TOSO Mytec 01 Loop Double Type User manual

No.R−120019E First edition
Instruction Manual
INDEX
■Caution ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 2
■Product View and Part Names ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 4
■Installation and Detaching ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 6
■How to Operate ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・10
■How to Use a Stop Controller (Optional)/Mytec 01 Only ・・・・・・・・・・・・・11
■How to Adjust the Screen Operation Force and the Ascent Speed ・・・・・・12
■Fixing Improper Rolled up Screen ・・・・・・・・・・・・・・・・・・・・・・・・・14
■Troubleshooting・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・15
■Cleaning ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・15
Roller Blind
Mytec 01 Loop/Mytec 01
Thank you for purchasing TOSO products. To ensure safe use of this product,
please read the following thoroughly and keep this manual stored.
Guide for Distributors and Installation Contractors
This manual contains information for a user to safely operate this product.
Please provide this manual to a customer.

Caution
* This manual contains cautions and instructions for safe use of the product.
Please read it carefully before using to ensure appropriate use.
●This document illustrates the dangers of using this product without taking necessary
precautions. Please refer to the symbols below for different types of safety points.
●This document illustrates safety points to be followed using the symbols below.
Illustrates specific actions which are prohibited.
Illustrates specific guidelines which must be followed.
Caution
This product is intended for indoor use. Please do not use it for outdoor
purposes.
Locations subject to high temperatures and high humidity, or areas
where water may leak, should be avoided.
Make sure to install this product horizontally.
Do not grab the set bar to carry or lift this product. It may cause damage
to the product.
■Precautions upon installing the product (Please read before installation.)
Check the foundation base and strength of the material before installing this product.
If not installed properly to the foundation base, there are dangers of it falling.
Install this product as instructed with the necessary quantity of brackets. Otherwise
the product may fall.
Warning
Warning
Caution
Illustrates that if this product is misused, there are dangers of
serious injuries or possible fatal accidents.
Illustrates that if this product is misused, there are dangers of
casualties or possible physical damage of the product.
P. 2
When there is a strong wind, either
close the window or have the Screen
completely rolled up.
Please do not dismantle the mechanical
assembly nor lubricate the moving parts
of this product. This will ensure physical
damage or malfunction of the product.
Please do not use it by
open flames.
■Safety in Use (Please read thoroughly.)
Please do not hang from or pull on
this product. This may damage the
product or cause it to fall down.
Please do not operate the product
abruptly or with unreasonable force. This
may cause the product to fall down or
break.
Please do not let children play with the cord or chain.
Please do not wrap the cord or chain around you, or allow it to get caught on
something, because this may result in an accident.
When not operating the product, tie the cord and chain at a height that is out of
reach of small children.
P. 3
Warning
Caution
Be sure to grasp the pull cord or the ball chain to operate
the blind. Do not operate it by grasping the screen, roller
pipe or weight bar.
Do not place an object that is liable to break or an object
that is likely to interfere with the operation of the product,
inside the range of the opening and closing operation.
Use the product within the specified height range. If you
use it outside this range, the screen may fall down or break.

Product View and Part Names
* The size of Side Holder changes with the size of the product and the screen.
* The figure shows a right operation.
Side Holder
Roller Pipe
Screen
Weight Bar
1)
2)
3)
4)
Weight Bar Cap
Metal Ball Chain or
Plastic Ball Chain
Ball Chain Connector
5)
6)
7)
Set Bar
Bracket (For Set Bar type)
Pull Ball Set
8)
9)
10)
P. 4
Mytec 01 Loop
Mytec 01
<Side Bracket Type> <Set Bar Type>
<Side Bracket Type> <Set Bar Type>
<Wrapping Type>
Component
10)
2)
2)
3)
3)
3)
4)
7)
5)
4)
5)
1)
3)
4)
5)
1)
1)
6)
7)
6)
2)
2)
10)
4)
5)
1)
8)
9)
8)
9)
■Accessories
■Optional Parts
P. 5
Bracket
(For Set Bar type) *1
Double-sided Tape
for Temporary
Positioning of Bracket *1
Component Winder *3
300-1400
1410-2700
2 pieces
3 pieces
2 sheets
3 sheets
2 screws
3 screws
Product Width
［mm］Fixing Screw
（Bindφ3.5×16）
1 winder
Side Holder Cover
Pull Grip Set Flat Grip Set
Mytec 01 Loop
Mytec 01
○
○
ー
○
ー
○
*1 Provided only with Set Bar Type.
*2 Set Bar Bracket Fixing Screws are for wooden part only. Use fixing screws that are suitable for
the strength and the material of the frame or wall to which the brackets are to be fixed.
*3 Please keep a Winder stored with this manual for future use.
Bracket Fixing Screw
(For Set Bar type) *2

P. 6
Installation and Detaching
■Installation Type
< Ceiling Attachment>
Install inside of a window frame.
Window
frame
<Wall Attachment>
Install on a wall or outside of a window frame.
Window
frame
■Installation and Detaching
<Side Bracket Type>
(1)Determine the mounting positions of the
brackets while ensuring that the dimension
between the brackets is the same as the
width of the product that you ordered.
* In the case of Mytec 01 Loop (right operation) and
Mytec 01, install the brackets so that the bracket
shown at right is on the left side.
*In the case of Mytec 01 Loop (left operation),
install the brackets so that the bracket shown at
right is on the right side.
(2)Install the brackets using the fixing screws.
Use fixing screws that are suitable for the
strength and the material of the wall or
window frame to which the brackets are to
be fixed. Be sure to install each side
holder using at least two fixing screws.
Caution
Product Width
<Mytec 01 Loop (right operation)/ Mytec 01>
<Mytec 01 Loop (left operation)>
Ceiling
Wall
P. 7
1) Pull down the screen about 5 and 10 cm, then
insert the dowel (transparent) at the end of
the screen into Side Holder (right side).
*In the case of Mytec 01 Loop (left operation), insert
the protrusion into Side Holder on the left side.
2) Install the black knob on roll screen body to
Side Holder (left side) to ensure that the red
part is visible at the front. Once the screen is
correctly in place, turn the dial in the “CLOSE”
direction until it clicks.
3) In the case of Mytec 01 Loop, set the screen so
that the position of the ball chain cover is at the top.
* Push the tab on the ball chain cover to the side
opposite the screen, and while keeping it pressed,
turn the cover through 90°.
* In the case of Mytec 01 Loop, set the chain as
the position of Chain Connector is located on the
rear side, then attach Chain Connector is about 3
cm below Bottom Bar.
(3)Install the screen.
* The illustration applies to the case of Mytec 01 Loop
(right operation)/Mytec 01.
(4)Finally, open and close the screen two or three
times, and check the operation and speed at
which the screen ascends and descends.
(5)How to remove the screen
1) Pull down the screen between about 5 and
10 cm and stop it in that position.
2) Turn the dial on Side Holder (left side) in the
“OPEN” direction until it stops.
* In the case of Mytec 01 Loop (left operation), the
dial is on the right side.
3) Grasp the product with both hands, and slowly
remove it.
* In the case of Mytec 01 Loop, take care that the
chain does not drop.
Dowel
(transparent)
Dowel
(transparent)
About 3cm
Chain Connector
About 5-10cm
<Ceiling Attachment>
<Mytec 01 Loop> <Mytec 01>
<Wall Attachment>
Ball chain cover
Ball chain cover
Push this tab to the side opposite
the screen, and while keeping it pressed,
turn the cover through 90°.

P. 8
Use mounting screws that are suitable for the
strength and the material of the wall or window
frame to which the brackets are to be fixed.
Caution
4-7 cm
Bracket
4-7 cm
Set Bar Set Bar
Bracket
Set Bar
Set BarBracket
Hook
Hook
(1)The optimum mounting position for the brackets
is between about 4 and 7 cm inward of both
ends. If three brackets are used, install them at
equal intervals.
(2)Install Brackets on the window frame or wall.
You can temporarily fix the brackets by using
the tape for temporary positioning provided.
(3)Attach Set Bar to the temporary fixing hook,
then push it to fix it in place.
(4)In the case of Mytec 01 Loop, set the screen
so that the position of the ball chain cover is at
the top.
* Push the tab on the ball chain to the side opposite
the screen, and while keeping it pressed, turn the
cover through 90°.
(5)Finally, open and close the screen two or three
times, and check the operation and speed at
which the screen ascends and descends.
(6)To remove Set Bar, push the tab on the
bracket 1), and while holding it pressed, pull
the set bar toward you 2).
* Before removing the screen, refer to P.7 (5) How
to remove the screen.
<Set Bar Type>
1)
2)
1)
2)
<Ceiling Attachment><Wall Attachment>
<Ceiling Attachment><Wall Attachment>
Ball chain cover
Ball chain cover
Push this tab to the side opposite
the screen, and while keeping it pressed,
turn the cover through 90°.
Bracket
Bracket
P. 9
■Installing/Removing the Pull Ball Set (Mytec 01 only)
(1)Remove Weight Bar Cap on one side from
Weight Bar.
(2)With the fixing lever facing the rear (window
side), insert Pull Ball Set into Weight Bar.
(3)Align the position of Pull Ball Set with the
center of Weight Bar, then push down the
fixing lever at the rear of Pull Ball Set to fix the
Pull Ball Set in place.
(4)To remove Pull Ball Set, carry out the
installation procedure in reverse((3)→(2)→
(1)). Center of Weight Bar
Pull Ball Set
Pull ball
Weight Bar
Weight Bar Cap
Fixing lever
* Rear (window side)
Push down
the fixing lever

P.10
How to Operate
<Mytec 01 Loop>
<Mytec 01>
To operate the blind, grasp the pull ball with your hand, and move it in the vertical
direction. Be sure to set the pull ball at the center of Weight Bar. If the pull ball does
not coincide with the center, or if you move it obliquely, trouble is likely to occur.
■How to close a screen
●
By pulling the pull ball directly downward and then
releasing it, the screen will stop at that position.
■How to open a scresn
●
By pulling down the pull ball a distance of about 5
to 6 cm and then releasing it, the screen will rise.
* If you pull down the screen hard, for example, the screen is likely to
overrun, and may fail to rise again. In such a case, turning Roller
Pipe slightly by hand will enable the screen to be rolled up.
* When the room temperature is low, such as during winter, the speed
at which the screen rises may slow down. Please note, however,
that this does not mean that the blind is broken. Turn by hand
Roller
Pipe
Screen
Caution
Caution
Make sure to pull Ball Chain slowly when using the product. If Ball Chain is pulled quickly,
the product may not roll up properly.
Please do not hang from the screen or the ball chain. The product may fall down.
■How to close a screen
●Pull the back side of Ball Chain downward.
■How to open a screen
●Pull the front side of Ball Chain downward.
Fixing over run
Pull ball Pull ball
Pull Pull
P. 11
■How to adjust the stop position
(1)First, set the screen in the fully rolled up con-
dition.
(2)Turn the dial of the stop controller on Side
Holder (right side) to the rear, and lower the
screen to the desired height. Turning the dial
toward you causes the screen to rise.
(3)Pull the pull ball, and open and close the
screen several times. If the stop position is
incorrect, carry out fine adjustment by turning
the dial.
Do not raise and lower the screen by turning the screen or Roller Pipe because
this may damage the blind.
Caution
●Stop Controller is optional parts and it can be stopped at a predetermined height. Use this
function when you wish to stop the screens of connected windows at the same height, for
example.
<Ceiling Attachment> <Wall Attachment>
Lower the screen
Stop controller dial
Raise the screen
How to Use a Stop Controller (Optional)/Mytec 01 Only

P.12
How to Adjust the Screen Operation Force and the Ascent Speed
<Mytec 01 Loop>
■Lighter roll up
<Right operation>
●Turn Winder 1-2 times clockwise while pulling
Winder as directed and unlocking the speed.
<Left operation>
●Turn Winder 1-2 times counter- clockwise while
pulling Winder as directed and unlocking the
speed.
<Left operaion>
●Turn Winder 1-2 times clockwise while pulling
Winder as directed and unlocking the speed.
■Heavier roll up
<Right operation>
● Turn Winder 1-2 times counter- clockwise while
pulling Winder as directed and unlocking the
speed.
(1)Remove the screen.
* Refer to P.7 (5) How to remove the screen.
(2)Align Winder provided with the black knob on
the screen that you removed, then carry out
adjustment as described below.
Winder
Black knob
While pulling
Turn
counter- clockwise
While pulling
Turn
clockwise
While pulling
Turn
clockwise
While pulling
Turn
counter- clockwise
Winder does not turn if not pulled to unlock direction as illustrated.
Do not turn more than twice at once.
Caution
Hold Winder securely especially while pulling to unlock direction. If Winder is released
while pulled to unlock direction, Roller Pipe blows off Winder, and it may cause accidents
or injuries.
P.13
<Mytec 01>
■Faster roll up
●Turn Winder 1-2 times clockwise while
pulling Winder as directed and unlocking
the speed.
■Slower roll up
●While pulling Winder as directed and
unlocking the speed, turn Winder half a
turn in the clockwise direction and then
1-2 times in the opposite direction.
While pulling
Turn clockwise
Winder does not turn if not pulled to unlock direction as illustrated.
Do not turn more than twice at once.
Caution
(3)To install the screen, follow the procedure set out on P.7 (3).
Hold Winder securely especially while pulling to unlock direction. If Winder is released
while pulled to unlock direction, Roller Pipe blows off Winder, and it may cause accidents
or injuries.
While pulling
Turn counter- clockwise
While pulling
Turn clockwise
half a turn

P.14
Fixing Improper Rolled up Screen
●When a screen is not rolled up properly, it may cause damages to the screen or the product.
TOSO Roller Blinds are inspected and adjusted to operate properly when delivered, however
if a roller blind rolls improperly, follow below instruction.
<What is Improper Rolling?>
1) Screen edge is misaligned.
2) Screen edge touches a side holder.
3) Weight Bar is not horizontal.
■How to fix improper rolling?
(1) Make sure a product is installed correctly.
1) Is a product installed horizontally?
2) Are Brackets placed at correct at position?
3) Has the pull ball been set at the center of
Weight Bar? (In the case of Mytec 01)
* Reinstall the product if it is not installed properly.
(2)In the case of Mytec 01 Loop, pull Ball Chain
slowly so as to lower the screen to the bottom and
stop it there, then roll up the screen once again.
In the case of Mytec 01, pull the pull ball vertically
downward so as to lower the screen to the bottom
and stop it there, then pull down the screen by a
further 3 to 4 cm and release it so that it rises
again.
(3)Repeat the instruction (2) for 2-3 times. Pull the pull ball
vertically
1) Install horizontally
1)
3)
2)
2) Brackets are
placed in
correct
positions
(Refer to P.9)
3) Set the pull ball at the center of
the weight bar (Refer to P.8)
P.15
Troubleshooting
Cleaning
● For regular care, dust with a feather duster or a hand mop.
● To avoid discoloration, avoid cleaning the screen with water or using it in a location
susceptible to splashing water.
Mytec 01 Loop
Mytec 01
Common
Do not disassemble or modify the mechanism inside Roller Pipe.
Caution
PhenomenonModel Actions
●When the screen does not stop
at the desired height, and rolls
down.
●When the screen does not stop
at the desired height, and rolls
up.
● When Ball Chain is pulled, it
does not operate smoothly with
an unusual noise, or does not
operate at all.
●When the screen does not roll
up, or when the roll-up speed
is very low.
●When the screen does not
descend
●
Adjust the operating force by repeat-
edly carrying out the procedure
described in “Lighter roll up” under
<Mytec 01 Loop> on P.12.
●
Adjust the operating force by repeat-
edly carrying out the procedure
described in “Heavier roll up” under
<Mytec 01 Loop> on P.12.
● It is likely that the position of
Ball Chain Cover is incorrect.
Carry out the procedure set
out on P.7 or P.8.
●
Repeatedly carry out the adjust-
ment procedure described in
“Faster roll up” under <Mytec 01>
on P.13.
● It is likely that this is because
the dial of Side Holder is not
fully in the “CLOSE” condition.
Turn the dial in the “CLOSE”
direction until it stops
completely.
