TNG L'S User manual

L’S Owner’s Manual
49cc
rev05-02

2
Welcome..!
...to the exciting world of motor scootering. This manual will assist you
in getting your scooter up and operating. After you charge the battery and
put regular gas (90 octane recommended) in the gas tank and two cycle oil in
the separate tank for its storage, you are ready to go!
The automatic CVT transmission eliminates shifting and fancy foot work.
Always remember to pull in the brake lever on the handlebar to be
able to engage the electric starter.
www.tngscooters.com

3
Table of Contents
1. Description 4
2. Scooter Identification 5
3. Control Functions 6
4. Break-In Procedures 11
5. Periodic Maintenance 13
7. Specifications 19
8. Warranty Statement Appendix

4
Description
1. Fuel Tank 7. Front Brake Lever 13. Main Stand 19. Oil Filler Cap
2. Throttle Control 8. Ignition Switch 14. Front Storage 20. Horn, Turn signal,
3. Rear Brake Lever 9. Handle 15. Electric Start Hi / Lo Beam Switch
4. Battery 10. Fuel Tank Cover 16. Storage Hook 21. Side Stand
5. Storage Compartment 11. Seat Lock 17. Speedometer 22. Engine “Kill” Switch
6. Muffler 12. Air Filter 18. Oil Warning Light
22

5
Serial Numbers
Vehicle Number Engine Serial Number

6
Controls
Ignition Switch
Engine “Kill” Switch X
O

7
Dimmer Switch
Dimmer Switch
Turn Signals
Low Beam
High Beam

8
Rear Brake Lever Front Brake Lever
Fuel Tank Cap

9
Steering Lock

10
Kick Start Operation
Electric Start Operation

11
Break-in
Do not ride the scooter at full throttle!
1st 500 Km keep the throttle at less than 1/2
500 Km to 1,000 Km keep the throttle at less than 3/4
0 Km 500 Km
500 Km 1,000 Km

12
Maintenance
(Every 3,000 Km)
Spark Plug Type
BR8HSA
Tool Kit Location

13
Air Filter
1. Foam Filter Cleaner
2. Foam Filter Oil

14
1. Oil Drain Plug
2. Washer
Replace every 4000 Km
(100 ccs)
Transmission Oil
Replacement
Checking Transmission Oil

15
Brake
Adjustment
1. Adjuster
Rear Brake
Front Brake
1. Adjuster

16
Engine Mixing Oil ( 2 cycle oil )
1. Oil Warning Light Use 2-stroke Injector oil
( 1.2 Litres Max)
(Fill slowly to prevent overflow!)

17
Battery
The battery is a “maintenance free” type. It should not require electrolyte replacement. To
maintain a full charge on the battery, it is best to use the kick starter for short trips. Always
charge the battery before storing the scooter for long periods of time. Open the battery plate on
the floor board to expose the battery. If the battery posts appear to be dirty or have a white
powder on them, they will require cleaning. This is done by:
Check to see that the ignition is turned off.
Disconnect the negative wire first, then the positive wire from the battery
and lift the battery out of the battery compartment.
Use a wire brush to clean the battery posts.
Gently wash and dry the battery before replacing it into the scooter.
Reverse the steps above to reinstall the battery into the scooter.

18
Tire Inspection
1. Tread Depth 1. Over Pressure
2. Perfect
3. Under Pressure
Tire Pressures

19
MaximumLoadCapacity 330 lbs.
Engine Type 2-stroke single cylinder
Displacement 49 cc
Bore x Stroke 40x39.6 mm
Compression Ratio 7:1
Lubrication Automatic
Starter Type Kick & Electric
Ignition Type CDI
Spark Plug Type BR8HSA or equivalent
Transmission CVT
Overall Length 1620 mm
Overall Width 625 mm
Overall Height 1010 mm
Wheelbase 1170 mm
Min. Ground Clearance 80mm
Dry Weight 180 lbs.
Fuel Tank Capacity 1.5 Gal
Oil Tank Capacity 1 Liters
Front & Rear Tire 3.50-10
Battery - 12Volt w/charger Located in Seat Compartment
Specifications

Warranty
CMSI, Inc., warrants to the first retail purchaser of all TN’G scooters from anAuthorized CMSI
Dealer and each subsequent owner that the vehicle is free from defects in materials and workman-
ship for the period stated in this warranty section.
To Qualify For This Warranty
• The CMSI vehicles must be purchased from a dealer within the United States, Canada or
Mexico who is authorized by CMSI to sell CMSI products.
• Dealer must be signed up and be familiar with CMSI warranty policy.
Warranty Verification Method
Contact a Authorized TN’G Dealer. For a complete list visit www.tngscooters.com
20
