Total TB20036 User manual

TB20036,UTB20036,TB20036-4,TB20036-6,
TB20036-7,TB20036-8,TB20036S
HEAT GUN
2000W
SCAN FOR VIDEO TOTAL TOOLS WORLD

Double insulated for additional protection.
Read the instruction manual before using.
CE conformity.
Wear safety glasses, hearing protection and dust mask.
Waste electrical products should not be disposed of with household waste.
Please recycle where facilities exist. Check with your Local Authority or
retailer for recycling advice.
Safety alert.
Please only use the accessories supported by the manufacturer.
2

.Failure to
follow the warnings and instructions may result in electric shock, fire and/or
serious injury.
The term "power tool" in the warnings refers to your mains-operated (corded)
power tool or battery-operated (cordless) power tool.
a) Cluttered and dark areas invite
accidents.
b)
Power tools
create sparks which may ignite the dust or fumes.
c)
Distractions can cause you to lose control.
a)
Unmodified plugs and matching outlets will
reduce risk of electric shock.
b)
There is an increased
risk of electric shock if your body is earthed or grounded.
c) Water
entering a power tool will increase the risk of electric shock.
d)
Damaged or entangled cords
increase the risk of electric shock.
e)
Use of a cord suitable for outdoor use
reduces the risk of electric shock.
f)
3

Use of an RCD
reduces the risk of electric shock.
a)
A moment of inattention while operating power tools may result in
serious personal injury.
b)
Protective equipment such as dust mask, non-skid safety shoes,
hard hat, or hearing protection used for appropriate conditions will
reduce personal injuries.
c)
Carrying power tools with your
finger on the switch or energizing power tools that have the switch on
invites accidents.
d)
A wrench or a key left attached to a rotating part of the
power tool may result in personal injury.
e)
This enables better control of the power tool in unexpected
situations.
f)
Loose
clothes, jewellery or long hair can be caught in moving parts.
g)
Use of dust collection can reduce dust-related hazards.
a)
The correct power tool will do the job better and safer at
the rate for which it was designed.
b)
Any power tool that cannot be controlled with the switch is dangerous
4

and must be repaired.
c)
Such preventive
safety measures reduce the risk of starting the power tool accidentally.
d)
Power tools are dangerous in the hands of
untrained users.
e)
Many accidents are caused by poorly maintained
power tools.
f) Properly maintained cutting tools
with sharp cutting edges are less likely to bind and are easier to control.
g)
Use of the power tool for
operations different from those intended could result in a hazardous
situation.
a)
Exposure to noise can cause hearing loss.
Loss of control can cause
personal injury.
Cutting accessory contacting a "live" wire may make exposed metal parts of the
power tool "live" and could give the operator an electric shock.
This will ensure that the safety of the power tool is
maintained.
5

Residual risks
Even when the power tool is used as prescribed it is not possible to
eliminate all residual risk factors. The following hazards may arise in
connection with the power tool’s construction and design:
a) Health defects resulting from vibration emission if the power tool is being
used over longer period of time or not adequately managed and properly
maintained.
b) Injuries and damage to property to due to broken accessories that are
suddenly dashed.
Warning! This power tool produces an electromagnetic field during
operation. This field may under some circumstances interfere with active or
passive medical implants. To reduce the risk of serious or fatal injury, we
recommend persons with medical implants to consult their physician and the
medical implant manufacturer before operating this power tool.
6

Caution! Read carefully this instruction and the separate safety instructions, to
reduce the risk of electric shock, other injury or fire before using the HOT AIR
GUN.
1. Safety instructions:
Never use the equipment as a hair dryer.
Never block the air inlet or outlet.
If the supply cord isdamaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard..
Do not use the equipment in an explosive atmosphere (danger of explosion).
Improper use can lead to fire.
Do not aim the airflow directly at people or animals.
Before putting the equipment away after use, letit cool down completely.
When not in use, always store the equipment in a dry place, locked away and
inaccessible to children.
After using the equipment, place it down with the nozzle upward and before
storing letit cool down completely.
Never leave the gun unattended when it is switched on. Keep an eye on
children.
A fire may result if the appliance is not used with care, therefore
be careful when using the appliance in places where there are combustible
materials.
Do not apply to thesame place for a long time.
Be aware that heat may be conducted to combustible materials that are out of
sight
1
2
1: Nozzle
2: Housing
3: Switch
4: Cable sleeve
3
4
7

2. Technical Specifications
3. Some applications:
Item No.
Voltage
Power consumption max
Adjustable temperature
Airflow
TB20036
220-240V~50/60Hz
2000W
480ºC/560ºC
250/380 L/min
• Removing paint /dissolving adhesives.
• Shaping plastic tubing.
• Welding plastics.
• Shrink heat fitting.
• Defrosting water pipes.
UTB20036
110-120V~50/60Hz
2000W
480ºC/560ºC
250/380 L/min
Item No.
Voltage
Power consumption max
Adjustable temperature
Airflow
TB20036-6TB20036-4
(ISRAEL Plug)
TB20036-7
(CHILE Plug)(IRAM Plug)
TB20036-8
(BS Plug)
TB20036S
(SAA Plug)
4. Putting into operation
The gun starts operating when the switch is pushed upward to po
The blower stops working when the switch is pushed downward of
It can be packed when it is cooled down.
Operation
Switching on:
Slide the switch to I,II . I:250L/min 50ºC-480ºC constant II:380L/min 50ºC-560ºC.
The appliance is not intended for use by persons (including children) with reduced
physical sensory or mental capabilities, or lack of experience and knowledge,unless
theyhave been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
5. Maintenance
Please recycle where facilities exist. Check with your local authority or
retailer for recycling advice.
• For safe and proper working, always keep the ventilation slots clean.
• Waste electrical products should not be disposed of with household waste.
8

Children should be supervised to ensure that they do not play with the appliance.
Do not dispose of electrical appliances as unsorted municipal waste, use separate collection facilities.
Contact you local government for information regarding the collection systems available.
If electrical appliances are disposed of in landfills or dumps, hazardous substances
can leak into the groundwater and get into the food chain, damaging your health and
well-being.
When replacing old appliances with new ones, the retailer is legally obligated to take
back your old appliance for disposals at least free of charge.
9

TB20036,UTB20036,TB20036-4,TB20036-6,
TB20036-7,TB20036-8,TB20036S Exploded view
10

NO. Part Description Qty
1 Screw ST2.9X16 8
2 right Housing 1
3 circlip 1
4 rivet 1
5 spring 1
6 heating wire assembly 1
7 Motor fixture 1
8 Bolt M3x5 3
9cable sleeve 1
10 Power cord 1
11 Wind balde 1
12 Bolt M2.5x5 2
13 Motor holder 1
14 Screw ST2.9X10 2
15 Motor fixture 1
16 Switch button 1
17 PCB 1
18 Screw ST4.1X16 2
19 anchorage 1
20 left Housing 1
TB20036,UTB20036,TB20036-4,TB20036-6,
TB20036-7,TB20036-8,TB20036S Spare part list
11

T0222.V03
MADE IN CHINA
www.totalbusiness.com
TOTAL TOOLS CO., PTE. LTD.
No. 45 Songbei Road
, Suzhou Industrial Park , China.
2000W
HEAT GUN
