Titan TCS-5525 User manual

Dealer Name
Dealer Phone
Serial Number
P/N 9027 • 10/17
512 West Gorgas Street §P.O. Box 3912 §Louisville, OH 44641-3912
1-800-822-8356
Attention Installer: Please be sure this manual and warranty information
are left with the power unit or customer when installation is complete.
Operating Instructions For
TITAN
Central Vacuums:
MODELS TCS-5525
& TCS-8575
Read Manual Before Operating System
Read the owner’s manual thoroughly before operating to
ensure the most efficient use of the system.

ModelsTCS-5525&TCS-8575
2
Models UL File Ref. # ETL File Ref. #
TCS-5525 N/A 99300
TCS-8575 N/A 99500

ModelsTCS-5525 &TCS-8575
3
TABLE OF CONTENTS:
Important Safety Instructions ....................................................................... 3
Grounding Instructions ................................................................................. 5
General Information ...................................................................................... 6
Registration ................................................................................................... 6
Operating Instructions .................................................................................. 6
General Maintenance .................................................................................... 6
Emptying the Dirt Canister and Filter Maintenance .................................... 7
Troubleshooting ............................................................................................. 8
IMPORTANTES MESURES DE SECURITÉ .................................................... 9
INSTRUCTIONS DE MISE À LA TERRE ....................................................... 11
Warranty ........................................................................................................ 12
IMPORTANT SAFETY INSTRUCTIONS
Read These Instructions Before Using This Vacuum System
Installation of this product should be made by a qualified, authorized
central vacuum dealer. Before installing, using, or servicing this product,
the installer should carefully read and fully understand the instructions
including all warnings, cautions, and safety notice statements. To
reduce the risk or personal injury, death and/or property damage, follow
all instructions for proper installation, operation and maintenance.
These instructions are not intended as a complete listing of all details
for installation, operation and maintenance. If you have any questions
concerning any of these procedures, STOP, and call an authorized central
vacuum dealer.

ModelsTCS-5525&TCS-8575
4
When using an electrical appliance, basic precautions should always be
followed, including the following:
WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC
SHOCK OR INJURY:
• Unplug and disconnect power before servicing.
• Do not allow to be used as a toy. Close attention is necessary when used
by or near children.
• Use only as described in this manual. Use only manufacturer’s
recommended attachments.
• Do not use with damaged cord or plug. If appliance is not working as
it should, has been dropped, damaged, left outdoors, or dropped into
water, return it to an authorized servicing dealer.
• Do not pull or carry by cord, use cord as a handle, close a door on cord,
or pull cord around sharp edges or corners. Do not run appliance over
cord. Keep cord away from heated surfaces.
• Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
• Do not handle system or appliance with wet hands.
• Use extra care when cleaning on stairs.
• Do not use on wet surfaces.
• Do not put any object into openings. Do not use with any opening
blocked. Keep openings free of dust, lint, hair, and anything that may
reduce airflow.
• Keep hair, loose clothing, fingers, and all parts of body away from
openings and moving parts.
• Do not pick up anything that is burning or smoking, such as cigarettes,
matches, or hot ashes.
• Connect to a properly grounded outlet. See grounding instructions.
• Turn off all controls before unplugging.
• Do not use to pick up flammable or combustible liquids such as gasoline
or use in areas where they may be present.
• Do not place or store anything on top of power unit - overheating of
motor could occur.
• Do not use without filter in place.
• Any service work required under the top cover should be performed by
an authorized service representative.

ModelsTCS-5525 & TCS-8575
5
GROUNDING
INSTRUCTIONS
This appliance must be grounded.
If it should malfunction or break
down, grounding provides a path of
least resistance for electric current
to reduce the risk of electric
shock. This appliance is equipped
with a cord having an equipment
grounding conductor and grounding
plug. The plug must be plugged
into an appropriate outlet that is
properly installed and grounded in
accordance with all local codes and
ordinances.
WARNING
Improper connection of the
equipment-grounding conductor
can result in a risk of electric
shock. Check with a qualified
electrician or service person if
you are in doubt as to whether the
outlet is properly grounded. Do not
modify the plug provided with the
appliance. If it will not fit the outlet,
have a proper outlet installed by a
qualified electrician.
Models TCS-5525 & TCS-8575 are
for use on a nominal 120 volt circuit
and has a grounding plug that looks
like the plug in Fig. A .
Make sure that the appliance is
connected to an outlet having the
same configuration as the plug. No
adapter should be used with this
appliance.
CONNECT TO A PROPERLY GROUNDED OUTLET ONLY.
SAVE THESE SAFETY INSTRUCTIONS
Intended For Household and Light Commercial Use. Do not vent into a
wall, a ceiling, or concealed space of a building or structure.
WARNING:
Electric shock could occur
if used on wet surfaces.
CAUTION:
Do not use on a
wet rug or floor.

ModelsTCS-5525&TCS-8575
6
GENERAL INFORMATION
Do not store objects on top of the power unit. This will block the motor cooling
ventilation. Restricting the cooling airflow may shorten the motor life.
The central vacuum is designed to vacuum ordinary household dirt and
dust. The system is designed for dry pickup.
The central vacuum system is a network of inlet valves, 2” PVC tubing, and
low voltage wiring installed in the walls of your home. The dirt is transported
through the in-wall tube system back to the dirt canister (located on the
power unit).
REGISTRATION
To register your TITAN system warranty in the United States and Canada,
register online at www.cvacregistration.com or fill out and mail the
warranty card located with this manual.
Proof of purchase or registration of the TITAN System is required before
any warranty work will be performed by an authorized dealer. Registration
ensures a fast and easy resolution to your warranty requirements.
OPERATING INSTRUCTIONS
Using the central vacuum system is easy. For standard systems, simply raise
the inlet valve lid, insert the hose end and attach the desired cleaning tool to
the hose wand. The power unit is activated when the hose is inserted into the
valve. Please refer to accessory instructions for further specifics on usage.
GENERAL POWER UNIT MAINTENANCE
The simple care and maintenance instructions included here will help
ensure trouble-free use of the central vacuum system.
• Do not place objects on top of the power unit. The motor could overheat.
• Do not allow the motor to remain ON unless a hose is connected or an
inlet valve is open. If airflow is not permitted to flow through fan blades,
motor damage may occur.
• Do not operate without the filter in place.
• Change the filter cartridge once a year.
• Empty the dirt canister when it is 2/3 full.
• The power unit does not require any lubrication.
• The exterior of the power unit can be wiped with a clean, dry cloth. Do
not use liquid cleaners or water as an electrical shock may occur.
• For additional service contact the qualified servicing dealer written
on the front of this manual.

ModelsTCS-5525 & TCS-8575
7
7
EMPTYING THE DIRT CANISTER & MAINTAINING THE
FILTER CARTRIDGE
The dirt canister is the removable lower portion of the power
unit. The canister needs to be removed and emptied when it is
2/3 full. The filter should be replaced once a year.
NOTE: When the dirt canister is removed the cyclonic cone will be visible.
The cone is held in place with a friction seal designed to hold the cone to
the body of the power unit when the canister is removed. The cone can be
removed by pulling on it. This allows access to the filter.
Follow These Steps (refer to Figures 1-4)
Make sure the power unit is OFF.
1. Unlatch and remove the dirt canister. Latches are located on opposite
sides of the power unit. (Fig. 1)
2. Remove the cyclonic cone. (Fig. 2)
3. Turn the filter latch (counter-clockwise) on the bottom of the filter and
align it with the slots in the filter base. (Fig. 3)
4. Remove the filter and gently tap it on the inside of the dirt canister to
remove the loose dirt and debris. The filter should be replaced at least
once a year. If it is time to replace it, model TCS-5525 uses filter 8106-01
and model TCS-8575 uses filter 8107-01. (Fig. 4)
5. Lock the filter in place by turning the filter latch clockwise until you feel
it snap. (Fig. 3)
6. Dispose of the dirt and debris captured in the dirt canister.
7. Seat the cyclonic cone in the dirt canister.
8. Raise the dirt canister to the base of the power unit and engage the
latches. Be certain the dirt canister is seated properly to the gasket on
the body of the power unit.
FIG. 3
FIG. 1
FIG. 4
FIG. 2

ModelsTCS-5525&TCS-8575
8
TROUBLESHOOTING THE SYSTEM
Motor Fails to Turn on
If the system fails to turn on when engaged, check the following:
• Check the main fuse or circuit breaker at the main power supply panel of
your home. Reset breaker or replace fuses if necessary.
• Check the power unit reset button located above the power cord.
Pressing the button should restore operation.
• If the circuit protector continues to trip off after a short period of time,
the motor brushes may be worn out. Contact the qualified servicing
dealer written on the front of this manual.
Loss of Vacuum
If the system shows a loss of vacuum power, check the following:
• The dirt canister may need cleaned or the filter may need replaced –
Follow instructions in this guide on page 7.
• The hose may be clogged – To check if there is an obstruction, unplug the
hose and insert an object that is smaller then the diameter of the hose (a
butter knife works well). Pass the object completely through the hose, if
it stops, that will indicate where the obstruction is located. A dry garden
hose can be inserted into the hose to help push the obstruction through.
• The dirt canister may not be properly seated to the gasket – Follow
instructions for replacing the dirt canister on page 7, Step 8.
• Tube lines may be obstructed – First check the 90° elbow located directly
behind the inlet valves, if an obstruction occurs it will usually not make
it past this elbow. If the obstruction is not visible at the elbow, attempt to
purge the tubing at each inlet valve. To do this, connect the hose and use
your hand to stop airflow at the end of the hose for a couple seconds, let
airflow resume. Repeat if necessary.
• If necessary, contact the qualified servicing dealer written on the front of
this manual.
Obtaining Service Under Warranty: To obtain repair on warranted parts,
contact the seller of the system with the power unit serial number.

ModelsTCS-5525 & TCS-8575
9
IMPORTANTES MESURES DE SECURITÉ
Lisez Complètement Le Mode D’emploi Avant D’utiliser Ce Système D’aspirateur.
L'installation de ce produit doit être effectuée par un concessionnaire
agréé et agréé. Avant d'installer, d'utiliser ou d'entretenir ce produit,
l'installateur doit lire attentivement et comprendre complètement
les instructions, y compris tous les avertissements, mises en garde
et déclarations de sécurité. Pour réduire le risque ou les blessures
corporelles, le décès et / ou les dommages matériels, respectez toutes
les instructions pour une installation, une opération et une maintenance
appropriées. Ces instructions ne sont pas une liste complète de tous les
détails pour l'installation, l'exploitation et la maintenance. Si vous avez des
questions concernant l'une de ces procédures, arrêtez-la et appelez un
revendeur autorisé de l'aspirateur central.
En employant un appareil électrique, des précautions fondamentales
devraient toujours être prises, y compris :
AVERTISSEMENT: POUR RÉDUIRE LES DANGERS DE
FEU, D’ÉLECTROCUTION, OU DE BLESSURE:
• Débrancher et couper le courant avant de le réparer.
• Ne pas utiliser sur des surfaces mouillées.
• Ne pas utiliser comme jouet et surtout faire attention quand on l’emploie
prés des enfants.
• Employer seulement tel que décrit dans ce manuel d’emploi et qu’avec
les accessories du fabricant.
• Ne pas utiliser si la corde ou la prise électrique est endommagée. Si
l’appareil ne fonctionnne pas, est endommagé, est tombé par terre, a
été laissé à l’extérieur, ou a été immergé, dans l’eau, veuillez rapporter
l’appareil à un centre de service.
• Ne pas tirer sur le cordon eléctrique. Ne pas utiliser le cordon eléctrique
comme poignée, ni le coincer dans une porte ou l’appuyer sur des
coins et boudures tranchants. Ne pas passer l’aspirateur sur le cordon
électrique. Eloigner le cordon électrique de la chaleur.
• Ne pas débrancher en tirant sur le cordon électrique. Pour le
débrancher, saisir la prise de courant, et non le cordon électrique.
• Ne pas utiliser avec les mains mouillées.

ModelsTCS-5525&TCS-8575
10
• Ne rien mettre dans les fentes et les orifices bouchés. Ne pase employer
avec des orifices bouches. Éliminer poussiére, cheveux et les autres
choses qui peuvent rendre difficile la circulation d’air.
• Gardez cheveux, vêtements amples, doigts, et toutes autres parties du
corps loin des orifices et des piéces mobiles.
• Ne pas aspirer queique chose qui brûle ou fume, comme des cigarettes,
des allumettes, ou des cendres chaudes.
• Brancher à une prise de courant munie d’une mise à la terre. Voir les
reseignements de mise à la terre.
• Éteindre tous les contrôles avant de débrancher.
• Faire bien attention en nettoyant les escaliers.
• Ne pas utiliser pour aspirer des liquides infammables comme l’essence
et ne pas employer dans des endroits où ces choses peuvent se trouver.
• Ne rien placer ou entreposer sur le dessus de l’appareil - une surchauffe
du moteur pourrait se produire.
• N’importe quel travail de service exigé sous la couverture supérieure
devrait être effectué par un technicien autorisé.

ModelsTCS-5525 & TCS-8575
11
NE BRANCHER L’APPAREIL QU’À UNE
PRISE AVEC MISE À LA TERRE.
INSTRUCTIONS DE MISE À LA
TERRE
Cet appareil doit avoir une mise à la
terre. Si une défectuosité ou autre
survenait, la mise à la terre offre une
voie de moindre résistance au courant
électrique, d’où un risque moins élevé d
électrocution. Cet appareil est
équipé d’ un cordon électricque
ayant un conducteur et une fiche de
mise à la terre. Cette fiche doit être
branchée dans une prise appropriée
qui a été installée et mise à la terre
convenablement en accord avec le code
électrique de votre région.
AVERTISSEMENT
Un branchement incorrect
de l’équipement de mise à la
terre peut causer un risque
d’électrocution. Si vous avez un
doute concernant la mise à la
terre de votre prise, veuillez faire
vérifier votre installation par un
électricien qualifié ou une personne
du service après-vente. Ne pas
modifier la fiche fournie avec
l’appareil - si la fiche ne se branche
pas à la prise, faites installer une
prise adéquate par un électricien
qualifié.
Les appareils, modéle TCS-5525
& TCS-8575 doivent être employés
avec un circuit de 120 volts et avoir
une prise qui ressemble à la prise
illustrée sur I’image A.
Vérifiez que votre appareil est
branché sur une prise ayant la
même configuration que la fiche
électrique. Aucun adapteur ne
devrait être utilisé avec cet appareil.
CONSERVEZ CES
INSTRUCTIONS
Usage réserve pour la maison ou
emploi commercial léger. Ne pas
ventiler dans un mur, un plafond, ou
un espace dissimule d’un bâtiment ou
un édifice.
ATTENTION :
NE PAS UTILIZER SUR TAPIS OU
PLACHER MOUILLE.

ModelsTCS-5525&TCS-8575
12
LIFETIME RESIDENTIAL
LIMITED WARRANTY
The TITAN Built-In Central Vacuum System (the “ TITAN System”) is manufactured by H-P Products,
Inc. (“H-P”), 512 W. Gorgas Street, Louisville, Ohio, 44641. The following is the exclusive limited
warranty (“Limited Warranty”) provided by H-P with respect to the TITAN System:
Permanently Installed Components
All permanently installed components of the TITAN System are warranted to be free from defects
in material and workmanship under normal use and care as long as the original purchaser
(“you”) owns the home of the original installation or until the system is removed from its original
installation location, whichever occurs first. In the event of a defect in a permanently installed
component of the TITAN System, you must contact an authorized TITAN dealer (an “Authorized
Dealer”). Upon determination of a defect with the permanently installed product, H-P will provide
any replacement parts to the Authorized Dealer at no cost to you.
Attachments
TITAN System cleaning attachments including: turbine power brushes, non-electric hoses,
wands, tools and tool caddies are warranted to be free from defects in material and workmanship
under normal use and care for three (3) years from original date of consumer purchase. In the
event of a defect in a System cleaning attachment, H-P will provide, at its option, parts for repair
or replacement to the Authorized Dealer at no cost to you for three (3) years from original date
of consumer purchase. Electric powerheads and hoses are warranted to be free from defects
in material and workmanship under normal use and care for one (1) year from original date of
purchase, as more fully set forth in the electric powerhead manual.
Limitations for Non-Residential Applications
In non-residential applications (a) permanently installed components of the TITAN System are
warranted to be free from defects in material and workmanship for one (1) year from date of
original installation, and (b) TITAN System cleaning attachments will be free from defects in
material and workmanship for ninety (90) days from the original date of purchase.
Limitations of Warranty
In addition to any limitations set forth above, this Limited Lifetime Warranty does not cover (a)
any power unit purchased from someone other than an Authorized Dealer; (b) any TITAN System
which has not been installed in accordance with manufacturer-recommended instructions; (c)
any TITAN System or attachment which has been altered or modified in any way; (d) any TITAN
System or attachment which has been damaged due to misuse, negligence, accident, or improper
operation; (e) any damage due to shipping and handling; (f) any damage due to installation or
faulty installation; (g) any TITAN System or attachment upon which an unauthorized repair or
service has been performed; (h) any damage to a permanently installed component as a result
of or relating to consumable items such as motor brushes, disposable bags, or filters. There is
NO warranty for consumable items such as light bulbs, belts, beater brushes, motor brushes,
disposable bags and filters.
AS A CONDITION PRECEDENT TO WARRANTY COVERAGE HEREUNDER, YOU MUST PROVIDE
PROOF OF PURCHASE OR HAVE REGISTERED THE SYSTEM’S POWER UNIT BY TELEPHONE
AT 1-800-822-8356 OR ONLINE AT WWW.CVACREGISTRATION.COM, OR BY COMPLETING AND
MAILING THE WARRANTY REGISTRATION CARD.
THIS WARRANTY IS A SOLE AND EXCLUSIVE WARRANTY. ALL OTHER WARRANTIES INCLUDING
IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE
ARE EXCLUDED. THIS WARRANTY COVERS ONLY LIABILITY AND RESPONSIBILITY DESCRIBED
HEREIN AND THERE IS NO LIABILTY FOR ANY CONSEQUENTIAL, INCIDENTAL OR SPECIAL
DAMAGES ARISING FROM THE USE OF THIS SYSTEM.
Some states do not allow exclusion or limitation or warranties or limitation of incidental or
consequential damages so the above exclusion may not apply to you. This warranty gives you
specific legal rights and you may have other rights that vary from state to state.
