Toastmaster TB208 Operation manual

Middleby Cooking Systems Group  1400 Toastmaster Drive  Elgin, IL 60120  [phone]  FAX [phone]
P/N 30858
Price $30.00
Rev. C  V1  2/99
OWNER'S OPERATING
& INSTALLATION
MANUAL
TB208/TB240/
TW208/TW240
Eng (UL)
Conveyor Toaster
Models TB208, TB240, TW208, TW240
© 1999 Toastmaster, A Middleby Company
is a registered trademark of Toastmaster, A Middleby Company. All rights reserved.

© 1999 Toastmaster, A Middleby Company
NO QUIBBLE LIMITED WARRANTY
TOASTMASTER, HEREINAFTER REFERRED TO AS THE SELLER, WARRANTS
EQUIPMENT MANUFACTURED BY IT TO BE FREE FROM DEFECTS IN MATERIAL
AND WORKMANSHIP FOR WHICH IT IS RESPONSIBLE. THE SELLERS OBLIGATION
UNDER THIS WARRANTY SHALL BE LIMITED TO REPLACING OR REPAIRING, AT
SELLERS OPTION, WITHOUT CHARGE, ANY PART FOUND TO BE DEFECTIVE AND
ANY LABOR AND MATERIAL EXPENSE INCURRED BY SELLER IN REPLACING OR
REPAIRING SUCH PART. SUCH WARRANTY SHALL BE LIMITED TO THE ORIGINAL
PURCHASER ONLY AND SHALL BE EFFECTIVE FOR A PERIOD OF ONE YEAR
FROM DATE OF ORIGINAL INSTALLATION, OR 18 MONTHS FROM DATE OF
PURCHASE, WHICHEVER IS EARLIER; PROVIDED THAT TERMS OF PAYMENT
HAVE BEEN FULLY MET.
As part of Toastmasters no quibble warranty, all in-warranty Toastmaster products that require service,
are to be serviced on site.
The warranty period for Accu-Miser griddles shall be 24 months from the date of installation or 30 months
from the date of purchase, whichever is earlier.
Normal maintenance functions, including lubrication, cleaning, or customer abuse, are not covered by this
no quibble warranty.
Seller shall be responsible only for repairs or replacements of defective parts performed by Sellers authorized
service personnel. Authorized service agencies are located in principal cities throughout the contiguous
United States, Alaska, and Hawaii. This warranty is valid in the 50 United States and is void elsewhere
unless the product is purchased through Middleby International with warranty included.
The foregoing warranty is exclusive and in lieu of all other warranties, expressed or implied. There
are no implied warranties of merchantability or of fitness for a particular purpose.
The foregoing shall be Sellers sole and exclusive obligation and Buyers sole and exclusive remedy for any
action including breach of contract or negligence. In no event shall Seller be liable for a sum in excess of the
purchase price of the item. Seller shall not be liable for any prospective or lost profits of Buyer.
i
Toastmaster  1400 Toastmaster Drive  Elgin, IL 60120  USA  [phone]  FAX [phone]
Middleby Corp 24-Hour Service Hotline [phone]
www.middleby.com
is a registered trademark of Toastmaster, A Middleby Company. All rights reserved.

WARNING: IN CASE OF FIRE
Disconnect the toaster from its power source IMMEDIATELY. Shutting down the electrical heating
elements allows the unit to cool, making it easier to put out the fire.
WARNING: FOR YOUR SAFETY
DO NOT STORE OR USE GASOLINE
OR OTHER FLAMMABLE VAPORS OR LIQUIDS
IN THE VICINITY OF THIS OR ANY OTHER APPLIANCE
WARNING
IMPROPER INSTALLATION, ADJUSTMENT, ALTERATION, SERVICE OR
MAINTENANCE CAN CAUSE PROPERTY DAMAGE, INJURY OR DEATH. READ
THE INSTALLATION AND OPERATING INSTRUCTIONS THOROUGHLY BEFORE
INSTALLING OR SERVICING THIS EQUIPMENT.
WARNING
DO NOT OPERATE THE CONVEYOR TOASTER:
ON EITHER OF ITS SIDES
ON ITS REAR SURFACE
WITHOUT LEGS
PREMATURE FAILURE OF THE HEATING ELEMENTS WILL OCCUR.
WARNING
DISCONNECT THE TOASTER FROM ITS ELECTRICAL POWER SUPPLY BEFORE
CLEANING OR SERVICING.
CAUTION
Using any parts other than genuine Toastmaster factory parts relieves the
manufacturer of all liability.
IMPORTANT
Contact your authorized service agent to perform maintenance and repairs. A service agency
directory is supplied with your oven.
IMPORTANT
Toastmaster (manufacturer) reserves the right to change specifications and product design
without notice. Such revisions do not entitle the buyer to corresponding changes, improvements,
additions or replacements for previously purchased equipment.
RETAIN THIS MANUAL FOR FUTURE REFERENCE
This manual provides detailed information for the installation and operation of your Conveyor Toaster. It
also contains information to assist the operator in diagnosing problems in the event of a malfunction. This
manual is an important tool for the operator and should be kept readily available.
ii

TABLE OF CONTENTS
SECTION 1
DESCRIPTION ..................................................................................................................................................... 1-1
A. Features .................................................................................................................................................. 1-1
B. Component Location................................................................................................................................ 1-1
C. Component Function ............................................................................................................................... 1-1
D. Toaster Specifications ............................................................................................................................. 1-2
SECTION 2
INSTALLATION ................................................................................................................................................... 2-1
A. Unpacking ............................................................................................................................................... 2-1
B. Assembly ................................................................................................................................................. 2-1
C. Electrical Connection ............................................................................................................................... 2-2
D. Checking the Installation.......................................................................................................................... 2-2
SECTION 3
OPERATION ........................................................................................................................................................ 3-1
A. Location and Function of Controls ........................................................................................................... 3-1
B. Operation Procedure ............................................................................................................................... 3-1
C. Shutdown Procedure ............................................................................................................................... 3-1
D. Clearing Jams ......................................................................................................................................... 3-2
E. Daily Cleaning ......................................................................................................................................... 3-2
SECTION 4
WIRING DIAGRAM .............................................................................................................................................. 4-1
iii

1-1
SECTION 1 - DESCRIPTION
Figure 1-1
Component location
SECTION 1
DESCRIPTION
A. FEATURES
Toastmaster Model TB208, TB240, TW208, and
TW240 Toasters are:
 Conveyor toasters.
 Equipped with an entry rack used to deliver the food
product into the toaster.
 Equipped with an internal slide-out crumb tray
 Equipped with an exit rack and a return crumb tray.
 Equipped with a Standby mode that saves energy
during slow periods and allows a quick return to
normal operation.
B. COMPONENT LOCATION
The major components of the toaster are shown in Figure
1-1 below.
C. COMPONENT FUNCTION (see Figure 1-1)
1. ON/OFF/STANDBY knob - see Section 3, Operation.
2. DARKER/LIGHTER knob - see Section 3, Operation.
3. Entry rack - Loaded with the product to be toasted.
The product then slides onto the conveyor. The entry
rack can be removed for cleaning.
4. Conveyor - Transports the product through the
toaster, and between the top and bottom heating
elements. The conveyor is driven by its own motor.
3. Entry rack
4. Conveyor
5. Heating elements
(inside toaster)
7. Return crumb tray
6. Exit rack
1. ON/OFF/STANDBY knob
2. DARKER/LIGHTER knob
5. Heating elements - Toast the food product. Three
elements are located above the conveyor, while one
is located below it.
6. Exit rack - Receives the toasted product as it leaves
the conveyor, then delivers the product underneath
the front of the toaster. The exit rack can be removed
for cleaning.
7. Return crumb tray - Collects crumbs from the toasted
product. The tray can be removed for cleaning.

1-2
SECTION 1 - DESCRIPTION
D. TOASTER SPECIFICATIONS
Overall Dimensions: TB208 TB240 TW208 TW240
Width 16-1/2 (419mm)
Depth (includes 2-1/4 / 57mm back guard) 25-1/4 (641mm)
Height (includes 4 / 102mm legs) 16-1/4 (413mm)
Toasting Chamber Dimensions:
Width 11-1/2 (292mm)
Length 15 (381mm)
Height of Opening 1-3/4 (44mm) 1-3/4 (44mm) 2-1/2 (64mm) 2-1/2 (64mm)
Toaster Information:
Approximate Net Weight 75 lbs. (34.0kg)
Approximate Shipping Weight 80 lbs. (36.3kg)
Construction Formed and welded sheet steel
Finish Stainless steel
Pre-Heat Time 20 Minutes
Delivery Time for First Bagel/Muffin 1 Minute 40 Seconds
Production Capacity 400 Bagels/Muffins per hour
Electrical Specifications:
Operating Voltage 208V 240V 208V 240V
Frequency 50/60Hz
Phase 1 Ph
kW Rating 2.7kW 2.9kW 2.7kW 2.9kW
Current Draw 13.1A 12.1A 13.1A 12.1A
Plug Type NEMA 6-15P (USA) or NEMA 6-20P (Canada)

2-1
SECTION 2 - INSTALLATION
SECTION 2
INSTALLATION
A. UNPACKING
IMPORTANT
IT IS THE CUSTOMERS RESPONSIBILITY TO
REPORT ANY CONCEALED OR NON-CONCEALED
DAMAGE TO THE FREIGHT COMPANY.
1. Remove the staples from the shipping carton.
2. Lift out the foam packaging and poly bag from around
the toaster.
3. Carefully lift the toaster out of the carton.
4. Remove all loose materials from the carton, including
the information packet.
5. Remove any parts or packaging materials from inside
the toasting chamber.
6. Retain all shipping materials until it is certain that
the toaster has not suffered concealed shipping
damage.
Figure 2-1 - Assembly
Exit rack
secures on hooks
on inside rear wall
of toaster
Legs (4)
thread into holes
in bottom of toaster
Entry rack
drops into holes
on brackets
Slide-out crumb tray
slides into opening
in front of toaster
Return crumb tray
slides underneath
exit rack
B. ASSEMBLY
1. Thread the 4 (102mm) legs into the four holes on
the bottom of the toaster. See Figure 2-1. Then,
place the toaster in the desired location.
2. Install the entry rack, exit rack, return crumb tray,
and slide-out crumb tray as shown in Figure 2-1.

2-2
SECTION 2 - INSTALLATION
C. ELECTRICAL CONNECTION
IMPORTANT
THE ELECTRICAL CONNECTION TO THE TOASTER
REQUIRES A CIRCUIT BREAKER/FUSED
DISCONNECT. ELECTRICAL SPECIFICATIONS ARE
LISTED ON THE SERIAL PLATE (SHOWN IN FIGURE
2-2), AND IN THE TOASTER SPECIFICATIONS TABLE
(PAGE 1-2).
CONSULT ALL APPLICABLE NATIONAL AND LOCAL
CODES FOR FURTHER ELECTRICAL CONNECTION
REQUIREMENTS.
1. Before proceeding with the electrical connections,
check the following:
a. Check that the supply wire size is adequate.
b. Check that the circuit breaker/fused disconnect
is present, and of the correct rating.
c. Check that the appropriate receptacle is available
for the power cord plug.
If necessary, refer to the toasters serial plate (Figure
2-2) and to the Toaster Specifications table (Page 1-
2).
WARNING
ENSURE THAT BOTH THE CIRCUIT
BREAKER/FUSED DISCONNECT AND THE
ON/OFF/STANDBY KNOB ARE IN THE OFF
POSITION BEFORE PROCEEDING.
Figure 2-2 - Serial Plate Location
WARNING
ENSURE THAT ANY PACKING MATERIAL
RESIDUE HAS BEEN REMOVED FROM
INSIDE THE TOASTING CHAMBER.
2. Insert the power cord plug into its receptacle.
D. CHECKING THE INSTALLATION
1. Restore power to the toaster at the circuit breaker/
fused disconnect.
2. Switch the ON/OFF/STANDBY knob to the ON
position.
3. Check that the conveyor is moving forward into the
toaster.
4. Check that all heating elements are heating and
glowing red.
5. Switch the ON/OFF/STANDBY knob to the OFF
position.
6. Visually check that the heating elements are no
longer on, and that the conveyor has stopped moving.

3-1
SECTION 3 - OPERATION
SECTION 3
OPERATION
A. LOCATION AND FUNCTION OF
CONTROLS
This section provides a basic description of the toaster
controls, their location, and the functions they perform.
The operator MUST be familiar with the controls. See
Figure 3-1.
1. ON/OFF/STANDBY Knob
 When set to ON, switches the heating elements
and conveyor on.
 When set to OFF, switches the heating
elements and conveyor off.
 When set to STANDBY, switches the top
heating elements off to conserve energy during
slow periods. The bottom heating element
remains on, allowing quick recovery.
2. DARKER/LIGHTER Knob
Adjusts the speed of the conveyor. This controls
the amount of toasting that the food product receives.
B. OPERATION PROCEDURE
1. Restore electrical power to the toaster at the circuit
breaker/fused disconnect.
2. Switch the ON/OFF/STANDBY knob to the ON
position.
3. Allow the toaster to pre-heat for at least 20 minutes.
4. Adjust the DARKER/LIGHTER knob to the desired
setting to provide correctly toasted food products.
5. Load the entry rack with the product to be toasted.
The food product will slide off the entry rack and onto
the conveyor.
6. During slow periods, switch the ON/OFF/STANDBY
knob to the STANDBY position. The top heating
elements will turn off, saving energy. The bottom
heating element remains on to allow quick recovery.
7. To return the toaster to normal operation from
STANDBY mode, switch the ON/OFF/STANDBY
knob to the ON position. Then, allow the toaster to
pre-heat. The top heating elements should reach
their normal temperature within 5 minutes.
C. SHUTDOWN PROCEDURE
1. Switch the ON/OFF/STANDBY knob to the OFF
position.
2. Disconnect electrical power to the toaster at the
circuit breaker/fused disconnect.
Figure 3-1 - Controls
ON/OFF/STANDBY
knob
DARKER/LIGHTER
knob

3-2
SECTION 3 - OPERATION
D. CLEARING JAMS
WARNING
NEVER INSERT YOUR HANDS INTO THE
TOASTING CHAMBER TO CLEAR A JAM.
SERIOUS INJURY MAY RESULT.
CAUTION
NEVER use a plastic object to clear a jam. If the toaster
is not completely cool, damage to the toaster may result.
CAUTION
When clearing a jam, use care to avoid damaging the
heating elements.
1. Switch the ON/OFF/STANDBY knob to the OFF
position.
2. Disconnect electrical power to the toaster at the
circuit breaker/fused disconnect.
3. Allow the toaster to cool.
4. Carefully clear the jam using a long object as a probe.
This object should preferably be made of wood, which
is less likely to damage the heating elements.
E. DAILY CLEANING
WARNING
WHEN CLEANING THE TOASTER, NEVER
APPLY ENOUGH LIQUID TO STAND IN
PLACE ON THE UNIT. DO NOT SPRAY,
RINSE, OR SUBMERGE THE TOASTER.
EXCESSIVE MOISTURE IN THE UNIT WILL
CAUSE A SEVERE ELECTRICAL HAZARD
AND MAY OTHERWISE DAMAGE THE
TOASTER.
CAUTION
DO NOT clean your toaster using abrasive cleaners or
pads. Both will scratch and dull the finish.
1. With the conveyor running, use a brush to clean any
crumbs off the conveyor into the slide-out crumb tray.
2. Switch the ON/OFF/STANDBY knob to the OFF
position.
3. Disconnect electrical power to the toaster at the
circuit breaker/fused disconnect.
4. Allow the toaster is cool.
WARNING
DO NOT TOUCH HOT SURFACES ON THE
TOASTER, OR REACH INTO THE TOASTING
CHAMBER, UNTIL THE UNIT HAS COOLED
THOROUGHLY.
5. Wipe the exterior of the toaster with a sponge or cloth
soaked in hot or warm detergent water. Wipe with a
clean, damp cloth to remove the excess detergent,
and then wipe again to dry the toaster.
6. Remove both the slide-out crumb tray and the return
crumb tray from the toaster, and empty them. Wash
the crumb trays in warm detergent water, and rinse
them.
CAUTION
Never remove the slide-out crumb tray while the conveyor
is moving.
7. Remove the entry and exit racks from the toaster.
Wash the racks in warm detergent water, and rinse
them.
8. Towel the trays and racks dry. Reassemble all parts
onto the toaster.

4-1
SECTION 4 - WIRING DIAGRAM
SECTION 4
WIRING DIAGRAM

For more information on the complete line
of Toastmaster products, contact your
Food Service Equipment Dealer, or write
to us at the address below.
A Middleby Company
Toastmaster  1400 Toastmaster Drive  Elgin, IL 60120  USA  [phone]  FAX [phone]
Middleby Corp 24-Hour Service Hotline [phone]
www.middleby.com
