Toshiba RAS-M10YKV-E User manual

SERVICE MANUAL
FILE NO. A01-004
AIR-CONDITIONER
SUPPLEMENT
SPLIT TYPE
PRINTED IN JAPAN, Mar.,2001 ToMo
RAS-M10YKV-E, RAS-M13YKV-E, RAS-M16YKV-E
RAS-4M27YAV-E
RAS-M10YKCV-E, RAS-M13YKCV-E, RAS-M16YKCV-E
RAS-4M27YACV-E
RAS-M10YKV-E, RAS-M13YKV-E, RAS-M16YKV-E
RAS-3M26YAV-E
R410A
• Indoor Unit (1)
• Indoor Unit (2)
• Outdoor Unit
• P.C. board Layout
RAS-4M27YAV-E
RAS-4M27YACV-E
RAS-3M26YAV-E
Parts List
File No. A01-004

– 2 –
CONTENTS
1. SPECIFICATIONS....................................................................................... 3
2. REFRIGERANT R410A ............................................................................ 26
3. CONSTRUCTION VIEWS ......................................................................... 34
4. WIRING DIAGRAM ................................................................................... 36
5. SPECIFICATIONS OF ELECTRICAL PARTS .......................................... 38
6. REFRIGERANT CYCLE DIAGRAM ......................................................... 40
7. CONTROL BLOCK DIAGRAM ................................................................. 48
8. OPERATION DESCRIPTION .................................................................... 50
9. INSTALLATION PROCEDURE ................................................................. 63
10. HOW TO DIAGNOSE THE TROUBLE ....................................................... 79
11. HOW TO REPLACE THE MAIN PARTS .................................................... 98
12. EXPLODED VIEWS AND PARTS LIST .................................................. 108

– 3 –
1. SPECIFICATIONS
1-1. Specifications
RAS-M10YKV-E, RAS-M13YKV-E, RAS-M16YKV-E/RAS-4M27YAV-E, RAS-3M26YAV-E
• For performance when each indoor unit is combined with other unit, refer to the separate table.
• The specifications may be subject to change without notice for purpose of improvement.
Indoor RAS-M10YKV-E, RAS-M13YKV-E, RAS-M16YKV-E Unit model Outdoor RAS-4M27YAV-E RAS-3M26YAV-E
Cooling capacity
(
kW
)
8.0 7.5
Cooling capacity range
(
kW
)
1.4 –9.2 1.4 –8.9
Heating capacity
(
kW
)
9.0 9.0
Heating capacity range
(
kW
)
0.8 –11.0 0.8 –10.8
Power supply 220/230/240V, 1Ph, 50/60Hz
Unit model RAS-M10YKV-E RAS-M13YKV-E RAS-M16YKV-E
Running current
(
A
)
0.15 0.15 0.15
Power consumption
(
W
)
30 30 30
Indoor
Power factor
(
%
)
91/87/83 91/87/83 91/87/83
Operation mode Cooling Heating Cooling Heating
Running current
(
A
)
11.60/11.09/10.63 10.44/9.98/9.57 10.44/9.98/9.57 11.83/11.31/10.84
Power consumption
(
W
)
2500 2250 2250 2550
Power factor
(
%
)
98 98 98 98
Electric
characteristics
Total
Starting current
(
A
)
11.60/11.09/10.63 11.83/11.31/10.84
C.O.P. (Cooling/Heating) 3.20/4.00 3.33/3.53
Unit model RAS-M10YKV-E RAS-M13YKV-E RAS-M16YKV-E
High dB
(
A
)
36/39 39/40 42/42
Medium dB
(
A
)
33/35 35/35 38/39
Indoor
(Coolin
g
/Heatin
g
)
Low dB
(
A
)
30/30 30/30 33/33
Unit model RAS-4M27YAV-E RAS-3M26YAV-E
Operating
noise
Outdoor
(Coolin
g
/Heatin
g
)Full indoor units operatin
g
dB
(
A
)
48/48 48/48
Unit model RAS-M10YKV-E RAS-M13YKV-E RAS-M16YKV-E
Height
(
mm
)
265 265 265
Width
(
mm
)
790 790 790
Dimension
Depth
(
mm
)
189 189 189
Net weight
(
k
g)
8 8 8
Fan motor output
(
W
)
19 19 19
Indoor unit
Air flow rate (Cooling/Heating)
(
m³/h
)
470/520 520/560 600/600
Unit model RAS-4M27YAV-E RAS-3M26YAV-E
Height
(
mm
)
795 795
Width
(
mm
)
900 900
Dimension
Depth
(
mm
)
320 320
Net weight
(
k
g)
65 64
Motor output
(
W
)
2000
Type Twin rotary type with DC-inverter variable speed control
Compressor
Model DA220A2F-20L
Fan motor output
(
W
)
60
Outdoor unit
Air flow rate
(
m³/h
)
High : 3000, Medium : 2800
Type Flare connection
Unit model RAS-M10YKV-E RAS-M13YKV-E RAS-M16YKV-E
Liquid side Ø6.35 Ø6.35 Ø6.35
Indoor unit
Gas side Ø9.52 Ø9.52 Ø12.7
Unit model RAS-4M27YAV-E RAS-3M26YAV-E
A unit liquid side/gas side Ø6.35/Ø12.7 Ø6.35/Ø12.7
B unit liquid side/gas side Ø6.35/Ø9.52 Ø6.35/Ø9.52
C unit liquid side/gas side Ø6.35/Ø9.52 Ø6.35/Ø9.52
Outdoor unit
D unit liquid side/gas side Ø6.35/Ø9.52 —
Maximum length (per unit)
(
m
)
25 25
Maximum length (total)
(
m
)
70 50
Maximum chargeless length
(
m
)
70 50
Piping
connection
Maximum height difference
(
m
)
15 15
Name of refrigerant R410ARefrigerant Weight
(
k
g)
2.4
Power supply 3 wires : includes earthWiring connection Interconnection 4 wires : includes earth
Indoor
(
°C
)
21 –32/0 –28Usable temperature range Outdoor
(
°C
)
10 –43/–10–21
Installation plate 1
Wireless remote controller 1
Label 2
Remote controller holder 1
Pan head wood screw 2 (Ø3.1 x 16L)
Purifying filter 1
Deodorizing filter 1
Battery 2
Mounting screw 6 (Ø4 x 25L)
Indoor unit
Installation manual 1
Installation manual 1
Accessory
Outdoor unit Owner's manual 1

–4 –
RAS-M10YKCV-E, RAS-M13YKCV-E, RAS-M16YKCV-E/RAS-4M27YACV-E
•For performance when each indoor unit is combined with other unit, refer to the separate table.
•The specifications may be subject to change without notice for purpose of improvement.
Indoor RAS-M10YKCV-E, RAS-M13YKCV-E, RAS-M16YKCV-E Unit model Outdoor RAS-4M27YACV-E
Cooling capacity (kW) 8.0
Cooling capacity range (kW) 1.4 –9.2
Power supply 220/230/240V, 1Ph, 50/60Hz
Unit model RAS-M10YKCV-E RAS-M13YKCV-E RAS-M16YKCV-E
Running current (A) 0.15 0.15 0.15
Power consumption (W) 30 30 30
Indoor
Power factor (%) 91/87/83 91/87/83 91/87/83
Running current (A) 11.60/11.09/10.63
Power consumption (W) 2500
Power factor (%) 98
Electric
characteristics
Total
Starting current (A) 11.60/11.09/10.63
C.O.P. 3.20
Unit model RAS-M10YKCV-E RAS-M13YKCV-E RAS-M16YKCV-E
High dB (A) 36 39 42
Medium dB (A) 33 35 39
Indoor
LowdB(A)303033
Unit model RAS-4M27YACV-E
Operating
noise
Outdoor 4 indoor units operating dB (A) 48
Unit model RAS-M10YKCV-E RAS-M13YKCV-E RAS-M16YKCV-E
Height (mm) 265 265 265
Width (mm) 790 790 790
Dimension
Depth (mm) 189 189 189
Net weight (kg) 8 8 8
Fan motor output (W) 19 19 19
Indoor unit
Air flow rate (m³/h) 470 520 600
Unit model RAS-4M27YACV-E
Height (mm) 795
Width (mm) 900
Dimension
Depth (mm) 320
Net weight (kg) 63
Motor output (W) 2000
Type Twin rotary type with DC-inverter variable speed control
Compressor
Model DA220A2F-20L
Fan motor output (W) 60
Outdoor unit
Air flow rate (m³/h) High : 3000, Medium : 2800
Type Flare connection
Unit model RAS-M10YKCV-E RAS-M13YKCV-E RAS-M16YKCV-E
Liquid side Ø6.35 Ø6.35 Ø6.35
Indoor unit
Gas side Ø9.52 Ø9.52 Ø12.7
Unit model RAS-4M27YACV-E
A unit liquid side/gas side Ø6.35/Ø12.7
B unit liquid side/gas side Ø6.35/Ø9.52
C unit liquid side/gas side Ø6.35/Ø9.52
Outdoor unit
D unit liquid side/gas side Ø6.35/Ø9.52
Maximum length (per unit) (m) 25
Maximum length (total) (m) 70
Maximum chargeless length (m) 70
Piping
connection
Maximum height difference (m) 15
Name of refrigerant R410ARefrigerant Weight (kg) 2.2
Power supply 3 wires : includes earthWiring connection Interconnection 4 wires : includes earth
Indoor (°C) 21 –32Usable temperature range Outdoor (°C) 10 –43
Installation plate 1
Wireless remote controller 1
Label 2
Remote controller holder 1
Pan head wood screw 2 (Ø3.1 x 16L)
Purifying filter 1
Deodorizing filter 1
Battery 2
Mounting screw 6 (Ø4 x 25L)
Indoor unit
Installation manual 1
Installation manual 1
Accessory
Outdoor unit Owner's manual 1

–5 –
1-2. Specifications of PerformanceWhen Each Indoor Unit is Combined with other Unit
Outdoor Unit : RAS-4M27YAV-E
<Cooling/220V>
•The above specification values are those under the conditions that the indoor DB/WB=27/19°C and the outdoor DB/
WB=35/–°C.
•Indoor unit 10 : RAS-M10YKV-E, 13 : RAS-M13YKV-E, 16 : RAS-M16YKV-E
Indoor unit Unit capacity (kW)
Power
su
pp
l
y
(V)
O
p
eratin
g
status ABCD A B C D
Cooling
capacity
(kW)
Power
consum
p
tion
(W)
Operating
current
(A)
Outdoor
noise
(dB)
220 1 unit 10 –––2.7 ––– 2.7
(1.4 to 3.2) 750 (640 to 950) 3.87 (3.68 to 4.64) 48
13 –––3.7 ––– 3.7
(1.4 to 4.4) 1200 (640 to 1520) 5.74 (3.68 to 7.20) 48
16 –––4.5 ––– 4.5
(1.4 to 5.0) 1650 (640 to 2000) 7.81 (3.68 to 9.28) 48
2 units 10 10 ––2.70 2.70 –– 5.4
(2.5 to 6.3) 1530 (640 to 2040) 7.10 (3.64 to 9.46) 48
13 10 ––3.41 2.49 –– 5.9
(2.7 to 6.6) 1810 (660 to 2220) 8.40 (3.75 to 10.30) 48
16 10 ––3.94 2.36 –– 6.3
(2.9 to 6.9) 2040 (670 to 2400) 9.46 (3.81 to 11.13) 48
13 13 ––3.15 3.15 –– 6.3
(2.9 to 6.9) 2040 (670 to 2400) 9.46 (3.81 to 11.13) 48
16 13 ––3.73 3.07 –– 6.8
(3.0 to 7.2) 2320 (690 to 2570) 10.76 (3.92 to 11.92) 48
16 16 ––3.60 3.60 –– 7.2
(3.2 to 7.5) 2550 (700 to 2750) 11.83 (3.98 to 12.76) 48
3 units 10 10 10 –2.53 2.53 2.53 –7.6
(3.8 to 8.2) 2400 (950 to 2720) 11.13 (4.80 to 12.62) 48
13 10 10 –3.13 2.28 2.28 –7.7
(3.9 to 8.3) 2410 (960 to 2740) 11.18 (4.85 to 12.71) 48
16 10 10 –3.50 2.10 2.10 –7.7
(4.0 to 8.5) 2410 (960 to 2790) 11.18 (4.85 to 12.94) 48
13 13 10 –2.82 2.82 2.06 –7.7
(4.0 to 8.5) 2410 (960 to 2790) 11.18 (4.85 to 12.94) 48
16 13 10 –3.22 2.65 1.93 –7.8
(4.1 to 8.6) 2430 (970 to 2810) 11.27 (4.90 to 13.03) 48
13 13 13 –2.60 2.60 2.60 –7.8
(4.1 to 8.6) 2430 (970 to 2810) 11.27 (4.90 to 13.03) 48
16 16 10 –3.04 3.04 1.82 –7.9
(4.1 to 8.7) 2440 (970 to 2830) 11.32 (4.90 to 13.13) 48
16 13 13 –2.99 2.46 2.46 –7.9
(4.1 to 8.7) 2440 (970 to 2830) 11.32 (4.90 to 13.13) 48
16 16 13 –2.80 2.80 2.30 –7.9
(4.2 to 8.9) 2440 (970 to 2880) 11.32 (4.90 to 13.36) 48
16 16 16 –2.67 2.67 2.67 –8.0
(4.3 to 9.0) 2450 (980 to 2900) 11.36 (4.95 to 13.45) 48
4 units 10 10 10 10 1.98 1.98 1.98 1.98 7.9
(4.0 to 8.7) 2450 (930 to 2800) 11.36 (4.70 to 12.99) 48
13 10 10 10 2.48 1.81 1.81 1.81 7.9
(4.1 to 8.8) 2450 (940 to 2820) 11.36 (4.75 to 13.08) 48
16 10 10 10 2.86 1.71 1.71 1.71 8.0
(4.1 to 9.0) 2500 (940 to 2860) 11.60 (4.75 to 13.27) 48
13 13 10 10 2.31 2.31 1.69 1.69 8.0
(4.1 to 9.0) 2500 (940 to 2860) 11.60 (4.75 to 13.27) 48
16 13 10 10 2.65 2.18 1.59 1.59 8.0
(4.2 to 9.1) 2500 (950 to 2880) 11.60 (4.80 to 13.36) 48
13 13 13 10 2.14 2.14 2.14 1.57 8.0
(4.2 to 9.1) 2500 (950 to 2880) 11.60 (4.80 to 13.36) 48
16 13 13 10 2.47 2.03 2.03 1.48 8.0
(4.2 to 9.2) 2500 (950 to 2900) 11.60 (4.80 to 13.45) 48
13 13 13 13 2.00 2.00 2.00 2.00 8.0
(4.2 to 9.2) 2500 (950 to 2900) 11.60 (4.80 to 13.45) 48
16 16 10 10 2.50 2.50 1.50 1.50 8.0
(4.2 to 9.2) 2500 (950 to 2900) 11.60 (4.80 to 13.45) 48

–6 –
Outdoor Unit : RAS-4M27YAV-E
<Cooling/230V>
•The above specification values are those under the conditions that the indoor DB/WB=27/19°C and the outdoor DB/
WB=35/–°C.
•Indoor unit 10 : RAS-M10YKV-E, 13 : RAS-M13YKV-E, 16 : RAS-M16YKV-E
Indoor unit Unit capacity (kW)Power
su
pp
l
y
(V)
O
p
eratin
g
status ABCD A B C D
Cooling
capacity
(kW)
Power
consum
p
tion
(W)
Operating
current
(A)
Outdoor
noise
(dB)
230 1 unit 10 –––2.7 ––– 2.7
(1.4 to 3.2) 750 (640 to 950) 3.71 (3.52 to 4.44) 48
13 –––3.7 ––– 3.7
(1.4 to 4.4) 1200 (640 to 1520) 5.49 (3.52 to 6.88) 48
16 –––4.5 ––– 4.5
(1.4 to 5.0) 1650 (640 to 2000) 7.47 (3.52 to 8.87) 48
2 units 10 10 ––2.70 2.70 –– 5.4
(2.5 to 6.3) 1530 (640 to 2040) 6.79 (3.48 to 9.05) 48
13 10 ––3.41 2.49 –– 5.9
(2.7 to 6.6) 1810 (660 to 2220) 8.03 (3.59 to 9.85) 48
16 10 ––3.94 2.36 –– 6.3
(2.9 to 6.9) 2040 (670 to 2400) 9.05 (3.64 to 10.65) 48
13 13 ––3.15 3.15 –– 6.3
(2.9 to 6.9) 2040 (670 to 2400) 9.05 (3.64 to 10.65) 48
16 13 ––3.73 3.07 –– 6.8
(3.0 to 7.2) 2320 (690 to 2570) 10.29 (3.75 to 11.40) 48
16 16 ––3.60 3.60 –– 7.2
(3.2 to 7.5) 2550 (700 to 2750) 11.31 (3.80 to 12.20) 48
3 units 10 10 10 –2.53 2.53 2.53 –7.6
(3.8 to 8.2) 2400 (950 to 2720) 10.65 (4.59 to 12.07) 48
13 10 10 –3.13 2.28 2.28 –7.7
(3.9 to 8.3) 2410 (960 to 2740) 10.69 (4.64 to 12.16) 48
16 10 10 –3.50 2.10 2.10 –7.7
(4.0 to 8.5) 2410 (960 to 2790) 10.69 (4.64 to 12.38) 48
13 13 10 –2.82 2.82 2.06 –7.7
(4.0 to 8.5) 2410 (960 to 2790) 10.69 (4.64 to 12.38) 48
16 13 10 –3.22 2.65 1.93 –7.8
(4.1 to 8.6) 2430 (970 to 2810) 10.78 (4.69 to 12.47) 48
13 13 13 –2.60 2.60 2.60 –7.8
(4.1 to 8.6) 2430 (970 to 2810) 10.78 (4.69 to 12.47) 48
16 16 10 –3.04 3.04 1.82 –7.9
(4.1 to 8.7) 2440 (970 to 2830) 10.83 (4.69 to 12.56) 48
16 13 13 –2.99 2.46 2.46 –7.9
(4.1 to 8.7) 2440 (970 to 2830) 10.83 (4.69 to 12.56) 48
16 16 13 –2.80 2.80 2.30 –7.9
(4.2 to 8.9) 2440 (970 to 2880) 10.83 (4.69 to 12.78) 48
16 16 16 –2.67 2.67 2.67 –8.0
(4.3 to 9.0) 2450 (980 to 2900) 10.87 (4.73 to 12.87) 48
4 units 10 10 10 10 1.98 1.98 1.98 1.98 7.9
(4.0 to 8.7) 2450 (930 to 2800) 10.87 (4.49 to 12.42) 48
13 10 10 10 2.48 1.81 1.81 1.81 7.9
(4.1 to 8.8) 2450 (940 to 2820) 10.87 (4.54 to 12.51) 48
16 10 10 10 2.86 1.71 1.71 1.71 8.0
(4.1 to 9.0) 2500 (940 to 2860) 11.09 (4.54 to 12.69) 48
13 13 10 10 2.31 2.31 1.69 1.69 8.0
(4.1 to 9.0) 2500 (940 to 2860) 11.09 (4.54 to 12.69) 48
16 13 10 10 2.65 2.18 1.59 1.59 8.0
(4.2 to 9.1) 2500 (950 to 2880) 11.09 (4.59 to 12.78) 48
13 13 13 10 2.14 2.14 2.14 1.57 8.0
(4.2 to 9.1) 2500 (950 to 2880) 11.09 (4.59 to 12.78) 48
16 13 13 10 2.47 2.03 2.03 1.48 8.0
(4.2 to 9.2) 2500 (950 to 2900) 11.09 (4.59 to 12.87) 48
13 13 13 13 2.00 2.00 2.00 2.00 8.0
(4.2 to 9.2) 2500 (950 to 2900) 11.09 (4.59 to 12.87) 48
16 16 10 10 2.50 2.50 1.50 1.50 8.0
(4.2 to 9.2) 2500 (950 to 2900) 11.09 (4.59 to 12.87) 48

–7 –
Outdoor Unit : RAS-4M27YAV-E
<Cooling/240V>
•The above specification values are those under the conditions that the indoor DB/WB=27/19°C and the outdoor DB/
WB=35/–°C.
•Indoor unit 10 : RAS-M10YKV-E, 13 : RAS-M13YKV-E, 16 : RAS-M16YKV-E
Indoor unit Unit capacity (kW)Power
su
pp
l
y
(V)
O
p
eratin
g
status ABCD A B C D
Cooling
capacity
(kW)
Power
consum
p
tion
(W)
Operating
current
(A)
Outdoor
noise
(dB)
240 1 unit 10 –––2.7 ––– 2.7
(1.4 to 3.2) 750 (640 to 950) 3.55 (3.38 to 4.26) 48
13 –––3.7 ––– 3.7
(1.4 to 4.4) 1200 (640 to 1520) 5.26 (3.38 to 6.60) 48
16 –––4.5 ––– 4.5
(1.4 to 5.0) 1650 (640 to 2000) 7.16 (3.38 to 8.50) 48
2 units 10 10 ––2.70 2.70 –– 5.4
(2.5 to 6.3) 1530 (640 to 2040) 6.51 (3.33 to 8.67) 48
13 10 ––3.41 2.49 –– 5.9
(2.7 to 6.6) 1810 (660 to 2220) 7.70 (3.44 to 9.44) 48
16 10 ––3.94 2.36 –– 6.3
(2.9 to 6.9) 2040 (670 to 2400) 8.67 (3.49 to 10.20) 48
13 13 ––3.15 3.15 –– 6.3
(2.9 to 6.9) 2040 (670 to 2400) 8.67 (3.49 to 10.20) 48
16 13 ––3.73 3.07 –– 6.8
(3.0 to 7.2) 2320 (690 to 2570) 9.86 (3.59 to 10.93) 48
16 16 ––3.60 3.60 –– 7.2
(3.2 to 7.5) 2550 (700 to 2750) 10.84 (3.65 to 11.69) 48
3 units 10 10 10 –2.53 2.53 2.53 –7.6
(3.8 to 8.2) 2400 (950 to 2720) 10.20 (4.40 to 11.56) 48
13 10 10 –3.13 2.28 2.28 –7.7
(3.9 to 8.3) 2410 (960 to 2740) 10.25 (4.44 to 11.65) 48
16 10 10 –3.50 2.10 2.10 –7.7
(4.0 to 8.5) 2410 (960 to 2790) 10.25 (4.44 to 11.86) 48
13 13 10 –2.82 2.82 2.06 –7.7
(4.0 to 8.5) 2410 (960 to 2790) 10.25 (4.44 to 11.86) 48
16 13 10 –3.22 2.65 1.93 –7.8
(4.1 to 8.6) 2430 (970 to 2810) 10.33 (4.49 to 11.95) 48
13 13 13 –2.60 2.60 2.60 –7.8
(4.1 to 8.6) 2430 (970 to 2810) 10.33 (4.49 to 11.95) 48
16 16 10 –3.04 3.04 1.82 –7.9
(4.1 to 8.7) 2440 (970 to 2830) 10.37 (4.49 to 12.03) 48
16 13 13 –2.99 2.46 2.46 –7.9
(4.1 to 8.7) 2440 (970 to 2830) 10.37 (4.49 to 12.03) 48
16 16 13 –2.80 2.80 2.30 –7.9
(4.2 to 8.9) 2440 (970 to 2880) 10.37 (4.49 to 12.24) 48
16 16 16 –2.67 2.67 2.67 –8.0
(4.3 to 9.0) 2450 (980 to 2900) 10.42 (4.54 to 12.33) 48
4 units 10 10 10 10 1.98 1.98 1.98 1.98 7.9
(4.0 to 8.7) 2450 (930 to 2800) 10.42 (4.31 to 11.90) 48
13 10 10 10 2.48 1.81 1.81 1.81 7.9
(4.1 to 8.8) 2450 (940 to 2820) 10.42 (4.35 to 11.99) 48
16 10 10 10 2.86 1.71 1.71 1.71 8.0
(4.1 to 9.0) 2500 (940 to 2860) 10.63 (4.35 to 12.16) 48
13 13 10 10 2.31 2.31 1.69 1.69 8.0
(4.1 to 9.0) 2500 (940 to 2860) 10.63 (4.35 to 12.16) 48
16 13 10 10 2.65 2.18 1.59 1.59 8.0
(4.2 to 9.1) 2500 (950 to 2880) 10.63 (4.40 to 12.24) 48
13 13 13 10 2.14 2.14 2.14 1.57 8.0
(4.2 to 9.1) 2500 (950 to 2880) 10.63 (4.40 to 12.24) 48
16 13 13 10 2.47 2.03 2.03 1.48 8.0
(4.2 to 9.2) 2500 (950 to 2900) 10.63 (4.40 to 12.33) 48
13 13 13 13 2.00 2.00 2.00 2.00 8.0
(4.2 to 9.2) 2500 (950 to 2900) 10.63 (4.40 to 12.33) 48
16 16 10 10 2.50 2.50 1.50 1.50 8.0
(4.2 to 9.2) 2500 (950 to 2900) 10.63 (4.40 to 12.33) 48

–8 –
Outdoor Unit : RAS-4M27YAV-E
<Heating/220V>
•The above specification values are those under the conditions that the indoor DB/WB=27/19°C and the outdoor DB/
WB=35/–°C.
•Indoor unit 10 : RAS-M10YKV-E, 13 : RAS-M13YKV-E, 16 : RAS-M16YKV-E
Indoor unit Unit capacity (kW)Power
su
pp
l
y
(V)
O
p
eratin
g
status ABCD A B C D
Heating
capacity
(kW)
Power
consum
p
tion
(W)
Operating
current
(A)
Outdoor
noise
(dB)
220 1 unit 10 –––4.0 ––– 4.0
(0.8 to 5.2) 1450 (300 to 1980) 6.73 (1.87 to 9.18) 48
13 –––5.0 ––– 5.0
(0.8 to 6.5) 2050 (310 to 2750) 9.51 (1.93 to 12.76) 48
16 –––5.5 ––– 5.5
(0.8 to 6.9) 2400 (310 to 3000) 11.13 (1.93 to 13.91) 48
2 units 10 10 ––3.60 3.60 –– 7.2
(1.5 to 10.0) 2100 (320 to 3200) 9.74 (1.94 to 14.84) 48
13 10 ––4.22 3.38 –– 7.6
(1.5 to 10.1) 2320 (320 to 3210) 10.76 (1.94 to 14.89) 48
16 10 ––4.57 3.33 –– 7.9
(1.5 to 10.1) 2480 (320 to 3230) 11.50 (1.94 to 14.98) 48
13 13 ––3.95 3.95 –– 7.9
(1.5 to 10.1) 2480 (320 to 3230) 11.50 (1.94 to 14.98) 48
16 13 ––4.35 3.95 –– 8.3
(1.5 to 10.2) 2700 (320 to 3240) 12.52 (1.94 to 15.03) 48
16 16 ––4.30 4.30 –– 8.6
(1.5 to 10.2) 2860 (320 to 3250) 13.27 (1.94 to 15.07) 48
3 units 10 10 10 –2.87 2.87 2.87 –8.6
(2.0 to 10.4) 2300 (380 to 2750) 10.67 (2.16 to 12.76) 48
13 10 10 –3.35 2.68 2.68 –8.7
(2.0 to 10.5) 2350 (380 to 2760) 10.90 (2.16 to 12.80) 48
16 10 10 –3.54 2.58 2.58 –8.7
(2.0 to 10.5) 2350 (380 to 2760) 10.90 (2.16 to 12.80) 48
13 13 10 –3.11 3.11 2.49 –8.7
(2.0 to 10.5) 2350 (380 to 2760) 10.90 (2.16 to 12.80) 48
16 13 10 –3.34 3.03 2.43 –8.8
(2.0 to 10.6) 2400 (380 to 2780) 11.13 (2.16 to 12.89) 48
13 13 13 –2.93 2.93 2.93 –8.8
(2.0 to 10.6) 2400 (380 to 2780) 11.13 (2.16 to 12.89) 48
16 16 10 –3.26 3.26 2.37 –8.9
(2.0 to 10.7) 2450 (380 to 2790) 11.36 (2.16 to 12.94) 48
16 13 13 –3.16 2.87 2.87 –8.9
(2.0 to 10.7) 2450 (380 to 2790) 11.36 (2.16 to 12.94) 48
16 16 13 –3.06 3.06 2.78 –8.9
(2.0 to 10.7) 2450 (380 to 2790) 11.36 (2.16 to 12.94) 48
16 16 16 –3.00 3.00 3.00 –9.0
(2.0 to 10.8) 2500 (380 to 2800) 11.60 (2.16 to 12.99) 48
4 units 10 10 10 10 2.23 2.23 2.23 2.23 8.9
(2.2 to 10.8) 2100 (450 to 2810) 9.74 (2.56 to 13.03) 48
13 10 10 10 2.62 2.09 2.09 2.09 8.9
(2.2 to 10.9) 2100 (460 to 2830) 9.74 (2.61 to 13.13) 48
16 10 10 10 2.83 2.06 2.06 2.06 9.0
(2.2 to 10.9) 2250 (460 to 2830) 10.44 (2.61 to 13.13) 48
13 13 10 10 2.50 2.50 2.00 2.00 9.0
(2.2 to 10.9) 2250 (470 to 2830) 10.44 (2.67 to 13.13) 48
16 13 10 10 2.68 2.43 1.95 1.95 9.0
(2.2 to 11.0) 2250 (480 to 2850) 10.44 (2.73 to 13.22) 48
13 13 13 10 2.37 2.37 2.37 1.89 9.0
(2.2 to 11.0) 2250 (480 to 2850) 10.44 (2.73 to 13.22) 48
16 13 13 10 2.54 2.31 2.31 1.85 9.0
(2.2 to 11.0) 2250 (490 to 2850) 10.44 (2.78 to 13.22) 48
13 13 13 13 2.25 2.25 2.25 2.25 9.0
(2.2 to 11.0) 2250 (490 to 2850) 10.44 (2.78 to 13.22) 48
16 16 10 10 2.61 2.61 1.89 1.89 9.0
(2.2 to 11.0) 2250 (500 to 2850) 10.44 (2.84 to 13.22) 48

–9 –
•The above specification values are those under the conditions that the indoor DB/WB=27/19°C and the outdoor DB/
WB=35/–°C.
•Indoor unit 10 : RAS-M10YKV-E, 13 : RAS-M13YKV-E, 16 : RAS-M16YKV-E
Outdoor Unit : RAS-4M27YAV-E
<Heating/230V>
Indoor unit Unit capacity (kW)Power
su
pp
l
y
(V)
O
p
eratin
g
status ABCD A B C D
Heating
capacity
(kW)
Power
consum
p
tion
(W)
Operating
current
(A)
Outdoor
noise
(dB)
230 1 unit 10 –––4.0 ––– 4.0
(0.8 to 5.2) 1450 (300 to 1980) 6.43 (1.79 to 8.78) 48
13 –––5.0 ––– 5.0
(0.8 to 6.5) 2050 (310 to 2750) 9.09 (1.85 to 12.20) 48
16 –––5.5 ––– 5.5
(0.8 to 6.9) 2400 (310 to 3000) 10.65 (1.85 to 13.31) 48
2 units 10 10 ––3.60 3.60 –– 7.2
(1.5 to 10.0) 2100 (320 to 3200) 9.32 (1.86 to 14.20) 48
13 10 ––4.22 3.38 –– 7.6
(1.5 to 10.1) 2320 (320 to 3210) 10.29 (1.86 to 14.24) 48
16 10 ––4.57 3.33 –– 7.9
(1.5 to 10.1) 2480 (320 to 3230) 11.00 (1.86 to 14.33) 48
13 13 ––3.95 3.95 –– 7.9
(1.5 to 10.1) 2480 (320 to 3230) 11.00 (1.86 to 14.33) 48
16 13 ––4.35 3.95 –– 8.3
(1.5 to 10.2) 2700 (320 to 3240) 11.98 (1.86 to 14.37) 48
16 16 ––4.30 4.30 –– 8.6
(1.5 to 10.2) 2860 (320 to 3250) 12.69 (1.86 to 14.42) 48
3 units 10 10 10 –2.87 2.87 2.87 –8.6
(2.0 to 10.4) 2300 (380 to 2750) 10.20 (2.07 to 12.20) 48
13 10 10 –3.35 2.68 2.68 –8.7
(2.0 to 10.5) 2350 (380 to 2760) 10.43 (2.07 to 12.24) 48
16 10 10 –3.54 2.58 2.58 –8.7
(2.0 to 10.5) 2350 (380 to 2760) 10.43 (2.07 to 12.24) 48
13 13 10 –3.11 3.11 2.49 –8.7
(2.0 to 10.5) 2350 (380 to 2760) 10.43 (2.07 to 12.24) 48
16 13 10 –3.34 3.03 2.43 –8.8
(2.0 to 10.6) 2400 (380 to 2780) 10.65 (2.07 to 12.33) 48
13 13 13 –2.93 2.93 2.93 –8.8
(2.0 to 10.6) 2400 (380 to 2780) 10.65 (2.07 to 12.33) 48
16 16 10 –3.26 3.26 2.37 –8.9
(2.0 to 10.7) 2450 (380 to 2790) 10.87 (2.07 to 12.38) 48
16 13 13 –3.16 2.87 2.87 –8.9
(2.0 to 10.7) 2450 (380 to 2790) 10.87 (2.07 to 12.38) 48
16 16 13 –3.06 3.06 2.78 –8.9
(2.0 to 10.7) 2450 (380 to 2790) 10.87 (2.07 to 12.38) 48
16 16 16 –3.00 3.00 3.00 –9.0
(2.0 to 10.8) 2500 (380 to 2800) 11.09 (2.07 to 12.42) 48
4 units 10 10 10 10 2.23 2.23 2.23 2.23 8.9
(2.2 to 10.8) 2100 (450 to 2810) 9.32 (2.45 to 12.47) 48
13 10 10 10 2.62 2.09 2.09 2.09 8.9
(2.2 to 10.9) 2100 (460 to 2830) 9.32 (2.50 to 12.56) 48
16 10 10 10 2.83 2.06 2.06 2.06 9.0
(2.2 to 10.9) 2250 (460 to 2830) 9.98 (2.50 to 12.56) 48
13 13 10 10 2.50 2.50 2.00 2.00 9.0
(2.2 to 10.9) 2250 (470 to 2830) 9.98 (2.55 to 12.56) 48
16 13 10 10 2.68 2.43 1.95 1.95 9.0
(2.2 to 11.0) 2250 (480 to 2850) 9.98 (2.61 to 12.64) 48
13 13 13 10 2.37 2.37 2.37 1.89 9.0
(2.2 to 11.0) 2250 (480 to 2850) 9.98 (2.61 to 12.64) 48
16 13 13 10 2.54 2.31 2.31 1.85 9.0
(2.2 to 11.0) 2250 (490 to 2850) 9.98 (2.66 to 12.64) 48
13 13 13 13 2.25 2.25 2.25 2.25 9.0
(2.2 to 11.0) 2250 (490 to 2850) 9.98 (2.66 to 12.64) 48
16 16 10 10 2.61 2.61 1.89 1.89 9.0
(2.2 to 11.0) 2250 (500 to 2850) 9.98 (2.72 to 12.64) 48

–10 –
Outdoor Unit : RAS-4M27YAV-E
<Heating/240V>
•The above specification values are those under the conditions that the indoor DB/WB=27/19°C and the outdoor DB/
WB=35/–°C.
•Indoor unit 10 : RAS-M10YKV-E, 13 : RAS-M13YKV-E, 16 : RAS-M16YKV-E
Indoor unit Unit capacity (kW)Power
su
pp
l
y
(V)
O
p
eratin
g
status ABCD A B C D
Heating
capacity
(kW)
Power
consum
p
tion
(W)
Operating
current
(A)
Outdoor
noise
(dB)
240 1 unit 10 –––4.0 ––– 4.0
(0.8 to 5.2) 1450 (300 to 1980) 6.16 (1.71 to 8.42) 48
13 –––5.0 ––– 5.0
(0.8 to 6.5) 2050 (310 to 2750) 8.72 (1.77 to 11.69) 48
16 –––5.5 ––– 5.5
(0.8 to 6.9) 2400 (310 to 3000) 10.20 (1.77 to 12.76) 48
2 units 10 10 ––3.60 3.60 –– 7.2
(1.5 to 10.0) 2100 (320 to 3200) 8.93 (1.78 to 13.61) 48
13 10 ––4.22 3.38 –– 7.6
(1.5 to 10.1) 2320 (320 to 3210) 9.86 (1.78 to 13.65) 48
16 10 ––4.57 3.33 –– 7.9
(1.5 to 10.1) 2480 (320 to 3230) 10.54 (1.78 to 13.73) 48
13 13 ––3.95 3.95 –– 7.9
(1.5 to 10.1) 2480 (320 to 3230) 10.54 (1.78 to 13.73) 48
16 13 ––4.35 3.95 –– 8.3
(1.5 to 10.2) 2700 (320 to 3240) 11.48 (1.78 to 13.78) 48
16 16 ––4.30 4.30 –– 8.6
(1.5 to 10.2) 2860 (320 to 3250) 12.16 (1.78 to 13.82) 48
3 units 10 10 10 –2.87 2.87 2.87 –8.6
(2.0 to 10.4) 2300 (380 to 2750) 9.78 (1.98 to 11.69) 48
13 10 10 –3.35 2.68 2.68 –8.7
(2.0 to 10.5) 2350 (380 to 2760) 9.99 (1.98 to 11.73) 48
16 10 10 –3.54 2.58 2.58 –8.7
(2.0 to 10.5) 2350 (380 to 2760) 9.99 (1.98 to 11.73) 48
13 13 10 –3.11 3.11 2.49 –8.7
(2.0 to 10.5) 2350 (380 to 2760) 9.99 (1.98 to 11.73) 48
16 13 10 –3.34 3.03 2.43 –8.8
(2.0 to 10.6) 2400 (380 to 2780) 10.20 (1.98 to 11.82) 48
13 13 13 –2.93 2.93 2.93 –8.8
(2.0 to 10.6) 2400 (380 to 2780) 10.20 (1.98 to 11.82) 48
16 16 10 –3.26 3.26 2.37 –8.9
(2.0 to 10.7) 2450 (380 to 2790) 10.42 (1.98 to 11.86) 48
16 13 13 –3.16 2.87 2.87 –8.9
(2.0 to 10.7) 2450 (380 to 2790) 10.42 (1.98 to 11.86) 48
16 16 13 –3.06 3.06 2.78 –8.9
(2.0 to 10.7) 2450 (380 to 2790) 10.42 (1.98 to 11.86) 48
16 16 16 –3.00 3.00 3.00 –9.0
(2.0 to 10.8) 2500 (380 to 2800) 10.63 (1.98 to 11.90) 48
4 units 10 10 10 10 2.23 2.23 2.23 2.23 8.9
(2.2 to 10.8) 2100 (450 to 2810) 8.93 (2.34 to 11.95) 48
13 10 10 10 2.62 2.09 2.09 2.09 8.9
(2.2 to 10.9) 2100 (460 to 2830) 8.93 (2.40 to 12.03) 48
16 10 10 10 2.83 2.06 2.06 2.06 9.0
(2.2 to 10.9) 2250 (460 to 2830) 9.57 (2.40 to 12.03) 48
13 13 10 10 2.50 2.50 2.00 2.00 9.0
(2.2 to 10.9) 2250 (470 to 2830) 9.57 (2.45 to 12.03) 48
16 13 10 10 2.68 2.43 1.95 1.95 9.0
(2.2 to 11.0) 2250 (480 to 2850) 9.57 (2.50 to 12.12) 48
13 13 13 10 2.37 2.37 2.37 1.89 9.0
(2.2 to 11.0) 2250 (480 to 2850) 9.57 (2.50 to 12.12) 48
16 13 13 10 2.54 2.31 2.31 1.85 9.0
(2.2 to 11.0) 2250 (490 to 2850) 9.57 (2.55 to 12.12) 48
13 13 13 13 2.25 2.25 2.25 2.25 9.0
(2.2 to 11.0) 2250 (490 to 2850) 9.57 (2.55 to 12.12) 48
16 16 10 10 2.61 2.61 1.89 1.89 9.0
(2.2 to 11.0) 2250 (500 to 2850) 9.57 (2.60 to 12.12) 48

–11 –
Outdoor Unit : RAS-4M27YACV-E
<Cooling/220V>
•The above specification values are those under the conditions that the indoor DB/WB=27/19°C and the outdoor DB/
WB=35/–°C.
•Indoor unit 10 : RAS-M10YKCV-E, 13 : RAS-M13YKCV-E, 16 : RAS-M16YKCV-E
Indoor unit Unit capacity (kW)Power
su
pp
l
y
(V)
O
p
eratin
g
status ABCD A B C D
Cooling
capacity
(kW)
Power
consum
p
tion
(W)
Operating
current
(A)
Outdoor
noise
(dB)
220 1 unit 10 –––2.7 ––– 2.7
(1.4 to 3.2) 750 (640 to 950) 3.87 (3.68 to 4.64) 48
13 –––3.7 ––– 3.7
(1.4 to 4.4) 1200 (640 to 1520) 5.74 (3.68 to 7.20) 48
16 –––4.5 ––– 4.5
(1.4 to 5.0) 1650 (640 to 2000) 7.81 (3.68 to 9.28) 48
2 units 10 10 ––2.70 2.70 –– 5.4
(2.5 to 6.3) 1530 (640 to 2040) 7.10 (3.64 to 9.46) 48
13 10 ––3.41 2.49 –– 5.9
(2.7 to 6.6) 1810 (660 to 2220) 8.40 (3.75 to 10.30) 48
16 10 ––3.94 2.36 –– 6.3
(2.9 to 6.9) 2040 (670 to 2400) 9.46 (3.81 to 11.13) 48
13 13 ––3.15 3.15 –– 6.3
(2.9 to 6.9) 2040 (670 to 2400) 9.46 (3.81 to 11.13) 48
16 13 ––3.73 3.07 –– 6.8
(3.0 to 7.2) 2320 (690 to 2570) 10.76 (3.92 to 11.92) 48
16 16 ––3.60 3.60 –– 7.2
(3.2 to 7.5) 2550 (700 to 2750) 11.83 (3.98 to 12.76) 48
3 units 10 10 10 –2.53 2.53 2.53 –7.6
(3.8 to 8.2) 2400 (950 to 2720) 11.13 (4.80 to 12.62) 48
13 10 10 –3.13 2.28 2.28 –7.7
(3.9 to 8.3) 2410 (960 to 2740) 11.18 (4.85 to 12.71) 48
16 10 10 –3.50 2.10 2.10 –7.7
(4.0 to 8.5) 2410 (960 to 2790) 11.18 (4.85 to 12.94) 48
13 13 10 –2.82 2.82 2.06 –7.7
(4.0 to 8.5) 2410 (960 to 2790) 11.18 (4.85 to 12.94) 48
16 13 10 –3.22 2.65 1.93 –7.8
(4.1 to 8.6) 2430 (970 to 2810) 11.27 (4.90 to 13.03) 48
13 13 13 –2.60 2.60 2.60 –7.8
(4.1 to 8.6) 2430 (970 to 2810) 11.27 (4.90 to 13.03) 48
16 16 10 –3.04 3.04 1.82 –7.9
(4.1 to 8.7) 2440 (970 to 2830) 11.32 (4.90 to 13.13) 48
16 13 13 –2.99 2.46 2.46 –7.9
(4.1 to 8.7) 2440 (970 to 2830) 11.32 (4.90 to 13.13) 48
16 16 13 –2.80 2.80 2.30 –7.9
(4.2 to 8.9) 2440 (970 to 2880) 11.32 (4.90 to 13.36) 48
16 16 16 –2.67 2.67 2.67 –8.0
(4.3 to 9.0) 2450 (980 to 2900) 11.36 (4.95 to 13.45) 48
4 units 10 10 10 10 1.98 1.98 1.98 1.98 7.9
(4.0 to 8.7) 2450 (930 to 2800) 11.36 (4.70 to 12.99) 48
13 10 10 10 2.48 1.81 1.81 1.81 7.9
(4.1 to 8.8) 2450 (940 to 2820) 11.36 (4.75 to 13.08) 48
16 10 10 10 2.86 1.71 1.71 1.71 8.0
(4.1 to 9.0) 2500 (940 to 2860) 11.60 (4.75 to 13.27) 48
13 13 10 10 2.31 2.31 1.69 1.69 8.0
(4.1 to 9.0) 2500 (940 to 2860) 11.60 (4.75 to 13.27) 48
16 13 10 10 2.65 2.18 1.59 1.59 8.0
(4.2 to 9.1) 2500 (950 to 2880) 11.60 (4.80 to 13.36) 48
13 13 13 10 2.14 2.14 2.14 1.57 8.0
(4.2 to 9.1) 2500 (950 to 2880) 11.60 (4.80 to 13.36) 48
16 13 13 10 2.47 2.03 2.03 1.48 8.0
(4.2 to 9.2) 2500 (950 to 2900) 11.60 (4.80 to 13.45) 48
13 13 13 13 2.00 2.00 2.00 2.00 8.0
(4.2 to 9.2) 2500 (950 to 2900) 11.60 (4.80 to 13.45) 48
16 16 10 10 2.50 2.50 1.50 1.50 8.0
(4.2 to 9.2) 2500 (950 to 2900) 11.60 (4.80 to 13.45) 48

–12 –
Outdoor Unit : RAS-4M27YACV-E
<Cooling/230V>
•The above specification values are those under the conditions that the indoor DB/WB=27/19°C and the outdoor DB/
WB=35/–°C.
•Indoor unit 10 : RAS-M10YKCV-E, 13 : RAS-M13YKCV-E, 16 : RAS-M16YKCV-E
Indoor unit Unit capacity (kW)Power
su
pp
l
y
(V)
O
p
eratin
g
status ABCD A B C D
Cooling
capacity
(kW)
Power
consum
p
tion
(W)
Operating
current
(A)
Outdoor
noise
(dB)
230 1 unit 10 –––2.7 ––– 2.7
(1.4 to 3.2) 750 (640 to 950) 3.71 (3.52 to 4.44) 48
13 –––3.7 ––– 3.7
(1.4 to 4.4) 1200 (640 to 1520) 5.49 (3.52 to 6.88) 48
16 –––4.5 ––– 4.5
(1.4 to 5.0) 1650 (640 to 2000) 7.47 (3.52 to 8.87) 48
2 units 10 10 ––2.70 2.70 –– 5.4
(2.5 to 6.3) 1530 (640 to 2040) 6.79 (3.48 to 9.05) 48
13 10 ––3.41 2.49 –– 5.9
(2.7 to 6.6) 1810 (660 to 2220) 8.03 (3.59 to 9.85) 48
16 10 ––3.94 2.36 –– 6.3
(2.9 to 6.9) 2040 (670 to 2400) 9.05 (3.64 to 10.65) 48
13 13 ––3.15 3.15 –– 6.3
(2.9 to 6.9) 2040 (670 to 2400) 9.05 (3.64 to 10.65) 48
16 13 ––3.73 3.07 –– 6.8
(3.0 to 7.2) 2320 (690 to 2570) 10.29 (3.75 to 11.40) 48
16 16 ––3.60 3.60 –– 7.2
(3.2 to 7.5) 2550 (700 to 2750) 11.31 (3.80 to 12.20) 48
3 units 10 10 10 –2.53 2.53 2.53 –7.6
(3.8 to 8.2) 2400 (950 to 2720) 10.65 (4.59 to 12.07) 48
13 10 10 –3.13 2.28 2.28 –7.7
(3.9 to 8.3) 2410 (960 to 2740) 10.69 (4.64 to 12.16) 48
16 10 10 –3.50 2.10 2.10 –7.7
(4.0 to 8.5) 2410 (960 to 2790) 10.69 (4.64 to 12.38) 48
13 13 10 –2.82 2.82 2.06 –7.7
(4.0 to 8.5) 2410 (960 to 2790) 10.69 (4.64 to 12.38) 48
16 13 10 –3.22 2.65 1.93 –7.8
(4.1 to 8.6) 2430 (970 to 2810) 10.78 (4.69 to 12.47) 48
13 13 13 –2.60 2.60 2.60 –7.8
(4.1 to 8.6) 2430 (970 to 2810) 10.78 (4.69 to 12.47) 48
16 16 10 –3.04 3.04 1.82 –7.9
(4.1 to 8.7) 2440 (970 to 2830) 10.83 (4.69 to 12.56) 48
16 13 13 –2.99 2.46 2.46 –7.9
(4.1 to 8.7) 2440 (970 to 2830) 10.83 (4.69 to 12.56) 48
16 16 13 –2.80 2.80 2.30 –7.9
(4.2 to 8.9) 2440 (970 to 2880) 10.83 (4.69 to 12.78) 48
16 16 16 –2.67 2.67 2.67 –8.0
(4.3 to 9.0) 2450 (980 to 2900) 10.87 (4.73 to 12.87) 48
4 units 10 10 10 10 1.98 1.98 1.98 1.98 7.9
(4.0 to 8.7) 2450 (930 to 2800) 10.87 (4.49 to 12.42) 48
13 10 10 10 2.48 1.81 1.81 1.81 7.9
(4.1 to 8.8) 2450 (940 to 2820) 10.87 (4.54 to 12.51) 48
16 10 10 10 2.86 1.71 1.71 1.71 8.0
(4.1 to 9.0) 2500 (940 to 2860) 11.09 (4.54 to 12.69) 48
13 13 10 10 2.31 2.31 1.69 1.69 8.0
(4.1 to 9.0) 2500 (940 to 2860) 11.09 (4.54 to 12.69) 48
16 13 10 10 2.65 2.18 1.59 1.59 8.0
(4.2 to 9.1) 2500 (950 to 2880) 11.09 (4.59 to 12.78) 48
13 13 13 10 2.14 2.14 2.14 1.57 8.0
(4.2 to 9.1) 2500 (950 to 2880) 11.09 (4.59 to 12.78) 48
16 13 13 10 2.47 2.03 2.03 1.48 8.0
(4.2 to 9.2) 2500 (950 to 2900) 11.09 (4.59 to 12.87) 48
13 13 13 13 2.00 2.00 2.00 2.00 8.0
(4.2 to 9.2) 2500 (950 to 2900) 11.09 (4.59 to 12.87) 48
16 16 10 10 2.50 2.50 1.50 1.50 8.0
(4.2 to 9.2) 2500 (950 to 2900) 11.09 (4.59 to 12.87) 48

–13 –
Outdoor Unit : RAS-4M27YACV-E
<Cooling/240V>
•The above specification values are those under the conditions that the indoor DB/WB=27/19°C and the outdoor DB/
WB=35/–°C.
•Indoor unit 10 : RAS-M10YKCV-E, 13 : RAS-M13YKCV-E, 16 : RAS-M16YKCV-E
Indoor unit Unit capacity (kW)Power
su
pp
l
y
(V)
O
p
eratin
g
status ABCD A B C D
Cooling
capacity
(kW)
Power
consum
p
tion
(W)
Operating
current
(A)
Outdoor
noise
(dB)
240 1 unit 10 –––2.7 ––– 2.7
(1.4 to 3.2) 750 (640 to 950) 3.55 (3.38 to 4.26) 48
13 –––3.7 ––– 3.7
(1.4 to 4.4) 1200 (640 to 1520) 5.26 (3.38 to 6.60) 48
16 –––4.5 ––– 4.5
(1.4 to 5.0) 1650 (640 to 2000) 7.16 (3.38 to 8.50) 48
2 units 10 10 ––2.70 2.70 –– 5.4
(2.5 to 6.3) 1530 (640 to 2040) 6.51 (3.33 to 8.67) 48
13 10 ––3.41 2.49 –– 5.9
(2.7 to 6.6) 1810 (660 to 2220) 7.70 (3.44 to 9.44) 48
16 10 ––3.94 2.36 –– 6.3
(2.9 to 6.9) 2040 (670 to 2400) 8.67 (3.49 to 10.20) 48
13 13 ––3.15 3.15 –– 6.3
(2.9 to 6.9) 2040 (670 to 2400) 8.67 (3.49 to 10.20) 48
16 13 ––3.73 3.07 –– 6.8
(3.0 to 7.2) 2320 (690 to 2570) 9.86 (3.59 to 10.93) 48
16 16 ––3.60 3.60 –– 7.2
(3.2 to 7.5) 2550 (700 to 2750) 10.84 (3.65 to 11.69) 48
3 units 10 10 10 –2.53 2.53 2.53 –7.6
(3.8 to 8.2) 2400 (950 to 2720) 10.20 (4.40 to 11.56) 48
13 10 10 –3.13 2.28 2.28 –7.7
(3.9 to 8.3) 2410 (960 to 2740) 10.25 (4.44 to 11.65) 48
16 10 10 –3.50 2.10 2.10 –7.7
(4.0 to 8.5) 2410 (960 to 2790) 10.25 (4.44 to 11.86) 48
13 13 10 –2.82 2.82 2.06 –7.7
(4.0 to 8.5) 2410 (960 to 2790) 10.25 (4.44 to 11.86) 48
16 13 10 –3.22 2.65 1.93 –7.8
(4.1 to 8.6) 2430 (970 to 2810) 10.33 (4.49 to 11.95) 48
13 13 13 –2.60 2.60 2.60 –7.8
(4.1 to 8.6) 2430 (970 to 2810) 10.33 (4.49 to 11.95) 48
16 16 10 –3.04 3.04 1.82 –7.9
(4.1 to 8.7) 2440 (970 to 2830) 10.37 (4.49 to 12.03) 48
16 13 13 –2.99 2.46 2.46 –7.9
(4.1 to 8.7) 2440 (970 to 2830) 10.37 (4.49 to 12.03) 48
16 16 13 –2.80 2.80 2.30 –7.9
(4.2 to 8.9) 2440 (970 to 2880) 10.37 (4.49 to 12.24) 48
16 16 16 –2.67 2.67 2.67 –8.0
(4.3 to 9.0) 2450 (980 to 2900) 10.42 (4.54 to 12.33) 48
4 units 10 10 10 10 1.98 1.98 1.98 1.98 7.9
(4.0 to 8.7) 2450 (930 to 2800) 10.42 (4.31 to 11.90) 48
13 10 10 10 2.48 1.81 1.81 1.81 7.9
(4.1 to 8.8) 2450 (940 to 2820) 10.42 (4.35 to 11.99) 48
16 10 10 10 2.86 1.71 1.71 1.71 8.0
(4.1 to 9.0) 2500 (940 to 2860) 10.63 (4.35 to 12.16) 48
13 13 10 10 2.31 2.31 1.69 1.69 8.0
(4.1 to 9.0) 2500 (940 to 2860) 10.63 (4.35 to 12.16) 48
16 13 10 10 2.65 2.18 1.59 1.59 8.0
(4.2 to 9.1) 2500 (950 to 2880) 10.63 (4.40 to 12.24) 48
13 13 13 10 2.14 2.14 2.14 1.57 8.0
(4.2 to 9.1) 2500 (950 to 2880) 10.63 (4.40 to 12.24) 48
16 13 13 10 2.47 2.03 2.03 1.48 8.0
(4.2 to 9.2) 2500 (950 to 2900) 10.63 (4.40 to 12.33) 48
13 13 13 13 2.00 2.00 2.00 2.00 8.0
(4.2 to 9.2) 2500 (950 to 2900) 10.63 (4.40 to 12.33) 48
16 16 10 10 2.50 2.50 1.50 1.50 8.0
(4.2 to 9.2) 2500 (950 to 2900) 10.63 (4.40 to 12.33) 48

–14 –
Outdoor Unit : RAS-3M26YAV-E
<Cooling/220V>
•The above specification values are those under the conditions that the indoor DB/WB=27/19°C and the outdoor DB/
WB=35/–°C.
•Indoor unit 10 : RAS-M10YKV-E, 13 : RAS-M13YKV-E, 16 : RAS-M16YKV-E
Indoor unit Unit capacity (kW)Power
su
pp
l
y
(V)
O
p
eratin
g
status ABCABC
Cooling
capacity
(kW)
Power
consum
p
tion
(W)
Operating
current
(A)
Outdoor
noise
(dB)
220 1 unit 10 ––2.7 –– 2.7
(1.4 to 3.2) 750 (640 to 950) 3.87 (3.68 to 4.64) 48
13 ––3.7 –– 3.7
(1.4 to 4.4) 1200 (640 to 1520) 5.74 (3.68 to 7.20) 48
16 ––4.5 –– 4.5
(1.4 to 5.0) 1650 (640 to 2000) 7.81 (3.68 to 9.28) 48
2 units 10 10 –2.70 2.70 –5.4
(2.5 to 6.3) 1530 (640 to 2040) 7.10 (3.64 to 9.46) 48
13 10 –3.41 2.49 –5.9
(2.7 to 6.6) 1810 (660 to 2220) 8.40 (3.75 to 10.30) 48
16 10 –3.94 2.36 –6.3
(2.9 to 6.9) 2040 (670 to 2400) 9.46 (3.81 to 11.13) 48
13 13 –3.15 3.15 –6.3
(2.9 to 6.9) 2040 (670 to 2400) 9.46 (3.81 to 11.13) 48
16 13 –3.73 3.07 –6.8
(3.0 to 7.2) 2320 (690 to 2570) 10.76 (3.92 to 11.92) 48
16 16 –3.60 3.60 –7.2
(3.2 to 7.5) 2550 (700 to 2750) 11.83 (3.98 to 12.76) 48
3 units 10 10 10 2.47 2.47 2.47 7.4
(3.8 to 8.2) 2230 (950 to 2720) 10.34 (4.80 to 12.62) 48
13 10 10 3.01 2.20 2.20 7.4
(3.9 to 8.3) 2230 (950 to 2750) 10.34 (4.80 to 12.76) 48
16 10 10 3.36 2.02 2.02 7.4
(4.0 to 8.5) 2230 (950 to 2820) 10.34 (4.80 to 13.08) 48
13 13 10 2.71 2.71 1.98 7.4
(4.0 to 8.5) 2230 (950 to 2820) 10.34 (4.80 to 13.08) 48
16 13 10 3.10 2.55 1.86 7.5
(4.0 to 8.6) 2250 (980 to 2850) 10.44 (4.95 to 13.22) 48
13 13 13 2.50 2.50 2.50 7.5
(4.0 to 8.6) 2250 (980 to 2850) 10.44 (4.95 to 13.22) 48
16 16 10 2.88 2.88 1.73 7.5
(4.1 to 8.8) 2250 (980 to 2920) 10.44 (4.95 to 13.54) 48
16 13 13 2.84 2.33 2.33 7.5
(4.1 to 8.8) 2250 (980 to 2920) 10.44 (4.95 to 13.54) 48
16 16 13 2.66 2.66 2.19 7.5
(4.2 to 8.9) 2250 (980 to 2950) 10.44 (4.95 to 13.68) 48

–15 –
Outdoor Unit : RAS-3M26YAV-E
<Cooling/230V>
•The above specification values are those under the conditions that the indoor DB/WB=27/19°C and the outdoor DB/
WB=35/–°C.
•Indoor unit 10 : RAS-M10YKV-E, 13 : RAS-M13YKV-E, 16 : RAS-M16YKV-E
Indoor unit Unit capacity (kW)Power
su
pp
l
y
(V)
O
p
eratin
g
status ABCABC
Cooling
capacity
(kW)
Power
consum
p
tion
(W)
Operating
current
(A)
Outdoor
noise
(dB)
230 1 unit 10 ––2.7 –– 2.7
(1.4 to 3.2) 750 (640 to 950) 3.71 (3.52 to 4.44) 48
13 ––3.7 –– 3.7
(1.4 to 4.4) 1200 (640 to 1520) 5.49 (3.52 to 6.88) 48
16 ––4.5 –– 4.5
(1.4 to 5.0) 1650 (640 to 2000) 7.47 (3.52 to 8.87) 48
2 units 10 10 –2.70 2.70 –5.4
(2.5 to 6.3) 1530 (640 to 2040) 6.79 (3.48 to 9.05) 48
13 10 –3.41 2.49 –5.9
(2.7 to 6.6) 1810 (660 to 2220) 8.03 (3.59 to 9.85) 48
16 10 –3.94 2.36 –6.3
(2.9 to 6.9) 2040 (670 to 2400) 9.05 (3.64 to 10.65) 48
13 13 –3.15 3.15 –6.3
(2.9 to 6.9) 2040 (670 to 2400) 9.05 (3.64 to 10.65) 48
16 13 –3.73 3.07 –6.8
(3.0 to 7.2) 2320 (690 to 2570) 10.29 (3.75 to 11.40) 48
16 16 –3.60 3.60 –7.2
(3.2 to 7.5) 2550 (700 to 2750) 11.31 (3.80 to 12.20) 48
3 units 10 10 10 2.47 2.47 2.47 7.4
(3.8 to 8.2) 2230 (950 to 2720) 9.89 (4.59 to 12.07) 48
13 10 10 3.01 2.20 2.20 7.4
(3.9 to 8.3) 2230 (950 to 2750) 9.89 (4.59 to 12.20) 48
16 10 10 3.36 2.02 2.02 7.4
(4.0 to 8.5) 2230 (950 to 2820) 9.89 (4.59 to 12.51) 48
13 13 10 2.71 2.71 1.98 7.4
(4.0 to 8.5) 2230 (950 to 2820) 9.89 (4.59 to 12.51) 48
16 13 10 3.10 2.55 1.86 7.5
(4.0 to 8.6) 2250 (980 to 2850) 9.98 (4.73 to 12.64) 48
13 13 13 2.50 2.50 2.50 7.5
(4.0 to 8.6) 2250 (980 to 2850) 9.98 (4.73 to 12.64) 48
16 16 10 2.88 2.88 1.73 7.5
(4.1 to 8.8) 2250 (980 to 2920) 9.98 (4.73 to 12.95) 48
16 13 13 2.84 2.33 2.33 7.5
(4.1 to 8.8) 2250 (980 to 2920) 9.98 (4.73 to 12.95) 48
16 16 13 2.66 2.66 2.19 7.5
(4.2 to 8.9) 2250 (980 to 2950) 9.98 (4.73 to 13.09) 48

–16 –
Outdoor Unit : RAS-3M26YAV-E
<Cooling/240V>
•The above specification values are those under the conditions that the indoor DB/WB=27/19°C and the outdoor DB/
WB=35/–°C.
•Indoor unit 10 : RAS-M10YKV-E, 13 : RAS-M13YKV-E, 16 : RAS-M16YKV-E
Indoor unit Unit capacity (kW)Power
su
pp
l
y
(V)
O
p
eratin
g
status ABCABC
Cooling
capacity
(kW)
Power
consum
p
tion
(W)
Operating
current
(A)
Outdoor
noise
(dB)
240 1 unit 10 ––2.7 –– 2.7
(1.4 to 3.2) 750 (640 to 950) 3.55 (338 to 4.26) 48
13 ––3.7 –– 3.7
(1.4 to 4.4) 1200 (640 to 1520) 5.26 (3.38 to 6.60) 48
16 ––4.5 –– 4.5
(1.4 to 5.0) 1650 (640 to 2000) 7.16 (3.38 to 8.50) 48
2 units 10 10 –2.70 2.70 –5.4
(2.5 to 6.3) 1530 (640 to 2040) 6.51 (3.33 to 8.67) 48
13 10 –3.41 2.49 –5.9
(2.7 to 6.6) 1810 (660 to 2220) 7.70 (3.44 to 9.44) 48
16 10 –3.94 2.36 –6.3
(2.9 to 6.9) 2040 (670 to 2400) 8.67 (3.49 to 10.20) 48
13 13 –3.15 3.15 –6.3
(2.9 to 6.9) 2040 (670 to 2400) 8.67 (3.49 to 10.20) 48
16 13 –3.73 3.07 –6.8
(3.0 to 7.2) 2320 (690 to 2570) 9.86 (3.59 to 10.93) 48
16 16 –3.60 3.60 –7.2
(3.2 to 7.5) 2550 (700 to 2750) 10.84 (3.65 to 11.69) 48
3 units 10 10 10 2.47 2.47 2.47 7.4
(3.8 to 8.2) 2230 (950 to 2720) 9.48 (4.40 to 11.56) 48
13 10 10 3.01 2.20 2.20 7.4
(3.9 to 8.3) 2230 (950 to 2750) 9.48 (4.40 to 11.69) 48
16 10 10 3.36 2.02 2.02 7.4
(4.0 to 8.5) 2230 (950 to 2820) 9.48 (4.40 to 11.99) 48
13 13 10 2.71 2.71 1.98 7.4
(4.0 to 8.5) 2230 (950 to 2820) 9.48 (4.40 to 11.99) 48
16 13 10 3.10 2.55 1.86 7.5
(4.0 to 8.6) 2250 (980 to 2850) 9.57 (4.54 to 12.12) 48
13 13 13 2.50 2.50 2.50 7.5
(4.0 to 8.6) 2250 (980 to 2850) 9.57 (4.54 to 12.12) 48
16 16 10 2.88 2.88 1.73 7.5
(4.1 to 8.8) 2250 (980 to 2920) 9.57 (4.54 to 12.41) 48
16 13 13 2.84 2.33 2.33 7.5
(4.1 to 8.8) 2250 (980 to 2920) 9.57 (4.54 to 12.41) 48
16 16 13 2.66 2.66 2.19 7.5
(4.2 to 8.9) 2250 (980 to 2950) 9.57 (4.54 to 12.54) 48

–17 –
Outdoor Unit : RAS-3M26YAV-E
<Heating/220V>
•The above specification values are those under the conditions that the indoor DB/WB=27/19°C and the outdoor DB/
WB=35/–°C.
•Indoor unit 10 : RAS-M10YKV-E, 13 : RAS-M13YKV-E, 16 : RAS-M16YKV-E
Indoor unit Unit capacity (kW)Power
su
pp
l
y
(V)
O
p
eratin
g
status ABCABC
Heating
capacity
(kW)
Power
consum
p
tion
(W)
Operating
current
(A)
Outdoor
noise
(dB)
220 1 unit 10 ––4.0 –– 4.0
(0.8 to 5.2) 1500 (300 to 1980) 6.96 (1.87 to 9.18) 48
13 ––5.0 –– 5.0
(0.8 to 6.5) 2050 (310 to 2750) 9.51 (1.93 to 12.76) 48
16 ––5.5 –– 5.5
(0.8 to 6.9) 2400 (310 to 3000) 11.13 (1.93 to 13.91) 48
2 units 10 10 –3.60 3.60 –7.2
(1.5 to 10.0) 2050 (320 to 3200) 9.51 (1.94 to 14.84) 48
13 10 –4.22 3.38 –7.6
(1.5 to 10.1) 2240 (320 to 3210) 10.39 (1.94 to 14.89) 48
16 10 –4.57 3.33 –7.9
(1.5 to 10.1) 2380 (320 to 3230) 11.04 (1.94 to 14.98) 48
13 13 –3.95 3.95 –7.9
(1.5 to 10.1) 2380 (320 to 3230) 11.04 (1.94 to 14.98) 48
16 13 –4.35 3.95 –8.3
(1.5 to 10.2) 2560 (320 to 3240) 11.87 (1.94 to 15.03) 48
16 16 –4.30 4.30 –8.6
(1.5 to 10.2) 2700 (320 to 3250) 12.52 (1.94 to 15.07) 48
3 units 10 10 10 2.87 2.87 2.87 8.6
(2.0 to 10.4) 2300 (380 to 2750) 10.67 (2.16 to 12.76) 48
13 10 10 3.35 2.68 2.68 8.7
(2.0 to 10.5) 2360 (380 to 2760) 10.95 (2.16 to 12.80) 48
16 10 10 3.59 2.61 2.61 8.8
(2.0 to 10.6) 2430 (380 to 2780) 11.27 (2.16 to 12.89) 48
13 13 10 3.14 3.14 2.51 8.8
(2.0 to 10.6) 2430 (380 to 2780) 11.27 (2.16 to 12.89) 48
16 13 10 3.34 3.03 2.43 8.8
(2.0 to 10.6) 2430 (380 to 2780) 11.27 (2.16 to 12.89) 48
13 13 13 2.93 2.93 2.93 8.8
(2.0 to 10.6) 2430 (380 to 2780) 11.27 (2.16 to 12.89) 48
16 16 10 3.26 3.26 2.37 8.9
(2.0 to 10.7) 2490 (380 to 2790) 11.55 (2.16 to 12.94) 48
16 13 13 3.16 2.87 2.87 8.9
(2.0 to 10.7) 2490 (380 to 2790) 11.55 (2.16 to 12.94) 48
16 16 13 3.09 3.09 2.81 9.0
(2.0 to 10.8) 2550 (380 to 2800) 11.83 (2.16 to 12.99) 48

–18 –
Outdoor Unit : RAS-3M26YAV-E
<Heating/230V>
•The above specification values are those under the conditions that the indoor DB/WB=27/19°C and the outdoor DB/
WB=35/–°C.
•Indoor unit 10 : RAS-M10YKV-E, 13 : RAS-M13YKV-E, 16 : RAS-M16YKV-E
Indoor unit Unit capacity (kW)Power
su
pp
l
y
(V)
O
p
eratin
g
status ABCABC
Heating
capacity
(kW)
Power
consum
p
tion
(W)
Operating
current
(A)
Outdoor
noise
(dB)
230 1 unit 10 ––4.0 –– 4.0
(0.8 to 5.2) 1500 (300 to 1980) 6.65 (1.79 to 8.78) 48
13 ––5.0 –– 5.0
(0.8 to 6.5) 2050 (310 to 2750) 9.09 (1.85 to 12.20) 48
16 ––5.5 –– 5.5
(0.8 to 6.9) 2400 (310 to 3000) 10.65 (1.85 to 13.31) 48
2 units 10 10 –3.60 3.60 –7.2
(1.5 to 10.0) 2050 (320 to 3200) 9.09 (1.86 to 14.20) 48
13 10 –4.22 3.38 –7.6
(1.5 to 10.1) 2240 (320 to 3210) 9.94 (1.86 to 14.24) 48
16 10 –4.57 3.33 –7.9
(1.5 to 10.1) 2380 (320 to 3230) 10.56 (1.86 to 14.33) 48
13 13 –3.95 3.95 –7.9
(1.5 to 10.1) 2380 (320 to 3230) 10.56 (1.86 to 14.33) 48
16 13 –4.35 3.95 –8.3
(1.5 to 10.2) 2560 (320 to 3240) 11.36 (1.86 to 14.37) 48
16 16 –4.30 4.30 –8.6
(1.5 to 10.2) 2700 (320 to 3250) 11.98 (1.86 to 14.42) 48
3 units 10 10 10 2.87 2.87 2.87 8.6
(2.0 to 10.4) 2300 (380 to 2750) 10.20 (2.07 to 12.20) 48
13 10 10 3.35 2.68 2.68 8.7
(2.0 to 10.5) 2360 (380 to 2760) 10.47 (2.07 to 12.24) 48
16 10 10 3.59 2.61 2.61 8.8
(2.0 to 10.6) 2430 (380 to 2780) 10.78 (2.07 to 12.33) 48
13 13 10 3.14 3.14 2.51 8.8
(2.0 to 10.6) 2430 (380 to 2780) 10.78 (2.07 to 12.33) 48
16 13 10 3.34 3.03 2.43 8.8
(2.0 to 10.6) 2430 (380 to 2780) 10.78 (2.07 to 12.33) 48
13 13 13 2.93 2.93 2.93 8.8
(2.0 to 10.6) 2430 (380 to 2780) 10.78 (2.07 to 12.33) 48
16 16 10 3.26 3.26 2.37 8.9
(2.0 to 10.7) 2490 (380 to 2790) 11.05 (2.07 to 12.38) 48
16 13 13 3.16 2.87 2.87 8.9
(2.0 to 10.7) 2490 (380 to 2790) 11.05 (2.07 to 12.38) 48
16 16 13 3.09 3.09 2.81 9.0
(2.0 to 10.8) 2550 (380 to 2800) 11.31 (2.07 to 12.42) 48

–19 –
Outdoor Unit : RAS-3M26YAV-E
<Heating/240V>
•The above specification values are those under the conditions that the indoor DB/WB=27/19°C and the outdoor DB/
WB=35/–°C.
•Indoor unit 10 : RAS-M10YKV-E, 13 : RAS-M13YKV-E, 16 : RAS-M16YKV-E
Indoor unit Unit capacity (kW)Power
su
pp
l
y
(V)
O
p
eratin
g
status ABCABC
Heating
capacity
(kW)
Power
consumption
(W)
Operating
current
(A)
Outdoor
noise
(dB)
240 1 unit 10 ––4.0 –– 4.0
(0.8 to 5.2) 1500 (300 to 1980) 6.38 (1.71 to 8.42) 48
13 ––5.0 –– 5.0
(0.8 to 6.5) 2050 (310 to 2750) 8.72 (1.77 to 11.69) 48
16 ––5.5 –– 5.5
(0.8 to 6.9) 2400 (310 to 3000) 10.20 (1.77 to 12.76) 48
2 units 10 10 –3.60 3.60 –7.2
(1.5 to 10.0) 2050 (320 to 3200) 8.72 (1.78 to 13.61) 48
13 10 –4.22 3.38 –7.6
(1.5 to 10.1) 2240 (320 to 3210) 9.52 (1.78 to 13.65) 48
16 10 –4.57 3.33 –7.9
(1.5 to 10.1) 2380 (320 to 3230) 10.12 (1.78 to 13.73) 48
13 13 –3.95 3.95 –7.9
(1.5 to 10.1) 2380 (320 to 3230) 10.12 (1.78 to 13.73) 48
16 13 –4.35 3.95 –8.3
(1.5 to 10.2) 2560 (320 to 3240) 10.88 (1.78 to 13.78) 48
16 16 –4.30 4.30 –8.6
(1.5 to 10.2) 2700 (320 to 3250) 11.48 (1.78 to 13.82) 48
3 units 10 10 10 2.87 2.87 2.87 8.6
(2.0 to 10.4) 2300 (380 to 2750) 9.78 (1.98 to 11.69) 48
13 10 10 3.35 2.68 2.68 8.7
(2.0 to 10.5) 2360 (380 to 2760) 10.03 (1.98 to 11.73) 48
16 10 10 3.59 2.61 2.61 8.8
(2.0 to 10.6) 2430 (380 to 2780) 10.33 (1.98 to 11.82) 48
13 13 10 3.14 3.14 2.51 8.8
(2.0 to 10.6) 2430 (380 to 2780) 10.33 (1.98 to 11.82) 48
16 13 10 3.34 3.03 2.43 8.8
(2.0 to 10.6) 2430 (380 to 2780) 10.33 (1.98 to 11.82) 48
13 13 13 2.93 2.93 2.93 8.8
(2.0 to 10.6) 2430 (380 to 2780) 10.33 (1.98 to 11.82) 48
16 16 10 3.26 3.26 2.37 8.9
(2.0 to 10.7) 2490 (380 to 2790) 10.59 (1.98 to 11.86) 48
16 13 13 3.16 2.87 2.87 8.9
(2.0 to 10.7) 2490 (380 to 2790) 10.59 (1.98 to 11.86) 48
16 16 13 3.09 3.09 2.81 9.0
(2.0 to 10.8) 2550 (380 to 2800) 10.84 (1.98 to 11.90) 48

–20 –
1-2-1. Operation Characteristic Curve
<Cooling> <Heating>
1-2-3. Capacity Variation Ratio According to Pipe Length
1-2-2. Capacity Variation Ratio According to Outdoor Temperature
16
14
12
10
8
6
4
2
0010 20 30 40 50 60 70 80
Inverter output frequency (rps)
Current (A)
•Conditions
Indoor : DB27˚C/WB19˚C
Outdoor : DB35˚C
Air flow : High
Pipe length: 5m x 4
4 units operating 240V
230V
220V
14
12
10
8
6
4
2
0010 10020 30 40 50 60 70 80 90
Inverter output frequency (rps)
Current (A)
• Conditions
Indoor : DB20˚C
Outdoor : DB7˚C / WB6˚C
Air flow : High
Pipe length: 5m x 4
4 units operating 240V
230V
220V
110
105
100
95
90
85
80010 20 30 40 50 60 70 80
Total pipe length (m)
Coolimg capacity ratio (%)
• Conditions
Indoor : DB27˚C/WB19˚C
Outdoor : DB35˚C
Indoor air flow: High
4 units operating
Standard pipe length 20m
110
105
100
95
90
85
80010 20 30 40 50 60 70 80
Total pipe length (m)
Heating capacity ratio (%)
• Conditions
Indoor : DB20˚C
Outdoor : DB7˚C/WB6˚C
Indoor air flow: High
4 units operating
Standard pipe length 20m
50
60
70
80
90
100
110
32 33 34 35 36 37 38 39 40 41 42 43 44
Outdoor temp. (˚C)
Cooling capacity ratio (%)
• Conditions
Indoor : DB27˚C/WB19˚C
Indoor air flow :High
Pipe length : 5m x 4
4 units operating
Current limited start
50
60
70
80
90
100
110
-
10 -9-8-7-6-5-4-3-2-1012345678910
Outdoor temp. (˚C)
Heating capacity ratio (%)
• Conditions
Indoor : DB20˚C
Air flow : High
Pipe length : 5m x 4
4 units operating
