Titan Lifts HD2P-9KCL Instruction manual

INSTALLATION, OPERATION
& MAINTENANCE MANUAL
FOLLOW THIS MANUAL CAREFULLY TO ENSURE THE MACHINE WILL
FUNCTION CORRECTLY AND PROVIDE MANY YEARS OF DEPENDABLE SERVICE.
FAILURE TO FOLLOW THESE INSTRUCTIONS AND SAFETY WARNINGS MAY
RESULT IN PERSONAL INJURY OR PROPERTY DAMAGE. KEEP THIS MANUAL IN A
SAFE DRY PLACE FOR FUTURE REFERENCE.
MODELS:
HD2P-9KCL
9,000 LB CAPACITY 2 POST LIFT
®

PO Box 7069 Greenwood, IN 46142
1.888.908-4826 FAX [phone]
www.titanlifts.com
TITAN MARKETING, LLC
®
To Our Valued Customers:
Thank you for purchasing a Titan Lifts®product. We hope this high quality equipment provides you with years of
dependable service.
It is unfortunate that rare situations may occur with the products you purchase from Titan Lifts®. We value your
business as well as the trust you have and need to maintain your relationship with us. Titan Lifts®carries liability
coverage that may protect our customers if a situation does occur. However, as in all accidents there must be
proof of liability for a claim to be made. Our insurance company requires the following procedures be observed in
order to consider a claim:
A. The claimant must contact the Titan Lifts®distributor immediately with the facts of the situation.
B. If any equipment is damaged, including vehicles or shop equipment, Titan Lifts®must be given the
opportunity to send an impartial representative to the site for proper assessment of the situation.
C. The Vehicle cannot be moved until either an impartial representative has reviewed the accident or clear
and precise pictures are taken that reect all the pertinent information for an impartial representative to be able
to access the information from a distance. Titan Lifts®or its representatives must approve the pictures before
anything can be moved.
D. If any potential liability is determined on behalf of Titan Lifts®, two estimates must be submitted for
damages to be reimbursed.
It is imperative that the claimant complies with these procedures, because without proper assessment of the
situation a claim will be denied.
ARBITRATION NOTICE
The installation or use of this equipment shall constitute an acknowledgment that the user agrees to resolve any
and all disputes or claims of any kind whatsoever, which relate in any way to the equipment, by way of binding
arbitration, not litigation. No suit or legal action may be led in any state or federal court. Any arbitration shall be
governed by the Federal Arbitration Act, and administered by the American Mediation Association, Indianapolis
Indiana. The maximum amount that an arbitrator may award and all damages shall not exceed the retail value of
this equipment.
WARRANTY NOTICE
This equipment must be assembled and used in the manner according to the documentation provided to be
covered by warranty.
Damaged or missing components must be reported within 72 hours of receipt to your freight carrier and to the
distributor. Claims must be led to cover cost.
If you have any questions or if we can be of any further assistance, please don’t hesitate to contact a Titan Lifts®
representative at 1-888-908-4826. Thank you for the opportunity to continue to serve your lift equipment needs.

TABLE OF CONTENTS
1-SAFETY���������������������������������������������������������������������������������������������������������������� PAGE 1
1�1 INTRODUCTION �������������������������������������������������������������������������������������������������������������������PAGE 1
1�2 SAFETY INSTRUCTIONS FOR COMMISSIONING����������������������������������������������������������������PAGE 1
1�3 SAFETY INSTRUCTIONS FOR OPERATION �������������������������������������������������������������������������PAGE 1
1�4 SAFETY INSTRUCTIONS FOR MAINTENANCE �������������������������������������������������������������������PAGE 3
1�5 RISKS �����������������������������������������������������������������������������������������������������������������������������������PAGE 3
2-DESCRIPTION ������������������������������������������������������������������������������������������������������ PAGE 4
3-UNPACKING & SETUP������������������������������������������������������������������������������������������ PAGE 5
3�1 DELIVERY AND CHECK OF PACKAGES��������������������������������������������������������������������������������PAGE 5
3�2 LIFTING AND HANDLING�����������������������������������������������������������������������������������������������������PAGE 5
3�3 PREPARATION ���������������������������������������������������������������������������������������������������������������������PAGE 5
4 SPECIFICATIONS ������������������������������������������������������������������������������������������������� PAGE 6
5-FLOOR REQUIREMENTS �������������������������������������������������������������������������������������� PAGE 6
5�1 SELECTING THE SITE AREA ������������������������������������������������������������������������������������������������PAGE 6
5�2 FLOOR REQUIREMENTS�������������������������������������������������������������������������������������������������������PAGE 6
5�3 IMPORTANT CONCRETE AND ANCHORING INFORMATION�����������������������������������������������PAGE 7
5�4 ANCHORING TIP SHEET ������������������������������������������������������������������������������������������������������PAGE 8
6-INSTALLATION INSTRUCTIONS ������������������������������������������������������������������������� PAGE 9
7-OPERATION INSTRUCTIONS����������������������������������������������������������������������������� PAGE 12
7�1 DEFECTS / MALFUNCTIONS����������������������������������������������������������������������������������������������PAGE 12
7�2 CONTROLS�������������������������������������������������������������������������������������������������������������������������PAGE 12
7.2.1 UP CONTROL .................................................................................................................. PAGE 12
7.2.2 SAFETY LOCK CONTROL............................................................................................... PAGE 12
7.2.3 LOWERING CONTROL .................................................................................................... PAGE 13
7�3 OPERATION������������������������������������������������������������������������������������������������������������������������PAGE 13
8-MAINTENANCE�������������������������������������������������������������������������������������������������� PAGE 15
8�1 MAINTENANCE SCHEDULE �����������������������������������������������������������������������������������������������PAGE 15
8.1.1 DAILY ............................................................................................................................... PAGE 15
8.1.2 WEEKLY ........................................................................................................................... PAGE 15
8.1.3 MONTHLY ....................................................................................................................... PAGE 16
8.1.4 BI-MONTHLY................................................................................................................... PAGE 16
8.1.5 YEARLY............................................................................................................................ PAGE 16
8�2 MAINTENANCE BY OPERATOR �����������������������������������������������������������������������������������������PAGE 17
8.2.1 HYDRAULIC SYSTEM ..................................................................................................... PAGE 17
8.2.2 GREASING POINTS ........................................................................................................ PAGE 17
8.2.3 OPERATION AND WEAR CHECKS ................................................................................. PAGE 18
8.2.4 LIFT STABILITY .............................................................................................................. PAGE 18
8�3 CLEANING ��������������������������������������������������������������������������������������������������������������������������PAGE 18
9-TROUBLESHOOTING ����������������������������������������������������������������������������������������� PAGE 19
10-OWNER/EMPLOYER RESPONSIBILITIES �������������������������������������������������������� PAGE 20
11-DIAGRAMS (FIG� 1-9)��������������������������������������������������������������������������������������� PAGE 21

1
1-SAFETY
INSTRUCTIONS
1.1 INTRODUCTION
• The lift may be installed and commissioned by authorized service personnel only.
• The standard lift version may not be installed and commissioned in the vicinity of
explosives or ammable liquids, outdoors or in moist rooms (e.g. car wash).
• Read this entire manual.
• Load should not exceed rated capacity for this lift – 9,000 lb (2,250 lb per lift arm)
• Only trained authorized personnel over the age of 18 years should operate the lift.
• Indoor use recommended.
• Always lift the vehicle using all four arms.
• Never use the lift to raise one end or one side of vehicle.
FAILURE TO COMPLY WITH INSTRUCTIONS COULD RESULT IN
PROPERTY DAMAGE.
WARNING: READ ENTIRE MANUAL AND COMPLY WITH ALL SAFETY AND SERVICE
PRECAUTIONS. DEATH, PERSONAL INJURY AND / OR PROPERTY DAMAGE MAY OCCUR IF
INSTRUCTIONS ARE NOT FOLLOWED CAREFULLY.
Personal injury and property damage incurred due to non-compliance with these safety
instructions are not covered by the product liability regulations.
FAILURE TO COMPLY WITH INSTRUCTIONS COULD RESULT IN PERSONAL
INJURY.
SYMBOLS
IMPORTANT INFORMATION
1.2 SAFETY INSTRUCTIONS FOR COMMISSIONING
1.3 SAFETY INSTRUCTIONS FOR OPERATION

2
WARNING: Prior to completely raising the vehicle, raise the vehicle 6” off the ground
and check the adapter pads for solid contact by performing the “BUMPER TEST”. Walk
around the back of the vehicle and push up and down on the bumper. The vehicle will rock,
but should not at any time lose contact with the pads. If the vehicle is bouncing off the pads
or feels at all unstable, you should lower it back to the ground and reposition the pads to
balance the load. Repeat this process until the vehicle is completely stable.
WARNING: Use this lift only in well ventilated areas. Carbon monoxide exhausted
from running vehicle engines is a colorless, odorless fume that, if inhaled, can cause serious
personal injury or death.
WARNING: People with pacemakers should consult their physician(s) before using this
product. Operation of electrical equipment in close proximity to a heart pacemaker could
cause interference or failure of the pacemaker.
WARNING: This product contains or produces a chemical known to the State of
California to cause cancer and birth defects (or other reproductive harm). (California Health
& Safety Code 25249.5 et seq.)
• Maintain a safe working environment. The work area should be clean, dry, clutter free, and
sufciently lit.
• Vehicle doors should be closed during the raising and lowering cycles.
• Closely watch the vehicle and lift during the raising and lowering cycles.
• Do not operate the lift in explosive atmospheres, such as in the presence of ammable
liquids, gases, or dust. Power equipment can create sparks which may ignite ammables.
• Keep hands, tools, and other extremities from under carriage and moving parts.
• Never operate this lift with someone on it.
• Do not allow anyone on the lift or inside a raised vehicle.
• Keep children and bystanders away from work area. Do not let children operate or play on
lift.
• Wear proper safety attire. Do not wear loose tting clothing while operating lift. Long hair,
jewelry and sleeves should be secured.
• Never leave the lift unattended while under a load.
• Do not operate this lift if under the inuence of drugs, alcohol, or medication. Operator
must be alert at all times when using heavy lift equipment.
• Comply with all applicable accident prevention regulations.
• Only use the vehicle manufacturer’s recommended lifting points.
• After positioning the vehicle, apply the parking brake.
• Use caution when removing or installing heavy vehicle components which may result in
center-of-gravity displacement.
• Use this lift only for the work it is intended. Do not use this product for an application for
which it was not designed. Misuse can lead to personal injury and/or property damage.

3
• Maintenance or repair work should be done by authorized service personnel only.
• Work on the electrical equipment should be done by certied licensed electricians only.
• Ensure that ecologically harmful substances are disposed of in accordance with the
appropriate regulations.
• To prevent the risk of damage, do not use high pressure / steam jet cleaners or caustic
cleaning agents.
• Do not replace or override the safety devices.
WARNING: Risks the personnel could encounter, due to an improper use of the lift, are
described in this section.
CRUSHING RISK
During lowering of runways and vehicles, personnel must not be within the area
covered by the lowering trajectory. The operator must be sure no one is in danger before
operating the lift. Stay clear of the lift when lowering or raising vehicles. Keep hands and feet
away from moving parts and especially points that could pinch. Keep your feet clear of the
lift when raising and lowering vehicles.
RISK OF THE VEHICLE FALLING FROM THE LIFT
Risk of the vehicle falling from the lift is increased: when the vehicle is improperly placed on
the platforms, when the vehicle’s weight or physical dimensions exceed the rated capacity
of the lift, or when there is excessive movement of the vehicle while on the lift. If vehicle
appears to begin falling, exit the area as quickly as possible to avoid injury. Always position
vehicle with the center of gravity midway between the adapters. Adding or removing parts of
a vehicle on the lift will alter the weight displacement on the lift. Therefore, use of auxiliary
safety stands in the front and back of the vehicle is recommended. Never override the
manufactured lift controls. Always use height adapter pads when possible to ensure proper
contact. Only authorized personnel should be allowed in the lift area and the lift should only
be operated by authorized and trained personnel. Adding or removing parts of a vehicle on
the lift will alter the weight displacement on the lift.
BUMPING RISK
When the lift is stopped at relatively low working height, the risk of bumping against
projecting parts increases. Always be aware of your surroundings and avoid bumping your
head or body on the lift or the vehicle.
1.4 SAFETY INSTRUCTIONS FOR MAINTENANCE
1.5 RISKS

4
The following is a 2-Column hydraulic, leaf chain driven lift.
The model numbers covered in this manual are designated below:
HD2P-9KCL: 2-Column Overhead Beam Lift type, 9,000 lb Capacity, Asymmetric
Swing Arm set up.
This lift is a 9,000 lb capacity, 2-Post Lift. The safety latch system is very similar to an
extension ladder. The safety latch is in contact with the rack as the lift ascends and drops
into place as the lift rises. Safety latch engages in rack in 3” increments at about 16” from the
ground. The latch must be manually disengaged for the lift to descend. The latch is released
by raising the latch rack using the hydraulic drive system and pulling the release handle. If
the user lets go of the manual release handle, the safety latch will re-engage on the next lock
latch it encounters. Heavy bearings and heavy-duty leaf chains are used throughout the lift.
The work is done with the heavy-duty chain connected to a 3” cylinder, driven by a hydraulic
pump capable of providing 3,000 psi.
Please read the Safety Procedures and operation instructions in this manual before
operating the lift. Proper installation is very important. To minimize the chance of making an
error in installation, please read this manual thoroughly before beginning installation. Check
with building owner and/or architect’s building plans when applicable. The lift should be
located on a level oor with 4” 3000 psi concrete sufciently cured, for at least 30 days.
This is a vehicle lift installation / operation manual and no attempt is made or implied herein
to instruct the user in lifting methods particular to an individual application. Rather, the
contents of this manual are intended as a basis for operation and maintenance of the unit
as it stands alone or as it is intended and anticipated to be used in conjunction with other
equipment.
Proper application of the equipment described herein is limited to the parameters detailed
in the specications and the uses set forth in the descriptive passages. Any other proposed
application of this equipment should be documented and submitted in writing to the factory
for examination. The user assumes full responsibility for any equipment damage, personal
injury, or alteration of the equipment described in this manual or any subsequent damages.
2-DESCRIPTION

5
3-UNPACKING & SETUP
Only skilled personnel who are familiar with the lift and this manual shall be allowed to carry
out, lifting, handling, transport and unpacking operations.
When the lift is delivered, carefully unpack the lift making sure all the parts have been
included. Check for possible damages due to transport and storage; verify that what is
specied in the conrmation of order is included. In case of damage in transit, the customer
must immediately inform the carrier of the problem.
Remove the lift and all parts from delivery pallet and place on a clean, solid, at surface.
Packages must be opened paying attention not to cause damage to people (keep a safe
distance when opening straps) and parts of the lift (be careful the objects do not drop
from the package when opening.)
LIFT AND HANDLE ONLY ONE PACKAGE AT A TIME
3.1 DELIVERY AND CHECK OF PACKAGES
3.2 LIFTING AND HANDLING
3.3 PREPARATION
When loading/unloading or transporting the equipment to the site, be sure to use suitable
loading (e.g. cranes, trucks) and hoisting means. Be sure to hoist and transport the
components securely so that they cannot drop, taking into consideration the package’s size,
weight, center of gravity, and its fragile parts.
Professional installation is required. The following tools and equipment are needed:
1. ISO-32, AW-32, or AW-46 hydraulic oil (2.5 Gallons)
2. Chalk line and Tape Measure
3. Rotary Hammer Drill with 3/4” Drill Bit. Core Drill Rebar Cutter recommended
4. 4’ Level
5. Sockets and Open Wrench set, metric & standard (1-1/8”for 3/4” Anchors)
6. Pliers
7. Torque Wrench
8. Metric allen wrench set

6
4 SPECIFICATIONS
Model Description Capacity Lifting Time Overall Height Overall Width Between Posts
HD2P-9KCL Clear Floor/
Asymmetric 9,000 lb 40-60 sec. 155” 132.25” 110.25”
Drive-Thru
102”
5-FLOOR REQUIREMENTS
WARNING: SPECIFICATIONS OF CONCRETE MUST BE ADHERED TO. FAILURE
TO DO SO COULD CAUSE LIFT FAILURE RESULTING IN PERSONAL INJURY OR
DEATH. THE FLOOR SHOULD BE A REINFORCED CONCRETE SLAB NOT LESS
THAN 4” THICK WITH THE COMPRESSIVE STRENGTH OF THE CONCRETE NO LESS
THAN 3,000 PSI.
DANGER: FOR CORRECT INSTALLATION OF THE LIFT, THE FLOOR MUST
BE FLAT AND LEVEL. CHECK WITH STRAIGHT EDGE AND LEVEL. IF A FLOOR IS
OF QUESTIONABLE SLOPE, CONSIDER A SURVEY OF THE SITE AND/OR THE
POSSIBILITY OF POURING A NEW LEVEL CONCRETE SLAB.
5.1 SELECTING THE SITE AREA
5.2 FLOOR REQUIREMENTS
1. Make sure that adequate space and height is available.
2. Check for ceiling clearance (lifting height plus vehicle height).
3. Check for clearance in front and rear of vehicle on lift.
4. Check for overhead garage door clearance.
Do not use the lift on any asphalt surface. Make sure the lift is used on a dry, oil/grease free,
at level CONCRETE surface capable of supporting the weight of the lift, the vehicle being
lifted, and any additional tools and equipment. The concrete oor surface should have a
minimum thickness of 4”. The concrete must have a minimum strength of 3,000 PSI, and
should be cured at least 30 days prior to use. Do not use the lift on concrete expansion
seams or on cracked, defective concrete.
IMPORTANT: NEW CONCRETE MUST BE ADEQUATELY CURED AT LEAST 30
DAYS MINIMUM. NO LIABILITY FOR ANY DAMAGES WILL BE ACCEPTED SHOULD
YOU INSTALL THE LIFT ON AN UNSUITABLE FLOOR.

7
5.3 IMPORTANT CONCRETE AND ANCHORING INFORMATION
1. Concrete shall have compression strength of at least 3,000 PSI and a minimum thickness
of 4”. Measure the length of the supplied anchor bolts in order to achieve a minimum
anchor embedment of 3-1/4”. If the top of the anchor exceeds 2” above the oor grade,
you DO NOT have enough embedment.
2. Before drilling 3/4” dia. Holes in concrete oor using holes in column base plate as guide,
make sure the hole distance from the edge of the concrete or any cracks is no less than
8”.
3. DANGER: DO NOT Install on asphalt or other similar unstable surface. Columns are
supported only by anchoring in oor.
4. Shim each column base until each column is plumb. If one column has to be elevated
to match the plane of the other column, full size base shim plates should be used
(Reference Shim Kit). Torque anchors to 85 ft-lbs. Shim thickness MUST NOT exceed
1/2”.
5. If anchors do not tighten to 85 ft-lbs installation torque, replace concrete under each
column base with a 4’ x 4’ x 6” thick 3,000 PSI minimum concrete pad pinned to the
existing concrete and ush with the top of existing oor. Let concrete cure at least 30
days before installing lifts and anchors.

8
5.4 ANCHORING TIP SHEET
1. Use a concrete hammer drill with a carbide tip, solid drill bit the same diameter as the
anchor, 3/4”. (.775 to .787 inches diameter). Do not use excessively worn bits or bits
which have been incorrectly sharpened�
2. Keep the drill perpendicular to the concrete while drilling.
3. Let the drill do the work. Do not apply excessive pressure. Lift the drill up and down
occasionally to remove residue to reduce binding.
4. Drill the hole for anchor bolt completely through the concrete. If an error is made during
the installation of these anchors, this will allow for the anchor bolt to be driven down into
the ground, so that a new anchor may be installed in place (g.1).
5� Be sure to clean all dust from hole� (g. 2).
6. Place a at washer and hex nut over threaded end of anchor, leaving approximately 1/4
inch of thread exposed above the nut (g.3). Carefully tap anchor into the concrete until
nut and at washer are against base plate. Be sure to only tap the top of the anchor and
not the nut. This could cause damage to the threads of the anchor.
7. Tighten the nut (g. 4) to 85 ft-lbs of torque (typically this should only be two to three full
turns).
DO NOT USE AN IMPACT WRENCH TO TIGHTEN ANCHORS!

9
6-INSTALLATION INSTRUCTIONS
1) After unloading the lift, place it near the intended installation location.
2) Remove the shipping bands and packing materials
from the unit.
3) Remove the packing brackets and bolts holding the
two columns together. Check to ensure all parts
arrived according to the parts list.
4) Once the lift location is decided, chalk the center line
in the bay and ensure that the proper lift placement
is observed from walls and obstacles. Also check the
ceiling height for clearance in this location. NOTE: the power unit column can be placed
on either side.
5) Assemble the overhead crossbar for model HD2P-9KCL. This is also a good time to
mount the brackets for the safety shut-off bar, the bar itself, and the shut-off switch. (Be
sure to leave bolts hand-tight.)
6) Position the columns facing each other 132.25” from the outside of the base plates,
then raise each carriage to the rst safety lock. NOTE: The power unit column is referred
to as the main side column and the non power unit column is referred to as the offside
column.
7) Using a 3/4” concrete drill bit, drill the anchor holes in the main side column, installing
anchors as you go (see Fig. 11, page 31). Use a block of wood or rubber mallet to drive
anchor bolts in.
8) Using a level , check column for side-to-side plumb and front-to-back plumb. Using
3/4” washers or shim stock, place shims as close as possible to the hole locations as
needed. Torque 3/4” anchor bolts to 85 ft-lbs. NOTE: DO NOT USE IMPACT WRENCH.
9) Using a tape measure, measure diagonally from the face of one column to the opposite
face of the other to ensure that the columns are square (see below). After conrming
the dimensions, install the overhead crossbar to the top of the columns (hand-tight).
BEFORE drilling the anchors for the offside column, ensure the column is square and
double check measurements. Drill the anchor holes in the offside column, installing
anchors as you go. Check front to back and side to side plumb before torquing anchors
to 85 ft-lbs. Use shims as needed.
*As a reference - the distance between columns should be 110�25” at the top and at
the bottom of the lift�*
PLEASE READ THIS INSTRUCTION BEFORE STARTING TO OPERATE THE LIFT.
105.50”
18.00”
13.50”
110.25” (Face of Column)

10
10) After both columns are properly torqued, tighten the (8) crossbar bolts.
11) Install safety lock release pulley brackets to the top of each column.
12) Install the safety cable, by routing through the pulleys
mounted on both columns.
13) Installing the equalizing cables: Route cables through
carriages and around pulleys as shown in diagram.
Secure cables to the carriage using on the two supplied
cable nuts. (The second nut will be used as a jam nut
after nal adjustments are made to cable.) Take up slack
in both cables by hand tightening cable nuts.
14) Properly route the hydraulic hoses from each column
through the guides on the overhead crossbar. Connect
both hoses using the supplied male union tting.
15) Install the power unit to the main side column using the supplied bolts, washer, and
nuts. Install the short hose to make the connection between the hydraulic hose tting on
the cylinder and the hydraulic tting on the power unit.
NOTE: Hydraulic tting may need to be moved
to the port on the opposite side of the valve
body on certain lift models. It is required that a
licensed electrician make the electrical hookup
to the power unit.
The power unit must be wired to a 220V single
phase, dedicated 30A circuit. Route safety
shut-off switch wiring down the channel on
the inside of the main side column, along side
the hydraulic hose. Insert the end of the wire
through the hole in the column and into the
junction box of the power unit where the nal
connection will be made.
Top Cable
Sheave
Equalizing
Cable*2
Locking
Nuts*4
Bottom
Cable Sheave
Carriage
WARNING: The wiring must comply with local code. Have a certied licensed
electrician make the electrical hook-up to the power unit. Protect each circuit with time delay
fuse or circuit breaker 208v.230v single Phase. 60Hz 30 Amp.

11
WARNING: DO NOT PERFORM ANY MAINTENANCE OR INSTALLATION
OF ANY COMPONENTS WITHOUT FIRST ENSURING THAT ELECTRICAL POWER
HAS BEEN DISCONNECTED AT THE SOURCE OR PANEL AND CANNOT BE RE-
ENERGIZED UNTIL ALL MAINTENANCE AND/OR INSTALLATION PROCEDURES
ARE COMPLETED.
DANGER: DO NOT RUN POWER UNIT WITHOUT FLUID. DAMAGE TO PUMP
CAN OCCUR. THE POWER UNIT MUST BE KEPT DRY. DAMAGE TO POWER UNIT
CAUSED BY WATER OR OTHER LIQUIDS SUCH AS DETERGENTS, ACID ETC., IS
NOT COVERED UNDER WARRANTY.
16) Install the lifting arms and arm restraint pins. The arm restraint pins must be installed
from the bottom of the mount. This will require removal of the handle, nut, lock washer,
at washer, and gear block.
17) Adjust the arm lock gear and the arm lock until they mesh, then tighten the nut of the
arm lock.
18) Grease the (4) inside corners of each column to prevent premature wear of the nylon
slide blocks and also to ensure smooth operation of the lift.
19) Fill power unit reservoir with (10)quarts of premium quality ISO-32, AW-32, or AW-46
hydraulic oil only. Be sure to periodically check dipstick to prevent spillage. NOTE: This is
a good time to check if all ttings on the lift are tightened properly.
20) Press and hold power button on motor to operate lift. Raise carriages all the way to the
top of the lift, then lower carriages down to the ground to bleed air from the hydraulic
system prior to adjusting cable tension. NOTE: Cables must be adjusted so that the
safety locks engage simultaneously prior to lifting any weight.
Use 5/8” wrench to
tighten the nut.
Lock the nut.
Arm lock
Arm lock gear

12
7-OPERATION INSTRUCTIONS
WARNING: LIFT OPERATION BY TRAINED AUTHORIZED PERSONNEL OVER
18 YEARS ONLY. APPLY THE PARKING BRAKE AFTER POSITIONING THE VEHICLE
ON THE LIFT. DO NOT ALLOW ANYONE TO STAY IN LIFT AREA DURING RAISING
AND LOWERING CYCLES. CLOSELY WATCH THE VEHICLE AND THE LIFT DURING
RAISING AND LOWERING CYCLES. OBSERVE THE RATED LOAD CAPACITY AND
LOAD DISTRIBUTION. DO NOT ALLOW ANYONE TO CLIMB ON LIFT OR STAY
INSIDE VEHICLE. AFTER RAISING THE VEHICLE FRAME 6”, STOP AND CHECK
ADAPTERS FOR SECURE CONTACT. PERFORM BUMPER TEST(PG.2). MAKE SURE
THE VEHICLE DOORS ARE CLOSED DURING RAISING AND LOWERING CYCLES.
WARNING: IN CASE OF DEFECTS OR MALFUNCTIONS SUCH AS JERKY LIFT
MOVEMENT OR DEFORMATION OF THE SUPERSTRUCTURE, SUPPORT OR LOWER
THE LIFT IMMEDIATELY. CONTACT QUALIFIED SERVICE PERSONNEL.
WARNING: PAY CLOSE ATTENTION WHEN SETTING THE LOCKS. THE LOCKS
MUST BE A LEVEL MATCH SET IN ORDER TO AVOID A VEHICLE TILT.
WARNING: ALWAYS LOCK THE LIFT BEFORE GOING UNDER THE VEHICLE.
NEVER ALLOW ANYONE TO GO UNDER THE LIFT WHEN RAISING OR LOWERING.
7.1 DEFECTS / MALFUNCTIONS
7.2 CONTROLS
7.2.1 UP CONTROL
7.2.2 SAFETY LOCK CONTROL
The safety latch mechanism will “Trip Over” as the lift raises and drop into each safety latch
stop. To lock the lift you must press the lowering handle on the power unit (Fig. 1) to relieve
the hydraulic pressure and let the safety locks engage into a level locked position.
Once the up button is actuated, the lift moves up until the button is
released or the limit stop is reached.
UP

13
1. Before driving a vehicle onto the lift make sure the lift is fully lowered. Before driving a
vehicle onto the lift, position the lift arms outward. Do not hit or run over the lifting arms,
as this could damage the vehicle and/or lift. Make sure the lift is fully lowered before
moving the vehicle over the lift. NOTE: It is recommended to swing both arms outward
pointing toward the front of the lift prior to loading a vehicle into the HD2P-9KCL.
2. Drive the vehicle over the lift while keeping the vehicle parallel with the lift and aligning
the center of gravity of the vehicle with the center of the lift. NOTE: The “Center of
Gravity” (COG) of the vehicle is the balance point at which there is equal weight in front
of and behind the COG, and equal weight on both sides of the COG. The COG is not
necessarily the dimensional center of the vehicle, but is often slightly toward the engine
from the dimensional center of the vehicle.
3. Turn off the vehicle’s engine and engage the parking brake of the vehicle.
4. Read the vehicles owner’s manual to identify the recommended vehicle lifting points.
5. Prepare the work area according to this manual. Move the lifting arms inward, and
position the rubber pads to contact with the vehicle manufacturer’s recommended lifting
points.
Press the up button enough to allow the safety locks to be disengaged.
Pull the latch release handle (Fig. 1) to release the safety locks.
WARNING: ALWAYS ENSURE BOTH SIDES RELEASE.
Press the lowering handle (Pg. 17 Fig. 2) until the lift is completely
lowered.
7.3 OPERATION
NOTE: IT IS NORMAL FOR AN EMPTY LIFT TO LOWER SLOWLY - IT MAY BE
NECESSARY TO ADD WEIGHT.
7.2.3 LOWERING CONTROL
WARNING: FAILURE TO OPERATE THE LIFT ACCORDING TO THIS MANUAL
MAY CAUSE DAMAGE TO THE LIFT, PROPERTY DAMAGE AND/OR PERSONAL
INJURY.
Fig. 1
IMPORTANT: PLACE THE FOUR RUBBER PADS UNDER EDGE OF VEHICLE AT
THE FOUR JACK POINTS.
6. Once the lifting arms have been positioned under the vehicle lifting points, operate the
power switch to make contact and lift the vehicle slightly. Test to make sure the vehicle
is well balanced and the contact between the rubber pads and vehicle lifting points are
secure by performing the “BUMPER TEST.” (pg. 2) Then proceed to lift the vehicle to the
desired height.

14
7. WARNING: Do not lift the vehicle if you cannot establish secure and level lifting
points. Do not use sub-standard shims or other devices in place of approved and
recommended rubber pad adapters. Never use the lift without the rubber pads in place on
each plate and in contact with the lifting points of a vehicle.
8. Press up button and raise vehicle to desired height. Do not go under vehicle until load
rests on level safety locks.
9. While lifting the vehicle a clicking sound should be noticeable which indicates the safety
mechanism is operating. If this sound is not heard, immediately cease using the lift and
call an authorized service agent.
10. When lift reaches maximum height, a limit switch will come into operation and stop the
lift. When lift has stopped, press and hold the lowering handle (Fig. 1) until load rests on
level safety locks.
11. Once the repair work to the vehicle is complete, make sure to remove all tools, safety jack
stands, and materials from under the vehicle and lift. Also, make sure the work area is
clear and it is safe to lower the vehicle.
12. Lower vehicle by pressing the Up button to disengage the safety locks. Pull the latch
release to release (Fig. 2) the safety locks then press the lowering handle (Fig. 1) until the
lift is completely lowered.
13. Move the lifting arms outward, out of the path of the vehicle. Clear all bystanders, and
any objects from work area and direction of vehicle.
14. Disengage the vehicle parking brake. Start the vehicle’s engine, and drive the vehicle off
the lift slowly and carefully.
WARNING: THE OPERATOR MUST BE TRAINED AND AUTHORIZED TO
OPERATE THE LIFT.
WARNING: DO NOT GO UNDER VEHICLE UNDER ANY CIRCUMSTANCES
WHILE VEHICLE IS BEING RAISED OR LOWERED.
WARNING: LOAD MUST BE EVENLY DISTRIBUTED BETWEEN BOTH LIFTING
PLATFORMS. IF LOAD IS UNBALANCED, REPOSITION VEHICLE. DO NOT LOWER
ON TO LOCKS AT DIFFERENT HEIGHTS.

15
8-MAINTENANCE
WARNING: DISCONNECT THE POWER BEFORE SERVICING THE LIFT.
IMPORTANT: THE MAINTENANCE INTERVALS INDICATED BELOW APPLY TO
AVERAGE WORKSHOP USE. THE LIFT SHOULD BE INSPECTED MORE FREQUENTLY
FOR SEVERE USE APPLICATIONS.
It is important to keep the lift clean, dry, lubricated and well maintained by establishing a periodic
preventive maintenance program to ensure trouble-free operation and long service life.
1. Check safety locking mechanism is functioning correctly.
2. Check safety lock audibly and visually while in operation.
3. Check safety latches for free movement and full engagement with rack.
4. Inspect the condition of rubber lifting pads and replace as necessary if worn or torn.
5. Check hydraulic connections, and hoses for leakage.
6. Check chain connections - Bends, cracks - and looseness.
7. Check for frayed cables in both raised and lowered positions.
8. Check snap rings at all rollers and sheaves.
9. Check bolts, nuts, and screws and tighten.
10. Check wiring & switches for damage.
11. Keep base plate free of dirt, grease or any other corrosive substances.
12. Check oor for stress cracks near anchor bolts.
13. Check swing arm restraints.
1. Check anchor bolts torque to 85 ft-lbs for the 3/4’’ anchor bolts. NOTE:
DO NOT USE IMPACT WRENCH.
2. Check oor for stress cracks near anchor bolts.
3. Check hydraulic oil level.
4. Check and tighten bolts and nuts, and screws.
5. Check cylinder pulley assembly for free movement or excessive wear on cylinder yoke or
pulley pin.
6. Check cable pulley for free movement and excessive wear.
8.1 MAINTENANCE SCHEDULE
8.1.1 DAILY
8.1.2 WEEKLY

16
8.1.3 MONTHLY
8.1.4 BI-MONTHLY
8.1.5 YEARLY
1. Check safety mechanism operation.
2. Check condition of shafts, shaft locks and bushings.
3. Check overall cleanliness.
1. Check condition of extensions and lubricate.
2. Check for oil leaks from cylinders.
3. Check for oil leaks at pipe joints.
Service and safety inspection on the lift must be performed by a competent person. This
inspection must be recorded. If the 12 month service and safety inspection is not performed,
the warranty is null and void.
1. Lubricate chain.
2. Grease the inside corners of the columns.
3. Change the hydraulic uid. A good maintenance program makes it mandatory to keep
hydraulic uid clean. Operating temperature, type of service, contamination levels,
ltration, and chemical composition of uid should be considered. If operating in harsh or
dusty conditions, a shorter interval may be required.
THE FOLLOWING ITEMS SHOULD ONLY BE PERFORMED BY A TRAINED
MAINTENANCE EXPERT.
• Replace hydraulic hoses.
• Replace chains and rollers.
• Replace cables and sheaves.
• Replace or rebuild air and hydraulic cylinders as required.
• Replace or rebuild pumps / motors as required.
• Check hydraulic and air cylinder rod and rod end (threads) for deformation or damage.
• Check cylinder mount for looseness and damage.
Relocating or changing components may cause problems. Each component in the system
must be compatible; an undersized or restricted line will cause a drop in pressure. All valve,
pump, and hose connections should be sealed and/or capped until just prior to use. Air
hoses can be used to clean ttings and other components. However, the air supply must be
ltered and dry to prevent contamination. Most important - CLEANLINESS - contamination is
the most frequent cause of malfunction or failure of hydraulic equipment.

17
8.2 MAINTENANCE BY OPERATOR
8.2.1 HYDRAULIC SYSTEM
8.2.2 GREASING POINTS
All moving parts have been lubricated at the factory and should be re-lubricated before the
rst use and at least once every six months to prevent damage.
1. Check the uid level with the lift fully lowered and add uid as required. Use premium
quality ISO-32, AW-32, or AW-46 hydraulic oil.
2. Visually check all hydraulic hoses and connections for tightness before each use to
ensure proper working condition.
3. Lightly oil the cylinder rods at least once every six months or when they become dry.
IMPORTANT: AFTER CLEANING WORKSHOP FLOOR OR LIFT, TO MAINTAIN
HOIST EFFICIENCY WE ADVISE TO LUBRICATE LIFTING ARM LOCKING
MECHANISM, AND SAFETY LOCKING MECHANISM. CHECK SAFETY LOCKING
MECHANISM IS FUNCTIONING CORRECTLY.
FIG. 2
SLIDE TRACKS:
• The carriage assembly slide tracks should be greased every six months (or more
frequently in case of noise generation).
• Slightly grease the slide tracks over their whole length using a brush.
ARM PINS:
• Grease the arm pins to prevent excessive wear
