Toro Dingo TX 107-9310 User manual

2004 by The Toro Company
8111 Lyndale Avenue South
Bloomington, MN 55420-1196
Contact us at www.Toro.com
All Rights Reserved
Printed in the USA
Original Instructions (EN)
Reference Guide Kit
DingoTX Compact Utility Loaders
Model No. 107-9310
Form No. 3351-415
Installation Instructions
Safety and Instruction Decals
Safety decals and instructions are easily visible to the operator and are located near any area
of potential danger. Replace any decal that is damaged or lost.
106-5712
Loose Parts
Note: Use the chart below to identify parts for assembly.
Description Qty. Use
Locking loop
Reference guide
Reference guide cover plate
Self tapping screw
1
1
1
1
Installing the reference guide

2
Installing the Reference Guide
Note: Determine the left and right sides of the machine
from the normal operating position.
The Dingo TX Reference Guide contains essential
operation information found in the Operator’s Manual. The
Reference Guide compliments the information from the
Operator’s Manual, but does not replace it.
1. Lower the loader arms, stop the engine, engage the
parking brake, and remove the key.
2. Clean the control panel of dirt and debris.
3. Check the underside of the control panel for existing
mounting holes in your unit in the locations shown in
Figure 1. If the mounting holes already exist, skip to
step 4. If the mounting holes are not present, follow the
procedure below to drill holes:
A. Measure out from the right side of the control panel
and mark a hole, 11/64 inch in diameter, to be
drilled for the self tapping screw as shown in
Figure 1.
B. Measure out from the right side of the control panel
and mark two holes, 9/32 inch in diameter, for the
locking loop posts as shown in Figure 1.
C. Place the center hole of locking loop over the hole
marked for the self tapping screw to verify the hole
marks for the locking loop posts are correct. Adjust
the marks accordingly if necessary.
D. Drill all holes as marked (Fig. 1).
m–7605
(10.8 cm)
(0.8 cm)
(10.2 cm)
1.9 in
(3.4 cm)
32
14.03 in
4.25 in
(4.8 cm)
1.33 in
0.33 in
3
Figure 1
1. Control panel
2. Self tapping screw hole,
11/64 inch diameter
3. Locking loop post hole,
9/32 inch diameter
4. Assembly the reference guide and install it to the
machine as shown in Figure 2.
Note: Be sure to have the metal cover displaying the safety
decal on top of the reference guide pages.
5. Secure the assembly to the control panel using the self
tapping screw and the center, smaller diameter, hole.
m–7606
1
2
3
4
5
Figure 2
1. Screw, self tapping
2. Locking loop
3. Cover plate
4. Reference guide
5. Control panel
Using the Guide
Attempting to the read the Reference Guide while
operating the machine could result in a loss of
control, causing injury to the operator and/or
bystanders.
•Stop the machine and engage the parking brake
before using the guide.
Warning
Do not attempt to read the Reference Guide while
operating the machine.
Stop the machine and engage the parking brake before
accessing the reference guide.
