Toshiba TOSVERT VF-PS1 Parts list manual

E6581540
TOSVERT VF-PS1 series
Metasys®N2 option unit Function Manual
MTS001Z
NOTICE
1. Make sure that this instruction manual is delivered to the end user of Metasys®N2
option unit.
2. Read this manual before installing or operating the Metasys®N2 option unit. Keep
it in a safe place for reference.
3. All information contained in this manual are subject to change without notice.
Please confirm the latest information on our web site.
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

E6581540
- 1 -
Table of Contents
1. INTRODUCTION.........................................................................................................................................2
2. NAMES AND FUNCTIONS OF MAIN PARTS...........................................................................................3
2.1. Outline view..........................................................................................................................................3
2.2. Metasys®N2 Connector......................................................................................................................3
2.3. LED indicator........................................................................................................................................4
2.4. Setting a station address......................................................................................................................5
3. PARAMETERS ...........................................................................................................................................9
3.1. Communication parameters.................................................................................................................9
3.2. f832: Communication Loss Action Time Setting................................................................................10
3.3. f851: Communication Loss Action Setting.........................................................................................10
3.4. f852: Preset speed operation selection .............................................................................................10
4. FUNCTIONAL PROFILE ..........................................................................................................................11
4.1. Synch Time Command.......................................................................................................................12
4.2. Status Update Request......................................................................................................................12
4.3. Analog Input Object............................................................................................................................13
4.3.1. Analog Input Attribute .................................................................................................................14
4.3.2. Analog Input COS Works............................................................................................................15
4.4. Binary Input Object.............................................................................................................................16
4.4.1. Binary Input Attribute ..................................................................................................................17
4.5. Binary Input COS Works....................................................................................................................17
4.6. Analog Output Object.........................................................................................................................18
4.6.1. Analog Output Attribute...............................................................................................................19
4.6.2. Analog Output COS Works.........................................................................................................19
4.7. Binary Output Object..........................................................................................................................20
4.7.1. Binary Output Attribute................................................................................................................21
4.7.2. Binary Output COS Works..........................................................................................................21
4.8. Error Message Format.......................................................................................................................22
4.9. VF-PS1 Parameter access ................................................................................................................23
5. VF-PS1 TRIP CODE.................................................................................................................................24
6. SPECIFICATIONS....................................................................................................................................26
- 1/26 -
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

E6581540
- 2 -
1.Introduction
Thank you for purchasing the Metasys®N2 option unit (MTS001Z) for VF-PS1 series
inverter.
Before using Metasys®N2 option unit, carefully read this function manual in order to
completely and correctly utilize its excellent performance.
After reading this function manual, please keep it handy for future reference.
For details of its general handling, see an instruction manual attached with the option
unit.
・TOSVERT VF-PS1 Instruction Manual ...................................E6581386
・TOSVERT VF-PS1 RS485 Communication Manual...............E6581413
・MTS001Z Instruction Manual..................................................E6581539
* Metasys®N2 is a registered trademark of Johnson Controls Inc.
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

E6581540
- 3 -
2.Names and functions of main parts
2.1. Outline view


2.2. Metasys®N2 Connector
Terminal
symbol Function Electrical specifications Internal circuits
B Communication signal (+)
A Communication signal (-)
GND Signal common
SCR
Metasys®N2
communication signal
EIA-485 Shield terminal.
B
A
GND
SCR
47k
47k
4.7k
4.7k
120
SW4
TERM



Don’t use
these connector or switches
Connector to the inverter
Metasys®N2 Connector（refer to 2.2）
(Terminal connector : MSTB 2,5/4-STF-5.08)
: PHOENIX CONTACT
Termination
Resistor SW
Panel mounting tabs
Earth Plate
Metasys®N2 LED indicato
r
(refer to 2.3)
Station address switch
(refer to 2.4)
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

E6581540
- 4 -
2.3. LED indicator
The option has two LEDs. Those function are below table.
Table 1 LED Behavior
State LEDs Comment
A COM LED: OFF
ERR LED: Flashing 5 times in 1 second Metasys®N2 failure.
B COM LED: OFF
ERR LED: 3 times in 2 sec, Off for 1 sec Communication loss detected. Confirm the network condition and connection of the cable.
C COM LED: ON
ERR LED: OFF 0.5 sec, ON 0.5 sec
Invalid configuration detected.
Note: When inverter occurred in e‑23 or e‑24,
the LED becomes this state.
D COM LED: Flashing
ERR LED: - Valid message received for this node
E COM LED: -
ERR LED: Flashing Invalid message received (any node)
F COM LED: OFF
ERR LED: OFF
No communication
Confirm the network condition and connection
of the cable.
COM
(Green)
ERR
(Red)
2s
OFF
1s
B D
OFF
E
OFF
1s
ON
C
1s
OFF
A F
OFF
OFF
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

E6581540
- 5 -
2.4. Setting a station address
The DIP switch on the circuit board of the option is used to set a station address.
Each DIP switch is ON when it is flipped to the lower position. By default, it is
factory-configured to 1.
The station address must be unique and not match any other device on the network.
SW
ID 1 2 3 4 5 6 7 8 SW
ID 1 2 3 4 5 6 7 8
0* OFF OFF OFF OFF OFF OFF OFF OFF 32
OFF OFF ON OFF OFF OFF OFF OFF
1 OFF OFF OFF OFF OFF OFF OFF ON 33
OFF OFF ON OFF OFF OFF OFF ON
2 OFF OFF OFF OFF OFF OFF ON OFF 34
OFF OFF ON OFF OFF OFF ON OFF
3 OFF OFF OFF OFF OFF OFF ON ON 35
OFF OFF ON OFF OFF OFF ON ON
4 OFF OFF OFF OFF OFF ON OFF OFF 36
OFF OFF ON OFF OFF ON OFF OFF
5 OFF OFF OFF OFF OFF ON OFF ON 37
OFF OFF ON OFF OFF ON OFF ON
6 OFF OFF OFF OFF OFF ON ON OFF 38
OFF OFF ON OFF OFF ON ON OFF
7 OFF OFF OFF OFF OFF ON ON ON 39
OFF OFF ON OFF OFF ON ON ON
8 OFF OFF OFF OFF ON OFF OFF OFF 40
OFF OFF ON OFF ON OFF OFF OFF
9 OFF OFF OFF OFF ON OFF OFF ON 41
OFF OFF ON OFF ON OFF OFF ON
10 OFF OFF OFF OFF ON OFF ON OFF 42
OFF OFF ON OFF ON OFF ON OFF
11 OFF OFF OFF OFF ON OFF ON ON 43
OFF OFF ON OFF ON OFF ON ON
12 OFF OFF OFF OFF ON ON OFF OFF 44
OFF OFF ON OFF ON ON OFF OFF
13 OFF OFF OFF OFF ON ON OFF ON 45
OFF OFF ON OFF ON ON OFF ON
14 OFF OFF OFF OFF ON ON ON OFF 46
OFF OFF ON OFF ON ON ON OFF
15 OFF OFF OFF OFF ON ON ON ON 47
OFF OFF ON OFF ON ON ON ON
16 OFF OFF OFF ON OFF OFF OFF OFF 48
OFF OFF ON ON OFF OFF OFF OFF
17 OFF OFF OFF ON OFF OFF OFF ON 49
OFF OFF ON ON OFF OFF OFF ON
18 OFF OFF OFF ON OFF OFF ON OFF 50
OFF OFF ON ON OFF OFF ON OFF
19 OFF OFF OFF ON OFF OFF ON ON 51
OFF OFF ON ON OFF OFF ON ON
20 OFF OFF OFF ON OFF ON OFF OFF 52
OFF OFF ON ON OFF ON OFF OFF
21 OFF OFF OFF ON OFF ON OFF ON 53
OFF OFF ON ON OFF ON OFF ON
22 OFF OFF OFF ON OFF ON ON OFF 54
OFF OFF ON ON OFF ON ON OFF
23 OFF OFF OFF ON OFF ON ON ON 55
OFF OFF ON ON OFF ON ON ON
24 OFF OFF OFF ON ON OFF OFF OFF 56
OFF OFF ON ON ON OFF OFF OFF
25 OFF OFF OFF ON ON OFF OFF ON 57
OFF OFF ON ON ON OFF OFF ON
26 OFF OFF OFF ON ON OFF ON OFF 58
OFF OFF ON ON ON OFF ON OFF
27 OFF OFF OFF ON ON OFF ON ON 59
OFF OFF ON ON ON OFF ON ON
28 OFF OFF OFF ON ON ON OFF OFF 60
OFF OFF ON ON ON ON OFF OFF
29 OFF OFF OFF ON ON ON OFF ON 61
OFF OFF ON ON ON ON OFF ON
30 OFF OFF OFF ON ON ON ON OFF 62
OFF OFF ON ON ON ON ON OFF
31 OFF OFF OFF ON ON ON ON ON 63
OFF OFF ON ON ON ON ON ON
*“0” must not be set as station address.
1 2 3 4 5 6 7 8
DIP ON
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

E6581540
- 6 -
SW
ID 1 2 3 4 5 6 7 8 SW
ID 1 2 3 4 5 6 7 8
64 OFF ON OFF OFF OFF OFF OFF OFF 96
OFF ON ON OFF OFF OFF OFF OFF
65 OFF ON OFF OFF OFF OFF OFF ON 97
OFF ON ON OFF OFF OFF OFF ON
66 OFF ON OFF OFF OFF OFF ON OFF 98
OFF ON ON OFF OFF OFF ON OFF
67 OFF ON OFF OFF OFF OFF ON ON 99
OFF ON ON OFF OFF OFF ON ON
68 OFF ON OFF OFF OFF ON OFF OFF 100
OFF ON ON OFF OFF ON OFF OFF
69 OFF ON OFF OFF OFF ON OFF ON 101
OFF ON ON OFF OFF ON OFF ON
70 OFF ON OFF OFF OFF ON ON OFF 102
OFF ON ON OFF OFF ON ON OFF
71 OFF ON OFF OFF OFF ON ON ON 103
OFF ON ON OFF OFF ON ON ON
72 OFF ON OFF OFF ON OFF OFF OFF 104
OFF ON ON OFF ON OFF OFF OFF
73 OFF ON OFF OFF ON OFF OFF ON 105
OFF ON ON OFF ON OFF OFF ON
74 OFF ON OFF OFF ON OFF ON OFF 106
OFF ON ON OFF ON OFF ON OFF
75 OFF ON OFF OFF ON OFF ON ON 107
OFF ON ON OFF ON OFF ON ON
76 OFF ON OFF OFF ON ON OFF OFF 108
OFF ON ON OFF ON ON OFF OFF
77 OFF ON OFF OFF ON ON OFF ON 109
OFF ON ON OFF ON ON OFF ON
78 OFF ON OFF OFF ON ON ON OFF 110
OFF ON ON OFF ON ON ON OFF
79 OFF ON OFF OFF ON ON ON ON 111
OFF ON ON OFF ON ON ON ON
80 OFF ON OFF ON OFF OFF OFF OFF 112
OFF ON ON ON OFF OFF OFF OFF
81 OFF ON OFF ON OFF OFF OFF ON 113
OFF ON ON ON OFF OFF OFF ON
82 OFF ON OFF ON OFF OFF ON OFF 114
OFF ON ON ON OFF OFF ON OFF
83 OFF ON OFF ON OFF OFF ON ON 115
OFF ON ON ON OFF OFF ON ON
84 OFF ON OFF ON OFF ON OFF OFF 116
OFF ON ON ON OFF ON OFF OFF
85 OFF ON OFF ON OFF ON OFF ON 117
OFF ON ON ON OFF ON OFF ON
86 OFF ON OFF ON OFF ON ON OFF 118
OFF ON ON ON OFF ON ON OFF
87 OFF ON OFF ON OFF ON ON ON 119
OFF ON ON ON OFF ON ON ON
88 OFF ON OFF ON ON OFF OFF OFF 120
OFF ON ON ON ON OFF OFF OFF
89 OFF ON OFF ON ON OFF OFF ON 121
OFF ON ON ON ON OFF OFF ON
90 OFF ON OFF ON ON OFF ON OFF 122
OFF ON ON ON ON OFF ON OFF
91 OFF ON OFF ON ON OFF ON ON 123
OFF ON ON ON ON OFF ON ON
92 OFF ON OFF ON ON ON OFF OFF 124
OFF ON ON ON ON ON OFF OFF
93 OFF ON OFF ON ON ON OFF ON 125
OFF ON ON ON ON ON OFF ON
94 OFF ON OFF ON ON ON ON OFF 126
OFF ON ON ON ON ON ON OFF
95 OFF ON OFF ON ON ON ON ON 127
OFF ON ON ON ON ON ON ON
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

E6581540
- 7 -
SW
ID 1 2 3 4 5 6 7 8 SW
ID 1 2 3 4 5 6 7 8
128 ON OFF OFF OFF OFF OFF OFF OFF 160
ON OFF ON OFF OFF OFF OFF OFF
129 ON OFF OFF OFF OFF OFF OFF ON 161
ON OFF ON OFF OFF OFF OFF ON
130 ON OFF OFF OFF OFF OFF ON OFF 162
ON OFF ON OFF OFF OFF ON OFF
131 ON OFF OFF OFF OFF OFF ON ON 163
ON OFF ON OFF OFF OFF ON ON
132 ON OFF OFF OFF OFF ON OFF OFF 164
ON OFF ON OFF OFF ON OFF OFF
133 ON OFF OFF OFF OFF ON OFF ON 165
ON OFF ON OFF OFF ON OFF ON
134 ON OFF OFF OFF OFF ON ON OFF 166
ON OFF ON OFF OFF ON ON OFF
135 ON OFF OFF OFF OFF ON ON ON 167
ON OFF ON OFF OFF ON ON ON
136 ON OFF OFF OFF ON OFF OFF OFF 168
ON OFF ON OFF ON OFF OFF OFF
137 ON OFF OFF OFF ON OFF OFF ON 169
ON OFF ON OFF ON OFF OFF ON
138 ON OFF OFF OFF ON OFF ON OFF 170
ON OFF ON OFF ON OFF ON OFF
139 ON OFF OFF OFF ON OFF ON ON 171
ON OFF ON OFF ON OFF ON ON
140 ON OFF OFF OFF ON ON OFF OFF 172
ON OFF ON OFF ON ON OFF OFF
141 ON OFF OFF OFF ON ON OFF ON 173
ON OFF ON OFF ON ON OFF ON
142 ON OFF OFF OFF ON ON ON OFF 174
ON OFF ON OFF ON ON ON OFF
143 ON OFF OFF OFF ON ON ON ON 175
ON OFF ON OFF ON ON ON ON
144 ON OFF OFF ON OFF OFF OFF OFF 176
ON OFF ON ON OFF OFF OFF OFF
145 ON OFF OFF ON OFF OFF OFF ON 177
ON OFF ON ON OFF OFF OFF ON
146 ON OFF OFF ON OFF OFF ON OFF 178
ON OFF ON ON OFF OFF ON OFF
147 ON OFF OFF ON OFF OFF ON ON 179
ON OFF ON ON OFF OFF ON ON
148 ON OFF OFF ON OFF ON OFF OFF 180
ON OFF ON ON OFF ON OFF OFF
149 ON OFF OFF ON OFF ON OFF ON 181
ON OFF ON ON OFF ON OFF ON
150 ON OFF OFF ON OFF ON ON OFF 182
ON OFF ON ON OFF ON ON OFF
151 ON OFF OFF ON OFF ON ON ON 183
ON OFF ON ON OFF ON ON ON
152 ON OFF OFF ON ON OFF OFF OFF 184
ON OFF ON ON ON OFF OFF OFF
153 ON OFF OFF ON ON OFF OFF ON 185
ON OFF ON ON ON OFF OFF ON
154 ON OFF OFF ON ON OFF ON OFF 186
ON OFF ON ON ON OFF ON OFF
155 ON OFF OFF ON ON OFF ON ON 187
ON OFF ON ON ON OFF ON ON
156 ON OFF OFF ON ON ON OFF OFF 188
ON OFF ON ON ON ON OFF OFF
157 ON OFF OFF ON ON ON OFF ON 189
ON OFF ON ON ON ON OFF ON
158 ON OFF OFF ON ON ON ON OFF 190
ON OFF ON ON ON ON ON OFF
159 ON OFF OFF ON ON ON ON ON 191
ON OFF ON ON ON ON ON ON
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

E6581540
- 8 -
SW
ID 1 2 3 4 5 6 7 8 SW
ID 1 2 3 4 5 6 7 8
192 ON ON OFF OFF OFF OFF OFF OFF 224
ON ON ON OFF OFF OFF OFF OFF
193 ON ON OFF OFF OFF OFF OFF ON 225
ON ON ON OFF OFF OFF OFF ON
194 ON ON OFF OFF OFF OFF ON OFF 226
ON ON ON OFF OFF OFF ON OFF
195 ON ON OFF OFF OFF OFF ON ON 227
ON ON ON OFF OFF OFF ON ON
196 ON ON OFF OFF OFF ON OFF OFF 228
ON ON ON OFF OFF ON OFF OFF
197 ON ON OFF OFF OFF ON OFF ON 229
ON ON ON OFF OFF ON OFF ON
198 ON ON OFF OFF OFF ON ON OFF 230
ON ON ON OFF OFF ON ON OFF
199 ON ON OFF OFF OFF ON ON ON 231
ON ON ON OFF OFF ON ON ON
200 ON ON OFF OFF ON OFF OFF OFF 232
ON ON ON OFF ON OFF OFF OFF
201 ON ON OFF OFF ON OFF OFF ON 233
ON ON ON OFF ON OFF OFF ON
202 ON ON OFF OFF ON OFF ON OFF 234
ON ON ON OFF ON OFF ON OFF
203 ON ON OFF OFF ON OFF ON ON 235
ON ON ON OFF ON OFF ON ON
204 ON ON OFF OFF ON ON OFF OFF 236
ON ON ON OFF ON ON OFF OFF
205 ON ON OFF OFF ON ON OFF ON 237
ON ON ON OFF ON ON OFF ON
206 ON ON OFF OFF ON ON ON OFF 238
ON ON ON OFF ON ON ON OFF
207 ON ON OFF OFF ON ON ON ON 239
ON ON ON OFF ON ON ON ON
208 ON ON OFF ON OFF OFF OFF OFF 240
ON ON ON ON OFF OFF OFF OFF
209 ON ON OFF ON OFF OFF OFF ON 241
ON ON ON ON OFF OFF OFF ON
210 ON ON OFF ON OFF OFF ON OFF 242
ON ON ON ON OFF OFF ON OFF
211 ON ON OFF ON OFF OFF ON ON 243
ON ON ON ON OFF OFF ON ON
212 ON ON OFF ON OFF ON OFF OFF 244
ON ON ON ON OFF ON OFF OFF
213 ON ON OFF ON OFF ON OFF ON 245
ON ON ON ON OFF ON OFF ON
214 ON ON OFF ON OFF ON ON OFF 246
ON ON ON ON OFF ON ON OFF
215 ON ON OFF ON OFF ON ON ON 247
ON ON ON ON OFF ON ON ON
216 ON ON OFF ON ON OFF OFF OFF 248
ON ON ON ON ON OFF OFF OFF
217 ON ON OFF ON ON OFF OFF ON 249
ON ON ON ON ON OFF OFF ON
218 ON ON OFF ON ON OFF ON OFF 250
ON ON ON ON ON OFF ON OFF
219 ON ON OFF ON ON OFF ON ON 251
ON ON ON ON ON OFF ON ON
220 ON ON OFF ON ON ON OFF OFF 252
ON ON ON ON ON ON OFF OFF
221 ON ON OFF ON ON ON OFF ON 253
ON ON ON ON ON ON OFF ON
222 ON ON OFF ON ON ON ON OFF 254
ON ON ON ON ON ON ON OFF
223 ON ON OFF ON ON ON ON ON 255
ON ON ON ON ON ON ON ON
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

E6581540
- 9 -
3.Parameters
3.1. Communication parameters
Set up the inverter parameters as follows. To update, reset the power of inverter. If these
parameters are not set to correct value, this unit can not work normally.
Table 2 LED Behavior
Title Function Description Value
f832 Network Time-Out 0: No action, 1 - 100s *
Unit: 0.1 sec (Setting range: 1 - 1000) 0
f851 Operation
at communication error
by disconnection
0: Inverter stop, communication command,
frequency mode open (by cmod, fmod)
1: None (continued operation)
2: Deceleration stop
3: Coast stop
4: Network error (err8 trip)
0
f852 Preset speed operation
selection 0: None 1 - 15: Preset speed operation 0
f853 Communication option
station address monitor
(Read Only) Station address (setup by switch) monitor 1 - 255
Network option
reset setting 0: None 1: Reset option board and inverter 0 **
*f832 must be set up by a hexadecimal number.
ex.) 100 sec = 0x3E8
Note) When the parameters are changed, the power must be cycled (or set f899 to 1) to
the VF-PS1 for the changes to take effect.
Note) When cmod or fmod is set to “Communication option input”, VF-PS1 drives
without RSCMDMOD (Binary Output Object - 10) or FRCMDMOD (Binary
Output Object - 11) at each Objects.
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

E6581540
- 10 -
3.2. f832: Communication Loss Action Time Setting
Set the communication loss action time to f832. The network loss action function starts
from receiving the properly frame message. The action of the network communication
loss is set by f851.
3.3. f851: Communication Loss Action Setting
This parameter sets up the VF-PS1 response to a loss of communications with the
Metasys®N2 network.
0: Stop and Communication release
The inverter decelerates the motor to a stop and gives an alarm (the leftmost LED 
flashes). Commands entered through the network are canceled, and the commands
set with parameters cmod and fmod become effective.
When communications are restored, the alarm is turned off.
1: None
The inverter remains in the state where it was when the problem arose, and it gives an
alarm.
2: Deceleration stop
The inverter decelerates the motor to a stop and gives an alarm. Commands
entered through the network are not canceled.
3: Coast stop
The inverter issues a command for a frequency of 0Hz and gives an alarm.
Commands entered through the network are not canceled.
4: Emergency stop
The error message err8 is displayed. Commands entered through the network are not
canceled.
When communications are restored, the inverter is not restored to working order and
the error message err8 does not disappear until the inverter is reset.
5: Preset speed operation command
Refer to Section 3.4.
3.4. f852: Preset speed operation selection
If the communication loss action (parameter f851) is set to 5 (preset speed command), the
VF-PS1 will run at a preset speed as set up by this parameter in the case of a
communication loss (with alarm). Commands entered through the network are not canceled.
For example,
If the inverter is set as described below,
f851 = 5 (preset speed operation command)
f852 = 8 (preset speed operation frequency 8)
f287 (preset speed operation frequency 8) = 10 (10Hz)
Operation is carried out as follows.
Network Operation of the VF-PS1
Normal conditions...........Operates according to commands entered through the network.
↓↓
communications loss ......Operates at 10Hz.
↓↓
Restoration......................Operates according to commands entered through the network.
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

E6581540
- 11 -
4.Functional profile
MTS001Z supports the following commands and objects.
Table 3 Analog Input Objects Table
Command/
Sub command/
Region Function Support Note
0 - Synch Time Command 9
1 - Read Memory Command No support “N01” response
4 - Poll Without Ack Message 9
5 - Poll With Ack Message 9
8 - Warm Start No support “N01” response
0
9 - Status Update Request 9
1 - Read Analog Input Command 9
2 - Read Binary Input Command 9
3 - Read Analog Output Command 9
4 - Read Binary Output Command 9
5 - Read Internal Parameter Command (Float) No support “N01” response
6 - Read Internal Parameter Command (Integer) No support “N01” response
1
7 - Read Internal Parameter Command (Byte) No support “N01” response
1 - Write Analog Input Command 9
2 - Write Binary Input Command 9
3 - Write Analog Output Command 9
4 - Write Binary Output Command 9
5 - Write Internal Parameter Command (Float) No support “N01” response
6 - Write Internal Parameter Command (Integer) No support “N01” response
2
7 - Write Internal Parameter Command (Byte) No support “N01” response
01 Override Analog Input Command No support “N01” response
02 Override Binary Input Command No support “N01” response
03 Override Analog Output Command 9
04 Override Binary Output Command 9
05 Override Internal Parameter Command (Float) No support “N01” response
06 Override Internal Parameter Command (Integer) No support “N01” response
7 2
07 Override Internal Parameter Command (Byte) No support “N01” response
01 Override Analog Input Release Request No support “N01” response
02 Override Binary Input Release Request No support “N01” response
03 Override Analog Output Release Request 9
04 Override Binary Output Release Request 9
05 Override Internal Parameter Release Request No support “N01” response
06 Override Internal Parameter Release Request No support “N01” response
3
07 Override Internal Parameter Release Request No support “N01” response
01 Write Analog Input Attributes Request 9
02 Write Binary Input Attributes Request 9
03 Write Analog Output Attributes Request 9
7
04 Write Binary Output Attributes Request 9
01 Read Analog Input Attributes Request 9
02 Read Binary Input Attributes Request 9
03 Read Analog Output Attributes Request 9
7
8
04 Read Binary Output Attributes Request 9
8 0 - 4 - Upload Request (data base) No support “N01” response
9 0 - 4 - Download Request (data base) No support “N01” response
F - - Identify Device Type Command 9
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

E6581540
- 12 -
4.1. Synch Time Command
MTS001Z responds “A” to Synch Time Command.
A normal response to Synch Time Command.
CHAR1 Start of message................................................ A
CHAR1 End of message................................................. (CR)
4.2. Status Update Request
The form and the version information of the MTS001Z connected inverter are returned.
Response example)
CHAR1 Start of message................................................ A
CHAR16 Model number.................................................... VFPS1-2007PM
CHAR4 Days in service................................................... 0000*
CHAR4 Device status ..................................................... 0108**
CHAR2 Checksum.......................................................... 02
CHAR1 End of message................................................. (CR)
* Days in service increases 1 in 24 hours at the continuation operation.
** VF-PS1 CPU1 version is shown.
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

E6581540
- 13 -
4.3. Analog Input Object
Analog Input Object is used for the output frequency of VF-PS1, and the monitor of
analog input terminal. COS (Change Of State) alarm and warning functions are also
enabled.
Overriding of analog input is not supported (“A” response).
Table 4 Analog Input Objects Table
Object
number Object name Contents Units
0 OUTPUTSPEED Output speed min-1
1 OUTPUTFREQ Output frequency Hz
2 DCBUSVOLT DC bus voltage V
3 OUTPUTVOLT Motor voltage V
4 CURRENT Motor current A
5 TORQUE Motor Torque %
6 POWER Motor Power %
7 DRIVETEMP Drive Thermal State %
8 KWH Input Energy counter kWh
9 RUNTIME Operating time h
10 LASTFLT Error code ** -
11 PREVFLT1 Previous fault 1 ** -
12 PREVFLT2 Previous fault 2 ** -
13 MBOXVALUEREAD Refer to section 4.9. -
14 A1ACT Analog input value 1 (RR/S4) -
15 *- - -
16 AI2ACT Analog input value 2 (VIB) -
17 AI3ACT Analog input value 3（RX）%
18 AI4ACT *** Analog input value 4（AI1）%
19 AI5ACT *** Analog input value 5（AI2）%
20 *- - -
21 *- - -
22 PRCPIDFBCK PID feedback value %
*Reserved (The response is “A”).
** Refer to section 5 about the trip code of VF-PS1.
*** These are enabled with ETB004Z (Expansion IO Card option).
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

E6581540
- 14 -
4.3.1. Analog Input Attribute
Table 5 Analog Input Attribute Table
Attribute Type Contents
1 Byte
Object Configuration
Bit 0 = COS_enabled (1)
Bit 1 = unused
Bit 2 = unused
Bit 3 = alarm_enabled (1)
Bit 4 = warning_enabled (1)
Bit 5 = unused
Bit 6 = unused
Bit 7 = unused
2 Byte
Object Status
Bit 0 = reliable (0) / unreliable (1)
Bit 1 = override active (1)
Bit 2 = out of range - high (1)
Bit 3 = out of range - low (1)
Bit 4 = COS status
Bit 5 = COS status
Bit 6 = COS status
where Bits 4,5,6 are:
000 = normal
001 = trouble (JCI use only)
010 = not available
011 = low warning
100 = low alarm
101 = high warning
110 = high alarm
Bit 7 = unused
3 Float Analog Input Value
4 Float Linear Ranging Parameter 1 (JCI use only)
5 Float Linear Ranging Parameter 2 (JCI use only)
6 Float Linear Ranging Parameter 3 (JCI use only)
7 Float Linear Ranging Parameter 4 (JCI use only)
8 Float Low Alarm Limit
9 Float Low Warning Limit
10 Float High Warning Limit
11 Float High Alarm Limit
12 Float Differential
13 Integer Filter Weight (JCI use only)
14 Float AI_Offset (JCI use only)
*Added shading functions are not supported (The response is “N10”).
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

E6581540
- 15 -
4.3.2. Analog Input COS Works
Analog Input points use 3 bits in the object configuration to determine how COS is
reported. First, no COS is reported when the COS_enabled bit is zero. If the
COS_enabled bit is set then COS will be reported whenever the object status changes.
The alarm_enabled and warning_enabled bit of the object configuration allow the
supervisory system to control the types of COS reported . If the alarm_enabled bit is zero,
then the COS status of the object status would not have a low alarm or high alarm
condition. If the warning_enabled bit is zero, then the COS status of the object status
would not have a low warning or high warning condition. If both bits are zero, then the
COS status would be normal.
COS works of MTS001Z is following.
* Status priority is given to “alarm” when both “alarm” and “warning” are enabled.
Status ON OFF
High Alarm Analog Input Value > High Alarm limit Analog Input Value < High Alarm limit - Differential
High Warning Analog Input Value > High Warning limit Analog Input Value < High Warning limit - Differential
Low Warning Analog Input Value < Low Warning limit Analog Input Value > Low Warning limit + Differential
Low Alarm Analog Input Value < Low Alarm limit Analog Input Value > Low Alarm limit + Differential
High Alarm Limit
Normal Band
High Warning Limit
Low Warning Limit
Low Alarm Limit
Differential
High Alarm
High Warning
Low Warning
Low Alarm
High Warning
High Alarm
Low Warning
Low Alarm
Differential
Differential
Differential
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

E6581540
- 16 -
4.4. Binary Input Object
Binary Input Object is used for the status of VF-PS1, and the monitor of a logic input
terminal. COS alarm and warning functions are also enabled.
Overriding of analog inputs is not supported (“A” response).
Table 6 Binary Input Objects Table
Object
number Object name VF-PS1 Contents
0 RO1ACT FL (TB) 0 = OFF, 1= ON
1 RO2ACT RY (TB) 0 = OFF, 1= ON
2 DI1ACT F (TB) 0 = OFF, 1= ON
3 DI2ACT R (TB) 0 = OFF, 1= ON
4 *- - -
5 RUNSTOP - 0 = Stop, 1= Run
6 FWDREV - 0 = Fwd, 1= Rev
7 FAULT - 1 = Tripped
8 HANDAUTO - 1 = Serial communication
9 MAINTREQ - 1 = Cumulative operation alarming
10 DRIVEREADY - 0 = Start-up, 1 = Standby
11 ATSETPOINT - 1 = Achieved
12 RO3ACT OUT2 0 = OFF, 1= ON
13 RO4ACT ** R2 0 = OFF, 1= ON
14 RO5ACT ** OUT5 0 = OFF, 1= ON
15 RO6ACT ** OUT6 0 = OFF, 1= ON
16 DI4ACT RES 0 = OFF, 1= ON
17 DI5ACT S1 0 = OFF, 1= ON
18 DI6ACT S2 0 = OFF, 1= ON
19 DI7ACT S3 0 = OFF, 1= ON
20 DI8ACT RR/S4 0 = OFF, 1= ON
21 DI9ACT ** LI5 0 = OFF, 1= ON
22 DI10ACT ** LI6 0 = OFF, 1= ON
23 DI11ACT ** LI7 0 = OFF, 1= ON
24 DI12ACT ** LI8 0 = OFF, 1= ON
*Reserved (The response is “A”).
** These are enabled with ETB004Z (Expansion IO Card option).
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

E6581540
- 17 -
4.4.1. Binary Input Attribute
Table 7 Binary Input Attribute Table
Attribute Type Contents
1 Byte
Object Configuration
Bit 0 = COS_enabled (1)
Bit 1 = normal state
Bit 2 = unused
Bit 3 = alarm_enabled (1)
Bit 4 = unused
Bit 5 = unused
Bit 6 = unused
Bit 7 = unused
2 Byte
Object Status
Bit 0 = reliable (0) / unreliable (1)
Bit 1 = override active (1)
Bit 2 = unused
Bit 3 = unused
Bit 4 = normal (0) / alarm (1)
Bit 5 = normal (0) / trouble (1) (JCI use only)
Bit 6 = current state
Bit 7 = unused
3 Integer Debouncing Value in Msec (1-65535) (JCI use only)
4 Integer32 Accumulator value (JCI use only)
* Added shading functions are not supported (The response is “N10”).
4.5. Binary Input COS Works
First, no COS is reported when the COS_enabled bit is zero. If the COS_enabled bit is
set then COS will be reported whenever the object status changes.
The alarm_enabled bit of the object configuration allow the supervisory system to control
the types of COS reported. If the alarm_enabled bit is zero, then the current status of the
object status would never have the normal/alarm bit set to alarm.
This bit is set to alarm when the normal state of the object configuration does not match
the current state of the object status.
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

E6581540
- 18 -
4.6. Analog Output Object
Analog Output is used for the speed reference of VF-PS1 etc. COS alarm and warning
functions are also enabled.
Overriding of analog outputs will be accepted and acknowledged with the active override
flag set. Upon release of the override command, the analog output point will reset the
active override flag, retain the override value, and not return to its pre-override value.
Table 8 Analog Output Objects Table
Object
number Object name Contents Units
0 INPUTREF Speed reference from Bus *%
1 ACCELTIME Acceleration time 0.1s
2 DECELTIME Deceleration time 0.1s
3 MBOXPARAM Refer to section 4.9. -
4 MBOXVALUEWRITE Refer to section 4.9. -
5 AO1COMMAND ** FM %
6 AO2COMMAND ** AM %
7 AO3COMMAND *** MON1 %
8 AO4COMMAND *** MON2 %
* 100% = vl(Base frequency), fh(Maximum frequency) limits this value.
** 0-2047（100%）
*** 0-2047（100%）, these are enabled with ETB004Z (Expansion IO Card option).
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

E6581540
- 19 -
4.6.1. Analog Output Attribute
Table 9 Analog Output Attribute Table
Attribute Type Contents
1 Byte
Object Configuration
Bit 0 = COS_enabled (1)
Bit 1 = unused
Bit 2 = unused
Bit 3 = unused
Bit 4 = unused
Bit 5 = unused
Bit 6 = unused
Bit 7 = unused
2 Byte
Object Status
Bit 0 = reliable (0) / unreliable (1)
Bit 1 = override active (1)
Bit 2 = saturated high (1) (JCI use only)
Bit 3 = saturated low (1) (JCI use only)
Bit 4 = unused
Bit 5 = unused
Bit 6 = unused
Bit 7 = unused
3 Float Current Value
4 Float Low Linear Ranging Parameter (JCI use only)
5 Float High Linear Ranging Parameter (JCI use only)
* Added shading functions are not supported (The response is “N10”).
4.6.2. Analog Output COS Works
Analog Output and Binary Output points have simple COS.
If the COS_enabled bit is set then COS will be reported whenever the object status
changes.
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]
