TOTALINE P360-1320 User manual

Operating
Manual
P360 -132 0
Wireless Thermostat
Thermostat Sans Fil
Termóstato inalámbrico
570-248
Operating Manual
69-2440EFS-01
®

M28450A
Read and save these instructions.
Need Help?
Visit www.Totaline.com
® U.S. Registered Trademark. Patents pending.
All rights reserved.
Battery Holder
Press down and pull to
remove batteries.
Batteries should be
replaced once a year
(see page 16).
Quick Reference
Card
Grasp and pull to
see basic operating
instructions at a
glance.
CAUTION: EQUIPMENT DAMAGE HAZARD. To prevent possible compressor damage,
do not operate cooling system when outdoor temperature is below 50°F (10°C).

Français : voir la page 20 • Español: vea la página 40
570-248 1 69-2440EFS—01
Contents
About your new thermostat
Programming at a glance.................. 2
Quick reference to controls .............. 3
Quick reference to display ................ 4
Programming & Operation
Set time and day ............................... 5
Fan settings (auto/on) ....................... 6
System settings (heat/cool ............... 7
Program schedules ........................... 8
Program schedule overrides........... 10
Auto-changeover (heat/cool) .......... 12
Remote control................................ 13
Display outdoor climate .................. 14
Find lost remote control.................. 14
Special features............................... 15
Appendices
Battery replacement........................ 16
In case of difficulty.......................... 18
Warranty........................................... 18
Regulatory information.................... 60

Operating Manual
69-2440EFS—01 2 570-248
About your new thermostat
Your new thermostat is pre-programmed and ready to go. All you have to do is
set the time and day. Then check the settings below and change if needed:
Set time and day (required for proper operation)1. ............. See page 5
Select fan setting (Auto/On)2. .................................................. See page 6
Select system setting (Heat/Cool)3. ....................................... See page 7
Program schedules:4. Preset to energy-saving levels
while you’re at work or asleep (assumes you
wake at 6 am, leave at 8 am, return at 6 pm
and go to bed at 10 pm)....................................................... See pages 8-9
CAUTION: EQUIPMENT DAMAGE HAZARD. You can override the program schedule at
any time, and manually adjust the temperature (see pages 10-11).

Français : voir la page 20 • Español: vea la página 40
570-248 3 69-2440EFS—01
Quick reference to controls
M28451A
Digital display (see page 4) Battery holder (see page 16)
Temperature buttons
Press to adjust temperature
settings (see page 9–11)
Hold button
Press to override programmed
temperature control (see page 11)
Function buttons
Press to select the function displayed just above each button.
(Functions change depending on the task.)

Operating Manual
69-2440EFS—01 4 570-248
Auto
Wake
Fan
Clock/Day
Schedule
Set
Aux Heat On
System More
Heat
AM
Heat
Setting
M28452
Indoor Recovery
75
75
6:30
Replace Battery
Quick reference to display screen
Current inside temperature Low battery warnings
(see pages 16–17)
Temperature setting
(see pages 9–11).
Current time/day
(see page 5)
Recovery
(see page 15)
Current program
period
Wake/Leave/Return/
Sleep (see pages 8-9)
Set Clock/Day/
Schedule
(see pages 5 and 9) More
Press to view outdoor climate (if
outdoor sensor is installed), or to
find a misplaced remote control if
installed (see page 14)
Auxillary heat
(Only for heat pumps
with auxillary heat)
System status
Heat On/Cool On
(If flashing, see page 15)
System setting
Heat/Cool/Auto/Off/Em
Heat (see page 7)
Fan Setting
Auto/On (see page 6)

Français : voir la page 20 • Español: vea la página 40
570-248 5 69-2440EFS—01
Set the time and day
Press1. SET CLOCK/DAY/SCHEDULE,
then press sor tto set clock.
Press2. SET DAY, then press sor
tto select the day of week.
Press3. DONE to save.
Auto
Fan
Clock/Day
Schedule
Set System More
Heat
PM
M28453
4:30
DaySchedule
Wed
Done
Set Set
M28454
Note: If the SET CLOCK/DAY/SCHEDULE
option is not displayed, press DONE or
CANCEL.
Note: If the display flashes Set Clock,
the thermostat will follow your settings
for the weekday “Wake” time period
until you reset the time and day.
Press SET DAY, then select current day
Press SET CLOCK/DAY/SCHEDULE, then adjust time

Operating Manual
69-2440EFS—01 6 570-248
Select the fan setting
In “Auto” mode (the most commonly
used setting), the fan runs only when the
heating or cooling system is on.
If set to “On,” the fan runs continuously.
Press FAN to select Auto or On.
Auto
Fan
Clock/Day
Schedule
Set System More
Heat
M28455
Clock/Day
Schedule
Set
On
FanSystem More
Heat
M28456
Note: Options may vary
depending on your heating/
cooling equipment.

Français : voir la page 20 • Español: vea la página 40
570-248 7 69-2440EFS—01
Select the system setting
Auto
Fan
Clock/Day
Schedule
Set System More
Heat
M28457
Auto
Fan
Clock/Day
Schedule
Set System More
Cool
M28458
• Heat:Thermostat controls only the
heating system.
• Cool:Thermostat controls only the
cooling system.
• Off:All systems are off.
• Auto:Thermostat automatically
selects heating or cooling depending
on the indoor temperature.
• Em Heat: (only for heat pumps with
auxiliary heat): Thermostat controls
Emergency and Auxiliary Heat.
Compressor is locked out.
Press SYSTEM to select:
Note: Options may vary
depending on your heating/
cooling equipment.

Operating Manual
69-2440EFS—01 8 570-248
Energy saving settings
This thermostat is preset with energy saving program settings. We recommend
these settings, since they can reduce your heating/cooling expenses by as much
as 33%. (See next page to adjust times and temperatures of each time period.)
Wake
(6:00 am)
Leave
(8:00 am)
Return
(6:00 pm)
Sleep
(10:00 pm)
Cool (Mon-Fri)Heat (Mon-Fri) Heat (Sat-Sun) Cool (Sat-Sun)
70 °78 °70 °78 °
62 °85 °62 °
[Or cancel period]
85 °
[Or cancel period]
70 °78 °70 °
[Or cancel period]
78 °
[Or cancel period]
62 °82 °62 °82 °

Français : voir la page 20 • Español: vea la página 40
570-248 9 69-2440EFS—01
To adjust program schedules
1. Press SET CLOCK/DAY/SCHEDULE, then SET
SCHEDULE.
2. Press s or t to set your weekday Wake
time (Mon–Fri), then press NEXT.
3. Press s or t to set the temperature for this
time period, then press NEXT.
4. Set time and temperature for the next time
period (Leave). Repeat steps 2 and 3 for each
weekday time period.
5. Press NEXT to set Weekend time periods (Sat-
Sun), then press DONE to save & exit.
Note: Make sure the thermostat is set to the
system you want to program (Heat or Cool).
M28459
Day
Done
Schedule
SetSet
Auto
Fan
Clock/Day
Schedule
Set System More
Heat
Cancel
Period
Mon Tues Wed Thur Fri
Wake
Done Next
AM
Heat
Setting
70
6:00
Set Schedule

Operating Manual
69-2440EFS—01 10 570-248
Auto
FanCancel System More
Heat
PM
Heat
Setting
M28460
Indoor
75
75
6:00
Hold Until
Program schedule override (temporary)
Press sor tto immediately
adjust the temperature. This
will temporarily override the
temperature setting for the current
time period.
The new temperature will be
maintained only until the next
programmed time period begins
(see page 8).
To cancel the temporary setting at
any time, press CANCEL.
Press to resume
program schedule
Temperature will be
maintained until the
time shown
Press to temporarily adjust temperature.

Français : voir la page 20 • Español: vea la página 40
570-248 11 69-2440EFS—01
Auto
FanCancel System More
Heat
PM
Heat
Setting
M28461
Indoor
75
75
6:00
Hold
Program schedule override (permanent)
Press HOLD to permanently adjust
the temperature. This will override
the temperature settings for all
time periods.
The “Hold” feature turns off the
program schedule and allows you
to adjust the thermostat manually,
as needed.
Whatever temperature you set
will be maintained 24 hours a day
until you manually change it, or
press CANCEL to resume the pro-
grammed schedule.
Press to permanently adjust temperature.
Press to resume
program schedule

Operating Manual
69-2440EFS—01 12 570-248
Auto Changeover is a feature used in climates
where both air conditioning and heating are
often used on the same day. When the system
is set to Auto, the thermostat automatically
selects heating or cooling depending on the
indoor temperature.
Heat and cool settings must be at least 3
degrees apart. The thermostat will automati-
cally adjust settings to maintain this 3-degree
separation.
Auto Changeover
Auto
Auto
Fan
Clock/Day
Schedule
Set System More
M28462
Press until screen
displays “Auto”
Note: The Auto system setting
may not appear, depending
on how your thermostat was
installed.

Français : voir la page 20 • Español: vea la página 40
570-248 13 69-2440EFS—01
Temperature is measured at
location of remote control
Remote control
Note: The thermostat may take up to 15 seconds to respond to commands entered
at the remote control. See Remote Control Operating Manual for more information.
at Thermostat
Reading
at Remote
Remote has Control
M28463
72
75
Auto
FanCancel More
The optional remote control can act
as a mobile thermostat, to maintain a
comfortable temperature as you move
from room to room.
When the system is responding to
temperatures measured at the Remote,
the thermostat will display “Remote has
Control.”
Press CANCEL to restore temperature
control to the thermostat (the system will
only respond to temperatures measured at
the thermostat).

Operating Manual
69-2440EFS—01 14 570-248
Auto
Fan
Clock/Day
Schedule
Set System More
Heat
M28464
FindRemote
Done
%
Outdoor
Humidity
Outdoor
85
50
M28465
Additional features
To display outdoor climate
If you have an outdoor air sensor, press
MORE to display the current outdoor tem-
perature and humidity. Press DONE to exit.
To find a lost remote control
If you misplace a remote control, press
MORE, then FIND REMOTE. The remote will
beep for two minutes to help you locate it.
Press anywhere on the display screen to
stop the beeping.
Press to display
more options
Press to find a lost
remote control
Outdoor
humidity
Outdoor
temperature

Français : voir la page 20 • Español: vea la página 40
570-248 15 69-2440EFS—01
Built-in compressor protection: This feature helps prevent damage to the
compressor in your air conditioning or heat pump system. Damage can occur
if the compressor is re-started too soon after shutdown. This feature forces the
compressor to wait for a few minutes before restarting.
During the wait time, the display will flash the message Cool On (or Heat On if
you have a heat pump).
Early Recovery: This feature eliminates the guesswork when setting your
schedule. It allows the thermostat to “learn” how long your furnace and air
conditioner take to reach programmed temperature settings, so the temperature
is reached at the time you set.
Special features
Note: When Early Recovery is in effect, the thermostat will display
“Recovery.”

Operating Manual
69-2440EFS—01 16 570-248
M28466A
Battery replacement
M28442M
28
44
2
Replace Battery
Install fresh batteries when the REPLACE
BATTERY warning begins flashing. The
warning flashes about two months before
the batteries are depleted.
Remove the battery holder and install 2 fresh
AA alkaline batteries.
After batteries are installed, the thermostat
will automatically restore communication
with the wireless network within a few
minutes.
Press down and pull to remove.
Insert fresh AA alkaline
batteries, then reinstall
battery holder.
Note: If batteries are inserted within 2 minutes,
the time and day will not have to be reset. All
other settings are retained in memory.

Français : voir la page 20 • Español: vea la página 40
570-248 17 69-2440EFS—01
Battery replacement (outdoor air sensor)
M28443A
M28444M2
8
444
Replace outdoor sensor batteries when the
REPLACE BATTERY OUTDOOR warning begins
flashing on the thermostat. The warning
flashes about two months before the
batteries are depleted.
Remove the sensor from the bracket,
remove the cover and install 2 fresh AA
lithium batteries.
After batteries are installed, the sensor will
automatically restore communication with
the wireless network within a few minutes.
Remove sensor
from bracket
Remove cover and
install 2 fresh AA
lithium batteries

Operating Manual
69-2440EFS—01 18 570-248
In case of difficulty
Heating or
cooling system
does not respond
• Check circuit breaker and reset if necessary.
• Make sure power switch at heating & cooling system is on.
• Make sure furnace door is closed securely.
• Wait 5 minutes for the system to respond.
Screen displays
“No Signal”
Thermostat has lost radio contact with the wireless network (usually
because of a power outage). To restore power:
• Check circuit breaker and reset if necessary.
• Make sure power switch at heating & cooling system is on.
• Make sure furnace door is closed securely.
After power is restored, the thermostat will automatically restore wireless
communication within a few minutes.
FIVE-YEAR WARRANTY—This CARRIER CORPORATION product is warranted to be free from defects in material and work-
manship under normal use and maintenance for a period of five years from the date of original installation. A new or remanu-
factured part to replace the defective part will be provided without charge for the part itself, through a qualified servicing
CARRIER CORPORATION dealer or service, provided the defective part is returned to our distributor. The replacement part
assumes the unused portion of the warranty.
THIS WARRANTY DOES NOT INCLUDE ANY ADDITIONAL LABOR ALLOWANCE OR OTHER COSTS incurred for diagnosis,
Limited Five-Year Warranty
