Titan Monstervault 4828 Installation instructions

TITAN MonsterVault

Model No: 4828

Installation and Owner’s manual

STEEL SECURITY SAFE

Read this manual carefully and never store it inside the safe!

Steel Security Safe with Digital Lock

TITAN MonsterVault

Model No: 4828

Installation and Owner’s manual

STEEL SECURITY SAFE

Read this manual carefully and never store it inside the safe!

Steel Security Safe with Digital Lock

TITAN MonsterVault

Model No: 4828

Installation and Owner’s manual

STEEL SECURITY SAFE

Read this manual carefully and never store it inside the safe!

Steel Security Safe with Digital Lock

PACKAGE CONTENTS

1– Steel Security Safe

1– Operation Manual

2– Override Access Keys

2– Handles W/Fasteners

Additional items needed:

4– “AA” Batteries

4– Fasteners for floor mounting

Optional vehicle mounting kit available. Contact our

Customer Service for specifications and pricing.

DO NOT RETURN SAFE TO STORE!

If there are any missing parts or you have difficulty

setting up or operating your safe, please contact our

Consumer Assistance Department by telephone:1-

877-276-3802

(USA & Canada)Monday–Friday

8am - 5pm PST

PRODUCT OVERVIEW

A- Safe Entry Knob

B- Override Key Cover

C- Electronic Digital Keypad

D- Safe Cabinet Body

E- Safe Door Assembly

SETUP

STEP 1. OPEN SAFE WITH OVERRIDE KEY

1. Insert override key and turn left to unlock safe.

2. Turn knob to right and open safe door.

3. Override key cover is located in box with key.

STEP 2. INSTALL BATTERIES/HANDLES

1. Remove battery compartment (A) cover on inside door by pressing in and sliding to right.

2. Insert 4 “AA” batteries

3. Replace the battery cover.

4. Do not close door before testing digital lock

5. Install two handles w/screws provided.

STEP 3. TEST DIGITAL LOCK

1. With door open, turnknob left to put locking door bolts (B) in lock position.

2. Remove override key and store in a secure place. NEVER STORE KEYS INSIDE SAFE!

3. Enter the preset pass code: “1”-“5”–“9”-“B”.

4. Turn knob to right within 5 seconds.

5. Lock bolts should recede into the unlocked position.

STEP 4. PROGRAM A NEW PASS CODE

1. With door open, press reset button (C) inside door.

2. Yellow light is on, enter new pass code in 30 seconds.

3. Enter new code (3 to 8 digits) followed by “A” or “B”.

4. Safe will beep and yellow light will turn off.

NOTE: The factory pre-set code will not work after a new pass code is programmed.

OPERATION

TO OPEN THE SAFE

1. To unlock and open safe, enter the pass code followed by “A” or “B”.

2. Turn door entry knob to the right and open door.

TO CLOSE THE SAFE

1. Close the door and hold it in the closed position.

2. Turn door entry knob to left to engage the lock bolts and lock safe.

SECURE LOCKOUT PERIODS

If a wrong code is entered three times in a row, the digital keypad will begin a five-minute secure lockout period. During this secure lockout

period the keypad will become disabled.

Once the lockout period has expired, the safe can be unlocked using the correct pass code.

You may use the override key to open safe, but keypad will complete the full lockout period.

OVERRIDE ACCESS KEY

If the pass code is unavailable or your keypad fails due to dead batteries or other malfunction, you can open the safe using the override access

key (see STEP 1. in the SETUP section).

REPLACING BATTERIES

Note: The pass code will not be erased if the batteries become weak or are removed.

To replace the batteries please follow the instructions in STEP 2. in the SETUP section. If your batteries are completely dead and you cannot

open the safe by using the digital keypad, use the override access key to open safe and access the battery compartment.

NOTE: It is NOT RECOMMENDED to use Non-alkaline or rechargeable batteries.

IF YOU FORGET THE PASS CODE

1. Use the override access key to open safe.

2. With door open, press red reset button (C) inside door.

3. Yellow light is on; enter new pass code in 30 seconds.

4. Enter pass code (3 to 8 digits) followed by “A” or “B”.

5. Safe will beep and yellow light will turn off.

SAFE SERIAL NUMBER

Whenever contacting our Consumer Assistance Department, you will need to provide them with the serial

number of your safe. The serial number tag is located on the lower right corner on the back of the safe.

Serial #

___________________

IMPORTANT: Do Not Remove Tags! This is needed if your safe fails or you lose your keys.

ORDERING NEW KEYS

If a key is lost or you would like additional keys, you must first contact our Consumer Assistance Department to verify ownership.

You will need to provide the following information:

To order keys by telephone, call us toll-free at: 1-877-276-3802

• Safe Serial Number

• Number of keys requested

• Name / Address / Telephone

• E-mail address if available

FLOOR MOUNTING INSTRUCTIONS

Items needed:

4 hex head fasteners and washers appropriate for your floor type.

Drill and drill bit matched to your floor material and fastener size.

Masking/Duct tape to hold templates to floor

Four sheets of paper for use as drilling templates

1 pencil

Socket wrench to tighten fasteners

Instructions: Read through all instructions before you begin

1. Place TITAN MonsterVault on floor in desired location.

2. If MV is located under bed, move bed away to expose entire Vault.

3. Slide one sheet of paper under each corner of vault leaving the edges of paper exposed and tape each sheet securely to the fl oor. Take

care not to change position of vault on floor.

4. Trace corner locations of vault onto templates.

5. Remove drawer. This requires 2 people, one person on the right side and one on the left. Open drawer fully. Locate black plas tic levers

on drawer slides and push left one up and right one down to release drawer. Slide drawer out and off glides.

6. Remove TITAN MonsterVault. Take care not to move templates or holes will not line up properly.

7. ENSURE THAT DRILLING HOLES WILL NOT DAMAGE OR INTERFERE WITH ANYTHING IN FLOOR ie. VENTS, ELECTRICAL,

PLUMBING. Drill mounting holes in floor and prepare holes for fasteners.

8. Place TITAN Monster Vault back on templates and align corner tracings.

9. Install front two fasteners but do not tighten until all four holes have been located and all fas teners are in place. Remove templates and

tighten all fasteners.

10. Replace drawer: This requires 2 people, one on the left side and one on the right side. Carefully align drawer with glides so they slide

back together. Push the drawer until completely closed to reset the glides.

11. Replace bed and secure your valuable in the TITAN MonsterVault.

NOTE: Bolting/unbolting of the unit is at the consumer’s expense and discretion. Hilltop Workshop LLC is not responsible for any associated costs

or damage.

If you have any questions about mounting the safe, please check with your local home center/hardware retailer or independent contractor.

LIMITED CONSUMER WARRANTY

We warrant that for a period of seven (7) years from the date of purchase, this product will be free from structural or mechanical defects resulting

from materials or workmanship. It’s at our sole option and as the purchaser’s sole remedy under this warranty, will repair or replace this product

or any component of the product found to be defective during the warranty period. Replacement or repair will be made with a new or

remanufactured product or component. If the product is no longer available, replacement may be made with a similar product of equal or greater

value. THIS IS YOUR EXCLUSIVE WARRANTY.

This warranty is only valid for the original retail purchaser from the date of initial retail purchase and is not transferabl e. You must keep the original

sales receipt. Proof of purchase is required to obtain warranty service. This warranty does not cover commercial use.

The dealers, service centers, or retail stores selling this product do not have the right to alter, modify or in any way change t he terms and

conditions of this warranty.

This warranty does not apply to the finish on the product. This warranty does not cover normal wear and tear of parts or damage resulting from

any of the following: negligent use or misuse of the product, use contrary to the operating instructions, disassembly, repair or alteration by anyone

other than us. or an authorized service center, improper installation, exposure to extremes of heat or humidity, or exceeding 100 lb. drawer load

capacity. Further, the warranty does not cover Acts of God, such as fire, flood, hurricanes and tornadoes.

We shall not be liable for any incidental or consequential damages caused by the breach of any express or implied warranty or otherwise re lating

to the sale of this product. We are also not responsible for: costs associated with removing or installing the product; damage or loss of the

contents of the product; nor for the unauthorized removal of the contents; or damages incurred during shipment.

THE ABOVE WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING ANY WARRANTIES OF

MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, WE DISCLAIMS ANY AND ALL OTHER COVENANTS AND

WARRANTIES.

Except to the extent prohibited by applicable law, any implied warranty of merchantability or fitness for a particular purpos e is limited in duration to

the duration of the above warranty period. Some states, provinces or jurisdictions do not allow the exclusion or limitation of incidental or

consequential damages or limitations on how long an implied warranty lasts, so the above limitations or exclusion may not app ly to you. This

warranty gives you specific legal rights, and you may also have other rights that vary from state to state, or province to pr ovince, or jurisdiction to

jurisdiction.
