FormNo.3404-882RevA
WalkSpreaderMountingKit
Workman®GTXSeriesUtilityVehicle
ModelNo.07029
InstallationInstructions
Safety
WARNING
CALIFORNIA
Proposition65Warning
Thisproductcontainsachemicalorchemicals
knowntotheStateofCaliforniatocausecancer,
birthdefects,orreproductiveharm.
SafetyandInstructional
Decals
Safetydecalsandinstructionsareeasily
visibletotheoperatorandarelocatednear
anyareaofpotentialdanger.Replaceany
decalthatisdamagedorlost.
133-4641
1.Warning—noridersontheattachment.
133-7202
1.Attention—readtheOperator’sManual;donotcarrymore
than45kg(100lb).
©2016—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
Registeratwww.Toro.com.OriginalInstructions(EN)
PrintedintheUSA
AllRightsReserved*3404-882*A

Installation
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
DescriptionQty.Use
Nopartsrequired–Preparethemachine.
Spreader-mountframe1
Snappin2
Clipbushing2
Spreader-pivotshaft1
Leftspreaderramp1
Rightspreaderramp1
Flange-headscrew(5/16x1-1/2inches)4
Flangenut(5/16inch)4
Clevispin1
Hairpincotter1
Installthewalk-speadermount(formachineswithaplastic
cargobed).
Nopartsrequired–Installthewalk-speadermount(formachineswithasteel
cargobed).
Nopartsrequired–Installthewalk-speadermount(formachinewithorwithout
theBrushGuardKitinstalled).
Important:Thetotalloadcapacitywhenthiskitisinstalledis45kg(100lb).Wheninstallingthespreader,verify
thattheweightofthespreaderloadedwithseedorfertilizerdoesnotexceed45kg(100lb),ordamagemayoccur.
Important:Afterinstallingthespreadermounttothemachine,thelengthofthefrontorrearofthemachineextends.
Ensurethatthereisalwaysadequateclearancewhenoperatingthemachinewiththespreadermountinstalled.
Ifinstalledonthefrontofthemachine,usecautionwhenapproachinghills,astheextensionofthefrontofthe
machinemakesitmorelikelytodamageturf.
PreparingtheMachine
1.Movethemachinetoalevelsurface(boxAofFigure1).
2.Engagetheparkingbrake(boxBofFigure1).
3.Shutofftheengine(boxCofFigure1).
4.Removethekeyfromtheignition(boxDofFigure1).
Figure1
2

InstallingtheWalk-Spreader
MounttotheRearofthe
Machine
ForMachineswithaPlasticCargoBed
1.Installthe2clipbushingstothespreader-mountframe
(Figure2).
Figure2
1.Spreader-mountframe2.Clipbushing
2.Slidethespreader-pivotshaftthroughthe
spreader-mountframeandclipbushings(Figure3).
Note:Ensurethattheholesonthespreader-pivot
shaftfaceupward.
Figure3
1.Spreader-pivotshaft
3.Slidetheleftandrightspreaderrampsontothe
spreader-pivotshaft(Figure4).
Figure4
1.Spreader-pivotshaft2.Spreaderramp
4.Aligntheholesonthespreader-pivotshaftwiththe
holesontheleftandrightspreaderramps,andsecure
themusingthe4ange-headscrews(5/16x1-1/2
inches)and4angenuts(5/16inch)asshownin
Figure5.
Figure5
1.Spreaderramp3.Flange-headscrew(5/16
x1-1/2inches)
2.Spreader-pivotshaft4.Flangenut(5/16inch)
5.Loosenthe“T”handleonthereceivertube(Figure6).
Figure6
1.Receivertube2.“T”handle
3

6.Inserttheassembledspreadermountintothemachine
receivertube(Figure7).
Figure7
1.Receivertube2.Assembledspreader
mount
7.Securetheassembledspreadermounttothereceiver
tubeusingtheclevispinandhairpincotter(Figure8).
Figure8
1.Clevispin2.Hairpincotter
8.Tightenthe“T”handleonthereceivertube(Figure9).
Figure9
1.“T”handle
Important:Ifyouusethespreadermountwhilein
transportmode without the spr eader installed ,secure
thespreader-rampassemblyusingthe2snappinsas
showninFigure10.
Figure10
1.Snappins
4

InstallingtheWalk-SpreaderMounttotheRearoftheMachine
ForMachineswithaSteelCargoBed
Repeatsteps1through8ofInstallingtheWalk-SpreaderMounttotheRearoftheMachine(page3).
Whenyoucompleteinstallationontherearofamachinewithasteelcargobed,theWalkSpreaderMountingKitappearsas
follows:
SteelCargoBedInstallation—Figure11
Figure11
5

InstallingtheWalk-SpreaderMounttotheFrontoftheMachine
ForMachinesWithorWithouttheBrushGuardKitInstalled
Repeatsteps1through8ofInstallingtheWalk-SpreaderMounttotheRearoftheMachine(page3).
WhenyoucompleteinstallationonthefrontofamachinewithorwithouttheBrushGuardKitinstalled,theWalkSpreader
MountingKitappearsasfollows:
WithBrushGuardKitInstallation—Figure12
Figure12
WithoutBrushGuardKitInstallation—Figure13
Figure13
6

Operation
InstallingaSpreaderontothe
Walk-SpreaderMount
1.Walkthespreaderupthespreaderramps.
2.Engagethespreaderaxlesusingtheaxleholders
(Figure14).
Figure14
1.Axleholders
3.Alignthekickstandonthespreaderbetweenthe
kickstand-retentiontabsonthespreader-mountframe
(Figure15).
4.Securethespreadertothespreader-mountframeusing
asnappin(Figure15).
Figure15
1.Kickstand-retentiontabs2.Snappin
