Titon HRV10.25 Q Plus ECO User manual

ventilation systems
Section HMB
auralite®compatible HRV units
HRV10 Q Plus ECO TP440HMB
HRV10.25 Q Plus ECO TP442HMB
HRV10M Q Plus ECO TP441HMB
HRV10.25M Q Plus ECO TP443HMB
Product Manual
Heat Recovery Ventilation Units
Section B/BC/BE
aurastat®and auramode®compatible HRV units
HRV10 Q Plus ECO TP480B
HRV10.25 Q Plus ECO TP482B
HRV10M Q Plus ECO TP481B
HRV10.25M Q Plus ECO TP483B
Cold Climate HRV units
HRV10 Q Plus ECO TP480BC
HRV10.25 Q Plus ECO TP482BC
HRV10M Q Plus ECO TP481BC
HRV10.25M Q Plus ECO TP483BC
Enthalpy Equipped Cold Climate HRV units
HRV10.25 Q Plus ECO Enthalpy TP482BE
Compatible with HMB units
auralite®TP518
LED Status Indicator
EN
Ventilation
System

Warnings, Safety Information and Guidance
Important Information
Important: read these instructions fully before the installation of this appliance
1. Installation of the appliance and accessories must be carried out by a qualied and suitable
competent person and be carried out in clean, dry conditions where dust and humidity are
at minimal levels.
2. This manual covers the installation of the Heat Recovery Ventilation (HRV) unit
3. All wiring must conform to current I.E.E. Wiring Regulations and all applicable standards
and Building Regulations.
4. Inspect the appliance and electrical supply cord. If the supply cord is damaged, it must be
replaced by the manufacturer, their service agent or similarly qualied persons in order to
avoid a hazard.
5. The unit is supplied with a mains rated 3 core exible cord (PVC sheathed, brown, blue and
green/yellow 0.75mm²).
6. The appliance must be connected to a local double pole isolation switch with a contact
separation of at least 3mm.
7. The appliance must be earthed.
8. HRV10 & 10M Q Plus suitable for 230V ~ 50/60Hz single phase with a fuse rating of 3A.
9. HRV10.25 & 10.25M Q Plus suitable for 230V ~ 50/60Hz single phase
with a fuse rating of 5A.
10. auralite® & aurastat®, control & communication cable access is via the tted cable gland(s)
which are suitable for Ø3- 6mm cable.
11. auralite® & aurastat® control & communication cable - Unshielded 4 Core 18-24AWG Strand-
ed, Tinned Copper.
12. Control & communication cables should not be placed within 50mm or on the same metal
cable tray as any 230V~ lighting or power cables.
13. Ensure all cable glands are fully tightened.
14. The unit must be stored in a clean and dry environment. Do not install the appliance in
areas where the following may be present or occur;
• Excessive oil or a grease laden atmosphere,
• Corrosive or ammable gases, liquids or vapours,
• Ambient temperatures above 40°C or below -5°C,
• Humidity levels above 90% or is a wet environment.
15. The appliance is not suitable for installation to the exterior of the dwelling.
16. This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children should be supervised to ensure that
they do not play with the appliance. Cleaning and user maintenance shall not be made by
children without supervision.
17. Ensure that external grilles are located away from any ue outlet, in accordance with rel-
evant Building Regulations.
18. The unit must not be connected to a tumble dryer or a cooker hood.
19. Precautions must be taken to avoid the back-ow of gases into the room from an open ue
appliance.
20. Ensure all ducting, condensate drain and associated pipe work is free from debris and
blockages before switching on the unit
2

Explanation of symbols on the appliance.
Read instruction Manual.
Risk of Electric Shock.
General hazard safety alert.
Disconnect the mains supply before removing this cover.
Wait until all machine components have completely stopped before touching
them.
Disconnect the mains supply before removing this
cover.
&
Before obtaining access to terminals or removing this
cover, all supply circuits must be disconnected.
Titon Recommend:
1. A short piece of exible ducting, approximately 200mm long is used to connect the unit to the ducting system.
2. Any exible ducting used must be pulled taut.
3. A minimum distance of 200mm between the HRV unit and any sharp bends in duct work.
4. Ducting should be insulated where it passes through unheated areas and voids with the equivalent of at least 25 mm
of a material having a thermal conductivity of ≤0.04 W/(m.K) to reduce the possibility of condensation forming. Where
a duct extends externally above roof level the section above the roof should be insulated or a condensate trap should
be tted just below roof level.
5. Ducts within the building heated envelope between the external terminals and the unit’s From Atmosphere and To
Atmosphere ports should be insulated and wrapped additionally with a vapour barrier outside the insulation.
6. Where ducts pass through re barriers, they must be appropriately re stopped in accordance with the requirements
of Building Regulations.
7. A ducting condensate drain must be tted to vertical To Atmosphere duct work.
8. Ducting must be installed in such a way that resistance to airow is minimised.
9. Ducting connected to the From Atmosphere & To Atmosphere ports, must be to/from the external air outside the
building envelope.
10. Duct joints to the unit’s duct ports must be xed using a method that ensures a long term seal is achieved. If using a
short piece of exible ducting secure using a hose clamp, do not over tighten.
11. A minimum distance of 2m exists between the external supply and exhaust terminals .
+
+
+
3

Contents
When this document
is viewed as a PDF the
headings & sub headings on
this page are hyper links to the content.
Additionally the page numbers in this
document are hyper links back to this
contents page.
Warnings, Safety Information and Guidance
Important Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Explanation of symbols on the appliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Titon Recommend: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Product Information
Packaging Contents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
HRV10 & 10.25 Q Plus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
HRV10M & 10.25M Q Plus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Installation
HRV10, 10M, 10.25 10.25M Q Plus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Condensate Drain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Fitting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Ducting Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Wiring Connections Access. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Section TPxxxHMB Product Overview
Controls & Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Filter Covers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
auralite® . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Auto Setback Speed. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Continuous Speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Boost Speed with Overrun Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
auralite® Boost Alert . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Summer Bypass . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
SUMMERboost® . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Automatic Frost Protection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Integrated Humidity Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Wiring Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
auralite® . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Switching & Controls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Commissioning Units TPxxxHMB
Controls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Control Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Continuous Supply & Extract Speeds: . . . . . . . . . . . . . . . . . . . . . . . . .16
Boost Supply & Extract Speeds: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Boost Overrun. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Humidity Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Controller Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Hardware Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Section TPxxxB/BC/BE Product Overview
Control & Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Enthalpy humidity-recovery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Boost Overrun Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Boost Delay Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Boost Inhibit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Internal Humidity Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Filter Change Alert. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
4 x Fan Speeds. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Summer Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
SUMMERboost® . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Summer By Pass. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Duct Heater Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
2 x Proportional Sensor Inputs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3 x Volt Free Inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
2 x Live Switch Inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Frost Protection Program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Multiple InternalTemperature Sensors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Supply Air Comfort Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Wiring Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Switching & Controls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
External Sensors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Duct Heater . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Ducting Layout. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Sensor Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Commissioning Units TPxxxB/BC/BE
HRV Controller Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Maintenance
Routine Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
HRV10 & 10.25 Q Plus Front Cover Removal. . . . . . . . . . . . . . . . . . . . . . . . . 28
HRV10M &10.25M Q Plus Front Cover Removal . . . . . . . . . . . . . . . . . . . . . . 28
Cleaning Interior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Cleaning Exterior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Filter Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
auralite® Filter Notication Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Service Record . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
4

Product Information
The HRVs are Mechanical Ventilation with Heat Recovery (MVHR) units. They are designed for the energy ecient
ventilation of dwellings. The units are designed for continuous ventilation, exhausting stale moist air from bathrooms,
toilets, kitchen and utility rooms. As the stale air is extracted, the unit’s heat exchanger transfers heat, which would have
been wasted, to the fresh air being supplied to the bedrooms and living rooms.
Packaging Contents
1 x HRV unit.
1 x Mounting Bracket.
1 x Ø40 x 12mm Condensate Drain worm gear hose clamp.
4 x Port Cover 150mm to 125 adapters, supplied packed on Duct Ports.
1 x This Product Manual.
EuP Documentation.
Any shortages or damage must be immediately reported to the supplier.
5

Dimensions
HRV10 & 10.25 Q Plus
HRV10M & 10.25M Q Plus
Service Void
484
920
663 400100
890
790
DO NOT ‘BOX IN’ UNIT
920
DO NOT ‘BOX IN’ UNIT
Service Void
470 800
900
100 400
675
6

Installation
HRV10, 10M, 10.25 10.25M Q Plus
Read and observe the guidance & safety notices listed in Warnings, Safety Information and Guidance .
Do not remove the Port Covers until connecting ducting. Port Covers are tted to prevent debris falling into the unit and
causing blockages and damage:
The Titon HRVQ Plus is designed to be mounted on a wall or similar. The
mounting surface must be suciently strong to support the unit.
Consider the positioning of electrical services and the Condensate Drain
when siting the unit.
Ensure there is sucient access around the HRV Q Plus for future
maintenance.
Do not ‘box-in’the unit making access to the unit dicult for maintenance
and repair.
The Unit MUST be mounted plumb and level front to back and side to side.
1. Mark a horizontal line on the wall using a spirit level. This line will be
approximately 330mm below the location of the top face of the unit when
tted (excluding duct ports).
2. Use the Mounting Brackets as a template to mark the three xing hole
centres.
3. Drill holes for xings, always use a xing suited to the wall type.
4. Fix the Mounting Bracket to the wall ensuring the interlocking side is at
the top, as shown. Mount the unit by locating the two Mounting Brackets
together. Ensure a positive location is made between the
two Mounting Brackets.
5. The Safety Bracket MUST be used. Rotate Safety Bracket into position. Drill
hole for Safety Bracket, always use a xing suited to the wall type.
Packing to be used as required behind the Safety Bracket to ensure unit is
level front to back.
Hook
on to
Wall
Bracket
7

Condensate Drain
The unit’s Condensation Drain Pipe must be tted and connected to the dwelling’s foul water drainage system in
accordance with the relevant building regulations.
The Condensate Drain:
Is attached via the Condensation Drain Socket on the base of the unit.
Must incorporate a suitable trap, which must act as an air lock, ie must be sealed.
Must be adequately secured and be insulated with the equivalent of at least 25mm of insulating material with a
thermal conductivity of 0.04 W/(mK) if any part of the pipe passes though an unheated void.
Should be installed to have a minimum 5° fall from the unit.
Titon recommend the use of a diaphragm type waste valve in place of a conventional‘wet’ trap which could dry out.
Such as, BRE certicate no. 042/97‘Hepworth HepvO® Hygienic self sealing plastic waste valve’recommended as an
alternative to traditional U-Traps.
Fitting
1. HRVxxM - Remove the left hand cover from the base of the unit, retain screws & washers.
2. All units - Fit hose clamp around the Condensate Drain Socket, ensuring it is pushed over the lip and aligned with a
screwdriver access hole to enable tightening of the hose clamp.
3. All units - Insert 22mm O/D PVC pipe into Condensate Drain Socket up to the stop, no more than 50mm of pipe
should be inserted into the Condensate Drain Socket.
4. Hand tighten the hose clip. Do not over tighten.
5. HRVxxM - Replace the cover on the base of the unit, ensure all screws and washers are reused.
8

Ducting Connections
Read and observe the Warnings, Safety Information and Guidance.
The HRV unit has a labels with the icons indicating which port is which.
It is very important that ducting is connected to the correct ports in line with the icons below.
EXTRACT FROM DWELLING - This duct port is connected to the ducting that carries waste air from the‘Wet Rooms’
to the HRV unit.
TO ATMOSPHERE - This duct port is connected to the ducting that carries the waste air to outdoors from the HRV
unit.
SUPPLY TO DWELLING - This duct port is connected to the ducting that carries the fresh warmed air to the
habitable rooms from the HRV unit.
FROM ATMOSPHERE - This duct port is connected to the ducting that carries fresh outdoor air to the HRV unit.
Wiring Connections Access
All wiring must conform to current I.E.E. Wiring Regulations and all applicable national standards and Building
Regulations. Read and observe the Warnings, Safety Information and Guidance.
The electronics compartment is mounted on top of the unit. The compartment has two removable lids, front & rear. The
front lid must always be removed before the rear lid; both lids are xed by four screws. All wiring must be routed into the
electronics compartment via the knock-outs and using cable glands or similar tted to the rear lid.
9

Section TPxxxHMB Product Overview
Controls & Features
The auralite HRV Q Plus units are controllable by various volt free switches and sensors. The following describes the
controls and features of the auralite HRV Q Plus units and how they are controlled. Ensure all controls are adequately
labelled, indicating their function clearly.
Filter Covers
The units are tted with removable lter covers on the front panel.
auralite®
auralite® is available separately as an optional add-on. auralite® is a low voltage hard wired remote LED ventilation system
status indicator, designed to t a standard UK patress or recessed backbox. The indicator has six LEDs which display:-
Normal Solid light - Unit is running at Continuous Speed.
Flashing light - Unit is running at Setback Speed.
Frost Unit is in Automatic Frost Protection mode.
Filter Filters require change.
Boost Solid light - Unit is running at Boost Speed.
Flashing light Boost Alert is active.
Summer Unit is in Summer bypass.
Fault Unit has a fault - Contact the installer.
Auto Setback Speed
Setback Speed is used to reduce ventilation rates. Setback Speed is automatically set at the mid point between minimum
possible Continuous Speed and the selected Continuous Speed. The Setback Speed can be enabled by connection of a
volt free one-way switch, or combined with the Boost Speed with the 3 position
switch TP 508.
Continuous Speed
Continuous Speed is the normal continuous extract and supply air ow running speed of the units.
Boost Speed with Overrun Timer
Boost Speed increases the extract and supply air ow. Boost Speed is congured with Step-less independent fan controls
and includes an Overrun Timer variable between 0 and 60 minutes. The Boost Speed can be triggered by any device which
provides a volt free one-way switch, such as a PIR, thermostat, humidistat or a standard one-way switch. If the unit is left
Boost (latching switch) for longer than 2 hours the Overrun Timer is disabled meaning the HRV will return to Continuous
Speed as soon as the switch holding the unit in Boost is released.
Ventilation
System
auralite® Indicator Panel
10

auralite® Boost Alert
Boost Alert is a timer designed to prevent the HRV being inadvertently left in Boost for long periods of time. Once the HRV
is placed in Boost the timer is started and after 2 hours Boost Alert will be activated. This is indicated by the Boost LED on
the auralite® Indicator Panel ashing. Once Boost Alert has been activated the Overrun Timer is disabled meaning the HRV
will return to Continuous Speed as soon as the switch holding the unit in Boost is released.
Summer Bypass
Summer Bypass is designed to operate during hot periods where fresh air can be vented straight into the property without
being preheated by the extracted stale air. Summer Bypass operation is automatically controlled. The Summer Bypass
mechanism diverts the stale air being extracted from the dwelling around the heat cell so that its heat energy is not
transferred to the fresh air being supplied to the property.
SUMMERboost®
An optional SUMMERboost® facility is available that allows both the supply
and extract fans to run at full speed whenever the Summer Bypass is activated.
By default SUMMERboost® is disabled by a Link Wire, see Wiring Diagrams.
Removal of the link wire will enable SUMMERboost®.
When SUMMERboost® is trigged by Summer Bypass the increased fan speed can be prevented either Manually or
Automatically.
Manual - This is by means of a volt-free switch wired directly into the controller PCB.
Automatic - This is by means of a dedicated wall mounted room thermostat. SUMMERboost® will only operate when the
temperature has exceeded the thermostat setting. Should the room temperature fall below the thermostat setting, then
SUMMERboost® will not operate.
Automatic Frost Protection
During very cold weather, Automatic Frost Protection will detect temperatures that could form ice inside the unit. It will
reduce the supply ventilation rate to prevent ice build up within the heat cell. Automatic Frost Protection reduces the ow
rate of cold air, thus allowing the warmer stale air to raise the temperature within the heat cell to such a level that prevents
the formation of ice. As internal temperatures rise Automatic Frost Protection will increase the supply ventilation ow rate
back to the commissioned settings.
Integrated Humidity Sensor
Units are tted with an Integrated Humidity Sensor. This continuously monitors the relative humidity (RH) of the extracted
air and triggers Boost Speed when the relative humidity rises over the set threshold. The Humidity Sensor’s trigger point is
variable from 55%RH to 85%RH and is congured using step-less independent potentiometer.
11

12

TPxxxHMB Units ONLY
Wiring Diagrams
Supply
auralite®
0V
12V
A
B
0V
12V
A
B
auralite® connection at Indicator ref EE180
auralite® connection at Unit ref EE180
0V
12V
A
B
0V
12V
A
B
Double Pole Isolator Fuse
L
N
L
N
Mains cable must be separate
from the communication cables.
See Important Information.
230V~
Supply wiring diagram 230V~ ref EE141
13

TPxxxHMB Units ONLY
Switching & Controls
Volt-free boost switching of MVHR
controller PCB using single-pole
switches TP 502, TP 503, TP 507
and / or TP500 / TP501 humidistat.
There is maximum of 10 single
pole switches or humidistats
that can used. TP500/TP501
Humidistat
12 3
Boost switching and Humidistat connection ref EE173
Setback Mode switching and connection ref EE177
Volt-free setback switching of MVHR
controller PCB using single-pole
latching switch and / or volt-free
normally open relay contacts.
To avoid the unit being inadvertently
left in Setback Mode, it is recom-
mended that only one latching switch
is tted.
Volt-free setback switch or
normally open relay contacts
SUMMERboost® switch connection ref EE178
Volt-free control of SUMMERboost®
using one way latching switch.
Volt-free control of SUMMERboost®
using room thermostat.
TP 522
Latching SUMMERboost® switch
TP509
Room Thermostat
Y1
L
Y2
14

TPxxxHMB Units ONLY
Three Position Rotary Switch TP 508 switching and connection ref EE175
SWITCH POSITIONS
1 - Setback Speed
2 - Continuous Speed
3 - Boost Speed
L U1 U2 U3
TP 508
Three position rotary switch
SUMMERboost® thermostat connection ref EE178
Volt-free control of SUMMERboost®
using one way latching switch.
Volt-free control of SUMMERboost®
using room thermostat.
TP 522
Latching SUMMERboost® switch
TP509
Room Thermostat
Y1
L
Y2
SUMMERboost® Link Wire
SUMMERboost® Link Wire must be
removed to enable SUMMERboost®.
SUMMERboost® Link Wire
15

Commissioning Units TPxxxHMB
Controls
The fan speeds of the Titon HRV Q Plus will require adjustment to ensure the ow rates achieved provide adequate
ventilation. The Titon HRV Q Plus has 2 standard fan speed settings Continuous Speed and Boost Speed.
The Continuous Speed and Boost Speed are programmed by placing the controller into Program Mode via the Program/
Run Switch and changing the position of rotary potentiometers.
When applying power for the rst time, the unit can take up to four minutes to start operating.
Prior to the rst commission set Continuous Speed potentiometers to minimum and Boost Speed potentiometers to
maximum or reset the controller.
Control Parameters
The Boost Speed cannot be set lower than the Continuous Speed.
The Continuous Speed cannot be set higher than the Boost Speed.
All switching inputs are disabled when the Program/Run Switch is in Continuous or Boost positions.
Speed control potentiometers are disabled when the Program/Run switch is in centre Run position.
For the commissioning settings to be stored the unit needs to be powered up.
Continuous Supply & Extract Speeds:
1. Move Program/Run Switch to Continuous position.
2. Rotate supply fan Continuous Speed adjustment potentiometer to achieve required supply continuous air ow.
3. Rotate extract fan Continuous Speed adjustment potentiometer to achieve required extract continuous air ow.
4. Return Program/Run Switch to centre position to exit commissioning.
Boost Supply & Extract Speeds:
1. Move Program/ Run Switch to Boost position.
2. Rotate supply fan Boost Speed adjustment potentiometer to achieve
required supply boost air ow.
3. Rotate extract fan Boost Speed adjustment potentiometer to achieve
required extract boost air ow.
4. Return Program/Run Switch to centre position to exit commissioning.
Humidity
Timer
Program
Switch
Potentiometers
Extract Supply
Run
Continuous
Boost
Boost Overrun Timer
Humidity Sensor
Extract
Supply
Control Identication
Humidity
Timer
Program
Switch
Potentiometers
Extract Supply
Run
Continuous
Boost
Boost Overrun Timer
Humidity Sensor
Extract
Supply
Boost
Overrun
Timer
Program
Switch
Run
Continuous
Boost
Boost Overrun Timer
Extract
Supply
Potentiometers
ExtractSupply
BP 40262/099
BoostCont
1
2
3
45
6
7
8
060
30
DO 4937 iss 01
Commissioning Pot positions
16

Boost Overrun
Boost Overrun Timer is variable between 0 and 60 minutes. Rotate
potentiometer to change overrun time. This can be done at any time.
Humidity Sensor
The Humidity Sensor’s trigger point is variable from 55%RH to 85%RH. Rotate
potentiometer to change trigger point. Humidity Sensor adjustment can be
done at any time without the need to move the Program / Run Header Link.
Controller Reset
Following a controller reset the ventilation system will need to be
fully commissioned.
The procedure to reset the Titon HRV Q Plus controller is a simple three step operation. The unit will need to be powered
up during the reset procedure.
1. Rotate the Supply and Extract Continuous Speed potentiometers fully anti-clockwise.
2. Rotate Supply and Extract Boost Speed potentiometers fully clockwise move the Run/Program Switch from the Run
position to the Continuous position, from the Continuous position to the Boost position and back to the Run position.
To ensure that the reset switch movements are registered by the controller wait two seconds between each switch
movement. Controller reset is now complete.
Hardware Reset
Certain conditions (repeated supply interruptions etc.) can activate the automatic
motor protection mode. Whereby the fan motors are prevented from operating. This requires a hardware reset to return
the unit to normal operating mode, to achieve this power to the unit should be switched o for 5 minutes, restoring the
power after this time will reset the hardware of both the motor and PCB. Commissioning settings are not aected during a
hardware reset.
Boost
Overrun
Timer
Program
Switch
Run
Continuous
Boost
Boost Overrun Timer
Extract
Supply
Potentiometers
ExtractSupply
BP 40262/099
BoostCont
1
2
3
45
6
7
8
060
30
DO 4937 iss 01
Continuous Speed
Boost Speed
Humidity Sensor
Boost Overrun Timer
Program / Run
Header Link
Setback Speed
1
2
3
45
6
7
8
030
15
55% 85%
70%
17

Section TPxxxB/BC/BE Product Overview
Control & Features
The TPxxx B and BE units are programmable with the aurastat®or auramode®controllers.
Enthalpy humidity-recovery
Units with the E sux use an enthalpy
heat recovery core that recovers some
of the humidity as well as heat.
Boost Overrun Timer
A programmable timer that controls
the time the HRV remains at Boost
Speed after all boost switches have
been released.
Boost Delay Timer
A programmable timer which can be
used to delay the HRV running at Boost
Speed after a boost switch has been
activated.
Boost Inhibit
A programmed time period that
prevents the HRV switching into Boost
Speed or SUMMERboost®.
Internal Humidity Sensor
The HRV has a relative humidity
(RH) sensor. The RH sensor can be
programmed to switch the HRV into
Boost Speed.
Filter Change Alert
The unit can display a lter warning via
a connected controller
4 x Fan Speeds
The units have 4 programmable speed
settings. All speeds allow independent
speed setting of both supply and
extract ventilation rates
Summer Mode
Summer Mode operates by slowing or
stopping the supply fan. This reduces
the supply of From Atmosphere air
to the dwelling. Summer Mode is
triggered automatically or via a Volt
Free input. Summer Mode must not be
enabled or installed in dwellings where
open ue combustion appliances are
used.
SUMMERboost®
SUMMERboost® allows both the supply
and extract fans to run at full speed
whenever the Summer Bypass is
activated. By default SUMMERboost® is
enabled.
Summer By Pass
Summer Bypass is designed to operate
during hot periods where fresh air can
be vented straight into the property
without being preheated by the
extracted stale air. Summer Bypass
operation is automatically controlled.
The Summer Bypass mechanism diverts
the stale air being extracted from the
dwelling around the heat cell so that
its heat energy is not transferred to
the fresh air being supplied to the
dwelling.
Duct Heater Control
To maintain ventilation ow rates
where prolonged periods of very low
temperatures occur, the facility for the
control of an electrically powered Duct
Heater is provided, MAX 1500W. The
Duct Heater is placed in-line between
the outside supply vent and the From
Atmosphere terminal on the HRV. In
these applications, the heater is used
to pre-warm the outside fresh air
supply before it enters the HRV.
2 x Proportional Sensor
Inputs
Enables connection of environmental
sensors to the HRV which can be used
to proportionally control HRV fan
speeds.
3 x Volt Free Inputs
Enables the connection of single pole
momentary switches, latching switches
or normally open relay contacts
to the HRV. These can be used to
switch between fan speeds or control
SUMMERboost® and Summer Mode.
2 x Live Switch Inputs
These inputs are used to switch the
HRV to Boost Speed via a switched live
input.
Frost Protection Program
During very cold weather, the Frost
Protection Program will detect
temperatures that could cause ice to
form inside the unit. It will reduce
or stop the supply ventilation rate,
thus allowing the warmer stale air to
raise the temperature within the unit
cell to such a level that prevents the
formation of ice. As temperatures
rise the Frost Protection Program
will increase the supply ventilation
ow rate back to the commissioned
settings.
Multiple Internal
Temperature Sensors
The unit measures From Atmosphere
and To Atmosphere air temperatures in
real-time. Additionally the temperature
of the heat cell is monitored.
18

TPxxxB/BC/BE Units ONLY
Supply Air Comfort Control
The Cold Climate units TPxxx BC
& BE have additional fan speed
control. If the supply to dwelling air
temperature falls below 10°C the unit
will limit the maximum speed to 45%.
Additionally, if the supply to dwelling
air temperature falls below 6°C the unit
will stop both fans.
Wiring Diagrams
Supply
Supply wiring Ref EE167
230V~
2 Pole
Isolator
Fuse
19

TPxxxB/BC/BE Units ONLY
Switching & Controls
Supply wiring with switch inputs Ref EE166
The Switched Live (LS1, LS2) Boost(s) must be supplied via
the same circuit as used to power the unit.
A 3 (LS1 only) or 4 (LS1 &LS2) pole local isolator must be
installed. The Boxed Relay (Part No. TP505) may be required
to switch from other circuits.
Wet Room Light Switch
Kitchen Light Switch
230V~
4 Pole
Isolator
2 Pole
Isolator
Fuse
20
