Tonghui SM6029 User manual

User Manual
Automatic Transformer Tester
SM6029

Scientific
SM6029 Manual 2/220
Copyright © Scientific All rights reserved.
This instru ent contains proprietary infor ation, no part of this anual ay
be photocopied, reproduced or translated without any prior written consent.
Infor ation in this anual supersede all corresponding previous released
aterial.
Scientific continues to i prove products and reserves rights to a end part or
all of the specifications, procedures, equip ent at any ti e without notice.
Ver1.0/0722
Scientific Mes-Technik Pvt. Ltd.,
B-14 Industrial Estate, Pologround,
Indore- 452015 (India)
Tel : [phone]/33
Fax : [phone],561641
Email : [e-mail]
Website: www.scientificindia.com

Scientific
SM6029 Manual 3/220
Contents
Chapter 1 First Ti e Operation ..............................................................10
1.1 To Inspect the package ..........................................................10
1.2 Power connection ..................................................................10
1.3 Fuse ...................................................................................10
1.4 Environ ent ........................................................................11
1.5 Use of Test Fixture ................................................................11
1.6 War -up .............................................................................11
1.7 Other features ......................................................................12
Chapter 2 Introduction .........................................................................13
2.1 Introduction to front panel .....................................................13
2.2 Introduction to rear panel ......................................................15
2.3 Introduction to display zone ...................................................16
2.4 Main enu keys and corresponding displayed pages ..................17
2.4.1 [DISP] ...........................................................................17
2.4.2 [SETUP] .........................................................................17
2.4.3 [SYSTEM] .......................................................................18
2.5 Basic Operation ....................................................................18
2.6 Start the instru ent..............................................................19
Chapter 3 Introduction to [DISP] ...........................................................20
3.1 <MEAS DISPLAY> .................................................................20
3.1.1 Test function ...................................................................21
3.1.2 Test range ......................................................................23
3.1.3 Test frequency ................................................................23
3.1.4 Test level .......................................................................24
3.1.5 DC bias ..........................................................................25
3.1.6 Test speed ......................................................................26
3.1.7 Tools .............................................................................26
3.1.8 Save LCR test result by U disk ...........................................27
3.2 <BIN NO. DISP> ..................................................................28
3.2.1 Co parator function ........................................................29
3.3 <BIN COUNT DISP> ..............................................................29
3.3.1 PARAM ...........................................................................30
3.3.2 NOM. .............................................................................30
3.3.3 BIN ...............................................................................30
3.3.4 HIGH/LOW .....................................................................31
3.3.5 COUNT ..........................................................................31
3.3.6 AUX ..............................................................................31
3.3.7 OUT ..............................................................................31
3.4 <LIST SWEEP DISP> .............................................................31
3.4.1 Sweep ode ...................................................................32
3.4.2 FREQ (Hz) ......................................................................33
3.4.3 Cp[F] D[ ] ......................................................................33

Scientific
SM6029 Manual 4/220
3.4.4 CMP (Co pare)...............................................................33
3.5 <TRACE SWEEP> .................................................................33
3.5.1 FORMAT .........................................................................34
3.5.2 SCALE ...........................................................................34
3.5.3 READ .............................................................................34
3.5.4 TRACE ...........................................................................35
3.5.5 POINTS ..........................................................................35
3.5.6 TRIGGER ........................................................................35
3.5.7 SAVE CSV & SAVE AS .......................................................35
3.6 <MEAS SETUP> ....................................................................36
3.6.1 Trigger ode ..................................................................38
3.6.2 Auto level control function ................................................38
3.6.3 Bias current isolation function ...........................................39
3.6.4 Average .........................................................................40
3.6.5 Level onitor function .....................................................40
3.6.6 Delay ti e .....................................................................41
3.6.7 Output i pedance ...........................................................41
3.6.8 Deviation test function .....................................................41
3.7 <CORRECTION> ...................................................................42
3.7.1 OPEN .............................................................................44
3.7.2 SHORT ...........................................................................45
3.7.3 LOAD .............................................................................47
3.7.4 Load correction test function .............................................48
3.7.5 Cable length selection ......................................................48
3.8 <LIMIT TABLE> ....................................................................49
3.8.1 Swap para eter ..............................................................49
3.8.2 Li it odes of co pare function .......................................50
3.8.3 Set no inal value of tolerance ode ..................................51
3.8.4 Co parator function ON/OFF ............................................51
3.8.5 Auxiliary bin ON/OFF .......................................................52
3.8.6 HIGH/LOW .....................................................................53
3.9 <LIST SWEEP SETUP> ..........................................................54
3.9.1 MODE ............................................................................54
3.9.2 Test para eter ...............................................................54
3.9.3 Sweep para eter setup ...................................................55
3.10 TRACE SWEEP SETUP ............................................................56
3.10.1 Function.........................................................................56
3.10.2 Level .............................................................................56
3.10.3 DC Bias ..........................................................................57
3.10.4 Trace .............................................................................57
3.10.5 Range ............................................................................57
3.10.6 Scale .............................................................................57
3.10.7 Frequency ......................................................................57
3.10.8 Speed ............................................................................57

Scientific
SM6029 Manual 5/220
3.10.9 For at ..........................................................................57
3.10.10 Trigger ...........................................................................57
3.10.11 Mode .............................................................................58
3.10.12 Start delay .....................................................................58
3.10.13 Point .............................................................................58
3.10.14 Step delay ......................................................................58
3.10.15 Maxi u and ini u ...................................................58
3.10.16 START ...........................................................................58
3.10.17 END ..............................................................................58
3.10.18 Coordination range settiing ...............................................59
Chapter 4 [SYSTEM] and <FILE MANAGE> ..............................................60
4.1 <SYSTEM SETUP> ................................................................60
4.1.1 MAIN FUNC ....................................................................60
4.1.2 Key Sound .....................................................................61
4.1.3 PASS BEEP .....................................................................61
4.1.4 FAIL BEEP ......................................................................61
4.1.5 LANGUAGE .....................................................................62
4.1.6 THEME ...........................................................................62
4.1.7 PASS WORD ...................................................................62
4.1.8 BUS MODE (Reserved function) .........................................63
4.1.9 GPIB ADDR (Reserved function) ........................................63
4.1.10 TALK ONLY .....................................................................64
4.1.11 BIAS SRC .......................................................................64
4.1.12 BAUD RATE ....................................................................65
4.1.13 DATA/TIME .....................................................................65
4.2 LCR <FILE MANAGE> ............................................................65
4.2.1 Setup file for single-group co ponent (*.STA) .....................66
4.2.2 U-disk anage perfor ance .............................................67
4.2.3 Operation steps for file anage ent ..................................68
Chapter 5 Execute LCR operation and so e exa ples ..............................70
5.1 Correction operation ..............................................................70
5.1.1 Sweep correction.............................................................70
5.1.2 Point-frequency correction ................................................70
5.2 Correct connection of DUT ......................................................71
5.3 Eli inate the influence of stray i pedance ...............................72
5.4 Operation exa ple for testing inductance with SM6029 ..............73
5.5 Operation exa ple of testing capacitance by ulti-frequency list sweep ...... 75
5.6 Operation exa ple of load correction .......................................78
Chapter 6 Transfor er Single- achine Test ............................................80
6.1 Circuit for transfor er single- achine test ...............................80
6.1.1 So e para eters of transfor er .......................................80
6.1.2 Transfor er single test circuit and TURN test ......................80
6.1.3 Transfor er leakage inductance test ..................................81
6.1.4 Capacitance test between windings of transfor er ...............81

Scientific
SM6029 Manual 6/220
6.2 <Transfor er Measure Setup> ...............................................82
6.2.1 DELAY ...........................................................................83
6.2.2 Bias...............................................................................83
6.2.3 MODE ............................................................................83
6.2.4 Setting TURN test conditions .............................................84
6.2.5 Setting Lx test conditions .................................................84
6.2.6 Setting DCR test conditions ..............................................85
6.2.7 Test frequency, voltage and switch .....................................85
6.3 <TRANS LIMIT SETUP> .........................................................85
6.3.1 LMT MODE .....................................................................86
6.3.2 Para eter colu n ...........................................................86
6.4 <TRANS MEAS DISP> ...........................................................87
6.5 <Transfor er Judge Display> .................................................87
6.5.1 Save transfor er single-group test result by U disk..............88
Chapter 7 Transfor er Auto Scanning Test ..............................................90
7.1 Introduction to scan test function ............................................90
7.2 Install and connect the scanning test syste ............................90
7.3 Upper panel of scanning box ..................................................91
7.4 Lower panel of scanning box ..................................................93
7.5 HANDLER interface ...............................................................93
7.5.1 Ti ing diagra of HANDLER signal ....................................93
7.5.2 Distribution and connection diagra for HANDLER ...............94
7.6 Exa ple of transfor er .........................................................94
7.7 <Transfor er ID> ................................................................95
7.7.1 CLEAR RAM ....................................................................95
7.7.2 TRANSFORMER PIN LABEL ................................................96
7.7.3 AUTOTRIG DELAY ............................................................96
7.7.4 HANDLER MODE ..............................................................97
7.7.5 SAVE LOG MODE .............................................................98
7.7.6 PASS DISP TIME .............................................................99
7.7.7 PASS DISP SIZE ............................................................ 100
7.7.8 COMMAND EXTRIG ........................................................ 100
7.7.9 NO MINUS DEV ............................................................. 100
7.7.10 SCAN DISP FONT .......................................................... 100
7.7.11 EXT RESET FUNC ........................................................... 100
7.7.12 SCAN PAGE FROM and SCAN PAGE NUMS ......................... 101
7.7.13 RESCAN IF FAIL ............................................................ 102
7.7.14 SAVE LOG AS ................................................................ 102
7.7.15 DC BIAS FACTOR ........................................................... 103
7.7.16 HDL VAL ID TIME .......................................................... 103
7.7.17 RELAY ACT TIME ........................................................... 104
7.7.18 Transfor er ID ............................................................. 104
7.7.19 PRIMARY NUMS ............................................................. 105
7.7.20 SECONDARY NUMS ........................................................ 105

Scientific
SM6029 Manual 7/220
7.7.21 RESCAN INTERVAL ........................................................ 105
7.7.22 SCAN DISP MODE.......................................................... 105
7.7.23 FAIL RESCAN ................................................................ 105
7.7.24 DCR MEAS DELAY .......................................................... 105
7.7.25 DCR OVER DELAY .......................................................... 106
7.7.26 IBIAS ON DELAY ........................................................... 106
7.7.27 IGNORE NOM ................................................................ 106
7.7.28 TRIGGER DELAY ............................................................ 107
7.7.29 CYLINDER CTRL ............................................................ 107
7.8 ALLOCATE PIN TO FIXTURE .................................................. 107
7.8.1 PIN TO FIXTURE ............................................................ 107
7.8.2 HFLX ........................................................................... 108
7.9 PIN SETUP ......................................................................... 108
7.10 SERIES PIN SHORT SETUP ................................................... 110
7.11 PARALLEL PIN SHORT SETUP ................................................ 111
7.12 <TRANS TEST CONDITION> ................................................. 111
7.12.1 Frequency, voltage, switch and scanning sequence ............. 112
7.12.2 Setting TURN test conditions ........................................... 112
7.12.3 Setting Lx test conditions ............................................... 115
7.12.4 Setting Lk test conditions ............................................... 120
7.12.5 Setting Cx test conditions ............................................... 121
7.12.6 Setting Zx test conditions ............................................... 122
7.12.7 Setting ACR test conditions ............................................. 124
7.12.8 Setting DCR test conditions ............................................ 125
7.12.9 Setting PS test conditions ............................................... 126
7.12.10 Setting BL test conditions ............................................... 127
7.12.11 Setting LED test conditions ............................................. 128
7.13 <TRANS SCAN TEST> ......................................................... 130
7.13.1 Display zone ................................................................. 130
7.13.2 Function keys ............................................................... 131
7.13.3 PRI page-turning function ............................................... 132
7.13.4 Lk Pin Disp ................................................................... 133
7.13.5 BAL display .................................................................. 133
7.13.6 <FILE MANAGE> ........................................................... 134
7.13.7 Operation steps for file anage ....................................... 134
7.13.8 Stored files of SM6029 ................................................... 137
7.13.9 Transfor er deviation-deduction ..................................... 137
7.13.10 Save scan test results by U disk ...................................... 139
7.14 Statistic page of transfor er scan test ................................... 140
7.14.1 Reset statistic count value .............................................. 140
7.15 FOCUS SCAN...................................................................... 141
7.16 FAQs and answers in transfor er scan test............................. 142
7.16.1 High and low li its ........................................................ 142
7.16.2 Measure ent ite loss .................................................. 142

Scientific
SM6029 Manual 8/220
7.16.3 Measure ent interruption .............................................. 142
7.16.4 Poor DCR accuracy ........................................................ 143
7.16.5 Poor Lk accuracy ........................................................... 143
7.16.6 Inaccurate TURN ........................................................... 143
7.16.7 Unstable TURN .............................................................. 143
7.16.8 Difference between the first and the second Lx .................. 143
7.16.9 Poor stability of Cx and Zx open test data ......................... 144
7.16.10 DCR and PS open cannot reach infinite large ..................... 144
7.17 User- ade test fixture ......................................................... 144
7.18 Self-check function of scanner relay ...................................... 144
7.18.1 Operation steps for scan self-check .................................. 144
7.18.2 Displayed infor ation on screen ...................................... 145
7.18.3 Detection ethod for relay short ..................................... 146
Chapter 8 Perfor ance and Test .......................................................... 147
8.1 Test function ...................................................................... 147
8.1.1 Para eter and sy bol ................................................... 147
8.1.2 Test co bination ........................................................... 147
8.1.3 Mathe atical operation .................................................. 147
8.1.4 Equivalent ode ........................................................... 147
8.1.5 Range .......................................................................... 147
8.1.6 Trigger ......................................................................... 147
8.1.7 Delay ti e ................................................................... 148
8.1.8 Connection odes of test ter inals ................................. 148
8.1.9 Test speed (Frequency>=10kHz) ..................................... 148
8.1.10 Average ....................................................................... 148
8.1.11 Display digit ................................................................. 148
8.2 Test signal ......................................................................... 148
8.2.1 Test signal frequency ..................................................... 148
8.2.2 Signal ode ................................................................. 149
8.2.3 Test signal level ............................................................ 149
8.2.4 Output i pedance ......................................................... 149
8.2.5 Monitor for test signal level ............................................. 149
8.2.6 Maxi u easure ent display range .............................. 149
8.2.7 DC bias voltage source ................................................... 150
8.2.8 Diode test .................................................................... 150
8.3 Measure ent accuracy ........................................................ 150
8.3.1
│ Z │ , │ Y │ , L, C, R, X, G, B accuracies ............................. 150
8.3.2 D accuracy ................................................................... 151
8.3.3 Q accuracy ................................................................... 151
8.3.4 Θ accuracy ................................................................... 151
8.3.5 G accuracy ................................................................... 151
8.3.6 Rp accuracy .................................................................. 152
8.3.7 Rs accuracy .................................................................. 152
8.3.8 Accuracy factor ............................................................. 152

Scientific
SM6029 Manual 9/220
8.3.9 DCR accuracy ............................................................... 156
8.3.10 Lk accuracy .................................................................. 156
8.3.11 Turns to Ratio accuracy .................................................. 156
8.4 Safety require ent ............................................................. 157
8.4.1 Insulation resistance ...................................................... 157
8.4.2 Insulation intensity ........................................................ 157
8.4.3 Leakage current ............................................................ 157
8.6 Perfor ance test ................................................................ 157
8.6.1 Working condition .......................................................... 157
8.6.2 The used instru ents and devices ................................... 157
8.6.3 Function check .............................................................. 158
8.6.4 Test signal level ............................................................ 158
8.6.5 Frequency .................................................................... 158
8.6.6 Measure ent accuracy ................................................... 158
8.6.7 Accuracy of C and D ...................................................... 159
8.6.8 Accuracy of L ................................................................ 159
8.6.9 Accuracy of Z ................................................................ 159
8.6.10 Accuracy of DCR ........................................................... 159
Chapter 9 Co and Reference ........................................................... 161
9.1 Subsyste co ands for SM6029 ........................................ 161
9.1.1 DISPlay subsyste co ands ........................................ 161
9.1.2 FREQuency subsyste co ands ................................... 164
9.1.3 VOLTage subsyste co ands ....................................... 164
9.1.4 CURRent subsyste co ands ....................................... 165
9.1.5 AMPLitude subsyste co ands .................................... 165
9.1.6 Output RESistor subsyste co ands ............................. 165
9.1.7 OUTPut subsyste co ands ........................................ 166
9.1.8 BIAS subsyste co ands ............................................ 167
9.1.9 FUNCtion subsyste co ands ...................................... 168
9.1.10 LIST subsyste co ands ............................................ 172
9.1.11 APERture subsyste co ands ...................................... 176
9.1.12 TRIGger subsyste co ands ....................................... 176
9.1.13 FETCh? subsyste co ands ......................................... 178
9.1.14 CORRection subsyste co ands ................................... 181
9.1.15 COMParator subsyste co ands .................................. 186
9.1.16 Mass MEMory subsyste co ands ................................ 191
9.1.17 TRAN subsyste co ands ........................................... 191
9.2 GPIB Co on Co ands ................................................... 200
Chapter 10 Description for Handler ........................................................ 205
10.1 Technology description ............................................................ 204
10.2 Operation description .............................................................. 204
Chapter 11 Maintenance and Service ..................................................... 219
Chapter 12 Warranty ........................................................................... 220

Scientific
SM6029 Manual 10/220
Chapter 1 First Time Operation
When you receive the instru ent, so e inspections are necessary, and the
condition ust be understood and available before installing the instru ent.
1.1 To Inspect the package
Inspect the shipping container for da age after unpacking it. It is not
reco ended to power on the instru ent in the case of a da aged container.
If the contents in the container do not confor to the packing list, notify us or
your dealer.
1.2 Power connection
1) Power-supplying voltage range: 100~120Vac or 198~242Vac. Being related
with the power setup on the rear panel.
2) Power-supplying frequency range: 47~63Hz.
3) Power-supplying power range: less than 80VA.
4) Power supplying input phase line L, zero line N, ground lead E should be as
sa e as the power plug of the instru ent.
5) After careful design, the instru ent can reduce the clutter ja ing caused
by AC power ter inal input, however, it should be used under the
environ ent with low-noise. Please install power filter if being unavoidable.
———————————————————————————————————————
Warning: In order to prevent ser and instr ment from being h rt by
leakage, it is necessary for ser to g arantee the gro nd line of s pply
power being reliably gro nded.
———————————————————————————————————————
1.3 F se
The instru ent has installed fuse, so operators should use the installed fuse of
our co pany.
———————————————————————————————————————
Warning: Be s re that the location of f se is consistent with
power-s pplying voltage range before charging.
———————————————————————————————————————

Scientific
SM6029 Manual 11/220
1.4 Environment
1) Please do not operate the instru ent in the place that is vibrative, dusty,
under direct sunlight or where there is corrosive air.
2) The nor al working te perature is 0℃ ～ 40℃, relative hu idity ≤75%, so
the instru ent should be used under above condition to guarantee the
accuracy.
3) There is heat abstractor on the rear panel to avoid the inner te perature
rising. In order to keep good airiness, please don’t obstruct the left and right
airiness holes to ake the instru ent aintain the accuracy.
4) Although the instru ent has been specially designed for reducing the noise
caused by ac power, a place with low noise is still reco ended. If this
cannot be arranged, please ake sure to use power filter for the instru ent.
5) Please store the instru ent in the place where te perature is between 5℃
and 40℃, hu idity is less than 85%RH. If the instru ent will not be put in
use for a ti e, please have it properly packed with its original box or a si ilar
box for storing.
6) The instru ent, especially the test cable should be far fro strong
electro- agnetic field, to avoid the ja ing on easure ent.
1.5 Use of Test Fixt re
Please use the accessory test fixture or cable, the test fixt re made by ser or
from other company may ca se the incorrect meas rement res lt. The
test fixture or cable should be kept clean, as well as the pin of DUT, thus to
guarantee the good connection between DUT and fixture.
Connect the fixture or cable to four test ter inals Hcur, Hpot, Lcur, Lpot on the
front panel. As for the DUT with shielding shell, connect shielding layer or ground
“┴”.
Note: When test fixture or cable has not being installed, the instru ent will
display an unstable test result.
1.6 Warm- p
1) To guarantee the accurate easure ent, the war -up ti e is no less than
15 in.
2) Please not turn on or off instru ent frequently, in order to avoid the inner
data fluster.

Scientific
SM6029 Manual 12/220
1.7 Other feat res
1) Power: consu ption power≤80VA.
2) Di ension (W*H*D): 430 *185 *473
3) Weight: About 13kg.

Scientific
SM6029 Manual 13/220
Chapter 2 Introd ction
In this chapter, the basic operation features of SM6029 series are described.
Please read the content carefully before using SM6029 series instru ents, thus
you can learn the operation of SM6029.
2.1 Introd ction to front panel
Figure 2-1 shows the front panel of SM6029.
1) USB HOST interface
Connect U flash disk so as to save or use a specified file.
2) [KEYLOCK]
Press [KEYLOCK], it will be lighted, which eans the function of current panel
is locked. Press it again, it will be off, which eans discharging the lock status.
If the password function is ON, it eans correct password is necessary when
discharging the key-lock, or the key cannot be unlocked.
When the instru ent is controlled by RS232, [KEYLOCK] will be lighted. Press
it again, it will be off, which eans discharging the lock status.
3) [DC BIAS]
[DC BIAS] is used to per it or forbid the output of 0-100 A/10V DC bias
source. Press this key, it will be lighted which eans DC bias output is
per itted. Press this key once ore, it will be off which eans DC bias output
is prohibited. The key is useless in so e pages where the DC BIAS cannot be
added.
4) [DC SOURCE]
This key is only valid in SM6029A/B/C LCR Meter. It is the function of DC
voltage source (-10~+10V).
5) Brand and odel
Brand and odel
6) LCD
800*480 colorful TFT LCD display, showing the easure ent results and

Scientific
SM6029 Manual 14/220
conditions.
7) [COPY]
Copy the currently displayed page to USB e ory.
8) [DISP]
Press this key to enter into the corresponding test display page.
9) [SETUP]
Press this key to enter into the corresponding test setup page.
10) [SYSTEM]
Press this key to enter into the syste setup page.
11) Nu erical keys
These keys are used to input data to the instru ent. The key consists of
nu erical keys [0] to [9], deci al point [.] and [+/-] key.
12) [ESC]
ESCAPE key
13) [←]
BACKSPACE key is used to delete the last nu eric of the input value.
14) [CAL]
Execute the calibration operation. Press this key to execute OPEN/SHORT
calibration.
15) PASS indicator
LED indicator shows the test result has passed.
16) [TRIGGER]
When the trigger ode is set to MAN ode, press this key to trigger the
instru ent.
17) [RESET]
Press this key, when transfor er auto scanning is cancelled, other operation
cannot be executed on other pages.
18) FAIL indicator
LED indicator shows the test result has failed.
19) [ENTER]
This key is used to end the input of data, and confir and save the data
displayed on the inputting line (the botto line on LCD).
20) Test ter inals (UNKNOWN)
4-te inal test pair are used to connect 4-ter inal test fixture or cable to
easure DUT.
The 4 ter inals are respectively as follows: Hcur, Hpot, Lpot and Lcur.
Transformer secondary test terminal (TURNS)
(+): Secondary (+) ter inal
(-): Secondary (-) ter inal
21) CURSOR
This key is used to ove the cursor on the LCD displayed page. When the
cursor oves to a zone, the corresponding zone will be lightened.
22) Knob for enu selection and nu eric input
This knob is used to ove the cursor, select and set para eters.

Scientific
SM6029 Manual 15/220
23) Confir ation key
This key is used to end the data input, confir and save the data input
through knob.
24) Ground ter inal
The ground ter inal is connected with the case of instru ent, which can be
used to protect or shield the ground connection.
25) FILE
This key is used to enter into FILE MANAGE interface (when in LCR funtion, it
is the only way to enter into the FILE MANAGE interface).
26) Soft keys
Six soft keys are used to select para eters. The corresponding function of
each soft key has been displayed on its left (the right part of LCD). The
function definition varies with different pages.
27) POWER
Power switch
2.2 Introd ction to rear panel
Figure 2-2 shows the rear panel of SM6029.
RATING FUSE
110V/60Hz 80VA
220V/50Hz 80VA T2AL 250V
~
~
T4AL 250V
!
TO AVOID ELECTRIC SHOCK,
THE POWER CORD PROTECTIVE GROUNDING CONDUCTOR
MUST BE CONNECTED TO GROUND
DISCONNECT POWER SUPPLY BEFORE REPLACING FUSE
WARNING
RS-232C
LAN DEVICE
SCANNER
HANDLER
DC BIAS INTERFACE
IEEE-488
1 2 3 4 5 6 7 8 9 10 11
Figure 2-2 Rear panel
1) HANDLER interface
Handler interface is used to realize the sorting output of test results.
2) LAN interface
LAN interface is used to realize the control and the co unication of network
syste .
3) Na eplate
Infor ation about production date, instru ent nu ber and anufacturer
etc..
4) USB DEVICE interface
The tester can co unicate with PC through the USB DEVICE interface.
5) SCANNER interface
Control the transfor er scanning box through SCANNER interface.

Scientific
SM6029 Manual 16/220
6) IEEE-488 interface
The tester can co unicate with PC through GPIB interface.
7) RS232 interface
Series co unication interface can realize the co unication with PC.
8) Fan window
Heat eli ination, aintaining the nor al working te perature
9) Power socket
Input AC power.
10) Fuse base
Being used to install power fuse, protect instru ent, and switch 110V/220V
by changing the direction of core.
———————————————————————————————————————
Warning: Be s re that the direction of f se is accordant with
power-s pply voltage range before charging.
———————————————————————————————————————
11) Ground ter inal
The ground ter inal is connected with instru ent casing, being available for
protecting or shielding ground connection.
2.3 Introd ction to display zone
SM6029 has a 65k, 7-inch TFT display. The display screen is divided into the
following zones:
1
4 3 2
Figure 2-3 display zones
1) Display page na e
Indicate the na e of the currently displayed page.

Scientific
SM6029 Manual 17/220
2) Soft keys
The zone is used to display the function definition of soft key. The definition of
soft key can be different as the difference of cursor’s direction in the zone.
3) Test result/ condition display zone
In this zone, test result infor ation and current condition are displayed.
4) Help
In this zone, infor ation about syste and user data input is displayed.
2.4 Main men keys and corresponding displayed
pages
2.4.1 [DISP]
When the LCR function is active, press this key-[DISP] to enter into the LCR
easure ent display page, the following soft keys will be displayed in the soft
key zone.
<MEAS DISPLAY>
<BIN NO.>
<BIN COUNT>
<LIST SWEEP>
<TRACE SWEEP>
When the transfor er easure ent function is active, press this key-[DISP],
the following soft keys will be displayed on the transfor er easure ent display
page.
<TRANS MEASDISP>
<JUDGE DISP>
<FILE MANAGE>
When the transfor er scan function is active, press this key-[DISP], the
following soft keys will be displayed on the transfor er scan display page.
<DEVIATION DEDUCT SETUP>
When in FOCUS SCAN function, no function page will be displayed.
2.4.2 [SETUP]
When the LCR function is active, press this key-[SETUP], the following soft keys
will be displayed in the soft key zone on the LCR easure ent setup page.
<MEAS SETUP>
<CORRECTION>
<LIMIT TABLE>
<LIST SETUP>
<TRACE SETUP>

Scientific
SM6029 Manual 18/220
When the transfor er easure ent function is active, press this key-[SETUP],
the following soft keys will be displayed on the transfor er easure ent setup
page.
<TRANS MEAS>
<LIMIT TABLE>
<CORRECTION>
<FILE MANAGE>
When the transfor er scan function is active, press this key-[SETUP], the
following soft keys will be displayed on the transfor er scan setup page.
<TRANS ID>
<PIN SETUP>
<TEST CONDITION>
<STATISTICS>
<FILE MANAGE>
<TOOLS>
When in FOCUS SCAN function, the setup pages are the sa e as the transfor er
scan setup pages.
2.4.3 [SYSTEM]
This key-[SYSTEM] is used to enter into the syste setup page. The following
soft keys will be available:
<SYSTEM SETUP>
<LAN SETUP>
2.5 Basic Operation
Basic operation of SM6029 is as follows:
Use enu keys ([DISP], SETUP], [SYSTEM]) and soft keys to select the
desired page.
Use cursor keys ([←][→]) and the slide switch to ove the cursor to the
desired zone. When the cursor oves to a specified zone, the zone will
beco e reverse expression.
The soft key functions corresponding to the current zone of the cursor will be
displayed in the soft key zone. Users can select and use the desired key.
Nu eric keys, [BACKSPACE] and [ENTER] are used to input data.
When a nu eric key is pressed down, the usable unit soft key will be
displayed in the soft key zone. You can choose a unit soft key or press [ENTER]
to end data inputting. When [ENTER] is used to ter inate data inputting, the
unit of data will be set to a default unit, such as Hz, V or A. For exa ple, the
default unit for frequency is Hz.

Scientific
SM6029 Manual 19/220
2.6 Start the instr ment
Plug in 3-line power plug.
Caution: Keep the power-supply voltage and frequency confor to above
specifications. Power input phase line L, zero line N, ground line E should be the
sa e as that of the instru ent.
Press the power switch at the left corner on the front panel and then a boot screen
will appear which displays our co pany logo, instru ent odel (SM6029A), and
the version nu ber of the software (Ver1.0.0).
If the password protection function is on, users are required to input the
password and then press [ENTER] to enter into the page of ain enu.
———————————————————————————————————————
Note: The instru ent has a defa lt password-2829. In your practical use, you
can change it and set your own one. Please see <SYSTEM> section for ore
infor ation.

Scientific
SM6029 Manual 20/220
Chapter 3 Introd ction to [DISP]
3.1 <MEAS DISPLAY>
When the LCR function is applied, press [DISP], the <MEAS DISPLAY> page will
be displayed on screen as shown in the following figure.
SM6029-301
On this page, the test result is displayed in upper-case character. The
easure ent control para eters can be set in this page:
Test function (FUNCA)
Test function (FUNCB)
Test frequency (FREQ)
Test level (LEVEL)
Test range (RANGE)
Test speed (SPEED)
DC bias (DC BIAS)
DC voltage source (DC SRC)
There are 8 zones in this page: FUNCA, FUNCB, FREQ, LEVEL, RANG, SPEED, DC
BIAS, DC SRC. The details will be discussed later.
The test result/ condition display zone shows the infor ation about test condition.
These conditions can be set on <Measure> page or <Correction> page.
Signal source voltage/ current onitor (Vm, Im)
Open, short, load correction ON/OFF status (CORR)
