AIR CONDITIONER (SPLIT TYPE)
Installation Manual
Drain Pump Kit
Model name :
TCB-DP22CUL
Installation Manual 2
Air Conditioner (Split type)
Manuel D’installation 12
Climatiseur (Type split)
English
Français

2
Drain Pump Kit Installation Manual
Please read this Installation Manual carefully before installing the Air Conditioner.
• This Manual describes the installation method of the DRAIN PUMP KIT.
• For installation of the outdoor unit, follow the Installation Manual attached to the outdoor unit.
WARNING
For this Drain Pump Kit, please use the Elbow Piping Kit (MODEL: TCB-KP12CUL, TCB-KP22CUL) sold separately.
If using a piping kit procured locally, it may cause a water leak or so on.
ADOPTION OF NEW REFRIGERANT
This Air Conditioner is a new type which adopts a new refrigerant HFC (R410A) instead of the conventional
refrigerant R22 in order to prevent destruction of the ozone layer.
English-1
CONTENTS
Accessory parts and Parts to be procured locally ...........................................3
1PRECAUTIONS FOR SAFETY ....................................................................4
2PREPARATION FOR INSTALLATION OF DRAIN PUMP KIT ....................5
3INSTALLATION PROCEDURE OF DRAIN PUMP KIT ...............................6
4DRAIN PIPING WORK ...............................................................................10
5THERMAL INSULATOR FOR CEILING PLATE ........................................10
6CABLE CONNECTION ..............................................................................11
7TEST RUN ..................................................................................................11

3
Drain Pump Kit Installation Manual
Accessory parts and Parts to be procured locally
rAccessory parts
rSpecification
Part name
Drain Pump Kit
Drain Pump Kit fixture
Drain hose
Thermal insulating pipe
Installation Manual
Drain hose fixing band
Thermal insulator
for drain connecting section
Thermal insulator
of ceiling panel
Screw
Banding band
Q’ty
1
1
1
1
1
2
2
1
4
2
Shape
This manual
Usage
—
For mounting Drain Pump Kit
For connecting vinyl chloride pipe of Dain Pump kit
For thermal insulation of drain hose
Be sure to hand to users.
For fixing drain hose
For thermal insulation of drain hose connecting section
For sealing upper piping hole of indoor unit
For fixing Drain Pump Kit
For fixing fixture of Drain Pump Kit
For fixing wires
Drain Pump Kit model name
TCB-DP22CUL
Height of drain up
23.6” (600mm) or lower from top face of the set
English-2
En

4
Drain Pump Kit Installation Manual
1PRECAUTIONS FOR SAFETY
• Ensure that all Local, National and International regulations are satisfied.
• Read this “PRECAUTIONS FOR SAFETY” carefully before Installation.
• The precautions described below include the important items regarding safety. Observe them without fail.
• After the installation work, perform a trial operation to check for any problem.
Follow the Owner’s Manual to explain how to use and maintain the unit to the customer.
• Turn off the main power supply switch (or breaker) before the unit maintenance.
• Ask the customer to keep the Installation Manual together with the Owner’s Manual.
WARNINGS
• Ask an authorized dealer or qualified installation professional to install/maintain the air
conditioner.
Inappropriate installation may result in water leakage, electric shock or fire.
• Turn off the main power supply switch or breaker before attempting any electrical work.
Make sure all power switches are off. Failure to do so may cause electric shock.
• Connect the connecting cable correctly.
If the connecting cable is connected in a wrong way, electric parts may be damaged.
• When moving the air conditioner for the installation into another place, be very careful not to
enter any gaseous matter other than the specified refrigerant into the refrigeration cycle.
If air or any other gas is mixed in the refrigerant, the gas pressure in the refrigeration cycle becomes abnormally
high and it resultingly causes pipe burst and injuries on persons.
• Do not modify this unit by removing any of the safety guards or by by-passing any of the safety
interlock switches.
• Exposure of unit to water or other moisture before installation may cause a short-circuit of
electrical parts.
Do not store it in a wet basement or expose to rain or water.
• After unpacking the unit, examine it carefully if there are possible damage.
• To avoid personal injury (with sharp edges), be careful when handling parts.
• Perform installation work properly according to the Installation Manual.
Inappropriate installation may result in water leakage, electric shock or fire.
• Electrical work must be performed by a qualified electrician in accordance with the Installation
Manual.
An insufficient power supply capacity or inappropriate installation may cause fire.
English-3

5
Drain Pump Kit Installation Manual
8.5” (216)
4.3”
(110)
1.1” (27.5)
3”
(76)
2”
(52)
1.5”
(39)
2.1”
(53)
12.6” (320) 6.7” (170)
2.8”
(70)
2”
(50)
5.1”
(130)
5.2”
(130)
4.7”
(120)
1.1” (27.5)
7.9” (200)
12.6” (320) 6.7” (170)
6.3” (160)
3.9” (100)
17.7” (450)
17.7” (450)
2.2” (55) 3.8” (97)
6.3” (160)
12.7” (323)
6.1” (155)
3.5” (90)
4.3” (109)
1.1” (27.5)
Hole for remote controller wires
(Ø1.6” (40) knockout)
Conduit hole
(Hole for power supply cable,
knockout)
Knockout hole for upper
piping of indoor unit
Opening hole on ceiling
(Ø3.9” (100), 2 positions)
Check port
Drain pipe
Refrigerant pipe
at liquid side
(Elbow piping kit)
Refrigerant pipe
at gas side
(Elbow piping kit)
Flexible hose of drain pipe
(Attached to Drain Pump Kit)
Refrigerant pipe
(Elbow piping kit)
Drain Pump Kit
2PREPARATION FOR INSTALLATION
OF DRAIN PUMP KIT
nCautions on installation
• In the installation work of the Drain Pump Kit, the pipe cannot be drawn out from other side than the upper side.
• Apply thermal insulation for all the drain pipes.
• Open two opening holes (Ø3.9” (100mm), 2 positions) on the ceiling surface to be installed in order to pass
refrigerant pipe and drain pipe.
• Set a 17.7” (450mm-square) check port on the ceiling surface to be installed.
Knockout positions at the upper part
of indoor unit (Unit: in (mm))
Opening hole positions on ceiling
(Unit: in (mm))
Refrigerant pipe and drain pipe positions (Unit: in (mm))
English-4

6
Drain Pump Kit Installation Manual
3INSTALLATION PROCEDURE
OF DRAIN PUMP KIT
nBefore installation
1. Removal of suction grille
Slide the suction grille fixing knobs
(2 positions) toward the arrow direction, and
then open the suction grille.
Under the condition of suction grille opened,
push the hook section of hinges (2 positions) at
the rear side, and then pull out the suction
grille.
Suction grille
Pull out suction grille
while pushing hook.
Suction grille
fixing knob
Hinge
Slide
English-5
2. Wire guard open
Remove the screws (2 pcs.) which are fixing
the wire guard. Using clamps mounted to the
wire guard, hang up the wire guard.
• Do not remove the fixing screws of clamps of
the indoor unit.
NOTE
After installation of the Drain Pump Kit, be sure to
mount the wire guard as original.
Do maintenance work after removing the screws
which are fixing the wire guard and hanging up the
wire guard with the clamps.
3. Removal of side panel
After removing the side panel fixing screws
(1 each at right and left), slide the side panel
forward and then remove it.
Clamps
Screws
Side forward
Removing the side
panel fixing screws

7
Drain Pump Kit Installation Manual
uTightening connection
CAUTION
• Do not apply excessive torque.
Otherwise, the nut may crack depending on the
conditions.
Unit : ft lbs (N•m)
• Tightening torque of flare pipe connections
Pressure of R410A is higher than that of R22.
(Approx. 1.6 times) Therefore, using a torque
wrench, tighten the flare pipe connecting sections
which connect the indoor and outdoor units of the
specified tightening torque.
Incorrect connections may cause not only a gas
leak, but also a trouble of the refrigeration cycle.
Align the centers of the connecting pipes and tighten
the flare nut as far as possible with your fingers.
Then tighten the nut with a spanner and torque
wrench as shown in the figure.
Tightening torque
10.3” to 13.3” (14 to 18)
24.3” to 31.0” (33 to 42)
36.9” to 45.7” (50 to 62)
50.2” to 60.5” (68 to 82)
Outer diam. of copper pipe
1/4” ( 6.4 mm) (diam.)
3/8” ( 9.5 mm) (diam.)
1/2” (12.7 mm) (diam.)
5/8” (15.9 mm) (diam.)
Flare at
indoor
unit side
Flare at
outdoor
unit side
Half union Flare nut
Externally
threaded side
Internally
threaded side
Use a wrench to secure. Use a torque wrench to tighten.
English-6
nKnockout hole
Open the draw-out port (Knockout hole) at upper
side.
nConnection of ELBOW PIPING KIT
Connect “ELBOW PIPING KIT” sold separately to
the indoor unit.
Draw-out port
at upper side
(Knockout hole)
Elbow type pipe
at gas side
Elbow type pipe
at liquid side Draw-out port
at upper side

8
Drain Pump Kit Installation Manual
nHow to install Drain Pump Kit
1. Mount the Drain Pump Kit fixture to the rear
side inside of the indoor unit. (1 screw)
2. Hang the temporary hanging hook of the Drain
Pump Kit to the side slit of the indoor unit from
inner side. Screw the Drain Pump Kit to the
indoor unit. (3 screws: Ceiling surface, side
face, and Drain Pump Kit fixture)
English-7
nThermal insulating process
Apply thermal insulation to pipes at liquid and gas
sides separately.
• Be sure to use thermal insulator with heat
resisting temperature 248°F (120°C) or more for
pipes at gas side.
• Using thermal insulators attached to the indoor
unit and Elbow Piping Kit, apply thermal
insulating process surely to pipe connecting
section without clearance.
• When fixing insulator to the elbow type pipe
temporarily with the banding band attached to
the Elbow Piping Kit, wrap the insulator using
vinyl tape so that there is no clearance.
CAUTION
Apply thermal insulating process surely so that no
exposure cannot be found up to the end of the
pipe connecting section of the indoor unit.
(If a part of the pipe is exposed, leakage may be
caused.)
For the connection of refrigerant pipe and thermal
insulating process after hanging down the indoor unit,
refer to the Installation Manual attached to the indoor
unit.
Fix with vinyl tape. Set the notch upward.
Attached thermal insulating pipeBanding band
Elbow Piping Kit side
Screwing of Drain Pump Kit fixture
Drain Pump Kit fixture
Temporary hanging hook of Drain Pump Kit
to the side slit of indoor unit
Screwing (To side face)
Drain Pump Kit
Drain Pump Kit
Screwing (To Drain Pump Kit fixture)
Screwing
(To ceiling surface)

9
Drain Pump Kit Installation Manual
nConnection of drain hose at
indoor unit side
1. Insert the drain hose attached to the indoor unit
into the drain pipe connecting port of the indoor
unit’s and into the drain pipe connecting port of
the Drain Pump Kit’s drain pan.
In this time, insert the drain hose until it strikes
on the connecting port of the drain pipe.
2. Align the hose band attached to the indoor unit
with the end of pipe connecting port, and then
tighten it firmly.
3. Cut off to 6.3” × 7.9” (160mm × 200mm) the
thermal insulator 7.9” × 7.9” (200mm × 200mm)
for drain hose attached to the indoor unit.
Using it, lap the connecting section of drain
pan and drain hose without clearance, and
then tighten it with two banding bands attached
to the indoor unit so that thermal insulator does
not open.
nConnection of drain hose at
Drain Pump Kit side
1. Insert the drain hose attached to the Drain Pump
Kit into the connecting port of drain pipes at the
upper side of the Drain Pump Kit.
2. Align the hose band attached to the Drain Pump
Kit with the end of pipe connecting port, and
then tighten it firmly.
3. Fit the drain connecting thermal insulator
attached to the Drain Pump Kit to sheet metal at
the upper side of the Drain Pump Kit, and then
lap it covering the drain hose without clearance.
Attached drain hose
Indoor unit
drain pan
Check the soft
hose is pushed
in to the end of
drain pan.
Drain Pump Kit
drain pan
Align the attached hose bands with the end
of hose and then tighten it while turning the
knob to the side.
Lap insulator over the
connecting section of drain
pan and drain hose.
Drain hose
Banding
band
Hose band
Thermal insulator attached to indoor unit
(Cut to 6.3” × 7.9” (160mm × 200mm))
Lap the one side of
the attached thermal
insulator on the other
side at the upper side.
12.7” (323mm)
Drain hose
(Attached to Drain Pump Kit)
Thermal insulator for drain
connecting section
(Attached to Drain Pump Kit)
Drain pipe
connecting port
Fit the drain connecting thermal insulator to sheet
metal at the upper side of the Drain Pump Kit,
and then lap it without clearance.
23.6” (600mm) or less
from the top face of indoor unit
Hard vinyl chloride
pipe VP-25
(Procured locally) Thermal insulating pipe
(Attached to Drain Pump Kit)
Thermal insulator for drain
connecting section
(Attached to Drain Pump Kit)
Hose band
(Attached to Drain Pump Kit)
Drain hose
(Attached to Drain Pump Kit)
Fit the thermal insulating pipe
to sheet metal at the upper side
of the Drain Pump Kit, and then
lap it without clearance.
∗When using the drain hose within 5.9” (150mm) or
less from the top face of the indoor unit, do not use
an elbow but connect the attached drain hose
directly, which was bent (with larger round as
possible as you can).
English-8

10
Drain Pump Kit Installation Manual
4DRAIN PIPING WORK
CAUTION
• Following the Installation Manual, perform the
drain piping work so that water is properly drained,
and apply a heat insulation so as not to cause a dew.
Inappropriate piping work may result in water
leakage in the room and wet of furniture.
nPiping/Heat insulating material
Require the following materials for piping and
heat insulating at site.
Piping
Heat insulator
Hard vinyl chloride pipe VP25
(Outer dia. : Ø1.3” (Ø32mm))
Foam polyethylene :
Thickness 0.4” (10mm) or more
REQUIREMENT
• Be sure to perform heat insulation of the drain pipes of the indoor unit.
• Never forget to perform heat insulation of the connecting part with the indoor unit.
An incomplete heat insulation causes dewing.
• Set the drain pipe with downward slope (1/100 or more), and do not make
swelling or trap on the piping. It may cause an abnormal sound.
• For length of the traversing drain pipe, restrict to 65’ 7” (20m) or less.
In case of a long pipe, provide support brackets
with interval of 4’ 11” to 6’ 7” (1.5m – 2m) in
order to prevent waving.
• Set the collective piping as shown in the right figure.
• Be sure not to apply force to the connecting part of the drain pipe.
• The hard vinyl-chloride pipe cannot be directly connected to the drain pipe connecting port of the indoor unit.
For connection with the drain pipe connecting port, be sure to use/fix the attached flexible hose with the hose
band, otherwise a damage or water leak is caused on the drain pipe connecting port.
Adhesive inhibited :
Use the attached flexible hose and hose band for connecting the drain hose to the drain piping connecting part.
If applying the adhesive, socket will be damaged and cause water leakage.
5THERMAL INSULATOR FOR
CEILING PLATE
Drain pipe thermal
insulator pipe
Refrigerant pipe
Ceiling thermal insulator
(Attached to Drain Pump Kit)
Trap
Arched
shape
Support
bracket
1/100 or more
downward
Heat
insulator
4’ 11” to 6’ 7” (1.5m – 2m)
NO
GOOD
As long as possible 3.9” (100mm)
VP30 or more Downward slope
1/100 or more
VP25
VP25
VP25
Extended
ventilating pipe
Adhere the ceiling thermal insulator attached to the
Drain Pump Kit to positions of the refrigerant pipe
and the drain pipe.
nConnection of drain pipe
• Connect hard vinyl chloride pipe (procured locally)
to the attached drain hose which has been installed.
English-9

11
Drain Pump Kit Installation Manual
6CABLE CONNECTION
1. Loosen the mounting screws (2 positions) of the cover of the electric parts box, and then remove the cover.
2. In the Drain Pump Kit, connect the connector (Blue 3P) for drain pump to P.C. board CN68 (Blue 3P) of the
indoor unit, and the connector (Red 3P) for float switch to P.C. board CN34 (Red 3P) of the indoor unit
respectively.
7TEST RUN
nCheck the draining
In the test run, check that water drain is properly performed and water does not leak from the connecting part
of the pipes. Be sure to check draining also when installed in heating period.
Using a pitcher or hose, pour water 0.3 galoon (1200cc) into the discharge port before installation of the ceiling
panel. Pour water gradually so that water does not spread on the motor of the drain pump.
Single phase 208/230V
White
Black
CN34
(RED)
Black
Red
Pull out connector CN34 (Red) from P.C. board.
1 2
Pump for oil-heater
Bucket
English-10
Electric parts box 2 screws
CN68 (Blue 3P)
P.C. board
CN34 (Red 3P)
(Connect white removing 3P connector for short-circuit.)
Pass connecting cable through the slot
at this side of the electric parts box.
(Fix the wires with banding band.)
• After the electric work has finished, pour water during
COOL mode operation.
• If the electric work has not yet finished, pull out the float
switch connector (CN34: Red) from the electric parts box,
and check draining by plugging the single phase 208/
230V power to the terminal blocks Qand R.
If doing so, the drain pump motor operates.
• Test water drain while checking the operation sound of
the drain pump motor.
(If the operation sound changes from continuous sound
to intermittent sound, water is normally drained.)
After the check, the drain pump motor runs,
connecting the float switch connector.
(In case of check by pulling out the float switch
connector, be sure to return the connector to the
original position.)
In this time, remove 3P connector (Red 3P)
for short-circuit of CN34 (Red 3P).
3. Using one of two banding bands attached to
the electric parts box, fix the wires.
∗Use the other banding band to bind the
wires so that they are not caught in the
cover of electric parts box.

EH99866301
