TOTALINE 1 For All User manual

OWNER'S MANUAL
P/N P374-2200
Commercial Systems & Services Carrier Corporation 05/02
7 Day programmable
Pre-Programmed
Occupied Comfort
Unoccupied Energy
Savings
Auto Changeover
Easy To Read Display
Thermoglow Backlight
Multi-Stage, One for All
3 Security Levels
Use with most Air Conditioning & Heating Systems including: 1 or 2 Stage
Electric Cooling & Gas Heating, Heat Pump, Electric or Hydronic Heat.
*
*
TOTALINE
Programmable
Digital Thermostat
1 For All
68
74
HEAT
COOL
o
o
Am
6:03
68
Su
TOTALINE
Meets California Title 24
OCCUPIED 1

Table Of Contents
FRONT PANEL
DISPLAY
QUICK START Set the clock and go
BASIC OPERATION
PROGRAMMING Occupied / Unoccupied
ADVANCED SETUP
ABOUT ADVANCED OPERATION
WARRANTY
Page 1
CAUTION
Follow Installation Instructions before proceeding.
SET THERMOSTAT TO MODE “OFF” PRIOR TO
CHANGING SETTINGS IN SETUP OR RESTORING
FACTORY DEFAULTS.
2
3
5
6
8
12
16
20
Commercial Systems & Services Carrier Corporation 05/02
P/N P374-2200

68
74
HEAT
COOL
o
o
Am
6:03
68
Su
TOTALINE
OCCUPIED 1
Front Panel
Page 2
Backlit LCD Display
Warmer or + Button
Cooler or - Button
Override Button
Heat or Cool Indicator
Red = Heat, Green = Cool
67
70
HEAT
COOL
AUTO
o
o
Am
6:03
68
S
Programmable
Thermostat
PROGRAM SET CLOCK HOLIDAYFAN
ProgramHoliday
Fan Set Clock Override Mode
MODE

1
2
4
3
Mode Indicators
Selects the operation mode of the equipment.
HEAT - indicates the heat mode.
COOL - indicates the air conditioning mode.
AUTO - indicates the system will automatically
changeover between heat and cool modes
as the temperature varies.
OFF - indicates the entire system is turned off.
PROGRAM ON - indicates the stored program
is enabled to run. Page 6.
Clock with Day of the Week
Indicates the current time and day. This clock is
also used to program the timer periods. Page 5.
Room Temperature Display
Indicates the current room temperature.
Desired Set Temperature
Indicates desired room temperature(s). Page 7.
Display
Page 3
1
1
1
3
4
4
7
9
10
6
88
88
HEAT
COOL
OFF
AUTO
Program
Locked
unoccupied123
Setup
On
StartStop
o
o
Am
Pm
i2 00
88
:
5
SuMTuWThFSa
Fan On
Service Filter
Override
2
8
1

5
6
7
9
10
Override Indication
Indicates the current program is currently being
overridden for up to 4 hours. Page 7,16.
Occupied or Unoccupied Indication
Indicates the program number: Occupied 1,2,3,
or Unoccupied. Page 8-11.
Setup Indication
Indicates the thermostat is in the programming
mode. Page 12.
Locked Indication
Locked appears after the right combination of
buttons are pressed, rendering the buttons
inoperative. Page 18.
Start / Stop Indication
Start or Stop appears when programming
timer functions. Page 9.
Fan Operation Indication
Fan On - indicates constant, continuous fan
operation.
When Fan On is not lit - indicates the fan will
only operate when necessary to heat or
to cool. Page 12.
Display
Page 4
8

Quick Start Set the Clock and Go
Page 5
Press the SET CLOCK
button.
Press the SET CLOCK
button as above to
return to normal
operation.
This thermostat is preprogrammed from the
factory to operate 1 or 2 Stage equipment without
the need for further programming. To optimize the
installation of this thermostat follow the instructions
in the Advanced Setup section.
* The thermostat is not preprogrammed from the
factory to operate electric heat or heat pump systems.
To control these systems, follow the steps in the
Advanced Setup section, pages 12 & 13.
2
Setup
M
buttons.
To adjust the
clock or Day use
Press
Setup
Am
12:00 i
:
SET CLOCK
SET CLOCK
MODE
During Setup & Programming:
Pressing the Mode button
selects different flashing items.
(Represented in dark black)
Pressing the Up and Down
buttons will modify the flashing
selection.

Basic Operation
Page 6
The HEAT setting indicates the
temperature the room has to
reach before the furnace will
turn on to heat the room.
The COOL setting indicates the
temperature the room has to
reach before the air conditioner
will turn on to cool the room.
OFF indicates both heating
and air conditioning
systems are turned off.
AUTO will automatically select
heat or cool based on room
temperature demand.
Program On will activate the
stored timer operation.
(Occupied or
Unoccupied Periods)
Select Mode
69
HEAT
o
Pm
12:00
70
M
:
72
COOL
o
Pm
12:00
70
M
:
69
72
HEAT
COOL
AUTO
o
o
Pm
12:00
70
M
:
OFF
Pm
12:00
70
M
:
70
73
HEAT
COOL
Program On
o
o
Pm
12:00
70
Occupied 1
M
:
Press
MODE
Press
Press
Press
MODE
MODE
MODE

Override
Page 7
Basic Operation
During programmed, unoccupied periods
a press of the Override button will force
the thermostat into Occupied 1 comfort
settings, temporarily, for 30 minutes.
Pressing the override button when the
countdown timer is less than 30, will
reset the timer to 30 minutes. If the timer
displays 30 minutes, the next press will
zero out the override timer, returning
to unoccupied.
When in Override, the Override icon and
the Occupied 1 icon appear on the display.
The time of day clock alternates with the
time remaining in override.
During Override, the setpoints are
adjustable, provided the keypad is not
locked.
Press
OVERRIDE
unoccupied
Occupied 1
Override
Pm
Pm
0:30
I2:00
buttons.
In any mode, adjust the
desired Set Temperature
with
Pressing the up/down buttons in Auto mode will adjust both the heat and cool
set temperatures simultaneously.
Pressing the up/down buttons in Heat or Cool modes will adjust only the
heat or cool set temperature.
Select Desired Temperature
69
72
HEAT
COOL
AUTO
o
o
Pm
12:00
70
M
:
55
72
85
74
HEAT
HEAT
COOL
COOL
o
o
o
o
Pm
I2:00
65
65
M
M

Programming Occupied & Unoccupied Periods
Page 8
Press
Press
Press
Press
Continued
Select the maximum # of
occupied periods to be
used on any one day.
Typically 1.
(1,2 or 3)
Adjust the cooling
setpoint for occupied 1.
Adjust the cooling
setpoint for unoccupied
periods.
Adjust the heating
setpoint for occupied 1.
(35 - 99 )
(35 - 99 )
(35 - 99 )
MODE
MODE
MODE
MODE
occupied 1
74
occupied COOL 1
74
72
occupied COOL
HEAT
1
85
unoccupied
COOL
Press the PROGRAM button to enter time period programming.
Press
PROGRAM

MODE
Programming Occupied & Unoccupied Periods
Page 9
Press
Press
Press
Press
Press
Continued
Adjust the heating set-
point for unoccupied
periods.
(35 - 99)
Select the day for
Occupied 1.
Adjust the stop time
for occupied 1.
Select Occupied 1 to run
on this day (On), or not to
run this day (Off).
Adjust the start time
for occupied 1.
(M - Su)
Off
On
MODE
MODE
MODE
MODE
65
unoccupied
HEAT
occupied
M 1
occupied
Am Start
M 1
7:00
occupied
Pm Stop
M 1
6:00
occupied
ON
M 1

Programming Occupied & Unoccupied Periods
Page 10
Press
Press
Press
Press
Press
Continued
Adjust the start time
for occupied 1.
Adjust the stop time
for occupied 1.
Select the day
for occupied 1.
Select Yes or No to copy
the previous day’s
program to this day.
Yes
No
If Yes is selected:
If No is selected:
Selecting Yes, then pressing mode will copy the
previous day’s program and then will ask the
same copy question again. If yes is selected
each time, this routine will repeat until Saturday
is copied to Sunday. After Saturday is copied
to Sunday, the copy command is unavailable.
The copy command becomes available after the maximum # of
occupied periods are programed in a day. This example uses 1
as the maximum occupied periods ever programed in one day.
(Tu - M)
MODE
MODE
MODE
MODE
MODE
Co Py
Tu
No
occupied
Tu 1
Occupied
Am Start
Tu 1
9:00
Occupied
Pm Stop
Tu 1
5:00

Programming Occupied & Unoccupied Periods
Page 11
Press
Select Occupied 1 to run
on this day (On), or not to
run this day (Off).
Off
On
Press
Select Yes or No to copy
the previous day’s
program to this day.
Yes
No
Press
If Yes is selected: If No is selected:
Selecting Yes, then pressing mode will copy the
previous day’s program and then will ask the
same copy question again. If yes is selected
each time, this routine will repeat until Saturday
is copied to Sunday. After Saturday is copied
to Sunday, the copy command is unavailable.
If no is selected, as in previous steps flashing prompts for input will appear for
start and stop times for Occupied 1. If more than one occupied period was
selected in step 1 on page 8, then cool/heat setpoints, and start/stop times
for additional occupied periods will be prompted.
PROGRAMMING NOTES
If only 1 Occupied period is selected in step 1 on page 8, Occupied 2 & 3 programming steps are
skipped. Further, if only 2 occupieds are selected, Occupied 3 programming steps are skipped.
Heat & Cool setpoints for Occupied 1 are the same for every day of the week. Heat & Cool setpoints
for Occupied 2 & 3 can be adjusted differently for each day of the week, if desired.
If the start time is set later in the day than the stop time, the program will run from the start time to
midnight and from midnight to the stop time on the same day. For example: 9:00pm start, 8:00am stop,
on Monday. In this example the program will run from 12:00am Monday to 8:00am Monday and again
from 9:00pm Monday to 12:00pm Monday.
The Unoccupied settings take effect at all times when: (1) the program is on and (2) the current time is
If the same start and stop times are programmed in for an occupied period, then it will run 24 hours.
If one occupied period starts and stops within another occupied period the lower occupied # has
priority. For example: If Occupied 3 is programmed to be “on” 24 hours, and Occupied 2 is
programmed to run that day, then Occupied 2 settings will take over from occupied 3 between
Occupied 2 start and stop times.
outside a preset occupied period. For this reason start and stop times aren’t necessary for unoccupied.
MODE
MODE
MODE
Occupied
OFF
Tu 1
Co Py
W
No

Advanced Setup
Page 12
Press
Press
Press
Press
Continued
Press the Mode button.
While holding the Mode,
press the Program button
to enter Setup screens.
NOTE: Each step # is located at
the top right corner of the
display for easy reference.
Steps 1 & 2 are accessed
by pressing Set Clock.
PROGRAM
MODE
MODE
MODE
MODE
MODE
Select reversing
valve type, O or B.
Step 4 only appears
if step 3 is ON.
Select Heat Pump
operation (ON) or,
Gas/Electric
operation (OFF)
3
Setup
4
Setup
Adjust the deadband
from 1 - 6 degrees.
Select Electric Heat ON
or OFF. Step 5 only
appears if step 3 is OFF.
2
eh
o
hp
6
5
Setup
Setup
88
OFF
OFF
ON
O
B
OFF

Advanced Setup
Page 13
Press
Press
Press
Press
Press
Continued
Select the cycles per
hour limit.
d=cycles per hour
limit defeated.
d1=d + defeat 5 min.
Compressor lockout.
(d, d1, 2 - 6)
MODE
MODE
MODE
MODE
MODE
6
8
Cy
Setup
Select the display back-
light always On, or Off
after 8 seconds.
On
Off
L I
9
ON
Setup
Adjust the minimum
difference between
cooling & heating
setpoints.
(0 - 6 )
81f
2
7
COOL
HEAT
Setup
i0
Setup
0
Service Filter
i i
Setup
500
Service Filter
Reset the Service Filter
counter to 0, to remove
the icon from the display.
Press
OVERRIDE
Adjust the number of
hours the blower will
run before the Service
Filter icon appears on
the display. 0 = off.
(0 - 1950)

Advanced Setup
Page 14
Press
MODE
Adjust the minimum
allowable cool setpoint
when security is in effect.
(Step 15 only appears
if step 13 is not 0).
(35 - 99)
65
I5
COOL
Locked
Setup
lo
MODE
PROGRAM
Press
Press the Mode button. While holding the
Mode, press the Program button to enter
Setup screens. If no buttons are press
-ed, the display will leave the setup
screens after 60 seconds.
Adjust the maximum
allowable heat setpoint
when security is in effect.
(Step 14 only appears
if step 13 is not 0).
(35 - 99)
80
I4
HEAT
Locked
Setup
hi
Press
Press
MODE
MODE
Select thermostat
operation in degrees
Fahrenheit or Centigrade.
C
F
F
i2
Setup
Select the security level:
0=no security in effect
1=setpoint range limited
2=1+ program on all times
3=2 + prohibits setpoint
changes
0
I3
Locked
Setup
Sec

Advanced Setup
Page 15
Step # Description Range Factory Default
1 Time of day clock set 24 hour 12:00 Am
2 Day of the week Sun - Sat Monday
3 Heat Pump
4 Reversing Valve Polarity
6
7
8
9
11 Service Filter run time set 0 - 1950 0
12
13
Off / On Off
O / B O
5 Electric Heat Off / On Off
Deadband or Temperature swing 1 - 6 2
Forced minimum difference heat/cool 0 - 6 2
Cycles per hour d, d1, 2 - 6 6
Thermoglow backlight Off / On On
10 Reset Service Filter Icon - - - -
Fahrenheit or Centigrade F / C F
Security Levels 0 - 4 4
14 Maximum allowable Heat setpoint 35 - 99 80
15 Minimum allowable Cool setpoint 35 - 99 65
Advanced Setup Table

About Advanced Features & Operation
Page 16
CLOCK BACKUP - In the event of a power loss, the thermostat
internal clock will continue to keep proper time for a
minimum of 48 hours without external power or batteries.
2 STAGE OPERATION - The 2nd Stage of heat or cool is
turned on when (1) the 1st Stage has been on for a
minimum of two minutes, and (2) the temperature spread
from the setpoint is equal to or greater than: the setpoint
plus the deadband, plus 2 degrees.
Heat
Setpoint
Cool
Setpoint
Dead
Band
Dead
Band
2 degrees 2 degrees
1st Stage
turn on
2nd Stage
turn on
1st Stage
turn on
2nd Stage
turn on
Heating Cooling
MINIMUM HEAT/COOL SETPOINT DIFFERENCE - The Heat
and Cool setpoints will not be allowed to come any closer
to each other than the value set in Advanced Setup step
# 7, on page 13. This minimum difference is enforced
during Auto changeover operation.
and Program On
OVERRIDE - As explained on page 7, pressing the Override
button during a programmed, Unoccupied period will force
the thermostat into Occupied 1, temporarily, for 30 minutes.
If the Override button is pressed during an Occupied
period, the thermostat will be forced into Unoccupied and
occupied # (1,2 or 3), it was forced out of will be
off, only for that day.
During Override periods the setpoints may be adjusted,
but they will not be remembered after Override ends.
the
turned

About Advanced Features & Operation
Page 17
EMERGENCY HEAT - To turn on Emergency Heat press in the
Fan button. While holding the Fan button press
button. The Cool setpoint display
During Emergency Heat the thermostat will turn
on the fan and the 2nd stage of heat, when there is a
demand for heat, locking out the 1st stage compressor.
Exiting Emergency Heat is the same as entering. During
Emergency Heat only OFF and HEAT are available.
Note: Emergency Heat is only available when the
thermostat is controlling a heat pump.
the Up
will read ‘EH’.
Press for
Emergency Heat
FAN
73
eh
74
Am
HEAT
Mo
I2:00
ENERGY SAVING SMART FAN - If Fan On is selected,
the fan will run continuously at all times,except in Off,
and will only run if there is a heating or cooling demand
in Unoccupied periods.

About Advanced Features & Operation
Page 18
KEYPAD LOCK - To prevent unauthorized use of the thermostat,
the front panel buttons may be disabled. To disable, or
‘lock’ the keypad, press and hold in the Mode button.
While holding the Mode button in, press the Up and Down
buttons in together. The Locked icon will appear on the
display.
Press all 3 for
Keypad Lockout
To unlock the buttons, again press and hold the Mode
button. While holding the Mode button in, press the Up
and Down buttons in together. The Locked icon will
disappear from the display.
MODE
85
55
unoccupied
Pm
COOL
HEAT
Locked
We
I2:00
83
ELECTRIC HEAT - Selecting Electric Heat on, page 13,
step 6, will cause the thermostat to turn on the fan
any time there is a heat demand. Since all
control the fan, this feature should be off
is only electric.
immediately
gas furnaces
unless the heater

About Advanced Features & Operation
Page 19
DUAL SETPOINT BEHAVIOR - The adjustable setpoint range
is: 35 - 99 degrees in Fahrenheit and 7 - 35 degrees in
Centigrade. When in the modes Heat or Cool, this
adjustable range is unhampered.
When adjusting any Auto mode, including programming
Occupied and Unoccupied periods, the thermostat will not
allow the Heat setpoint to get closer to the Cool setpoint
than the value programmed as the minimum difference in
step 7, page 13.
When entering the Auto mode from Cool, the Heat and
Cool setpoints will remain spread apart by the amount
that they were adjusted, prior to entering Auto.
For example: If the Cool setpoint was set to 80 while
in the Cool mode and the Heat setpoint was adjusted to
70 while in the Heat mode, upon entering the Auto mode
the Heat and Cool setpoints would be 80 and 70. Both
setpoints would then move up and down together, (in this
example spread by 10 degrees), by pressing the up or
down buttons.
To move the Heat and Cool setpoints closer together,
enter the Cool or Heat mode by pressing the Mode button,
then adjust the setpoint(s) closer together. Heat is limited
to how close it can come to Cool by step 7, page 13.
The above applies if the Security level does not equal 4.
FACTORY DEFAULTS - If, for any reason it is desirable to
return all stored settings back to the factory default
settings, press the Mode button. While holding the Mode
button in, press the Fan button for 5 sec. All icons will
appear. Press and hold in the Fan button until Fd
appears. This resets all factory settings. To return to
normal operation, press the Mode button twice more.
