Titon CME2.1 Q Plus TP312CH User manual

ventilation systems
Extract Ventilation Unit
Product Manual
EN
CME2.1 Q Plus
Extract Ventilation Unit with Humidity Sensor
and auralite/controller connection
TP312CH
TP313CH

2
Warnings, Safety information and
Guidance
Important Information
Important: read these instructions fully before the
installation of this appliance
1. Installation of the appliance and accessories must be carried
out by a qualied and suitably competent person and be car-
ried out in clean, dry conditions where dust and humidity are
at minimal levels.
2. All wiring must conform to current I.E.E. Wiring Regulations
and all applicable standards and Building Regulations.
3. The appliance must be connected to a local double pole
isolation switch with a contact separation of at least 3mm.
Ideally located adjacent to the unit.
4. The appliance must be earthed.
5. Units are suitable for 230V ~ 50/60Hz single phase with a
fuse rating of 3A.
6. Boost and Communication cable - Unshielded 4 Core 18-
24AWG Stranded, Tinned Copper.
7. Boost and Communication cables should not be placed
within 50mm or on the same metal cable tray as any 230V
lighting or power cables.
8. The unit must be stored in a clean and dry environment.
9. Do not install the appliance in areas where the following may
be present or occur;
• Excessive oil or a grease laden atmosphere,
• Corrosive or ammable gases, liquids or vapours,
• Ambient temperatures above 40°C or below -5°C,
• Humidity levels above 90% or is a wet environment.

3
10. The appliance is not suitable for installation to the exterior of
the dwelling.
11. This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
12. Children should be supervised to ensure that they do not
play with the appliance.
13. Ensure that external grilles are located away from any ue
outlet, in accordance with relevant Building Regulations.
14. The unit must not be connected to a tumble dryer.
15. The unit must not be connected to a cooker hood.
16. Precautions must be taken to avoid the back-ow of gases
into the room from an open ue appliance.
17. Ensure all ducting is free from debris and blockages before
switching on the unit.

4
Commissioning
TP312CH & TP313CH . . . . . . . . . . . . . . . . . . . . . . . . .22
Control Parameters . . . . . . . . . . . . . . . . . . . . .22
Commissioning. . . . . . . . . . . . . . . . . . . . . . . . .23
Boost Overrun . . . . . . . . . . . . . . . . . . . . . . . . .24
Humidity Sensor . . . . . . . . . . . . . . . . . . . . . . .24
Controller Reset . . . . . . . . . . . . . . . . . . . . . . . .25
Hardware Reset . . . . . . . . . . . . . . . . . . . . . . . .25
Maintenance
Routine maintenance . . . . . . . . . . . . . . . . . . . . . . . .26
Cleaning Exterior . . . . . . . . . . . . . . . . . . . . . . . 26
Cleaning Interior . . . . . . . . . . . . . . . . . . . . . . .26
Access to the Interior for Cleaning . . . . . . . .27
Technical
Product Fiche . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Service Record . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Installed by. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Warnings, Safety information and Guidance
Important Information . . . . . . . . . . . . . . . . . . . . . . . .2
Product Overview
Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Component Identication . . . . . . . . . . . . . . . . . . . . . 7
Packaging Contents. . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Product Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Setback Speed . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Continuous Speed . . . . . . . . . . . . . . . . . . . . . . . 9
Boost Speed with Overrun Timer . . . . . . . . . .10
Boost Overrun Timer . . . . . . . . . . . . . . . . . . . .10
Integrated Humidity Sensor . . . . . . . . . . . . . .10
Remote indicator panel (auralite) or control
connection . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Installation
Fixing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Ducting Connections. . . . . . . . . . . . . . . . . . . . . . . . .14
How to Convert Port Cover . . . . . . . . . . . . . . .16
Wiring Connections Access . . . . . . . . . . . . . . .17
Wiring Diagrams . . . . . . . . . . . . . . . . . . . . . . .18
Wiring Diagrams . . . . . . . . . . . . . . . . . . . . . . .19
Wiring Diagrams . . . . . . . . . . . . . . . . . . . . . . .20
Contents

5

6
Product Overview
Dimensions
This diagram details the overall size of the unit and the additional space required
around the unit to allow for commissioning and future servicing and maintenance.
450
421
355
390
252
550
450
590
Service Void
All dimensions in mm

7
Component Identication
Unit components
Cover
Inlet ring
Scroll
Base
Cover / Scroll / Inlet Ring assembly

8
Packaging Contents
Inspect the unit when taking delivery. Check the unit for damage and that all
accessories have been supplied. The box contains:
CME2.1 Q Plus Unit x 1.
Port covers x 3.
This Product manual x 1.
Screw Pack x 1.
User Guide x 1.
All shortages or damage must be immediately reported to the supplier.
Product Features
Compact low prole unit.
Hidden installation xings.
All duct ports on one level.
Accepts 204mm x 60mm or 110mm x 54mm ducting.
Can be cleaned and serviced without disturbing any ducting.
Straightforward installation.
Versatile volt-free boost and setback switching.
Remote indicator panel or control connection.
The CME2.1 Q Plus is controllable by various volt-free switches and sensors. Mains
switching can be achieved by use of the Titon Boxed Relay 5A TP 505.
The following describes the controls and features of the CME2.1 Q Plus and how
they are controlled. Ensure all controls are adequately labelled, indicating their
function clearly.
GB Patent GB2491516.

9
Model CME2.1 Q Plus
Part Number TP312CH TP313CH
Complete unit l
2nd Fix Cover / Scroll / Inlet Ring assembly l
Setback Speed l
Continuous Speed l
Boost Speed l
Boost Overrun Timer l
Remote indicator panel or control connection (auralite)l
Integrated Humidity Sensor l
Setback Speed
Setback Speed is a reduced ventilation rate. Setback Speed is congured using
a step-less independent fan control potentiometer. The Setback Speed can be
enabled by connection of a volt-free one-way switch, or combined with the Boost
Speed with the 3 position switch TP 508.
Continuous Speed
Continuous Speed is the normal running speed of the unit. Continuous Speed is
congured using a step-less independent fan control potentiometer.

10
Boost Speed with Overrun Timer
Boost Speed is an increased speed providing higher extract air ow. Boost Speed
is congured using a step-less independent fan control potentiometer. The Boost
Speed can be triggered by any device which provides a volt-free one-way switch,
such as a PIR, thermostat, humidistat or a standard one-way switch
Boost Overrun Timer
Boost Overrun Timer maintains the Boost Speed for a specic time variable between
0 and 30 minutes. The Boost Overrun Timer time is congured using step-less
independent potentiometer.
Integrated Humidity Sensor
The units are tted with an Integrated Humidity Sensor. This continuously
monitors the relative humidity (RH) of the extracted air. The fan speed increases
proportionally between Continuous Speed & Boost Speed depending on the
measured %RH; see below for details.
The Humidity Sensor’s set point is variable from 55%RH to 85%RH and is congured
using a potentiometer.
RH Set
Point
-10% +10%
Continuous
Speed
Boost
Speed

11
Remote indicator panel (auralite) or control connection
The auralite remote indicator panel can optionally be connected to the unit.
auralite is a low voltage hard wired remote LED ventilation system status indicator,
designed to t a standard UK patress or recessed backbox. The indicator is for use
with specic Titon CME units. The indicator has six LEDs which display
Setback Unit is running at Setback Speed.
Normal Unit is running at Normal Speed.
Boost Unit is running at Boost Speed.
Humidity Control Humidity sensor is controlling unit’s fan speed.
Boost Overrun The Boost Overrun Timer is active.
Fault Unit has a fault - Contact the installer.
Setback, Normal and Boost LEDs will slowly blink o and on when the unit has been
running at Boost Speed for 120 minutes.
Setback Boost
Normal
Humidity
Control
FaultBoost
Overrun
Boost Alert
auralite® Indicator Panel

12
Installation
Fixing
1. The unit must be securely xed to a
smooth at surface, any orientation
is possible.
2. Mark the four xing hole centres
using the Base as a template.
3. Drill holes for xings, use 4mm
Pan Head screws. Always use a
xing type and length suited to
the substrate type. The unit weighs
approximately 5kg.
4. Mount the Base, ensuring it is not
distorted by the xings or mounting
surface.
5. Clip the Motor and Lid assembly to
the Base, ensure that all 6 clips have
engaged.
Tighten screws by hand, DO NOT over
tighten screws or use power tools.
1
2
3
4
5
6
260
260
EXTRACT
PORT
Positions of Clips

13
6. Unscrew the 2 retaining screws that hold on the Cover and remove, retain the
screws.
7. Fit two screws from the Screw Pack
through the preformed holes at the
front of the Inlet Ring to securely x
the Inlet Ring/Scroll assembly to the
Base.
8. Fit one screw from the Screw Pack
through the preformed hole in the
back of the Base. to securely x the
Inlet Ring/Scroll assembly to the
Base.
9. Re-t the Cover using the 2 screws
retained and 1 screw from the
Screw Pack.

14
Ducting Connections
Titon recommend the use of guidance given in the Domestic Ventilation
Compliance Guide 2010 Edition ISBN-978 1 85946 378 9 and
Approved Document Part F 2010 ISBN-978 1 85946 370 3 for all
installations in the United Kingdom.
The above documents can be downloaded free from www.planningportal.gov.uk.
Titon recommend that:
1. 204 x 60mm ducting is used for the
connection of the Extract Port to
Outside.
2. 204 x 60mm or 110 x 54mm ducting
is used for connection to the other
ports.
3. A minimum distance of 200mm
between the CME2.1 Q Plus unit and
any sharp bends in duct work.
4. Ducting should be insulated where
it passes through unheated areas
and voids.
5. Unit should be insulated when
tted in unheated area.
6. Where a duct extends externally above roof level the section above the roof
should be insulated or a condensate trap should be tted just below roof level.
7. Where ducts pass through re barriers, they must be appropriately re stopped
in accordance with the requirements of Part B Building Regulations (England &
Wales).
8. A ducting condensate drain must be tted to vertical Extract Port to Outside
duct work.
9. Condensate drain pipe work must be adequately secured, installed to have
a minimum 5° fall and be insulated if any part of the pipe passes though an
unheated void.
EXTRACT
PORT
Extract Port to Outside

15
10. All insulation to be the equivalent of
at least 25mm of insulating material
with a thermal conductivity
of 0.04 W/(mK).
11. Ducting must be installed in such
a way that resistance to airow is
minimised.
12. Ducting connected to the Extract
Port to Outside must be to the
external air outside the building
envelope.
13. All ducting joints including those to
the CME2.1 Q Plus unit’s Duct Ports
and Convertible Port Covers must
be permanently connected and
sealed.
14. Do not distort ducting, Convertible
Port Cover or Duct Ports.
15. 204 x 60mm ducting ts inside the
units Duct Ports.
16. 110 x 54mm ducting ts inside the
Convertible Port Cover.
17. Unused extract ports must be tted
with non-converted or undamaged
port covers.

16
How to Convert Port Cover
1. To enable tment of 110 x 54mm
ducting, modify the Convertible
Port Cover by tearing out the ‘rip
strip’.
2. When using the convertible port
cover ensure the tear out section is
completely removed.

17
Wiring Connections Access
Access to the connections for mains, boost and other volt-free control functions is
via removal of the Cover and the internal printed circuit board cover. Printed circuit
board cover must be replaced following connection of wiring.
Printed circuit board cover
Cable Access

18
Wiring Diagrams
All Pole
Isolator
3A Fuse
L N
Supply Wiring Diagram 230V~50/60Hz
Volt-free boost switching of
unit’s controller PCB using
single-pole switches TP 502,
TP 503, TP 507
and/or TP500 / TP501
Humidistat.
There maximum of
10 single
pole switches or
humidistats
that can used.
123
TP500/TP501
Boost switching and External Humidistat connection

19
Wiring Diagrams
Volt-free setback switching of the
unit’s controller PCB using single-
pole latching switch and / or volt-free
normally open relay contacts
To avoid the unit being inadvertently
left in Setback Mode, it is recom-
mended that only one latching
switch is tted.
Volt-free setback switch or
normally open relay contacts
Setback Switch connection
Three position Rotary Switch TP 508 switching and connection
SWITCH POSITIONS
1 - Setback Speed
2 - Continuous Speed
3 - Boost Speed
TP 508
Three position
rotary switch
LU1U2U3

20
Wiring Diagrams
0V
+V(5V)
AB
0V
+V(5V)
AB
Connection of auralite
