Tohnichi CPT-G User manual

STEP.2䙤Turning on Power
STEP.3䙤Setting the counter to "00"
STEP.4䙤Selecting the subject
䯂When "MODE_S"appears,
press MEM key to confirm.
STEP.5䙤Selecting the tightening mode
䯂Use 䦱䦻key to select "PRESET" and press
MEM key to confirm.
CPT-G Quick Start "PRESET MODE"
Put in the batteries and the interchangeable head before turning on the power.
䯂Push Power key and turn on the power.
 
PRESET MODE can register up to 10 kinds of target torque,
working like having 10 different preset type torque wrenches.
STEP.1
䎈
䯂Select the target range by using 䦱䦻key to select the
percentage "0% to +10%" against the target torque
value and press MEM key to confirm.
STEP.6䙤Setting the higher limit value
STEP.7䙤Setting the target torque
䯂Set the target torque of part A through J respectively
in order.
Use 䦱䦻key to set the target torque and press
MEM key to confirm. If you need to fininsh setting in
the middle of the way, Press C key. It returns to
counter "00".
STEP.8䙤Selecting the registered target torque
䯂Use 䦱key to set the counter to "01", and press
MD key. LCD starts to blink.
Use 䦱䦻key to select the part from A - J, and press
MEM key to confirm.
STEP.9䙤Tightening bolts
䯂Now it is ready.
Target torque is indicated by the blue LED. The red LED
starts to move toword right as you tighten. Upon
reaching the target torque, the blue LED starts to blink
and the buzzer goes off to signal tightening completion.
After tightening is complete, press MEM key to save the
measured data.
䎵䎨䎧 䎥䎯䎸䎨
note) Upon reaching 80% of the target torque, the buzzer starts to sound
off-and-on to signal it is coming close to the target torque. When it
reaches out of the target torque range, the red LED turns on and the
buzzer pattern changes to indicate over-torque tightening.
275*
275*
ԙ275*
Ԙ275*
ԙ275*
Ԙ275*
ԙ275*
Ԙ275*
Memo)
Please refer to the instruction manual for details.䙤
Refer P8 for PRESET mode, and P15 for its setting.
Refer P18 for other setting including auto memory, buzzer on/off, etc.
䦱key: Change digit
䦻key: Change number
%QWPVGT
䯂Use 䦱䦻key to set the counter to "00",
and press MD key for more than 2 seconds.
ԙ275*
Ԙ275*
Ԛ275*
ԙ275*
ԛ275*
Ԙ275*
note) If the measured data remains in the memory, you cannot change to
other parts A - J.
Press C key to clear the measured data first, then select part A - J.
(note) If you are changing from "JUDGE"mode, "CLR_OK"(Clear OK?)
appears when you push MEM key.
Push MEM key again to confirm, then it proceed to STEP6.
(The measured data will be deleted as you push MEM key to confirm.
Record the data in advance if necessary.)
䎔䎓䎑䎓䎗䎑䎱䎑䎰
note) Target torque cannot be set when it is out of its capacity range.

STEP.6䙤Setting the lower limit torque value
䯂Use 䦱䦻key to select the tightening direction and press
MEM key to confirm.
Repeat STEP6 - 8 process to set partB-Jinthesame
way. If you need to fininsh setting in the middle of the
way, Press C key. It returns to counter "00".
STEP.2䙤Turning on Power
STEP.3䙤Setting the counter to "00"
STEP.4䙤Selecting the subject
䯂When "MODE_S"appears, press MEM key
to confirm.
STEP.5䙤Selecting the tightening mode
䯂Use 䦱䦻key to select "JUDGE" and press
MEM key to confirm.
CPT-G Quick Start "JUDGEMENT MODE"
Put in the batteries and the interchangeable head before turning on the power.
䯂Push Power key and turn on the power.
 
JUDGEMENT MODE can register up to 10 different torque ranges,
and makes judgement for the measurement.
STEP.1
STEP.7䙤Setting the upper limit torque value
STEP.9䙤Selecting the registed target torque
䯂Use 䦱key to set the counter to "01", and press MD key.
LCD starts to blink.
Use 䦱䦻key to select the part A - J, and press MEM
key to confirm.
STEP.10䙤Tightening bolts 䯂Now it is ready
Target torque range is indicated by the blue LED.
The red LED starts to move toward right as you tighten.
Upon reaching the lower limit torque, the blue LED starts
to blink and the buzzer goes off to indicate it reached the
target range. After completion, press MEM to save the
measured data.
䎵䎨䎧 䎥䎯䎸䎨
275*
275*
Memo)
Please refer to the instruction manual for details.
Refer P10 for judgement tightening operation, P16 for its setting.
Refer P18 for other setting including auto memory, buzzer on/off, etc.
%QWPVGT
䯂Use 䦱䦻key to set the counter to "00",
and press MD key for more than 2 seconds.
ԙ275*
Ԙ275*
Ԛ275*
ԙ275*
ԛ275*
Ԙ275*
ԙ275*
Ԙ275*
ԙ275*
Ԙ275*
䯂Set the lower limit torque value of part A.
Use 䦱䦻key to set the lower limit torque value
and press MEM key to confirm. 䙤
䦱key: Change digit 䦻key: Change number
䯂Set the upper limit torque value of part A.
Use 䦱䦻key to set the upper limit torque value
and press MEM key to confirm.䙤䙤
STEP.8䙤Selecting tightening direction
ԙ275*
Ԙ275*
CW: clockwise CCW: counter clockwise
䦱key: Change digit 䦻key: Change number
(note) If you are changing from "PRESET"mode,
"CLR_OK"(Clear OK?) appears when you push MEM key.
Push MEM key again to confirm, then it proceed to STEP6.
(The measured data will be deleted as you push MEM key to confirm.
Record the data in advance if necessary. )
note) If the measured data remains in the memory, you cannot change to
other parts A - J.
Press C key to clear the measured data first, then select part A - J.
note) Upon reaching 80% of the lower limit torque value, the buzzer starts to sound
off-and-on to signal it is coming close to the lower limit torque value. When it
reaches out of the target torque range, the red LED turns on and the buzzer
pattern changes to indicate over-torque tightening.
䎔䎓䎑䎓䎗䎑䎱䎑䎰
note) Lower limit torque value cannot be set when it is out of its capacity range.
note) Upper limit torque value must be higher than the lower limit torque value
and within its capacity range.
ԙ275*
Ԙ275*
