.00 is shown in Figure 8.
1.6.1.2 Description of operation
The controller provides algorithm of operation of the whole turnstile. It is assembled on the
120 х 80 mm size card from foil-clad textile laminate, on which electronic components and
terminals for connection to other turnstile units as well as for connection to control peripherals
(ACS, control panel etc.) are located.
The controller generates signal for 7 infrared transmitters and picks up signal from 7 infrared
receivers that enables to detect human (or object) presence in the turnstile access area with high
probability. Furthermore, the controller AUIA.206.21.20.00 controls light and sound indication,
receives commands from control panel using interface RS-485, picks up commands and generates
report signals for ACS via signal inputs and outputs as well as controls operation of motor
controllers (РВС.201.01.00.00).
The controller and therefore the turnstile can be in the following modes:
•"INITIAL STATE".
•"SINGLE ACCESS IN THE DIRECTION А".
•"SINGLE ACCESS IN THE DIRECTION B".
•"SINGLE ACCESS IN BOTH DIRECTIONS".
•"FREE ACCESS IN THE DIRECTION А".

15
•"FREE ACCESS IN THE DIRECTION B".
•"FREE ACCESS IN BOTH DIRECTIONS".
•"LOCK OF ACCESS IN THE DIRECTION А".
•"LOCK OF ACCESS IN THE DIRECTION B".
•"LOCK OF ACCESS IN BOTH DIRECTIONS".
•«"ALARM".
"INITIAL STATE"
The turnstile is in this mode during energization and after completion of the turnstile access, if
during access the mode is not changed to "LOCK", "FREE" or "ALARM". In this mode red LED is
constantly lit on both LED boards, sound indication is OFF, access is locked by blades.
"SINGLE ACCESS"
The turnstile goes to this mode when command "SINGLE ACCESS A/B" comes from control
panel via interface RS-485 or when signal inputs "INP1" ("ACCESS А TO BE OPENED") or/and
"INP2" ("ACCESS B TO BE OPENED") are closed on common wire (terminal "GND"). In this
case if command comes via interface RS-485, the access start waiting time is 5 sec. and when signal
inputs are short circuited the turnstile will wait for access start while input is closed. Green arrow is
lit on LED display from the side of authorized access and red cross is lit from the side of denied
access. Glass blades go to cabinet slots clearing access. Pedestrian is able to access through the
turnstile. If access start time is up and access is not started (the first IR barrier in the direction of
movement was not locked), the turnstile returns to "INITIAL STATE". If within the above time
period access is started, controller generates the signal "ACCESS IS OCCUPIED" (outputs "OUT1"
or/and "OUT2") and starts tracing position and direction of pedestrian movement in the turnstile
access way, analyzing 6 IR barriers. As soon as pedestrian is behind the blades line they close, the
controller generates the signal "DETECTION OF ACCESS" of 0,3 second duration (outputs
"OUT3" or "OUT4") and LED display is switched from green to red. After the pedestrian turnstile
access the controller removes the signal "ACCESS IS OCCUPIED" and returns to "INITIAL
STATE".
"FREE ACCESS"
The turnstile goes to this mode either upon command "FREE ACCESS А/В" arrived via
interface RS- 485 from control panel or if during "SINGLE ACCESS" initiated by signal on input
"INP1" ("ACCESS А TO BE OPENED") or/and "INP2" ("ACCESS B TO BE OPENED") at the
end of 0,3 sec. after the signal "DETECTION OF ACCESS А" or "DETECTION OF ACCESS B"
is removed by controller, the signal on the relevant input "INP1" or "INP2" was not removed. In
this mode glass blades go to the turnstile cabinet slots, green arrow is blinking on LED display from
the side of authorized access. Thus every turnstile access is traced and the signal "DETECTION OF
ACCESS" of 0,3 second duration is generated to the relevant output («OUT3» or "OUT4").
In this state the turnstile will be until arrival of command "CANCELLATION OF FREE
ACCESS" via interface RS-485 or until removal of signals from "INP1" or/and "INP2" depending
on the cause of switching to the free access mode.
"LOCK OF ACCESS"
The turnstile switches to this mode only upon command "LOCK OF ACCESS А/В" arrived
via interface RS-485 from control panel.
Thus red LED is blinking from the side of locked access, glass blades are closed (if the
turnstile is not open for free or single access from opposite side), controller does not respond to
signals of inputs "INP1" ("ACCESS А TO BE OPENED") or/and «INP2» ("ACCESS B TO BE
OPENED") respectively.

16
The lock mode prevails over single and free access mode. It means that access can be locked
at any time, thus, if within the blade closing area there is no any obstacle they will be closed. The
controller will be in this mode until arrival of command "CANCELLATION OF ACCESS LOCK"
via interface RS-485 from control panel.
Fig. 8 –Appearance and configuration of controller AUIA.206.21.20.00
"ALARM"
The turnstile switches to this mode from any above mentioned mode in case of unauthorized
access attempts. In this case red LED is frequently blinking (4 times per second), siren alarm is
generated on control panel and output "OUT5" is activated on the controller board. If the turnstile
was opened, then blades would be closed if there were no obstacles in the closing area. The turnstile
will return to the mode preceding the "ALARM" mode as soon as causes of this mode disappear. In
this case the output "OUT5" will go to passive state, siren alarms on control panel will be off and
blades and light indication will be set according to the current mode.
The purpose of the controller contacts intended for connection to peripherals is specified in
Table 5.
1 - ON - when command is issued, the turnstile will
open for 5 seconds;
-OFF - when command is issued, the turnstile will
open for the time set in ACS;
2 - ON - Outputs OUT1-5 will be NC;
- OFF - Outputs OUT1-5 will be NO;
3 - 5 - Not usable;
6 - Free access mode setting when blades are normally
closed is possible by closing IN1 and IN2. Signal on
IN1 or IN2 must be more than 6500 ms to set free
access;
- ON - Activation of free access mode when blades
are normally closed;
- OFF - Deactivation of free access mode when blades
are normally closed;
7 - ON - Activation of free access mode A when blades
are normally closed;
Blades will be open when the first IR sensor is
crossed;
- OFF - Deactivation of free access mode A when
blades are normally closed;
Blades will be open all the time;
8 - ON - Activation of free access mode B when blades
are normally closed;
Blades will be open when the first IR sensor is crossed;
- OFF - Deactivation of free access mode B when
blades are normally closed;
Blades will be open all the time;

17
Table 5
№
Connec
tor/cont
act
Description
Directio
n
Designation
Signal description and
parameters
1
2
3
4
5
ХТ4/1
INP1
(«TO BE OPENED
A»)
ENTRY
Command "TO BE
OPENED FOR SINGLE
/ FREE ACCESS"
1) logical «0» (02,2)
V;
2) logical «1» (3 5)
V;
3) active level of
signal (factory setting)
logical «0»
4) voltage on open
input < 5 V
ХТ4/2
INP2
(«TO BE OPENED
B»)
ENTRY
ХТ4/3
INP3
(«PANIC»)
ENTRY
Command "SWITCHING
TO PANIC STATE"
ХТ4/4
INP4
ENTRY
Not applicable
ХТ4/5
INP5
ENTRY
ХТ4/6
INP6
ENTRY
ХТ4/7
GND
COMMON WIRE
ХТ3/1
GND
COMMON WIRE
ХТ3/2
OUT1
(«ACCESS A IS
OCCUPIED»)
EXIT
Signal is generated from
the moment of blocking
of the first IR barrier in
the direction of
movement and is
removed after
cancellation of the latter
1) type of output –
open collector;
2) peak voltage on
privacy key 55V;
3) peak current of
public key 100mA;
4) resistance of public
key (5 7) Ohm;
5) active level of
signal (Factory
setting) –logical «0»
(connection on GND)
ХТ3/3
OUT2
(«ACCESS B IS
OCCUPIED»)
EXIT
ХТ3/4
OUT3
(«DETECTION OF
ACCESS А»)
EXIT
Signal appears during
barring of the second last
IR barrier and continues
0,2 sec.
ХТ3/5
OUT4
(«DETECTION OF
ACCESS В»)
EXIT
ХТ3/6
OUT5 («ALARM»)
EXIT
Output is active in case
of unauthorized access
attempt
ХТ5/1
POW
«+» power supply
1)Power supply
voltage 12V;
2)Consumption
current < 150 mA
ХТ5/2
B1
It is used for data
transmission via serial
port. It is used for
connection of control
panel.
Interface RS-485
ХТ5/3
A1
Interface RS-485
ХТ5/4
GND
COMMON WIRE

18
Continued Table 5
1
2
3
4
5
ХТ1/1
BUZ
Output for connection of
audible alarm. The output
is active in case of
unauthorized access
1) type of output –
open collector;
2) peak voltage on
privacy key 60V;
3) peak current of
public key 250mA;
4) resistance of public
key (0,48640) Ohm;
5) active level of
signal (Factory
setting) –logical «0»
(connection on GND)
ХТ1/2
B2
It is used for data
transmission via serial
port.
Interface RS-485
ХТ1/3
A2
Interface RS-485
ХТ2/1
+ 12V
«+» power supply
(energization of
controller)
1) Power supply
voltage 12V;
2) Consumption
current < 150 mA
ХТ2/2
+ 12V
ХТ2/3
GND (common)
«-» power supply
(common wire)
ХТ2/4
GND (common)

19
1.6.2 Turnstile controller РСВ.201.01.00.00
1.6.2.1 Appearance of controller РСВ.201.01.00.00 is shown in Figure 9.
1.6.2.2 Description of operation
The controller is designed to control DC motor, intended to move the turnstile blades, and
electromagnetic brake installed on motor shaft. Control is performed based on the signals coming
from magnetic sensor as well as from motor current sensor. Control commands come to inputs
"IN1" and "IN2" from the controller AUIA.206.21.20.00.
Fig. 9 – Appearance of controller РСВ.201.01.00.00

20
Table 6
№
Connector
/contact
Descriptio
n
Direction
Designation
Signal description and
parameters
X1/1
IN1
ENTRY
«TO BE OPENED A»
1) logical “0”
(0 1,7) V; 2)
2) logical “1”
(3,7 5) V; 3)
3) active level of signal
–logical “0”;
4) voltage on open input
≤ 5 V
X1/2
IN2
ENTRY
«LOCK»
X1/3
IN3
ENTRY
Not applicable
X1/4
IN4
ENTRY
Not applicable
X1/5
IN5
ENTRY
To be connected to
magnetic sensor
X1/6
IN6
ENTRY
X1/7
IN7
ENTRY
X1/8
IN8
ENTRY
X1/9
GND
“-“ power supply
(common wire)
X1/10
GND
X1/11
GND
X1/12
+5 V
EXIT
Not applicable
X2/1
GRN1
EXIT
Not applicable
X2/2
RED1
EXIT
Not applicable
X2/3
GRN2
EXIT
Not applicable
X2/4
RED2
EXIT
Not applicable
X2/5
-MG1
EXIT
Not applicable
1) type of output –
open collector;
2) peak voltage on
privacy key 50V;
3) peak current of
public key 5A
X2/6
+MG1
EXIT
Not applicable
X2/7
-MG2
EXIT
Not applicable
X2/8
+MG2
EXIT
Not applicable
X2/9
MOT1
EXIT
Connection of motor
1) voltage (10 ÷ 27)V;
2) current ≤ 4 А
X2/10
MOT2
EXIT
X2/11
GND
“-“ power supply
(common wire)
X2/12
+24 V
ENTRY
“+” power supply
(energization of controller)
1) voltage (10 ÷ 27)V;
2) current ≤ 4 А
Х3
Х3
ENTRY/
EXIT
Communication port
1) logical “0” (0 ÷ 1)V;
2) logical “1” (3,5 ÷ 5) V
