Toro 7211 User manual

Operator’s Manual
English (EN, GB)
Form No. 3328–383 Rev A
Workman)3200 & 4200
Liquid Cooled Gas Utility Vehicle
Model No. 07211—Serial No. 230000001 and Up
Model No. 07211TC—Serial No. 230000001 and Up
Model No. 07212—Serial No. 230000001 and Up
Model No. 07218—Serial No. 230000001 and Up

2
All Rights Reserved
Printed in the USA
W2002 by The Toro Company
8111 Lyndale Avenue South
Bloomington, MN 55420-1196
CALIFORNIA
Proposition 65 Warning
The engine exhaust from this product contains
chemicals known to the State of California to cause
cancer, birth defects, or other reproductive harm.
Warning
Important The engine in this product is not equipped
with a spark arrester muffler. It is a violation of California
Public Resource Code Section 4442 to use or operate this
engine on any forest-covered, brush-covered, or
grass-covered land as defined in CPRC 4126. Other states
or federal areas may have similar laws.
This spark ignition system complies with Canadian
ICES-002.
Ce système d’allumage par étincelle de véhicule est
conforme à la norme NMB-002 du Canada.
Contents
Page
Introduction 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safe Operating Practices 4. . . . . . . . . . . . . . . . . . . .
Supervisor’s Responsibilities 4. . . . . . . . . . . . . . . .
Before Operating 4. . . . . . . . . . . . . . . . . . . . . . . . .
While Operating 5. . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sound Pressure Level 6. . . . . . . . . . . . . . . . . . . . . .
Vibration Level 6. . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety and Instruction Decals 7. . . . . . . . . . . . . . . .
Specifications 15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
General Specifications 15. . . . . . . . . . . . . . . . . . . . .
Dimensions 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setup 17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Install Rear Fenders 18. . . . . . . . . . . . . . . . . . . . . . .
Install Wheels 18. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Install Steering Wheel 18. . . . . . . . . . . . . . . . . . . . .
Install Front Fenders 19. . . . . . . . . . . . . . . . . . . . . . .
Install ROPS 19. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Activate and Charge Battery 19. . . . . . . . . . . . . . . . .
Full Bed Removal 21. . . . . . . . . . . . . . . . . . . . . . . . .
Re–Install Full Bed 21. . . . . . . . . . . . . . . . . . . . . . . .
Before Operating 23. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Check Crankcase Oil 23. . . . . . . . . . . . . . . . . . . . . .
Fill Fuel Tank 24. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Check Cooling System 24. . . . . . . . . . . . . . . . . . . . .
Check Transaxle / Hydraulic Fluid 25. . . . . . . . . . . .
Check Front Differential Oil 25. . . . . . . . . . . . . . . . .
Check Torque Of Wheel Nuts 26. . . . . . . . . . . . . . .
Check Tire Pressure 26. . . . . . . . . . . . . . . . . . . . . . .
Check Brake Fluid 27. . . . . . . . . . . . . . . . . . . . . . . .
Operation 28. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Controls 28. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Pre–starting Checks 31. . . . . . . . . . . . . . . . . . . . . . .
Starting Engine 31. . . . . . . . . . . . . . . . . . . . . . . . . . .
Driving Vehicle 31. . . . . . . . . . . . . . . . . . . . . . . . . . .
Stopping Vehicle 32. . . . . . . . . . . . . . . . . . . . . . . . . .
Stopping Engine 32. . . . . . . . . . . . . . . . . . . . . . . . . .
New Vehicle Break–in 32. . . . . . . . . . . . . . . . . . . . .
Check Interlock System 32. . . . . . . . . . . . . . . . . . . .
Operating Characteristics 32. . . . . . . . . . . . . . . . . . .
Passengers 33. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Speed 33. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Turning 33. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Braking 33. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tipovers 34. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hills 35. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Loading And Dumping 35. . . . . . . . . . . . . . . . . . . . .
Using The Differential Lock 36. . . . . . . . . . . . . . . .
Four Wheel Drive 36. . . . . . . . . . . . . . . . . . . . . . . . .
Transporting Vehicle 37. . . . . . . . . . . . . . . . . . . . . .
Towing Vehicle 37. . . . . . . . . . . . . . . . . . . . . . . . . . .
Trailer Towing 37. . . . . . . . . . . . . . . . . . . . . . . . . . .
Remote Hydraulic Control 38. . . . . . . . . . . . . . . . . .
Maintenance 40. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service Interval Chart 40. . . . . . . . . . . . . . . . . . . . . .
Greasing Bearings And Bushings 40. . . . . . . . . . . . .
Maintenance 42. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Recommended Maintenance Schedule 42. . . . . . . . .
Daily Maintenance Checklist 43. . . . . . . . . . . . . . . .
Heavy Duty Operation 44. . . . . . . . . . . . . . . . . . . . .
Using Bed Safety Support 44. . . . . . . . . . . . . . . . . .
Jacking Vehicle 45. . . . . . . . . . . . . . . . . . . . . . . . . . .
General Air Cleaner Maintenance Practices 45. . . . .
Servicing Air Cleaner 45. . . . . . . . . . . . . . . . . . . . . .
Changing Engine Oil And Filter 46. . . . . . . . . . . . . .
Fuel System 46. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Removing Debris From Engine Cooling System 47.
Changing Engine Coolant 47. . . . . . . . . . . . . . . . . .
Adjusting Belts 48. . . . . . . . . . . . . . . . . . . . . . . . . . .
Adjusting Accelerator Pedal 49. . . . . . . . . . . . . . . . .
Changing Transaxle / Hydraulic Fluid 49. . . . . . . . .
Replacing Hydraulic Filter 50. . . . . . . . . . . . . . . . . .
Change Front Differential Oil 50. . . . . . . . . . . . . . . .
Cleaning Hydraulic Strainer 50. . . . . . . . . . . . . . . . .
Replacing Spark Plugs 51. . . . . . . . . . . . . . . . . . . . .
Adjusting Brake Pedal 51. . . . . . . . . . . . . . . . . . . . .

3
Adjusting Clutch Pedal 52. . . . . . . . . . . . . . . . . . . . .
Adjusting Parking Brake 52. . . . . . . . . . . . . . . . . . .
Adjusting Shift Cables 53. . . . . . . . . . . . . . . . . . . . .
Adjusting High–low Cable 53. . . . . . . . . . . . . . . . . .
Adjusting Differential Lock Cable 53. . . . . . . . . . . .
Inspect Brakes 53. . . . . . . . . . . . . . . . . . . . . . . . . . .
Inspect Tires 53. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front Wheel Toe–in 53. . . . . . . . . . . . . . . . . . . . . . .
Inspect Constant Velocity Boot 54. . . . . . . . . . . . . .
Emergency Box Raising 54. . . . . . . . . . . . . . . . . . . .
Fuses 54. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Jump Starting Procedure 54. . . . . . . . . . . . . . . . . . .
Battery Storage 55. . . . . . . . . . . . . . . . . . . . . . . . . . .
Battery Care 55. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hydraulic Schematic 56. . . . . . . . . . . . . . . . . . . . . .
Hydraulic Schematic 57. . . . . . . . . . . . . . . . . . . . . .
Electrical Schematic 58. . . . . . . . . . . . . . . . . . . . . . .
Electrical Schematic 59. . . . . . . . . . . . . . . . . . . . . . .
The Toro General Commercial Products Warranty 60. .
Introduction
Read this manual carefully to learn how to operate and
maintain your product properly. The information in this
manual can help you and others avoid injury and product
damage. Although Toro designs and produces safe
products, you are responsible for operating the product
properly and safely.
Whenever you need service, genuine Toro parts, or
additional information, contact an Authorized Toro
Distributor or Toro Customer Service and have the model
and serial numbers of your product ready. These numbers
are stamped into a plate located on the right frame member
under dash.
Write the product model and serial numbers in the space
below:
Model No:
Serial No.
This manual identifies potential hazards and has special
safety messages that help you and others avoid personal
injury and even death. Danger, Warning, and Caution are
signal words used to identify the level of hazard. However,
regardless of the hazard, be extremely careful.
Danger signals an extreme hazard that will cause serious
injury or death if you do not follow the recommended
precautions.
Warning signals a hazard that may cause serious injury or
death if you do not follow the recommended precautions.
Caution signals a hazard that may cause minor or moderate
injury if you do not follow the recommended precautions.
This manual uses two other words to highlight information.
Important calls attention to special mechanical
information and Note: emphasizes general information
worthy of special attention.
Safety
The TORO WORKMAN meets the requirements of
ANSI B56.8a–1994.
Supervisors, operators and service persons should be
familiar with the following standards and publications:
(The material may be obtained from the address shown).
•Flammable and Combustible Liquids Code:
ANSI/NFPA 30
•National Fire Protection Association:
ANSI/NFPA #505; Powered Industrial Trucks
ADDRESS:
National Fire Prevention Association
Barrymarch Park
Quincy, Massachusetts 02269 U.S.A
•ANSI/ASME B56.8 Personal Burden Carriers
ADDRESS:
American National Standards Institute, Inc.
1430 Broadway
New York, New York 10018 U.S.A.
•ANSI/UL 558; Internal Combustion Engine Powered
Industrial Trucks
ADDRESS:
American National Standards Institute, Inc.
1430 Broadway
New York, New York 10018 U.S.A.
OR
Underwriters Laboratories
333 Pfingsten Road
Northbrook, Illinois 60062 U.S.A.

4
Safe Operating Practices
The WORKMAN is an off–highway vehicle
only, and is not designed, equipped, or
manufactured for use on public streets, roads
or highways.
Warning
The WORKMAN was designed and tested to offer safe
service when operated and maintained properly.
Although hazard control and accident prevention
partially are dependent upon the design and
configuration of the machine, these factors are also
dependent upon the awareness, concern, and proper
training of the personnel involved in the operation,
maintenance and storage of the machine. Improper use
or maintenance of the machine can result in injury or
death.
This is a specialized utility vehicle designed for off–road
use only. its ride and handling will have a different feel
than what drivers experience with passenger cars or
trucks. So take time to become familiar with your
WORKMAN.
Not all of the attachments that adapt to the
WORKMAN are covered in this manual. See the
specific Operator’s Manual provided with attachment
for additional safety instructions. READ THESE
MANUALS.
TO REDUCE THE POTENTIAL FOR INJURY OR
DEATH, COMPLY WITH THE FOLLOWING
SAFETY INSTRUCTIONS.
Supervisor’s Responsibilities
•Make sure operators are thoroughly trained and familiar
with the Operator’s Manual and all labels on the
vehicle.
•Be sure to establish your own special procedures and
work rules for unusual operating conditions (e.g. slopes
too steep for vehicle operation). Use the 3rd High
Lockout switch if high speed could result in a safety or
vehicle abuse situation.
Before Operating
•Operate the machine only after reading and
understanding the contents of this manual. A
replacement manual is available by sending complete
model and serial number to: The Toro Company, 8111
Lyndale Avenue South, Minneapolis, Minnesota 55420.
•Never allow children to operate the vehicle. Never
allow adults to operate it without proper instructions.
Only trained and authorized persons should operate this
vehicle. Make sure all operators are physically and
mentally capable of operating the vehicle. Anyone who
operates the vehicle should have a motor vehicle
license.
•This vehicle is designed to carry only you, the operator,
and one passenger in the seat provided by the
manufacturer. Never carry any other passengers on the
vehicle.
•Never operate the vehicle when under the influence of
drugs or alcohol.
•Become familiar with the controls and know how to
stop the engine quickly.
•Keep all shields, safety devices and decals in place. If a
shield, safety device or decal is malfunctioning,
illegible, or damaged, repair or replace it before
operating the machine.
•Always wear substantial shoes. Do not operate machine
while wearing sandals, tennis shoes or sneakers. Do not
wear loose fitting clothing or jewelry which could get
caught in moving parts and cause personal injury.
•Wearing safety glasses, safety shoes, long pants and a
helmet is advisable and required by some local safety
and insurance regulations.
•Keep everyone, especially children and pets, away from
the areas of operation.
•Before operating the vehicle, always check all parts of
the vehicle and any attachments. If something is wrong,
stop using vehicle. Make sure problem is corrected
before vehicle or attachment is operated again.
•Since gasoline is highly flammable, handle it carefully.
– Use an approved gasoline container.
– Do not remove cap from fuel tank when engine is
hot or running.
– Do not smoke while handling gasoline.
– Fill fuel tank outdoors and to about one inch below
top of tank (bottom of filler neck). Do not overfill.
– Wipe up any spilled gasoline.
•Use only an approved non–metal, portable fuel
container. Static electric discharge can ignite gasoline
vapors in a ungrounded fuel container. Remove the fuel
container from the bed of the vehicle and place on the
ground away from the vehicle before filling. Keep
nozzle in contact with container while filling. Remove
equipment from vehicle bed before filling
•Check the safety interlock system daily for proper
operation; refer to page 32. If a switch should
malfunction, replace the switch before operating

5
machine. After every two years, replace the interlock
switches in the safety system, whether they are working
properly or not.
While Operating
•Operator and passenger should remain seated whenever
the vehicle is in motion. Operator should keep both
hands on steering wheel, whenever possible and
passenger should use hand holds provided. Keep arms
and legs within the vehicle body at all times. Never
carry passengers in the box or on attachments.
Remember your passenger may not be expecting you to
brake or turn and may not be ready.
•Never overload your vehicle. Name plate (located under
dash on passenger side) shows load limits for vehicle.
Never overfill attachments or exceed the vehicle
maximum GVW.
•When starting the engine:
– Sit on operator’s seat and ensure parking brake is
engaged.
– Disengage PTO (if so equipped) and return hand
throttle lever to OFF position (if so equipped).
– Move shift lever to NEUTRAL and depress clutch
pedal.
– Keep foot off accelerator pedal.
– Turn ignition key to START.
•Using the machine demands attention. Failure to
operate vehicle safely may result in an accident, tip over
of vehicle and serious injury or death. Drive carefully.
To prevent tipping or loss of control:
– Use extreme caution, reduce speed and maintain a
safe distance around sand traps, ditches, creeks,
ramps, any unfamiliar areas or other hazards.
– Watch for holes or other hidden hazards.
– Use caution when operating vehicle on a steep
slope. Normally travel straight up and down slopes.
Reduce speed when making sharp turns or when
turning on hillsides. Avoid turning on hillsides
whenever possible.
– Use extra caution when operating vehicle on wet
surfaces, at higher speeds or with a full load.
Stopping time will increase with a full load. Shift
into a lower gear before starting up or down a hill.
– When loading bed, distribute load evenly. Use extra
caution if the load exceeds the dimensions of the
vehicle/bed. Operate vehicle with extra caution
when handling off–center loads that cannot be
centered. Keep loads balanced and secure to prevent
them from shifting.
– Avoid sudden stops and starts. Do not go from
reverse to forward or forward to reverse without
first coming to a complete stop.
– Do not attempt sharp turns or abrupt maneuvers or
other unsafe driving actions that may cause a loss of
vehicle control.
– Do not pass another vehicle traveling in the same
direction at intersections, blind spots, or at other
dangerous locations.
– When dumping, do not let anyone stand behind
vehicle and do not dump load on any one’s feet.
Release tailgate latches from side of box, not from
behind.
– Keep al bystanders away. Before backing up, look to
the rear and assure no one is behind. Back up
slowly.
– Watch out for traffic when near or crossing roads.
Always yield the right of way to pedestrians and
other vehicles. This vehicle is not designed for use
on streets or highways. Always signal your turns or
stop early enough so other persons know what you
plan to do. Obey all traffic rules and regulations.
– Never operate vehicle in or near an area where there
is dust or fumes in the air which are explosive. The
electrical and exhaust systems of the vehicle can
produce sparks capable of igniting explosive
materials.
– Always watch out for and avoid low over hangs
such as tree limbs, door jambs, over head walkways,
etc. Make sure there is enough room over head to
easily clear the vehicle and your head.
– If ever unsure about safe operation, STOP WORK
and ask your supervisor.
•Do not touch engine, transaxle, radiator, muffler or
muffler manifold while engine is running or soon after
it has stopped because these areas may be hot enough to
cause burns.
•If the machine ever vibrates abnormally, stop
immediately, turn engine off, wait for all motion to stop
and inspect for damage. Repair all damage before
resuming operation.
•Before getting off the seat:
– Stop movement of the machine.
– Lower bed.
– Shut engine off and wait for all movement to stop.
– Set parking brake.
– Remove key from ignition.
– Block wheels if machine is on an incline.

6
Maintenance
•Before servicing or making adjustments to the machine,
stop engine, set parking brake and remove key from
ignition to prevent accidental starting of the engine.
•Never work under a raised bed without placing bed
safety support on fully extended cylinder rod.
•Make sure all hydraulic line connectors are tight, and all
hydraulic hoses and lines are in good condition before
applying pressure to the system.
•Keep body and hands away from pin hole leaks or
nozzles that eject hydraulic fluid under high pressure.
Use paper or cardboard, not hands, to search for leaks.
Hydraulic fluid escaping under pressure can have
sufficient force to penetrate skin and do serious damage.
If fluid is injected into the skin it must be surgically
removed within a few hours by a doctor familiar with
this form of injury or gangrene may result.
•Before disconnecting or performing any work on the
hydraulic system, all pressure in system must be
relieved by stopping engine, cycling dump valve from
raise to lower and/or lowering box and attachments.
Place the remote hydraulics lever in the float position. If
box must be in raised position, secure with safety
support.
•To make sure entire machine is in good condition, keep
all nuts, bolts and screws properly tightened.
•To reduce potential fire hazard, keep the engine area
free of excessive grease, grass, leaves and accumulation
of dirt.
•If the engine must be running to perform a maintenance
adjustment, keep hands, feet, clothing, and any parts of
the body away from the engine and any moving parts.
Keep everyone away.
•Do not overspeed engine by changing governor settings.
Maximum engine speed is 3650 rpm. To assure safety
and accuracy, have an Authorized TORO Distributor
check maximum engine speed with a tachometer.
•If major repairs are ever needed or assistance is
required, contact an Authorized TORO Distributor.
•To be sure of optimum performance and safety, always
purchase genuine TORO replacement parts and
accessories. Replacement parts and accessories made by
other manufacturers could be dangerous. Altering this
vehicle in any manner may affect the vehicle’s
operation, performance, durability or its use may result
in injury or death. Such use could void the product
warranty of The TORO Company.
•This vehicle should not be modified without the TORO
Company’s authorization. Direct any inquiries to The
TORO Company, Commercial Division, Vehicle
Engineering Dept., 300 West 82nd St., Bloomington,
Minnesota 55420–1196. USA
Sound Pressure Level
This unit has an equivalent continuous A-weighted sound
pressure at the operator ear of: 82 dB(A), based on
measurements of identical machines per Directive
98/37/EC and amendments.
Vibration Level
Hand-Arm
This unit does not exceed a vibration level of 2.5 m/sat
the hands based on measurements of identical machines per
ISO 5349 procedures.
Whole Body
This unit does not exceed a vibration level of 0.5 m/sat
the posterior based on measurements of identical machines
per ISO 2631 procedures.

7
Safety and Instruction Decals
Safety decals and instructions are easily visible to the operator and are located near any area
of potential danger. Replace any decal that is damaged or lost.
87-8520
Model 07211 & 07212
87-9880
Model 07218

8
93-9446
Model 07211TC
1. Horn
2. Engine—stop
3. On 4. Engine—start 5. Read the Operator’s Manual.
93-9852
1. Warning—read the
Operator’s Manual.
2. Crushing hazard—install the
cylinder lock.
87-5920

9
87-6000
93-9430
1. Locked
2. Differential lock
3. Unlocked
87-6670
93-9851
1. Headlights 2. Engine—start
87-6020
93-9443
1. Parking brake
87-5910
1. Slow 2. Fast
105-7971
1. Slow
2. Fast
3. Transmission—third high;
no fast speed
4. Head lights

10
87-5960
93-9857
1. Vehicle speed
2. Transmission—high
3. Transmission—low
87-6010
93-9444
1. Unlocked
2. Locked
3. Read the Operator’s
Manual.
4. Lower the cargo bed
5. Raise the cargo bed
87-5930
1. When adding fuel to the tank, leave 1 inch (25 mm) between
the fuel and the top of the tank.
93-9448
1. Warning—when adding fuel to the tank, leave 25 mm between
the fuel and the top of the tank; read the Operator’s Manual.
93-9442
1. Maximum tongue weight
is 90 kg; maximum trailer
weight is 680 kg.
2. For information on
transmission fluid, read
the Operator’s Manual.
93-9447
1. Warning—read the Operator’s Manual; remove the ignition key
before servicing or performing maintenance on the engine air
intake system.

11
93-6687
1. Do not step here.
93-7814
1. Entanglement hazard, belt—stay away from moving parts.
93-6689
1. Warning—do not carry passengers.
93-9850
1. Do not repair or revise—read the Operator’s Manual.
93-9899
1. Crushing hazard—install the cylinder lock.
93-9868
1. Crushing hazard of hand—read the Operator’s Manual.
93-9879
1. Stored energy hazard—read the Operator’s Manual.
93-9449
1. Read the Operator’s
Manual.
2. Grease every 100 hours.
3. Add grease (9 grease
points).
105-4228
4 Wheel Drive

12
105-4219
2 Wheel Drive
93-8071
1. Hot surface/burn hazard—stay a safe distance from the hot
surface.
94-5272
98-9335
1. Cutting/dismemberment hazard, fan—stay away from moving
parts.
105-4215
1. Warning—avoid pinch points.
106-6730

13
105-4214
1. Warning—the machine
can tip.
2. Do not jump from a
tipping machine.
3. Hold tight and brace your
feet.
4. The passenger should
hold the hip restraint and
hand hold.
5. Lean away from the
direction the machine is
tipping.
92-2609
Model 07211TC only
93-6668
Model 07211TC only
1. Battery
2. Read the instructions
before servicing or
performing maintenance.
3. Contains lead; do not
discard.
93-7276
Model 07211TC only
1. Explosion hazard—wear
eye protection.
2. Caustic liquid/chemical
burn hazard—to perform
first aid, flush with water.
3. Fire hazard—no fire, open
flames, or smoking.
4. Poison hazard—keep
children a safe distance
from the battery.
93-9860
1. Warning, tipping hazard—read the Operator’s Manual.
2. Operational hazard—keep bystanders a safe distance from the
machine and do not carry passengers (other than in the
passenger seat).
3. Turn the ignition key to the engine-stop position and remove it
before leaving the machine.

14
93-9084
Model 07211TC only
1. Lift point 2. Tie-down point
93-9089
Model 07211TC only
1. Warning—the hydraulic
oil pressure is 133 bar.
2. Coupler A
3. Coupler B
93-9090
Model 07211TC only
1. Warning—read the Operator’s Manual; turn the key to the
engine-stop position, engage the parking brake, and move the
remote hydraulic control lever to the float position.
93-9525
Model 07211TC only
93-9866
Model 07211TC only
1. Float
2. Read the Operator’s
Manual.
3. On
4. A-coupler, lower the
attachment, or clockwise
flow direction
5. Raise the attachment,
counterclockwise flow
direction, or B-coupler
94-1224
Model 07211TC only
1. The maximum load is 1179 kg, the vehicle weight is 635 kg,
and the maximum gross vehicle weight is 1814 kg.

15
Specifications
Note: Specifications and design subject to change without notice.
General Specifications
Type 4 wheel step through, out front operator style, two person vehicle. Certified to meet
ANSI Specifications B56.8a–1994.
Engine
Daihatsu 31 hp, three cylinder, liquid cooled, counterbalanced, gasoline engine;
regulated to 3650 rpm maximum by a mechanical governor. 58.1 cu. in. (952 cc)
displacement. Forced lubrication by gear pump. 40 amp alternator with I/C
regulator. Spin–on oil filter.
Air Cleaner Heavy duty, 2-stage, remote mounted air cleaner.
Battery 12 volt with 650 cold cranking Amps @ 0 degrees F.
Cooling System
Mid mounted radiator with a removable screen which has a lower clean out access.
Cooling system capacity is approximately 4 qts. of 50/50 mixture of ethylene glycol
anti–freeze.
Fuel System Gasoline tank capacity is 7 gallons. 12 volt, electric fuel pump.
Transmission
Rear transaxle configuration, twin axle drive. 3 speed synchromesh, H–shift pattern
with high–low range providing 6 forward and 2 reverse speeds. Manual engage
differential lock. 4 wheel drive output shaft (4 wd only).
Clutch 6.7” clutch and pressure plate.
Front Differential
(4wd only)
5.0 to 1 ratio
Center Differential
(4wd only)
Bi–directional overrunning clutch
Frame Welded, high strength steel construction.
Front Suspension Independent “A” frame control arm, dual progressive rate coil springs and dual
shock absorbers with anti–sway bar.
Rear Suspension DeDion axle (weight carrying axle is independent of transaxle), leaf spring and dual
shock absorbers.
Steering System Power assist, 3 position tilt steering wheel, 3–3/4 turns lock–to–lock. 17.5 to 1 ratio,
14” diameter steering wheel.
Tires Front tires: 20” x 10”-10, 4-ply rating, rib tread.
Rear tires: 24” x 13”-12, 4-ply rating, turf tread.
Brakes
4 wheel hydraulic, dual safety circuit self adjusting drum: 7” diameter front and 8”
diameter rear (2wd) 8” diameter front and rear (4wd). Hand actuated parking brake
actuates rear brake shoes.
ROPS 2 post roll over protection structure with shoulder restraint.
Hydraulics
4 gpm pressure balanced gear pump provides hydraulic flow for power steering, lift
and optional remote hydraulics. Lift control valve and dual cylinders for lifting dump
box. Transaxle is used for reservoir for hydraulic system. 8 quart total capacity.
Spin–on 25 micron hydraulic oil filter. 100 mesh strainer in transaxle.
Seat Bucket seats with shoulder and hip restraints. Fore and aft adjustment for operator
comfort.
Controls
Foot operated accelerator, clutch and brake pedals. Hand operated shifter,
differential lock, parking brake, high–low range shifter, hydraulic lift and tilt steering
levers. Ignition switch, light switch, horn button and 3rd high lockout switch.
Gauges Hour meter, fuel gauge, coolant temperature gauge. Warning light cluster includes
engine low oil pressure and charge indicator. Tachometer optional.

16
Lights Twin halogen headlights and single taillight. Rear stop light.
Tow Hitch Hitch has hole for ball or pin.
Interlocks Clutch pedal must be depressed to start engine.
Ground Speed
Forward Speeds w/24” Rear Tires
High range: 7.6/11.5/19.8 mph
Low range: 2.9/4.5/7.7 mph
Reverse Speeds w/24” Tires
High range: 7.2 mph
Low range: 2.8 mph
Base Weight
(Dry w/o flatbed)
1400 lbs. (2wd)
1600 lbs. (4wd)
Rated Capacity 2,600 lbs. (includes 200 lb. operator, 200 lb. passenger and loaded attachment).
Maximum. Gross Vehicle
Weight
4,000 lbs. (2wd)
4,200 lbs. (4wd)
Tow Capacity Tongue weight 200 lbs.
Maximum trailer weight 1,500 lbs.
Ground Clearance 7” w/ no load
Wheel Base 70”
Wheel Tread
(center line to center line)
Front 46”
Rear 47.7”
Dimensions
Overall Width 63”
Overall Length 124.5” w/o bed
127” w/full bed
133” w/2/3 bed in rear mounting
location
Height 75” to top of ROPS

17
Setup
Note: Determine the left and right side of the machine from the normal operating position.
Description Qty. Use
Fenders–Rear
Capscrew 5/16–18 x 1” lg.
Flatwasher .344” I.D.
Locknut 5/16–18
Capscrew 1/4–20 x 1” lg.
Flatwasher .281” I.D.
Locknut 1/4–20
Truss head screw
Locknut 3/8–16
2
4
4
4
12
12
12
6
6
Mount rear fenders on Model 07211TC only
Wheel Nut
Wheel–Front
Wheel Nut
Wheel–Rear
10
2
10
2
Mount wheels on Model 07211TC only
Steering wheel
Foam Seal
Washer
Nut
Cap
1
1
1
1
1
Install steering wheel on Model 07211TC only
Fenders–Front
Phillips screw
Washer
Locknut 10–24
2
14
14
14
Install front fenders on Model 07211TC only
ROPS
Capscrew 1/2–13 x 3” lg.
Locknuts 1/2–13
1
4
4
Mount ROPS on Model 07211TC only
Operator’s Manual (vehicle) 2Read before operating the machine.
Parts Catalog 1
Registration Card 1Fill out and return to Toro.

18
Install Rear Fenders
(Model 07211TC only)
1. Loosen the locknuts and capscrews securing tail light
plates to right and left frame brackets (Fig. 1).
2. Pivot tail light plates rearward and tighten capscrews
and locknuts.
1
23
Figure 1
1. Tail light plate
2. Frame bracket
3. Tail light mounting bracket
3. Secure rear of each tail light plate to rear of frame
brackets with a 5/16–18 x 1” lg. capscrew, .281” I.D.
flatwasher and nut, as shown in figure 1.
4. On left side, remove (2) capscrews, washers and nuts
securing tail light mounting bracket to tail light plate
(Fig. 2).
1
2
Figure 2
1. Fender 2. Fender mounting bracket
5. Position a fender over each tail light plate, aligning
mounting holes.
6. On left side, loosely secure tail light mounting bracket,
rear of fender and tail light plate together with (2)
capscrews, washers and nuts, previously removed.
7. On right side, secure rear of fender to tail light plate
with (2) 1/4–20 x 1” lg. capscrews, .281” I.D.
flatwashers and nuts
8. Loosely secure front of each fender mounting bracket to
frame with a 1/4–20 x 1” lg. capscrew and locknut.
9. Loosely secure side of each fender to frame (3) 3/8–16
x 1” lg. truss head screws and locknuts.
Note: Capscrews securing fronts of fenders to mounting
brackets may have to be loosened to align all mounting
holes.
10. Tighten all fasteners.
Install Wheels
(Model 07211TC only)
1. Remove and discard fasteners securing wheels.
2. Mount wheels and torque nuts to 55–75 ft-lb.
12
Figure 3
1. Wheel 2. Wheel nut
Install Steering Wheel
(Model 07211TC only)
1. Remove jam nut from steering shaft. Slide foam seal,
steering wheel and washer onto steering shaft.
2. Secure steering wheel to shaft with jam nut and tighten
it to 10–15 ft-lb.

19
3. Install cap to steering wheel.
1
2
3
4
5
Figure 4
1. Steering wheel
2. Jam nut
3. Cap
4. Washer
5. Foam seal
Install Front Fenders
(Model 07211TC only)
1. Mount a fender to each side of skirt with (7) 10–24
Phillips screws, flat washers and locknuts.
1
Figure 5
1. Fender
Install ROPS
(Model 07211TC only)
1. Insert each side of ROPS into mounting bracket on each
side of vehicle frame, positioning ROPS as shown in
figure 6.
2. Secure each side of ROPS to mounting brackets with
(2) 1/2–13 x 3” lg. capscrews and locknuts.
FRONT
1
2
Figure 6
1. ROPS 2. Mounting bracket
Activate and Charge Battery
If battery is not filled with electrolyte or activated, it must
be removed from vehicle, filled with electrolyte and
charged. Bulk electrolyte with 1.260 specific gravity can be
purchased from a local battery supply outlet.
CALIFORNIA
Proposition 65 Warning
Battery posts, terminals, and related accessories
contain lead and lead compounds, chemicals
known to the State of California to cause cancer
and reproductive harm. Wash hands after
handling.
Warning
Danger
Battery electrolyte contains sulfuric acid which is a
deadly poison and causes severe burns.
•Do not drink electrolyte and avoid contact with
skin, eyes or clothing. Wear safety glasses to
shield your eyes and rubber gloves to protect
your hands.
•Fill the battery where clean water is always
available for flushing the skin.

20
1. Loosen knobs securing battery cover to battery base and
slide cover off.
2. Remove capscrew, washers and locknut securing battery
hold down to battery base. Remove hold down and slide
battery out of battery base.
1
3
2
2
Figure 7
1. Battery cover
2. Knob
3. Battery base
3. Remove filler caps from battery and slowly fill each
cell until electrolyte is just above the plates.
4. Replace filler caps and connect a 3 to 4 amp battery
charger to the battery posts. Charge the battery at a rate
of 3 to 4 amperes for 4 to 8 hours.
Charging the battery produces gasses that can
explode.
Never smoke near the battery and keep sparks and
flames away from battery.
Warning
5. When battery is charged, disconnect charger from
electrical outlet and battery posts.
2
1
Figure 8
1. Positive (+) cable 2. Hold down
6. Remove filler caps. Slowly add electrolyte to each cell
until level is up to fill ring. Install filler caps.
Important Do not overfill battery. Electrolyte will
overflow onto other parts of the vehicle and severe
corrosion and deterioration will result.
7. Slide battery into battery base so battery terminals are
toward the rear of the vehicle.
8. Install the positive cable (red) to the positive (+)
terminal and the negative cable (black) to the negative
(—) terminal of the battery and secure with capscrews
and nuts. Slide the rubber boot over the positive
terminal to prevent possible short–out from occurring.
Incorrect battery cable routing could damage the
machine and cables causing sparks. Sparks can
cause the battery gasses to explode, resulting in
personal injury.
•Always disconnect the negative (black) battery
cable before disconnecting the positive (red)
cable.
•Always connect the positive (red) battery cable
before connecting the negative (black) cable.
Warning
9. Install battery hold down and secure to base with
capscrew, washers and locknut.
10. Reinstall battery cover to battery base and tighten
knobs.
