Titan Lifts HD2P-15000C Instruction manual

INSTALLATION, OPERATION
& MAINTENANCE MANUAL
FOLLOW THIS MANUAL CAREFULLY TO ENSURE THE EQUIPMENT WILL
FUNCTION CORRECTLY AND PROVIDE MANYYEARS OF DEPENDABLE SERVICE.
FAILURE TO FOLLOW THESE INSTRUCTIONS AND SAFETYWARNINGS MAY
RESULT IN PERSONAL INJURY OR PROPERTY DAMAGE. KEEP THIS MANUAL IN A
SAFE DRY PLACE FOR FUTURE REFERENCE.
MODEL:
HD2P-15000C
15,000 LB CAPACITY 2 POST LIFT
®

Products May Be
Upgraded Without Notice
Please Visit
WWW.TITANLIFTS.COM
For The Latest Version Of
This Manual
P.O. Box 7069 • Greenwood, IN 46142 • Ph. 888-908-4826 • Fx. 317-215-2770 • www.titanlifts.com

CONTENTS
1-SAFETY.......................................................................................................................... 1
1.1 INTRODUCTION .............................................................................................................................1
1.2 SAFETY INSTRUCTIONS FOR COMMISSIONING..........................................................................1
1.3 SAFETY INSTRUCTIONS FOR OPERATION ...................................................................................1
1.4 SAFETY INSTRUCTIONS FOR MAINTENANCE .............................................................................3
1.5 RISKS .............................................................................................................................................3
2-DESCRIPTION ................................................................................................................ 4
3-UNPACKING & SETUP.................................................................................................... 5
3.1 DELIVERY AND CHECK OF PACKAGES..........................................................................................5
3.2 LIFTING AND HANDLING...............................................................................................................5
3.3 PREPARATION ...............................................................................................................................5
4 SPECIFICATIONS ........................................................................................................... 6
5-FLOOR REQUIREMENTS ................................................................................................ 6
5.1 SELECTING THE SITE AREA ..........................................................................................................6
5.2 FLOOR REQUIREMENTS.................................................................................................................6
5.3 IMPORTANT CONCRETE AND ANCHORING INFORMATION.........................................................7
5.4 ANCHORING TIP SHEET ................................................................................................................7
6-INSTALLATION INSTRUCTIONS ................................................................................... 8
7-OPERATION INSTRUCTIONS....................................................................................... 11
7.1 DEFECTS / MALFUNCTIONS........................................................................................................11
7.2 CONTROLS...................................................................................................................................11
7.2.1 UP CONTROL.......................................................................................................................................................................... 11
7.2.2 SAFETY LOCK CONTROL...................................................................................................................................................... 11
7.2.3 LOWERING CONTROL ........................................................................................................................................................... 12
7.3 OPERATION..................................................................................................................................12
8-MAINTENANCE............................................................................................................ 14
8.1 MAINTENANCE SCHEDULE .........................................................................................................14
8.1.1 DAILY ....................................................................................................................................................................................... 14
8.1.2 WEEKLY ................................................................................................................................................................................... 14
8.1.3 MONTHLY................................................................................................................................................................................ 15
8.1.4 BIMONTHLY............................................................................................................................................................................ 15
8.1.5 YEARLY .................................................................................................................................................................................... 15
8.1.6 EVERY OTHER YEAR.............................................................................................................................................................. 15
8.2 MAINTENANCE BY OPERATOR ...................................................................................................16
8.2.1 HYDRAULIC SYSTEM ............................................................................................................................................................ 16
8.2.2 GREASING POINTS................................................................................................................................................................ 16
8.2.3 OPERATION AND WEAR CHECKS ....................................................................................................................................... 17
8.2.4 LIFT STABILITY...................................................................................................................................................................... 17
8.3 CLEANING ....................................................................................................................................17
9-TROUBLESHOOTING ................................................................................................... 18
10-OWNER/EMPLOYER RESPONSIBILITIES .................................................................. 19
11-DIAGRAMS (FIG. 1-9)................................................................................................. 20

PO Box 7069 Greenwood, IN 46142
1.888.908-4826 FAX [phone]
www.titanlifts.com
TITAN MARKETING, LLC
®
To Our Valued Customers:
Thank you for purchasing a Titan Lifts®product. We hope this high quality equipment provides you with years of
dependable service.
It is unfortunate that rare situations may occur with the products you purchase from Titan Lifts®. We value your
business as well as the trust you have and need to maintain your relationship with us. Titan Lifts®carries liability
coverage that may protect our customers if a situation does occur. However, as in all accidents there must be
proof of liability for a claim to be made. Our insurance company requires the following procedures be observed in
order to consider a claim:
A. The claimant must contact the Titan Lifts®distributor immediately with the facts of the situation.
B. If any equipment is damaged, including vehicles or shop equipment, Titan Lifts®must be given the
opportunity to send an impartial representative to the site for proper assessment of the situation.
C. The Vehicle cannot be moved until either an impartial representative has reviewed the accident or clear
and precise pictures are taken that reect all the pertinent information for an impartial representative to be able
to access the information from a distance. Titan Lifts®or its representatives must approve the pictures before
anything can be moved.
D. If any potential liability is determined on behalf of Titan Lifts®, two estimates must be submitted for
damages to be reimbursed.
It is imperative that the claimant complies with these procedures, because without proper assessment of the
situation a claim will be denied.
ARBITRATION NOTICE
The installation or use of this equipment shall constitute an acknowledgement that the user agrees to resolve any
and all disputes or claims of any kind whatsoever, which relate in any way to the equipment, by way of binding
arbitration, not litigation. No suit or legal action may be led in any state or federal court. Any arbitration shall be
governed by the Federal Arbitration Act, and administered by the American Mediation Association, Indianapolis
Indiana. The maximum amount that an arbitrator may award and all damages shall not exceed the retail value of
this equipment.
WARRANTY NOTICE
This equipment must be assembled and used in the manner according to the documentation provided to be
covered by warranty.
Damaged or missing components must be reported within 72 hours of receipt to your freight carrier and to the
distributor. Claims must be led to cover cost.
If you have any questions or if we can be of any further assistance, please don’t hesitate to contact a Titan Lifts®
representative at 1-888-908-4826. Thank you for the opportunity to continue to serve your lift equipment needs.

1
1-SAFETY
INSTRUCTIONS
1.1 INTRODUCTION
• The lift may be installed and commissioned by authorized service personnel only.
• The standard lift version may not be installed and commissioned in the vicinity of
explosives or ammable liquids, outdoors or in moist rooms (e.g. car wash).
• Read this entire manual.
• Load should not exceed rated capacity for this lift –15,000 lbs. (3,750 lb per lift arm)
• Only trained authorized personnel over the age of 18 years should operate the lift.
• Indoor use recommended.
• Always lift the vehicle using all four arms.
• Never use the lift to raise one end or one side of vehicle.
FAILURE TO COMPLY WITH INSTRUCTIONS COULD RESULT IN
PROPERTY DAMAGE.
WARNING: READ ENTIRE MANUAL AND COMPLY WITH ALL SAFETY AND SERVICE
PRECAUTIONS. DEATH, PERSONAL INJURY AND / OR PROPERTY DAMAGE MAY OCCUR IF
INSTRUCTIONS ARE NOT FOLLOWED CAREFULLY.
Personal injury and property damage incurred due to non-compliance with these safety
instructions are not covered by the product liability regulations.
FAILURE TO COMPLY WITH INSTRUCTIONS COULD RESULT IN PERSONAL
INJURY.
SYMBOLS
IMPORTANT INFORMATION
1.2 SAFETY INSTRUCTIONS FOR COMMISSIONING
1.3 SAFETY INSTRUCTIONS FOR OPERATION

2
WARNING: Prior to completely raising the vehicle, raise the vehicle 6” off the ground
and check the adapter pads for solid contact by performing the “BUMPER TEST”. Walk
around the back of the vehicle and push up and down on the bumper. The vehicle will rock,
but should not at any time lose contact with the pads. If the vehicle is bouncing off the pads
or feels at all unstable, you should lower it back to the ground and reposition the pads to
balance the load. Repeat this process until the vehicle is completely stable.
WARNING: Use this lift only in well ventilated areas. Carbon monoxide exhausted
from running vehicle engines is a colorless, odorless fume that, if inhaled, can cause serious
personal injury or death.
WARNING: People with pacemakers should consult their physician(s) before using this
product. Operation of electrical equipment in close proximity to a heart pacemaker could
cause interference or failure of the pacemaker.
WARNING: This product contains or produces a chemical known to the State of
California to cause cancer and birth defects (or other reproductive harm). (California Health
& Safety Code 25249.5 et seq.)
• Maintain a safe working environment. The work area should be clean, dry, clutter free, and
sufciently lit.
• Vehicle doors should be closed during the raising and lowering cycles.
• Closely watch the vehicle and lift during the raising and lowering cycles.
• Do not operate the lift in explosive atmospheres, such as in the presence of ammable
liquids, gases, or dust. Power equipment can create sparks which may ignite ammables.
• Keep hands, tools, and other extremities from under carriage and moving parts.
• Never operate this lift with someone on it.
• Do not allow anyone on the lift or inside a raised vehicle.
• Keep children and bystanders away from work area. Do not let children operate or play on
lift.
• Wear proper safety attire. Do not wear loose tting clothing while operating lift. Long hair,
jewelry and sleeves should be secured.
• Never leave the lift unattended while under a load.
• Do not operate this lift if under the inuence of drugs, alcohol, or medication. Operator
must be alert at all times when using heavy lift equipment.
• Comply with all applicable accident prevention regulations.
• Only use the vehicle manufacturer’s recommended lifting points.
• After positioning the vehicle, apply the parking brake.
• Use caution when removing or installing heavy vehicle components which may result in
center-of-gravity displacement.
• Use this lift only for the work it is intended. Do not use this product for an application for
which it was not designed. Misuse can lead to personal injury and/or property damage.

3
• Maintenance or repair work should be done by authorized service personnel only.
• Work on the electrical equipment should be done by certied licensed electricians only.
• Ensure that ecologically harmful substances are disposed of in accordance with the
appropriate regulations.
• To prevent the risk of damage, do not use high pressure / steam jet cleaners or caustic
cleaning agents.
• Do not replace or override the safety devices.
WARNING: Risks the personnel could encounter, due to an improper use of the lift, are
described in this section.
CRUSHING RISK
During lowering of runways and vehicles, personnel must not be within the area
covered by the lowering trajectory. The operator must be sure no one is in danger before
operating the lift. Stay clear of the lift when lowering or raising vehicles. Keep hands and feet
away from moving parts and especially points that could pinch. Keep your feet clear of the
lift when raising and lowering vehicles.
RISK OF THE VEHICLE FALLING FROM THE LIFT
Risk of the vehicle falling from the lift is increased: when the vehicle is improperly placed on
the platforms, when the vehicle’s weight or physical dimensions exceed the rated capacity
of the lift, or when there is excessive movement of the vehicle while on the lift. If vehicle
appears to begin falling, exit the area as quickly as possible to avoid injury. Always position
vehicle with the center of gravity midway between the adapters. Adding or removing parts
of a vehicle on the lift will alter the weight displacement on the lift. Therefore, use of auxilary
safety stands in the front and back of the vehicle is recommended. Never override the
manufactured lift controls. Always use height adapter pads when possible to ensure proper
contact. Only authorized personnel should be allowed in the lift area and the lift should only
be operated by authorized and trianed personnel. Adding or removing parts of a vehicle on
the lift will alter the weight displacement on the lift.
BUMPING RISK
When the lift is stopped at relatively low working height, the risk of bumping against
projecting parts increases. Always be aware of your surroundings and avoid bumping your
head or body on the lift or the vehicle.
1.4 SAFETY INSTRUCTIONS FOR MAINTENANCE
1.5 RISKS

4
2-DESCRIPTION
The following is a 2-Column Hydraulic, Leaf chain driven lift.
The model numbers covered in this manual are designated below:
HD2P-15000C: 2-Column Overhead Beam Lift type, 15,000 lbs. Capacity, Symmetric
Swing Arm set up.
This lift is a 15,000 lb. capacity, 2-Post Lift. The safety latch system is very similar to an
extension ladder. The safety latch is in contact with the rack as the lift ascends and drops
into place as the lift rises. Safety latch engages in rack in 3” increments at about 16” from
the ground. The latch must be manually disengaged for the lift to descend. The latch is
released by pulling the release cable raising the latch up off the latch rack. Once the raise
button is pressed, the latch will automatically re-engage after approximately 3”of travel.
Heavy bearings and heavy-duty leaf chains are used throughout the lift. The work is done
with the heavy-duty chain connected to a 3” cylinder, driven by a hydraulic pump capable of
providing 3,000 psi.
Please read the Safety Procedures and operation instructions in this manual before
operating the lift. Proper installation is very important. To minimize the chance of making an
error in installation, please read this manual thoroughly before beginning installation. Check
with building owner and/or architect’s building plans when applicable. The lift should be
located on a level oor with 6” 3000 psi concrete sufciently cured, for at least 30 days.
This is a vehicle lift installation / operation manual and no attempt is made or implied herein
to instruct the user in lifting methods particular to an individual application. Rather, the
contents of this manual are intended as a basis for operation and maintenance of the unit
as it stands alone or as it is intended and anticipated to be used in conjunction with other
equipment.
Proper application of the equipment described herein is limited to the parameters detailed
in the specications and the uses set forth in the descriptive passages. Any other proposed
application of this equipment should be documented and submitted in writing to the factory
for examination. The user assumes full responsibility for any equipment damage, personal
injury, or alteration of the equipment described in this manual or any subsequent damages.

5
3-UNPACKING & SETUP
Only skilled personnel who are familiar with the lift and this manual shall be allowed to carry
out, lifting, handling, transport and unpacking operations.
When the lift is delivered, carefully unpack the lift making sure all the parts have been
included. Check for possible damages due to transport and storage; verify that what is
specied in the conrmation of order is included. In case of damage in transit, the customer
must immediately inform the carrier of the problem.
Remove the lift and all parts from delivery pallet and place on a clean, solid, at surface.
Packages must be opened paying attention not to cause damage to people (keep a safe
distance when opening straps) and parts of the lift (be careful the objects do not drop
from the package when opening.)
LIFT AND HANDLE ONLY ONE PACKAGE AT A TIME
3.1 DELIVERY AND CHECK OF PACKAGES
3.2 LIFTING AND HANDLING
3.3 PREPARATION
When loading/unloading or transporting the equipment to the site, be sure to use suitable
loading (e.g. cranes, trucks) and hoisting means. Be sure to hoist and transport the
components securely so that they cannot drop, taking into consideration the package’s size,
weight, center of gravity, and its fragile parts.
The installation of this lift is relatively simple and can be accomplished by 2 men in a few
hours. The following tools and equipment are needed:
1. ISO-32, AW-32, or AW-46 hydraulic oil.
2. Chalk line and Tape Measure
3. Rotary Hammer Drill with 3/4” Drill Bit. Core Drill Rebar Cutter recommended
4. Transit and a 4’ Level
5. Sockets and Open Wrench set, 1/2” thru 1-1/2”(1-1/8”for 3/4” Anchors)
6. Vise Grips
7. Torque Wrench

6
4 SPECIFICATIONS
5-FLOOR REQUIREMENTS
WARNING: SPECIFICATIONS OF CONCRETE MUST BE ADHERED TO. FAILURE
TO DO SO COULD CAUSE LIFT FAILURE RESULTING IN PERSONAL INJURY
OR DEATH. THE FLOOR SHOULD BE A REINFORCED CONCRETE SLAB NOT
LESS THAN 6” (152.4MM) THICKWITH THE COMPRESSIVE STRENGTH OF THE
CONCRETE NO LESS THAN 3,000 PSI (20.68MPA).
DANGER: FOR CORRECT INSTALLATION OF THE LIFT, THE FLOOR MUST
BE FLAT AND LEVEL. CHECKWITH STRAIGHT EDGE AND LEVEL. IF A FLOOR IS
OF QUESTIONABLE SLOPE, CONSIDER A SURVEY OF THE SITE AND/OR THE
POSSIBILITY OF POURING A NEW LEVEL CONCRETE SLAB.
5.1 SELECTING THE SITE AREA
5.2 FLOOR REQUIREMENTS
1. Make sure that adequate space and height is available.
2. Check for ceiling clearance (lifting height plus vehicle height).
3. Check for clearance in front and rear of vehicle on lift.
4. Check for overhead garage door clearance.
Do not use the lift on any asphalt surface. Make sure the lift is used on a dry, oil/grease
free, at level CONCRETE surface capable of supporting the weight of the lift, the vehicle
being lifted, and any additional tools and equipment. The concrete oor surface should
have a minimum thickness of 6”. The concrete must have a minimum strength of 3,000 PSI
and should be aged at least 30 days prior to use. Do not use the lift on concrete expansion
seams or on cracked, defective concrete.
IMPORTANT: NEW CONCRETE MUST BE ADEQUATELY CURED AT LEAST 30
DAYS MINIMUM. NO LIABILITY FOR ANY DAMAGESWILL BE ACCEPTED SHOULD
YOU INSTALL THE LIFT ON AN UNSUITABLE FLOOR.
Model Description Capacity Lifting Time Overall Height Overall Width Between Posts
HD2P-15000C ClearFloor/
Symmetric 15,000 lbs 45 sec. 182” 148” 120”
Max Lift Height/
Standard Pads
Max Lift Height/
Truck Adapter
Drive-Thru
Width
Arm Length
Retracted
Arm Length
Extended
Plate
Dimensions Column Width
76 1/2” 85 1/2” 109 1/2” 39” 52 1/2” 20 1/2” x 34 1/2”
x 3/4” 14 3/4”

7
5.3 IMPORTANT CONCRETE AND ANCHORING INFORMATION
1. Concrete shall have compression strength of at least 3,000 PSI and a minimum thickness of
4”. Measure the length of the supplied anchor bolts in order to achieve a minimum anchor
embedment of 3-1/4”. If the top of the anchor exceeds 2” above the oor grade, you DO NOT
have enough embedment.
2. Before drilling 3/4” dia. Holes in concrete oor using holes in column base plate as guide, make
sure the hole distance from the edge of the concrete or any cracks is no less than 8”.
3. DANGER: DO NOT Install on asphalt or other similar unstable surface. Columns are
supported only by anchoring in oor.
4. Shim each column base until each column is plumb. If one column has to be elevated to match
the plane of the other column, full size base shim plates should be used (Reference Shim Kit).
Torque anchors to 85 ft-lbs. Shim thickness MUST NOT exceed 1/2”.
5. If anchors do not tighten to 85 ft-lbs installation torque, replace concrete under each column
base with a 4’ x 4’ x 36” thick 3,000 PSI minimum concrete pad pinned to the existing concrete
and ush with the top of existing oor. Let concrete cure at least 30 days before installing lifts
and anchors.
5.4 ANCHORING TIP SHEET
1. Use a concrete hammer drill with a carbide tip, solid drill bit the same diameter as the anchor,
3/4”. (.775 to .787 inches diameter). Do not use excessively worn bits or bits which have been
incorrectly sharpened.
2. Keep the drill perpendicular to the concrete while drilling.
3. Let the drill do the work. Do not apply excessive pressure. Lift the drill up and down occasionally
to remove residue to reduce binding.
4. Drill the hole for anchor bolt completely through the concrete. If an error is made during the
installation of these anchors, this will allow for the anchor bolt to be driven down into the
ground, so that a new anchor may be installed in place (g.1).
5. Be sure to clean all dust from hole (g. 2).
6. Place a at washer and hex nut over threaded end of anchor, leaving approximately 1/4 inch of
thread exposed above the nut (g.3). Carefully tap anchor into the concrete until nut and at
washer are against base plate. Be sure to only tap the top of the anchor and not the nut. This
could cause damage to the threads of the anchor.
7. Tighten the nut (g. 4) to 85 ft-lbs of torque (typically this should only be two to three full turns).
DO NOT USE AN IMPACTWRENCH TO TIGHTEN ANCHORS!

8
6-INSTALLATION INSTRUCTIONS
PLEASE READ THIS INSTRUCTION BEFORE STARTING TO OPERATE THE LIFT.
Check for ceiling clearance to conrm the lift can be set up in your bay.
1) After unloading the lift, place it near the intended installation location.
2) Remove the shipping bands and packing materials from the unit.
3) Open the wrapping from the upper column and carefully remove the parts form inside.
Unbolt the column from the shipping brackets. Remove the up-rights (part# 9) from the
packaging and assemble them to the scolumns based on any height restrictions.
4) Once the lift location is decided, chalk the center line in the bay and ensure that the
proper lift placement is observed from walls and obstacles. Also check the ceiling height
for clearance in this location. (See Fig 5A & 5B) NOTE: the power unit column can be
located on either side.
5) Assemble the uprights to the columns on model HD2P-15000C. (See Fig. 1, page 21).
6) Position the columns facing each other with 148” between the outside of the base plates.
NOTE: The power unit column is referred to as the main side column and the non power
unit column is referred to as the offside column.
7) Using a 3/4” concrete drill bit, drill the anchor holes in the main side column, installing
anchors as you go (see Fig. 7, pg. 27). Use a block of wood or rubber mallet to drive
anchor bolts in.
8) Using a level , check column for side-to-side plumb and front-to-back plumb. Use 3/4”
washers or shim stock, placing shims as close as possible to the hole locations. This will
prevent bending the column bottom plates. Tighten 3/4” anchor bolts to 85-lbs. NOTE:
DO NOT USE IMPACTWRENCH.
9) Using a tape measure, measure from front corner of the base on main side column to the
opposite front corner of the offside column to ensure columns are square. (see Fig. 7,
page 27) After conrming the dimensions, install the overhead beam (see Fig 4, page 24)
to the top of the columns BEFORE drilling the anchors for the offside column to ensure
the column is plumb.
10) After overhead beam is assembled, drill and anchor offside column as described in steps
7&8.

9
11) Installing the equalizing cables: refer to Fig 5 (pg. 25) for general cable arrangement for the
HD2P-15000C. Set carriages on the rst safety latch engagement. Be sure each carriage
is at the same height by measuring from the top of the base to the bottom of the
carriage (double check the latches before working under the carriages). This dimension
should be within 1/4”. Run rst cable Fig 5. Tighten nut on one cable stud so that the end
of stud passes the nylon on the nut. Pull the other end of cable and run nut on it. Tighten
both nuts. Repeat above for second cable.
12) Connect the hydraulic hoses, as shown on Fig. 6 (pg. 26) for HD2P-15000C Clear Floor
Type.
13) Mount the power unit on lift as shown in Fig. 6 (pg. 26).
14) Install the swing arms on the carriages using the included 1 1/2” diameter pins. Check
for proper engagement of the arm lock- the rack on the lock should fully engage the gear
on the arm.
15) Adjust the carriage cables tension. Adjust each cable to approximately 1/2” side-to-side
play. Check the latch releases to insure the carriage is still sitting on the appropriate
latch. NOTE: Tightening cable adjustment nut on main side column will raise carriage
on offside column and vise versa. Refer to Fig 5 pg. 25.
16) Remove the ll cap from the power unit and ll the oil tank reservoir. To ll the oil tank
resevoir, the lift must be completely lowered. FIll the oil tank with a premium quality ISO-
32, or AW-46 Hydraulic Oil.
17) Make the Electrical hookup to the power unit.(220V Single Phase). It is recommended
that a 220 Volt, 30 Amp twist lock plug be installed in the power line just ahead of the
power unit. Use properly sized wire for 30-amp circuit.
WARNING: THE WIRING MUST COMPLY WITH LOCAL CODE. HAVE A
CERTIFIED ELECTRICIAN MAKE THE ELECTRICAL HOOK-UP TO THE POWER
UNIT. PROTECT EACH CIRCUITWITH TIME DELAY FUSE OR CIRCUIT BREAKER;
208V-230V SINGLE PHASE. 60 HZ 30 AMP.

10
18) Install the shut-off mechanism for the 15000C model. Screw two long screws into holes
on up-rights, and tighten them with two M6 nuts each. Run shut-off cable through hole
at long screw end on offside up-right and x it with cable clamp, across the power side
long screw hole, to the microswitch on top of power unit, then x the cable end with
cable clamp also. Make it as tight at you can without tripping the cutoff microswitch.
19) Do not place any vehicle on the lift at this time. Read the operation instructions (pg 12-
14) and cycle the lift up and down several times to ensure safety latches click together
and all air is removed from the system. Ensure all hydraulic ttings are tight and not
leaking. To lower the lift, the safety latch releases must be manually released. Latches
will automatically reset once the lift ascends approximately 17” from base. If latches
click out of sync, tighten the cable on the one that clicks rst.
WARNING: DO NOT PERFORM ANY MAINTENANCE OR INSTALLATION
OF ANY COMPONENTS WITHOUT FIRST ENSURING THAT ELECTRICAL POWER
HAS BEEN DISCONNECTED AT THE SOURCE OR PANEL AND CANNOT BE
REENERGIZED UNTIL ALL MAINTENANCE AND/OR INSTALLATION PROCEDURES
ARE COMPLETED.
DANGER: DO NOT RUN POWER UNIT WITHOUT FLUID. DAMAGE TO PUMP
CAN OCCUR. THE POWER UNIT MUST BE KEPT DRY. DAMAGE TO POWER UNIT
CAUSED BYWATER OR OTHER LIQUIDS SUCH AS DETERGENTS, ACID ETC., IS
NOT COVERED UNDERWARRANTY.

11
7-OPERATION INSTRUCTIONS
WARNING: LIFT OPERATION BY TRAINED AUTHORIZED PERSONNEL OVER
18YEARS ONLY. APPLY THE PARKING BRAKE AFTER POSITIONING THE VEHICLE
ON THE LIFT. DO NOT ALLOW ANYONE TO STAY IN LIFT AREA DURING RAISING
AND LOWERING CYCLES. CLOSELY WATCH THE VEHICLE AND THE LIFT DURING
RAISING AND LOWERING CYCLES. OBSERVE THE RATED LOAD CAPACITY AND
LOAD DISTRIBUTION. DO NOT ALLOW ANYONE TO CLIMB ON LIFT OR STAY
INSIDE VEHICLE. AFTER RAISING THE VEHICLE FRAME 6”, STOP AND CHECK
ADAPTERS FOR SECURE CONTACT. PERFORM BUMPER TEST. MAKE SURE THE
VEHICLE DOORS ARE CLOSED DURING RAISING AND LOWERING CYCLES.
WARNING: IN CASE OF DEFECTS OR MALFUNCTIONS SUCH AS JERKY LIFT
MOVEMENT OR DEFORMATION OF THE SUPERSTRUCTURE, SUPPORT OR LOWER
THE LIFT IMMEDIATELY. CONTACT QUALIFIED SERVICE PERSONNEL.
WARNING: PAY CLOSE ATTENTION WHEN SETTING THE LOCKS. THE LOCKS
MUST BE A LEVEL MATCH SET IN ORDER TO AVOID A VEHICLE TILT.
WARNING: ALWAYS LOCK THE LIFT BEFORE GOING UNDER THE VEHICLE.
NEVER ALLOW ANYONE TO GO UNDER THE LIFTWHEN RAISING OR LOWERING.
7.1 DEFECTS / MALFUNCTIONS
7.2 CONTROLS
7.2.1 UP CONTROL
7.2.2 SAFETY LOCK CONTROL
The safety latch mechanism will “Trip Over” as the lift raises and drop into each safety latch
stop. To lock the lift you must press the lowering handle on the power unit (Fig. 1) to relieve
the hydraulic pressure and let the safety locks engage into a level locked position.
Once the up button is actuated, the lift moves up until the button is
released or the limit stop is reached.
UP

12
1. Before driving a vehicle onto the lift make sure the lift is fully lowered. Before driving a
vehicle onto the lift, position the lift arms outward. Do not hit or run over the lifting arms,
as this could damage the vehicle and/or lift. Make sure the lift is fully lowered before
moving the vehicle over the lift. NOTE: It is recommended to swing both arms outward
pointing toward the front of the lift prior to loading a vehicle onto the 15000C.
2. Drive the vehicle over the lift while keeping the vehicle parallel with the lift and aligning
the center of gravity of the vehicle with the center of the lift. NOTE: The “Center of
Gravity” (COG) of the vehicle is the balance point at which there is equal weight in front
of and behind the COG, and equal weight on both sides of the COG. The COG is not
necessarily the dimensional center of the vehicle, but is often slightly toward the engine
from the dimensional center of the vehicle.
3. Turn off the vehicle’s engine and engage the parking brake of the vehicle.
4. Read the vehicles owner’s manual to identify the recommended vehicle lifting points.
5. Prepare the work area according to this manual. Move the lifting arms inward, and
position the rubber pads to contact with the vehicle manufacturer’s recommended lifting
points.
7.3 OPERATION
NOTE: IT IS NORMAL FOR AN EMPTY LIFT TO LOWER
SLOWLY - IT MAY BE NECESSARY TO ADDWEIGHT.
7.2.3 LOWERING CONTROL
Fig. 1
WARNING: FAILURE TO OPERATE THE LIFT ACCORDING TO THIS MANUAL
MAY CAUSE DAMAGE TO THE LIFT, PROPERTY DAMAGE AND/OR PERSONAL
INJURY.
Fig. 2
IMPORTANT: PLACE THE FOUR RUBBER PADS UNDER EDGE OF VEHICLE AT
THE FOUR JACK POINTS.
6. Once the lifting arms have been positioned under the vehicle lifting points, operate the
power switch to make contact and lift the vehicle slightly. Test to make sure the vehicle
is well balanced and the contact between the rubber pads and vehicle lifting points are
secure by performing the “BUMPER TEST.” (pg. 2) Then proceed to lift the vehicle to the
desired height.
Press the up button enough to allow the safety locks to be
disengaged. Pull both latch releases Fig. 2 to release the safety
locks.
WARNING: ALWAYS RELEASE BOTH SIDES.
Press the lowering handle Fig. 1 until the lift is completely
lowered.

13
7. WARNING: Do not lift the vehicle if you cannot establish secure and level lifting
points. Do not use sub-standard shims or other devices in place of approved and
recommended rubber pad adapters. Never use the lift without the rubber pads in place on
each plate and in contact with the lifting points of a vehicle.
8. Press up button and raise vehicle to desired height. Do not go under vehicle until load
rests on level safety locks.
9. While lifting the vehicle a clicking sound should be noticeable which indicates the safety
mechanism is operating. If this sound is not heard, immediately cease using the lift and
call an authorized service agent.
10. When lift reaches maximum height, a limit switch will come into operation and stop the
lift. When lift has stopped, press and hold the lowering handle (Fig. 1) until load rests on
level safety locks.
11. Once the repair work to the vehicle is complete, make sure to remove all tools, safety jack
stands, and materials from under the vehicle and lift. Also, make sure the work area is
clear and it is safe to lower the vehicle.
12. Lower vehicle by pressing the Up button to disengage the safety locks. Pull both latch
releases to release (Fig. 2) the safety locks then press the lowering handle (Fig. 1) until
the lift is completely lowered.
13. Move the lifting arms outward, out of the path of the vehicle. Clear all bystanders, and
any objects from work area and direction of vehicle.
14. Disengage the vehicle parking brake. Start the vehicle’s engine, and drive the vehicle off
the lift slowly and carefully.
WARNING: THE OPERATOR MUST BE TRAINED AND AUTHORIZED TO
OPERATE THE LIFT.
WARNING: DO NOT GO UNDER VEHICLE UNDER ANY CIRCUMSTANCES
WHILEVEHICLE IS BEING RAISED OR LOWERED.
WARNING: LOAD MUST BE EVENLY DISTRIBUTED BETWEEN BOTH LIFTING
PLATFORMS. IF LOAD IS UNBALANCED, REPOSITION VEHICLE. DO NOT LOWER
ON TO LOCKS AT DIFFERENT HEIGHTS.

14
8-MAINTENANCE
WARNING: DISCONNECT THE POWER BEFORE SERVICING THE LIFT.
IMPORTANT: THE MAINTENANCE INTERVALS INDICATED BELOW APPLY TO
AVERAGEWORKSHOP USE. THE LIFT SHOULD BE INSPECTED MORE FREQUENTLY
FOR SEVERE USE APPLICATIONS.
It is important to keep the lift clean, dry, and well maintained by establishing a periodic
preventive maintenance program to ensure trouble-free operation and long service life.
1. Check safety locking mechanism is functioning correctly.
2. Check safety lock audibly and visually while in operation.
3. Check safety latches for free movement and full engagement with rack.
4. Inspect the condition of rubber lifting pads and replace as necessary if worn or torn.
5. Check hydraulic connections, and hoses for leakage.
6. Check chain connections - Bends, cracks - and looseness.
7. Check for frayed cables in both raised and lowered positions.
8. Check snap rings at all rollers and sheaves.
9. Check bolts, nuts, and screws and tighten.
10. Check wiring & switches for damage.
11. Keep base plate free of dirt, grease or any other corrosive substances.
12. Check oor for stress cracks near anchor bolts.
13. Check swing arm restraints.
1. Check anchor bolts torque to 85 ft-lbs for the 3/4’’ anchor bolts. NOTE:
DO NOT USE IMPACT WRENCH.
2. Check oor for stress cracks near anchor bolts.
3. Check hydraulic oil level.
4. Check and tighten bolts and nuts, and screws.
5. Check cylinder pulley assembly for free movement or excessive wear on cylinder yoke or
pulley pin.
6. Check cable pulley for free movement and excessive wear.
8.1 MAINTENANCE SCHEDULE
8.1.1 DAILY
8.1.2WEEKLY

15
8.1.3 MONTHLY
8.1.4 BIMONTHLY
8.1.5YEARLY
8.1.6 EVERY OTHER YEAR
1. Check safety mechanism operation.
2. Check condition of shafts, shaft locks and bushings.
3. Check overall cleanliness.
1. Check condition of extensions and lubricate.
2. Check oil leaks from cylinders.
3. Check oil leaks at pipe joints.
Service and safety inspection on the lift must be performed by a competent person. This
inspection must be recorded. If the 12 month service and safety inspection is not performed,
the warranty is null and void.
1. Lubricate chain
2. Grease rub blocks and column surface contacting rub blocks.
3. Change the hydraulic uid. A good maintenance program makes it mandatory to keep
hydraulic uid clean. Operating temperature, type of service, contamination levels,
ltration, and chemical composition of uid should be considered. If operating in harsh or
dusty conditions, a shorter interval may be required.
THE FOLLOWING ITEMS SHOULD ONLY BE PERFORMED BY A TRAINED
MAINTENANCE EXPERT.
• Replace hydraulic hoses.
• Replace chains and rollers.
• Replace cables and sheaves.
• Replace or rebuild air and hydraulic cylinders as required.
• Replace or rebuild pumps / motors as required.
• Check hydraulic and air cylinder rod and rod end (threads) for deformation or damage.
• Check cylinder mount for looseness and damage.
Relocating or changing components may cause problems. Each component in the system
must be compatible; an undersized or restricted line will cause a drop in pressure. All valve,
pump, and hose connections should be sealed and/or capped until just prior to use. Air
hoses can be used to clean ttings and other components. However, the air supply must be
ltered and dry to prevent contamination. Most important - CLEANLINESS - contamination is
the most frequent cause of malfunction or failure of hydraulic equipment.
Hydraulic oil should be replaced.

16
8.2 MAINTENANCE BY OPERATOR
8.2.1 HYDRAULIC SYSTEM
8.2.2 GREASING POINTS
All moving parts have been lubricated at the factory and should be re-lubricated before the
rst use and at least once every six months to prevent damage.
1. Check the uid level with the lift fully lowered and add uid as required. Use premium
quality ISO-32, AW-32, or AW-46 hydraulic oil.
2. Visually check all hydraulic hoses and connections for tightness before each use to
ensure proper working condition.
3. Lightly oil the cylinder rods at least once every six months or when they become dry.
IMPORTANT: AFTER CLEANINGWORKSHOP FLOOR OR LIFT, TO MAINTAIN
HOIST EFFICIENCY WE ADVISE TO LUBRICATE LIFTING ARM LOCKING
MECHANISM, AND SAFETY LOCKING MECHANISM. CHECK SAFETY LOCKING
MECHANISM IS FUNCTIONING CORRECTLY.
FIG. 3
SLIDE TRACKS:
• The carriage assembly slide tracks should be greased every six months (or more
frequently in case of noise generation).
• Slightly grease the slide tracks over their whole length using a brush.
