INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33002
1. Cutter Module: B-SX208-QM-R
1- 1
INSTALLATION PROCEDURE FOR OPTIONAL
EQUIPMENT
1. Cutter Module: B-SX208-QM-R
B-SX208-QM-R is an optional cutter module for the B-SX6T/SX8T Series.
•Packing List
The following parts are supplied with the kit. Make sure you have all items shown below.
Cutter Unit (1 pc.)
Cutter Module Cover
(1 pcs.)
Cutter Harness (1 pc.) Cutter Support Plate
(1 pc.)
Print Head Cleaner
(1 pc.)
Cutter Attaching
Screw (2 pcs.)
FL-4x6 Screw (2 pcs.)
SM4x6 Screw (1 pc.) Installation Manual
(1 copy)
Note: for how to use the print head cleaner, please refer to the Owner’s Manual.
•Installation Procedure
1. Turn the power off.
2. Open the right side cover and top covers.
WARNING!
1. Turn the printer power off and disconnect the power cord before installing an optional
equipment.
2. Be careful not to pinch your fingers or hands with the covers.
3. Be careful not to injure your fingers when installing the cutter module.
Top Cover
Right Side Cover

INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33002
1. Cutter Module: B-SX208-QM-R
1- 2
3. Remove the six screws (B-4x6, FL-4x6 and B-3x8) to detach the left side cover.
4. Remove the four FL-4x6 screws to detach the front cover.
5. Remove the SM-4x8 screw and operation panel harness to detach the operation panel.
FL-4x6 Screw
B-3x8 Screw
B-4x6 Scre
w
FL-4x6 Screw
FL-4x6 Scre
w
FL-4x6 Scre
w
SM-4x8 Screw
Operation Panel Harness
Operation Panel
B-4x6 Scre
w
Left Side Cove
r

INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33002
1. Cutter Module: B-SX208-QM-R
1- 3
6. Attach the cutter support plate to the main frame with the two screws (FL-4x6).
7. Connect the cutter harness to CN3 on the cutter interface PC board through the opening of the cutter
unit.
8. Install the cutter unit with the supplied four screws (cuter attaching screws, SM-4x6 and FL-4x6). When
installing the cutter unit, make sure that the cutter guide does not contact with the platen. If so, a print
failure or noise may occur.
FL-4x6 Screw
FL-4x6 Scre
w
Cutter Support Plate
Main Frame
Cutter Interface PC Board
CN3
Cutter Unit Cutter Harness
Cutter Unit FL-4x6 Screw
SM-4x6 Screw
Cutter Attaching Scre
w
Opening

INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33002
1. Cutter Module: B-SX208-QM-R
1- 4
9. Connect the cutter harness to the connector on the printer through the opening of the main frame.
10. Mount the cutter cover with the two screws.
Fit the cutter cover into the cutter attaching screws and secure the cutter cover with the two screws.
11. Attach the operation panel and the left side cover on the printer.
12. Close the top cover and right side cover.
13. After the reassembly is completed, perform a test print to confirm that the cutter works properly.
If the print start position becomes misaligned when media is fed in the reverse direction, fine adjust
the back feed value using the Back Feed Fine Adjustment procedure in system mode.
Cutter Harness
Connecto
r
Main Flame
Screw
Cutter Attaching
Screw
Opening
Cutter Cove
r
Screw

INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33002
1. Cutter Module: B-SX208-QM-R
1- 5
•Adjusting the Cutter Guide Plates
After attaching the cutter unit the following adjustment procedure should be employed to prevent paper
jams.
1. Attach the cutter guide plate A with the two SM-4x6C screws so that the fixed cutter is positioned
0.1 mm to 0.4 mm above the bottom of the cutter guide plate A.
2. Attach the cutter guide plate B with the two FL-4x8 screws so that there is a clearance of 0.5 mm
between the cutter guide plate A and cutter guide plate B using a clearance gauge.
• Media loading procedure------------- Owner’s Manual, Section 2.4
• Operation check------------------------Owner’s Manual, Section 2.10
• System mode setting------------------System Mode Manual
• Cleaning --------------------------------- Owner’s Manual, Section 4.1.5
Cutter Guide Plate B
Cutter Guide Plate A
Screw
(FL-4x8)
Fixed Cutte
r
Screw
(SM-4x6C)
0.1 to 0.4 mm
0.5 mm

INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33002
2. Strip Module: B-SX908-H-QM-R
2- 1
2. Strip Module: B-SX908-H-QM-R
B-SX908-H-QM-R is an optional strip module for the B-SX6T/SX8T Series.
•Packing List
The following parts are supplied with the kit. Make sure you have all items shown below.
Strip Unit (1 pc.)
Strip Harness (1 pc.)
Installation Manual (1 copy)
•Installation Procedure
1. Turn the power off.
2. Open the right side cover and top cover.
3. Remove the six screws (B-4x6, FL-4x6 and B-3x8) to detach the left side cover.
Top Cover
Right Side Cover
FL-4x6 Screw
B-3x8 Screw
B-4x6 Scre
w
B-4x6 Scre
w

INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33002
2. Strip Module: B-SX908-H-QM-R
2- 2
4. Remove the four FL-4x6 screws to detach the front cover.
5. Remove the SM-4x8 screw and operation panel harness to detach the operation panel.
6. Connect the strip harness to CN5 on the PWM PC Board through the opening of the strip base.
FL-4x6 Screw
FL-4x6 Scre
w
FL-4x6 Scre
w
SM-4x8 Screw
Operation Panel Harness
Operation Panel
Strip Unit Strip Harness
Strip Base
PWM PC Board
Opening
CN5

INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33002
2. Strip Module: B-SX908-H-QM-R
2- 3
7. Install the strip unit into the printer with the four FL-4x6 screws which were removed in step 4.
8. Connect the strip harness to the connector on the printer through the opening of the main frame.
9. Attach the operation panel and the left side cover on the printer.
10. Close the top cover and right side cover. After that, perform an operation check for a proper strip issue.
• Media loading procedure------------- Owner’s Manual, Section 2.4
• Operation check------------------------Owner’s Manual, Section 2.10
• System mode setting------------------System Mode Manual
• Cleaning --------------------------------- Owner’s Manual, Section 4.1.6
FL-4x6 Screw FL-4x6 Screw
FL-4x6 Scre
w
Strip Unit
Connecto
r
Opening
Main Frame
Strip Harness

INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33002
3. Ribbon Saving Module: B-SX908-R-QM-R
3- 1
3. Ribbon Saving Module: B-SX908-R-QM-R
B-SX908-R-QM-R is an optional strip module for the B-SX6T Series.
•Packing List
The following parts are supplied with the kit. Make sure you have all items shown below.
Solenoid (R) (1 pc.)
(Connector: White) Solenoid (L) (1 pc.) (Connector: Yellow) RSV PC Board (1 pc.)
Locking Support (3 pcs.)
SM-3x5 Screw (4 pcs.) Installation Manual (1 copy)
•Installation Procedure
1. Turn the power off.
2. Open the right side cover and top cover.
Top Cover
Right Side Cover

INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33002
3. Ribbon Saving Module: B-SX908-R-QM-R
3- 2
3. Remove the two B-4x6 screws to detach the print head front plate.
4. Remove the four SM-4x8 screws to detach the blind plate (R) and blind plate (L).
5. Attach the blind plate (L) to the solenoid (L) with the two SM-3x5 screws.
6. Reverse the blind plate (L) and attach the three locking supports.
B-4x6 Screw
B-4x6 Scre
w
SM-4x8 Scre
w
SM-4x8 Screw
Print Head Front Plate
Blind Plate (R)
Blind Plate (L)
SM-3x5 Screw
Blind Plate (L)
Solenoid (L)
Locking Support

INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33002
3. Ribbon Saving Module: B-SX908-R-QM-R
3- 3
7. Fit the locking supports into the RSV PC board, then connect the solenoid (L) harness to CN1 on the
RSV PC board.
8. Attach the blind plate (R) to the solenoid (R) with the two SM-3x5 screws.
9. Draw the two harnesses (2 pins, 3 pins) from the head block, then connect the harness (2 pins) and the
harness (3 pins) into CN2 and CN3 on the RSV PC board.
RSV PC Board
CN1
Harness
Solenoid (L)
SM-3x5 Scre
w
Solenoid (R)
Blind Plate (R)
Harness (3 pins)
Harness (2 pins)
CN3
CN2
RSV PC Board

INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33002
3. Ribbon Saving Module: B-SX908-R-QM-R
3- 4
10. Connect the solenoid (R) harness to the head block harness.
11. While inserting the head up link into the spring pin of the solenoid, attach the solenoids (L) and (R) to
the head block.
Note: It is easier to attach the solenoid in the following procedure. First remove the plunger from the
solenoid. Next, insert the head up link into the plunger then the plunger into the solenoid.
Solenoid (R)
Harness
Spring Pin
Head Up Lin
k
Solenoid (L)
Head Up
Lin
k
Plunger Plunge
r
Solenoid

INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33002
3. Ribbon Saving Module: B-SX908-R-QM-R
3- 5
12. Insert piled 12 pieces of tag paper (0.16-mm thick, I-BEST-S is recommended.) between the print head
and the platen. Then turn the head lever to the LOCK position.
13. Fully push the head up link to the direction indicated by the arrow 1. Push the solenoid toward the
head up link as indicated by the arrow 2, then secure the solenoid with the two SM-4x8 screws.
Solenoid (L) Solenoid (R)
Head Lever
Tag Paper
LOCK Position
Head Up Link
Head Up
Link
1
2
SM-4x8 Scre
w
1
2
SM-4x8 Scre
w
Solenoid (L) Solenoid (R)

INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33002
3. Ribbon Saving Module: B-SX908-R-QM-R
3- 6
14. After installing the solenoids (L) and (R), reassemble the print head front plate so that this part fits into
the slot of the shaft.
15. Perform a label issue to check the ribbon saving operation.
Print Head Front Plate Shaft Slot

INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33002
4. Wireless LAN Module: B-SA704-WLAN-QM-R
4- 1
4. Wireless LAN Module: B-SA704-WLAN-QM-R
B-SA704-WLAN-QM-R is an optional wireless LAN module for the B-SX6T/SX8T Series, B-SA4TM/SA4TP
Series and B-852-QQ/QP-R Series .
•Packing List
The following parts are supplied with the kit. Make sure you have all items shown below.
Wireless LAN Board (1 pc.) Antenna Cover (1 pc.) SMW-3x6 Screw (4 pcs.)
Installation Manual (1 copy) Shield Sheet (1.pc) FCC/IC Sticker (1 pc.)
NOTES:
1. DO NOT CHANGE the DIP Switch settings on the Wireless LAN Board. Doing so may cause a malfunction.
2. MAC address of the Wireless LAN module will be necessary when setting the MAC address filtering function
of an access point. As it is printed on the top of the wired LAN connector on the Wireless LAN Board, write
down it on Installation Manual before mounting the covers so that an end user can know the MAC address.
3. Be careful not to hit or damage the antenna when installing this kit. A damaged antenna may affect the
performance.
4. The shield sheet is used only when this option is installed in the B-SA4TP model.
DIP Switch
MAC Address
12-digit code printed on the right
side of “W” is MAC address.
Wireless LAN Board
Antenna

INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33002
4. Wireless LAN Module: B-SA704-WLAN-QM-R
4- 2
•Installation Procedure
1. Turn the power off.
2. Open the right side cover and top cover.
3. Remove the six screws (B-4x6, FL-4x6 and B-3x8) to detach the left side cover.
4. Remove the two SMW-3x6 screws to detach the blind plate.
Top Cover
Right Side Cover
FL-4x6 Screw
B-3x8 Screw
B-4x6 Scre
w
B-4x6 Scre
w
Left Side Cove
r
SMW-3x6
Blind Plate

INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33002
4. Wireless LAN Module: B-SA704-WLAN-QM-R
4- 3
5. Put the antenna of the wireless LAN board out of the opening of the back of the printer.
Care must be taken not to hit the antenna against the printer frame, as damaged antenna may affect the
performance.
6. As the following picture shows, secure the wireless LAN board to the back of the printer with the two out
of the supplied SMW-3x6 screws.
Opening
Wireless LAN Board
A
ntenna
SMW-3x6 scre
w

INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33002
4. Wireless LAN Module: B-SA704-WLAN-QM-R
4- 4
7. Secure the wireless LAN board onto the MAIN PC board with the SMW-3x6 screw.
8. Connect the wireless LAN power cable to CN12 on the MAIN PC board.
9. Connect the LAN cable as shown below.
SMW-3x6 Screw
Wireless LAN Board
CN12
MAIN PC Board
MAIN PC Board
LAN Cable
CN17
