Toshiba TOSVERT VF-AS3 User manual

E6582125⑥
Embedded Ethernet Function Manual
NOTICE
1. Read this manual before installing or operating. Keep this manual on hand of the end
user, and make use of this manual in maintenance and inspection.
2. All information contained in this manual will be changed without notice. Please contact
your Toshiba distributor to confirm the latest information.

Safety precautions
On the inverter and in its instruction manual, important information is contained for preventing injuries to
users and damages to assets and for proper use of the device. Read the instruction manual attached to
VF-AS3 along with this instruction manual for completely understanding the safety precautions and adhere
to the contents of these manuals.
- TOSVERT VF-AS3 Instruction Manual.................................................E6582062
WARNING
Prohibited
▼Do not use application of writing into inverter parameters more than 100,000 times.
The Life of EEPROM is approximately 100,000 times.
Frequent writing to the EEPROM of inverter will cause a memory corruption.
Mandatory
▼The following steps must be performed before wiring and installation.
Turn off all input power, wait at least 15 minutes, and confirm that the charge lamp of the
drive is no longer lit.
If steps above are not properly performed, this can result in electric shock.
▼Use an emergency stop device and an additional safety device in your system to prevent
serious accident due to the option malfunctions.
Usage without any emergency stop device or any additional safety device can result in
accident or injury.
CAUTION
Prohibited
▼Do not use application of writing into inverter parameters more than 100,000 times.
The Life of EEPROM is approximately 100,000 times.
Frequent writing to the EEPROM of inverter will cause a memory corruption.
▼Do not connect RS485 communication cable into Ethernet port.
Erroneous connection will result in failure.
Mandatory
▼Insert an electromagnetic contactor between the inverter and the power supply so that the
machine can be stopped without fail from an external controller in case of an emergency.
▼About the handling of the inverter, please follow the Inverter’s instruction manual.
▼Set up “Communication error trip function (see below)”to stop the Inverter when the device
is deactivated by an unusual event such as tripping, an operating error, power outage,
failure, etc.
- Network Time-Out, Inverter operation at disconnection, Preset speed operation selection
(Refer to "2.4.4 Setting for Communication error detection" for details)
Deactivated the device may cause an accident, if the “Communication error trip function”is
not properly set up.

E6582125
1
Contents
1. Overview..................................................................................................................................................2
1.1. Specification.................................................................................................................................2
1.2. LED indicator................................................................................................................................3
1.3. Installation Topology....................................................................................................................4
1.4. EDS file ........................................................................................................................................4
1.5. Display of Embedded Ethernet setting screen.............................................................................5
1.6. Setting IP address........................................................................................................................6
2. Parameters ..............................................................................................................................................7
2.1. Common parameters ...................................................................................................................7
2.2. Communication parameters.........................................................................................................8
2.3. Monitor parameters....................................................................................................................10
2.4. The details of the parameter setting ..........................................................................................11
2.5. The overview of the VF-AS3 command parameters..................................................................19
2.6. The overview of the VF-AS3 monitor parameters......................................................................22
3. Modbus TCP..........................................................................................................................................26
3.1. Header format............................................................................................................................26
3.2. Setting of Unit ID........................................................................................................................26
3.3. List of Modbus functions supported ...........................................................................................26
3.4. "03 (0x03) Read Holding Registers" function.............................................................................27
3.5. "06 (0x06) Write Single Register" function.................................................................................28
3.6. "16 (0x10) Write Multiple Registers" function.............................................................................29
3.7. "23 (0x17) Read/Write Multiple Registers" function...................................................................30
3.8. "43 (0x2B) Read Device identification" function.........................................................................32
3.9. Error Code..................................................................................................................................33
4. EtherNet/IP ............................................................................................................................................34
4.1. Identity Object (0x01).................................................................................................................35
4.2. Message Router Object (0x02)..................................................................................................37
4.3. Assembly Object (0x04).............................................................................................................38
4.4. Connection Manager Object (0x06)...........................................................................................51
4.5. Motor Data Object (0x28)...........................................................................................................52
4.6. Control Supervisor Object (0x29)...............................................................................................53
4.7. AC/DC Drive Object (0x2A) .......................................................................................................55
4.8. Parameter access 1 Objects (0x64)...........................................................................................56
4.9. Parameter access 2 Objects (0x65)...........................................................................................57
4.10. Port Object (0xF4)......................................................................................................................58
4.11. TCP/IP interface Object (0xF5)..................................................................................................60
4.12. Ethernet link object (0xF6).........................................................................................................62
5. Web server.............................................................................................................................................65
5.1. Accessing webserver of VF-AS3 ...............................................................................................65
5.2. Page structure of web server.....................................................................................................67
5.3. Description for each page..........................................................................................................68

E6582125
2
1. Overview
The VF-AS3 embeds an Ethernet dual port adapter that can be used for the following Modbus TCP
functions and EtherNet/IP functions. Also VF-AS3 is certified for EtherNet/IP communication with CPU1
version 108 or more.
1.1. Specification
Embedded ethernet module specifications
Item
Specification
Ethernet connector
Dual RJ45 shielded connector
Supported topology
Daisy chain topology, Star topology
Supported network
Modbus TCP / EtherNet/IP
Indicator
4 LEDs indicating the communication status and error
status.
Network specifications
Item
Specification
Modbus TCP
Supported function
Read Holding Registers (0x03)
Write Single Register (0x06)
Write Multiple Registers (0x10)
Read/Write Multiple Registers (0x17) with I/O scanning
Read Device Identification (0x2B)
Command reception time
About 5ms *
EtherNet/IP
(CPU1 version
V108 or more)
Supported Object
Identity Object (0x01)
Message Router Object (0x02)
Assembly Object (0x04)
Connection Manager Object (0x06)
Motor Data Object (0x28)
Control Supervisor Object (0x29)
AC/DC Drive Object (0x2A)
Parameter access 1 Object (0x64)
Parameter access 2 Object (0x65)
Port Object (0xF4)
TCP/IP Interface Object (0xF5)
Ethernet Link Object (0xF6)
I/O assembly instances
20/70, 21/71, 22/72, 23/73 (AC Drive Device profile)
100/150, 101/151, 102/152, 105/155, 107/157 (Vender
specification)
Command reception time
About 5ms *
Ethernet
Baud rate
Auto negotiation (10/100Mbps, Full/Half duplex)
IP configuration mode
Fixed, BOOTP, DHCP
Auto MDI-X
Supported
LLDP
Supported
Web server
Inverter status monitor, inverter parameter
monitor/configuration, network status monitor,
password lock, access management
SNTP
Supported (Setup from Web server interface)
* Command reception time is until the inverter is operated by RUN command from network.

E6582125
3
1.2. LED indicator
The LED indicator shows the present status of the network and module.
The behavior of LNK1 LED and LNK2 LED
Link Activity
Color and behavior
Meaning
OFF
No link
Green blinking
Network activity at 100 Mbit/s
Green ON
Link established at 100 Mbit/s
Yellow blinking
Network activity at 10 Mbit/s
Yellow ON
Link established at 10 Mbit/s
The behavior of MS LED
Module Status
Color and behavior
Meaning
OFF
Device does not have IP address or powered off
Flashing Green/Red (250ms cycle)
Power on testing
Green flashing (500ms cycle)
Device has not been configured
Green ON
Device is operating correctly
Red flashing (500ms cycle)
Device has detected a communication error
Red ON
Device has detected a non-recoverable error
The behavior of NS LED
Network Status
Color and behavior
Meaning
OFF
The device does not have IP address or powered off
Flashing Green/Red (250ms cycle)
Power on testing
Green flashing (500ms cycle)
Device has a valid IP, but no command word connection
Green ON
A connection is established to control the command word
Red flashing (500ms cycle)
An established connection to control the command word is closed
or timed out
Red ON
Duplicated IP

E6582125
4
1.3. Installation Topology
The product support daisy chain and star topology wiring solutions:
Daisy Chain and/or Star topology
Note: Please use the LAN cable comply with ANSI/TIA/EIA-568-B.2 (CAT5E or successor).
1.4. EDS file
As for acquisition of an EDS file for VF-AS3, please contact your Toshiba distributor.

E6582125
5
1.5. Display of Embedded Ethernet setting screen
Inverter IP address can be set easily by Embedded Ethernet setting screen from guidance function of LCD
panel. In addition, current settings can be checked in the monitor display by scrolling the screen.
Access Embedded Ethernet setting screen of the
guidance function with the following operation.
[ESC] key => Select "3. Guidance function"
=> [OK] key => Select "3.1 Embedded Ethernet"
=> [OK] key
The Embedded Ethernet setting screen
allows you to set IP address setting mode,
IP address, subnet mask, default gateway and
device name.
In addition, you can check the currently settings
in the monitor display by scrolling the screen.
Here is an example when the IP address
192. 168. 0. 1 is obtained by DHCP server.
Embedded Ethernet
Device Name
IP setting DHCP
IP address 0. 0. 0. 0
Mask 0. 0. 0. 0
Gateway 0. 0. 0. 0
21:19
STOP
0.0Hz
Top
Monitor
Return
Standard Mode screen
Embedded Ethernet setting screen
Embedded Ethernet
Mask 0. 0. 0. 0
Gateway 0. 0. 0. 0
IP address monitor 192. 168. 0. 1
Mask monitor 255. 255. 255. 0
Gateway monitor 192. 168. 0. 200
21:19
STOP
0.0Hz
Top
Monitor
Return
Standard Mode
0.0
Copy
Screen
Setting
Monitor
STOP
0.0Hz
21:19
Hz

E6582125
6
1.6. Setting IP address
This section contains two methods to set the IP address.
One is a method using the DHCP servicer, and the other a method to set manually.
For detail of IP setting parameters, refer to section “0”.
To obtain the IP address by using the DHCP server
(1) Select "IP Setting" on Embedded Ethernet setting
screen and set "2: DHCP."
(2) Connect the inverter and the equipment with a DHCP
server function, and reset the inverter.
(3) Check that the IP settings have been obtained by
the monitor display in Embedded Ethernet setting screen.
To set the IP address manually
(1) Select "IP Setting" on the Embedded Ethernet setting
screen and set "0: Fixed."
(2) Set "IP Address", "Mask", "Gateway" to arbitrary values,
and reset the inverter. If you don’t know Gateway address,
you may set the value of “0.0.0.0” for “Gateway” setting.
(3) Check that the IP settings have been changed by
Embedded Ethernet setting screen.
Embedded Ethernet
Device Name
IP setting Fixed
IP address 192. 168. 11. 10
Mask 255. 255. 255. 0
Gateway 192. 168. 11. 100
21:19
STOP
0.0Hz
Top
Monitor
Return
Embedded Ethernet
Mask 0. 0. 0. 0
Gateway 0. 0. 0. 0
IP address monitor 192. 168. 0. 1
Mask monitor 255. 255. 255. 0
Gateway monitor 192. 168. 0. 200
21:19
STOP
0.0Hz
Top
Monitor
Return
Embedded Ethernet
Mask 255. 255. 255. 0
Gateway 192. 168. 11. 100
IP address monitor 192. 168. 11. 10
Mask monitor 255. 255. 255. 0
Gateway monitor 192. 168. 11. 100
21:19
STOP
0.0Hz
Top
Monitor
Return
Embedded Ethernet
Device Name
IP setting DHCP
IP address 0. 0. 0. 0
Mask 0. 0. 0. 0
Gateway 0. 0. 0. 0
21:19
STOP
0.0Hz
Top
Monitor
Return

E6582125
7
2. Parameters
2.1. Common parameters
The product doesn't operate if these parameters are not correctly set.
Title
Comm.
No.
Parameter name
Description
Default
setting
CMOd
0003
Command mode selection
0: Terminal
1: Operation panel, Extension panel
2: Embedded Ethernet
3: RS485 communication (connector 1)
4: RS485 communication (connector 2)
5: Communication option
1
FMOd
0004
Frequency setting mode
selection 1
0: －
1: Terminal RR
2: Terminal RX
3: Terminal II
4: Terminal AI4 (option)
5: Terminal AI5 (option)
6-9: －
10: Touch wheel 1 (power off or press OK to save)
11: Touch wheel 2 (press OK to save)
12: Sr0
13,14: －
15: Terminal Up/Down frequency
16: Pulse train
17: High resolution pulse train (option)
18,19: －
20: Embedded Ethernet
21: RS485 communication (connector 1)
22: RS485 communication (connector 2)
23: Communication option
1
AUE
0032
Eco-standby power setting
0: -
1: Embedded Ethernet OFF
(Unable to communicate with Ethernet)
0
F519
0519
Setting of acceleration /
deceleration time unit
0: -
1: 0.01s unit (0 after execution)
2: 0.1s unit (0 after execution)
0 (*1)
F749
0749
Integrating wattmeter display
unit selection
0: 1.0=1kWh
1: 1.0=10kWh
2: 1.0=100kWh
3: 1.0=1000kWh
4: 1.0=10000kWh
5: 1.0=100000kWh
(*2)
F830
0830
MODBUS continuous address
0: Disabled
1: Enabled
0
F856
0856
Number of motor pole pair for
communication
1: 2 pole
2: 4 pole
3: 6 pole
4: 8 pole
5: 10 pole
6: 12 pole
7: 14 pole
8: 16 pole
2
F897
0897
Parameter Writing
0: Storage to memory device
1: Storage to memory device except by
communication
0

E6582125
8
Title
Comm.
No.
Parameter name
Description
Default
setting
F899
0899
Communication function reset
0: -
1: Reset option and inverter (after execution: 0)
-
(*1): 0.1s unit is selected as default setting.
(*2): Default setting values vary depending on the capacity.
2.2. Communication parameters
Title
Comm.
No.
Parameter name
Description
Default
setting
C081 to
C096
C081 to
C096
Device Name 1-16 (*1)
Max 16 characters
Default setting1 function ([tyP] = “3”) does not
work for this parameter.
0
C606
C606
Emb Eth. Communication
error detection delay
0.0 - 100.0 sec.
0.0
C607
C607
Emb Eth. Communication
error operation
0: Turn off bit 10, 14 and 15 of FA36
1: Continue running
2: Deceleration stop
3: Coast stop
4: Network error stop (E-43 trip)
5: Preset speed operation (by C608 setting)
4
C608
C608
Emb Eth. Preset speed at
communication error
0: None
1 to 15: Preset speed
0
C609
C609
Emb Eth. Communication
error detection
0: Always
1: Communication command (Frequency
command and command from Emb Eth.)
enabled
2: 1 + during run
1
C610
C610
Emb Eth. IP setting mode
(*1)
0: Fixed
1: BOOTP
2: DHCP
2
C611 to
C614
C611 to
C614
Emb Eth. IP address setting
value (*1)
The IP address of the device.
These fields are effective settings at [C610] = “0”.
0.0.0.0
C615 to
C618
C615 to
C618
Emb Eth. Subnet mask
setting value (*1)
The subnet mask of the device.
These fields are effective settings at [C610] = “0”.
0.0.0.0
C619 to
C622
C619 to
C622
Emb Eth. Default gateway
setting value (*1)
The gateway IP address of the device.
These fields are effective settings at [C610] = “0”.
0.0.0.0
C641 to
C650
C641 to
C650
Emb Eth. Scanner input
select 1 to 10
0: No action
1: FA36 (Emb Ethernet command 1)
2: FA38 (Emb Ethernet command 2)
3: FA37 (Emb Ethernet frequency command)
4: FA40 (Emb Ethernet torque command)
5: FA50 (Terminal output data)
6: FA51 (Terminal FM data)
7: FA52 (Terminal AM data)
8: F601 (Stall prevention level 1)
9: F441 (Power running torque limit level 1)
10: F443 (Regenerative torque limit level 1)
11: F460 (Speed control response 1)
12: F461 (Speed control stabilization coefficient 1)
13: ACC (Acceleration time 1) (*2)
14: dEC (Deceleration time 1) (*2)
15: UL (Upper limit frequency)
16: vb (Manual torque boost 1)
17: vLv (Base frequency voltage 1)
C641: 1
C642: 3
C643 to
C644: 0

E6582125
9
Title
Comm.
No.
Parameter name
Description
Default
setting
C651 to
C660
C651 to
C660
Emb Eth. Scanner output
select 1 to 10
0: No action
1: FD01 (Inverter status 1)
2: FD00 (Output frequency)
3: FD03 (Output current)
4: FD05 (Output voltage)
5: FC91 (Alarm code)
6: FD22 (PID feedback value)
7: FD06 (Input terminal status)
8: FD07 (Output terminal status)
9: FE35 (Terminal RR input value)
10: FE36 (Terminal RX input value)
11: FE37 (Terminal II input value)
12: FD04 (Input voltage (DC detection))
13: FD16 (Speed feedback frequency (real time))
14: FD18 (Torque)
15: FE60 (My function monitor output 1)
16: FE61 (My function monitor output 2)
17: FE62 (My function monitor output 3)
18: FE63 (My function monitor output 4)
19: F880 (Free memorandum)
20: FD29 (Input power)
21: FD30 (Output power)
22: FE14 (Cumulative operation time)
23: FE40 (Terminal FM output value)
24: FE41 (Terminal AM output value)
25: FD20 (Torque current)
26: FD23 (Motor overload factor)
27: FD24 (Inverter overload factor)
28: FD25 (Braking resistor overload factor)
29: FD26 (Motor load factor)
30: FD27 (Inverter load factor)
31: FE56 (Terminal S4/S5 pulse train input value)
32: FE70 (Inverter rated current)
33: FE76 (Input cumulative power)
34: FE77 (Output cumulative power)
35: FD83 (Internal temperature 1)
C651: 1
C652: 2
C653 to
C654: 0
C666
C666
Emb Eth. I/O scan timeout
detection time
0: Disable
0.1-30.0 s
2.0
C667
C667
Emb Eth. I/O scan setting
(*1) (*4)
0: Disable
1: Enable
1
C668
C668
Emb Eth. Web server (*1)
0: Disabled
1: Enabled
1
C669
C669
Emb Eth. Web server reset
0: -
1: Execution
(after execution: 0)
0
C670
C670
Emb Eth. Unit ID
0-247 (*3)
0
C671
C671
Emb Eth. Massage timeout
detection time (*1) (*4)
0: Disable
0.1-100.0 s
2.0
C680
C680
EmbEth. Inverter to
inverter communication
select (*1) (*4)
0: Disabled
1: Inverter to inverter communication
2: Pump control
0
C681
C681
EmbEth. Inverter to
inverter communication ID
(*1) (*4)
0: Leader
1-9: Follower 1-9
0

E6582125
10
Title
Comm.
No.
Parameter name
Description
Default
setting
C682
C682
EmbEth. Inverter to
inverter communication
(*1) (*4)
0: Follower (0Hz command when Leader fails)
1: Follower (continue running when Leader fails)
2: Follower (emergency off when Leader fails)
3: Leader (transmit frequency command)
4: Leader (transmit output frequency signal)
5: Leader (transmit torque command)
6: Leader (transmit output torque command)
0
(*1): These parameters are affected after reset. Wait 5 second from the setting to reset to ensure that settings
are reflected.
If you want to change the IP address and the device name, please set the device name first.
(*2): The unit is depended by the [F519] setting.
(*3): In the CPU1 version V104 or earlier of VF-AS3, parameter value 14 is reserved for internal process.
Do not set the <C670> at 14 with V104 or earlier, inverter initialization cannot be completed after reset.
(*4): This parameter is supported in the CPU1 version V114 or rater.
2.3. Monitor parameters
The following parameters can be used for network status confirmation of the embedded ethernet.
Title
Comm.
No.
Parameter name
Description
C623 to
C628
C623 to
C628
Emb Eth. MAC address monitor
The MAC address of the device.
[C623 –C624 –C625 –C626 –C627 –C628]
C629 to
C632
C629 to
C632
Emb Eth. IP address monitor
The current IP address of the device.
C633 to
C636
C633 to
C636
Emb Eth. Subnet mask monitor
The subnet mask actual of the device.
C637 to
C640
C637 to
C640
Emb Eth. Default gateway monitor
The gateway IP address actual of the device.
C696
C696
Emb Eth. Command monitor
This parameter displays the command from
Embedded Ethernet.
C697
C697
Emb Eth. Frequency command
monitor
This parameter displays the reference frequency from
embedded ethernet.
C698
C698
Emb Eth. Error monitor
Monitor of the Ethernet error.
0: No error
1: Modbus TCP Scanning timeout
3: INV to INV communication timeout
4: EtherNet/IP timeout
5: Modbus Message timeout
C699
C699
Emb Eth. External error monitor
Monitor of the Ethernet error.
0: No error
1: Invalid IP address
2: Duplicate IP address
3: INV to INV communication configuration error

E6582125
11
2.4. The details of the parameter setting
[F830: MODBUS continuous address]
VF-AS3 does not have parameters of the communication number “0xXXXA” to “0xXXXF” and “0xXXAX” to
“0xXXFX”.
When parameters are accessed with the Modbus function command 0x03 and 0x10, it is possible to select
these parameters are slipped or not by parameter [F830].
・[F830] = “0: Disabled” (Default setting)
Communication number “0xXXXA” to “0xXXXF” and “0xXXAX” to “0xXXFX” are skipped.
Example: When 3 word read/write command is executed from communication number “0x0009” ([ACC:
Acceleration time 1]), access the communication number in the following order.
Access word
Parameter
Communication No.
1
[ACC: Acceleration time 1]
0x0009
2
[DEC: Deceleration time 1]
0x0010
3
[FH: Maximum frequency]
0x0011
・[F830] = “1: Enabled”
Communication number “0xXXXA” to “0xXXXF” and “0xXXAX” to “0xXXFX” are not skipped.
Example: When 3 word read/write command is executed from communication number “0x0009” ([ACC:
Acceleration time 1]), access the communication number in the following order.
Access word
Parameter
Communication No.
1
[ACC: Acceleration time 1]
0x0009
2
None*
0x000A
3
None*
0x000B
Note) If the parameter not assigned is accessed (read) by communication, inverter returns "0x8000".
If the parameter not assigned is accessed (write) by communication, inverter returns error code
“0x02: Illegal Data Address”.

E6582125
12
[F897: Parameter writing]
When [F897: Parameter writing] is set to "1", all writing via communication is only done to the RAM. This
parameter can be used when frequently writing to EEPROM supported parameters, but the content of the
parameters return to the values stored in EEPROM each time the inverter is reset.
If you want to temporarily allow storage to EEPROM when [F897] = "1", you can set [FA93] to "1:
Temporarily suppress mode for RAM" to allow writing EEPROM supported parameters.
Important
▼The [F897] setting is reflected after a reset operation such as power off, so you need power
reset after the setting. In addition, note that if [0897] = "0" is set via communication, the
[F897] parameter does not return to "0: Storage to memory device". To set to "0", modify the
setting from the operation panel.
[C081 to C096: Device name 1 to 16]
This devide can set the "Device name" of 16 characters.
(These 16 characters are stored in the parameter [C081] to [C096].)
Please set the setting of the device name according to the following rules.
1. The parameter is displayed by the hexadecimal number.
2. Each parameter shows an ASCII character on Guidance function and Web server.
3. The relation between the device name and the parameter is as follows.
Example for Device Name =’VFAS3-2007P’
Chars No.
Parameter
Character (Ex.)
ASCII (Ex.)
Set point(Ex.)
1
C081
‘V’
0x56
86
2
C082
‘F’
0x46
70
3
C083
‘A’
0x41
65
4
C084
‘S’
0x53
83
5
C085
‘3’
0x33
51
6
C086
‘-‘
0x2D
45
7
C087
‘2’
0x32
50
8
C088
‘0’
0x30
48
9
C089
‘0’
0x30
48
10
C090
‘7’
0x37
55
11
C091
‘P’
0x50
80
12
C092
-
0x00
0x00
13
C093
-
0x00
0x00
14
C094
-
0x00
0x00
15
C095
-
0x00
0x00
16
C096
-
0x00
0x00
Parameter writing
Parameter writing
Parameter writing
[F897] = “0”
[F897] = “1”
[FA93] = “1”
[FA93] = “0”

E6582125
13
Setting for Communication error detection [C606] to [C609]
[C606: Emb Eth. Communication error detection delay]
Adjustment range: 0.0 - 100.0 sec.
The waiting time of network error detection can be adjusted. If network error was removed during [C606],
inverter will continue normal operation.
[C607: Emb Eth. Communication error operation]
Adjustment range:
0: Turn off bit 10, 14 and 15 of FA36
1: Continue running
2: Deceleration stop
3: Coast stop
4: Network error stop (E-43 trip)
5: Preset speed operation (by C608 setting)
When the communication error is detected, inverter will operate in accordance with the setting of [C607].z
[C608: Emb Eth. Preset speed at communication error]
Adjustment range:
0: None
1 to 15: Preset speed
When the communication error is detected, operation frequency can be selected from preset speed (Only
when [C607] is set to 5). When you set “0: None”, inverter will operate in accordance with enabled
frequency command.
[C609: Emb Eth. Communication error detection]
Adjustment range:
0: Always
1: Communication command
2: 1 + during run
Condition of communication error detection can be selected by setting of [C609].
When [C609] is set to “1: Communication command”, inverter will enable the communication error
detection if frequency command and communication command 1 from Embedded Ethernet are enabled.
When [C609] is set to “2: 1 + during run”, inverter detect the communication error during operation only in
the above condition.
[C666: Emb Eth. I/O scan timeout detection time]
Adjustment range:
0: Disable
0.1-30.0 s
When you use the I/O scanning service of ModbusTCP, inverter will detect the time out error if I/O
scanning is not performed between periods of [C666] setting.
When [C666] is set to “0: Disable”, timeout for I/O scanning function does not detected.

E6582125
14
[C671: Emb Eth. Massage timeout detection time]
Adjustment range:
0: Disable
0.1-100.0 s
When you use the Massage service of ModbusTCP, inverter will detect the time out error if Massage is not
performed between periods of [C671] setting.
When [C671] is set to “0: Disable”, timeout for Massage function does not detected.
Massage time out error is not detected during I/O scanning.
Assigning IP addresses parameters [C610], [C611] to [C622]
The following setting parameters can be accessed from the “Embedded Ethernet setting” on guidance
function. For detail of “Embedded Ethernet setting”, refer to section “1.6 Setting IP address”.
The address is assigned according to setting of [C610: Emb Eth. IP setting mode].
C610
Comments
0
The device uses the address defined in [C611] to [C622]
1
The device receives its address from a BOOTP server.
2
The device receives its address from a DHCP server.
When you set up the IP address by manual ([C610] = “0”), bellow parameters setting are needed.
[C611 to C614: Emb Eth. IP address setting value 1 to 4]
[C615 to C618: Emb Eth. Subnet mask setting value 1 to 4]
[C619 to C622: Emb Eth. Default gateway setting value 1 to 4]
These parameters are effective settings at [C610] = “0: Fixed”).
If you set [C610] = “1: BOOTP” or “2: DHCP”, these parameters are invalidity.
After dynamic addressing by BOOTP server or DHCP server, the new address values are displayed in the
bellow monitor parameters.
[C629 to C632: Emb Eth. IP address monitor 1 to 4]
[C633 to C636: Emb Eth. Subnet mask monitor 1 to 4]
[C637 to C640: Emb Eth. Default gateway monitor 1 to 4]

E6582125
15
Embedded Ethernet Inverter to inverter communication [C680] to [C682]
[C680: EmbEth. Inverter to inverter communication select]
Adjustment range:
0: Disabled
1: Inverter to inverter communication
2: Pump control
[C681: EmbEth. Inverter to inverter communication ID]
Adjustment range:
0: Leader
1 to 9: Follower 1 to 9
[C682: Emb Eth. Inverter to inverter communication]
Adjustment range:
0: Follower (0Hz command when Leader fails)
1: Follower (continue running when Leader fails)
2: Follower (emergency off when Leader fails)
3: Leader (transmit frequency command)
4: Leader (transmit output frequency signal)
5: Leader (transmit torque command)
6: Leader (transmit output torque command)
When [C680] is set to “1: Inverter to inverter communication”, you can use inverter to inverter
communication. (Please refer to “Pump control function manual” E6582124 for usage of “2: Pump control”)
Inverter to inverter communication can be used to implement speed-proportional control between multiple
inverters without using a PLC or a computer. Commands are input to the leader inverter via the operation
panel or analog signal.
When the inverter-to-inverter communication function is used, the leader inverter keeps sending data
selected by parameter [C682] to all follower inverters on the same network. You can configure a network
using this function to perform simple synchronized operation or speed proportional operation.
* When the leader trips, all follower inverters operate according to the parameter [C682] of each follower
inverter.
* To select how the followers operate when cable is disconnected or the leader is turned off (continue /
alarm/trip), use the communication error detection function ([C606] to [C609]).
* Up to 9 followers can be connected by this function.
<Communication connection schematic diagram (example)>
Leader
(60Hz)
Follower 1
(50Hz)
Inverter
Inverter
Inverter
Inverter
Follower 2
(40Hz)
Follower 3
(30Hz)

E6582125
16
Important
▼In case of communication cable is disconnected, you can trip a follower inverter by using the
communication error detection function ([C606] to [C609]). The leader will not trip even if its
cable is disconnected. To trip the leader, install an interlock from the follower side using an
FL failure relay signal, etc.
Transmission data
The leader side operation command (Run/Stop and Forward/Reverse) and reference value (frequency
command, torque command, output frequency or output torque) are transmitted to the follower side.
These data are sent as UDP packets.
When transmitting frequency command or output frequency, data is converted using [FH: Maximum
frequency] as below.
Details of transmitted data during inverter-to-inverter communication (frequency value)
𝑓𝑐(%) = Leader frequency value(Hz) ×10000
Leader maximum frequency(Hz)(1=0.01%)
* Calculation results of 1 (0.01%) or less are rounded down. As a result, a maximum error of 0.01%
occurs.
Conversion details of frequency commands after they are received by followers
The value after conversion below is written to the RAM as a frequency command value.
𝑓𝑐(𝐻𝑧) = Reception data(%) × Follower maximum frequency(Hz)
10000 (1=0.01Hz)
* Calculation results of 1 (0.01 Hz) or less are rounded down. As a result, a maximum error of 0.01 Hz
occurs.
Parameter setting
Network setting
Please set the parameter [C610] to [C620] so that leader and followers build a single subnetwork.
Example settings
Leader
IP address: 192.168.0.10
Subnet musk: 255.255.255.0
Follower 1
IP address: 192.168.0.20
Subnet musk: 255.255.255.0
Follower 2
IP address: 192.168.0.30
Subnet musk: 255.255.255.0

E6582125
17
Inverter to inverter communication setting
Set only one inverter on the network as leader and all others as followers.
* If multiple leaders are set on the same network, data conflict will occur. Be sure to only set one
leader.
Setting for the leader inverter
Set the data to be set from the leader to the followers.
3: Leader (transmit frequency command)
4: Leader (transmit output frequency signal)
5: Leader (transmit torque command)
6: Leader (transmit output torque command)
Setting for the follower inverters
Set the operation of the follower side when the leader trips.
0: Follower (0 Hz command when Leader fails)
Output frequency is limited by the lower limit frequency.
1: Follower (continue running when Leader fails)
When an output frequency is set on the leader, the trip causes the output frequency of the
leader to change to 0 Hz. In this case, the frequency command to the followers will be 0 Hz.
2: Follower (emergency off when Leader fails)
The stop pattern follows the [F603: Emergency off stop pattern] settings.
* These parameters are reflected after resetting the inverter or turning the inverter power off and then on.
Run command select ([CMOD]) and Frequency command select 1 ([FMOd])
For [CMOD] and [FMOd], set the input that gives commands to the inverter.
Setting for the leader inverter
Set an arbitrary value to receive the command for leader.
Setting for the follower inverters
Set a value for Embedded Ethernet ([CMOD] = "2", [FMOd] = "20").

E6582125
18
Parameter setting example for embedded ethernet
Below setting example, the frequency reference and operation command are input from the panel of the
leader, and these are transmitted to the follower by inverter to inverter communication.
Parameters of the leader (examples)
[CMOd] = "1" Example: Operation panel
[FMOd] = "10" Example: Touch wheel 1
[C610] = "0" Fixed
[C611] = "192"
[C612] = "168"
[C613] = "1"
[C614] = "10"
[C611] = "255"
[C612] = "255"
[C613] = "255"
[C614] = "0"
[C680] = "1" Inverter to inverter communication
[C681] = "0" Leader
[C682] = "3" Leader (transmit frequency command)
Parameters of the followers (examples)
[CMOd] = "2" Embedded Ethernet
[FMOd] = "20" Embedded Ethernet
[C610] = "0"
[C611] = "192"
[C612] = "168"
[C613] = "1"
[C614] = "20"
[C611] = "255"
[C612] = "255"
[C613] = "255"
[C614] = "0"
[C680] = "1" Inverter to inverter communication
[C681] = "1" Follower 1
[C682] = "0" Follower (0Hz command when Leader fails)
