200W MULTI-CUTTER TTB507HTL
SAFETY AND OPERATING MANUAL
Original Instructions
24

200W MULTI-CUTTER TTB507HTL
GUARANTEE
This product carries a guarantee of 24 months. If your product develops a
fault within this period, you should, in the first instance contact the retailer where the
item was purchased.
This guarantee specifically excludes losses caused due to:
- Fair wear and tear
- Misuse or abuse
- Lack of routine maintenance
- Failure of consumable items (such as batteries)
- Accidental dammage
- Cosmetic damage
- Failure to follow manufacturer’s guidelines
- Loss of use of the goods
This guarantee does not affect your statutory rights.This guarantee is only valid in the
UK.
For any enquiries relating to the guarantee please refer to your retailer.
Congratulations on your purchase of a . Power tool from
Titan Power Tools (UK) Ltd. We want you to continue getting the best
performance from it so this handbook includes information on safety,
handling and care. Please retain this handbook in case you need to refer to
any of the information in the future.
Your power tool comes with a 24-month guarantee, so should it
develop a fault within this period contact your retailer.

GENERAL SAFETY INSTRUCTIONS
WARNING! Read all safety warnings designated by the symbol and all instructions.
WARNING! Read all safety warnings and all instructions. Failure to follow the
warnings and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
1. Work area safety
a. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b. Do not operate power tools in explosive atmospheres, such as in the
presence of flammable liquids, gases or dust. Power tools create sparks which
may ignite the dust or fumes.
c. Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.
2. Electrical safety
a. Power tool plugs must match the outlet. Never modify the plug in any way.
Do not use any adapter plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce risk of electric shock.
b. Avoid body contact with earthed or grounded surfaces, such as pipes,
radiators, ranges and refrigerators.There is an increased risk of electric shock if
your body is earthed or grounded.
c. Do not expose power tools to rain or wet conditions. Water entering a power
tool will increase the risk of electric shock.
d. Do not abuse the cord. Never use the cord for carrying, pulling or
unplugging the power tool. Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords increase the risk of electric shock.
e. When operating a power tool outdoors, use an extension cord suitable for
outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
f. If operating a power tool in a damp location is unavoidable, use a residual
current device (RCD) protected supply. Use of an RCD reduces the risk of electric
shock.
3. Personal safety
a) Stay alert, watch what you are doing and use common sense when operating a
power tool. Do not use a power tool while you are tired or under the influence of
drugs, alcohol or medication. A moment of inattention while operating power tools may
result in serious personal injury.
b) Use personal protective equipment. Always wear eye protection. Protective
equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection used
for appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-position before
connecting to power source and/or battery pack, picking up or carrying the tool.
Carrying power tools with your finger on the switch or energising power tools that have the
switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool on. A

200W MULTI-CUTTER TTB507HTL
wrench or a key left attached to a rotating part of the power tool may result in personal
injury.
e) Do not overreach. Keep proper footing and balance at all times. This enables
better control of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair,
clothing and gloves away from moving parts. Loose clothes, jewellery or long hair can
be caught in moving parts.
g) If devices are provided for the connection of dust extraction and collection
facilities, ensure these are connected and properly used. Use of dust collection can
reduce dust-related hazards.
4. Power tool use and care
a) Do not force the power tool. Use the correct power tool for your application.
The correct power tool will do the job better and safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off. Any power
tool that cannot be controlled with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or the battery pack from the
power tool before making any adjustments, changing accessories, or storing
power tools. Such preventive safety measures reduce the risk of starting the power tool
accidentally.
d) Store idle power tools out of the reach of children and do not allow persons
unfamiliar with the power tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment or binding of moving parts,
breakage of parts and any other condition that may affect the power tool’s
operation. If damaged, have the power tool repaired before use. Many accidents are
caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp
cutting edges are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc. in accordance with these
instructions, taking into account the working conditions and the work to be
performed. Use of the power tool for operations different from those intended could result
in a hazardous situation.
5. Service
a) Have your power tool serviced by a qualified repair person using only identical
replacement parts. This will ensure that the safety of the power tool is maintained.
SAFETY INSTRUCTION FOR CUTTING
1. Hold power tool by insulated gripping surfaces, when performing an operation
where the cutting accessory may contact hidden wiring or its own cord. Cutting
accessory contacting a “live” wire may make exposed metal parts of the power tool “live”
and could give the operator an electric shock.
2. Always wear a dust mask.

VIBRATION
The European Physical Agents (Vibration) Directive has been brought in to help reduce
hand arm vibration syndrome injuries to power tool users.The directive requires power
tool manufacturers and suppliers to provide indicative vibration test results to enable users
to make informed decisions as to the period of time a power tool can be used safely on a
daily basis and the choice of tool.
Further Advice can be found at www.hse.gov.uk
Vibration total values (triax vector sum)determined according to EN60745:
Typical weighted vibration Vibration emission value ah =3.94m/s2
Uncertainty K =1.5m/s²
The declared vibration emission value should be used as a minimum level and should be used with the
current guidance on vibration.
Calculating the actual period of the actual period off use can be difficult and the HSE website has further
information.
The declared vibration emission has been measured in accordance with a standardised test stated
above and may be used to compare one tool with another.
The declared vibration emission value may also be used in a preliminary assessment of exposure.
Warning:The vibration emission value during actual use of the power tool can differ from the
declared value depending on the ways in which the tool is used dependant on the following
examples and other variations on how the tool is used:
How the tool is used and the materials being cut.
The tool being in good condition and well maintained
The use the correct accessory for the tool and ensuring it is sharp and in good condition.
The tightness of the grip on the handles.
And the tool is being used as intended by its design and these instructions.
This tool may cause hand-arm vibration syndrome if its use is not adequately
managed
Warning: Identify safety measures to protect the operator that are based on an estimation of
exposure in the actual conditions of use (taking account of all parts of the operating cycle such
as the times when the tool is switched off and when it is running idle in addition to the trigger time).
NoteThe use of other tools will reduce the users’ total working period on this tool.
Helping to minimise your vibration exposure risk.
ALWAYS use sharp blades.
Maintain this tool in accordance with these instructions and keep well lubricated (where appropriate)
Avoid using tools in temperatures of 10°C or less
Plan your work schedule to spread any high vibration tool use across a number of days.
Health Surveillance
All employees should be part of an employer’s health surveillance scheme to help identity any vibration
related diseases at an early stage, prevent disease progression and help employees stay in work.

200W MULTI-CUTTER TTB507HTL
Double insulation:
The tool is double insulated.This means that all the external metal parts are electrically insulated
from the mains power supply.This is done by placing insulation barriers between the electrical and
mechanical components making it unnecessary for the tool to be earthed.
Important note:
Be sure the supply is the same as the voltage given on the rating plate.The tool is fitted with a two-
core cable and plug.
Always remove the mains plug from socket before carrying out any adjustment or servicing.

SYMBOLS
To reduce the risk of injury, user must read instruction manual
Double insulation
Warning
Wear ear protection
Wear eye protection
Wear dust mask
This product has been marked with a symbol relating to removing electric and electronic
waste.This means that this product shall not be discarded with household waste but
that it shall be returned to a collection system which conforms to the European Directive
2002/96/CE. It will then be recycled or dismantled in order to reduce the impact on the
environment. Electric and electronic equipment can be hazardous for the environment
and for human health since they contain hazardous substances.
yyWxx Manufacturing date code;Year of manufacturing (20yy) and week of manufacturing
(Wxx);

200W MULTI-CUTTER TTB507HTL
4
5
10 9 8 7
3 2
1
11
612 13 14

1. Key storage
2. Variable speed control
3. Venting slots
4. On/Off switch
5. Sanding pad (PERFORATED)*
6. Sanding sheet*
7. Flange
8. Hex key*
9. HSS semicircle saw blade*
10. End cut blade*
11. Dust extraction access
12. Dust collection adapter (35mm)*
13. Dust collection adapter (32mm)*
14. Small flange
Works with other oscillating tool brands’ accessories. The following compatible
brands are trademarks owned by third parties which may be registered by their
respective owners: black & Decker®, bosch®, Chicago Electric®, Craftsman®,
Dremel®, fein®, Genesis®, Makita®, Mastercraft®, Milwaukee®, Performax®, Porter
Cable®, Ridgid®, Ryobi®, Skil®, andTool Shop®.

200W MULTI-CUTTER TTB507HTL
TECHNICAL DATA
Voltage
Power input
Oscillations speed
Oscillations angle
Protection class
Machine weight
NOISE AND VIBRATION DATA
A weighted sound pressure 79dB(A)
A weighted sound power 90dB(A)
KpA&KwA: 3.0dB(A)
Wear ear protection when sound pressure is over 85dB(A)
Typical weighted vibration 3.94m/s2K=1.5m/s2
ACCESSOIRES
Allen key 1
End cut blade 1
Sanding pad (perforated) 1
HSS semicircle saw blade 1
80grit sanding sheet(perforated) 5
180grit sanding sheet(perforated) 5
120grit sanding sheet(perforated) 5
Dust collection adapter (32mm&35mm) 1
Small flange 1
220-240V~50Hz
200W
11000-20000/min
3.2°
/II
1.36kg

OPERATION INSTRUCTIONS
NOTE: Before using the tool, read the instruction book carefully.
Warning: Before working your tool
make sure that no power cords will
be damaged. Before mounting or replacing
application tools or accessories, pull the
power plug.This preventative safety measure
eliminates danger from accidentally starting
the power tool.
Do not touch the gear box after long working time,
because it could be hot.
1. MOUNTING ACCESSORIES
Caution: For all work or when changing
application tools, always wear protective
gloves. Avoid danger of injury from the sharp edges
of the application tools. Application tools can become
very hot while working, presenting danger of burns!
Warning:To reduce the risk of injury, do
not let the Universal end cut blades or
any segment saw blades face back toward the
user’s hand.
- Loosen the flange
Use the Hex Key to rotate the flange clockwise.(See Fig. 1)
- Insert Accessories
For the accessories with machine and most other
branded accessories, the flange must be completely
removed to install accessory (See Fig. 2).
Note: For the Universal-FitTM Accessory
Insert the Accessory onto the Universal-FitTM Accessory
Interface.(See Fig. 4)
- Tighten the flange
Use the Hex Key to rotate the flange counterclockwise
until accessory is tightened securely.(See Fig. 3)
2. MOUNTING / CHANGING THE SANDING
SHEET (See Fig. 5)
Align the sanding sheet and press it onto the sanding
pad by hand.
Firmly press the power tool with the sanding sheet
against a flat surface and briefly switch the power
tool on.This provides for good adhesion and prevents
premature wear.
If one point has become worn, pull off the sanding
sheet, turn it 120° and replace.
a
1
1
2
Fig. 1
Fig. 2
Fig. 3
Fig. 4

200W MULTI-CUTTER TTB507HTL
3. USEING THE SUCTION DEVICE(See Fig. 6-1
6-2)
When vacuuming, insert the adapter(12) into the
access(11) then connecting a vacuum cleaner .
If you use the vacuum cleaner tube (32mm), first
connect it to the adapter (13) then insert into the
access.
Installing the baffle on the sanding pad
Baffle Of Sanding Pad is intended to be used with
vacuum to improve dust collection capabilities.
-Press both sides of the baffle (a) to push it into the
back of the sanding pad, then release the baffle to fix
it into the sanding pad. (See Fig. 6-2)
4. OPERATING THE ON/OFF SWITCH
——Switching the power tool ON:
Slide switch (4) forward (I).
——Switching the power tool OFF:
Slide switch (4) backward (0).
5. USING THE VARIABLE SPEED CONTROL
Select oscillation frequency (speed) while the motor
is running.
The variable speed control (2) can be used to set
the optimum oscillating frequency according to the
accessories used and the respective application.
High oscillation frequency:
Sanding, sawing, rasping and polishing stone and
metal.
Low oscillation frequency:
Polishing varnishes.
6. SANDING
Typical application: wood, metal; small areas,
especially corners, edges and places difficult to
access.
Select high oscillation frequency.
Select high oscillation frequency.
Sand with a constant movement and light pressure.
Heavy pressure does not increase the removal – the
sanding sheet merely wears faster.
7. SAWING WITH THE SEMICIRCLE SAW BLADE
The workpiece must be inserted firmly or clamped
tightly before it is cut.
Typical application: wood, PVC, soft metal sheet.
Select high oscillation frequency .
The saw blade lasts longer if the wear is distributed
evenly.To ensure an even distribution, loosen the
a
1
1
2
Fig. 5
Fig. 6-1
Fig. 6-2

saw blade, rotate it and retighten firmly.
8. SAWING WITH THE END CUT SAW BLADE
(See Fig. 7)
Warning: The sawing teeth are very
sharp. Do not touch during mounting and
application.
The workpiece must be inserted firmly or
clamped tightly before it is cut.
Typical application: wood, plaster board, soft plastics
and metal (e. g. nails).
When plunging and sawing use a slight pendulum
motion, to allow sufficient chip removal.
9. SCRAPING
Typical application: Scraping off old varnish or
adhesives, removing glued carpeting, e. g. on stairs
or other small to medium-sized surfaces.
Select medium / high oscillation frequency.
a
1
1
2
Fig. 7

200W MULTI-CUTTER TTB507HTL
WORKING HINTS FOR YOUR TOOL
If your power tool becomes too hot, especially when
used at low speed, set the speed to maximum and
run it with no load for 2-3 minutes to cool the motor.
Avoid prolonged usage at very low speeds. Always
keep the blade sharp.
Always ensure the workpiece is firmly held or
clamped to prevent movement.
Any movement of the material may affect the quality
of the cutting or sanding finish.
Start your tool before working and turn it off only
after you stop working.
Do not start sanding without having the sandpaper
fitted.
Do not allow the sandpaper to wear away , it will
damage the sanding pad.The guarantee does not
cover sanding pad wear and tear.
Use coarse grit paper to sand rough surfaces,
medium grit for smooth surfaces and fine grit for
finishing surfaces. If necessary, first make a test run
on scrap material.
Excessive force will reduce the working efficiency
and cause motor overload. Replacing the accessory
regularly will maintain optimum working efficiency.
MAINTENANCE
Remove the plug from the socket before
carrying out any adjustment, servicing or
maintenance.
Your power tool requires no additional lubrication
or maintenance. There are no user serviceable parts
in your power tool. Never use water or chemical
cleaners to clean your power tool. Wipe clean with
a dry cloth. Always store your power tool in a dry
place. Keep the motor ventilation slots clean. Keep
all working controls free of dust. Occasionally you
may see sparks through the ventilation slots.This is
normal and will not damage your power tool.
If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.

ENVIRONMENTAL PROTECTION
This product has been marked with a symbol
relating to removing electric and electronic
waste.This means that this product shall not
be discarded with household waste but that it shall
be returned to a collection system which conforms
to the European Directive 2002/96/CE. It will then
be recycled or dismantled in order to reduce the
impact on the environment. Electric and electronic
equipment can be hazardous for the environment
and for human health since they contain hazardous
substances. For further information visit www.
recyclemore.co.uk
UK PLUG REPLACEMENT
The fuse in the main plug of your power tool should
always be replaced with one of identical rating.
Check the voltage given on your power tool matches
the supply voltage.
The power tool is supplied with a fitted plug,
however if you should need to fit a new plug follows
the instruction below.
IMPORTANT
The wire in the mains lead are coloured in ccordance
with the following code:
Blue ---Neutral
Brown ---Live
The wire that is coloured blue must be connected
to the terminal that is marked with the letter N.The
wire that is coloured brown must be connected to the
terminal that is marked with the letter L.
A 13AMP (BS1363 or BS1363/A) plug must be used
and a 13 AMP fuse must be fitted.
13 AMP
FUSE
BROWN
L (LIVE)
CABLE GRIP
OUTER
SLEEVE
BLUE
N (NEUTRAL)

200W MULTI-CUTTER TTB507HTL
Name / title: Philippe Biannic / Quality Manager
Signature:
Date: 27/02/2 012
2011/65/EU
EN 60745-1:2009+A11:2011
EN 60745-2-4:2009+A11:2011
2012/19/EU Waste Electrical and Electronic Equipment (WEEE)
